USER MANUAL PTZA6-2W30H Aigis

PTZA6 Series Pan-Tilt-Zoom Domes Installation Manual

Aigis Mechtronics, Inc.

1124 Louise Road, Winston-Salem, NC 27292

Ph [phone] <ax [phone]

www.aigismech.com

Table2of2Contents2

1. Important Safeguards....3

1.1. Warnings....3

1.2. +environmental Specifications....3

1.3. Lightning-Proof Requirements....3

1.4. Lightning and Surge Proofing....4

1.5. Water Proofing....4

1. Installation 4

2.1. Before You Start....4

2.2. Materials Required....4

1. Bracket Installation....4

3.1. Overview....4

3.2. Bracket Installation....5

3.2.1. Wall Bracket Installation 5

3.2.2. Pendant Bracket Installation 5

3.2.3. Corner Bracket Installation....6

3.2.4. Pole Bracket Installation 7

3.3. Wiring and Installing the Dome Cover......8

3.4. Pan/Tilt Module Installation 9

1. Recess Mount Installation....10

4.1. Ceiling Hole Preparation.... 10

4.2. PTZ Module Installation....12

4.3. Trim Ring and Dome Bubble Attachment..... 12

IMPORTANT SA<+%UARDS

1. Read Instructions - All the safety and operating instructions should be read before the unit is operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the unit and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug the unit from the outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause hazards.

7. Accessories - Do not place this unit on an unstable stand, tripod, bracket, or mount. The unit may fall, causing serious injury to a person and serious damage to the unit. Use only with a stand, tripod, bracket, or mount recommended by the manufacturer or sold with the product. Any mounting of the unit should follow the manufacturer's instructions and should use a mounting accessory recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

1. Ventilation - Openings in the enclosure, if any, are provided for ventilation, to ensure reliable operation of the unit, and to protect it from overheating. These openings must not be blocked or covered. This unit

should not be placed in a built-in installation unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

1. Power Sources - This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply you plan to use, consult your appliance dealer or local power company. For units intended to operate from battery power or other sources, refer to the operating instructions.

2. Grounding or Polarization - This unit may be equipped with a polarized alternating-current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. Alternatively, this unit may be equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

3. Power Cord Protection - Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit from the appliance.

4. Power Lines - An outdoor system should not be located in the vicinity of overhead power lines or other electric light or power circuits or where it can fall into such

power lines or circuits. When installing an outdoor system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal. U.S.A. models only - refer to the National Electrical Code Article 820 regarding installation of CATV systems.

1. Overloading - Do not overload outlets and extension cords as this can result in a fire or electric shock.

2. Object and Liquid Entry - Never push objects of any kind into this unit through openings, as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.

3. Servicing - Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

4. Damage Requiring Service - Unplug the unit from the outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power supply cord or plug is damaged.

b. If liquid has been spilled or objects have fallen into the unit.

c. If the unit has been exposed to rain or water.

d. If the unit does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation.

e. If the unit has been dropped or the cabinet has been damaged.

f. When the unit exhibits a distinct change in performance--this indicates a need for service.

1. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

2. Safety Check - Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to determine that the unit is in proper operating condition.

3. Coax Grounding - If an outside cable system is connected to the unit, be sure the cable system is grounded. U.S.A. models only--Section 810 of the National Electrical Code, ANSI/NFPA No.70-1981, provides information with respect to proper grounding of the mount and supporting structure, grounding of the coax to a discharge unit, size of grounding conductors, location of discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

4. Lightning - For added protection of this unit during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the unit due to lightning and power line surges.

CAUT ON RISK OF ELECTRIC SHOCK, DO NOT OPEN! CAUTION: TO R+DUC+ TH+ RISK O< +L+CTRICAL SHOCK, DO NOT OP+N COV+RS. NO US+ S+RVIC+ABL+ PARTS AR+ INSID+. R<+R S+RVIC+ TO QUALI

1. Important Safeguards

1.1. Warnings

- Read this manual fully before attempting installation. - Do not install this product near flammable or explosive materials. - Installation must be performed by qualified service personnel in accordance with the national and local safety codes. - Ensure any lift equipment used employs proper safety features. - Cut off power to the unit before servicing. - Do not exceed 30VAC on 24 volt models. Operation above 30VAC violates low voltage operation (Class 2) specifications. Normal operation is 24VAC. - Be careful not to drop the camera module or camera housing during installation. - Do not install this dome in any environment exceeding the environmental conditions described below.

