USER MANUAL TC1303B Microchip

Analog and Interface Product Selector Guide

Thermal Management • Motor Driver • Power Management Interface and Networking Peripherals • Linear and Mixed Signal CO and Smoke Detector ICs

Microchip TC1303B - Analog and Interface Product Selector Guide - 1

Microchip TC1303B - Analog and Interface Product Selector Guide - 2

Thermal Management

Temperature Sensors 4
Logic Output Temperature Sensors....4
Voltage Output Temperature Sensors. 4
Serial Output Temperature Sensors 4
Serial Output Temperature Sensors with Multichannel Temperature Sensors . . 5
Sensor Conditioning ICs....6
Open-Loop Fan Controllers and Fan Fault Detectors 6
Closed-Loop Fan Controllers with SMBus/1°C Interface 6

Motor Drivers

Stepper Motors, DC Motors and 3-Phase BLDC Motors 7

Position Sensors

Inductive Sensors....8

Power Management

Voltage References....8

Single Output Linear Regulators 8

Multiple Output Linear Regulators....15

Linear Regulators-LDO Controller and SIM Card 17

DDR Termination Regulators....17

High-Voltage Linear Regulators....17

Single Output Switching Regulators (Buck).... 17

Single Output Switching Regulators (Boost) 19

Multiple Output Switching Regulators 20

Combination Switching Regulators....21

Inductorless Offline Switching Regulators 21

PWM Controllers 21

Hybrid PWM Controllers 23

Power Modules 24

Charge Pump DC-to-DC Converters 24

Inverting or Doubling Charge Pumps 24

Regulated Charge Pumps 24

CPU/System Supervisors 25

Power MOSFET Drivers 27

Low-Side Power MOSFET Drivers 28

High-Side Power MOSFET Drivers....30

Synchronous Power MOSFET Drivers 30

Battery Chargers 31

Hot Swap Controllers 32

Power Switches 32

USB Port Power Controllers 32

Current Limit USB Protection Switches 33

Load Switches....34

Reverse Power Feed 35

Display and LED Drivers

Electroluminescent Backlight Drivers 36

16-Segment Drivers....36

Offline Drivers 36

Single Lamp Drivers....36

Dual Lamp Drivers....36

LED Drivers 36

Automotive 36

General Purpose 36

Backlight 37

Linear 38

Linear Regulators....38

Display 38

Sequential Linear....38

Camera Flash 38

High-Voltage Interface

Driver Arrays....39

Sink 39

Source....39

Source-Sink. 40

Amplifiers and MEMS Drivers 40

MOSFETS - Interface 40

Depletion-Mode N-Channel 40

Enhancement Mode N-Channel 40

Enhancement Mode P-Channel 41

N-Channel (Enhancement Mode MOSFET Arrays) 42

Complimentary (Enhancement Mode MOSFET Arrays) 42

Applications Specific....43

Liquid Lens Driver 43

Complimentary MOSFET Level Translator and Driver 43

High-Side Current Monitor 43

Fault Protection 43

Relay Driver and Controller 43

Linear

Op Amps 43

Zero-Drift Operational Amplifiers 47

Differential Amplifiers. 49

Programmable Gain Amplifiers (PGA) 49

Selectable Gain Amplifiers (SGA) 49

Instrumentation Amplifiers. 49

Comparators 50

Current Sense Amplifiers 50

Mixed Signal

Successive Approximation Register (SAR) A/D Converters 50

Delta-Sigma A/D Converters. 50

Pipelined A/D Converters 52

Energy Metering and Power Monitoring ICs 53

Energy Measurement AFEs. 53

DC Power Monitors 54

Dual-Slope A/D Converters....54

Binary and BCD A/D Converters....54

Display A/D Converters....54

Digital Potentiometers. 55

Frequency-to-Voltage/Voltage-to-Frequency Converters....56

D/A Converters. 56

Interface and Networking

CAN Products 58

LIN Products 58

Line Circuits 59

Line Drivers 61

Ethernet Products. 62

Ethernet Controllers....62

Ethernet Bridges 62

Ethernet Transceivers 62

EtherCat® Controllers....62

Ethernet Switches 63

Serial Peripherals 63

Wi-Fi® Modules....63

Wi-Fi RF Front-End Products 64

Bluetooth® Modules 65

IEEE 802.15.4 zigbee® RF Transceiver Products....66

Sub-GHz Transceivers/Modules 66

Sub-GHz Transmitters 66

Sub-GHz Receivers 66

MCU Transmitters....66

USB Bridge Devices 66

USB Products 66

USB Hub Controllers 66

USB-C™ Power and Charging 67

USB Transceivers/Switches 67

USB Flash Media Controllers....67

USB Security 67

Real-Time Clock/Calendar (RTCC) 67

CO and Smoke Detector ICs

Photoelectric Smoke Detector ICs 68

Ionization Smoke Detector ICs 68

Ionization Smoke Detector Front Ends 68

CO Detectors 68

Piezoelectric Horn Drivers....69

Ultrasound

High-Voltage Analog Multiplexers 69

Ultrasound MOSFET Drivers....70

Ultrasound TR Switches 70

Arbitrary Waveform Generators 70

Ultrasound Transmitters 70

PoE Controllers 71

Total System Solutions

Total System Solutions 72

Analog and Interface Solutions

Are You Looking for Complete Analog and Interface Design Solutions?

Microchip's integrated analog technology, peripherals and features are engineered to meet today's demanding design requirements. Our broad spectrum of analog products addresses thermal management, power management, battery management, mixed-signal, linear, interface and safety and security solutions. Combined with Microchip's Intelligent Analog microcontrollers, our extensive analog portfolio can be used in thousands of high-performance design applications in the automotive, communications (wireless), consumer, computing and industrial control markets.

Our broad portfolio of standalone analog and interface devices offers highly integrated solutions that combine various analog functions in space-saving packages and support a variety of bus interfaces. Many of these devices support functionality that enhances the analog features currently available on PIC ^® MCUs.

Want a Business Partner, Not Just a Vendor?

Successful companies recognize the value of a strategic supplier relationship to help them deliver innovative products to market quickly. They trust their suppliers to furnish quality components for current design opportunities as well as technology road

Microchip's Standalone Analog and Interface Portfolio
Microchip TC1303B - Want a Business Partner, Not Just a Vendor? - 1

maps and innovative solutions to stay ahead of tomorrow's design trends. Microchip provides low-risk product development, lower total system cost and faster time to market to more than 80,000 of these successful companies worldwide. Headquartered in Chandler, Arizona, Microchip offers outstanding technical support along with dependable delivery and quality.

Are Quality and Delivery a Concern?

Microchip's quality systems are certified according to the International Organization for Standards/Technical Specification (ISO/TS)-16949:2002 requirements. This demonstrates that our quality systems meet the most stringent industry quality-management system standards, resulting in high-quality semiconductor products. Direct control over manufacturing resources allows shortened design and production cycles. By owning the wafer fabrication facilities and the majority of the test and assembly operations, and by employing proprietary statistical process control techniques, Microchip has been able to achieve and maintain high production yields.

Need Additional Support and Resources?

Microchip is committed to supporting its customers by helping design engineers develop products faster and more efficiently. You can access three main service areas at www.microchip.com. The Design Support area provides a fast way to get questions answered. The Sample and Buy area offers evaluation samples of any Microchip device. microchipDIRECT provides 24-hour pricing, ordering, inventory and credit for convenient purchasing of all Microchip devices and development tools. This site also features online programming capabilities. Finally, the Training area offers opportunities to expand your knowledge with Microchip's online web seminars and hands-on courses at our worldwide Technical Training Centers. Our seminars and training classes are designed to fit your schedule and offer an overview of many product, development tool and application topics. Visit www.microchip.com/training for class content and schedules.

Have you ever encountered a technical dilemma at a critical point in your design development and your supplier was not available to answer your questions? Microchip's 24/7 global technical support line offers you technical support resources any time help is needed. Because some technical problems require hands-on assistance in order to be resolved quickly, Microchip has also developed a global team of field applications engineers and field sales engineers who provide local assistance.

Microchip TC1303B - Need Additional Support and Resources? - 1

THERMAL MANAGEMENT

THERMAL MANAGEMENT: Multichannel Temperature Sensors
Part #	Typical Accuracy (°C)	Maximum Accuracy @ 25°C (°C)	Maximum Temperature Range (°C)	Vcc Range (V)	Maximum Supply Current (μA)	Features Packages
Logic Output Temperature Sensors
TC6501	±0.5	±3	-58 to +125	+2.7 to +5.5	40	Cross to MAX6501, onon drain	5-pin SOT-23A
TC6502	±0.5	±3	-58 to +125	+2.7 to +5.5	40	Cross to MAX6502, push-pull	5-pin SOT-23A
TC6503	±0.5	±3	-55 to +125	+2.7 to +5.5	40	Cross to MAX6503, open-drain	5-pin SOT-23A
TC6504	±0.5	±3	-58 to +125	+2.7 to +5.5	40	Cross to MAX6504, push-pull	5-pin SOT-23A
TC620	±1	±3	-40 to +125	+4.5 to +18	400	Two resistor-programmable trip points	8-pin PDP, 8-pin SOIC
TC621	Note 1	Note 1	40 to +85	+4.5 to +18	400	Requires external thermistor, resistor-programmable trip points	8-pin PDP, 8-pin SOIC
TC622	±1	±5	-40 to +125	+4.5 to +18	800	Dual output, TO-220 for heat sink mounting, resistor-programmable trip points	8-pin PDP, 8-pin SOIC, 5-pin TO-220
TC623	±1	±3	-40 to +125	+2.7 to +4.5	250	Two resistor-programmable trip points	8-pin PDP, 8-pin SOIC
TC624	±1	±5	-40 to +125	+2.7 to +4.5	300	Dual output, resistor-programmable trip points	8-pin PDP, 8-pin SOIC
MCP9501	±1	±1	-40 to +125	+2.7 to +5.5	40	Active High, Push-Pull Output, Rising Temperature Switch	5-pin SOT-23
MCP9502	±1	±4	-40 to +125	+2.7 to +5.5	40	Active Low, Ocon Drain Output, Rising Temperature Switch	5-pin SOT-23
MCP9503	±1	±4	-40 to +125	+2.7 to +5.5	40	Active High, Push-Pull Output, Falling Temperature Switch	5-pin SOT-23
MCP9504	±1	±4	-40 to +125	+2.7 to +5.5	40	Active Low, Ocon Drain Output, Falling Temperature Switch	5-pin SOT-23
MCP9509	±0.5	NS	-40 to +125	+2.7 to +5.5	50	Resistor programmable temperature switch	5-pin SOT-23
MCP9510	±0.5	NS	-40 to +125	+2.7 to +5.5	80	Resistor programmable temperature switch	6-pin SOT-23
Voltage Output Temperature Sensors
MCP9700	±1±4-40 to -125 +2.3 to +5.5 12 Linear Active Thermistor					* IC. Temperature slope: 10 mV/°C	3-pin TO-92, 5-pin SC-70, 3-pin SOT-23
MCP9701	±1	±1	-40 to +125	+3.1 to +5.5	12	Linear Active Thermistor IC, Temperature slope: 18.53 mV/°C, cross to MAX6612	3 pin TO-92, 5-pin SC-70, 3-pin SOT-23
MCP9700A	±1	±2	-40 to +125	+2.3 to +5.5	12	Linear Active Thermistor IC, Temperature slope: 10 mV/°C	3 pin TO-92, 5-pin SC-70, 3-pin SOT-23
MCP9701A	±1	±2	-40 to +125	+3.1 to +5.5	12	Linear Active Thermistor IC, Temperature slope: 19.53 mV/°C, cross to MAX6612	3-pin TO-92, 5-pin SC-70, 3-pin SOT-23
TC1048	±0.5	±2	-40 to +125	+2.7 to +4.4	60	High precision temperature-to-voltage converter, 6.25 mV/°C	3-pin SOT-23B
TC1047	±0.5	±2	-40 to +125	+2.7 to +4.4	60	High precision temperature-to-voltage converter, 10 mV/°C	3-pin SOT-23B
TC1047A	±0.5	±2	-40 to +125	+2.5 to +5.5	60	High precision temperature-to-voltage converter, 10 mV/°C	3 pin SOT-23B
Serial Output Temperature Sensors
MCP9800	±0.5	±1	-56 to +125	+2.7 to +5.5	400	SMBus/IC compatible interface, 0.0625°C to 0.5°C adj. resolution, Power-saving one-shot temperature measurement	5-pin SOT-23
MCP9801	±0.5	±1	-56 to +125	+2.7 to +5.5	400	SMBus/IC compatible interface, 0.0625°C to 0.5°C adj. resolution, Power-saving one-shot temperature measurement, multi-drop capability	8-pin MSOP, 8-pin SOIC
MCP9802	±0.5	±1	-56 to +125	+2.7 to +5.5	400	SMBus/IC compatible interface with time out, 0.0625°C to 0.5°C adj. resolution, Power-saving one-shot temperature measurement	5-pin SOT-23
MCP9803	±0.5	±1	-56 to +125	+2.7 to +5.5	400	SMBus/IC compatible interface with time out, 0.0625°C to 0.5°C adj. resolution, Power-saving one-shot temperature measurement, Multi-drop capability	8-pin MSOP, 8-pin SOIC
MCP9804	±0.25	±1	-40 to +125	+2.7 to +5.5	400	User programmable temperature limits with soft output, 1°C temp. accuracy from -40°C to 125°C	8-pin MSOP, 8-pin 2 x 3 DFN
MCP9805	±0.5	+12	-20 to +125	+3.0 to +3.6	400	JEDEC-compatible register set, SMBus/IC compatible interface, Programmable, Shul-down modes and EVENT output	8-pin TSSOP, 8-pin 2 x 3 DFN
MCP9806	±0.25	±0.5	-40 to +125	+2.7 to +5.5	400	0.5°C temperature accuracy from -10°C to +100°C	8-pin 2 x 3 DFN, 8-pin MSOP
MCP9843	±0.5	±14	-20 to +125	+3.0 to +3.6	500	Compliant to JEDEC TSE30063 specification	8-pin TSSOP, 8-pin 2 x 3 DFN, 8 pin 2 x 3 TDFN
MCP98243	±1	±3	-40 to +125	+3.0 to +3.6	500	Serial output temperature sensor with integrated EEPROM (TSE200263)	8-pin TSSOP, 8-pin 2 x 3 DFN, 8-pin 2 x 3 TDFN
MCP98244	±0.5	±3	-40 to +125	+1.7 to +3.6	500	Serial output temperature sensor compliant to TSE2004a	8-pin 2 x 3 TDFN
MCP9844	±0.5	±3	-40 to +125	+1.7 to +3.6	500	Serial output temperature sensor with integrated EEPROM (TSE2004a)	8-pin 2 x 3 TDFN
TC677	±0.5	±1	-55 to +125	+2.7 to +5.5	400	SP-compatible interface, 0.0625°C temperature resolution	5-pin SOT-23A, 8-pin SOIC
TC672	±0.5	±1	-56 to +125	+2.86 to +5.5	400	SP-compatible interface, Power saving one shot temperature measurement, 0.25°C temperature resolution	8 pin MSOP, 8 pin 3 x 3 DFN
TC674	±0.5	±2	-40 to +125	+2.7 to +5.5	350	SMBus/IC compatible interface, 1°C temperature resolution	5-pin SOT-23A, 5-pin TO-220
TON75A ±0.5±2 -40 to +125 +2.7 to +5.5			500			SMBus/IC compatible interface, power-saving one-shot temperature measurement, multi-drop capability, 0.0625°C to 0.5°C adjustable temperature resolution	8-pin MSOP, 8-pin SOIC
AT3018/4	±1	±2	-56 to +125	+1.7 to +5.5	125	SMBus/IC compatible interface, 0.0625°C to 0.5°C adj. resolution, power-saving one-shot temperature measurement	8 pin SOIC, 8 pin MSOP, 8 pin 2 x 3 UDFN, 4 bal WLCSP, 5 bal WLCSP
AT3018/5A	±0.5	±1	-55 to +125	+1.7 to +5.5	125	SMBus/IC compatible interface, 0.0625°C to 0.5°C adj. resolution, power-saving one-shot temperature measurement	8 pin SOIC, 8-pin MSOP, 8 pin 2 x 3 UDFN
AT3018/6A	±0.5	±1	-56 to +125	+1.7 to +5.5	125	SMBus/IC compatible interface, nonvolatile registers to retain user-configured or pre-closed power-up defaults	8 pin SOIC, 8 pin MSOP, 8 pin 2 x 3 UDFN
AT3018/92A	±0.5	±1	-56 to +125	+1.7 to +5.5	125	SMBus/IC compatible interface, nonvolatile registers to retain user-configured or pre-defined power-up defaults, integrated 2 KB serial EEPROM	8 pin SOIC, 8 pin MSOP, 8 pin 2 x 3 UDFN

Note 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.
2: Maximum accuracy measured at 85°C.

THERMAL MANAGEMENT: Multichannel Temperature Sensors

Part #	Typical Accuracy (°C)	Maximum Accuracy @ 25°C (°C)	Maximum Temperature Range (°C)	Vcc Range (V)	Maximum Supply Current (μA)	Features Packages
Serial Output Temperature Sensors (Continued)
AT3CTSE754A ±0.5±1-55 to +125 +1.7 to +5.5 125						SMBus/IC compatible interface, nonvoltatile registers to retain user-configured or pre-dolined power-up defaults, integrated 4 KB serial EEPROM	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 UDFN
AT3CTSE758A +0.5+1-55 to +125 +1.7 to +5.5 125						SMBus/IC compatible interface, nonvoltatile registers to retain user-configured or pre-dolined power-up defaults, integrated 8 KB serial EEPROM	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 UDFN
AT3CTSE002B	±1	±3	-40 to +125	+2.7 to +3.6	500	JEDEC UC42.4 SO-DIMM SPD + TS compliant, SMBus/IC compatible interface, integrated 2 KB serial EEPROM 8-pin 2 x 3 UDFN
AT3CTSE004A	+0.5	+3	-40 to +125	+1.7 to +3.6	500	JEDEC UC42.4 (TSE2004ay) DIMM SPD + TS compliant, SMBus/IC compatible interface, integrated 4 KB serial EEPROM 8-pin 2 x 3 UDFN

THERMAL MANAGEMENT PRODUCTS: Multichannel Temperature Sensors

Part #	# of Remote Temp. Sensors	Typ. Accuracy (°C)	Maximum Accuracy @ 25°C (°C)	Maximum Temp. Range (°C)	Ambient Temp. Sensor	Alert/ THERM	Hardware Shutdown	Vcc Range (V)	Typ.Supply Current (μA)	Description and Additional Features Packages
Serial Output Temperature Sensors with Multichannel Temperature Sensors:
MIC184	1	±1.0	±2.0	-55 to +125	1	1	-	2.7-5.5	340	Local/Remote Thermal Supervisor	8-pin SOIC, 8-pin MSOP
MIC280	1	+1.0	+2.0	-55 to +125	1	1	-	3.0-3.6	230	Precision lityBilty Thermal Supervisor	8-pin SOT
MIC281	1	+1.0	+3.0	-55 to +125	0	1	-	3.0-3.6	230	Low-Cost lityBilty Thermal Sensor	8-pin SOT
MIC284	1	+1.0	±2.0	-55 to +125	1	2	-	2.7-5.5	350	Two-Zone Thermal Supervisor with CRIT Output	8-pin SOIC, 8-pin MSOP
MIC384	2	±1.0	±2.0	-55 to +125	1	1	-	2.7-5.5	350	Three-Zone Thermal Supervisor	8-pin SOIC, 8-pin MSOP
MCP9802	1	+0.25	+1.0	-40 to +125	1	2	-	3.0-3.6	450	Lower Temperature Dual Temperature Sensor	8-pin WDFN
MCP9803	2	±0.25	±1.0	-40 to +125	1	2	-	3.0-3.6	450	Lower Temperature Triple Temperature Sensor	10-pin 3 x 3 VDFN
MCP9804	3	+0.25	+1.0	-40 to +125	1	2	-	3.0-3.6	450	Lower Temperature Quad Temperature Sensor	10-pin 3 x 3 VDFN
EVC1046	5	±0.25	±1.0	-40 to +125	1	-	-	3.0-3.6	365	Sextuple SMBus/IC Sensor with REC, Beta Compensation and Hottest of Thermal Zones	10-pin MSOP
EVC1047	6	±0.25	±1.0	-40 to +125	1	-	-	3.0-3.6	365	Septuple SMBus/IC Sensor with REC, Beta Compensation and Hottest of Thermal Zones	10-pin MSOP
EVC1072	1	±0.25	±1.0	-40 to +125	1	2	-	3.0-3.6	430	Dual SMBus/IC Sensor with Selectable Address	8-pin MSOP
EVC1073	2	±0.25	±1.0	-40 to +125	1	2	-	3.0-3.6	430	Triple SMBus/IC Sensor with Selectable Address	10-pin MSOP
EVC1074	3	±0.25	±1.0	-40 to +125	1	2	-	3.0-3.6	430	Quad SMBus/IC Sensor with Selectable Address	10-pin MSOP
EVC1812	1	±0.25	±1.0	-40 to +125	1	2	-	1.82-3.6	25	Dual Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	9-pin WDFN
EVC1813	2	+0.25	+1.0	-40 to +125	1	2	-	1.82-3.6	25	Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	10-pin WDFN
EVC1814	3	±0.25	±1.0	-40 to +125	1	2	-	1.82-3.6	25	Quad Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	10-pin WDFN
EVC1815	4	+0.25	+1.0	-40 to +125	1	2	-	1.82-3.6	25	Five Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	10-pin WDFN
EVC1833	2	+0.25	+1.0	-40 to +125	1	2	-	1.82-3.6	25	Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	8-pin WDFN
EVC1412	1	+0.25	+1.0	-40 to +125	1	2	-	3.0-3.6	430	Dual SMBus/IC Sensor with REC, Beta Compensation and Selectable Address	8-pin TDFN, 8-pin MSOP
EVC1413	2	+0.25	+1.0	-40 to +125	1	2	-	3.0-3.6	430	Triple SMBus/IC Sensor with REC, Beta Compensation and Selectable Address	10-pin DFN, 10-pin MSOP
EVC1414	3	±0.25	±1.0	-40 to +125	1	2	-	3.0-3.6	430	Quad SMBus/IC Sensor with REC, Beta Compensation and Selectable Address	10-pin MSOP, 10-pin DHN
EVC1422	1	+0.25	+1.0	-40 to +125	1	1	1	3.0-3.6	430	Dual SMBus/IC Sensor with REC, Beta Compensation and Resistor-Selltable Hardware Thermal Shutdown	8-pin MSOP
EVC1423	2	+0.25	+1.0	-40 to +125	1	1	1	3.0-3.6	430	Triple SMBus/IC Sensor with REC, Beta Compensation and Resistor-Selltable Hardware Thermal Shutdown	10-pin MSOP
EVC1424	3	+0.25	+1.0	-40 to +125	1	1	1	3.0-3.6	430	Quad SMBus/IC Sensor with REC, Beta Compensation and Resistor-Selltable Hardware Thermal Shutdown	10-pin MSOP
EVC1428	7	±0.25	±1.0	-40 to +125	1	1	1	3.0-3.6	450	Octal SMBus/IC Sensor RLC, Beta Compensation and Resistor-Soluble Hardware Thermal Shutdown and Hottest of Thermal Zones	16-pin QFN
EVC1438	7	±0.25	±1.0	-40 to +125	1	1	1	3.0-3.6	450	Octal SMBus/IC Sensor REC, Beta Compensation and Resistor-Selltable Hardware Thermal Shutdown and Hottest of Thermal Zones	16-pin QFN
EMC1822	1	±0.25	±1.0	-40 to +125	1	1	1	1.62-3.6	25	Dual Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	8-pin WDFN
EMC1823	2	±0.25	±1.0	-40 to +125	1	1	1	1.62-3.6	25	Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	10-pin WDFN
EMC1824	3	±0.25	±1.0	-40 to +125	1	1	1	1.62-3.6	25	Quad Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	10-pin VDFN
EMC1825	4	±0.25	±1.0	-40 to +125	1	1	1	1.62-3.6	25	Five Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	10-pin VDFN
EMC1843	2	±0.25	±1.0	-40 to +125	1	1	1	1.62-3.6	25	Triple Channel 1.8V Temperature Sensor with Rate of Change, Resistance Error Correction, Beta Comp	8-pin WDFN

Note 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor. 2: Maximum accuracy measured at 55°C. 3: TCN75 idle current is 250 mA. This device also has a Software Shutdown mode that reduces supply current to < 1 mA.

THERMAL MANAGEMENT: Sensor Conditioning ICs

Product	Description	Typical Tc Accuracy (°C)	Typical Th Accuracy (°C)	Temperature Range (°C)	Vcc Range (V)	Max Supply Current (μA)	Packages
MCP9800	±1.5°C thermocouple to degrees C converter. Supports thermocouple types K, J, T, N, S, E, B and R.	1	1	-40 to +125	2.7 to 5.5	500	5 × 5 MQFN
MCP98L00	±4°C thermocouple to degrees C converter. Supports thermocouple types K, J, T, N, S, E, B and R.	1	4	-40 to +125	2.7 to 5.5	500	5 × 5 MQFN
MCP98RL00	±8°C thermocouple to degrees C converter. Supports thermocouple types K, J, T, N, S, E, B and R.	1	6	-40 to +125	2.7 to 5.5	500	5× 5 MQFN
MCP9801	±1.5C Thermocouple to IC converter. This device has Opens/Shorts pin detection. This device supports K, J, T, N, S, E, B and R type thermocouples.	±1.0 ±1.5 -40 to +125 2.7 to 5.5 500 5 × 5 MQFN
MCP98L01	±4.0C Thermocouple to IC converter. This device has Opens/Shorts pin detection. This device supports K, J, T, N, S, E, B and R type thermocouples.	±1.0 ±4.0 -40 to +125 2.7 to 5.5 500 5 × 5 MQFN
MCP98RL01	±6.0C Thermocouple to IC converter. This device has Opens/Shorts pin detection. This device supports K, J, T, N, S, E, B and R type thermocouples.	±1.0 ±6.0 -40 to +125 2.7 to 5.5 500 5 × 5 MQFN

THERMAL MANAGEMENT: Open-Loop Fan Controllers and Fan Fault Detectors

Part # Description		# of Temp. Monitors	Typical Accuracy (°C)	Maximum Accuracy @ 25°C (°C)	Maximum Temperature Range (°C)	Vcc Range (V)	Maximum Supply Current (μA)	Features Packages
EVC2101	Single SMBus FC Fan Manager	2	±0.5	±1	-40 to +125	+3.0 to +3.6	1,000	Fan Controller with high-frequency PWM driver, programmable fan speed lable and alert	8-pin MSOP, 8-pin SOIC
TC642	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	1,000	FanSenseTM Fan Monitor, Minimum fan speed control	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC642B	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	400	FanSense Fan Monitor, Minimum fan speed control, Fan auto-restart	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC646	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	1,000	FanSense Fan Monitor, Auto-shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC646B	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	400	FanSense Fan Monitor, Auto-shutdown, Fan auto-restart	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC647	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	1,000	FanSense Fan Monitor, Minimum fan speed control	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC647B	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	400	FanSense Fan Monitor, Minimum fan speed control, Fan auto-restart	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC648	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	1,000	Overtemperature alert, Auto-shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC648B	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	400	Overtemperature alert, Auto-shutdown, Fan auto-restart	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC649	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	1,000	FanSense Fan Monitor, Auto-shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC649B	Fan Manager	1	Note 1	Note 1	-40 to +85	-3.0 to +5.5	400	FanSense Fan Monitor, Auto-shutdown, Fan auto-restart	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
TC650	Fan Manager	1	±1	±3	-40 to +125	-2.8 to +5.5	90	Overtemperature alert	8-pin MSOP
TC651	Fan Manager	1	±1	±3	-40 to +125	-2.8 to +5.5	90	Overtemperature alert, Auto-shutdown	8-pin MSOP
TC652	Fan Manager	1	±1	±3	-40 to +125	-2.8 to +5.5	90	FanSense Fan Monitor, Overtemperature alert	8-pin MSOP
TC653	Fan Manager	1	±1	±3	-40 to +125	-2.8 to +5.5	90	FanSense Fan Monitor, Overtemperature alert, Auto-shutdown	8-pin MSOP
TC654	Dual SMBus Fan Manager	1	Note 1	Note 1	-40 to +85	+3.0 to +5.5	320	FanSense Fan Monitor, RPM data	10-pin MSOP
TC655	Dual SMBus Fan Manager	1	Note 1	Note 1	-40 to +85	+3.0 to +5.5	320	FanSense Fan Monitor, RPM data, Overtemperature alert	10-pin MSOP
TC664	Single SMBus Fan Manager	1	Note 1	Note 1	-40 to +85	+3.0 to +5.5	320	FanSense Fan Monitor, RPM data	10-pin MSOP
TC665	Single SMBus Fan Manager	1	Note 1	Note 1	-40 to +85	+3.0 to +5.5	320	FanSense Fan Monitor, RPM data, Overtemperature alert	10-pin MSOP
TC670	Predictive Fan Fault Detector	1	N/A	N/A	-40 to +85	+3.0 to +5.5	150	FanSense Fan Monitor, Programmable threshold	6 pin SOT 23

Note 1: These devices use an external temperature sensor. Accuracy of the total solution is a function of the accuracy of the external sensor.

THERMAL MANAGEMENT: Closed-Loop Fan Controllers with SMBus/IC Interface

Part #

# of Fan Drivers

PWM/ Linear Control

# of Remote Temp. Monitors

Ambient Temp. Sensor

Typical Accuracy (°C)

Maximum Accuracy @ 25°C (°C)

Maximum Temperature Range (°C)

Vcc Range (V)

SMBus Alert

System Shutdown

Voltage Monitors

Description

Packages

EVC2112

Linear

±0.25

±1.0

0 to 185

+3.3 and +5

Yes

RPM-Based Fan Controller with Hardware Thermal Shutdown

20-pin QFN

EVC2103-1

PWM

-0.5

+1.0

-40 to -125

+3.0 to +3.6

Yes

RPM-Based Fan Controller with Hardware Thermal Shutdown

12-pin QFN

EVC2103-2

PWM

-0.5

+1.0

-40 to -125

+3.0 to +3.6

Yes

RPM-Based Fan Controller with Hardware Thermal Shutdown

16-pin QFN

EVC2103-4

PWM

±0.5

±1.0

-40 to -125

+3.0 to +3.6

Yes

RPM-Based Fan Controller with Hardware Thermal Shutdown and EEPROM loadable

16-pin QFN

EVC2104

PWM

±0.25

±1.0

-40 to +85

+3.0 to +3.6

Yes

Dual RPM-Based PWM Fan Controller with Hardware Thermal Shutdown

20-pin QFN

EVC2105

Linear

±0.25

±1.0

-40 to +85

+3.3 and +5.0

Yes

RPM-Based High-Side Fan Controller with Hardware Thermal Shutdown

20-pin QFN

THERMAL MANAGEMENT: Closed-Loop Fan Controllers with SMBus/IC Interface

EVC2106 2

PWM & Linear

±0.25

±1.0

-40 to +85

+3.3 and -5.0

Yes

RPM-Based High Side Fan Controller with Hardware Thermal Shutdown

28-pin QFN

EVC2113

PWM

±0.5

±1.0

-40 to +125

+3.0 to +3.6

Yes

Single RPM-Based Fan Controller with Multiple Temperature Zones and Hardware Thermal Shutdown

16-pin QFN

EVC2301

PWM

N/A

-40 to +125

+3.0 to +3.6

Yes

N/A

Single RPM-Based PWM Fan Speed Controller

8-pin MSOP

EVC2302

PWM

N/A

-40 to +125

+3.0 to +3.6

Yes

N/A

Dual RPM-Based PWM Fan Speed Controller

10-pin MSOP

EVC2303

PWM

N/A

-40 to +125

+3.0 to +3.6

Yes

N/A

Triple RPM-Based PWM Fan Speed Controller

12-pin QFN

EVC2305

PWM

N/A

-40 to +125

+3.0 to +3.6

Yes

N/A

Penta RPM-Based PWM Fan Speed Controller

16-pin QFN

MOTOR DRIVERS

MOTOR DRIVERS: Stepper Motors, DC Motors and 3-Phase BLDC Motors

Part #	Motor Type	Input Voltage Range (V)	Internal/ External FETs	Output Current (mA)	Control Scheme	Motor Speed Output	Protections	Temperature Operating Range (°C)	Features	Packages
ATA6826C	DC Motor	7 to 40	Internal	1000	SPI	N/A	Short Circuit, Overtemperature, Power Supply Fall	-40 to +125	3 half bridge outputs, No shoot-through, Very low quiescent current: <2 μA	SO14
ATA6831C	DC Motor	7 to 40	Internal	1000	SPI	N/A	Short Circuit, Overtemperature, Power Supply Fall	-40 to +125	3 half bridge outputs, No shoot-through, Very low quiescent current: <2 μA, PWM Input	18 pin 4 x 4 QFN
ATA6832C	DC Motor	7 to 40	Internal	1000	SPI	N/A	Short Circuit, Overtemperature, Power Supply Fall	-40 to +150	3 half bridge outputs, No shoot-through, Very low quiescent current: <2 μA, PWM Input	18 pin 4 x 4 QFN
ATA6836C	DC Motor	7 to 40	Internal	650	SPI	N/A	Short Circuit, Overtemperature, Power Supply Fall	-40 to +125	6 half bridge outputs, No shoot-through, Very low quiescent current: <2 μA	24-pin 5 x 5 QFN, SO28
ATA6836C	DC Motor	7 to 40	Internal	850	SPI	N/A	Short Circuit, Overtemperature, Power Supply Fall	-40 to +125	6 half bridge outputs, No shoot-through, Very low quiescent current: <2 μA	24-pin 5 x 5 QFN
ATA6829C	DC Motor	7 to 20	External	100	PWM, DIR	N/A	Short Circuit, Overtemperature, Over/ Under Voltage, Chargepump Fall	-40 to +125	Dead time adjust, Charge pump supply for external battery reverse protection NMOS, LDO 3V3/5V, Window Watchdog, LIN TRX, Sleep mode <45μA	32-pin 7 x 7 QFN
ATA6824C	DC Motor	7 to 20	External	100	PWM, DIR	N/A	Short Circuit, Overtemperature, Over/ Under Voltage, Chargepump Fall	-40 to +150	Dead time adjust, Charge pump supply for external battery reverse protection NMOS, LDO 3V3/5V, Window Watchdog, I/V interface	32-pin 7 x 7 TOFP
ATA6843	3-Phase Brushless Motor	5.5 to 32	External	100	Direct PWM	N/A	Short Circuit, Overtemperature, Over/ Under Voltage, Chargepump Fall	-40 to +125	Charge pump supply for external battery reverse protection NMOS, Dead time adjust, LDO 3V3/5V, Window Watchdog, LIN TRX, Sleep mode <45μA	48-pin 7 x 7 QFN
ATA6844	3-Phase Brushless Motor	5.5 to 32	External	100	Direct PWM	N/A	Short Circuit, Overtemperature, Over/ Under Voltage, Chargepump Fall	-40 to +150	Charge pump supply for external battery reverse protection NMOS, Dead time adjust, LDO 3V3/5V, Window Watchdog, LIN TRX, Sleep mode <45 μA	48-pin 7 x 7 QFN
MCP8063	3-Phase Brushless Motor	2.0 to 14.0	Internal	750 Sensorless Sinusoidal		Frequency Generator	Overtemperature, Motor Lock-up, Overcurrent, Overvoltage	-40 to +125	3-Phase BLDC 180° Sinusoidal Sensorless Fan Motor Driver, Overcurrent limitation, Output Switching Frequency at 25 kHz	Thermally Enhanced 8-pin 4 x 4 DFN
MTS62C19A	One Bipolar Stepper Motor or Two DC Motors	10.0 to 40.0	Internal	750	Direct PWM Input, Current Limit Control, Microstepping	No	Overtemperature, Under Voltage	-40 to +105	Dual Full-Bridge Motor Driver for Stepper Motors, Pin compatible with Allegro 6219	24-pin SOIC
MTS2916A	One Bipolar Stepper Motor or Two DC Motors	10.0 to 40.0	Internal	750	Direct PWM Input, Current Limit Control, Microstepping	No	Overtemperature, Under Voltage	-40 to +105	Dual Full-Bridge Motor Driver for Stepper Motors, Pin compatible with Allegro 2916	24-pin SOIC
MTD6501C	3-Phase Brushless Motor	2.0 to 14.0	Internal	800 Sensorless Sinusoidal		Frequency Generator	Overtemperature, Motor Lock-up, Overcurrent, Overvoltage	-30 to -95	3-Phase BLDC 180° Sinusoidal Sensorless Fan Motor Driver, Overcurrent limitation, Output Switching Frequency at 20 kHz	Thermally Enhanced 8-pin SOIa
MTD6501D	3-Phase Brushless Motor	2.0 to 14.0	Internal	510	Sensorless Sinusoidal	Frequency Generator	Overtemperature, Motor Lock-up, Overcurrent, Overvoltage	-30 to -95	3-Phase BLDC 180° Sinusoidal Sensorless Fan Motor Driver, Boost Mode, Overcurrent limitation, Output Switching Frequency at 20 kHz	10-pin MSOP
MTD6501G	3-Phase Brushless Motor	2.0 to 14.0	Internal	800 Sensorless Sinusoidal		Frequency Generator	Overtemperature, Motor Lock-up, Overcurrent, Overvoltage	-30 to -95	3-Phase BLDC 180° Sinusoidal Sensorless Fan Motor Driver, Overcurrent limitation, Output Switching Frequency at 23 kHz	Thermally Enhanced 8-pin SOP
MTD6502B	3-Phase Brushless Motor	2.0 to 5.5	Internal	750 Sensorless Sinusoidal		Frequency Generator	Overtemperature, Motor Lock-up, Overcurrent, Overvoltage	-40 to +125	3 Phase BLDC Sinusoidal Sensorless Fan Motor Driver, Direction control, Overcurrent limitation, Output Switching Frequency at 30 kHz	10-pin 3 x 3 TDFN
MTD6508	3-Phase Brushless Motor	2.0 to 5.5	Internal	750 Sensorless Sinusoidal		Frequency Generator	Overcurrent, Overvoltage, Overtemperature, Motor Lock-up	-40 to +125	180° Sinusoidal Sensorless Drive, Direction Control, Programmable BFMF Coefficient Range, Output Switching Frequency at 30 kHz, Programmable Start-up RPM and Slew Rate, Selectable Start-up Strength and Phase Target Regulation	10-pin 3 x 3 UDFN, 18-pin 4 x 4 UDFN

