Product Type	4-Door Mailbox System
Model Number	60003 (also compatible with 60004, 60005, 61743, 61752, 61759)
Brand	WilTec
Total Dimensions (mm)	470 × 270 × 385
Foot Dimensions (mm)	1500 × 50
Number of Individual Mailboxes	4
Material	Metal (steel or similar)
Color	Black (typical)
Weight	Approximately 12 kg
Power Supply	None (manual/mechanical operation)
Lock Type	Key lock for each mailbox door
Included Components	Mailbox unit, frame, cross bars, keys and locks, name plates, spacers, ring covers, floor screws, cross bar screws, spacer screws, mailbox screws
Assembly Required	Yes, with provided hardware
Installation Type	Floor-mounted with anchor screws
Recommended Use	Outdoor or indoor mail collection for multiple recipients
Weather Resistance	Designed for outdoor use
Maintenance	Clean with a soft, dry cloth; avoid abrasive cleaners
Safety Precautions	Ensure stable mounting; keep keys away from children
Spare Parts Availability	Keys and screws available from manufacturer
Warranty	Standard manufacturer warranty (check product documentation)
Manual Languages	English (and others available online)
Certifications	Not specified

Frequently Asked Questions - 60003 WilTec

What are the dimensions of the WilTec 60003 mailbox system?

The overall dimensions are 470 × 270 × 385 mm, with a foot dimension of 1500 × 50 mm.

How many individual mailboxes does this system have?

It includes 4 individual mailboxes, each with its own lock and key.

Is the mailbox system easy to assemble?

Yes, assembly is straightforward with the provided hardware. Follow the step-by-step instructions: attach ring covers, connect frame and cross bars, anchor to the floor, then attach mailboxes with spacers and tighten all screws.

Can the mailbox be mounted on a wall instead of the floor?

The system is designed for floor mounting using the provided floor screws. Wall mounting is not recommended or supported.

What tools are needed for assembly?

You will need a drill for the anchor holes, a screwdriver or wrench for tightening screws, and a level to ensure the frame is straight.

Are replacement keys available if lost?

Yes, you can contact WilTec customer service to order replacement keys. The lock cylinder may be removable for key duplication.

How do I clean and maintain the mailbox?

Wipe with a soft, damp cloth and mild detergent if needed. Avoid abrasive cleaners that may scratch the finish. Regularly check and tighten screws.

What is the weight capacity of each mailbox?

Each mailbox can hold standard mail and small packages. For heavy items, consider the overall sturdiness of the frame.

Is the mailbox weatherproof?

It is designed for outdoor use and can withstand typical weather conditions, but prolonged exposure to harsh elements may cause wear. A protective coating is applied.

Can I purchase spare parts separately?

Yes, spare parts such as name plates, screws, and keys can be ordered from WilTec. Contact their service team via email or the contact form on their website.

USER MANUAL 60003 WilTec

4-Door Mailbox System

60003-60005, 61743, 61752, 61759

Illustration similar, may vary depending on model

Read and follow the operating instructions and safety information before using for the first time.

Technical changes reserved!

Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further developments.

Updating the documentation

If you have suggestions for improvement or have found any irregularities, please contact us.

The information contained in this document may alter at any time without prior notice. No part of this document may be copied or otherwise duplicated without prior written consent. All rights reserved. WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating manual, nor in the diagrams and illustrations shown.

Although WilTec Wildanger Technik GmbH has made every possible effort to ensure that this operating manual is complete, accurate, and up-to-date, errors cannot be ruled out entirely.

If you have found an error or wish to suggest an improvement, we look forward to hearing from you.

Send us an e-mail to:

[e-mail]

or use our contact form:

https://www.wiltec.de/contacts/

The most recent version of this manual in several languages can be found in our online shop:

https://www.wiltec.de/docsearch

Our postal address is:

To return your goods for exchange, repair, or other purposes, please use the following address. Attention! To allow for a trouble-free complaint or return, it is important to contact our customer service team before returning your goods.

Retourenabteilung

Thank you for choosing to purchase this quality product. To minimise the risk of injury, we ask you to always take some basic safety precautions when using this product. Please read this operating manual carefully and make sure that you understand it.

Keep these operation instructions in a safe place.

Technical drawing and parts list

No	Name	No	Name
1	Mailbox	7	Ring covers
2	Frame	8	Floor screw
3	Cross bar	9	Cross bar screw
4	Key and lock	10	Spacer screw
5	Name plate	11	Mailbox screws
6	Spacer

Assembly instructions

Choose a suitable location to place your mailbox system. Make sure that the surface is level and that you can anchor the frame firmly with the floor screws. We recommend that you assemble the mailbox close to where it is to be installed.

• Push the ring covers (7) onto the frame rods (2). Check that the ring is pointing in the correct direction (see fig. 1).
• Connect the frame (2) and the cross bars (3) using the screws (9). Leave the assembly loose and do not fully tighten the screws yet.
• Place the frame in the location that you have chosen and mark the mounting holes for the intended location (lift the ring covers to do this).
• Set the bracket aside and drill holes at the marked locations. Then you can attach the frame (2) with the floor screws (8). Then connect the mailbox unit (1) to each other using the screws (11).
• Now attach the mailboxes (1) with the spacers (6) between the bars of the frame (2). Use the spacer screws (10) for this.
  • Now tighten all the screws and finally attach the name tags (5) to the desired locations.

Figure 1

Technical specifications

Total dimen-sions (mm)	60003	60004	60005	61743	61752	61759
	470 × 270 × 385
Dimensions of foot (mm)	1500 × 50	1500 × 50	1500 × 50	1500 × 50	1500 × 50	1500 × 50
Number of in-dividual boxes	4
