USER MANUAL 61753 WilTec

8-Door Mailbox System (2 × 4)

60015-60017, 61747, 61753, 61763

XPO the tool experts

Black metal filing cabinet with multiple drawers and a rolled-up paper clip (no visible text or symbols)

Illustration similar, may vary depending on model

Please read and follow the operating instructions and safety information prior to initial operation.

Technical changes reserved!

Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further developments.

The information contained in this document may alter at any time without prior notice. No part of this document may be copied or otherwise duplicated without prior written consent. All rights reserved. WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating manual, nor in the diagrams and illustrations shown.

Although WilTec Wildanger Technik GmbH has made every possible effort to ensure that this operating manual is complete, accurate, and up-to-date, errors cannot be ruled out entirely.

If you have found an error or wish to suggest an improvement, we look forward to hearing from you. Send us an e-mail to:

[e-mail]

or use our contact form:

https://www.wiltec.de/contacts/

The most recent version of this manual in several languages can be found in our online shop:

https://www.wiltec.de/docsearch

Our postal address is:

WilTec Wildanger Technik GmbH Königsbenden 12 52249 Eschweiler – Germany

To return your goods for exchange, repair, or other purposes, please use the following address. Attention! To allow for a trouble-free complaint or return, it is important to contact our customer service team before returning your goods.

Thank you for choosing to purchase this quality product. To minimise the risk of injury, we ask you to always take some basic safety precautions when using this product. Please read this operating manual carefully and make sure that you understand it. Keep these operation instructions in a safe place.

Technical drawing and parts list

Technical diagram of a server rack with numbered components and corresponding labeled parts for assembly or maintenance.

No	Name	No	Name
1	Mailbox	7	Ring covers
2	Frame	8	Floor screw
3	Cross bar	9	Cross bar screw
4	Key and lock	10	Spacer screw
5	Name plate	11	Mailbox screws
6	Spacer

Assembly instructions

Choose a suitable location to place your mailbox system. Make sure that the surface is level and that you can anchor the frame firmly with the floor screws. We recommend that you assemble the mailbox close to where it is to be installed.

• Push the ring covers (7) onto the frame rods (2). Check that the ring is pointing in the correct direction (see fig. 1).
• Connect the frame (2) and the cross bars (3) using the screws (9). Leave the assembly loose and do not fully tighten the screws vet.
• Place the frame in the location that you have chosen and mark the mounting holes for the intended location (lift the ring covers to do this).
• Set the bracket aside and drill holes at the marked locations. Then you can attach the frame (2) with the floor screws (8). Then connect the mailbox unit (1) to each other using the screws (11).
• Now attach the mailboxes (1) with the spacers (6) between the bars of the frame (2). Use the spacer screws (10) for this.
  • Now tighten all the screws and finally attach the name tags (5) to the desired locations.

Close-up of a black cylindrical object with a circular base, resembling a floor or mechanical component (no text or symbols visible)

Figure 1

Technical specifications

Total dimen-sions (mm)	60015	60016	60017	61747	61753	61763
	270 × 770 × 468
Dimensions of foot (mm)	1500 × 50	1500 × 50	1500 × 50	1500 × 49	1500 × 49	1500 × 49
Number of in-dividual boxes	8