MOTOR DRIVERS: Stepper Motors, DC Motors and 3-Phase BLDC Motors

Part #	Motor Type	Input Voltage Range (V)	Internal/ External FETs	Output Current (mA)	Control Scheme	Motor Speed Output	Protections	Temperature Operating Range (°C)	Features Packages
MTD6505	3- Phase Brushless Motor	2.0 to 5.5	Internal 750	Senscless Sinusoidal		Frequency Generator	Ovocurrent, Ovorvoltage, Overtemperature, Motor Lock-up	-40 to +125	^180 ° Sinusoidal Sensorless Drive, Direction Control, Programmable EEMF Coefficient Range, Output Switching Frequency at 30 kHz	10-pin 3 x 3 UDFN

POSITION SENSORS

POSITION SENSORS: Inductive Sensors

Part #

Calibration Segments

Sensor Offset Adjust

Origin Adjust (bits)

Output Interface

Output Resolution (bits)

Redundant IC support

# of ADCs

ADC Sampling Rate (samples/sec)

ADC for external sensor (bits)

MCU

Temperature Range (°C)

Features Packages

LX3301A

Yes

Analog, PWM

Yes

2000

N/A

32 bit, 8 MHz

-40 to +125

AEC-Q100 Grade 1, ISO28262 Support, Integrated Input EMI liters

LX3302A 8

Yes 12

Analog, PWM, SENT, PSIC, SIVCos

Yes

2000

32 bit, 8 MHz

-40 to +150

AEC-Q100 Grade 0, ISO28262 Support, Integrated temperature sensor, external sensor interface

POWER MANAGEMENT

POWER MANAGEMENT: Voltage References

Part #	Vin Max(V)	Output Voltage(V)	Max. LoadCurrent (mA)	Initial Accuracy(max,%)	TemperatureCoefficient (ppm/°C)	Maximum SupplyCurrent (μA @ 25°C)	Packages
MCP1501	5.5	1.024, 1.250, 1.8, 2.048, 2.5, 3.0, 3.8, 4.096	20	±0.06	50	350	8-pin 2 x 2 WDRN, 6-pin SOT-25 (AEC-Q100), 8-pin SOIC
MCP1525	5.5	2.5	+2	+1	50	100	3-pin TO-92, 3-pin SOT-23B
MCP1541	5.5	4.098	±2	±1	50	100	3 pin TO-92, 3 pin SOT-23B
LM4040C	15	2.5, 4.098, 5.0	15	±0.5	100	65-85	3 pin SOT-23
LM4040D	15	2.5, 4.098, 5.0	15	±1	150	65-85	3-pin SOT-23
LM4041C	15	1.225, Aql. (1.24-10V)	12	±0.5	100	70	3 pin SOT-23
LM4041D	15	1.225, Aql. (1.24-10V)	12	±1	150	70	3 pin SOT-23
MIC40403	10	Adjustable	15	±1	-	70	8-pin SOT-143

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features	Packages
MCP1911	150	1.8	5.5	1.2, 1.8, 2.9, 3.0, 3.3	400	250 rA	± 2	50	Ultra-Low Iq	1 x 1 DFN, SOT28-3, SOT28-5, SC70-3, SC70-5
MCP1912	300	1.8	5.5	1.2, 1.8, 2.9, 3.0, 3.3	400	250 rA	± 2	50	Ultra-Low Iq	1 x 1 DFN, SOT28-3, SOT28-5, SC70-3, SC70-5
MIC5231	10	3.5	12	2.75, 3.0, 3.3, 5.0	150	850 rA	± 2	50	High Input Voltage, Small Package	5-pin SOT-23
MIC5232	10	2.7	7	1.2, 2.6, 2.9, 3.3	100	1.8 μA	± 2	55	7V input	5-pin TSOT, 6-pin VDTN
MAQ5280	25	4.5	120	Adj.	1100	31 μA	± 2	80	Ultra-High Input Voltage, Load Dump	8-pin SOIC
MIC5280	25	4.5	120	Adj.	1100	31 μA	± 2	80	High Input Voltage, Load Dump, Reverse Battery Protection	8-pin SOIC
MIC5281	25	6	120	3.3, 5.0, Adj.	2000	6 μA	± 3	90	High Input Voltage, Load Dump	8 pin MSOP*
MAQ5281	25	6	120	3.3, 5.0, Adj.	2000	6 μA	± 3	90	High Input Voltage, Load Dump	8 pin MSOP*
MAQ5282	50	6	120	3.3, 5.0, Adj.	2000	6 μA	± 3	90	High Input Voltage, High PSRR	8 pin MSOP*
MIC5282	50	6	120	3.3, 5.0, Adj.	2000	6 μA	± 3	90	High Input Voltage, Load Dump	8 pin MSOP*
TC1014	50	2.7	6	1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.8, 4.0, 5.0	85	50 μA	± 0.5	64	Ultra Low Dropout	5 pin SOT-23
TC1054	50	2.7	6	1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.8, 4.0, 5.0	85	50 μA	± 0.5	64	Ultra Low Dropout	5 pin SOT-23
TC1070	50	2.7	6	1.23-5.5	85	50 μA	± 0.5	64	Ultra Low Dropout	5 pin SOT-23
TC1072	50	2.7	6	2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.8, 4.0, 5.0	85	50 μA	± 0.5	64	Ultra Low Dropout	6 pin SOT-23
TC1223	50	2.7	6	2.8, 2.7, 2.8, 3.0, 3.3, 3.6, 4.0, 5.0	85	50 μA	± 0.5	64	Ultra Low Dropout	5 pin SOT-23
TC2014	50	2.7	6	1.8, 2.7, 2.8, 3.0, 3.3	45	50 μA	± 0.4	55	Ultra Low Dropout	5 pin SOT-23
TC2054	50	2.7	6	1.8, 2.7, 2.9, 3.0, 3.3	45	55 μA	± 0.4	50	Ultra Low Dropout	5 pin SOT-23

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MCP1790	70	6	30	3.0, 3.3, 5.0	700	70 μA	±0.2	90	High Input	3-pin SOT-223, 3-pin DOPAK
MCP1791	70	300.0, 3.3, 5.0	700.70 μA	-0.2 90 High Input 5-pin DDPAK, 5-pin SOT-223
MIC5203	80	2.5	18	2.6, 2.8, 3.0, 3.3, 3.8, 3.8, 4.0, 4.5, 5.0	300	180 μA	±3	60	High input Voltage, Small Package	4 pin SOT 143, 5 pin SOT 23
MIC5213	80	2.5	18	2.5, 2.6, 2.7, 2.8, 3.0, 3.3, 3.6, 5.0	280	180 μA	±3	60	High input Voltage, Small Package	5-pin SC70
TC1016	80	2.7	6	1.8, 2.7, 2.8, 3.0	150	50 μA	±0.5	58	Low Dropout	5 pin SC 70, 5 pin SOT 23
LF2951	100	2	30	4.9, 5.0, Adj.	380	100 μA	±0.5	70	High input Voltage, High PSRR	8-pin SOIC, 8-pin PDIP
MIC5200	100	2.5	28	3.0, 3.3, 4.8, 5.0	230	130 μA	±1	70	Low Dropout	8 pin MSOP, 3 pin SOT 223, 8-pin SOIC
MIC5233	100	2.5	36	1.8, 2.5, 3.0, 3.3, 5.0, Adj.	270	18 μA	±1	50	High input Voltage, Reverse Battery and Current Protection	3 pin SOT-223, 5-pin SOT-23
MCP1792	100	4.5	55	3.3, 5.0	250	25	2	70	AEC-Q100 Qualified and PPAP Capable with Automotive Grade 0	3-Lead SOT-2233-Lead SOT-23A
MCP1793	100	4.5	55	3.3, 5.0	250	25	2	70	AEC-Q100 Qualified and PPAP Capable with Automotive Grade 0	5-Lead SOT-2235-Lead SOT-23A
MCP1799	80	4.5	45	3.3, 5.0	300	50	2	70	AEC-Q100 Qualified and PPAP Capable with Automotive Grade 0	3-Lead SOT-2233-Lead SOT-23A
MIC5253	100	2.7	6.5	1.5, 1.8, 1.85, 2.5, 2.6, 2.7, 2.8, 2.9, 3.0, 3.1, 3.2, 3.3	16575 μA	+0.570 Low Dropout			5-pin SC70
MIC5270	100	-2	-16	(-3.0, (-4.1, -4.5, 0, Adj.	500	35 μA	±2	50	Negative LDO	5-pin SOT-23
MIC5271	100	-3.3	-16	(-3.0, (-4.1, -4.5, 0, Adj.	500	25 μA	±2	50	Negative LDO	5 pin SOT-23
TC1015	100	2.7	6	1.8, 2.5, 2.7, 2.8, 2.95, 3.0, 3.3, 3.6, 4.0, 5.0	180	50 μA	±0.5	64	Low Dropout	5 pin SOT-23
TC1059	100	2.7	6	1.8, 2.5, 2.7, 2.8, 2.95, 3.0, 3.3, 3.6, 4.0, 5.0	180	50 μA	±0.5	64	Low Dropout	5 pin SOT-23
TC1071	100	2.7	6	1.23-5.5	180	50 μA	±0.5	64	Low Dropout	5 pin SOT-23
TC1073	100	2.7	6	2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0	180	50 μA	±0.5	64	Low Dropout	6 pin SOT-23
TC1224	100	2.7	6	2.5, 2.7, 2.8, 3.0, 3.3, 3.6, 4.0, 5.0	180	50 μA	±0.5	64	Low Dropout	5 pin SOT-23
TC2015	100	2.7	6	1.8, 2.7, 2.8, 3.0, 3.3	90	55 μA	±0.4	55	Low Dropout	5 pin SOT-23
TC2055	100	2.7	6	1.8, 2.7, 2.8, 3.0, 3.3	90	55 μA	±0.4	50	Low Dropout	5 pin SOT-23
TC59	100	-	-10	-8	380	3 μA	±0.5	50	Negative LDO	3 pin SOT-23A
TC1188	120	2.7	6	1.8, 2.8, 2.84, 3.15	130	50 μA	±0.5	80	High PSRR	5 pin SOT-23
TC1189	120	2.7	6	1.8, 2.8, 2.94, 3.15	130	50 μA	±0.5	80	High PSRR	5 pin SOT-23
MCP1810	150	2.5	5.5	1.2, 1.8, 2.5, 3.0, 3.3, 4.2	380	0.02 μA	±1	25	Ultra Low Is	5 pin SOT-23, 2 × 2 VDTN
MAQ5283	150	6	120	3.3, 5.0, Adj.	1800	8 μA	±3	75	High Input Voltage, High PSRR	8 pin SOIC
MIC2951	150	2	30	3.3, 5.0	320	120 μA	±1	67	Load Dump, Reverse Battery Protection	8 pin MSOP, 8 pin SOIC, 8 pin PDIF
MIC5205	150	2.5	18	2.5, 2.7, 2.8, 2.85, 2.9, 3.0, 3.1, 3.2, 3.3, 3.6, 3.8, 4.0, 5.0, Adj.	165	80 μA	±1	75	High Input Voltage, Small Package	5 pin SOT-23
MIC5206	150	2.5	18	2.5, 2.7, 3.0, 3.2, 3.3, 3.6, 3.8, 4.0, 5.0, Adj.	165	1.3mA	±1	75	High input Voltage, Small Package	8 pin MSOP, 5 pin SOT-23
MIC5225	150	2.5	18	1.5, 1.8, 2.5, 2.7, 3.0, 3.3, 5.0, Adj.	310	29 μA	±0.5	35	High input Voltage, Small Package, Reverse Current Protection	5 pin SOT-23
MIC5234	150	2.5	30	Adj.	320	20 μA	±1		High Input Voltage, Load Dump, Reverse Battery and Current Protection	8 pin SOIC
MIC5235	150	2.5	24	1.5, 1.8, 2.5, 2.7, 3.0, 3.3, 5.0, Adj.	310	18 μA	±1	35	High Input Voltage, Reverse Battery and Current Protection	5 pin SOT-23
MIC5236	150	2.5	30	2.5, 3.0, 3.3, 5.0, Adj.	300	20 μA	±1	55	High Input Voltage, Load Dump, Reverse Battery and Current Protection	8 pin MSOP, 8 pin SOIC
MIC5238	150	1.5	8	1.0, 1.1, 1.3	310	28 μA	±5	50	Low Dropout	5 pin TSOT, 5 pin SOT-23
MIC5247	150	2.7	8	1.5, 1.6, 1.8, 1.85, 2.0, 2.1, 2.2, 2.4	150	65 μA	±1	80	Low Dropout	5 pin TSOT, 6 pin VDTN, 5 pin SOT-23
MIC5248	150	2.7	8	1.2	-	100 μA	±3	80	Low Dropout	6 pin VDTN, 5 pin SOT-23
MIC5252	150	2.7	8	1.8, 2.5, 2.8, 2.85, 3.0, 4.75	135	50 μA	±1	60	Low Dropout	8 pin VDTN, 5 pin SOT-23
MIC5255	150	2.7	8	2.5, 2.6, 2.7, 2.75, 2.8, 2.85, 2.9, 3.0, 3.1, 3.2, 3.3, 3.5	135	90 μA	±1	80	Low Dropout	5 pin TSOT, 6 pin VDTN, 5 pin SOT-23

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MIC5256 1502.7 6				1.5, 1.8, 2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.1, 3.3	13590 μA +160 Low Dropout 5-pin TSOT, 5-pin SOT-23
MIC5258	150	2.7	6	1.2	-	65 μA	±3	-	Low Dropout	5-pin SOT-23
MIC5260 1502.7	5.5			1.5, 1.8, 1.85, 2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.1, 3.2, 3.3	210 /5 μA ±2.84 Low Dropout 5-pin TSOT, 8 pin UDFN
MIC5268	150	2.7	6	1.2	-	110 μA	±3	-	Low Dropout	5-pin SOT-23
MIC5283	150	6	120	3.3, 5.0, Adj.	1800	8 μA	±3	75	High Input Voltage, Load Dump	8 pin SOIC, 8-pin VDFN
MIC5295	150	2.3	24	3.0, 3.3, 5.0, Adj.	310	18 μA	+1	50	Reverse Battery and Current Protection	5-pin TO-252
MIC5301 1502.3	5.5			1.3, 1.5, 1.8, 2.1, 2.5, 2.6, 2.8, 2.85, 2.9, 3.0, 3.3, 4.6, Adj.	40	85 μA ±2.75	Ultra Low Dropout			5-pin TSOT, 6-pin UDFN, 6-pin WDFN
MIC5302	150	2.3	5.5	1.3, 1.5, 1.8, 2.1, 2.5, 2.6, 2.8, 2.85, 2.9, 3.0, 3.3, 4.6	50	85 μA	±2	65	Ultra Low Dropout	4-pin UDFN
MIC5304	150	2.3	5.5	5.15/1.85, 3.16/1.875, 3.2/1.8	65	24 μA	±0.5	65	Ultra Low Dropout	6-pin UDFN
MIC5305	150	2.25	5.5	1.5, 1.8, 2.0, 2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.3, 4.6, 4.75, Adj.	60	90 μA	±1	65	Ultra Low Dropout	5-pin TSOT, 6-pin UDFN, 6-pin UDFN
MIC5306	150	2.25	5.5	1.8, 2.5, 2.6	45	16 μA	±1	62	Ultra Low Dropout	5-pin TSOT
MIC5308	150	1.6	5.5	1.2, 1.8, 1.8, Adj.	45	23 μA	±2	90	Ultra Low Dropout, Ultra High PSRR	6-pin TSOT, 6-pin UDFN
MIC5317	150	2.5	6	1.0, 1.2, 1.5, 1.8, 2.5, 2.8, 3.0, 3.3	155	32 μA	±2	80	High PSRR	5-pin TSOT, 4-pin UDFN, 5-pin SOT 23
MIC5365 1502.5	5.5			1.5, 1.8, 2.0, 2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.3	15532 μA ±2.80 High PSRR					5-pin SC70, 5-pin TSOT, 4-pin UDFN
MIC5366 1502.5	5.5			1.5, 1.8, 2.0, 2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.3	15532 μA +2.80 High PSRR				5-pin SC70, 4-pin UDFN
MIC5376	150	2.5	5.5	2.8	120	29 μA	±2	60	Low Dropout	5-pin SC70, 4-pin UDFN
MIC5377	150	2.5	5.5	Adj.	120	29 μA	+2	60	Low Dropout	5-pin SC70, 8-pin UDFN
MIC5378	150	2.5	5.5	Adj.	120	29 μA	+2	60	Low Dropout	5-pin SC70, 8-pin UDFN
MCP1711	150	1.4	6	1.1-5.0	670	0.6 μA	±1	-	Ultra Low Io, Caploss	4-pin UDFN, 5-pin SOT 23
MCP1754	150	3.6	16	1.8-5.0	300	58 μA	±0.4	72	High Performance	8 pin DFN, 8 pin SOT 223, 5 pin SOT 23
MCP1754S	160	3.6	16	1.8-5.0	300	56 μA	±0.2	72	High Performance	3 pin SOT 89, 3 pin SOT 23A, 3-pin SOT-223, 8-pin DFN
MCP1804	150	2	28	1.8-18	300	50 μA	±2	60	High Input	3-pin SOT-89, 5-pin SOT-89, 3-pin SOT-223, 5-pin SOT-23
TC1017	150	2.7	6	1.8, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.3, 4.0	285	53 μA	+0.5	58	Low Dropout	5-pin SC-70, 5-pin SOT-23
TC1185	150	2.7	6	1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0	270	50 μA	+0.5	64	Low Dropout	5-pin SOT-23
TC1186	150	2.7	6	1.8, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3, 3.6, 4.0, 5.0	270	50 μA	±0.5	64	Low Dropout	5 pin SOT-23
TC1187	150	2.7	6	1.28-5.5	270	50 μA	±0.5	84	Low Dropout	5 pin SOT-23
TC2185	150	2.7	6	1.8, 2.7, 2.8, 3.0, 3.3	140	55 μA	+0.4	55	High Accuracy	5-pin SOT-23
TC2186	150	2.7	6	1.8, 2.7, 2.8, 3.0, 3.3	140	55 μA	±0.4	50	High Accuracy	5 pin SOT-23
MIC5207 180 2.5	16			1.8, 2.6, 2.8, 2.9, 3.0, 3.1, 3.2, 3.3, 4.0, 5.0, Adj.	165	80 μA	+3	75	High Input Voltage, Small Package	5-pin TSOT, 5-pin SOT-23
MIC5201	200	2.6	28	3.0, 3.3, 4.8, 5.0, Adj.	270	130 μA	±2	75	Low Dropout	8-pin MSOP, 3-pin SOT-223, 8-pin SOIC
MIC5267	200	2.5	5.5	1.2, 1.5, 3.3	180	29 μA	+2	65	Low Dropout	6-pin UDFN
MIC5368	200	2.5	5.5	1.2, 1.5, 3.3	180	29 μA	±1	65	Low Dropout	8 pin UDFN
MIC94000	200	1.8	3.6	Input Follower	170	136 μA	-	0	RippleBlocker	4 pin UDFN
MIC94310 200 1.8	5.6			1.2, 1.5, 1.8, 1.85, 2.5, 2.7, 2.8, 2.85, 3.0, 3.3	40	170 μA	+1	85	RippleBlocker	4-pin UDFN, 5-pin SOT-23
MIC2954	250	2	30	5.0, Adj.	375	140 μA	+1	-	Load Dump	3-pin SOT-223, 3-pin TO-220, 8-pin SOIC

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MCP1700	250	2.3	6	1.8, 2.5, 3.0, 3.3, 5.0	300	1.6 μA	±0.4	44	Low Is	3-pin TO-92, 3-pin SOT-89, 3-pin SOT-23, 6-pin DFN
MCP1702	250	2.7	13.2	1.2, 1.5, 1.8, 2.5, 2.8, 3.0, 3.3, 4.0, 5.0	605	2 μA	+0.4	44	Low Is	3-pin TO-92, 3-pin SOT-89, 3-pin SOT-23A
MCP1703A	250	2.7	16	1.2-5.5	605	2 μA	+0.4	35	High Input, Low Is	3-pin SOT-89, 3-pin SOT-23A, 3-pin SOT-223, 8-pin DFN
MAQ5300	300	2.3	5.5	1.5, 1.8, 2.5, 2.8, 2.85, 3.0, 3.3	100	85 μA	±2	65	Low Dropout	6-pin VDFN
MIC5249	300	2.7	6	1.5, 1.8, 2.5, 2.8, 2.85, 3.0, 3.3	340	85 μA	+1	65	High PSRR	8-pin MSOP
MIC5259	300	2.7	8	1.5, 1.8, 2.1, 2.5, 2.8, 2.85, 3.0, 3.3	300	105 μA	+0.5	70	Low Dropout	5-pin TSOT, 6-pin VDFN
MIC5303	300	2.3	5.5	1.5, 1.8, 2.1, 2.5, 2.6, 2.8, 2.85, 2.9, 3.0, 3.3	100	85 μA	±2	65	Ultra Low Dropout	4 pin UDFN
MIC5307	300	2.4	5.5	1.5, 1.8, 2.8, 3.0	120	20 μA	±1	62	Low Dropout	5 pin TSOT
MIC5309	300	1.7	5.5	1.2, 1.5, 1.9, Adj.	100	23 μA	±2	90	Ultra High PSRR	6-pin TSOT, 6-pin UDFN
MIC5318	300	2.3	6	1.5, 1.8, 2.5, 2.8, 3.3, Adj.	110	85 μA	±2	75	High PSRR	5-pin TSOT, 6-pin UDFN
MIC5323	300	2.65	5.5	1.6, 2.9, 3.3, Adj.	120	90 μA	±2	80	High PSRR	5 pin TSOT, 8 pin UDFN
MIC5327	300	2.3	5.5	1.8, 2.8	180	24 μA	±0.5	60	High PSRR	4-pin UDFN
MIC5337	300	2.3	5.5	1.8, 2.8	180	24 μA	±0.5	65	High PSRR	4-pin UDFN
MIC5353	300	2.6	6	1.8, 2.5, 2.6, 2.8, 3.0, 3.3, Adj.	180	90 μA	±2	60	Low Dropout	6-pin UDFN
MIC5363	300	2.5	5.5	1.2, 2.1, 2.8, 3.3	225	36 μA	±2	80	High PSRR	6-pin UDFN
MIC5364	300	2.5	5.5	1.2, 2.1, 2.8, 3.3	225	36 μA	±2	80	High PSRR	6-pin UDFN
MIC5501	300	2.5	5.5	1.2, 1.8, 2.8, 3.0, 3.3	180	36 μA	±2	60	Low Dropout	4 pin UDFN, 5 pin SOT-23
MIC5502	300	2.5	5.5	1.2, 1.8, 2.8, 3.0, 3.3	180	36 μA	±2	60	Low Dropout	4 pin UDFN
MIC5503	300	2.5	5.5	1.2, 1.8, 2.8, 3.0, 3.3	180	36 μA	±2	60	Low Dropout	4 pin UDFN
MIC5504	300	2.5	5.5	1.2, 1.8, 2.6, 3.0, 3.1, 3.3	180	36 μA	±2	60	Low Dropout	4 pin UDFN, 5-pin SOT-23
MIC5512	300	2.5	5.5	1.2, 1.6, 2.8, 3.3	180	36 μA	±2	65	Low Dropout	6-pin UDFN
MIC5514	300	2.5	5.5	1.2, 1.8, 2.9, 3.0, 3.3	180	36 μA	±2	65	Low Dropout	6-pin UDFN
MCP1755	300	3.6	18	1.8-5.5	300	69 μA	±0.85	80	High Input, Low Dropout	3 pin SOT-223, 8-pin DFN, 5 pin SOT-223, 5-pin SOT-23
MCP1755S	300	3.6	18	1.8-5.5	300	86 μA	±0.85	80	Low Dropout	3 pin SOT-223, 8-pin DFN
MCP1924	300	2.1	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	200	120 μA	±0.4	55	High Accuracy	5 pin SOT-223, 5-pin SOT-23
MCP1924S	300	2.1	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	200	120 μA	±0.4	55	High Accuracy	3 pin SOT-223,
TC1107	300	2.7	6	2.5, 2.7, 2.8, 3.0, 3.3, 5.0	240	50 μA	±0.5	60	Low Dropout	8-pin MSOP, 8-pin SOIC 150mil
TC1108	300	2.7	6	2.5, 2.7, 2.8, 3.0, 3.3, 5.0	240	50 μA	+0.5	60	Low Dropout	3 pin SOT-223
TC1173	300	2.7	6	3.3, 5.0, 2.5, 2.7, 2.8, 3.0	240	50 μA	±0.5	60	Low Dropout	8-pin MSOP, 8-pin SOIC 150mil
TC1174	300	2.7	6	1.23-5.5	270	50 μA	+0.5	60	Low Dropout	8-pin MSOP, 8-pin SOIC 150mil
TC1263	300	2.7	6	2.5, 2.8, 3.0, 3.3, 5.0	240	50 μA	±0.5	50	Low Dropout	8-pin MSOP
TC1300	300	2.7	6	2.5, 2.7, 2.8, 2.65, 3.0, 3.3	210	80 μA	+0.5	60	Low Dropout	8-pin MSOP
MIC28201	400	2	28	3.3, 4.8, 5.0, 12	400	140 μA	±1	70	Load Dump, Reverse Battery Protection	5 pin TO-220, 5 pin DDPAK, 8-pin SOIC
MIC28202	400	2	28	Adj.	400	140 μA	+1	70	Load Dump, Reverse Battery Protection	5 pin TO-220, 5 pin DDPAK
MIC28204	400	2	28	5.0, Adj.	400	140 μA	+1	70	Load Dump, Reverse Battery Protection	8-pin SOIC, 8-pin PDIP
MIC2820A	400	2	28	3.3, 4.8, 5.0, 12	400	140 μA	+1	70	Load Dump, Reverse Battery Protection	3 pin SOT-223, 3-pin TO-220
MIC5325	400	1.7	5.5	1.2, 1.5, 1.8, 3.3, 3.6	110	35 μA	+2	65	Low Noise	8-pin UDFN
MIC47050	500	1	3.6	1.2, 1.8, Adj.	44	6 μA	±0.5	50	Ultra Low Dropout	6 pin UDFN, 6 pin VDFN
MIC47053	500	1	3.6	Adj.	44	6 μA	±2	55	Ultra Low Dropout	8-pin UDFN
MIC5209	500	2.5	18	1.8, 2.5, 3.0, 3.3, 3.6, 4.2, 5.0, Adj.	350	8 mA	±1	75	High Input Voltage, Small Package	8 pin SOIC, 3 pin SOT-223, 8 pin VDFN, 5 pin DDPAK
MIC5216	500	2.5	12	2.5, 3.3, 3.6, 5.0	300	8 mA	±1	75	High Input Voltage, Small Package	8-pin MSOP, 5-pin SOT-23
MIC5219 5002.5	12			2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.1, 3.3, 3.6, 5.0, Adj.	350	12 mA	±1	75	High Input Voltage, Small Package	8-pin MSOP, 8-pin UDFN, 8-pin VDFN, 5-pin SOT-23

www.microchip.com/analloy
POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MIC5287	500	2.5	16	2.5, 3.3, 5.0	300	8 mA	±3	75	High input Voltage, Reverse Battery Protection	3-pin TO-263, 3-pin TO-220
MIC5239	500	2.3	30	1.5, 1.8, 2.5, 3.0, 3.3, 5.0, Adj.	350	23 μA	+1	50	Reverse Battery and Current Protection	8-pin MSOP, 8-pin SOIC, 3-pin SOT-223
MIC5319 5002.6	5.5			1.379, 1.8, 1.85, 2.5, 2.6, 2.7, 2.8, 2.85, 2.9, 3.0, 3.3, 5.0, Adj.	200	50 μA	±1	70	High PSRR	5-pin TSOT, 6-pin VDFN
MIC5524	500	2.5	5.5	1.2, 1.6, 2.8, 3.0, 3.3	260	38 μA	+2	65	Low Noise	4-pin UDFN
MIC5528	500	2.5	5.5	3.3	260	38 μA	±2	70	Low Dropout	6-pin UDFN, 6-pin X2DFN
MIC94305	500	1.8	3.6	Input Follower	170	150 μA	-	0	RippleBlocker	8-pin UDFN
MIC94325	500	1.8	3.6	Adj.	100	170 μA	+1	85	RippleBlocker	6-pin UDFN
MIC94345	500	1.8	3.6	1.2, 1.5, 1.8, 2.8, 3.3	100	170 μA	+1	85	RippleBlocker	6-pin UDFN
MIC94355	500	1.8	3.6	1.2, 1.5, 1.8, 2.8, 3.3	100	170 μA	+1	85	RippleBlocker	6-pin UDFN
MCP1725	500	2.3	6	0.8, 1.2, 1.6, 2.5, 3.0, 3.3, 5.0	210	120 μA	±0.5	60	Low Dropout	8-pin DFN, 8-pin SOIC 150mil
MCP1825	500	2.1	6	0.8, 1.2, 1.6, 2.5, 3.0, 3.3, 5.0	210	120 μA	±0.5	60	Low Dropout	5-pin TO-220, 5-pin DDPAK, 5-pin SOT-223
MCP1825S	500	2.1	6	0.8, 1.2, 1.6, 2.5, 3.0, 3.3, 5.0	300	120 μA	±0.5	60	Low Dropout	3-pin TO-220, 3-pin SOT-223, 3-pin DDPAK
TC1262	500	2.7	6	2.5, 2.6, 3.0, 3.3, 5.0	350	80 μA	±0.5	64	Low Dropout	3-pin TO-220, 3-pin SOT-223, 3-pin DDPAK
TC1263	500	2.7	6	2.5, 2.6, 3.0, 3.3, 5.0	350	80 μA	±0.5	64	Low Dropout	5-pin TO-220, 5-pin DDPAK, 8-pin SOIC 150mil
MIC283/1	750	4.3	26	3.3, 5.0, 12	370	160 μA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DDPAK
MIC28372	750	4.3	26	Adj.	370	160 μA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DDPAK
MIC2837A	750	4.3	26	3.3, 5.0, 12	370	160 μA	+1	-	Load Dump, Reverse Current Protection	3-pin TO-263, 3-pin TO-220
MIC3775	750	2.25	6	1.5, 1.65, 1.8, 2.5, 3.0, 3.3, Adj.	280	6.5 mA	+1	60	Reverse Current Protection	8-pin MSOP
MIC3875	750	2.25	16	1.65, 1.9, 2.5, 3.0, 3.3, 5.0, Adj.	300	7.5 mA	±1	55	Reverse Current Protection	8-pin MSOP
TC1264	800	2.7	6	1.9, 2.5, 3.0, 3.3	450	80 μA	±0.5	64	Low Dropout	3-pin TO-220, 3-pin SOT-223, 3-pin DDPAK
TC1265	800	2.7	6	1.9, 2.5, 3.0, 3.3	450	80 μA	±0.5	64	Low Dropout	5-pin TO-220, 5-pin DDPAK, 8-pin SOIC 150mil
TC2117	800	2.7	6	1.9, 2.5, 3.0, 3.3	600	80 μA	±0.5	55	Low Dropout	3-pin SOT-223, 3-pin DDPAK
MIC37100	1000	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	280	400 μA	±1	50	Reverse Battery and Current Protection	3-pin SOT-223
MIC37101	1000	2.25	6	1.5, 1.65, 1.8, 2.1, 2.5, 3.3	290	400 μA	+1	50	Reverse Battery and Current Protection	8-pin SOIC
MIC37102	1000	2.25	6	Adj	280	400 μA	±1	50	Reverse Battery and Current Protection	8-pin SOIC, 5-pin SPAK
MIC38100	1000	2.25	16	1.8, 2.5, 3.3, 5.0	410	6.5 mA	+1	55	Reverse Battery and Current Protection	3-pin SOT-223
MIC39101	1000	2.25	16	1.9, 2.5, 3.3, 5.0	410	6.5 mA	±1	55	Reverse Battery and Current Protection	8-pin SOIC
MIC39102	1000	2.25	16	Adj.	410	8.5 mA	±1	55	Reverse Battery and Current Protection	8-pin SOIC
MIC47100	1000	1	3.6	0.8, 1.0, 1.2, Adj.	60	350 μA	±0.5	60	Ultra Low Dropout	8-pin MSOP, 8-pin VDFN
MIC89101	1000	1.95	5.5	1.8	215	11 mA	±2	55	Low Dropout	10-pin VDFN
MIC89103	1000	1.95	5.5	Adj.	215	11 mA	±2	55	Low Dropout	10-pin VDFN
MCP1726	1000	2.3	6	0.8, 1.2, 1.8, 2.5, 3.3, 5.0	500	130 μA	±0.5	54	Low Dropout	8-pin DFN, 8 pin SOIC 150mil
MCP1826	1000	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	225	120 μA	±0.5	60	Low Dropout	5-pin TO-220, 5-pin DDPAK, 5-pin SOT-223
MCP1826S	1000	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	225	120 μA	±0.5	60	Low Dropout	3-pin TO-220, 3-pin SOT-223, 3-pin DDPAK
MIC2840A	1250	2	28	3.3, 5.0, 12	400	35 mA	±1	-	Load Dump, Reverse Current Protection	3-pin TO-263, 3-pin TO-220
MIC2841A	1250	2	28	Adj.	430	35 mA	+1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DDPAK
MIC29150	1500	2.25	26	3.3, 5.0, 12	350	22 mA	+1	-	Load Dump, Reverse Current Protection	3-pin TO-263, 3-pin TO-220
MIC29151	1500	2.25	26	3.3, 5.0, 12	350	22 mA	+1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DDPAK