1.2. Environmental Specifications

Indoor Domes:

Operating Temperature: $$ - 1 0 ^ {\circ} \sim + 5 0 ^ {\circ} \mathrm{C} $$ $$ (+ 1 4 ^ {\circ} \sim 1 2 2 ^ {\circ} F) $$ Humidity: $$ \text { Non - condensing } $$ $$ < 95 \% \text { R.H. } $$ Air Pressure $$ 0. 8 6 \sim 1. 0 6 \text { bar } $$ Power Supply (included) $$ 2 4 \mathrm{VAC}, 5 0 / 6 0 \mathrm{Hz} $$ $$ 1. 0 \text { Amps } $$

Outdoor Domes:

Operating Temperature $$ - 4 0 ^ {\circ} \sim + 6 0 ^ {\circ} \mathrm{C} $$ $$ (- 4 0 ^ {\circ} \sim + 1 4 0 ^ {\circ} F) $$ Humidity: $$ \text { Non - condensing } $$ $$ < 95 \% \text { R.H. } $$ Air Pressure $$ 0. 8 6 \sim 1. 0 6 \text { bar } $$ Power Supply (included) $$ 2 4 \mathrm{VAC}, 5 0 / 6 0 \mathrm{Hz} $$ $$ 2. 5 \text { Amps } $$

1.3. Lightning-Proof Requirements

Refer to Figure 1 throughout this section. - Maintain a minimum of 50 meter (164 feet) distance from any high voltage cables or equipment. - Run outdoor rated cable under building eaves if possible. - Run cabling to the site in buried, sealed steel tubes (conduit). In areas exposed to the elements, shield the cables with steel conduit. Connect the conduit to ground at a single point; connect the ground to a Bus. - In strong thunderstorm or high faradic zones (such as high voltage transformer substations), extra strong lightning proof equipment and a lightning rod must be employed. - Take the building lightning proof requirements into account to design the lightning proof and grounding system of outdoor equipment and cable. Ensure that the system is in accordance with national and industrial standards. - The system must be grounded with equal potentials. The earth ground connection must satisfy the anti-interference and electrical safety requirements and must not short circuit eith the high voltage electricity net. When the system is grounded separately, the resistance of the ground conductor should be <4 and the cross-sectional area of the ground conductor should be <25mm^2 .

Power cable lightning conductor Communication/Data cable lightning conductor Video cable lightning conductor 45° The dome must be installed within the angle of 45 degree under the lightning rod. Ground wire resistance should be less than 4Ω Sealed Steel Tube (conduit)

Figure 1 – Typical Outdoor Installation

1.4. Lightning and Surge Proofing

This product uses TVS Lightning Proof technology which can prevent damage to the equipment caused by lightning strickes below 1500W and impulse signals such as surge; but it is also necessary to abide by the above stated precautions to ensure electrical safety.

1.5. Water Proofing

Outdoor domes are IP66 rated which indicates they are dustproof, waterproof, and moisture proof. Do not install an indoor dome in an outdoor environment. Protect the unit from damaged caused by long term water wear. Utilize thread sealant tape and RTV sealant on outdoor units.

2. Installation

Note: Disregard references to RTV sealant and thread sealant tape for indoor installations.

2.1. Before You Start

- Read this manual in detail. - Ensure that all installation and maintenance work is performed by technical personnel with proper qualifications and experience with this type of equipment. - All electrical work must be in accordance with the latest local and national laws and regulations including fire prevention measures. - Ensure that all components were included in the shipment. If any parts are missing contact the shipper. - Handle the pan/tilt module carefully. The camera module is designed to snap into the dome with very little effort. Do not bend and components or attempt to force the unit into place. Do not handle the dome bubble with your hands. - Make sure the installation site is sufficient in terms of structural integrity and/or available space before commencing the installation. Maintain a safety coefficient of at least 4 when installing this product. - The unit is shipped in the safest possible packaging. Keep it for possible future use. If the unit needs to be returned, replace it properly in its packaging and contact your supplier for return authorization and shipping instructions. - When using a wall mount, pendant mount, or corner mount, ensure that the mounting accessory can support at least 4 times the weight of the unit. When using a pole mount, ensure that the installation is in accordance with the lightning-proof requirements stated above. When mounting an indoor unit into the ceiling, utilize support wires if necessary and ensure that the ceiling can support the weight of the unit.

2.2. Materials Required

Minimum Video Coaxial Cable Requirements: - 75Ω impedance - All copper conductor wire (core) • 95% copper shield mesh

International Gauge Max Transmission Distance

RG59/U 750ft (229m)

RG6/U 1,000ft (305m)

RG11/U 1,500ft (457m)

• RS485 Communications cables (refer to Appendix) • 24VAC Power supply cables (refer to Appendix) \- Thread sealant tape • Room Temperature Vulcanizing (RTV) sealant \- Customer-supplied 1.5" NPT pipe for Pendant Mount installations (cut to desired length)

3. Bracket Installation

Figure 2 – PTZ Unit and Acces

3.1. Overview

These units were designed the installer in mind. Quick and simple connections are required to complete the installation. Some of the features include: - External threading of the external cover to easily connect the cover to the mount bracket. - Quick-attach and release mechanism used to connect the camera module to the external cover. - Simple, clearly marked connection board. - Mounting options include wall mount, pole mount, pendant mount and corner mount.