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MIC29152	1500	2.25	28	Adj.	350	22 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-252, 5-pin TO-220, 5-pin DOPAK
MIC37139	1500	2.25	6	1.8, 2.5	500	17 mA	+1	50	Reverse Battery and Current Protection	Please call for package information
MIC37150	1500	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	325	17 mA	±1	45	Reverse Battery and Current Protection	3-pin SPAK
MIC37151	1500	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	325	17 mA	±1	45	Reverse Battery and Current Protection	5-pin SPAK
MIC37152	1500	2.25	6	Adj.	325	17 mA	+1	45	Reverse Battery and Current Protection	8-pin SOIC, 5-pin SPAK
MIC37153	1500	2.25	6	Adj.	325	17 mA	±1	45	Reverse Battery and Current Protection	8-pin SOIC
MIC39150	1500	2.25	18	1.65, 1.8, 2.5	375	17 mA	±1	53	Reverse Battery and Current Protection	3-pin TO-263, 3-pin TO-220
MIC39151	1500	2.25	18	1.65, 1.8, 2.5	375	17 mA	±1	53	Reverse Battery and Current Protection	5-pin TO-220, 5-pin DOPAK
MIC39152	1500	2.25	18	Adj.	375	17 mA	±1	53	Reverse Battery and Current Protection	5-pin TO-252, 5-pin DOPAK
MIC47150	1500	1.4	6.5	Adj.	280	15 mA	+1	55	Low Dropout	5-pin TO-252
MIC49150	1500	1.4	6.5	0.9, 1.2, 1.5, 1.8, Adj.	280	15 mA	±1	57	Low Dropout	9-pin MSOP, 5-pin SPAK
MIC56150	1500	1	3.8	Adj.	100	12.5 mA	±1	60	Ultra Low Dropout	8-pin SOIC
MIC81150	1500	1.1	3.8	1.0, Adj.	75	7.8 mA	±1	50	Ultra Low Dropout, Soft Start	10 pin MSOP, 10 pin VDFN
MCP1727	1500	2.3	6	0.9, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	330	120 μA	+0.5	60	Low Dropout	8-pin DFN, 8-pin SOIC 150mil
MCP1927	1500	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	330	120 μA	+0.5	60	Low Dropout	5-pin TO-220, 5-pin DOPAK
MCP1827S	1500	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	330	120 μA	+0.5	60	Low Dropout	3-pin TO-220, 3-pin DOPAK
MIC49200	2000	1.4	6.5	1.0, 1.9, Adj.	400	15 mA	±1	83	Low Dropout	5-pin SPAK
MIC68200	2000	1.65	5.5	1.2, 1.5, 1.8, 2.5, 3.3, Adj	300	42 mA	±1	60	Low Dropout, Soft Start	10 pin VDFN
MIC37252	2500	3	6	Adj.	550	40 mA	+2	50	Reverse Current Protection	5-pin SPAK, 5-pin DOPAK
MIC2937A	750	4.3	28	3.3, 5.0, 12	370	160 μA	±1	-	Load Dump, Reverse Current Protection	3-pin TO-263, 3-pin TO-220
MIC3775	750	2.25	6	1.5, 1.65, 1.8, 2.5, 3.0, 3.3, Adj.	280	8.5 mA	±1	50	Reverse Current Protection	8-pin MSOP
MIC3975	750	2.25	10	1.65, 1.8, 2.5, 3.0, 3.3, 5.0, Adj.	300	7.5 mA	±1	55	Reverse Current Protection	8-pin MSOP
TC1264	800	2.7	6	1.9, 2.5, 3.0, 3.3	450	80 μA	+0.5	64	Low Dropout	3 pin TO-220, 3 pin SOT-223, 3-pin DOPAK
TC1265	800	2.7	6	1.9, 2.5, 3.0, 3.3	450	80 μA	+0.5	64	Low Dropout	5 pin TO-220, 5 pin DOPAK, 8 pin SOIC 150mil
TC2117	800	2.7	6	1.9, 2.5, 3.0, 3.3	600	80 μA	+0.5	55	Low Dropout	3-pin SOT-223, 3-pin DOPAK
MIC37100	1000	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	280	400 μA	±1	50	Reverse Battery and Current Protection	3 pin SOT-223
MIC37101	1000	2.25	6	1.5, 1.65, 1.8, 2.1, 2.5, 3.3	280	400 μA	+1	50	Reverse Battery and Current Protection	8-pin SOIC
MIC37102	1000	2.25	6	Adj.	280	400 μA	±1	50	Reverse Battery and Current Protection	8-pin SOIC, 5-pin SPAK
MIC39100	1000	2.25	18	1.8, 2.5, 3.3, 5.0	410	8.5 mA	±1	55	Reverse Battery and Current Protection	3 pin SOT-223
MIC39101	1000	2.25	18	1.9, 2.5, 3.3, 5.0	410	8.5 mA	+1	55	Reverse Battery and Current Protection	8-pin SOIC
MIC39102	1000	2.25	18	Adj.	410	6.5 mA	±1	55	Reverse Battery and Current Protection	8-pin SOIC
MIC47100	1000	1	3.6	0.9, 1.0, 1.2, Adj.	90	350 μA	+0.5	80	Ultra Low Dropout	8-pin MSOP, 8-pin VDFN
MIC69101	1000	1.65	5.5	1.8	215	11 mA	±2	55	Low Dropout	10 pin VDFN
MIC69103	1000	1.65	5.5	Adj.	215	11 mA	+2	55	Low Dropout	10 pin VDFN
MCP1726	1000	2.3	6	0.8, 1.2, 1.8, 2.5, 3.3, 5.0	500	130 μA	+0.5	54	Low Dropout	9-pin DFN, 8-pin SOIC 150mil
MCP1926	1000	2.3	6	0.9, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	225	120 μA	+0.5	60	Low Dropout	5 pin TO-220, 5 pin DOPAK, 6 pin SOT-223
MCP1928S	1000	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	225	120 μA	+0.5	60	Low Dropout	3 pin TO-220, 3 pin SOT-223, 3 pin DOPAK
MIC2940A	1250	2	26	3.3, 5.0, 12	400	35 mA	±1	-	Load Dump, Reverse Current Protection	3-pin TO-263, 3-pin TO-220
MIC2941A	1250	2	26	Adj.	400	35 mA	±1	-	Load Dump, Reverse Current Protection	5 pin TO-220, 5 pin DOPAK

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MIC29150	1500	2.25	28	3.3, 5.0, 12	350	22 mA	±1	-	Load Dump, Reverse Current Protection	3-pin TO-263, 3-pin TO-220
MIC29151	1500	2.25	28	3.3, 5.0, 12	350	22 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29152	1500	2.25	28	Adj.	350	22 mA	+1	-	Load Dump, Reverse Current Protection	5-pin TO-252, 5-pin TO-220, 5-pin DOPAK
MIC37139	1500	2.25	6	1.8, 2.5	500	17 mA	±1	50	Reverse Battery and Current Protection	Please call for package information
MIC37150	1500	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	325	17 mA	+1	45	Reverse Battery and Current Protection	3-pin SPAK
MIC37151	1500	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	325	17 mA	±1	45	Reverse Battery and Current Protection	5-pin SPAK
MIC37152	1500	2.25	6	Adj.	325	17 mA	±1	45	Reverse Battery and Current Protection	8-pin SOIC, 5-pin SPAK
MIC37153	1500	2.25	6	Adj.	325	17 mA	±1	45	Reverse Battery and Current Protection	9-pin SOIC
MIC39150	1500	2.25	18	1.65, 1.8, 2.5	375	17 mA	±1	53	Reverse Battery and Current Protection	3 pin TO-263, 3 pin TO-220
MIC39151	1500	2.25	18	1.65, 1.8, 2.5	375	17 mA	+1	53	Reverse Battery and Current Protection	5-pin TO-220, 5-pin DOPAK
MIC39152	1500	2.25	18	Adj.	375	17 mA	±1	53	Reverse Battery and Current Protection	5-pin TO-252, 5-pin DOPAK
MIC47150	1500	1.4	6.5	Adj.	290	15 mA	±1	55	Low Dropout	5-pin TO-252
MIC49150	1500	1.4	6.5	0.9, 1.2, 1.5, 1.8, Adj.	280	15 mA	±1	57	Low Dropout	8 pin MSOP, 5 pin SPAK
MIC59150	1500	1	3.8	Adj.	100	12.5 mA	+1	60	Ultra Low Dropout	8-pin SOIC
MIC81150	1500	1.1	3.8	1.0, Adj.	75	7.5 mA	±1	50	Ultra Low Dropout, Soft Start	10-pin MSOP, 10-pin VDTN
MCP1727	1500	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	330	120 μA	±0.5	60	Low Dropout	8-pin DFN, 8-pin SOIC 150ml
MCP1827	1500	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	330	120 μA	±0.5	60	Low Dropout	5-pin TO-220, 5-pin DOPAK
MCP1827S	1500	2.3	6	0.8, 1.2, 1.8, 2.5, 3.0, 3.3, 5.0	330	120 μA	±0.5	60	Low Dropout	3 pin TO-220, 3 pin DOPAK
MIC49200	2000	1.4	6.5	1.0, 1.8, Adj.	400	15 mA	+1	83	Low Dropout	5-pin SPAK
MIC68200	2000	1.85	5.5	1.2, 1.5, 1.8, 2.5, 3.3, Adj.	300	42 mA	±1	60	Low Dropout, Soft Start	10-pin VDFN
MIC37252	2500	3	6	Adj.	550	40 mA	±2	50	Reverse Current Protection	5-pin SPAK, 5-pin DOPAK
MIC29300	3000	2.25	28	3.3, 5.0, 12	370	37 mA	±1	-	Load Dump, Reverse Current Protection	3 pin TO-263, 3 pin TO-220
MIC29301	3000	2.25	28	3.3, 5.0, 12	370	37 mA	+1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29302	3000	2.25	28	Adj.	370	37 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29302A	3000	3	16	Adj.	450	60 mA	±1	-	Reverse Battery and Current Protection	5 pin TO-252, 5 pin DOPAK
MIC29302H	3000	2.25	28	Adj.	370	37 mA	+1	-	Load Dump, Reverse Current Protection	5-pin DOPAK
MIC29303	3000	2.25	28	Adj.	370	37 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29310	3000	2.3	16	3.3, 5.0	600	60 mA	±1	-	Load Dump, Reverse Current Protection	3 pin TO-263, 3 pin TO-220
MIC29312	3000	2.3	16	Adj.	600	60 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC35302	3000	2.25	6	Adj.	370	20 mA	+1	50	Reverse Battery and Current Protection	5-pin TO-252
MIC37300	3000	2.25	6	1.5, 1.65, 1.8, 2.5, 3.3	300	27 mA	±1	50	Reverse Current Protection	3 pin SPAK
MIC37301	3000	2.25	6	1.5, 1.8, 2.5, 3.3	300	27 mA	+1	50	Reverse Current Protection	8-pin SOIC, 5-pin SPAK
MIC37302	3000	2.25	6	Adj.	300	27 mA	±1	50	Reverse Current Protection	5-pin SPAK, 5-pin DOPAK
MIC37303	3000	2.25	6	Adj.	300	27 mA	±1	50	Reverse Current Protection	8 pin SOIC, 8 pin VDFN
MIC38300	3000	2.25	18	1.9, 2.5	365	45 mA	-1	-	Reverse Battery and Current Protection	3 pin TO-263, 3 pin TO-220
MIC38301	3000	2.25	18	1.9, 2.5	365	45 mA	-1	-	Reverse Battery and Current Protection	5 pin TO-220, 5 pin DOPAK
MIC38302	3000	2.25	18	Adj.	385	45 mA	+1	-	Reverse Battery and Current Protection	5 pin DOPAK
MIC47300	3000	1.4	6.5	Adj.	230	25 mA	+1	-	Low Dropout	5-pin TO-252
MIC49300	3000	1.4	6.5	0.9, 1.2, 1.5, 1.8, Adj.	280	25 mA	+1	-	Low Dropout	5-pin SPAK
MIC68300	3000	1	3.8	1.2V, Adj.	205	30 mA	±1	65	Low Dropout	8 pin SOIC, 8 pin DOPAK
MIC61300	3000	1.1	3.6	1.0, Adj.	150	7.6 mA	+1	55	Low Dropout, Soft Start	10-pin MSOP, 10-pin VDFN

www.microchip.com/analloy

POWER MANAGEMENT: Single Output Linear Regulators

Part #	Output Current (mA)	Vin Min (V)	Vin Max (V)	Vout (V)	Voltage Drop Typical (mV)	Iq Typical (μA)	Output Accuracy (%)	PSRR 1 kHz (dB)	Features Packages
MIC89301 300	61.655.512	275	32 mA	2.65Low Dropout						8-pin SOIC, 5-pin SPAK, 5-pin DOPAK
MIC89302	3000	1.65	5.5	Adj.	275	32 mA	±2	55	Low Dropout	5-pin SPAK, 5-pin DOPAK
MIC89303	3000	1.65	5.5	Adj.	275	32 mA	±2	55	High Current	8-pin SOIC, 12 pin VDFN
MIC89400	4000	1.65	5.5	1.8, Adj.	380	90 mA	+2	50	Low Dropout, Soft Start	16-pin VQFN
MIC89401	4000	1.65	5.5	Adj.	380	90 mA	±2	50	Low Dropout, Soft Start	16-pin VQFN
MIC29500	5000	2.25	28	3.3, 5.0, 12	370	70 mA	±1	-	Load Dump, Reverse Current Protection	3-pin TO-220
MIC29501	5000	2.25	28	3.3, 5.0, 12	370	70 mA	+1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29502	5000	2.25	28	Adj.	370	70 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29503	5000	2.25	28	Adj.	370	70 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220, 5-pin DOPAK
MIC29510	5000	2.3	16	3.3, 5.0	700	100 mA	±1	-	Load Dump, Reverse Current Protection	3-pin TO-220
MIC29512	5000	2.3	16	Adj.	700	100 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-220
MIC37501	5000	2.3	6	1.5, 1.65, 1.8, 2.5, 3.3	330	57 mA	+1	-	Reverse Current Protection	7-pin SPAK
MIC37502	5000	2.3	6	Adj.	330	57 mA	±1	-	Reverse Current Protection	7-pin SPAK, 5-pin DOPAK
MIC39500	5000	2.25	16	1.8, 2.5	400	70 mA	+1	30	Reverse Battery and Current Protection	3-pin TO-263, 3-pin TO-220
MIC39501	5000	2.25	16	1.8, 2.5	400	70 mA	±1	30	Reverse Battery and Current Protection	5-pin TO-220, 5-pin DOPAK
MIC49500	5000	1.4	6	0.8, 1.2, Adj.	280	55 mA	+1	75	Low Dropout	7-pin SPAK
MIC89502	5000	1.65	5.5	Adj.	250	54 mA	±1	52	High Current	7-pin SPAK
MIC29712	7500	2.3	16	Adj.	700	250 mA	±2	-	High Current	5-pin TO-220
MIC29751	7500	2.5	28	3.3, 5.0	425	120 mA	±1	-	Load Dump, Reverse Current Protection	5-pin TO-247
MIC29752	7500	2.5	28	Adj.	425	120 mA	+1	-	Load Dump, Reverse Current Protection	5-pin TO-247

POWER MANAGEMENT: Multiple Output Linear Regulators

Part #	Product Type	IOUT #1	IOUT #2	IOUT #3	IOUT #4	VIN Min. (V)	VIN Max. (V)	VOUT (V)	Voltage Drop Typ. (mV)	IGND Typ. (μA)	PSRR 1kHz (dB)	Packages
MIC2210	Dual LDOs	150 mA	300 mA	-	-	2.25	5.5	Please Refer to Datasheet	120/140	48/60 μA	60	10-pin VDFN
MIC2211	Dual LDOs	150 mA	300 mA	-	-	2.25	5.5	Please Refer to Datasheet	120/140	49/60 μA	60	10-pin VDFN
MIC2212	Dual LDOs	150 mA	300 mA	-	-	2.25	5.5	Please Refer to Datasheet	120/140	48/60 μA 60	10-pin VDFN
MIC2213	Dual LDOs	150 mA	300 mA	-	-	2.25	5.5	Please Refer to Datasheet	120/140	49/60 μA	60	10-pin VDFN, 16-pin VDFN
MIC2214	Dual LDOs	150 mA	300 mA	-	-	2.25	5.5	Please Refer to Datasheet	120/140	49/60 μA	60	10-pin VDFN, 16-pin VDFN
MIC2215	Multi Channel LDOs	250 mA	250 mA	250 mA	-	2.25	5.5	Please Rotor to Datasheet	100	110 μA	70	18-pin VDFN
MIC2219	Dual LDOs	150 mA	300 mA	-	-	2.25	5.5	Please Refer to Datasheet	120	48 μA	60	10-pin VDFN
MIC5202	Dual LDOs	100 mA	100 mA	-	-	2.5	28	Please Rotor to Datasheet	225	170 μA	75	8-pin SOC
MIC5208	Dual LDOs	50 mA	50 mA	-	-	2.5	16	Please Refer to Datasheet	250	180 μA	-	8-pin MSOP
MIC5210	Dual LDOs	150 mA	150 mA	-	-	2.5	16	Please Rotor to Datasheet	165	80 μA	75	8-pin MSOP
MIC5211	Dual LDOs	60 mA	60 mA	-	-	2.5	16	Please Rotor to Datasheet	250	90 μA	80	6-pin SCT 23
MIC5212	Dual LDOs	500 mA	500 mA	-	-	4	16	Please Refer to Datasheet	350	1.5mA	75	8-pin SOC
MIC5264	Dual LDOs	150 mA	150 mA	-	-	2.7	5.5	Please Rotor to Datasheet	210	75 μA	64	10-pin VDFN
MIC5310	Dual LDOs	150 mA	150 mA	-	-	2.3	5.5	Please Rotor to Datasheet	35	85 μA	70	8-pin UDFN, 8-pin VDFN
MIC5311	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	120	28 μA	60	10-pin VDFN
MIC5312	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Rotor to Datasheet	120	28 μA	60	10 pin VDFN
MIC5315	Dual LDOs	300 mA	300 mA	-	-	1.7	5.5	Please Refer to Datasheet	85	30 μA	65	10-pin UDFN

POWER MANAGEMENT: Multiple Output Linear Regulators

Part #	Product Type	Iout #1	Iout #2	Iout #3	Iout #4	Vin Min. (V)	Vin Max. (V)	Vout (V)	Voltage Drop Typ. (mV)	IGND Typ. (μA)	PSRR 1kHz (dB)	Packages
MIC5318	Dual LDOs	300 mA	300 mA	-	-	1.7	5.5	Please Refer to Datasheet	85	30 μA	65	12-pin UDFN
MIC5320	Dual LDOs	150 mA	150 mA	-	-	2.3	5.5	Please Refer to Datasheet	85	85 μA	65	6-pin TSOT, 6-pin UDFN, 6-pin WDFN
MIC5321	Dual LDOs	150 mA	150 mA	-	-	2.3	5.5	Please Refer to Datasheet	35	85 μA	75	6-pin TSOT, 6-pin UDFN, 6-pin WDFN
MIC5322	Dual LDOs	150 mA	150 mA	-	-	2.3	5.5	Please Refer to Datasheet	35	150 μA	75	6-pin UDFN
MIC5330	Dual LDOs	300 mA	300 mA	-	-	2.3	5.5	Please Refer to Datasheet	75	85 μA	70	8-pin VDFN
MIC5331	Dual LDOs	300 mA	300 mA	-	-	2.3	5.5	Please Refer to Datasheet	120	40 μA	65	8-pin UDFN
MIC5332	Dual LDOs	300 mA	300 mA	-	-	2.3	5.5	Please Refer to Datasheet	120	40 μA	65	8-pin UDFN
MIC5333	Dual LDOs	300 mA	300 mA	-	-	2.3	5.5	Please Refer to Datasheet	120	40 μA	65	10-pin UDFN
MIC5335	Dual LDOs	300 mA	300 mA	-	-	2.3	5.5	Please Refer to Datasheet	75	90 μA	65	6-pin UDFN
MIC5338	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	220	38 μA	55	6-pin UDFN
MIC5339	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	220	38 μA	55	6-pin UDFN
MIC5350	Dual LDOs	300 mA	300 mA	-	-	2.6	5.5	Please Refer to Datasheet	75/125	95 μA	50	8-pin UDFN
MIC5355	Dual LDOs	500mA	500 mA	-	-	2.5	5.5	Please Refer to Datasheet	350	38 μA	55	8-pin MSOP
MIC5358	Dual LDOs	500mA	500 mA	-	-	2.5	5.5	Please Refer to Datasheet	350	38 μA	55	8-pin MSOP, 8-pin VDFN
MIC5357	Dual LDOs	500mA	500 mA	-	-	2.6	5.5	Please Refer to Datasheet	130	95 μA	70	8-pin MSOP
MIC5370	Dual LDOs	150mA	150 mA	-	-	2.3	5.5	Please Refer to Datasheet	155	32 μA	60	6-pin UDFN
MIC5371	Dual LDOs	150mA	150 mA	-	-	2.5	5.5	Please Refer to Datasheet	155	32 μA	60	6-pin UDFN
MIC5373	Multi-Channel LDOs	200mA	200 mA	200 mA	-	1.7	5.5	Please Refer to Datasheet	170	32 μA	55	16-pin UDFN
MIC5374	Multi-Channel LDOs	200 mA	200 mA	200 mA	1 mA	1.7	5.5	Please Refer to Datasheet	170	42 μA	55	16-pin UDFN
MIC5380	Dual LDOs	150 mA	150 mA	-	-	2.5	5.5	Please Refer to Datasheet	155	32 μA	60	10 pin UDFN
MIC5381	Dual LDOs	150 mA	150 mA	-	-	2.5	5.5	Please Refer to Datasheet	155	32 μA	60	10-pin UDFN
MIC5383	Multi-Channel LDOs	200 mA	200 mA	200 mA	-	1.7	5.5	Please Refer to Datasheet	170	32 μA	55	16 pin UDFN
MIC5384	Multi-Channel LDOs	200 mA	200 mA	200 mA	1 mA	1.7	5.5	Please Refer to Datasheet	170	42 μA	55	16 pin UDFN
MIC5385	Multi-Channel LDOs	150 mA	150 mA	150 mA	-	2.5	5.5	Please Refer to Datasheet	180	32 μA	70	8-pin UDFN
MIC5387	Multi-Channel LDOs	150 mA	150 mA	150 mA	-	2.5	5.5	Please Refer to Datasheet	180	32 μA	70	6-pin UDFN
MIC5388	Dual LDOs	200 mA	200 mA	-	-	2.5	5.5	Please Refer to Datasheet	175	32 μA	73	6-pin WLOSP
MIC5389	Dual LDOs	200 mA	200 mA	-	-	2.5	5.5	Please Refer to Datasheet	175	32 μA	73	6-pin WLOSP
MIC5392	Dual LDOs	150 mA	150 mA	-	-	2.5	5.5	Please Refer to Datasheet	155	57 μA	60	6-pin UDFN, 6-pin X2DFN
MIC5393	Dual LDOs	150 mA	150 mA	-	-	2.5	5.5	Please Refer to Datasheet	155	57 μA	60	6-pin X2DFN
MIC5396	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	160	37 μA	60	8-pin UDFN, 8-pin X2DFN
MIC5397	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	160	37 μA	60	8-pin UDFN, 8-pin X2DFN
MIC5398	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	160	37 μA	60	8-pin X2DFN
MIC5399	Dual LDOs	300 mA	300 mA	-	-	2.5	5.5	Please Refer to Datasheet	160	37 μA	60	8-pin UDFN, 8-pin X2DFN
MIC68220	Dual LDOs	2.0A	2.0A	-	-	1.65	5.5	Please Refer to Datasheet	300	15 mA	40	20-pin VDFN
TC1307	Multi-Channel LDOs	150 mA	150 mA	150 mA	150 mA	2.7	6	Please Refer to Datasheet	200	220 μA	60	16 pin CSOP
TC1301A	Dual LDOs	300 mA	150 mA	-	-	2.7	6	Please Refer to Datasheet	104	103 μA	58	8-pin MSOP, 8-pin DFN
TC1301B	Dual LDOs	300 mA	150 mA	-	-	2.7	6	Please Refer to Datasheet	104	114 μA	58	8-pin MSOP, 8-pin DFN
TC1302A	Dual LDOs	300 mA	150 mA	-	-	2.7	6	Please Refer to Datasheet	104	103 μA	58	8-pin MSOP, 8-pin DFN
TC1302B	Dual LDOs	300 mA	150 mA	-	-	2.7	6	Please Refer to Datasheet	104	114 μA	58	8-pin MSOP, 8-pin DFN

POWER MANAGEMENT: Linear Regulators - LDO Controller and SIM Card

Part #	Product Type	Vin Min. (V)	Vin Max. (V)	Vout (V)	IGND Typ. (μA)	VRLF (V)	VLN (V)	Internal Charge Pump	External N-Ch. MOSFET	Packages
MIC5166	LDO Controllers	3	36	3.3, 5.0, Adj.	2.7	1.235	2.4	-	Yes	8-pin SOIC, 8-pin PDIF
MIC5167	LDO Controllers	3	36	3.3, 5.0, 12	4.5	1.235	2.4	Yes	Yes	14-pin PDIF, 14-pin SOIC 150mil
MIC5168	LDO Controllers	3	36	5.0, Adj.	4.5	1.235	2.4	Yes	Yes	14-pin PDIF, 14-pin SOIC 150mil
MIC5169	LDO Controllers	1.65	5.5	1.8, 3.0, Adj.	10	1.235	1.2	-	Yes	6-pin SOT-23
MIC5190	LDO Controllers	0.9	5.5	Adj. down to 0.5V	15	0.5	0.8	-	Yes	10-pin MSOP, 10-pin VDFN
MIC5191	LDO Controllers	1	5.5	Adj. down to 1.0V	15	1	0.8	-	Yes	10-pin MSOP, 10-pin VDFN
MIC4555	SIM Card Lvl Shifter with 50 mA LDO	2.7	5.5	1.9, 3.3	41/79	-	-	-	-	16-pin VDFN

POWER MANAGEMENT: DDR Termination Regulators

Part #	IOUT	Vin MIn. (V)	Vin Max. (V)	Vout (V)	PWR Good	VTT Accuracy	External Transistor	Sync Buck	Frequency Features	Packages
MIC5162	±7A	1.35	6	1/2 of Vin	-	±5 mV	√	-		10-pin MSOP
MIC5163	±7A	0.75	8	1/2 of Vin	-	±5 mV	√	-	Low Voltage	10-pin MSOP
MIC5164	±7A	1.35	8	1/2 of Vin	√	±5 mV	√	-		10-pin MSOP
MIC5165	±7A	0.75	6	1/2 of Vin	√	±5 mV	√	-	Low Voltage	10-pin MSOP
MIC5166	±3A	0.9	9.6	1/2 of Vin	√	±25 mV	-	-	-	DDR 1, 2, 3, 4
MIC5167	±6A	2.6	5.5	Adj. down to 0.35V	√	±12 mV	-	√	1 MHz	Integrated Sync Buck

POWER MANAGEMENT: High-Voltage Linear Regulators

Part #	Input to Output Voltage Differential (Min.)	Input to Output Voltage Differential (Max.)	Output Voltage (V)	Max Output Current (mA)	Typical Line Regulation (%/V)	Typical Load Regulation (%/mA)	Packages
LR6	12	450	1.2-440	10	0.003	0.15	3-Lead TO-252, 3-Lead TO-92, 3-Lead SOT-89
LR12	12	130	1.2-88	50	0.003	0.06	3-Lead TO-252, 8-Lead SOIC, 3-Lead TO-92
LR645	15	450	13	3	0.0001	0.50	8-Lead SOIC, 3-Lead TO-92, 3-Lead TO-220, 3-Lead SOT-89
LR745	25	450	20	2	0.0001	0.50	3-Lead TO-92, 3-Lead SOT-89

POWER MANAGEMENT: Single Output Switching Regulators (Buck)

Part #	Input Voltage Range (V)	Output Voltage (V)	Operating Junction Temperature Range (°C)	Switching Frequency (kHz)	Output Current (mA)	Features	Packages
MIC28517	4.5V-70V	0.6V to 32	-40 to 125	270 to 800	8000	COM	6 x 6
MIC28516	4.5V-70V	0.6V to 32	-40 to 125	270 to 800	8000	DCM	6 x 6
LX7167A	3.0 to 5.5	0.6 to 3.3	-10 to +85	3000	2400	Sub-mode, UVLO, OV, Power Good	8-pin 2 x 2 DFN
LX7176	3.0 to 5.5	0.6 to 3.3	0 to +85	1050	3000	PWM, 100% Duty Cycle, UVLO, OV, Power Good	12-pin 2 x 2 QFN
LX7176A	3.0 to 5.5	0.6 to 3.3	0 to +85	1050	4000	PT/M/PWM, 100% Duty Cycle, UVLO, OV, Power Good	12-pin 2 x 2 QFN
LX7180A	3.0 to 5.5	0.6 to 3.3	0 to +85	1050	4000	IC Programmable, Power Save Mode, Power Good	12-pin 2 x 2 DFN
LX7165/7178	3.0 to 5.5	0.6 to 3.3	0 to +85	1875	5000	IC Programmable, Power Save Mode, Power Good	1.8 x 2 WLCSP
LX7219/7220	2.7 to 5.5	0.6 to 3.3	-40 to +85	1200	6000	IC Programmable, Power Save Mode, Power Good	14-pin 2 x 3 VQFN
MCP1801	2.7 to 5.5	0.9V to 4W	-40 to +85	750	500	UVLO, Auto switching, LDO	5-pin MSCP
MCP1802	2.7 to 5.5	0.8 to 4.5	40 to +85	2000	500	P2M, PWM auto-switching, UVLO, soft start, power good indicator	10-pin MSCP, 10-pin 3 x 3 DFN
MCP1803	2.7 to 5.5	0.8 to 4.0	-40 to +85	2000	500	Overtemperature and overcurrent protection	5-pin TSOT 23, 8 pin 2 x 3 DFN
MCP1812	2.7 to 5.5	0.8 to 5.5	40 to +85	1400	10000	Overall efficiency >94%, Soft start, overtemperature and overcurrent protection	8-pin MSCP, 8-pin 3 x 3 DFN
MIC29245	2.7 to 5.5	Adj.	40 to -125	4,000	500	LDO Standby Mode and Low Q current	10-pin 3 x 3 NLF
MIC23030	2.7 to 5.5	1.0, 1.2, 1.5, 1.8, 4x	-40 to +125 8,000		400	HyperLight Load *mode	6 pin 1.6 x 1.8 NLF

POWER MANAGEMENT: Single Output Switching Regulators (Buck)

Part #	Input Voltage Range (V)	Output Voltage (V)	Operating Junction Temperature Range (°C)	Switching Frequency (kHz)	Output Current (mA) Features Packages
MIC23031 2.7 to 5.6		1.0, 1.2, 1.5, 1.8, Adj.	-40 to +125 4,000	400 HyperLight Load mode 6-pin 1.5 x 1.6 MLF
MIC23050 2.7 to 5.6		1.0, 1.2, 1.8, 3.3	-40 to +125 4,000	800 HyperLight Load mode 8-pin 2 x 2 MLF
MIC23051 2.7 to 5.6		1-1.2, 1-1.8, 1.15 - 1.4, 0.95-1.25	-40 to +125 4,000	800 HyperLight Load mode, voltage scaling 8-pin 2 x 2 MLF
MIC23150 2.7 to 5.6		1.0, 1.2, 1.35, 1.8, 3.3	-40 to +125 4,000	2,000 HyperLight Load mode 8-pin 2 x 2 MLF
MIC23153 2.7 to 5.6 - 1.8, Adj.		40 to +125 4,000	2,000 Power Good, Hypoertight Load mode 10-pin 2.5 x 2.5 MLF
MIC23155 2.7 to 5.6 - 1.8, Adj.		40 to +125 3,000	2,000 Power Good, Hypoertight Load mode 10-pin 2.5 x 2.5 MLF
MIC23303	2.7 to 5.5	Adj.	40 to +125	4,000	3,000	Power Good, Hypoertight Load mode
MIC232011	2.7 to 5.5	Adj.	40 to +125	2,000	2,000	Power Good
MIC23202	2.3 to 5.5	Adj.	-40 to +125	1,600-2,500	800
MIC23204	2.3 to 5.5	Adj.	40 to +125	2,000	500
MIC23267	3 to 5.5	Adj.	-40 to +125	400-1,500	2,000	Power Good
MIC23207	2.7 to 5.5	Adj.	-40 to +125	2,000	3,000	Power Good
MIC23208	2.7 to 5.5	Adj.	-40 to +125	1,000	3,000	Power Good
MIC23209	2.6 to 5.5	Adj.	-40 to +125	800-1,200	3,000	Power Good
MIC23400	2.6 to 5.5	Adj.	-40 to +125	200-4,000	4,000	Power Good
MIC23601	2.6 to 5.5	Adj.	-40 to +125	4,000	6,000	Power Good
MIC23602	2.6 to 5.5	Adj.	-40 to +125	1,000	6,000	Power Good
MIC23700	2.6 to 5.5	Adj.	-40 to +125	1,000	7,000	Power Good
MIC23050	2.6 to 5.5	Adj.	-40 to +125	400 2,000	10,000	Power Good
MCP16311	4.4 to 30.0	2.0 to 24.0	-40 to +125	600	1000	PWM operation, enable function
MCP16312	4.4 to 30.0	2.0 to 24.0	-40 to +125	500	1000	PWM operation, enable function
MCP16301	4.0 to 30	2.0 to 15	-10 to +85	900	600	Integrated N channel, UVLO. Soft start, overtemperature protection
MIC24045 4.5 to 19		0.64 to 5.25	-40 to +125	310-1200	5000	TC Programmable, 4.5V-19V input, SA Step-Down Converter
TG105	2.2 to 10	3.0, 3.3, 5.0	-40 to +85	300	1000	Low power shutdown mode
MIC24046	4.5 to 19	0.7 to 3.3	-40 to +125	400-700	5000	Pin-Programmable, 4.5V-19V input, SA Step-Down Converter
MIC24051	4.5 to 19	Adj.	-40 to +125	600	6000	Power Good, Soft Start, Architecture Regulation Scheme
MIC24052	4.5 to 19	Adj.	-40 to +125	600	6000	Power Good, Soft Start, HyperLight Load mode
MIC24053	4.5 to 19	Adj.	-40 to +125	600	9000	Power Good, Soft Start, Architecture Regulation Scheme
MIC24054	4.5 to 19	Adj.	-40 to +125	600	9000	Power Good, Soft Start, HyperLight Load mode
MIC24055	4.5 to 19	Adj.	-40 to +125	600	12000	Power Good, Soft Start, Architecture Regulation Scheme
MIC24056	4.5 to 19	Adj.	-40 to +125	600	12000	Power Good, Soft Start, HyperLight Load mode
MIC26601	4.5 to 28	Adj.	-40 to +125	600	6000	Power Good, Soft Start, Hyper Speed Control Architecture
MIC26603	4.5 to 28	Adj.	-40 to +125	600	6000	Power Good, Soft Start, HyperLight Load mode
MIC26603Z	4.5 to 28	Adj.	-40 to +125	600	6000	Power Good, Soft Start, HyperLight Load mode
MIC26901	4.5 to 28	Adj.	-40 to +125	600	9000	Power Good, Soft Start, Hyper Speed Control architecture
MIC26903	4.5 to 28	Adj.	-40 to +125	600	9000	Power Good, Soft Start, HyperLight Load mode
MIC26950	4.5 to 26	Adj.	-40 to +125	300	12000	Soft Start, Architecture Regulation Scheme; Hyper Speed Control architecture, Thermal Shutdown
MIC27600	4.5 to 36	Adj.	-40 to +125	300	7000	Soft Start, Architecture Regulation Scheme; Hyper Speed Control architecture, Thermal Shutdown
MIC4680	4 to 34	3.3, 5.0, Adj.	-40 to +125	200	1,300
MIC4681	4 to 30	Adj.	-40 to +125	400	2,000
MIC4682	4 to 34	Adj.	-40 to +125	200	2,000
MIC4684	4 to 30	Adj.	-40 to +125	200	2,000
MIC4685	4 to 30	Adj.	-40 to +125	200	3,000
MCP16331	4.4 to 50	2.0 to 24.0	40 to +125	500	1000	Integrated N-channel, UVLO, Soft start, Overtemperature Protection
MIC28510	4.5 to 75	Adj.	-40 to +125	100-500	4000	Soft Start, Architecture Regulation Scheme; Hyper Speed Control architecture, Thermal Shutdown

POWER MANAGEMENT: Single Output Switching Regulators (Buck)

Part #	Input Voltage Range (V)	Output Voltage (V)	Operating Junction Temperature Range (°C)	Switching Frequency (kHz)	Output Current (mA) Features Packages
MIC28511-1 4.6 to 60 Adj. -40 to +125 200-680 3000 Power Good, Soft Start, HyperLight Load						*mode 24-pin 3 x 4 FCQFN
MIC28511-2	4.6 to 60	Adj.	-40 to +125	200-680	3000	Power Good, Soft Start, Hyper Speed Control architecture	24-pin 3 x 4 FCQFN
MIC28514 4.5 to 75 0.6 to 32 -40 to +125 270-800 5000						Adj. Soft Start, Power Good, Internal Compensation, Enable, Pro Bias Start Up	32-pin 6 x 6 VQFN
MIC28515 4.5 to 75 0.6 to 32 -40 to +125 270-800 5000						Selectable Operating Mode, Power Good, Internal Compensation, Enable, Pro Bias Start Up	32-pin 6 x 6 VQFN
MIC28512-1 4.6 to 70 Adj. -40 to +125 200-680 2000 Power Good, Soft Start, HyperLight Load mode 24-pin 3 x 4 FCQFN
MIC28512-2	4.6 to 70	Adj.	-40 to +125	200-680	2000	Power Good, Soft Start, Hyper Speed Control architecture	24-pin 3 x 4 FCQFN
MIC28513-1	4.6 to 45	Adj.	-40 to +125	200-680	4000	Power Good, Soft Start, Hyper Speed Control architecture	24-pin 3 x 4 FCQFN
MIC28513-2	4.6 to 45	Adj.	-40 to +125	200-680	4000	Power Good, Soft Start, Hyper Speed Control architecture	24-pin 3 x 4 FCQFN
MIC4830	2.7 to 5.5	Adj.	-40 to +125	3300	3000	Power Good, Safe Start, Thermal Shutdown and Current Limit	10-pin 3 x 4 DFN
MIC4950	2.7 to 5.5	Adj.	40 to +125	3300	5000	Power Good, Safe Start, Thermal Shutdown and Current Limit	8-pin SOIC, 10-pin 3 x 4 DFN
MIC23350	2.4 to 5.5	0.6 to 3.3	-40 to +125	600-3000	3000	Pin selectable Vout, 100% Duty Cycle, Safe Startup, UVLO, TSD, OCP, Power Good	16-pin 2.5 x 2.5 FTQFN
MIC23356	2.4 to 5.5	0.6 to 3.84	-40 to +125	600-3000	3000	I2C programmable, 100% Duty Cycle, Safe Startup, UVLO, TSD, OCP, Power Good	16-pin 2.5 x 2.5 FTQFN
MIC23650	2.4 to 5.5	0.6 to 3.3	-40 to +125	1000-1400	6000 (pulsed)	Pin selectable Vout, 100% Duty Cycle, Safe Startup, UVLO, TSD, OCP, Power Good	16-pin 2.5 x 2.5 FTQFN
MIC23656	2.4 to 5.5	0.6 to 3.84	-40 to +125	1000-1400	6000 (pulsed)	I2C programmable, 100% Duty Cycle, Safe Startup, UVLO, TSD, OCP, Power Good	16-pin 2.5 x 2.5 FTQFN

POWER MANAGEMENT: Single Output Switching Regulators (Boost)

Part #	Input Voltage Range (V)	Output Voltage (V)	Operating Junction Temperature Range (°C)	Switching Frequency (kHz)	Output Switch Current (mA)	Features	Packages
MCP16411	0.8-5.25	1.8-8.25	-40 to +125	PRWPWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Boost Converter, In-Out Bypass, Low Battery Output, PG and Overtemp. Shutdown state is Output Discharge	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16412	0.8-5.25	1.8-8.25	-40 to +125	PWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Bcos: Converter, In-Out Bypass, Low Battery Output, PG and Overtemp. Shutdown state is Output Discharge	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16413	0.8-5.25	1.8-8.25	-40 to +125	PRWPWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Boost Converter, In-Out Bypass, Low Battery Output, PG and Overtemp. Shutdown state is In-Out Bypass	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16414	0.8-5.25	1.8-8.25	-40 to +125	PWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Bcos: Converter, In-Out Bypass, Low Battery Output, PG and Overtemp. Shutdown state is In-Out Bypass	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16415	0.8-5.25	1.8-8.25	-40 to +125	PRWPWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Boost Converter, In-Out Bypass, Low Battery Output and PG. Shutdown state is Output Discharge	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16416	0.8-5.25	1.8-8.25	-40 to +125	PWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Bcos: Converter, In-Out Bypass, Low Battery Output and PG. Shutdown state is Cutout Discharge	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16417	0.8-5.25	1.8-8.25	-40 to +125	PTMPWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Boost Converter, In-Out Bypass, Low Battery Output and PG. Shutdown state is In-Out Bypass	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP16418	0.8-5.25	1.8-8.25	-40 to +125	PWM 500 kHz	Dependent on Vin, Vur 1000 mA type switching current	Low Ig Boost Converter, In-Out Bypass, Low battery Output and PG. Shutdown state is In-Out Bypass	10-lead MSOP, 10-lead 3mm x 3mm TDFN
MCP1623/4	0.65 to 5.5	2.0 to 5.5	-40 to +85	500	425	Integrated synchronous boost regulator, 0.65V start-up voltage, soft start, True load disconnect	6-pin SOT-23, 8-pin (2 x 3) DFN
MCP1642B/D	0.65 to 5.5	1.8 to 5.5	-40 to +85	1000	1800	Integrated synchronous bocal regulator, 0.65V start-up voltage, soft start, enable, power good output, true load disconnect or input-to-output bypass option	8-pin MSOP, 8-pin (2 x 3) DFN
MCP16251/2	0.62 to 5.5	1.8 to 5.5	-40 to +85	500	850	True load disconnect shutdown (MCP16251)/input to output bypass shutdown (MCP16252)	6-pin SOT-23, 8-pin (2 x 3) DFN
MCP1640/B/C/D	0.65 to 5.5	2.0 to 5.5	-40 to +85	500	800	Integrated synchronous bocal regulator, 0.65V start-up voltage, Soft start, True load disconnect or input-to-output bypass option	6-pin SOT-23, 8-pin (2 x 3) DFN
MCP1643	0.5 to 5.5	0.8 to 5.0	-40 to +85	1000	1600	True load disconnect. Shutdown	8-pin MSOP, 8-pin (2 x 3) DFN
MCP1665	2.7 to 5	Up to 32	-40 to +85	500	3000	Pin selectable PWM or PTMPWM mode	10-pin (2 x 2) VQFN
MCP1663/4	2.4 to 5.5	Up to 32	-40 to +85	500	1800	High efficiency (up to 92%), fixed frequency, non synchronous, 300 mV feedback for LED driving (MCP1663)	5-pin SOT-23, 8 pin (2 x 3) TDFN
MCP1661/2	2.4 to 5.5	Up to 32	-40 to +85	500	1800	Non-synchronous, Soft start, Enable, 300 mV feedback for LED driving (MCP1662)	6-pin SOT-23, 8-pin (3 x 3) TDFN
MIC2141	2.2 to 14	Up to 22	-40 to +95	330	1000	Micropower bocal converter with control signal input to proportionally adjust output voltage	5-pin SOT-23

POWER MANAGEMENT: Single Output Switching Regulators (Boost)

Part #	Input Voltage Range (V)	Output Voltage (V)	Operating Junction Temperature Range (°C)	Switching Frequency (kHz)	Output Switch Current (mA)	Features Packages
MIC2619	2.8 to 8.5	Up to 35	-40 to +125	1200	350	1.2 MHz PWM boost converter with OVP	6-pin Thin SOT-23
MIC2990 2.5 to 10	Up to 34 -40	to +125 1200 750	2 mm x 2 mm	PWM boost regulator with internal Schottky diode	2 x 2 MLF
MIC2605/06	4.5 to 20	Up to 40	-40 to +125	1200/2000	500	0.5A, 1.2 MHz/2 MHz wide input range boost with integrated switch and Schottky diode	2 x 2 MLF
MIC2145	2.4 to 18	Up to 18	-40 to +85	450	900	High-efficiency 2.5W boost converter	8-pin MSOP, 3 x 3 MLF
MIC2570/1	1.3 to 15	Up to 36	-40 to +85	20	1100	Two-cell/single-cell switching regulator	8-pin SOIC, 8-pin MSOP
MIC2288	2.5 to 10	Up to 34	-40 to +125	1200	1200	1A 1.2 MHz PWM boost converter in Thin SOT-23 and 2 mm x 2 mm MLF	5-pin SOT-23, 2 x 2 MLF
MIC3172	3 to 40	Up to 65	-40 to +85	100	1250	100 kHz 1.25A switching regulators with enable pin	9-pin SOIC, 8-pin DIP
MIC2295/86	2.5 to 10	Up to 34	-40 to +125	1200/600	1200	High power density 1.2A boost regulator	5-pin SOT-23, 2 x 2 MLF
MIC2601/02	4.5 to 20	Up to 40	-40 to +125	1200/2000	1200	1.2A, 1.2 MHz/2 MHz wide input range integrated switch boost regulator	2 x 2 MLF
MIC2250/61	2.5 to 5.5	Up to 32/27	-40 to +125	Variable	900	High-efficiency low EMI boost regulator with frequency differing	5-pin SOT-23, 2 x 2 MLF
MIC2172	3 to 40	Up to 65	-40 to +85	100	1250	100 kHz 1.25A switching regulator with frequency sync	8-pin DIP, 8-pin SOIC
MIC2253	2.5 to 10	Up to 30	-40 to +125	1200	3500	3.5A 1 MHz high-efficiency boost regulator with OVP and softstart	3 x 3 MLF
MIC2171	3 to 40	Up to 65	-40 to +85	100	2500	100 kHz 2.5A switching regulator	TO220, TO263
MIC2875/76	2.5 to 8	Up to 8	-40 to +125	2000	1800	4.8A ISW, synchronous boost regulator with bi-directional load disconnect	2 x 2 Thin MLF
MIC2877	2.5 to 5.5	Vin to 6.5V	-40 to +125	2000	6500	6.5A ISW, synchronous boost regulator with bidirectional load disconnect	2 x 2 FTQFN

POWER MANAGEMENT: Multiple Output Switching Regulators

Part #	Description	Input Voltage Range (V)	Number of Outputs	Output Voltage (V)	Operating Temperature Range (°C)	Control Scheme	Switching Frequency (kHz)	Output Current (mA)	Features	Packages
MCP16501	Cost and Size Optimized PMIC for SAMA5DX/SAM9X6/SAMA7G Series MPUs	2.7 to 5.5	4	Buck1: 1.2 to 3.7V Buck2-3: 0.6 to 1.85V LDO: 0.9V to 3.7V	-40 to +125	PWM, PFM, Hyst	2000	Buck1-3: 1A/Channel LDO: 300 mA	100% Max Duty Cycle, High Efficiency, Low Quiescent Current, Integrated Power Sequencing, Multi-Mode Operation, Fault Management and Protection Features	24-pin 4 x 4, VQFN
MCP16502	High Performance PMIC for SAMA5DX/SAM9X6/SAMA7G Series MPUs	2.7 to 5.5	6	Buck1: 1.2 to 3.7V Buck2-4: 0.6 to 1.85V LDO: 1.2V to 3.7V	-40 to +125	PWM, PFM, Hyst	2000	Buck1-4: 1A/Channel LDO1-2: 300 mA/channel	I=O, DVS, 100% Max Duty Cycle, High Efficiency, Low Quiescent Current, Integrated Power Sequencing, Multi-Mode Operation, Fault Management and Protection Features	32-pin 5 x 5, VQFN
MIC4742	2 MHz Dual 2A Integrated Switch Buck Regulator	2.9 to 5.5 2	DC/DC: 0.6 to 5.5	-40 to +125		PWM Mode	2000	DC to DC: 2,000/2,000 mA	AEC-C100 Oracle 2 Variant available	16-pin 3 x 3 MLF, SSOP
MIC4744	4 MHz Dual 2A Integrated Switch Buck Regulator	2.9 to 5.5 2	DC/DC: 0.8 to 5.5	-40 to +125		PWM Mode	4000	DC to DC: 2,000/2,000 mA		16-pin 3 x 3 MLF, SSOP
MIC4762	1.8MHz Dual 2A Integrated Switch	3 to 6	2	DC/DC: 0.8 to 6	-40 to +125	PWM Mode	1800	DC to DC: 2,000/2,000 mA		3 x 3 MLF
MIC2238	2.5 MHz Dual Phase PWM Buck Regulator	2.5 to 5.5 2	DC/DC: 0.8 to 3.3	-40 to +125		PWM Mode	2500	DC to DC: 800/800 mA	Automatic switching into light load mode of operation	3 x 3 MLF
MIC23250	4 MHz Dual Synchronous Buck Regulator	2.7 to 5.5 2	DC/DC: 0.8 to 3.3	-40 to +125		PWM Mode	4000	DC to DC: 400/400 mA	With HyperLight Load*mode	2 x 2 MLF; 2.5 x 2.5 MLF
MIC23254	4 MHz Dual 400 mA Synchronous Buck Regulator	2.5 to 5.5 2		1.0/1.8	-40 to +125	PWM Mode	4000	DC to DC: 400/400 mA	With Low Input Voltage and HyperLight Load mode	2 x 2 MLF
MIC23450	3 MHz, PWM, 2A Tripc Buck Regulator	2.7 to 5.5	3	DC/DC: 1.0 to 3.3	-40 to +125	PWM Mode	3000	DC to DC: 2,000/2,000/2,000 mA	With HyperLight Load mode and Power Good	5 x 5 QFN
MIC24420	2.5A Dual Output PWM Synchronous Buck Regulator	4.5 to 15.2	DC/DC: 0.7 to 10.5	-40 to +125		PWM Mode	1000	DC to DC: 2,500/2,500 mA	Power Good and Soft Start, 180° out of phase operation	4 x 4 QFN
MIC24421	2.5A Dual Output PWM Synchronous Buck Regulator	4.5 to 15.2	DC/DC: 0.7 to 10.5	-40 to +125		PWM Mode	500	DC to DC: 2,500/2,500 mA	Power Good and Soft Start, 180° out of phase operation	4 x 4 QFN
MIC25400	2A Dual Output PWM Synchronous Buck Regulator	4.5 to 13.2	2 DC/DC: 0.7 to 9.4	-40 to -125		PWM Mode	1000	DC to DC: 2,000/2,000 mA	180° out of phase operation	4 x 4 QFN

POWER MANAGEMENT: Multiple Output Switching Regulators

Part # Description		Input Voltage Range (V)	Number of Outputs	Output Voltage (V)	Operating Temperature Range (°C)	Control Scheme	Switching Frequency (kHz)	Output Current (mA)	Features Packages
MIC23158	3 MHz PWM Dual 2A Buck Regulator with Output Auto Discharge - B15	2.7 to 5.5 2 DC/DC: 1 to 3.3 -40 to +125				PWM Mode	3000DC to DC: 2,000/2,000 mA		HyperLight Load mode, Power Good and Output Auto-Discharge	3 x 4 MLF
MIC23158 3 MHz PWM Dual 2A Buck Regulator 2.7 to 5.5 2 DC/DC: 1 to 3.3 -40 to +125						PWM Mode	3000DC to DC: 2,000/2,000 mA HyperLight Load mode and Power Good 3 x 4 MLF
MIC23451	3 MHz, 2A Triple Synchronous Buck Regulator	2.7 to 5.5 3DC/DC: 1 to 3.3 -40 to +125				PWM Mode	3000	DC to DC: 2,000/2,000/2,300 mA	HyperLight Load mode and Power Good 4 x 4 CFN
MIC2330	Dual Synchronous Step-Down DC/DC Regulator	2.5 to 5.5 2 DC/DC: 0.8 to 3.3 -40 to +125				PWM Mode	2500 DC to DC: 800/600 mA	Power Good and Soft Start	3 x 3 MLF
MIC23065	4 MHz DC/DC Regulator and I.D.O Regulator	2.7 to 5.5 2		DC/DC Boost: 1.9 to 3.3DC/DC Buck: 1 to Boost Vcu	-40 to -125	PWM Mode	4000	DC to DC Buck: 600 mA, LDO: 300 mA	Flexible sequencing feature	2.5 x 2.5 MLF
MIC2225 2 MHz DC/DC Converter with LDO 2.7 to 5.5 2				DC/DC: 1.3 to 4.5LDO: 0.8 to 3.3	-40 to -125	PWM Mode	2000	DC to DC Buck: 600 mA, LDO: 300 mA	Independent enable, >95% efficiency	2 x 2 MLF
MIC23099	Step-Up/Step-Down Regulators with Battery Monitoring	0.65 to 1.6 2		DC/DC: 1.7 to 2.5LDO: 0.8 to 2.5	-40 to -125	PWM Mode	100 Boost, 1000 Buck	DC to DC Buck: 30mA, DC/DC Boost 200 mA	AV/AMABattery Monitoring	2.5 x 2.5 CFN
MIC2800	2 MHz DC/DC Converter with Two Linear Regulators, POR/Power Good pin and LOWC Mode	2.7 to 5.5 3		DC/DC: 1.8 to 3.3LDOs: 0.6 to 3.6	-40 to -125	PWM Mode	2000	DC to DC Buck: 600 mA, LDO: 300/300 mA	POR/Power Good pin and LOWC mode	3 x 3 MLF
MIC2810	2 MHz DC/DC Regulator with Two Linear Regulators, LDO1 has a separate Vw Pin and can either post-regulate the DC/DC converter or be connect directly to the main input supply, POR/Power Good Pin.	2.7 to 5.5 3		DC/DC: 1.8 to 3.3LDOs: 0.6 to 3.6	-40 to -125	PWM Mode	2000	DC to DC Buck: 600 mA, LDO: 300/300 mA	LDO1 has a separate VIN pin and can either post regulate the DC/DC converter	3 x 3 MLF
MIC2811	2 MHz 800 mA DC/DC Regulators with Triple 300 mA LDOs	2.7 to 5.5 4		LDO1/2: 0.6 to 3.6LDO3: 1.0 to 3.9	-40 to -125	PWM Mode	2000	DC to DC Buck: 600 mA, LDO: 300/300/300 mA	LDO1 and LDO2 have separate Vin	3 x 3 MLF
MIC2821	2 MHz 800 mA DC/DC Regulators with Triple 300 mA LDOs	2.7 to 5.5 4		LDO1/2: 0.6 to 3.6LDO3: 1.0 to 3.9	-40 to -125	PWM Mode	2000	DC to DC Buck: 600 mA, LDO: 3O0/300/300 mA	Independent enable for all four regulators.	3 x 3 MLF
MIC2826	Quad Output PMIC with HyperLight Load Mode DC/DC, Three LDOs and IC Control	2.7 to 5.5 4		DC/DC: 0.8 to 1.8LDOs: 0.8 to 3.3	-40 to -125	PWM Mode	4000	DC to DC Buck: 500 mA, LDO: 150/150/150 mA	IC Control and Dynamic Voltage Scaling 3 LDOs	2.5 x 2.5 MLF
MIC2827	Triple Output PMIC with HyperLight Load Mode DC-DC, Two LDOs and IC Control	2.7 to 5.5 3		DC/DC: 0.8 to 1.8LDOs: 0.8 to 3.3	-40 to -125	PWM Mode	4000	DC to DC Buck: 500 mA, LDO: 150/150 mA	IC Control and Dynamic Voltage Scaling 3 LDOs	2.5 x 2.5 MLF
MIC7400	Configurable Five-Channel Buck Regulator Plus One-Boost	2.4 to 5.5 6		Bucks: 0.8 to 3.3(Configurable)Boost: 7.0 to 14.0(Configurable)	-40 to -125	PWM Mode	2000 Boost, 1300 Bucks	DC to DC Bucks: 3,000 mA, DC/DC Boost 200 mA	Highly Integrated configurable, featuring five buck regulators, one boost regulator and global power good indicator	4.5 x 4.5 CFN
MIC7401	Configurable Five-Channel Buck Regulator Plus One-Boost with HyperLight Load mode, IC Control, and Enable	2.4 to 5.5 6		Bucks: 0.8 to 3.3(Configurable)Boost: 7.0 to 14.0(Configurable)	-40 to -125	PWM Mode	2000 Boost, 1300 Bucks	DC to DC Bucks: 3,000 mA, DC/DC Boost 200 mA	Highly Integrated configurable, facturing five buck regulators, one boost regulator, global power good indicator and enable pin	4.5 x 4.5 CFN

POWER MANAGEMENT: Combination Switching Regulators

Part #	Description	Input Voltage Range (V)	Output Voltage (V)	Operating Temp. Range (°C)	Control Scheme	Switching Frequency (kHz)	Typical Active Current (mA)	Output Current (mA)	Features	Packages
TC1300	Synchronous Buck Regulator, LDO with Power Good	2.7 to 5.5	DC/DC: 0.8 to 4.5LDO: 1.5 to 3.3	-40 to +85	PFW/PWM	2000	65/600	DC/DC: 500 mA LDO: 300 mA	RFM/PWM auto-switching, Power good output	10-pin MSOP, 10-pin 3 x 3 DFN
TC1304	Synchronous Buck Regulator, LDO 2.7 to 5.5		DC/DC: 0.8 to 4.5LDO: 1.5 to 3.3	-40 to 185	PFW/PWM	2000	65/600	DC/DC: 500 mA LDO: 300 mA	RFM/PWM auto-switching, Power sequencing	10-pin MSOP, 10-pin 3 x 3 DFN
TC1313	Synchronous Buck Regulator, LDO 2.7 to 5.5		DC/DC: 0.8 to 4.5LDO: 1.5 to 3.3	-40 to +85	PFW/PWM	2000	65/600	DC/DC: 500 mA LDO: 300 mA	RFM/PWM auto-switching	10-pin MSOP, 10-pin 3 x 3 DFN

POWER MANAGEMENT: Inductorless Offline Switching Regulators

Part #	VIN (Vac)	Adjustable Vout (V)	Fixed Vout (V)	Iout Max. (mA)	Load Regulation (%/mA)	Packages
SR086 90-285 9.0-50 3.31000.025 8-Lead SOIC with Heat Slug
SR087 90-285 9.0-50 61000.017 8-Lead SOIC with Heat Slug
SR10	60-285	6.0-28	6.0, 12, 24	60	-	B-Load SOIC

POWER MANAGEMENT: PWM Controllers

Part #	Supported Topologies	Supported Outputs	Input Voltage Range (V)	Output Voltage (V)	Operating Frequency (Hz)	Operating Temp. Range (°C)	Features	Packages
MIC2101	Sync. Buck	1	4.5 to 38	0.8 to 24	200k to 600k	-40 to +125	HyperLight Load mode, External Clock Sync, Power Good, Soft Start, Internal Compensation and Voltage Bias	16-pin 3 x 3 MLF*
MIC2102	Sync. Buck	1	4.5 to 39	0.8 to 24	200k to 600k	-40 to +125	Power Good, Soft Start, Internal Compensation and Voltage Bias	18-pin 3 x 3 MLF
MIC2103	Sync. Buck	1	4.5 to 75	0.8 to 24	200k to 600k	-40 to +125	HyperLight Load mode, External Clock sync, Power Good, Soft Start, Internal Compensation and Voltage Bias	16-pin 3 x 3 MLF
MIC2104	Sync. Buck	1	4.5 to 75	0.8 to 24	200k to 600k	-40 to +125	Power Good, Soft Start, Internal Compensation and Voltage Bias	16-pin 3 x 3 MLF
MIC2111B	Sync. Buck	1	3.3 to 5.5	0.6 to 3.64	200k to 2M	-40 to +125	Power Good, Soft Start, Internal Voltage Bias, Enable Pin, Current Limit/Short Circuit Protection	3 x 3 OFN
MIC2124	Sync. Buck	1	3.0 to 19	0.6 to 12	300k	-40 to +125	Soft Start, Internal Voltage Bias	10-pin MSOP
MIC2130	Sync. Buck	1	9.0 to 40	0.7 to 24	150k or 400k	-40 to +125	Power Good, Soft Start, Internal Voltage Bias	18-pin e-TSSOP, 16-pin 4 x 4 MLF
MIC2131	Sync. Buck	1	9.0 to 40	0.7 to 24	150k or 400k	-40 to +125	Power Good, Soft Start, Internal Voltage Bias	16-pin e-TSSOP, 16-pin 4 x 4 MLF
MIC2130	Sync. Buck	2	4.5 to 14.5	0.7 to 5.5	500k	-40 to +125	Power Good, Soft Start, Internal Voltage Bias	24-pin 4 x 4 MLF
MIC2151	Sync. Buck	2	4.5 to 14.5	0.7 to 5.5	300k	-40 to +125	Power Good, Soft Start, Internal Voltage Bias	24-pin 4 x 4 MLF
MIC2155	Sync. Buck	1	4.5 to 14.5	0.7 to 3.8	500k	-40 to +125	External Clock Sync, Power Good, Soft Start	32-pin 5 x 5 MLF
MIC2164	Sync. Buck	1	3.0 to 29	0.8 to 5.5	300k, 600k, 1M	-40 to +125	Soft Start, Internal Compensation and Voltage Bias	10 pin MSOP
MIC2164C	Sync. Buck	1	3.0 to 29	0.8 to 5.5	270k	-40 to +125	Soft Start, Internal Compensation and Voltage Bias	10-pin MSOP
MIC2165	Sync. Buck	1	4.5 to 28	0.8 to 5.5	600k	-40 to +125	Hyper Speed Control architecture, Power Good, Soft Start, Internal Voltage Bias	10 pin MSOP
MIC2166	Sync. Buck	1	4.5 to 29	0.8 to 5.5	600k	-40 to +125	Power Good, Soft Start, Internal Compensation and Voltage Bias	10-pin MSOP
MIC2168	Sync. Buck	1	3.0 to 14.5	0.8 to 5.5	1.0M	-40 to +125	Soft Start, Internal Compensation and Voltage Bias	10-pin MSOP
MIC2169	Sync. Buck	1	3.0 to 14.5	0.8 to 5.5	500k	-40 to +125	Soft Start, Internal Voltage Bias	10-pin MSOP
MIC2169A	Sync. Buck	1	3.0 to 14.5	0.8 to 5.5	500k	-40 to +125	Soft Start, Internal Voltage Bias	10-pin MSOP
MIC2169B	Sync. Buck	1	3.0 to 14.5	0.8 to 5.5	500k	-40 to +125	Soft Start, Internal Voltage Bias	10-pin MSOP
MIC2176	Sync. Buck	1	4.5 to 75	0.6 to 24	100k, 200k, or 300k	-40 to +125	Soft Start, Internal Compensation and Voltage Bias	10-pin MSOP
MIC2162	Sync. Buck	1	4.5 to 32	1.25 to 6.0	300k	-40 to +85	Skip Mode, External Clock Sync, Soft Start, Internal Voltage Bias	16-pin SOP, 16-pin SSOP
MIC2163	Sync. Buck	1	2.9 to 14	1.3 to 12	200k/400k	-40 to +125	External Clock Sync, Soft Start, Internal Voltage Bias	16-pin SOP, 16-pin OSOP
MIC2128	Sync. Buck	1	4.5 to 75	0.6 to 30	200k to 600k	-40 to +125	Programmable soft-start/frequency/current-limit, Internal compensation and voltage bias	16-pin 3 x 3 MLF
MIC2127A	Sync. Buck	1	4.5 to 75	0.6 to 30	200k to 800k	-40 to +125	Light load operation, Programmable frequency, Current Limit, Switch over LDO	16-pin 3 x 3 MLF
MIC2184	Async. Buck	1	2.9 to 14	1.3 to 12	200k/400k	-40 to +125	External Clock Sync, Soft Start, Internal Voltage Bias	16-pin SOP, 16-pin OSOP
MIC2185	Boost, SEPIC, Quk	1	2.9 to 14	3.3 to 5.5	200k/400k	-40 to +85	Skip Mode, External Clock Sync, Soft Start, Internal Voltage Bias	16-pin SOIC, 16-pin OSOP
MIC2186	Boost, SEPIC, Flyback	1	2.9 to 14	3.3 to 5.5	100/200/400k	-40 to +85	Skip Mode, External Clock Sync, Soft Start, Internal Voltage Bias	16-pin SOP, 16-pin OSOP
MIC2193	Sync. Buck	1	2.9 to 14	3.3 to 5.5	400k	-40 to +125	Internal Voltage Bias, UVLO	8-pin SOIC
MIC2194	Async. Buck	1	2.9 to 14	3.3 to 5.5	400k	-40 to +125	Internal voltage Bias, UVLO, Current Limit/Short Circuit Protection	8-pin SOIC
MIC2196	Boost, SEPIC	1	2.9 to 14	3.3 to 5.5	400k	-40 to +125	Internal voltage Bias, UVLO, Current Limit/Short Circuit Protection	8-pin SOIC
MIC2198	Sync. Buck	1	4.5 to 32	0.8 to 6.0	500k	-40 to +125	Internal voltage Bias, UVLO, Current Limit/Short Circuit Protection	12-pin 4 x 4 MLF
MIC2199	Duck	1	4.5 to 32	0.8 to 6.0	300k	-40 to +125	Internal voltage Bias, UVLO, Current Limit/Short Circuit Protection	12-pin 4 x 4 MLF
MIC3808	Push Pull, Hat Bridge, Full Bridge	1	8.3 to 15	-	Adj. to 1V	-40 to +85	Soft Start, Internal Voltage Bias, UVLO, Current Limit/Short Circuit Protection	8-pin SOP, 8-pin MSOP
MIC3809	Push Pull, Hat Bridge, Full Bridge	1	4.1 to 15	-	Adj. to 1V	-40 to +85	Soft Start, Internal Voltage Bias, UVLO, Current Limit/Short Circuit Protection	8-pin SOP, 8-pin MSOP