External Cover Camera Module (PTZ) Camera Lens Dome Bubble PTZ Unit Flange Adapter Wall Mount Pendant Mount


Pole Bracket Hose Clamps Pole Mount Corner Mount

3.2. Bracket Installation

Select an appropriate mounting location such that a safety factor of 4 can be achieved.

3.2.1. Wall Bracket Installation

Hold up the wall arm to the desired installation location and use it as a template to mark the center of the drill holes. The upper two holes are slotted for easy installation. Mark the portion of the slotted holes as shown in

.

3.30 in 94mm 5.51 in 140mm

Drill out the four holes in the mounting surface with a bit large enough to accept an M9 or 1/4" wall anchor. Drill to an approximate depth of 3.0 inches (75mm). Insert the wall anchor (not provided, see

01 Power/video/data cables 02 Wall Mount 03 Wall Anchor 04 RTV Sealant

3.2.2. Pendant Bracket Installation Hold the pendant mount flange up to the ceiling and mark the hole pattern.

φ103mm 120° 120°

04 02 05 03 05 01

3.2.3. Corner Bracket Installation Hold up the corner bracket to the desired installation location and use it as a template to mark the center of the drill holes. The hole pattern in shown in

78.00 mm 140.00 mm

Technical line drawing of a mechanical assembly with bolt holes and a central circular component labeled '06' (no text or symbols beyond the label)

01 Cables 02 Wall Mount 01 Cables 02 Wall Mount 03 Corner Bracket 04 M8 x 30mm screw 05 M8 Wall Anchor 06 RTV Sealant

3.2.4. Pole Bracket Installation Apply RTV sealant around the edge of the wall mount as shown in

01 Cables 02 Wall Mount 03 Pole Bracket 04 Hose Clamps 05 M8x30mm Screw 06 Pole 07 RTV Sealant 02 07

3.3. Wiring and Installing the Dome Cover The 4-position and 12-position terminal blocks are supplied in the packaging of the PTZ dome. The BNC connector is not supplied. Make the required connections based on the diagram in

Alarm Cable C ontrol Cable Vid eo Cable Power Cable BNC conn e c t o r 1 2 76543 A+Bt AUX1 AUX2 Rs485 AC24V %ND

Metal Button

Video Cable Connection P rotec tive Cover A la rm C a b le conne c tion D I P Switch P o w e r C a b le /C on tro l Cable Con ne c tion

M 4Screw G1½"

L+D Metal Button

3.4. Pan/Tilt Module Installation Remove the pan/tilt module from the packaging and inspect it for damage. If the unit needs to be returned to the factory, replace it properly in its packaging as shown in

Technical line drawing of a device with a close-up view showing internal components (no text or symbols)

% u id e notch e AMP Socket Loc king flange s Lo cking clips

Heater wire Heater wire connectors Safety line

Captive Screws

4. Recess Mount Installation Indoor recess-mount domes can be mounted in drop ceilings (a.k.a. ceiling tiles, acoustic ceiling tiles, etc.) or sheetrock ceilings. A typical installation is shown in

Technical line drawing of a mechanical assembly with no visible text or symbols

4.1. Ceiling Hole Preparation Draw a circle on the ceiling for the hole the PTZ will be mounted into. The dimensions of the hole should be 8.86-in (225mm) minimum to 8.94-in (227mm) maximum, as shown in

Ø225.00⁺².00 ±0.00 mm

Tightening Cap Screw Cap Power Cable Control Cable (RS485) Video Cable Alarm Cable

Metal ButtonMetal Button

Bulkhead connector AC Power / Data Terminal Block Alarm Term inal Block BNC Conn e c tor

AMP Socket L+D

Rai se clips un til the gap is larger than the ceiling tile thickn ess.

Technical line drawing of a mechanical device with no visible text or symbols

Technical line drawing of a mechanical assembly with a cylindrical component mounted on a base plate (no text or symbols) If the ceiling is not strong enough to meet the 4x safety factor, support wires can be attached to a support beam and connected to the back of the PTZ housing. M3 tapped holes Attach to housing using M3 Screws Attach to support beam Support wires

4.2. PTZ Module Installation Remove the pan/tilt module from the packaging and inspect it for damage. If the unit needs to be returned to the factory, replace it properly in its packaging as shown in

Technical line drawing of a device with internal components and a close-up view of a mechanical assembly (no text or symbols)

4.3. Trim Ring and Dome Bubble Attachment Attach the tether to one of the two threaded plastic posts in the trim ring using an M3 screw from the hardware kit (see

Tether Tab and groove M3 plastic threaded posts

% uid e n o tc he AMP Socket Lo ckng flan ge s Lo ckng clip s

Simple line drawing of a dome-shaped object with concentric rings, intersected by two perpendicular lines (no text or symbols)