POWER MANAGEMENT: PWM Controllers

Part #	Supported Topologies	Supported Outputs	Input Voltage Range (V)	Output Voltage (V)	Operating Frequency (Hz)	Operating Temp. Range (°C)	Features Packages
MIC3838	Push-Full, Half Bridge, Full Bridge	18.3 to 15	-Adj. to 1M -40 to +85				Soft Start, Internal Voltage Bias, UVLO, Current Limit/Short Circuit Protection	10 pin MSOP
MIC3839	Push-Full, Half Bridge, Full Bridge	14.1 to 15	-Adj. to 1M -40 to +85				Soft Start, Internal Voltage Bias, UVLO, Current Limit/Short Circuit Protection	10 pin MSOP
MIC38C42	Forward, Flyback	1	15.5 to 20	-	Adj. to 500k	-40 to +85	Forward.Flyback Supported Topologies	8-pin PDIP, 14-pin FDIP, 8-pin MSOP, 8-pin SOIC, 14-pin SOIC
MIC38C43	Forward, Flyback	1	9.0 to 20	-	Adj. to 500k	-40 to +85	Forward.Flyback Supported Topologies	8-pin PDIP, 14-pin FDIP, 8-pin MSOP, 8-pin SOIC, 14-pin SOIC
MIC38C44	Forward, Flyback	1	15.5 to 20	-	Adj. to 500k	-40 to +85	Forward.Flyback Supported Topologies	8-pin PDIP, 14-pin FDIP, 8-pin MSOP, 8-pin SOIC, 14-pin SOIC
MIC38C45	Forward, Flyback	1	9.0 to 20	-	Adj. to 500k	-40 to +85	Forward.Flyback Supported Topologies	8-pin PDIP, 14-pin FDIP, 8-pin MSOP, 8-pin SOIC, 14-pin SOIC
MIC38HC42	Forward, Flyback	1	15.5 to 20	-	Adj. to 500k	-40 to +85	Forward.Flyback Supported Topologies	8-pin PDIP, 14-pin FDIP, 8-pin SOIC, 14-pin SOIC
MIC38C43	Forward, Flyback	1	9.0 to 20	-	Adj. to 500k	-40 to +85	Forward.Flyback Supported Topologies	8-pin PDIP, 14-pin FDIP, 8-pin MSOP, 8-pin SOIC, 14-pin SOIC
MIC9130	Forward, Flyback	1	9.0 to 180	-	Adj. to 1.5M	-40 to +125	Forward.Flyback Supported Topologies, External Clock Sync	16-pin SOIC, 16-pin QSOP
MIC9131	Forward, Flyback	1	9.0 to 180	-	Adj. to 1M	-40 to +125	Forward.Flyback Supported Topologies, External Clock Sync	16 pin SOIC, 16 pin QSOP
MCP1830	Flyback, Boost, SEPIC, Quk	1	3.0 to 5.5	-	Sync. to 1M	-40 to +125	External Clock Sync, Current Limit/Short Circuit Protection	8-pin 2x3 DFN, 8-pin MSOP
MCP1830V	Flyback, Boost, SEPIC, Quk	1	3.0 to 5.5	-	Sync. to 1M	-40 to +125	External Clock Sync, Current Limit/Short Circuit Protection	8-pin 2x3 DFN, 8-pin MSOP
MCP1831	Flyback, Boost, SEPIC, Quk	1	3.0 to 5.5	-	Sync. to 2M	-40 to +125	External Clock Sync, Current Limit/Short Circuit Protection	20-pin TSSOP, 20 pin SSOP, 20 pin 4 x 4 QFN
MCP1831V	Flyback, Boost, SEPIC, Quk	1	3.0 to 5.5	-	Sync. to 2M	-40 to +125	External Clock Sync, Current Limit/Short Circuit Protection	20 pin TSSOP, 20-SSOP, 20-pin 4 x 4 DFN
MCP1831HV	Flyback, Boost, SEPIC, Quk	1	3.5 to 16	-	Sync. to 2M	-40 to +125	External Clock Sync, Current Limit/Short Circuit Protection	20-pin TSSOP, 20-SSOP
MCP1631VHV	Flyback, Boost, SEPIC, Quk	1	3.5 to 16	-	Sync. to 2M	-40 to +125	External Clock Sync, Current Limit/Short Circuit Protection	20-pin TSSOP, 20-SSOP
MCP1632	Flyback, Boost, SEPIC, Quk	1	3.0 to 6	-	300k/600k	-40 to +125	Soft Start, Internal Voltage Bias, UVLO, Current Limit/Short Circuit Protection	8 pin MSOP, 8 pin 2 x 3 DFN
MCP1633	Flyback, Boost, SEPIC, Quk	1	3 to 5.5	-	Sync to 2.2M	-40 to +125	High Speed Current Mode, Easy to Interface with MCU	16-pin 3 x 3 mm QFN
MCP19035	Sync, Buck	1	4.5 to 30	-	500k/600k	-40 to +125	Power Good, Soft Start, Internal Voltage Bias, UVLO, Current Limit/ Short Circuit Protection	10 pin 3 x 3 DFN
MCP1633	Flyback, Boost, SEPIC, Quk	1	3 to 5.5	-	Sync to 2.2M	-40 to +125	High Speed Current Mode, Easy to Interface with MCU	16-pin 3 x 3mm QFN

POWER MANAGEMENT: Hybrid PWM Controllers - Digitally Enhanced Power Analog

Part #	Input Voltage Range (V)	Output Voltage (V)	Topologies Supported	Channels	Program Memory Size (kWords)	RAM (bytes)	GPIO	Product features integrated MCU, LDO, MOSFET drivers, 10-bit ADC, temp sensor, user-configurable operation and:	Packages
MCP19110	4.5 to 32	0.5 to 90% * VN	Sync, Buck	1	4	256	11	Configurable and dynamically changeable internal analog compensation network	24-pin 4 × 4 QFN
MCP19111	4.5 to 32	0.5 to 90% * VN	Sync, Buck	1	4	256	14	Configurable and dynamically changeable internal analog compensation network and a debug interface	28-pin 5 × 5 QFN
MCP19114	4.5 to 42	Dependent on topology	Boost, Flyback, SEPIC, Cuk	1	4	256	8	Excellent regulation for constant current applications	24-pin 4 × 4 QFN
MCP19115	4.5 to 42	Dependent on topology	Boost, Flyback, SEPIC, Cuk	1	4	256	12	Excellent regulation for constant current applications and a debug interface	28-pin 5 × 5 QFN

POWER MANAGEMENT: Hybrid PWM Controllers – Digitally Enhanced Power Analog

Part #	Input Voltage Range (V)	Output Voltage (V)	Topologies Supported	Channels	Program Memory Size (kWords)	RAM (bytes)	GPIO	Product features Integrated MCU, LDO, MOSFET drivers, 10-bit ADC, temp sensor, user- configurable operation and:	Packages
MCP19118 4.5 to 42		Dependent on topology	Boost, Flyback, SEPIC, OJK	18 3368				Improved current regulation accuracy, additional code space (compared to MCP19114 or MCP19115)	24-pin 4 x 4 QFN
MCP19117 4.5 to 42		Dependent on topology	Boost, Flyback, SEPIC, OJK	18 33612				Improved current regulation accuracy, additional code space (compared to MCP19114 or MCP19115) and a debug interface	28-pin 5 x 5 QFN
MCP19118	4.5 to 40	0.5 to 90% * VN	Sync, Buck	1	4	256	11	Configurable and dynamically changeable internal analog compensation network	24-pin 4 x 4 QFN
MCP19119	4.5 to 40	0.5 to 90% * VN	Sync, Buck	1	4	256	14	Configurable and dynamically changeable internal analog compensation network and a debug interface	28-pin 5 x 5 QFN
MCP19122	4.5 to 40	0.3 to 16	Sync, Buck	1	4	256	12	Emulated average current mode control, programmable gain feedback amplifier, multiphase operation, improved regulation accuracy and current measurement accuracy (Compared to MCP19110/1/8/9)	24-pin 4 x 4 QFN
MCP19123	4.5 to 40	0.3 to 16	Sync, Buck	1	4	256	16	Emulated average current mode control, programmable gain feedback amplifier, multiphase operation, improved regulation accuracy and current measurement accuracy (Compared to MCP19110/1/8/9) and a debug interface	28-pin 5 x 5 QFN
MCP19124 4.5 to 42		Dependent on topology	Boost, Flyback, SEPIC, OJK	14256 8				Dual independent voltage and current control loops allow seamless transitions from constant voltage to constant current regulation	24-pin 4 x 4 QFN
MCP19125 4.5 to 42		Dependent on topology	Boost, Flyback, SEPIC, OJK	14256 12				Dual independent voltage and current control loops allow seamless transitions from constant voltage to constant current regulation and a debug interface	28-pin 5 x 5 QFN
MCP19214 4.5 to 42		Dependent on topology	Boost, Flyback, SEPIC, OJK	2	8	338	8	Dual channels, which can be configured to control two outputs, or one bi-directional system	28-pin 5 x 5 QFN
MCP19215 4.5 to 42		Dependent on topology	Boost, Flyback, SEPIC, OJK	2 8 33612				Dual channels, which can be configured to control two outputs, or one bi-directional system and a debug interface	32-pin 5 x 5 QFN

POWER MANAGEMENT: Power Modules

Part #	Input Voltage Range (V)	Output Voltage (V)	Operating Temp. Range (°C)	Control Scheme	Switching Frequency (kHz)	Vout Max. (V)	Output Current (A)	Features	Packages
MIC28304-1	4.5 to 70	Adj.	-40 to +125	COT	600	24	3	HyperLight Load Mode, Power Good, Soft Start	64-pin 12 x 12 QFN
MIC28304-2	4.5 to 70	Adj.	-40 to +125	COT	600	24	3	Hyper Speed Control Architecture, Power Good, Soft Start	64-pin 12 x 12 QFN
MIC45205-1	4.5 to 26	Adj.	-40 to +125	COT	200-600	5.5	6	HyperLight Load Mode, Power Good, Soft Start	52-pin 8 x 8 QFN
MIC45205-2	4.5 to 26	Adj.	-40 to +125	COT	200-600	5.5	6	Hyper Speed Control Architecture, Power Good, Soft Start	52-pin 8 x 8 QFN
MIC45208-1	4.5 to 26	Adj.	-40 to +125	COT	200-600	5.5	10	HyperLight Load Mode, Power Good, Soft Start	52-pin 10 x 10 QFN
MIC45208-2	4.5 to 26	Adj.	-40 to +125	COT	200-600	5.5	10	Hyper Speed Control Architecture, Power Good, Soft Start	52-pin 10 x 10 QFN
MIC45212-1	4.5 to 26	Adj.	-40 to +125	COT	200-600	5.5	14	HyperLight Load Mode, Power Good, Soft Start	64-pin 12 x 12 QFN
MIC45212-2	4.5 to 26	Adj.	-40 to +125	COT	200-600	5.5	14	Hyper Speed Control Architecture, Power Good, Soft Start	64-pin 12 x 12 QFN
MIC33030	2.7 to 5.5	1.2, 1.8, Adj.	40 to +125	PWM	8,000	3.6	0.4	HyperLight Load Mode	10-pin 2.5 x 2.0 MLF*
MIC33050	2.7 to 5.5	1.0, 1.2, 1.8, 3.3, Adj.	-40 to +125	PWM	4,000	3.3	0.6	HyperLight Load Mode	12-pin 3 x 3 MLF
MIC33153	2.7 to 5.5	1.2, Adj.	-40 to +125	PWM	4,000	3.6	1.2	HyperLight Load Mode, Power Good, Soft Start	14-pin 3 x 3.5 MLF
MIC3385	2.7 to 5.5	1.5, Adj.	-40 to +125	PWM	9,000	5.5	0.6	LowQ	14-pin 3 x 3.5 MLF
MIC33M650	2.4 to 5.5	Ph Selectable	-40 to +125	COT	1000-2500	3.94	6	HyperLight Load, Meet CISPR 32 class B specifications	53-pin 8 x 10 x 3 mm thin B1QFN
MIC33M658	2.4 to 5.5	PC Configurable	-40 to +125	COT	1200-2500	3.64	6	Hyper Light Load, Meet CISPR 32 class B specifications	53-pin 8 x 10 x 3 mm thin B1QFN
MIC28303-1	4.5 to 50	Adj.	-40 to +125	COT	600	24	3	HyperLight Load Mode, Power Good, Soft Start	64-pin 12 x 12 QFN
MIC28303-2	4.5 to 50	Adj.	-40 to +125	COT	600	24	3	Hyper Speed Control Architecture, Power Good, Soft Start	64-pin 12 x 12 QFN
MIC45118-1	4.5 to 20	Adj.	-40 to +125	COT	600	17	6	HyperLight Load Mode, Power Good, Soft Start	52-pin 8 x 8 QFN
MIC45118-2	4.5 to 20	Adj.	-40 to +125	COT	600	17	6	Hyper Speed Control Architecture, Power Good, Soft Start	52 pin 8 x 8 QFN
MIC45404	4.5 to 19	Selectable	40 to +125	Fixed	400-790	3.3	5	Power Good, Soft Start	64-pin 6 x 10 QFN
MIC33M356	2.4 to 5.5	3.3	-40 to +125	COT	2300	3.84	3	HyperLight Load, PC, Meet CISPR 32 class B specifications	3 x 4.5 x 1.8
MIC33M350	2.4 to 5.5	3.3	-40 to +125	COT	1200	3.3	3	HyperLight Load, Meet CISPR 32 class B specifications	3 x 4.5 x 1.8
MIC38300	3.0 to 5.5	Adjustable, Down to 1.0V	-40 to +125	Switcher Plus LDO	Adjustable by Low Pass Filter(LPF) pin	Up to 5.0V	3	HELDOTM High Efficiency Regulator, Ultra Fast Transient, Low Output Noise	28-pin 4 mm x 6 mm x 0.9 mm MLF
MIC38150	3.0 to 5.5	Adjustable, Down to 1.0V	-40 to +125	Switcher Plus LDO	Adjustable by LPF pin	Up to 5.0V	1.5	HELDO High Efficiency Regulator, Ultra Fast Transient, Low Output Noise	28-pin 4 mm x 6 mm x 0.9 mm MLF

POWER MANAGEMENT: Charge Pump DC-to-DC Converters

Part # Configuration		Input Voltage Range (V)	Output Voltage (V)	Typical Output Current (mA)	Switching Frequency (kHz)	Supply Current (Is, floating output μA, 25°C)	Output Resistance (Ω, at typical output current, 25°C)	Power Conversion Efficiency (%)	Features Packages
Inverting or Doubling Charge Pumps
TC682	Inverted doubling	2.4 to 5.5	-2°VN	10	12	185	140	92% at 2.5 mA	-	8-pin SCIC and 8-pin PDIP
TC1240A	Doubling	2.5 to 5	2°VN	20	80	550	12	94% at 5 mA	Shutdown	6-pin SOT 28
TC7660S	Inverting or doubling	1.5 to 12	-VN or 2° VN	20	10 or 45	80	80	98% at 1 mA	Boost pin increases switching frequency	8-pin SCIC and 8-pin PDIP
TC7660H	Inverting or doubling	1.5 to 10	-VN or 2° VN	20	120	1000	55	85% at 10 mA	High-voltage oscillator	8-pin SCIC and 8-pin PDIP
TC7662B	Inverting or doubling	1.5 to 15	-VN or 2° VN	20	10 or 35	80	65	96% at 1 mA	Boost pin increases switching frequency	8-pin SCIC and 8-pin PDIP
TC7662A	Inverting or doubling	3 to 18	-VN or 2° VN	40	12	190	50	97% at 7.5 mA	No low-voltage terminal required	8-pin PDIP
TC962	Inverting or doubling	3 to 18	-VN or 2° VN	60	12 or 24	190	35	97% at 7.5 mA	Boost pin increases switching frequency	16-pin SOC, 8-pin PDIP
Regulated Charge Pumps
MCP1256	Regulated	1.8 to 3.6	3.3	100	650	2300	N/A	85% at 60 mA	Soft start, shutdown, power good signal and sleep mode	10-pin MSOP and 10-pin 3 x 3 DFN
MCP1257	Regulated	1.8 to 3.6	3.3	100	650	2300	N/A	85% at 60 mA	Soft start, shutdown, low battery warning signal, and sleep mode	10-pin MSOP and 10-pin 3 x 3 DFN
MCP1258	Regulated	1.8 to 3.6	3.3	100	650	2300	N/A	85% at 60 mA	Soft start, shutdown, power good signal and bypass mode	10-pin MSOP and 10-pin 3 x 3 DFN
MCP1259	Regulated	1.8 to 3.6	3.3	100	650	2300	N/A	85% at 60 mA	Soft start, shutdown, low battery warning signal, and bypass mode	10-pin MSOP and 10-pin 3 x 3 DFN
MCP1252	Regulated	2.0 to 5.5	3.3, 5.0, or adjustable	150	65060	N/A 81% at 10 mA			Shutdown, power good, regulated output, adjustable version	8-pin MSOP
MCP1253	Regulated	2.0 to 5.5	3.3, 5.0, or adjustable	150	1000	60	N/A	81% at 10 mA	Shutdown, power good, regulated output, adjustable version	8-pin MSOP

POWER MANAGEMENT: CPU/System Supervisors

Part #

Type

Watchdog Timer

Manual Reset

Power Fall

Operating Temp. Range (°C)

Vcc Range (V)

Nominal Reset Voltage (V)

Reset Type

Output

Typical Reset Pulse Width (ms)

Typical Supply Current (μA)

Packages

MCP100

Supervisor

-40 to +85

1.0-5.5

2.7, 3, 3.15, 4.5, 4.6, 4.75, 4.85

Active Low

Push-Pull

350

3-pin SOT-23, 3-pin TO-92

MCP101

Supervisor

-40 to +85

1.0-5.5

2.7, 3, 3.15, 4.5, 4.6, 4.75, 4.85

Active High

Push-Pull

350

3-pin SOT-23, 3-pin TO-92

MCP102

Supervisor

-40 to +125

1.0-5.5

1.95 (Temp), 2.4, 2.7, 3, 3.15, 4.5, 4.75

Active Low

Push-Pull

120

3-pin SC/70, 3-pin SOT 23, 8-pin SOIC 150 mil, 3-pin TO-92

MCP103

Supervisor

-40 to +125

1.0-5.5

1.95 (Temp), 2.4, 2.7, 3, 3.15, 4.5, 4.75

Active Low

Push-Pull

120

3-pin SC/70, 3-pin SOT 23

MCP120

Supervisor

-40 to +85

1.0-5.5

2.7, 3, 3.15, 4.5, 4.6, 4.75, 4.85

Active Low

Open-Drain

350

8-pin SOT 23, 8-pin SOIC 150 mil, 3-pin TO-92

MCP121

Supervisor

-40 to +125

1.0-5.5

1.95 (Temp), 2.4, 2.7, 3, 3.15, 4.5, 4.75

Active Low

Open-Drain 120

3-pin SC-70, 3-pin SOT-23, 8-pin SOIC 150 mil, 3-pin TO-92

MCP130

Supervisor

-40 to +85

1.0-5.5

2.7, 3, 3.15, 4.5, 4.6, 4.75, 4.85

Active Low

Open-Drain

350

8-pin SOT-23, 8-pin SOIC 150 mil, 3-pin TO-92

MCP131

Supervisor

-40 to +125

1.0-5.5

1.95 (Temp), 2.4, 2.7, 3, 3.15, 4.5, 4.75

Active Low

Open-Drain 120

3-pin SC-70, 3-pin SOT-23, 8 pin SOIC 150 mil, 3 pin TO-92

MCP1316

Supervisor

√

-40 to -125

1.0-5.5

2.9, 4.6, (2.0-2.4V-I-Temp, 2.4-4.7-Ext)

Active Low

Push-Pull

200

5-pin SOT-23

MCP1316M

Supervisor

√

-40 to +125

1.0-5.5

2.9, 4.6, (2.0-2.4V-I-Temp, 2.4-4.7-Ext)

Active Low

Open-Drain 200

5-pin SOT-23

MCP1317

Supervisor

√

-40 to +125

1.0-5.5

2.9, 4.6, (2.0-2.4V-I-Temp, 2.4-4.7-Ext)

Active High

Push-Pull

200

5-pin SOT-23

MCP1318

Supervisor

√

-40 to +125

1.0-5.5

2.9, 4.6, (2.0-2.4V-I-Temp, 2.4-4.7-Ext)

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

200

5-pin SOT-23

MCP1318M

Supervisor

√

-40 to +125

1.0-5.5

2.9, 4.6, (2.0-2.4V-I-Temp, 2.4-4.7-Ext)

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

200

5-pin SOT-23

www.microchip.com/analloy
POWER MANAGEMENT: CPU/System Supervisors

Part # Type

Watchdog Timer

Manual Reset

Power Fall

Operating Temp. Range (°C)

Vcc Range (V)

Nominal Reset Voltage (V) Reset Type Output

Typical Reset Pulse Width (ms)

Typical Supply Current (μA)

Packages

MCP1319

Supervisor -

✓

-40 to +126 1.0-5.5

2.9, 4.8,(2.0-2.4V=I-Temp, 2.4-4.7=Ext)

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

200 15-pin SOT-23

MCP1319M

Supervisor -

✓

-40 to +126 1.0-5.5

2.9, 4.8,(2.0-2.4V=I-Temp, 2.4-4.7=Ext)

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

200 15-pin SOT-23

MCP1320

Supervisor

✓

-40 to +126 1.0-5.5

2.9, 4.8, (2.0-2.4V=I-Temp, 2.4-4.7=Ext)

Active Low Open Drain 200 15-pin SOT-23

MCP1321

Supervisor

✓

-40 to +126 1.0-5.5

2.9, 4.8, (2.0-2.4V=I-Temp, 2.4-4.7=Ext)

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

200 15-pin SOT-23

MCP1322

Supervisor -

✓

-40 to +126 1.0-5.5

2.9, 4.8, (2.0-2.4V=I-Temp, 2.4-4.7=Ext)

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

200 15-pin SOT-23

MCP7809

Supervisor

-40 to +85

1.0-5.5

2.7, 3.0, 3.15, 4.5, 4.6, 4.75, 4.85

Active Low

Push-Pull

350

3-pin SOT-23

MCP7810

Supervisor

-40 to +85

1.0-5.5

2.7, 3.0, 3.15, 4.5, 4.6, 4.75, 4.85

Active High

Push-Pull

350

3-pin SOT-23

TC1232

Supervisor

✓

-40 to +85

1.5-5.5

4.5, 4.75

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

610

8-pin PDIP, 16 pin SOIC 300 ml, 8-pin SOIC 150 ml

TC1270A

Supervisor -

✓

-40 to +125

1.0-5.5

2.7, 3, 3.15, 4.5, 4.75

Active Low

Push-Pull

280

4-pin SOT-143, 5-pin SOT-23

TC1270AN

Supervisor -

✓

-40 to +125

1.0-5.5

2.7, 3, 3.15, 4.5, 4.75

Active Low

Open Drain

280

4-pin SOT-143, 5-pin SOT-23

TC1271A

Supervisor -

✓

-40 to +125

1.0-5.5

2.7, 3, 3.15, 4.5, 4.75

Active High

Push Pull

280

4-pin SOT-143, 5-pin SOT-23

TC1272A

Supervisor

-40 to -125

1.0-5.5

4.50, 4.25, 3.89, 3.00, 2.85, 2.55, 2.25

Active Low

Push-Pull

140

3-pin SOT-23

TC32M

Supervisor

✓

-40 to +85

1.5-5.5

4.25

Active Low

Open Drain

500

3-pin TO-82, 3-pin SOT-223

TCM809

Supervisor

40 to -125

1.0-5.5

4.50, 4.25, 3.89, 3.00, 2.85, 2.55, 2.25

Active Low

Push-Pull

140

3-pin SC-70, 3-pin SOT-23

TCM810

Supervisor

40 to -125

1.0-5.5

4.50, 4.25, 3.89, 3.00, 2.85, 2.55, 2.25

Active High

Push-Pull

140

3-pin SC-70, 3-pin SOT-23

MIC705

Supervisor

✓ ✓

✓

-40 to +85

1.5-5.5

4.65

Active Low

Push-Pull

140

8-pin SOIC

MIC706

Supervisor

✓ ✓

✓

-40 to +85

1.5-5.5

4.4

Active Low

Push-Pull

140

8-pin SOIC

MIC707

Supervisor -

✓

-40 to +85

1.5-5.5

4.65

Active Low/High or High/Low

Push-Pull

140

8-pin SOIC

MIC708

Supervisor -

✓

-40 to +85

1.5-5.5

4.4

Active Low/High or High/Low

Push-Pull

140

8-pin SOIC

MIC803

Supervisor

-40 to +125

1.0-5.5

2.63, 2.93, 3.00, 3.08, 4.00, 4.10, 4.38, 4.63

Active Low Open Drain

20/140/1100

53-pin SOT23, 3-pin SC70

MIC809

Supervisor

-40 to +85

1.4-5.5

2.63, 2.93, 3.08, 4.00, 4.38, 4.63

Active Low

Push-Pull

140

3-pin SOT23, 3-pin SC70

MIC809-5

Supervisor

✓

-40 to +125

1.4-5.5

2.93

Active Low

Push Pull

3-pin SOT23, 3 pin SC70

MIC810

Supervisor

-40 to +85

1.4-5.5

2.63, 2.93, 3.08, 4.00, 4.38, 4.63

Active Low/High or High/Low

Push-Pull

14/63-pin SOT23, 3-pin SC70

MIC811

Supervisor

✓

-40 to +85

1.4-5.5

2.63, 2.93, 3.08, 4.00, 4.38, 4.63

Active Low

Push Pull

140

SOT143

MIC812

Supervisor -

✓

-40 to +85

1.4-5.5

2.63, 2.93, 3.08, 4.00, 4.38, 4.63

Active Low/High or High/Low

Push Pull

14/65SOT143

MIC1810

Supervisor

-40 to +85

1.5-5.5

4.12, 4.37, 4.82

Active Low

Push-Pull

100

3-pin SOT23

MIC1815

Supervisor

-40 to +85

1.5-5.5

2.55, 2.88

Active Low

Push Pull

100

3 pin SOT23

MIC1232

Supervisor

✓

-40 to +85

4.5-5.5

4.37, 4.62

Active Low/High or High/Low

Push-Pull

250

8-pin SOIC, 8-pin PDIP

MIC1832

Supervisor

✓

-40 to +85

1.4-5.5

2.55, 2.88

Active Low/High or High/Low

Push Pull

250

8-pin SOIC, 8-pin PDIP

MIC2755

Supervisor -

✓

-40 to +85

1.5-5.5

1.24

Active Low

Open Drain

700

8-pin MSOP

MIC2775

Supervisor -

✓

-40 to +85

1.5-5.5

1.69, 2.25, 2.34, 2.53, 2.87, 2.81, 2.93, 3.09, 4.43, 4.68

Active Low/High or High/Low

Push Pull

14/65-pin SOT23

MIC2776N

Supervisor -

✓

-40 to +85

1.5-5.5

0.3

Active Low

Open Drain

140

5-pin SOT23

MIC2776H

Supervisor -

✓

-40 to +85

1.5-5.5

0.3

Active High

Push Pull

140

5-pin SOT23

MIC2776L

Supervisor -

✓

-40 to +85

1.5-5.5

0.3

Active Low

Push Pull

140

6-pin SOT23

MIC2778

Supervisor -

-40 to +85

1.5-5.5

1.24 with adjustable hysteresis

Active Low

Open Drain

140

5-pin SOT23

MIC2779H

Supervisor -

-40 to +85

1.5-5.5

1.24 with adjustable hysteresis

Active High

Push Pull

140

5-pin SOT23

POWER MANAGEMENT: CPU/System Supervisors

Part # Type

Watchdog Timer

Manual Reset

Power Fall

Operating Temp. Range (°C)

Vcc Range (V)

Nominal Reset Voltage (V) Reset Type Output

Typical Reset Pulse Width (ms)

Typical Supply Current (μA)

Packages

MIC2770L

Supervisor

-40 to +85

1.5-5.5

1.24 with adjustable hysteresis

Active Low

Push-Pull

140

5-pin SOT23

MIC2765

Supervisor

√

-40 to 185

1.5-5.5

1.62

Active Low

Push-Pull

0.025

6 pin 1.2 x 1.2 QFN

MIC6315

Supervisor -

√

-40 to +85 1.4-5.5

2.63, 2.93, 3.00, 3.08, 4.00, 4.10, 4.38, 4.63

Active Low

Open-Drain

20/140/1100

4-pin SOT143

MIC8114

Supervisor

√

-40 to 185

1.0-5.5

3.08

Active Low

Push-Pull

790

4 pin SOT143

MIC8115

Supervisor -

√

-40 to +85

1.0-5.5

3.08

Active Low

Push-Pull

1100

4-pin SOT143

MIC826

Supervisor

√

-40 to +125

1.0-5.5

1.665, 2.189, 2.315, 2.625, 2.925, 3.075, 4.375, 4.625

Active Low/high or High/Low

Push-Pull 140

6-pin 1.8 x 1.6 DFN

MIC706P/R/S/T

Supervisor

√

-40 to +85

1.5-5.5

2.63, 2.93, 3.08

Active Low

Push-Pull

140

8-pin SOIC

MIC706P/R/S/T

Supervisor -

√

-40 to +85 1.6-5.5

2.63, 2.93, 3.08

Active Low/high or High/Low

Push-Pull 14030

8-pin SOIC

TC51

Detector

-40 to +85

0.7-10

2.94, 2.65, 2.16 (1.8-6V)

Active Low

Open-Drain

3-pin SOT-23A

TC54 Detector

-40 to +85

0.7-10

4.21, 4.12, 2.94, 2.84, 2.85, 2.06, 1.37 (1.4-6V)

Active Low

CMOS Push-Pull or Open drain

3-pin SOT-89, 3-pin TO-92, 5-pin SOT-23, 3-pin SOT 23A

MCP111

Detector

-40 to +125

1.0-5.5

1.87(temp), 2.29, 2.59, 2.86, 2.87, 3.03, 4.31, 4.58

Active Low

Open-Drain

3-pin SC-70, 3-pin SOT-89, 3-pin SOT-23, 3 pin TO-82

MCP112

Detector

-40 to +125

1.0-5.5

1.87(temp), 2.29, 2.59, 2.86, 2.87, 3.03, 4.31, 4.58

Active Low Push Pull

3-pin SC-70, 3-pin SOT-89, 6-pin PDIP, 3 pin SOT 23, 3 pin TO-82

TC52

Detector

-40 to +85

1.5-10

4.41, 2.65 (1.5-5V)

Active Low

Open-Drain

5-pin SOT-23

TC53

Detector

-40 to +85

1.5-10

2.84, 2.65, 2.16 (1.8-6V, IV)

Active Low

CMOS Push-Pull or Open drain

5-pin SOT-23

MIC2772

Dual

√

-40 to +85

1.0-5.5

2.93, 3.08, 4.38, 4.63

Active Low

Open-Drain

20/140/1100

8-pin 2 x 2 MLF

MIC2774N Dual

√

-40 to +85 1.5-5.5

1.69, 2.25, 2.34, 2.53, 2.87, 2.81, 2.93, 3.09, 4.43, 4.68

Active Low

Open-Drain

1403.55-pin SOT23

MIC2774H Dual

√

-40 to +85 1.5-5.5

1.69, 2.25, 2.34, 2.53, 2.87, 2.81, 2.93, 3.09, 4.43, 4.68

Active High Push-Full 1403.55-pin SOT23

MIC2774L

Dual

√

-40 to +85 1.5-5.5

1.69, 2.25, 2.34, 2.53, 2.87, 2.81, 2.93, 3.09, 4.43, 4.68

Active Low Push-Pull 1403.55-pin SOT23

MIC2777

Dual

-40 to +85

1.5-5.5

1.69, 2.25, 2.34, 2.53, 2.87, 2.81, 2.93, 3.09, 4.43, 4.68

Active Low/High or High/Low

Push-Pull 1403.55-pin SOT23

MIC2782

Push Button

Dual

-40 to +85

1.5-5.5

Custom options

Active Low

Open-Drain

500/1000/2000

2.2

6-pin 0.8 x 1.2 CSP

MIC2790

Push Button

√

-40 to +125

1.5-5.5

0.4

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

1.0540

8-pin 2 x 2 DFN

MIC2791

Push Button

√

-40 to +125

1.5-5.5

0.4

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

1.0540

8-pin 1.8 x 1.6 DFN

MIC2793

Push Button

√

-40 to +125

1.5-5.5

0.4

Active Low/High or High/Low

Dual Output Open-Drain and/or Push-Pull

1.0540

8-pin 2 x 2 DFN

POWER MANAGEMENT: Power MOSFET Drivers

Part #	Drivers	Configuration	Peak Output Current (source/sink, A)	Maximum Supply Voltage (V)	Output Resistance (source/sink, Ω)	Propagation Delay ( T_in/T_out , ns)	Rise/Fall Time ( T/T_in , ns)	Capacitive Load Drive	Features	Packages
Low-Side Power MOSFET Drivers
MCP1401	Single	Inverting	0.5/0.5	18	12/10	35/35	19/15	470 pF in 19 ns	Small footprint	5-pin SOT-23
MCP1402	Single	Non-inverting	0.5/0.5	18	12/10	35/35	19/15	470 pF in 19 ns	Small footprint	6-pin SOT-23
MCP14A0051	Single	Inverting	0.5/0.5	18	12.5/7.5	33/24	40/28	1000 pF in 40 ns	Enable pin, small footprint	6-pin SOT-23, 6-pin 2 x 2 DFN
MCP14A0052	Single	Non-inverting	0.5/0.5	18	12.5/7.5	33/24	40/28	1000 pF in 40 ns	Enable pin, small footprint	6-pin SOT-23, 6-pin 2 x 2 DFN
TC1410N	Single	Non-inverting	0.5/0.5	18	18/16	30/30	25/25	300 pF in 25 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP
TC1411N	Single	Non-inverting	1.0/1.0	18	8/8	30/30	25/25	1000 pF in 25 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP

www.microchip.com/analloy
POWER MANAGEMENT: Power MOSFET Drivers

Part # Drivers Configuration			Peak Output Current (source/sink, A)	Maximum Supply Voltage (V)	Output Resistance (source/sink, Ω)	Propagation Delay ( T_R/T_e2,ns)	Rise/Fall Time (T/T1, ns)	Capacitive Load Drive	Features Packages
Low-Side Power MOSFET Drivers
MIC4416 Single Non-Inverting 1.2/1.2 18.3.5/3.5 33/23 14/16 1000 pF in 16 ns SOT-143
MIC4417 Single Inverting 1.2/1.2 18.3.5/3.5 33/23 14/16 1000 pF in 16 ns SOT-143
TC1426	Dual	Inverting	1.2/1.2	18	12/8	36/43	23/17	1000 pF in 38 ns		8-pin SOIC, 8-pin PDIP
TC1427	Dual	Non-inverting	1.2/1.2	16	12/8	36/43	23/17	1000 pF in 38 ns		8-pin SOIC, 8-pin PDIP
TC1428	Dual	Complimentary	1.2/1.2	18	12/8	38/43	23/17	1000 pF in 38 ns		8-pin SOIC, 8-pin PDIP
MIC4467 Quad Inverting 1.2/1.2 18			5/5	30/45 14/13 1000 pF in 28 ns					Latch up Protected; Input to -5V	16-pin WSOIC, 14-pin PDIP, 100 pF in 19 ns
MIC4468	Quad	Non-inverting	1.2/1.2	18	5/5	30/45	14/13	1000 pF in 25 ns	Latch-up Protected; Input to -5V	16-pin WSOIC, 14-pin PDIP, 100 pF in 19 ns
MIC4469	Quad	Complimentary	1.2/1.2	18	5/5	30/45	14/13	1000 pF in 25 ns	Latch-up Protected; Input to -5V, SMD	18-pin WSOIC, 14-pin PDIP, 100 pF in 19 ns
TC4467	Quad	Inverting	1.2/1.2	18	10/10	40/40	15/15	4/0 pF in 15 ns		16-pin SOIC, 14-pin PDIP
TC4468	Quad	Non-inverting	1.2/1.2	18	10/10	40/40	15/15	4/0 pF in 15 ns		16-pin SOIC, 14-pin PDIP
TC4469	Quad	Complimentary	1.2/1.2	18	10/10	40/40	15/15	4/0 pF in 15 ns		16-pin SOIC, 14-pin PDIP
MCP14A0151	Single	Inverting	1.5/1.5	18	4.5/3	33/24	11/10	1000 pF in 11.5 ns	Low Input Threshold and Enabe Pin	6-pin SOT-23, 6-pin 2 x 2 DFN
MCP14A0152	Single	Non-inverting	1.5/1.5	18	4.5/3	33/24	11/10	1000 pF in 11.5 ns	Low Input Threshold and Enabe Pin	6-pin SOT-23, 6 pin 2 x 2 DFN
MCP1415	Single	Inverting	1.5/1.5	18	8/4	44/47	18/21	4/0 pF in 13 ns	Small footprint	5 pin SOT-23
MCP1416	Single	Non-inverting	1.5/1.5	18	6/4	44/47	18/21	4/0 pF in 13 ns	Small footprint	5-pin SOT-23
MIC4414	Single	Non-inverting	1.5/1.5	18	3.5/3.5	44/47	18/21	1000 pF in 12 ns	Very small footprint	1.2 x 1.2 QFN
MIC4415	Single	Inverting	1.5/1.5	18	3.5/3.5	29/30	12/12	1000 pF in 12 ns	Very small footprint	1.2 x 1.2 QFN
TC4626	Single	Inverting	1.5/1.5	6	10/8	29/30	33/27	1000 pF in 40 ns	Boosted drive voltage	16-pin SOIC, 8-pin PDIP
TC4627	Single	Non-inverting	1.5/1.5	6	10/8	35/45	33/27	1000 pF in 40 ns	Boosted drive voltage	16-pin SOIC, 8-pin PDIP
TC4404	Single	Inverting	1.5/1.5	18	7/7	15/32	25/25	1000 pF in 30 ns	Open - drain	8 pin SOIC, 8 pin PDIP
TC4405	Single	Non-inverting	1.5/1.5	18	7/7	15/32	25/25	1000 pF in 30 ns	Open - drain	8-pin SOIC, 8-pin PDIP
MCP14A0153	Dual	Inverting	1.5/1.5	18	4.5/3	25/24	11/10	1000 pF in 11.5 ns	Low Input Threshold and Enabe Pin	8-pin SOIC, 8-pin WSOP, 8-pin 2 x 3 DFN
MCP14A0154	Dual	Non-inverting	1.5/1.5	18	4.5/3	25/24	11/10	1000 pF in 11.5 ns	Low Input Threshold and Enabe Pin	8-pin SOIC, 8-pin WSOP, 8-pin 2 x 3 DFN
MCP14A0155	Dual	Complimentary	1.5/1.5	18	4.5/3	25/24	11/10	1000 pF in 11.5 ns	Low Input Threshold and Enabe Pin	8-pin SOIC, 8-pin WSOP, 8-pin 2 x 3 DFN
TC4426A	Dual	Inverting	1.5/1.5	18	7/7	30/30	25/25	1000 pF in 25 ns		8-pin SOIC, 8-pin WSOP, 8-pin PDIP, 8-pin 6 x 6 DFN-S
TC4427A	Dual	Non-inverting	1.5/1.5	18	7/7	30/30	25/25	1000 pF in 25 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP, 8-pin 6 x 5 DFN-S
TC4428A	Dual	Complimentary	1.5/1.5	18	7/7	30/30	25/25	1000 pF in 25 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP, 8-pin 6 x 5 DFN-S
MIC4426	Dual	Inverting	1.5/1.5	18	8/6	17/23	18/15	1000 pF in 18 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP, 8-pin CerDIP
MIC4427	Dual	Non-inverting	1.5/1.5	18	6/6	17/23	18/15	1000 pF in 18 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP, 8-pin CerDIP
MIC4428	Dual	Complimentary	1.5/1.5	18	6/6	17/23	18/15	1000 pF in 18 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP, 8-pin CerDIP
MIC4426	Dual	Inverting	1.5/1.5	20	6/6	37/40	13/15	1000 pF in 15 ns		8-pin eSOIC, 8-pin eMSOP-B, 3 x 3 DFU
MIC4427	Dual	Non-inverting	1.5/1.5	20	6/6	37/40	13/15	1000 pF in 15 ns		8-pin eSOIC, 8-pin eMSOP-B, 3 x 3 DFN
MIC4428	Dual	Complimentary	1.5/1.5	20	6/6	37/40	13/15	1000 pF in 15 ns		8 pin eSOIC, 8 pin eMSOP-B, 3 x 3 DFN
MCP14C6B	Dual	Inverting	2.0/2.0	18	5/5	45/45	12/15	1000 pF in 15 ns	Enable pin	8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
MCP14E7	Dual	Non-inverting	2.0/2.0	18	5/5	45/45	12/15	1000 pF in 15 ns	Enable pin	8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
MCP14EB	Dual	Complimentary	2.0/2.0	18	5/5	45/45	12/15	1000 pF in 15 ns	Enable pin	8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
TC1412	Single	Inverting	2.0/2.0	16	4/4	35/35	19/19	1000 pF in 18 ns		8-pin SOIC, 8-pin MSOP, 8-pin PDIP
TC1412N	Single	Non-inverting	2.0/2.0	16	4/4	35/35	16/18	1000 pF in 18 ns		8 pin SOIC, 8 pin MSOP, 8 pin PDIP

POWER MANAGEMENT: Power MOSFET Drivers

Part # Drivers Configuration			Peak Output Current (source/sink, A)	Maximum Supply Voltage (V)	Output Resistance (source/sink, Ω)	Propagation Delay (Tg/Td, ns)	Rise/Fall Time (T/T1, ns)	Capacitive Load Drive	Features Packages
Low-Side Power MOSFET Drivers
MIC4478 Dual Non-Inverting 2.5/2.5 32 6/3 160/70 120/45 1,000pF in 45 ns. 8-pin SOIC
MIC4479 Dual Inverting 2.5/2.5 32 8/3 160/70 120/45 1,000pF in 45 ns. 8-pin SOIC
MIC4460 Dual Complimentary 2.5/2.5 32 6/3 160/70 120/45 1,000pF in 45 ns. 8-pin SOIC
TC4423A	Dual	Inverting	3.0/3.0	18	2.2/2.8	40/41	12/12	1800 pF in 12 ns
TC4424A	Dual	Non-Inverting	3.0/3.0	18	2.2/2.8	40/41	12/12	1800 pF in 12 ns
TC4425A	Dual	Complimentary	3.0/3.0	18	2.2/2.8	40/41	12/12	1800 pF in 12 ns
MCP14E9	Dual	Inverting	3.0/3.0	18	4/4	45/45	14/17	1800 pF in 17 ns	Enable pin
MCP14E10	Dual	Non Inverting	3.0/3.0	18	4/4	45/45	14/17	1800 pF in 17 ns	Enable pin
MCP14E11	Dual	Complimentary	3.0/3.0	18	4/4	45/45	14/17	1800 pF in 17 ns	Enable Pin
MCP14A0301	Single	Interverting	3.0/3.0	18	2.2/1.5	15/18	13/12	1,800 pF in 13 ns	Low Input Threshold, Enable Pin
MCP14A0302	Single	Non Inverting	3.0/3.0	18	2.2/1.5	15/18	13/12	1,800 pF in 13 ns	Low Input Threshold and Enable Pin
TC1413N	Single	Non-Inverting	3.0/3.0	16	2.7/2.7	35/35	20/20	1800 pF in 20 ns
MIC4123	Dual	Inverting	3.0/3.0	20	5/5	44/59	11/11	1,800 pF in 11 ns
MIC4124	Dual	Non-Inverting	3.0/3.0	20	5/5	44/59	11/11	1,800 pF in 11 ns
MIC4125	Dual	Complimentary	3.0/3.0	20	5/5	44/59	11/11	1,800 pF in 11 ns
MIC4423	Dual	Inverting	3.0/3.0	18	5/5	33/38	23/25	1,800 pF in 23ns
MIC4424	Dual	Non-Inverting	3.0/3.0	18	5/5	33/38	23/25	1,800 pF in 23ns
MIC4425	Dual	Complimentary	3.0/3.0	18	5/5	33/38	23/25	1,800 pF in 23ns
MIC4223	Dual	Inverting	4.0/4.0	18	30/16	25/35	15/15	2000 pF in 15 ns	Enable pin
MIC4224	Dual	Non-Inverting	4.0/4.0	18	30/16	25/35	15/15	2000 pF in 15 ns	Enable pin
MIC4225	Dual	Complimentary	4.0/4.0	18	30/16	25/35	15/15	2000 pF in 15 ns	Enable pin
MCP14E3	Dual	Inverting	4.0/4.0	18	2.5/2.5	46/50	15/18	2200 pF in 15 ns	Enable pin
MCP14E4	Dual	Non-Inverting	4.0/4.0	18	2.5/2.5	46/50	15/18	2200 pF in 15 ns	Enable pin
MCP14E5	Dual	Complimentary	4.0/4.0	18	2.5/2.5	46/50	15/18	2200 pF in 15 ns	Enable pin
MCP1403	Dual	Inverting	4.5/4.5	18	2.2/2.8	40/40	15/18	2200 pF in 15 ns
MCP1404	Dual	Non-Inverting	4.5/4.5	18	2.2/2.8	40/40	15/18	2200 pF in 15 ns
MCP1405	Dual	Complimentary	4.5/4.5	18	2.2/2.8	40/40	15/18	2200 pF in 15 ns
MCP14A0451	Single	Inverting	4.5/4.5	18	1.6/1.2	18/19	9/9	2200 pF in 9.5 ns	Low Input Threshold, Enable
MCP14A0452	Single	Non-Inverting	4.5/4.5	18	1.6/1.2	16/19	9/9	2200 pF in 9.5 ns	Low Input Threshold, Enable
MIC4120	Single	Non-Inverting	6.0/6.0	20	5/5	45/50	12/13	2200 pF in 12 ns
MIC4129	Single	Inverting	6.0/6.0	20	5/5	45/50	12/13	2200 pF in 12 ns
MCP14A1201	Single	Inverting	12/12	18	1.5/1.2	28/28	25/25	15,000 pF in 25 ns	Low Input Threshold and Enable
MCP14A1202	Single	Non-Inverting	12/12	18	1.5/1.2	28/28	25/25	15,000 pF in 25 ns	Low Input Threshold and Enable
MIC4420	Single	Non-Inverting	6.0/6.0	18	2.8/2.5	18/48	12/13	2200 pF in 12 ns
MIC4429	Single	Inverting	6.0/6.0	18	2.8/2.5	19/48	12/13	2200 pF in 12 ns
MIC44F18	Single	Non-Inverting	6.0/6.0	13	2/2	15/13	10/10	1000 pF in 10 ns	Enable pin
MIC44F19	Single	Inverting	6.0/6.0	13	2/2	15/13	10/10	1000 pF in 10 ns	Enable pin
MIC44F20	Single	Inverting	6.0/6.0	13	2/2	15/13	10/10	1000 pF in 10 ns	Enable pin

POWER MANAGEMENT: Power MOSFET Drivers

Part # Drivers Configuration			Peak Output Current (source/sink, A)	Maximum Supply Voltage (V)	Output Resistance (source/sink, Ω)	Propagation Delay (Tg/Td2, ns)	Rise/Fail Time (T/Td, ns)	Capacitive Load Drive	Features Packages
Low-Side Power MOSFET Drivers
MCP1406 Single Inverting 6.0/8.0 18 2.1/1.5 40/40 20/20 2500 pF in 20 ns 8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
MCP1407 Single Non-Inverting 6.0/8.0 19 2.1/1.5 40/40 20/20 2500 pF in 20 ns 8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
MCP14A0601	Single	Inverting	8.0/6.0	18	2.0/2.3	29/29	15/15	2500 pF in 10 ns	Low Logic Input, Enable	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 DFN
MCP14A0602	Single	Non-Inverting	6.0/6.0	18	2.0/2.3	29/29	15/15	2500 pF in 10 ns	Low Logic Input, Enable	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 DFN
TC4421A	Single	Inverting	9.0/9.0	18	1.25/0.8	38/42	28/26	4700 pF in 15 ns		8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
TC4422A	Single	Non-Inverting	9.0/9.0	18	1.25/0.8	38/42	28/26	4700 pF in 15 ns		8-pin SOIC, 8-pin PDIP, 8 pin 6 x 5 DFN
MIC14/21A	Single	Inverting	9.0/9.0	18	0.8/0.6	15/35	20/24	10,000 pF in 24 ns		8-pin PDIP, 8-pin SOIC, 5-pin TO-220
MIC4422A	Single	Non-Inverting	9.0/9.0	18	0.8/0.6	15/35	20/24	10,000 pF in 24 ns		8-pin PDIP, 8 pin SOIC, 5-pin TO-220
MIC14/51	Single	Inverting	12.0/12.0	18	0.8/0.6	25/40	20/24	10,000 pF in 24 ns		8-pin PDIP, 8-pin SOIC, 5-pin TO-220
MIC4462	Single	Non-Inverting	12.0/12.0	18	0.8/0.6	25/40	20/24	10,000 pF in 24 ns		8-pin PDIP, 8-pin SOIC, 5-pin TO-220
TC4451	Single	Inverting	12.0/12.0	18	1.0/0.9	47/41	30/32	10,000 pF in 21 ns		8-pin SOIC, 8-pin PDIP, 8-pin 6 x 5 DFN
TC4452	Single	Non-Inverting	12.0/12.0	18	1.0/0.9	44/44	30/32	10,000 pF in 21 ns		8-pin SOIC, 8-pin PDIP, 8 pin 6 x 5 DFN

POWER MANAGEMENT: Power MOSFET Drivers (Continued)

Part #	Drivers	Configuration	Peak Output Current (source/sink, A)	Maximum Supply Voltage (V)	Output Resistance (source/sink, Ω)	Propagation Delay (Tet/Tcs, ns)	Rise/Fall Time (T./T, ns)	Capacitive Load Drive	Features	Packages
High-Side Power MOSFET Drivers
TC4431	High-Side Single	Inverting	3.0/1.5	30	7/7	62/78	25/33	1000 pF in 25 ns	30V, high-side driver	8-pin SOIC, 8-pin PDIP
TC4432	High-Side Single	Non-inverting	3.0/1.5	30	7/7	62/78	25/33	1000 pF in 25 ns	30V, high-side driver	8-pin SOIC, 8-pin PDIP
TC4403	Floating Load Driver	Non-inverting	1.5/1.5	18	2.8/3.5	33/38	28/32	1800 pF in 25 ns	Floating load driver	8-pin PDIP
MIC5011	High-Side or Low Side Single	Non-inverting	950 μA*	32	N/A	N/A	25 μs/4 μs	1000 pF in 60 μs	Less than 1 μA in Standby Mode	8-pin SOIC, 8-pin PDIP
MIC5013	High-Side or Low Side Single	Non-inverting	225 μA*	32	N/A	N/A	60 μs/4 μs	1000 pF in 60 μs	With over-current shutdown and a fault flag	8-pin SOIC, 8-pin PDIP
MIC5014	High-Side or Low Side Single	Non-inverting	800 μA*	30	N/A	N/A	90 μs/6 μs	1000 pF in 90 μs	Withstands 80V transient and Reverse battery protected to -20V	8-pin SOIC, 8-pin PDIP
MIC5015	High-Side or Low Side Single	Inverting	800 μA*	30	N/A	N/A	90 μs/6 μs	1000 pF in 90 μs	Withstands 80V transient and Reverse battery protected to -20V	8-pin SOIC, 8-pin PDIP
MIC5018	High-Side or Low Side Single	Non-inverting	10 μA*	9	N/A	N/A	750 μs/10 μs	3,000 pF in 2.1 ms	Small Package	SOT 143
MIC5019	High-Side or Low Side Single	Non-inverting	10 μA*	9	N/A	N/A	440 μs/5.58 μs	3,000 pF in 1.24 ms	Ultra Small 1.2 × 1.2 mm DFN	4-pin DFN
MIC5021	High-Side or Low Side Single	Non-inverting	5600 μA*	38	N/A	500/800	400 ns/400 ns	2,000 pF in 550 ns	100 kHz operation guaranteed over full temperature and operating voltage range	8-pin SOIC, 8-pin PDIP
MIC5060	High-Side or Low Side Single	Non-inverting	800 μA*	30	N/A	N/A	90 μs/6 μs	1,000 pF in 90 μs	Withstands 80V transient and Reverse battery protected to -20V	8-pin MLF
Part # Drivers Configuration			Peak Output Current (source/sink, A)	Maximum Supply Voltage (V)	Output Resistance (source/sink, Ω)	Propagation Delay (Ta/Ta, ns)	Rise/Fall Time (Tt/Tt, ns)	Capacitive Load Drive	Features Packages
Synchronous Power MOSFET Drivers
MCP14628 Half Bridge Driver Dual Inputs 2.0/3.5				5.5(36V Boot Pin)	1/1(0.5 on low side)	15/22 10/10 3300 pF in 10 ns			Continuous or discontinuous operation	8-pin SOIC, 8-pin 3 x 3 DFN
MCP14700 Half Bridge Driver Dual Inputs 2.0/3.5				5.5(36V Boot Pin)	1/1(0.5 on low side)	15/22 10/10 3300 pF in 10 ns Allows external dead time control				8-pin SOIC, 8-pin 3 x 3 DFN
MIC4100 Half Bridge Driver Dual Inputs 2.0/2.0				16 (100V Boot Pin)	3.0/3.0 27/27 10/10 1000 pF in 10 ns 8-pin SOIC
MIC4101 Half Bridge Driver Dual Inputs 2.0/2.0				16 (100V Boot Pin)	3.0/3.0 31/31 10/10 1000 pF in 10 ns 8-pin SOIC
MIC4102 Half Bridge Driver Single PWM 3.0/2.0				16 (100V Boot Pin)	2.5/1.5 60/70	10/6	1000 pF in 10 ns		Adaptive Dead Time and Anti-Shoot-Through Circuitry	8-pin SOIC
MIC4103	Half Bridge Driver Dual Inputs 3.0/2.0			16 (100V Boot Pin)	2.5/1.25	24/24	10/6	1000 pF in 10 ns		8-pin SOIC
MIC4104	Half Bridge Driver Dual Inputs 3.0/2.0			16 (100V Boot Pin)	2.5/1.25	24/24	10/6	1000 pF in 10 ns		8 pin SOIC
MIC4800 Half Bridge Driver		Dual Inputs,Single PWM	-	28V	-	-	15/13.5	3000 pF in 15 ns	Intema 5V LDO	3 x 3 QFN
MIC4804	Half Bridge Driver Dual Inputs 1.0/1.0			16V (85V Boot Pin)	-	33/34	20/20	1000 pF in 20 ns	Small 2.5 x 2.5 mm DFN	8 pin SOIC, 8 pin 2.5 x 2.5 DFN
MIC4805 Half Bridge Driver		Dual Inputs,Single PWM	1.0/1.0	16V (85V Boot Pin)	-	35/35 20/20	1000 pF in 20 ns		Adaptive Dead Time and Anti-Shoot-Through Circuitry	8-pin SOIC, 8-pin 2.5 x 2.5 DFN
MIC4806 Full Bridge Driver		Dual Inputs,Single PWM	1.0/1.0	16V (85V Boot Pin)	-	35/35 20/20	1000 pF in 20 ns		Adaptive Dead Time and Anti-Shoot-Through Circuitry	4 x 4 QFN

"Charge pump current

POWER MANAGEMENT: Battery Chargers

Part #	Mode	Cell Type	# of Cells	Vcc Range (V)	Cell Voltage (V)	Maximum Charging Current (mA)	Max. Voltage Regulation (%)	Int/Ext FET	Features	Packages
MCP73113	Linear	Li-Ion/Li-Polymer	1	4 to 16	4.1, 4.2, 4.35, 4.4	1100	±0.5	Int	6.5V Overvoltage Protection	10-pin 3 x 3 DFN
MCP73114	Linear	Li-Ion/Li-Polymer	1	4 to 16	4.1, 4.2, 4.35, 4.4	1100	±0.5	Int	6.8V Overvoltage Protection	10-pin 3 x 3 DFN
MCP73123	Linear	LiFePO4	1	4 to 16	3.6	1100	±0.5	Int	9.5V Overvoltage Protection, LiFePO4 charging	10-pin 3 x 3 DFN
MCP73213	Linear	Li-Ion/Li-Polymer	2	4 to 16	9.2, 8.4, 8.7, 9.8	1100	±0.6	Int	13V Overvoltage Protection	10-pin 3 x 3 DFN
MCP73223	Linear	LiFePO4	2	4 to 16	7.2	1100	±0.6	Int	13V Overvoltage Protection, LiFePO4 charging	10-pin 3 x 3 DFN
MCP73828	Linear	Li-Ion/Li-Polymer	1	4.5 to 5.5	4.1, 4.2	N/A	±1.0	Ext	Small size, charge current set by external FET	6-pin SOT-23
MCP73827	Linear	Li-Ion/Li-Polymer	1	4.5 to 5.5	4.1, 4.2	N/A	±1.0	Ext	Mode indicator, Charge current monitor, Charge current set by external FET	8-pin MSOP
MCP73828	Linear	Li-Ion/Li-Polymer	1	4.5 to 5.5	4.1, 4.2	N/A	±1.0	Ext	Temperature monitor, Charge current set by external FET	8-pin MSOP
MCP73841	Linear	Li-Ion/Li-Polymer	1	4.5 to 12	4.1, 4.2	N/A	±0.5	Ext	Safety charge timers, Temperature monitor, Charge current set by external FET	10-pin MSOP
MCP73841	Linear	Li-Ion/Li-Polymer	1	4.5 to 12	4.1, 4.2	N/A	±0.5	Ext	Safety charge timers, Temperature monitor, Charge current set by external FET	10-pin MSOP
MCP73842	Linear	Li-Ion/Li-Polymer	2	8.7 to 12	8.2, 8.4	N/A	±0.5	Ext	Safety charge timers, Temperature monitor, Charge current set by external FET	10-pin MSOP
MCP73843	Linear	Li-Ion/Li-Polymer	1	4.5 to 12	4.1, 4.2	N/A	±0.5	Ext	Safety charge timers, Charge current set by external FET	8-pin MSOP
MCP73844	Linear	Li-Ion/Li-Polymer	2	8.7 to 12	8.2, 8.4	N/A	±0.5	Ext	Safety charge timers, Charge current set by external FET	8-pin MSOP
MCP73811	Linear	Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2	500	±1.0	Int	Selectable charge current (100 mA, 500 mA), Charge enable input	5-pin SOT-23
MCP73812	Linear	Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2	500	±1.0	Int	Programmable charge current (100 mA, 500 mA), Charge enable input	5-pin SOT-23
MCP73830/L Linear	Li-Ion/Li-Polymer		1	3.75 to 6.0	4.2	1000/200	±0.75	Int	Soft-start, Charge enable pin	6-pin 2 x 2 TDFN

POWER MANAGEMENT: Battery Chargers

Part # Mode Cell Type	# of Cells	Vcc Range (V)	Cell Voltage (V)	Maximum Charging Current (mA)	Max. Voltage Regulation (%)	Int/Ext FET	Features Packages
MCP73831 Linear Li-Ion/Li-Polymer	13.7 to 6.0	4.2, 4.35, 4.4, 4.5	500 ± 0.75 Int				UVLO, Thermal regulation, Programmable charge current, Tin state STAT pin	5-pin SCT-23, 8-pin 2 × 3 DFN
MCP73832 Linear Li-Ion/Li-Polymer	13.7 to 6.0	4.2, 4.35, 4.4, 4.5	500 ± 0.75 Int				UVLO, Thermal regulation, Programmable charge current, Open-drain STAT pin	5-pin SOT-23, 8-pin 2 × 3 DFN
MCP73833 Linear Li-Ion/Li-Polymer	14.5 to 6.5	4.1, 4.2	500 ± 0.5 Int				USB control, Safety charge timers, Temperature monitor, Thermal regulation	16 pin 4 × 4 QFN
MCP73835 Linear Li-Ion/Li-Polymer	14.5 to 6.5	4.1, 4.2	500 ± 0.5 Int				USB control, Safety charge timers, Thermal regulation	10-pin 3 × 3 DFN
MCP73833 Linear Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	UVLO, Thermal regulation, Thermistor input, LDO Test mode, Multiple Vire outputs, Safety timer, Power good output	10-pin 3 × 3 DFN, 10-pin MSOP
MCP73834 Linear Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	UVLO, Thermal regulation, Thermistor input, LDO Test mode, Multiple Vire outputs, Safety timer, Timer enable input	10-pin 3 × 3 DFN, 10-pin MSOP
MCP73837 Linear Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	Dual input (USB, DC input from adapter) auto-switching, UVLO, Thermal regulation, Thermistor input, Power good output	10-pin 3 × 3 DFN, 10 pin MSOP
MCP73838 Linear Li-Ion/Li Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	Dual input (USB, DC input from adapter) auto-switching, UVLO, Thermal regulation, Timer enable input	10 pin 3 × 3 DFN, 10 pin MSOP
MCP73843 Linear Li-Ion/Li-Polymer	1	4.5 to 12	4.1, 4.2	N/A	+0.5	Ext	Safety charge timers, Charge current set by external FET	8-pin MSOP
MCP73844 Linear Li-Ion/Li-Polymer	2	8.7 to 12	8.2, 8.4	N/A	+0.5	Ext	Safety charge timers, Charge current set by external FET	8-pin MSOP
MCP73811 Linear Li-Ion/Li Polymer	1	3.7 to 6.0	4.2	500	+1.0	Int	Sociotable charge current (100 mA, 500 mA), Charge enable input	5-pin SOT-23
MCP73812 Linear Li-Ion/Li Polymer	1	3.7 to 6.0	4.2	500	+1.0	Int	Programmable charge current (100 mA, 500 mA), Charge enable input	5-pin SOT-23
MCP73830L Linear Li-Ion/Li Polymer	1	3.75 to 6.0	4.2	1000/200	+0.75	Int	Soft start, Charge enable pin	6 pin 2 × 2 TDFN
MCP73831 Linear Li-Ion/Li-Polymer	13.7 to 6.0	4.2, 4.35, 4.4, 4.5	500 ± 0.75 Int				UVLO, Thermal regulation, Programmable charge current, Tin state STAT pin	5-pin SCT-23, 8-pin 2 x 3 DFN
MCP73832 Linear Li-Ion/Li-Polymer	13.7 to 6.0	4.2, 4.35, 4.4, 4.5	500 ± 0.75 Int				UVLO, Thermal regulation, Programmable charge current, Open-drain STAT pin	5-pin SCT-23, 8-pin 2 x 3 DFN
MCP73833 Linear Li-Ion/Li-Polymer	14.5 to 5.5	4.1, 4.2	500 ± 0.5 Int				USB control, Safety charge timers, Temperature monitor, Thermal regulation	16 pin 4 × 4 QFN
MCP73855 Linear Li-Ion/Li-Polymer	14.5 to 5.5	4.1, 4.2	500 ± 0.5 Int				USB control, Safety charge timers, Thermal regulation	10-pin 3 × 3 DFN
MCP73833 Linear Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2, 4.35. 4.4, 4.5	1000	+0.75	Inl	UVLO, Thermal regulation, Thermistor input, LDO Test mode, Multiple Vire outputs, Safety timer, Power good output	10-pin 3 x 3 DFN, 10 pin MSOP
MCP73834 Linear Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	UVLO, Thermal regulation, Thermistor input, LDO Test mode, Multiple Vire outputs, Safety timer, Timer enable input	10-pin 3 x 3 DFN, 10-pin MSOP
MCP73837 Linear Li-Ion/Li-Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	Dual input (USB, DC Input from adapter) auto-switching, UVLO, Thermal regulation, Thermistor input, Power good output	10 pin 3 × 3 DFN, 10 pin MSOP
MCP73838 Linear Li-Ion/Li Polymer	1	3.7 to 6.0	4.2, 4.35, 4.4, 4.5	1000	+0.75	Inl	Dual input (USB, DC Input from adapter) auto-switching, UVLO, Thermal regulation, Timer enable input	10-pin 3 x 3 DFN, 10 pin MSOP
MCP73871 Linear Li-Ion/Li-Polymer	1	3.75 to 6.0	4.1, 4.2, 4.35, 4.4	1000 (PVC Adapter, 900 (USB)	+0.5Int		Simultaneous charging of load and battery, Load-dependent charging, Multiple programmable charge currents	20-pin 4 x 4 QFN, 20-pin SSOP

POWER MANAGEMENT: Hot Swap Controllers & E-Fuse

Part #	Number of Outputs	Input Voltage Range (V)	Latch Off	Auto Retry	OVLO	UVLO	Number of Power Good	Description	Packages
MIC2065	1	+2.3 to +16.5	√	-	Adjustable	Adjustable	-	Pin-Pin equivalent to LTC18/12	16-pin QSOP
MIC2582	1	+2.3 to +13.2	√	-	-	Adjustable	-	Pin-Pin equivalent to LTC1422, dual-level fault detection	8-pin SOIC
MIC2583	1	+2.3 to +13.2	√	-	-	Adjustable	1 Active High	Dual-level fault detection, CL discharge capability	16-pin QSOP
MIC2583R	1	+2.3 to +13.2	-	√	-	Adjustable	1 Active High	Dual-level fault detection, CL discharge capability	16-pin QSOP
MIC2584	2	Ch 1: +2.3 to +13.2 Ch 2: +1.0 to +13.2	√	-	Adjustable	Adjustable	2 Active High	Output voltage tracking with dual-level fault tracking	16-pin TSSOP
MIC2587	1	+10 to -80	√	-	-	Adjustable	1 Active High/Low	Pin-pin equivalent to LTC1641-1	8-pin SOIC
MIC2587R	1	+10 to +80	-	√	-	Adjustable	1 Active High/Low	Pin pin equivalent to LTC1641-2	8-pin SOIC

POWER MANAGEMENT: Hot Swap Controllers & E-Fuse

Part #	Number of Outputs	Input Voltage Range (V)	Latch Off Auto Retry OVLO UVLO			Number of Power Good		Description Packages
MIC2588 1-19 to -80			√	-	Adjustable	Adjustable	1 Active High/Low	Pin-pin equivalent to LTC1840, LT1840A, LT4250	8-pin SOIC
MIC2594 1-19 to -80			√	-Adjustable	Adjustable 1	Active High/Low	MIC2588 with programmable UVLO hysteresis 8-pin SOIC
MIC2595 1-19 to -80			√	-	Adjustable	Adjustable	3 Active High/Low	Staggered power good provides load sequencing, programmable UVLO hysteresis	14-pin SOIC
MIC2595R 1-19 to -80				√	Adjustable	Adjustable	3 Active High/Low	Staggered power good provides load sequencing, programmable UVLO hysteresis	14-pin SOIC
LX8237	2	4.3 to 13.2	√	-	-	Fixed	-	Dual E-Fuse for 12V and 5V, Dual Power Regulators, FC Control and Current Monitoring, power disable support	24-pin 3.5 x 4.5 QFN

POWER MANAGEMENT: Power Switches

Part #	Description	USB Port Power Switch (55 mΩ)	High-Speed USB 2.0 Switch	Battery Charger Emulation Profile	8 Resistor Set Current Limits	Charging Indicator Output	Attach Detection Output	Current Measurement	Power Allocation	Interface	Packages
USB Port Power Controllers
UCS1001-1	USB Port Power Controller with Charger Emulation	1	1	9	Up to 2.4A	√	-	-	-	Discrete I/O	20-pin 4 × 4 QFN
UCS1001-2	USB Port Power Controller with Charger Emulation	1	1	9	Up to 2.4A	-	√	-	-	Discrete I/O	20-pin 4 × 4 QFN
UCS1001-3	USB Port Power Controller with Charger Emulation	1	1	9	Up to 2.4A	√	-	-	-	Discrete I/O	20-pin 4 × 4 QFN
UCS1001-4	USB Port Power Controller with Charger Emulation	1	1	9	Up to 2.4A	-	√	-	-	Discrete I/O	20-pin 4 × 4 QFN
UCS1002-1	Programmable USB Port Power Controller with Charger Emulation	1	1	9 + 1 programmable	Up to 2.4A	√	-	√	√	I/C/SMBus 20-pin 4 × 4 QFN
UCS1002-2	Programmable USB Port Power Controller with Charger Emulation	1	1	9 + 1 programmable	Up to 2.4A	√	-	√	√	I/C/SMBus	20-pin 4 × 4 QFN
UCS1003-1	Programmable USB Port Power Controller with Charger Emulation	1	1	9 + 1 programmable	Up to 3A	-	√	√	√	I/C/SMBus	20-pin 4 × 4 QFN
UCS1003-2	Programmable USB Port Power Controller with Charger Emulation	1	1	9	Up to 3A	√	-	-	-	Discrete I/O	20-pin 4 × 4 QFN
UCS1003-3	Programmable USB Port Power Controller with Charger Emulation	1	1	9	Up to 3A	-	√	-	-	Discrete I/O	20-pin 4 × 4 QFN
UCS61003	Programmable USB Port Power Controller Automotive	1	1	9 + 1 programmable	Up to 3A	-	√	√	√	I/C/SMBus	28-pin 5 × 5 QFN

POWER MANAGEMENT: Power Switches (Continued)

Current Limit USB Protection Switches

Part #

Channels

Vin Range (V)

Fixed Current Limit(Min.)

Adj. CurrentLimit (Max.)

Rps(on)(mΩ)

CurrentLimited/Latched

ReverseBlocking

Enable Logic

ULVO

ThermalProtection

FaultFlag

CurrentMeasurement

Packages

UCS2114

Dual

2.9-5.5

3.0A

3.4A

√

Active Low, Active High

√

20-pin 3 × 3 QFN

UCS2113

Dual

2.9-5.5

3.0A

3.4A

√

Active Low, Active High

√

20-pin 4 × 4 QFN

UCS2112

Dual

2.9-5.5

3.0A

3.4A

√

Active Low, Active High

√

20-pin 4 × 4 QFN

MIC2003/13

Single

2.5-5.5

500 mA, 800 mA, 1.2A

√

-5-pin SOT23, 2 × 2

MIC2004/14

Single

2.5-5.5

500 mA, 800 mA, 1.2A

√

Active High

√

-5-pin SOT23, 2 × 2

MIC2005/15

Single

2.5-5.5

500 mA, 800 mA, 1.2A

√

Active High

√

5-pin SOT23, 6-pin SOT23,2 × 2

MIC2005A

Single

2.5-5.5

500 mA

170

√

Active Low, Active High

√

-5-pin SOT23, 6-pin SOT23

MIC2009A

Single

2.5-5.5

900 mA

170

√

Active Low, Active High

√

-6-pin SOT23

MIC2009L

Single

2.5-5.5

500 mA, 800 mA, 1.2A

√

-Active Low

√

-5-pin SOT23

MIC2007/17

Single

2.5-5.5

2.0A

100

√

Active High

√

-6-pin SOT23, 2 × 2

MIC2008/18

Single

2.5-5.5

2.0A

√

Active High

√

-6-pin SOT23, 2 × 2

MIC2009/19

Single

2.5-5.5

2.0A

√

Active High

√

-8-pin SOT23, 2 × 2

MIC2025-1

Single

2.7-5.5

500 mA

140

√

Active High

√

-8-pin SOIC, 8-pin MSOP

MIC2025-2

Single

2.7-5.5

500 mA

140

√

Active Low

√

-8 pin SOIC, 8 pin MSOP

Part # Channels Vix Range (V)

Fixed Current Limit(Min.)

Adj. CurrentLimit (Max.)

Ros(on)(mΩ)

CurrentLimited/Latched

ReverseBlocking

Enable Logic ULVO

ThermalProtection

FaultFlag

CurrentMeasurement

Packages

MIC2028-1 Dual 2.7~5.5 500 mA -90

√

Active High

√

-8-pin SOIC, 8 pin PDIP

MIC2028-2 Dual 2.7~5.5 500 mA -90

√

Active Low

√

-8-pin SOIC, 8 pin PDIP

MIC2026A-1 Dual 2.7~5.5 500 mA -100

√

Active High

√

-8-pin SOIC

MIC2026A-2 Dual 2.7~5.5 500 mA -100

√

Active Low

√

-8-pin SOIC

MIC2027-1 Quad 2.7~5.5 500 mA -150

√

Active High

√

-16-pin SOIC, 16-pin WSOIC

MIC2027-2 Quad 2.7~5.5 500 mA -150

√

Active Low

√

-16-pin SOIC, 18-pin WSOIC

MIC2033 Single 2.5~5.5

475 mA, 517 mA, 760mA, 900 mA, 1.14A

-125

√

-Active Low, Active High

√

-8-pin SOT-23, 8-pin DFN*

MIC2039

Single

2.5~5.5

2.5A

√

-Active Low, Active High

√

-8-pin SOT-23, 2 x 2*

MIC2040-1

Single

0.8~5.5

1.5A

√

Active High

√

-10-pin MSOP

MIC2040-2

Single

0.8~5.5

1.5A

√

Active Low

√

-10-pin MSOP

MIC2041-1

Single

0.8~5.5

1.5A

Latched

√

Active High

√

-10-pin MSOP

MIC2041-2

Single

0.8~5.5

1.5A

Latched

√

Active Low

√

-10-pin MSOP

MIC2042-1

Single

0.8~5.5

3.0A

√

Active High

√

-8-pin SOIC, 14-pin TSSOP

MIC2042-2

Single

0.8~5.5

3.0A

√

Active Low

√

-8-pin SOIC, 14-pin TSSOP

MIC2043-1

Single

0.8~5.5

3.0A

Latched

√

Active High

√

-8-pin SOIC, 14-pin TSSOP

MIC2043-2

Single

0.8~5.5

3.0A

Latched

√

Active Low

√

-8-pin SOIC, 14-pin TSSOP

MIC2044-1

Single

0.8~5.5

6.0A

√

Active High

√

-16-pin TSSOP

MIC2044-2

Single

0.8~5.5

6.0A

√

Active Low

√

-16-pin TSSOP

*Reduced Height Package

POWER MANAGEMENT: Load Switches

Part #	Channels	Viv Range (V)	Max. Switch Current	Ros(ow) (mΩ)	Soft Start (μs)	Load Discharge (Ω)	Enable Logic	Input Pull-Up Resistor	Reverse Blocking	Packages
MIC94030	Single	2.7-13.5	1.0	750	-	-	Active Low	-	√	4-pin SOT143
MIC94040	Single	1.7-5.5	3.0	26	-	-	Active High	-	-	4-pin 1.2 × 1.2 MLF
MIC94041	Single	1.7-5.5	3.0	26	-	250	Active High	-	-	4-pin 1.2 × 1.2 MLF
MIC94042	Single	1.7-5.5	3.0	26	100	-	Active High	-	-	4-pin 1.2 × 1.2 MLF
MIC94043	Single	1.7-5.5	3.0	26	-	250	Active High	-	-	4-pin 1.2 × 1.2 MLF
MIC94044	Single	1.7-5.5	3.0	26	900	-	Active High	-	-	4-pin 1.2 × 1.2 MLF
MIC94045	Single	1.7-5.5	3.0	26	900	200	Active High	-	-	4-pin 1.2 × 1.2 MLF
MIC94050	Single	1.8-5.5	1.8	125	-	-	Active Low	-	√	4 pin SOT143
MIC94051	Single	1.8-5.5	1.8	125	-	-	Active Low	√	√	4 pin SOT143
MIC94052	Single	1.8-5.5	2.0	70	-	-	Active Low	-	-	6-pin SC70
MIC94053	Single	1.8-5.5	2.0	70	-	-	Active Low	√	-	6-pin SC70
MIC94060	Single	1.7-5.5	2.0	77	-	-	Active High	-	-	6-pin SC70, 1.2 × 1.6
MIC94061	Single	1.7-5.5	2.0	77	-	200	Active High	-	-	6 pin SC70, 1.2 × 1.6
MIC94062	Single	1.7-5.5	2.0	77	800	-	Active High	-	-	6-pin SC70, 1.2 × 1.6
MIC94063	Single	1.7-5.5	2.0	77	800	200	Active High	-	-	6-pin SC70, 1.2 × 1.6
MIC94064	Single	1.7-5.5	2.0	77	115	-	Active High	-	-	6-pin SC70, 1.2 × 1.6

POWER MANAGEMENT: Load Switches

Part #	Channels	Vin Range (V)	Max. Switch Current	Rps(ω) (mΩ)	Soft Start (μs)	Load Discharge (Ω)	Enable Logic	Input Pull-Up Resistor	Reverse Blocking	Packages
MIC94065	Single	1,7-5,5	2.0	77	115	200	Active High	-	-	8-pin SC70, 1.2 x 1.6
MIC94070	Single	1,7-5,5	1.2	120	-	-	Active High	-	-	8-pin SC70, 1.2 x 1.6
MIC94071	Single	1,7-5,5	1.2	120	-	200	Active High	-	-	8-pin SC70, 1.2 x 1.6
MIC94072	Single	1,7-5,5	1.2	120	800	-	Active High	-	-	8-pin SC70, 1.2 x 1.6
MIC94073	Single	1,7-5,5	1.2	120	800	200	Active High	-	-	8-pin SC70, 1.2 x 1.6
MIC94080	Single	1,7-5,5	2.0	67	-	-	Active High	-	-	4-pin 0.85 x 0.85 TMLF
MIC94081	Single	1,7-5,5	2.0	67	-	250	Active High	-	-	4-pin 0.85 x 0.85 TMLF
MIC94082	Single	1,7-5,5	2.0	67	800	-	Active High	-	-	4-pin 0.85 x 0.85 TMLF
MIC94083	Single	1,7-5,5	2.0	67	800	250	Active High	-	-	4-pin 0.85 x 0.85 TMLF
MIC94084	Single	1,7-5,5	2.0	67	120	-	Active High	-	-	4-pin 0.85 x 0.85 TMLF
MIC94085	Single	1,7-5,5	2.0	67	120	250	Active High	-	-	4-pin 0.85 x 0.85 TMLF
MIC94090	Single	1,7-5,5	1.2	130	-	-	Active High	-	-	8-pin SC70, 1.2 x 1.2
MIC94091	Single	1,7-5,5	1.2	130	-	250	Active High	-	-	8-pin SC70, 1.2 x 1.2
MIC94092	Single	1,7-5,5	1.2	130	790	-	Active High	-	-	8-pin SC70, 1.2 x 1.2
MIC94093	Single	1,7-5,5	1.2	130	790	250	Active High	-	-	8-pin SC70, 1.2 x 1.2
MIC94094	Single	1,7-5,5	1.2	130	120	-	Active High	-	-	8-pin SC70, 1.2 x 1.2
MIC94095	Single	1,7-5,5	1.2	130	120	250	Active High	-	-	8-pin SC70, 1.2 x 1.2
MIC94101	Single	1,7-5,5	3.0	15.5	2700	-	Active High	-	✓	1.5 x 1 WLCSP
MIC94162	Single	1,7-5,5	3.0	15.5	80	200	Active High	-	✓	1.5 x 1 WLCSP
MIC94163	Single	1,7-5,5	3.0	15.5	80	-	Active High	-	✓	1.5 x 1 WLCSP
MIC94164	Single	1,7-5,5	3.0	15.5	2700	200	Active High	-	✓	1.5 x 1 WLCSP
MIC94165	Single	1,7-5,5	3.0	15.5	2700	-	Active High	-	✓	1.5 x 1 WLCSP
MIC94112	Single	0.5-5,5	7.0	6.6	1100	2300	Active High	-	-	10-pin 1.2 x 2.0 CFN
MIC94068	Dual	1,7-5,5	2	85	-	-	Active High	-	-	8-pin 2 x 2 MLF
MIC94067	Dual	1,7-5,5	2	85	-	200	Active High	-	-	8-pin 2 x 2 MLF
MIC94068	Dual	1,7-5,5	2	85	800	-	Active High	-	-	8-pin 2 x 2 MLF
MIC94069	Dual	1,7-5,5	2	85	800	200	Active High	-	-	8-pin 2 x 2 MLF

*Reduced Height Package

POWER MANAGEMENT: Reverse Power Feed

Part #	Application	FETs	Interface	Operating Temperature	Ports	1-Pair Power
PD81000	PSE for CPE	N/A	I2C	-40 to +85	1
PD81101	PSE for CPE	Internal 0.2Ω	I2C	-40 to +85	1	21W
PD82000	PD for DPU	N/A	I2C	-40 to +85	4 to 16

DISPLAY AND LED DRIVERS

DISPLAY AND LED DRIVERS: Electroluminescent Backlight Drivers
Part # Type		Input Voltage Low (V)	Input Voltage High (V)	Nominal Output Voltage (V)	Max. Switch Resistance (Ω)	Output Regulation Max. Lamp Size per Device (in)		3) Packages
16-Segment Drivers
HV509 16-Segment Drivers 2.5±50 to ±200—6.532-pin VQFN
HV529 16-Segment Drivers 1.7 5.5x50 to ±200—6.532-pin VQFN
Offline Drivers
HV509	Offline Driver	50	200	±50 to ±200	-	-	100	8-pin SOIC, 9-pin SOIC 150 mil
Single Lamp Drivers
HV516	Single Lamp Driver	2.7	5.5	±180	-	Yes	42	18-pin QFN
IV823	Single Lamp Driver	2	9.5	±90	6	Yes	23	9-pin SOIC 150 mil
IV825	Single Lamp Driver	1	1.5	±56	15	No	3	8-pin MSOP, 9-pin SOIC 150 mil
HV830	Single Lamp Driver	2	9.5	±100	4	Yes	26	8-pin SOIC 150 mil
HV833	Single Lamp Driver	1.6	8.5	±90	4	Yes	12	8-pin MSOP
HV850	Single Inductorless Lamp Driver	3	4.2	±70	-	Yes	1.5	8-pin MSOP
HV852	Single Inductorless Lamp Driver	2.4	5	±80	-	Yes	1.5	10-pin WDFN, 8-pin MSOP
HV853	Single Inductorless Lamp Driver	3.2	5	±80	-	Yes	1.5	10-pin WDFN, 8-pin MSOP
HV857	Single Lamp Driver	1.8	5	±95	6	Yes	5	8-pin WDFN, 8-pin MSOP
IV857L	Single Lamp Driver	1.8	5	±95	6	Yes	5	8-pin WDFN, 8-pin MSOP
HV859	Single Lamp Driver	1.8	5	±105	6	Yes	5	8-pin WDFN, 8-pin MSOP
HV860	Single Lamp Driver	2.5	4.5	±110	6	Yes	5	12-pin WOFN
MIC4828	Single Lamp Driver	1.8	5.5	±80	7	Yes	3	8-pin MSOP
MIC4827	Single Lamp Driver	1.8	5.5	±90	7	Yes	3	8-pin MSOP
MIC4830	Single Lamp Driver	1.8	5.5	±90	7	Yes	4	8-pin MSOP, 8-pin VDFN
MIC4832	Single Lamp Driver	1.8	5.5	±110	7	Yes	3	8-pin MSOP, 8-pin VDFN
Dual Lamp Drivers
HV681	Dual Lamp Drivers	2.5	4.5	±90	7	Yes	5	16-pin WOFN
MIC4833	Dual Lamp Drivers	2.5	5.8	±110	12	Yes	4	12-pin VDFN

DISPLAY AND LED DRIVERS: LED Drivers
Part #	Application	Topology	Input Voltage (V)	Output Current	Dimming	Packages
Automotive (AEC-Q100 Certified) LED Drivers
AT9917	Auto	Boost, Sepic	5.3-40	External FET	PWM/Linear	24-pin TSSOP
AT9918	Auto	Buck	4.6-40	External FET	PWM	8-pin DFN
AT9932	Auto	Boost-Buck (Gk)	5.3-40	External FET	PWM/Linear	24-pin TSSOP
AT9933	Auto	Boost Buck (Gk)	9.0-75	External FET	PWM	8-pin SOIC
MAQ3203	Auto	Buck	4.5-42	External FET	PWM	8-pin SOIC

General Purpose LED Drivers
Part #	Topology	Input Voltage (V)	Dimming	Iq Typ. (mA)	Switching Frequency (Hz)	Switching MOSFET	Dithered	ILED Accuracy	Vrs (V)	Packages
HV9801A	Buck	15-450	4-Level Switch	1.0	100K	External FET	-	N/A	0.2s	16-pin SOIC 150 mil, 8-pin SOIC 150 mil
HV9803B	Buck	7-13.2	PWM/Linear	1.5	100K	External FET	-	±2%	0.26	8-pin SOIC 150 mil
HV9805	2-Stage	102-285	-	2.5	370K	0.7A FET	-	N/A	1.26	10 pin MSOP
HV98100	Buck-Boost	9.5-17.5	-	0.2	320K	External FET	-	±5%	0.2	6-pin SOT-23
HV98101	Buck-Boost	9.5-17.5	-	0.2	320K	External FET	-	±5%	0.2	8-pin SOT-23
HV9861A	Buck	15-450	PWM/Linear	1.5	100K	External FET	-	±3%	0.27	16-pin SOIC 150 mil, 8-pin SOIC 150 mil
HV99108	Buck	8-450	PWM/Linear	1.0	100K	External FET	-	±5%	0.25	16-pin SOIC 150 mil, 8-pin SOIC 150 mil
HV96001	Current Mode Boost	8-60	Extra Wide Range PWM and Analog	3.4 200 kHz		External -			0.4	16/SOIC, 16/QFN
Part #	Topology	Input Voltage (V)	Dimming	I_0 Typ. (mA)	Switching Frequency (Hz)	Switching MOSFET	Dithered	ILED Accuracy	Vs(V)	Packages
General Purpose LED Drivers (Continued)
HV9810C	Buck	15-450	PWM/ linear	1.0	100K	External FET	-	±5%	0.25	16-pin SOIC 150 mil, 8-pin SOIC 150 mil
HV9918	Buck	4.5-40	PWM	1.5	2M	0.7A FET	-	±5%	0.23	8-pin WDFN
HV9919B	Buck	4.5-40	PWM	1.5	2M	External FET	-	±5%	0.23	8-pin WDFN
HV9921	Buck	20-400	-	0.2	100K	20 mA	-	N/A	N/A	3-pin TO-92, 3-pin SOT-89
HV9922	Buck	20-400	-	0.2	100K	50 mA	-	N/A	N/A	3-pin TO-92, 3-pin SOT-89
HV9923	Buck	20-400	-	0.2	100K	30 mA	-	N/A	N/A	3-pin TO-92, 3-pin SOT-89
HV9925	Buck	20-400	PWM	0.3	100K	20-50 mA	-	N/A	0.47	8-pin SOIC
HV9930	Cuk	8-200	PWM	1.0	Variable	External FET	-	N/A	0.12	8-pin SOIC 150 mil
HV9931	Buck	8-450	PWM	1.0	100K	External FET	-	N/A	7.5	8-pin SOIC 150 mil
MIC3201	Buck	6-20	PWM	1.2	Hyst to 1.0M	1A FET	-	±5%	2	8-pin SOIC
MIC3202	Buck	6-37	PWM	1.2	Hyst to 1.0M	1A FET	0	±5%	2	8-pin SOIC
MIC3202-1	Buck	6-37	PWM	1.2	Hyst to 1.0M	1A FET	-	±5%	2	8-pin SOIC
MIC3203	Buck	4.5-42	PWM	1.0	Hyst to 1.5M	External FET	0	±5%	2	8-pin SOIC
MIC3203-1	Buck	4.5-42	PWM	1.0	Hyst to 1.5M	External FET		±5%	2	Please call for package information
MIC3205	Buck	4.5-40	PWM	1.3	Hyst to 1M	External FET	-	±5%	2	10-pin VDFN
MIC3230	Boost	6-45	PWM	3.2	100K-1.0M	External FET	-	±5%	0.25	16-pin TSSOP, 12-pin VDFN
MIC3231	Boost	6-45	PWM	3.2	100K-1.0M	External FET	0	±5%	0.25	16-pin TSSOP, 12-pin VDFN
MIC3232	Boost	6-45	PWM	3.2	400K	External FET		±5%	0.25	10-pin MSOP

Backlight LED Drivers

Part #	Topology	Input Voltage (V)	Dimming	I_q Typ. (mA)	Output Current	Int. Diode	V_is ( V)	Frequency	Packages
HV9803	Buck	7-13.2	PWM/Linear	1.5	External FET	N/A	0.8	100K	8-pin SOIC 150 mil
HV9911	Boost, SEPIC, Buck-Boost	9-250	PWM /Linear	N/A	External FET	N/A	0.45	100K	16-pin SOIC 150 mil
HV9912	Boost, SEPIC, Buck-Boost	9 100	PWM/Linear	N/A	External FET	N/A	0.45	100K	16-pin SOIC 150 mil
HV9961	Buck	8-450	PWM/Linear	3.5	External FET	N/A	0.27	100K	8-pin SOIC 150 mil, 16-pin SOIC 150mil
HV9963	Boost, SEPIC, Buck-Boost	8-40	PWM/Linear	N/A	External FET	N/A	N/A	100K	16-pin SOIC 150 mil
HV9967B	Buck	8-60	PWM/Linear	N/A	1A FET	N/A	0.24	100K	8-pin MSOP, 8-pin WDFN
HV9980	Buck	100-160	PWM/Linear	3.0	0.07A FET	N/A	N/A	500K	24-pin SOIC 300 mil
HV9985	Boost, SEPIC, Buck	10-40	PWM/Linear	1.5	External FET	N/A	N/A	500K	40-pin VQTN
MIC2282	Boost	0.9-15	N/A	0.12	1A BJT	N/A	0.22	20K	8-pin MSOP
MIC2287	Boost	2.5-10	PWM/Analog	2.5	2A BJT	N/A	0.095	1.2M	5-pin TSOT, 8-pin VDFN
MIC2287C	Boost	2.5-10	PWM/Analog	2.5	2A BJT	N/A	0.095	1.2M	5-pin TSOT, 8-pin VDFN
MIC2289	Boost	2.5-10	PWM/Analog	2.5	2A BJT	Yes	0.095	1.2M	6-pin TSOT, 8-pin VDFN
MIC2289C	Boost	2.5-10	PWM/Analog	2.5	2A BJT	Yes	0.095	1.2M	6-pin TSOT
MIC2291	Boost	2.5-10	PWM/Analog	2.8	2A BJT	N/A	0.095	1.2M	5-pin TSOT, 8-pin VDFN
MIC2292	Boost	2.5-10	PWM/Analog	2.5	2A BJT	Yes	0.095	1.6M	8-pin VDFN
MIC2292C	Boost	2.5-10	PWM/Analog	2.5	2A BJT	Yes	0.095	1.6M	8-pin VDFN
MIC2293	Boost	2.5-10	PWM/Analog	2.5	2A BJT	Yes	0.095	2.0M	8-pin VDFN
MIC2293C	Boost	2.5-10	PWM/Analog	2.5	2A BJT	Yes	0.095	2.0M	8-pin VDFN
MIC2297	Boost	2.5-10	PWM/Analog	4	3A BJT	N/A	0.2	600K	10-pin VDFN
MIC2298	Boost	2.5-10	PWM/Analog	15	6A BJT	N/A	0.2	1.0M	12-pin VDFN
MIC2298	Boost	2.5-10	PWM/Analog	15	8A BJT	N/A	0.2	2.0M	12-pin VDFN
MIC3223	Boost	4.5-20	PWM	2.1	10A FET	N/A	0.2	1.0M	16-pin TSOP
MIC3263	Boost	6-40	PWM	6.5	2A BJT	N/A	2.36	400K-1.8M	24-pin VQTN
MIC3287	Boost	2.8-6.5	PWM/Analog	2.1	1A BJT	N/A	0.25	1.2M	5-pin TSOT, 6-pin TSOT, 8-pin VDFN
MIC3289	Boost	2.5-6.5	1-Wire	1.4	2A BJT	Yes	0.25	1.2M	6-pin TSOT, 8-pin VDFN

DISPLAY AND LED DRIVERS: LED Drivers (Continued)

Part #	Input Voltage (V)	# of White LEDs	Dimming	Io Typ. (mA)	V Dropout LED @ 20 mA	ILED Matching	Ext. LDOs	Vonorout	IQLDO	Comments	Packages
Linear LED Drivers
MIC2841A	3-5.5	4 @ 20 mA	PWM (200 Hz~500 kHz)	1.4	40 mV	±1.5%	-	-	-	DAMTM	10-pin UDFN
MIC2842A	3-5.5	4 @ 20 mA	1-Wire, 46-Steps	1.4	40 mV	±1.5%	-	-	-	DAM	10-pin UDFN
MIC2843A	3-5.5	6 @ 20 mA	PWM (200 Hz~500 kHz)	1.4	40 mV	±1.5%	-	-	-	DAM	10-pin UDFN
MIC2844A	3-5.5	6 @ 20 mA	1-Wire, 46-Steps	1.4	40 mV	±1.5%	-	-	-	DAM	10-pin UDFN
MIC2848A	3-5.5	6 @ 20 mA	1-Wire, 46-Steps	1.4	40 mV	±1.5%	2	150	35	DAM	14-pin VQFN
MIC2860-2D	3-5.5	2 @ 30.2 mA	1-Wire, 32-Steps	0.7	52 mV	±0.5%	-	-	-		6-pin SC70, 8-pin SOT-23
MIC2860-2P	3-5.5	2 @ 30.2 mA	PWM down to 250Hz	0.7	52 mV	±0.5%	-	-	-		6-pin SC70, 8-pin SOT-23
MIC4811	3-5.5	8 @ 50 mA	PWM (200 Hz~500 kHz)	1.7	100 mV @ 50 mA	±1.0%	-	-	-	DAM	10-pin MSOP
MIC4812	3-5.5	6 @ 100 mA	PWM (200 Hz~500 kHz)	3.2	190 mV @ 100 mA	±1.0%	-	-	-	DAM	10-pin eMSOP
MIC4801	3-5.5	1 @ 800 mA	PWM (200 Hz~500 kHz)	2.2	150 mV @ 400 mA	N/A	-	-	-	±1% Accuracy	8-pin SOIC
MIC4802	3-5.5	1 @ 800 mA	PWM (200 Hz~500 kHz)	4.1	260 mV @ 600 mA	N/A	-	-	-	±1% Accuracy	8-pin eSOIC

Linear Regulators

Part #	Input Voltage (V)	Output Voltage (V)	Output Current (mA)	Dimming	Parallelable	Packages	Features
CL2	5.0-90	5.0-90	20	External FET	Yes	3-pin TO-252, 3-pin TO-92, 3-pin SOT-89	-
CL25	5.0-90	5.0-90	25	External FET	Yes	3-pin TO-92, 3-pin SOT-89	-
CL220	5.0-220	5.0-220	20	External FET	Yes	3-pin TO-252, 3-pin TO-220	-
CL320	6.5-90	4.0-90	20	PWM	Yes	8-bit SOIC with Heat Slug	OTP, separate ENABLE pin
CL325	6.5-90	4.0-90	25	PWM	Yes	8-bit SOIC with Heat Slug	OTP, separate ENABLE pin
CL330	6.5-90	4.0-90	30	PWM	Yes	8-bit SOIC with Heat Slug	OTP, separate ENABLE pin
CL520	4.75-90	1.0-90	20	-	Yes	3-pin TO-252, 3-pin TO-92	-
CL525	4.75-90	1.0-90	25	-	Yes	3-pin TO-252, 3-pin TO-92	-
CL8	6.5-90	4.0-90	100	No	Yes	3-pin TO-252, 3-pin TO-220	Reverse polarity protection, OTP
CL7	6.5-90	4.0-90	100	PWM	Yes	8-pin SOIC with Heat Slug	Reverse polarity protection, OTP

Display LED Drivers

Part #	Input Voltage (V)	Sink Current (mA)	Segments	LEDs	Description	Packages
MIC5400	4.75-5.5	30	N/A	2 banks of B	Driving Large LED Array In Signs	28-pin SOIC
MM5450	4.75-11	15	34	N/A	7-Segment LED Driver with EN	40-pin PDIP, 44-pin PLCC
MM5451	4.75-11	15	35	N/A	7-Segment LED Driver	40-pin PDIP, 44-pin PLCC

Sequential Linear LED Drivers

Part #	Vin (V)	Vout (V)	Output Current (mA)	Dimming	Parallelable	Features	Packages
CL9800	90-275	70-350	115	External Dimmer	Yes	6-Stage	33-pin QFN
CL9801	90-275	70-350	200	External Dimmer	Yes	4-Stage	33-pin QFN
CL98020	90-135	70-190	115	External Dimmer	Yes	4-Tap	8-pin SOIC EP
CL88030	90	320	N/A	External	Yes	4-Tap, ALR, OTP, Icur FET Dependent	10-Id QFN (3 mm x 3 mm)
CL88031	90	320	N/A	External	Yes	6-Tap, ALR, OTP, Icur FET Dependent	10-Id QFN (3 mm x 3 mm)

Camera Flash LED Drivers

Part #	Input Voltage (V)	# of LED Channels	Max. LED Current (mA)	Standby Current (mA)	Switch Frequency (MHz)	Peak Efficiency (%)	Current Accuracy (%)	Interface	Packages
MIC2870	2,7-5	2	1500	0.90	2	94	+10	IC	16-pin TOFN
MIC2871	2,7-5,5	1	1200	0.23	2	94	± 5	Single Wire	14 pin LDFN
MIC2873	2,7-5,5	1	1200	0.17	2	92	± 6	Single Wire	9 pin WLCSP
MIC2874	2,7-5,5	1	1200	0.17	4	92	± 8	Single-Wire	9-pin WLCSP

HIGH-VOLTAGE INTERFACE

HIGH-VOLTAGE INTERFACE: Driver Arrays
Part #	Output Channels	Vour Operating (V) Transient	Vour Operating (V) Sustained	Input Structure	Description
Sink
HV5122 32 250 225 Serial Serial to parallel converter with output enable and strobe
HV5222 32 250 225 Serial Serial to parallel converter with output enable and strobe
HV5622 32 230 220 Serial Serial to parallel converter with latches, polarity, and clanking
HV5628 32 230 220 Serial Serial to parallel converter with latches, polarity, and clanking
HV5530 32 315300Serial Serial to parallel converter with latches, polarity, and blanking
HV5622 32 230 220 Serial Serial to parallel converter with latches, polarity, and clanking
HV5628 32 250 220 Serial Serial to parallel converter with latches, polarity, and clanking
HV5630 32 315300Serial Serial to parallel converter with latches, polarity, and blanking
MIC5800	4	90	80	Parallel	4.4 MHz (min.) Data at 5V, Higher at 12V, TTL/CMOS/PMOS Logic; Integrated clamp diodes; CLR/Strobe/Enable Out
MIC5801	8	50	50	Parallel	4.4 MHz (min.) Data at 5V, Higher at 12V, TTL/CMOS/PMOS Logic; Integrated clamp diodes; CLR/Strobe/Enable Out
MIC5821 8 5035Serial Similar to MIC5801, Adds thermal Shutdown, UVLO, OCP
MIC5822	8	80	50	Serial	8-bit SRs (Cascacable), Operable with split supply (to -20V), 3.3 MHz (min.) Data at 6V, TTL/CMOS/PMOS/NMOS Logic
MIC5841	8	50	35	Serial	8-bit SRs (Cascacable), Operable with split supply (to -20V), 3.3 MHz (min.) Data at 6V, Higher at 12V, TTL/CMOS/PMOS/NMOS Logic
MIC5842 8 80 50Serial					8-bit SRs (Cascacable), Operable with split supply (to -20V), 3.3 MHz (min.) Data at 5V, Higher at 12V, Low Power Logic; TTL/CMOS/PMOS/NMOS; Internal Pull Up/Down Res's
MIC58P01 8 80 80 Parallel					8-bit SRs (Cascacable), Operable w/Split Supply (to -20V), 3.3 MHz (min.) Data at 6V, Higher at 12V, Low Power Logic; TTL/CMOS/PMOS/NMOS; Internal Pull Up/Down Res's
MIC58P42 8 80 50Serial Similar to MIC5842, adds thermal shutdown, UVLO, OCP
MIC58P50 8 80 80 Parallel Similar to MIC58P01, with added error flag output
MIC58P60 8 80 50Serial Similar to MIC58P12, with added error flag output
Source
HV57009	64	95	85	Serial	Current controlled driver with latches and blanking, two 32-bit shift registers
MIC2981/82	8	50	35	Parallel	8-Ch. driver with parallel I/Os; TTL/CMOS/PMOS Logic; Integrated clamp diodes; VwC-12V
MIC5891	8	50	35	Serial	8-bit SRs (Cascacable), Operable with split supply (to -20V), 5 MHz (min.) Data at 5V, Integrated clamp diodes; TTL/CMOS/PMOS/NMOS Logic; Strobe and output enable
Source-Sink
HV5416 64200 180 Serial Serial to parallel converter with latches, polarity, and blanking
HV507	64	320	300	Serial	Serial to parallel converter with latches, polarity, and blanking
HV508	2	60	45	Parallel	H-Bridge output with two output voltage level selections and polarity. Specialty targeted as LCD shutter driver
HV513	8	275	250	Serial	Serial to parallel converter with latches, polarity, and blanking Hi-Z and short circuit dotct
HV518	32	80	60	Serial	Serial to parallel converter with latches, oracle, and strobe; Specially targeted as vacuum fluorescent display drive
HV5308 82	90 80 Serial Serial to parallel converter with latches, and output enable
HV5408 82	90 80 Serial Serial to parallel converter with latches, and output enable
HV574	80	80	80	Serial	Serial to parallel converter with latches, polarity and blanking
HV57708	64	80	80	Serial	Polarity, and blanking with four 16-bit shift registers
HV57908	64	80	80	Serial	Latches, blanking, polarity, and single shift register
HV5812 20	90 80 Serial Serial to parallel converter with latches, blanking and strobe
HV582	96	85	80	Serial	96-Channel, with high-voltage CMOS Outputs, 80V
HV589	128 90 80 Serial 128 Channel, with high voltage CMOS Outputs, 80V
HV66	32	70	60	Serial	Serial to parallel converter with latches, polarity and blanking
HV6810	10	90	80	Serial	Serial to parallel converter with data latches and channel polarity select
HV7022	34	250	250	Serial	Serial to parallel converter with direction, oracle, and polary select; particularly useful for ACTFEL displays
HV7224 40260 240 Serial Serial to parallel converter with latches, and output enable
HV7620 32 225 200 Serial Serial to parallel converter with latches, channel polarity select, and blanking
HV9308	32	90	80	Serial	Serial to parallel converter latches and output enable, CW directional shift
HV9408	32	80	80	Serial	Serial to parallel converter latches and output enable; COW directional shift
HV9808	32	90	80	Serial	Serial to parallel converter latches, polarity, and output enable; CCW directional shift

HIGH-VOLTAGE INTERFACE: Amplifiers and MEMS Drivers

Part #	Output Channels	Slew Rate (V/μs)	Closed Loop Gain (V/V)	Feedback Resistance (MΩ)	Source Current (Max. μA)	Sink Current (Max. μA)	Output Capacitive Load (Max. pF)	Packages
HV254	32	3	50	12	300	300	100	100-pin MOFP
HV256	32	2	72	12	715	715	3000	100-pin MOFP
HV257	32	2	72	12	500	500	3000	100 pin MOFP
HV264	4	8	66.7	5.3	3000	3000	15	24 pin TSSOP
HV265	4	0.02	82	4.9	3000	300	200	TSSOP-24
HV56022	2	0.2	75	1.9	96000	167000	N/A	20-Ld. 4 mm x 4 mm VQFN
HV56020	2	0.2	75	1.9	96000	167000	N/A	43-Ld. 7 mm x 7 mm VQFN

HIGH-VOLTAGE INTERFACE: MOSFETs - Interface

Part #	BVosx Min. (V)	Ros(ov) Max. (Ω)	Vos(off) Min. (V)	Vos(off) Max. (V)	Packages
Depletion-Mode N-Channel
LND01	9	1.4	-0.8	-3	5-pin SOT-23
DN1509	90	6	-1.8	-3.5	2-pin SOT-B9, 5-pin SOT-23
DN2625	250	3.5	-1.5	-2.1	8-pin VDFN, 3-pin DPAK
DN3525	250	6	-1.6	-3.5	3-pin SOT-B9
DN2530	300	12	-1	-3.5	3-pin TO-92, 3-pin SOT-B9
DN3535	350	10	-1.5	-3.5	3-pin SOT-B9
DN2635	350	26	-1.5	-3.5	3-pin TO-92, 3-pin TO-220
DN3135	350	35	-1.5	-3.5	3-pin SOT-B9, 3-pin SOT-23
DN2540	400	25	-1.5	-3.5	3-pin TO-92, 3-pin SOT-B9, 3-pin TO-220
DN3545	450	20	-1.5	-3.5	3-pin TO-92, 3-pin SOT-B9
DN3145	450	60	-1.5	-3.5	3-pin SOT-B9
DN2450	500	10	-1.5	-3.5	3-pin DPAK, 3-pin SOT-B9
LND150	500	1000	-1	-3	3-pin TO-B2, 3-pin SOT-B9, 3-pin SOT-23
LND250	500	1000	-1	-3	3-pin SOT-23
DN3785	650	8	-1.5	-3.5	3-pin DPAK
DN2470	700	42	-1.5	-3.5	3-pin DPAK

Enhancement-Mode N-Channel

Part #	BVnss Min. (V)	Ros(ov) Max. (Ω)	Ciss Max. (pF)	Vcs(m) Max. (V)	Packages
TN2501	16	2.5	110	1.0	3-pin SOT-89
TN2702	20	1.3	200	1.0	3-pin TO-82
VN0300	30	1.2	190	2.5	3-pin TO-82
TN2604	40	0.8	150	1.6	3-pin TO-82
TN2504	40	1.0	125	1.6	3-pin SOT-89
TN0104	40	2.0	70	1.6	3-pin TO-82, 3-pin SOT-89
VN0104	43	3.0	65	2.4	3-pin TO-82
VN3205	50	0.3	300	2.4	3-pin TO-82, 3-pin SOT-89
TN2608	60	1.5	150	2.0	3 pin TO-82
TN2106	60	2.5	50	2.0	3-pin TO-82, 3-pin SOT-83
2N8663	60	3.0	50	2.0	3-pin TO-39
TN2106	60	3.0	50	2.0	3-pin TO-82
VN0106	60	3.0	65	2.4	3-pin TO-82
VN0606	60	3.0	50	2.0	3-pin TO-82
VN2106	60	4.0	50	2.4	3-pin TO-82
2N7000	60	5.0	60	3.0	3-pin TO-82
2N7002	60	7.5	50	2.5	3-pin SOT-83
2N7008	60	7.5	50	2.5	3-pin TO-82
VN2221	80	7.5	60	2.5	3-pin TO-82
Part #	BVoss Min. (V)	Ros(ov) Max. (Ω)	Ciss Max. (pF)	Vss(n+) Max. (V)	Packages
Enhancement-Mode N-Channel (Continued)
VN0806 80 4.0502.0 3-pin TO-92
VN0109 90 3.0652.4 3 pin TO-92
2N6661 30 4.0502.0 3 pin TO-99
VN2210 1000.45002.4 3-pin TO-92, 3-pin TO-99
TNC61001.51502.0 3 pin TO-92
TN2510 1001 5125 2.0 3-pin SOT-88
TNC11003.0602.0 3-pin TO-92
VN2110 1004.0502.4 3-pin SOT-23
VN1206 120 6.0125 2.0 3-pin TO-92
TNC620 200 6.01501.69 pin TO-82
VN2224 240 1.33x03.03-pin TO-92
TNPs24 240 6.0125 2.0 3-pin SOT-89
VN2406 240 6.0125 2.0 3 pin TO-92
VN2410 240 10.0125 2.0 3-pin TO-82
TN2124 240 15.0502.0 3-pin SOT-23
TN2425 250 3.5200 2.0 3-pin SOT-89
TN5325 250 7.0 1102.0 3 pin TO-92, 3 pin SOT-89, 3 pin SOT-23
TN2130 30025.0 502.4 3 pin SOT-23
TNP435 3x08.0200 0.8 (min)	3-pin SOT-89
TN53535C15.01102.0 3 pin SOT-89, 3 pin SOT-23
TN2640 4005.0225 2.0 3 pin DPAK, 3 pin TO-92, 8 pin SOIC 150 ml
TN2540 40012.0 125 2.0 3-pin TO-92, 3-pin SOT-89
VN4012 40012.0 1101.8 3-pin TO-92
VN2450 50013.01501.03-pin TO-82, 3-pin SOT-88
VN0550 50060.0554.03-pin TO-92
VN2460 60020.0 1504.03-pin TO-92, 3 pin SOT-88
Enhancement-Mode P-Channel
LP0701	-16.5	1.5	250	-1.0	3-pin TO-92, 5-pin SOIC 150 mil
TP5622	-20 2.0 125	-2.4	3-pin SOT-89
VP3203	-30	0.6	300	-3.5	3-pin TO-92, 3-pin SOT-99
TP0924	-40	2.0	150	-2.4	3-pin TO-92
TP2104	-40	6.0	60	2.0	3-pin TO-92, 3-pin SOT-23
VP0104	-40	8.0	60	-3.5	3-pin TO-92
VP2206	-60	0.9	450	-3.5	3-pin TO-92, 3-pin TO-38
VP0106	-60	8.0	60	-3.5	3-pin TO-92
VP2106	-60	12.0	60	-3.5	3-pin TO-92
VP0808	-80	5.0	1x0	-4.5	3-pin TO-92
VP0109	-90	8.0	80	-3.5	3-pin TO-92
TP2510	-100	3.5	125	-2.4	3-pin SOT-88
VP2110	-100	12.0	60	-3.5	3-pin SOT-23
TP0620	-200	12.0	150	-2.4	3-pin TO-92
TP2520	-200	12.0	125	-2.0	3-pin SOT-88
TP2522	-220	12.0	125	-2.4	3-pin SOT-88
TPs322	-220	12.0	110	-2.4	3-pin SOT-88, 3-pin SOT-23
TP2424	-240	8.0	200	-2.4	3-pin SOT-88
TP2435	-350	15.0	200	-2.4	3-pin SOT-88
Part #	BVoss Min. (V)	Rds(on) Max. (Ω)	Ciss Typ. (pF)	Vos(th) Max. (V)	Packages
Enhancement-Mode P-Channel (Continued)
TP2635 - 350 15.0300 - 2.0 3-pin TO-92
TP2535 -350 25.0 125 -2.4 3-pin TO-82
TP5335 -350 30.0110 - 2.4 3-pin SOT-23
TP2640 -400 15.0300 - 2.0 3-pin TO-92, 8-pin SOIC 150 ml
TP2540 -400 25.0 125 -2.4 3-pin TO-82, 3-pin SOT-89
VP2450 -500 30.0130 -3.5 3 pin TO-92, 3-pin SOT-89
VP0550 -500 125.0 70 -1.5 3-pin TO-62
N-Channel (Enhancement-Mode MOSFET Arrays)
TD8944 240 6	8s2	8-pin SOIC
TN2501	18	2.5	110	1.0	3-pin SOT-89
TN0702	20	1.3	200	1.0	3-pin TO-92
VN0300	30	1.2	190	2.5	3-pin TO-92
TN0604	40	0.8	190	1.6	3-pin TO-82
TN2504	40	1.0	125	1.6	3-pin SOT-89
TN5104	40	2.0	70	1.6	3-pin TO-92, 3-pin SOT-89
VN0104	40	3.0	65	2.4	3-pin TO-82
VN3205	50	0.3	300	2.4	3-pin TO-92, 3-pin SOT-89
TN0608	60	1.5	150	2.0	3-pin TO-82
TN2106	60	2.5	50	2.0	3-pin TO-92, 3-pin SOT-23
2N8660	60	3.0	50	2.0	3-pin TO-39
TN0108	60	3.0	80	2.0	3-pin TO-92
VN0108	60	3.0	65	2.4	3-pin TO-92
VN0806	60	3.0	50	2.0	3-pin TO-92
VN2106	60	4.0	50	2.4	3-pin TO-92
2N7000	60	5.0	60	3.0	3-pin TO-92
2N7002	60	7.5	50	2.5	3-pin SOT-23
2N7008	60	7.5	50	2.5	3-pin TO-92
VN2222L	60	7.5	80	2.5	3-pin TO-92
VN0808	80	4.0	50	2.0	3-pin TO-92
VN0109	90	3.0	65	2.4	3-pin TO-92
2N6661	90	4.0	50	2.0	3-pin TO-39
VN2210	100	0.4	500	2.4	3-pin TO-92, 3-pin TO-39

Complimentary (Enhancement-Mode MOSFET Arrays)

Part #	BVoss N-Channel (V)	BVoss P-Channel (V)	Rosa(on) N-Channel Max. (Ω)	Rosa(on) P-Channel Max. (Ω)	Vos(n+) Max. (V)	Details	Packages
TC1650	500	-500	60.0	125.0	4.0	N- and P-Channel Pair	8-pin SOIC
TC2320	200	-200	7.0	12.0	2.0	N- and P-Channel Pair	8-pin SOIC
TC6215	150	-150	4.0	7.0	2.0	N- and P-Channel Pair	8-pin SOIC
TC6320	200	-200	7.0	8.0	2.0	N- and P-Channel Pair	8-pin SOIC, 8-lead VDFN (4 x 4 mm)
TC6321	200	-200	7.0	8.0	2.0	N- and P-Channel Pair	8-lead VDFN (8 x 5 mm)
TC7920	200	-200	7.0	8.0	2.0	2 N- and P-Channel Pairs	12-pin VDFN
TC8020	200	-200	8.0	9.5	3.0	6 N- and P-Channel Pairs	56-pin VDFN
TC8220	200	-200	6.3	6.5	2.0	2 N- and P-Channel Pairs	12-pin VDFN

HIGH-VOLTAGE INTERFACE: Application Specific

Part # DC/DC

Input Voltage Min. (V)

Input Voltage Max. (V)

Output Voltage Min. (VRMS)

Output Voltage Max. (VRMS)

Load Min. (pF) Load Max. (pF) Packages

Liquid Lens Driver
HV692 Internal Charge Pump 2.65 5.51080100200 10-pin WDFN

Complimentary MOSFET Level Translator and Driver

Part #	# of Channels	Input Voltage Low (V)	Input Voltage High (V)	Output Voltage Low (V)	Output Voltage High (V)	Input to Output Isolation (V)	Packages
HT0440	2	3.15	5.5	6	10	± 400	10-pin VD TN, 8-pin SOIC 150 mil
HT0740	1	3.15	5.5	4.5	8.5	+400	8-pin SOIC 150 mil

High-Side Current Monitor

Part #	Vin (V)	Gain	Rise and Fall Time (μs)	VSENSE Max. (mV)	Quiescent Current Max. (μA)	Packages
HV7800	8.0-150	Fixed, 1	0.7-2.0	500	50	5-pin SOT-23
HV7801	8.0-450	Fixed, 5	0.7-2.0	500	50	5-pin SOT-23
HV7802	8.0-450	Adjustable	0.7-1.4	500	50	8-pin MSOP

Fault Protection

Part #	Voltage (V)	# of Channels	Ron (Ω)	Voff (V)	Packages
FP0100	100	1	4.5	4.5	3-pin SOT-89

Relay Driver and Controller

Part #

Vin Min. (V)

Vin Max. (V)

In Max. (mA)

Oscillator Frequency Min. (kHz)

Oscillator Frequency Max. (kHz)

Oscillator Frequency fvsNC Min. (kHz)

Max Output Duty Cycle (%)

Typical Current Sense Pull-In (V)

Typical Current Sense Hold

External Adjustable Regulator Output Voltage (V)

External Adjustable Regulator Output Current (mA)

Packages

HV9901

450

140

150

89.6

0.883

Adjustable

2.0-5.5

0-1.0

14 pin SOIC

LINEAR

LINEAR: Op Amps

Part #	# Per Package	GBWP	Io Typical (μA)	Vos Max (mV)	Typical Input Bias Current (pA)	Input Voltage Noise Density (nV/rHz)	Operating Voltage (V)	Temperature Range (°C)	Features	Packages
MCP6441	1	9 kHz	0.45	4.5	1	190^th	1.8 to 8.0	-40 to +125	Fail-to-Rail Input/Output	5-pin SOT-23a, 5-pin SOC-70a,b
MCP6442	2	9 kHz	0.45	4.5	1	190^th	1.8 to 8.0	-40 to +125	Fail-to-Rail Input/Output	8-pin SOIC, 8-pin MSOP, 8-pin 2 × 3 TDFN
MCP6444	4	9 kHz	0.45	4.5	1	190^th	1.8 to 8.0	-40 to +125	Fail to Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MCP6031	1	10 kHz	0.9	0.15	1	165^th	1.8 to 5.5	-40 to +125	Fail to Rail Input/Output	8-pin SOIC, 8 pin MSOP, 8 pin 2 × 3 DFN, 5 pin SOT-23
MCP6032	2	10 kHz	0.9	0.15	1	165^th	1.8 to 5.5	-40 to +125	Fail-to-Rail Input/Output	8-pin SOIC, 8-pin MSOP
MCP6033	1	10 kHz	0.9	0.15	1	165^th	1.8 to 5.5	-40 to +125	Fail-to-Rail Input/Output. Chip select	8-pin SOIC, 8-pin MSOP, 8-pin 2 × 3 DFN
MCP6034	4	10 kHz	0.9	0.15	1	165^th	1.8 to 5.5	-40 to +125	Fail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MCP6041	1	14 kHz	0.6	3	1	170^th	1.4 to 8.0	-40 to +125	Fail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 5-pin SOT-23a
MCP6042	2	14 kHz	0.6	3	1	170^th	1.4 to 8.0	-40 to +125	Fail to Rail Input/Output	8-pin PDIP, 8 pin SOIC, 8 pin MSOP
MCP6043	1	14 kHz	0.6	3	1	170^th	1.4 to 8.0	-40 to +125	Fail to Rail Input/Output. Chip select	8 pin PDIP, 8 pin SOIC, 8 pin MSOP, 6 pin SOT-23a
MCP6044	4	14 kHz	0.6	3	1	170^th	1.4 to 8.0	-40 to +125	Fail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MIC7111	1	25 kHz	20	7	1	110	1.8 to 11	-40 to -85	Fail-to-Rail Input/Output	5-pin SOT-23

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout
Note 1: Values are typical at 1 kHz 2: Values are typical at 10 kHz

LINEAR: Op Amps (Continued)

Part #	# Per Package	GBWP	Io Typical (μA)	Vos Max (mV)	Typical Input Bias Current (pA)	Input Voltage Noise Density (nV/rtHz)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP6421	190 kHz 4.41195					38	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EM Rejection	5-pin SOT-23a, 5-pin SC-70a
MCP6422	2.90 kHz 4.41195					38	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EM Rejection	8-pin SOIC, 8-pin MSOP
MCP6424	490 kHz 4.41195					38	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EM Rejection	14-pin SOIC, 14-pin TSSOP
MCP6141	1100 kHz 0.631170					38	1.4 to 6.0 -40 to +125	Rail-to-Rail Input/Output, G >10 stable	5-pin SOT-23	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6142	2.100 kHz 0.631170					38	1.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output, G >10 stable	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6143	1100 kHz 0.631170					38	1.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output, G >10 stable, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 6-pin SOT-23a
MCP6144	4100 kHz 0.631170					38	1.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output, G >10 stable	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP606	1	155 kHz	19	0.25	1	38	2.5 to 6.0	-40 to +85	Rail-to-Rail Output	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP, 5-pin SOT23a
MCP607	2	155 kHz	19	0.25	1	38	2.5 to 6.0	-40 to +85	Rail-to-Rail Output	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP
MCP608	1	155 kHz	19	0.25	1	38	2.5 to 6.0	-40 to +85	Rail-to-Rail Output, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP
MCP609	4	155 kHz	19	0.25	1	38	2.5 to 6.0	-40 to +85	Rail-to-Rail Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP616	1	190 kHz	19	0.15	15000	32	2.3 to 5.5	-40 to +85	Rail-to-Rail Output, PNP input	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP617	2	190 kHz	19	0.15	15000	32	2.3 to 5.5	-40 to +85	Rail-to-Rail Output, PNP input	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP618	1	190 kHz	19	0.15	15000	32	2.3 to 5.5	-40 to +85	Rail-to-Rail Output, Chip select, PNP input	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP619	4	190 kHz	19	0.15	15000	32	2.3 to 5.5	-40 to +85	Rail-to-Rail Output, PNP input	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6231	1	300 kHz	20	5	1	52	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output		8 pin PDIP, 8 pin SOIC, 8 pin MSOP, 8 pin 2 x 3 TDFN, 5 pin SC-704, 5 pin SOT-23a
MCP6232	2	300 kHz	20	5	1	52	1.8 to 6.0	-40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 TDFN
MCP6234	4	300 kHz	20	5	1	52	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6051	1	385 kHz	30	0.15	1	34	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8 pin 2 x 3 DFN, 5 pin SOT-23G
MCP6052	2	385 kHz	30	0.15	1	34	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8 pin 2 x 3 DFN
MCP6064	4	385 kHz	30	0.15	1	34	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MIC861	1	400 kHz	4.6	10	20	-	2.43 to 5.25	-40 to +85	Rail-to-Rail Output	5-pin SC-70
MIC863	2	450 kHz	4.2	6.0	10	-	2.0 to 5.25	-40 to +85	Rail-to-Rail Output	8-pin SOT-23
LMC7101	1	500 kHz	6.0	6	1	37	2.7 to 12	-40 to +85	Rail-to-Rail Input/Output	5-pin SOT-23
MIC7300	1	500 kHz	1000	9	0.5	37	2.2 to 10	-40 to +85	Rail-to-Rail Input/Output, High Output Drive	5 pin SOT-23, 8 pin MSOP
MCP6241	1	550 kHz	50	5	1	45	1.6 to 5.5 -40 to +125	Rail-to-Rail Input/Output		8 pin PDIP, 8 pin SOIC, 8 pin MSOP, 8 pin 2 x 3 TDFN, 5 pin SC-704, 5 pin SOT-23a
MCP6242	2.350 kHz	60	6145			38	1.8 to 5.5 -40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6244	4	550 kHz	50	5	1	45	1.8 to 5.5 -40 to +125	Rail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6061	1	730 kHz	60	0.15	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8 pin SOIC, 8 pin 2 x 3 DFN, 5 pin SOT-23
MCP6062	2	730 kHz	60	0.15	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8 pin SOIC, 8 pin 2 x 3 DFN
MCP6064	4	730 kHz	60	0.15	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MIC7122	2	750 kHz	800	9	1	37	2.2 to 15	-40 to +85	Rail-to-Rail Input/Output
MCP6001	1	1 MHz	100	4.5	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	5-pin SOT-23	6 pin, 5-pin SC-70a
MCP6002	2	1 MHz	100	4.5	1	28	1.8 to 6.0	-40 to +125	Rail-to-Rail Input/Output
MCP6004	4	1 MHz	100	4.5	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	14 pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6007	2	1 MHz	70	1.6	1	25	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	8-pin SOIC, 8-pin MSOP
MCP6009	4	1 MHz	70	1.6	1	25	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin SOIC, 14-pin TSSOP
MCP6401	1	1 MHz	45	4.5	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	5 pin SOT-23	6 pin, 5 pin SC-70a
MCP6402	2	1 MHz	45	4.5	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8 pin SOIC, 8 pin 2 x 3 TDFN
MCP6404	4	1 MHz	45	4.5	1	28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MCP6411	1	1 MHz	47	1	1	38	1.7 to 5.5 -40 to +125		5 pin SOT-23a, 5 pin SC-70a
MCP6L01	1	1 MHz	85	5	2	24a	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	5 pin SOT-23	6 pin, 5 pin SC-70a
MCP6L02	2.1 MHz	85	52 24			28	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8-pin MSOP
MCP6L04	4	1 MHz	85	5	2	24a	1.8 to 6.0 -40 to +125	Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
Part #	# per Package	GBWP	Io Typical (μA)	Vos Max (mV)	Typical Input Bias Current (pA)	Input Voltage Noise Density (nV/rHz)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP6071	11.2 MHz 1100.15119					-	1.8 to 6.0 -40 to +125 Rail-to-Rail Input/Output 8-pin SOIC, 8-pin 2 x 3 DFN, 5-pin SOT-23			*
MCP6072	2 1.2 MHz 1100.15119					-	1.8 to 6.0 -40 to +125 Rail-to-Rail Input/Output 8-pin SOIC, 8-pin 2 x 3 DFN
MCP6074	41.2 MHz 1100.15119					-	1.8 to 6.0 -40 to +125 Rail-to-Rail Input/Output 14-pin SOIC, 14-pin TSSOP
MCP6H01	11.2 MHz 1353.51035					-	Single Supply: 3.5 to 16 Dual Supply: ±1.75 to ±9	-40 to +125 Rail-to-Rail Output	8-pin SOIC, 8-pin 2 x 3 TDFN, 5-pin SOT-23, 5-pin SO-70
MCP6H02	2 1.2 MHz 1353.51035					-	Single Supply: 3.5 to 16 Dual Supply: ±1.75 to ±9	-40 to +125 Rail-to-Rail Output 8-pin SOIC, 8 pin 2 x 3 TDFN
MCP6H04	41.2 MHz 1353.51035					-	Single Supply: 3.5 to 16 Dual Supply: ±1.75 to ±9	-40 to +125 Rail-to-Rail Output 14 pin SOIC, 14 pin TSSOP
MCP6271	1	2 MHz	170	3	1	20*	2.0 to 6.0	-40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 5-pin SOT-23*
MCP6272	2	2 MHz	170	3	1	20*	2.0 to 6.0 -40 to +125 Rail-to-Rail Input/Output 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6273	1	2 MHz	170	3	1	20*	2.0 to 6.0 -40 to +125 Rail-to-Rail Input/Output, Chip select 8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin SOT-23
MCP6274	4	2 MHz	170	3	1	20*	2.0 to 6.0 -40 to +125 Rail-to-Rail Input/Output 14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6275	2	2 MHz	150	3	1	20*	2.0 to 6.0 -40 to +125	Rail-to-Rail Input/Output, Dual connected, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6471	1	2 MHz	100	1.5	1	27*	2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output 5-pin SOT-23			, 5-pin SC-70
MCP6472	2.2 MHz	1001.5	127			-	2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output 8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 TDFN
MCP6474	4	2 MHz	100	1.5	1	27*	2.0 to 5.5 -40 to +125 Rail-to-Rail Input/Output 14-pin SOIC, 14-pin TSSOP
MCP6L71	1	2 MHz	150	4	1	19*	2.0 to 6.0 -40 to +125 Rail-to-Rail Input/Output 8-pin SOIC			* 8-pin MSOP, 5-pin SOT-23
MCP6L72	2	2 MHz	150	4	1	19*	2.0 to 6.0 -40 to +125 Rail-to-Rail Input/Output 8-pin SOIC, 8-pin MSOP
MCP6L74	4	2 MHz	150	4	1	19*	2.0 to 6.0 -40 to +125 Rail-to-Rail Input/Output 14 pin SOIC, 14 pin TSSOP
MIC6211	1	2.5 MHz	1200	7	50000	-	4.0 to 32	-40 to +85	-	5-pin SOT-23
MCP6H71	1	2.7 MHz	480	4	10	28*	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±8	-40 to +125 Rail-to-Rail Output 8-pin SOIC, 8 pin 2 x 3 TDFN
MCP6H72	2.7 MHz 480	4	1028			-	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±8	-40 to +125 Rail-to-Rail Output 8-pin SOIC, 8-pin 2 x 3 TDFN
MCP6H74	4	2.7 MHz	480	4	10	28*	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±8	-40 to +125 Rail-to-Rail Output 14 pin SOIC, 14 pin TSSOP
MCP6C1	1	2.8 MHz	230	2	1	29*	2.7 to 6.0	40 to +125	Rail-to-Rail Output	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP, 5-pin SOT-23*
MCP6C2	2	2.8 MHz	230	2	1	29*	2.7 to 6.0 -40 to +125 Rail-to-Rail Output 8-pin PDIP, 8-pin SOIC, 8-pin TSSOP
MCP6C3	1	2.8 MHz	230	2	1	29*	2.7 to 6.0	-40 to +125	Rail-to-Rail Output, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP, 8 pin SOT-23*
MCP6C4	4	2.8 MHz	230	2	1	29*	2.7 to 6.0 -40 to +125 Rail-to-Rail Output 14 pin PDIP, 14 pin SOIC, 14 pin TSSOP
MCP6L1	1	2.9 MHz	200	3	1	21*	2.7 to 6.0 -40 to +125 Rail-to-Rail Output 8-pin SOIC			* 8-pin MSOP, 5-pin SOT-23
MCP6L2	2	2.9 MHz	200	3	1	21*	2.7 to 6.0 -40 to +125 Rail-to-Rail Output 8-pin SOIC, 8-pin MSOP
MCP6L4	4	2.8 MHz	200	3	1	21*	2.7 to 6.0 -40 to +125 Rail-to-Rail Output 14 pin SOIC, 14 pin TSSOP
MCP6477	2.3 MHz	140 1.6	1 17			-	1.8 to 5.5 -40 to +125		Rail-to-Rail Input/Output, Enhanced EMI Rejection	8-pin SOIC, 8-pin MSOP
MCP6479	4.3 MHz	140 1.6	1 17			-	1.8 to 5.5 -40 to +125		Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin SOIC, 14-pin TSSOP
MIC882	2	3.0 MHz	31	6	10	-	2.0 to 5.25	-40 to +85	Rail-to-Rail Output	8-pin SOT-23
MCP6286	1	3.5 MHz	540	1.5	1	5.4*	2.2 to 6.5 -40 to +125 Rail-to-Rail Output, Low noise		5-pin SOT 23	* *
MIC880	1	4.0 MHz	33	20	20	-	2.43 to 6.25	-40 to +125	Rail-to-Rail Output	5 pin SC-70
MCP6481	1	4 MHz	240	1.5	1	23*	2.2 to 6.5 -40 to +125 Rail-to-Rail Input/Output 5-pin SOT-23			, 5-pin SC-70
MCP6482	2.4 MHz	240 1.5	123			-	2.2 to 6.5 -40 to +125 Rail-to-Rail Input/Output 8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 TDFN
MCP6484	4	4 MHz	240	1.5	1	23*	2.2 to 6.5 -40 to +125 Rail-to-Rail Input/Output 14 pin SOIC, 14 pin TSSOP
MCP6281	1	5 MHz	445	3	1	16*	2.2 to 6.0	-40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 5-pin SOT-23* *
MCP6282	2	5 MHz	445	3	1	16*	2.2 to 6.0 -40 to +125 Rail-to-Rail Input/Output 8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6283	1	5 MHz	445	3	1	16*	2.2 to 6.0	-40 to +125	Rail-to-Rail Input/Output, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 6 pin SOT-23* *
MCP6284	4	5 MHz	445	3	1	16*	2.2 to 6.0 -40 to +125 Rail-to-Rail Input/Output 14 pin PDIP, 14 pin SOIC, 14 pin TSSOP

www.microchip.com/anailog
Legend: S - Standard Pinout; R - Reverse Pinout; U - Alternative Pinout
Note 1: Values are typical at 1 kHz 2: Values are typical at 10 kHz

LINEAR: Op Amps (Continued)

Part #	# per Package	GBWP	Io Typical (μA)	Vos Max (mV)	Typical Input Bias Current (pA)	Input Voltage Noise Density (nV/rHz)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP8265 2.5 MHz 4003116						^11	2.2 to 8.0 -40 to +125		Rail-to-Rail Input/Output, Dual connected, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6H81 15.5 MHz 700 41023						^11	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±6	-40 to +125	Rail-to-Rail Output	8-pin SOIC, 8-pin 2 x 3 TDFN
MCP6H82 2.5.5 MHz 700 41023						^11	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±6	-40 to +125	Rail-to-Rail Output	8-pin SOIC, 8-pin 2 x 3 TDFN
MCP6H84 45.5 MHz 700 41023						^11	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±6	-40 to +125	Rail-to-Rail Output	14-pin SOIC, 14-pin 2 x 3 TDFN
MCP6491	1	7.5 MHz	530	1.5	1	19 ^11	2.4 to 5.5 -40 to +125	Rail-to-Rail Input/Output	5-pin SOT-23	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 TDFN
MCP6492 2.7.5 MHz 530		1.5	119			^11	2.4 to 5.5	-40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 14-pin TSSOP
MCP6454	4	7.5 MHz	530	1.5	1	19 ^11	2.4 to 5.5	-40 to +125	Rail-to-Rail Input/Output	14-pin SOIC, 8-pin SOIC, 8-pin TSSOP, 8-pin MSOP, 8-pin SOT-23 ^11
MCP6C21	1	10 MHz	1000	0.5	1	8.7 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Input/Output, 1/2 Vcc Vre=	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP, 8-pin MSOP, 8-pin SOT-23 ^11
MCP6C22	2	10 MHz	1000	0.5	1	8.7 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP
MCP6C23	1	10 MHz	1000	0.5	1	8.7 ^11	2.5 to 5.5 -40 to +125		Rail-to-Rail Input/Output, Chip select, 1/2 Vcc Vre=	8-pin PDIP, 8-pin SOIC, 8-pin TSSOP
MCP6C24	4	10 MHz	1000	0.5	1	8.7 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6291	1	10 MHz	1000	3	1	8.7 ^11	2.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 5-pin SOT-23 ^11
MCP6292	2	10 MHz	1000	3	1	8.7 ^11	2.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6203	1	10 MHz	1000	3	1	8.7 ^11	2.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 6-pin SOT-23 ^11
MCP6294	4	10 MHz	1000	3	1	8.7 ^11	2.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6295	2	10 MHz	1100	3	1	8.7 ^11	2.4 to 6.0 -40 to +125		Rail-to-Rail Input/Output, Dual connected, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6H91	1	10 MHz	2000	4	10	23 ^11	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±6	-40 to +125	Rail-to-Rail Output	8-pin SOIC, 8-pin 2 x 3 TDFN
MCP6H92 2	10 MHz	2000 41023				^11	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±6	-40 to +125	Rail-to-Rail Output	8-pin SOIC, 8-pin 2 x 3 TDFN
MCP6H94	4	10 MHz	2000	4	10	23 ^11	Single Supply: 3.5 to 12 Dual Supply: ±1.75 to ±6	-40 to +125	Rail-to-Rail Output	14-pin SOIC, 14-pin TSSOP
MCP6L91	1	10 MHz	850	4	1	9.4 ^11	2.4 to 6.0 -40 to +125	Rail-to-Rail Input/Output	8-pin SOIC	8-pin MSOP ^11 , 8-pin MSOP ^11 , 8-pin SOT-23 ^11
MCP6L92 2	10 MHz	850 419.4				^11	2.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8-pin MSOP
MCP6L94	4	10 MHz	850	4	1	9.4 ^11	2.4 to 6.0	-40 to +125	Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MCP621	1	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	8-pin SOIC, 8-pin 2 x 3 TDFN
MCP6215	1	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, mCal Technology	5-pin SOT-23 ^11
MCP622	2	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, mCal Technology	8-pin SOIC, 8-pin 2 x 3 DFN
MCP623	1	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	6-pin SOT-23 ^11
MCP624	4	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, mCal Technology	14-pin SOIC, 14-pin TSSOP
MCP625	2	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	10-pin MSOP, 10-pin 3 x 3 DFN
MCP629	4	20 MHz	2500	0.2	5	13 ^11	2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	16-pin 4 x 4 QFN
MCP631	1	24 MHz	2500	8	4	10 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	8 pin SOIC, 8 pin 2 x 3 TDFN, 5 pin SOT-23 ^11
MCP632	2	24 MHz	2500	8	4	10 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	8 pin SOIC, 8 pin 3 x 3 DFN
MCP633	1	24 MHz	2500	8	4	10 ^11	2.5 to 5.5 -40 to +125	Rail-to-Rail Output, Chip select, 8-pin SOIC, 8-pin SOT-23
MCP634	4	24 MHz	2500	8	4	10 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	14 pin SOIC, 14 pin TSSOP
MCP635	2	24 MHz	2500	8	4	10 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, Chip select	10-pin MSOP, 10-pin 3 x 3 DFN
MCP639	4	24 MHz	2500	8	4	10 ^11	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, Chip select	16-pin 4 x 4 QFN

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout
Note 1: Values are typical at 1 kHz 2: Values are typical at 10 kHz 3: Values are typical at 1 MHz

LINEAR: Op Amps (Continued)

Part #	# per Package	GBWP	Io Typical (μA)	Vos Max (mV)	Typical Input Bias Current (pA)	Input Voltage Noise Density (nV/rTHz)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP651 150 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	8-pin SOIC, 8-pin 2 x 3 TDFN
MCP651S 150 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125	Rail-to-Rail Output, mCal Technology 5-pin SOT-23
MCP652 2 50 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125	Rail-to-Rail Output, mCal Technology 8-pin SOIC, 8-pin 3 x 3 DFN
MCP653 150 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	6-pin SOT-23 ^a
MCP654 450 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125	Rail-to-Rail Output, mCal Technology 14-pin SOIC, 14-pin TSSOP
MCP655 2 50 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	10-pin MSOP, 10-pin 3 x 3 DFN
MCP659 450 MHz 60000.2	67.5						2.5 to 5.5 -40 to +125		Rail-to-Rail Output, Chip select, mCal Technology	16-pin 4 x 4 QFN
MCP660	3	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	14-pin SOIC, 14-pin TSSOP
MCP661	1	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	8-pin SOIC, 8-pin 2 x 3 TDFN, 5-pin SOT-23(S)
MCP662	2	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	8-pin SOIC, 8-pin 3 x 3 DFN
MCP663	1	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, Chip select	8-pin SOIC, 6-pin SOT 23
MCP664	4	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output	14-pin SOIC, 14-pin TSSOP
MCP665	2	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, Chip select	10-pin MSOP, 10-pin 3 x 3 DFN
MCP669	4	60 MHz	6000	8	6	6.8(3)	2.5 to 5.5	-40 to +125	Rail-to-Rail Output, Chip select	16-pin 4 x 4 QFN
MIC920	1	60 MHz	550	5	260000	10	5.0 to 18	-40 to +85	High Output Drive, High Slow Rate	5-pin SG-70, 5-pin SOT-23

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout
Note 1: Values are typical at 1 kHz 2: Values are typical at 10 kHz 3: Values are typical at 1 MHz

LINEAR: Zero-Drift Operational Amplifiers

Part #	# per Package	GBWP	Io Max (mA)	Vos Max (μV)	Vos Drift Max (μV/°C)	Operating Voltage (V)	Temperature Range (°C)	Features	Packages
MCP6V11	1	80 kHz	0.011	8	0.05	1.6 to 5.5	-40 to -125	Rail-to-Rail Input/Output	5-pin SOT-23 ^A11 , 5-pin SC-70 ^A11
MCP6V12	2	80 kHz	0.011	8	0.05	1.6 to 5.5	-40 to -125	Rail-to-Rail Input/Output	8-pin 2 x 3 TDFN, 8-pin MSOP
MCP6V14	4	80 kHz	0.011	8	0.05	1.6 to 5.5	-40 to -125	Rail-to-Rail Input/Output	14-pin TSSOP
MCP6V16	1	80 kHz	0.011	25	0.15	1.6 to 5.5	-40 to +125	Rail-to-Rail Input/Output	5-pin SOT-23 ^A12 , 5-pin SC70 ^A12
MCP6V17	2	80 kHz	0.011	25	0.15	1.6 to 5.5	-40 to +125	Rail-to-Rail Input/Output	8-pin 2 x 3 TDFN, 8-pin MSOP
MCP6V19	4	80 kHz	0.011	25	0.15	1.6 to 5.5	-40 to +125	Rail-to-Rail Input/Output	14-pin TSSOP
MCP6V31	1	300 kHz	0.034	8	0.05	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output	5-pin SOT 23 ^A11 , 5-pin SC-70 ^A11
MCP6V32	2	300 kHz	0.034	8	0.05	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output	8-pin 2 x 3 TDFN, 8-pin MSOP
MCP6V34	4	300 kHz	0.034	8	0.05	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output	14-pin TSSOP
MCP6V36	1	300 kHz	0.034	25	0.15	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output	5-pin SOT-23 ^A12 , 5-pin SC70 ^A12
MCP6V37	2	300 kHz	0.034	25	0.15	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output	8-pin 2 x 3 TDFN, 8-pin MSOP
MCP6V38	4	300 kHz	0.034	25	0.15	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output	14-pin TSSOP
TC7652	1	0.4 MHz	3	5	0.05	5 to 16	0 to +70	Single and Split Supply, Low Noise	8-pin PDIP, 14-pin PDIP
MCP6V61	1	1 MHz	0.13	8	0.015	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SOT-23 ^A11 , 5-pin SC-70 ^A11
MCP6V62	2	1 MHz	0.13	8	0.015	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	8-pin 2 x 3 TDFN, 8-pin MSOP
MCP6V64	4	1 MHz	0.13	8	0.015	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin TSSOP
MCP6V66	1	1 MHz	0.13	25	0.15	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SOT-23 ^A12 , 5-pin SC-70 ^A12
MCP6V67	2	1 MHz	0.13	25	0.15	1.8 to 5.5	-40 to -125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	8-pin 2 x 3 TDFN, 8-pin MSOP
MCP6V68	4	1 MHz	0.13	25	0.15	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin TSSOP

LINEAR: Zero-Drift Operational Amplifiers

Part #	per Package	GBWP	Io Max (mA)	Vos Max ( V)	Vos Drift Max ( V/°C)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP6V01	1	1.3 MHz	0.4	2	0.05	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output	6-pin SOIC, 8-pin 2 × 3 TDFN
MCP6V02	2	1.3 MHz	0.4	2	0.05	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output	6-pin SOIC, 8-pin 4 × 4 DFN
MCP6V03	1	1.3 MHz	0.4	2	0.05	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Chio select	8-pin SOIC, 8-pin 2 × 3 TDFN
MCP6V06	1	1.3 MHz	0.4	3	0.05	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8-pin 2 × 3 TDFN
MCP6V07	2	1.3 MHz	0.4	3	0.05	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8-pin 4 × 4 DFN
MCP6V08	1	1.3 MHz	0.4	3	0.05	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Chio select	6-pin SOIC, 8 pin 2 × 3 TDFN
TC813A/B	2	1.5 MHz	1.1	15	0.15/0.30	7 to 18	0 to +70	Single and Split Supply	6-pin PDIP, 8-pin SOIC
TC7650	1	2 MHz	3.5	5	0.05	4.5 to 16	0 to +70	Single and Split Supply	6-pin PDIP, 14-pin PDIP
MCP6V28	1	2 MHz	0.9	2	0.05	2.3 to 5.5	-40 to +125	Rail-to-Rail Input/Output	8-pin SOIC, 8-pin MSOP, 8 pin 2 × 3 TDFN
MCP6V27	2	2 MHz	0.8	2	0.05	2.3 to 5.5	-40 to +125	Rail-to-Rail Input/Output	6 pin SOIC, 8 pin MSOP, 8 pin 4 × 4 DFN
MCP6V28	1	2 MHz	0.8	2	0.05	2.3 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Chio select	6-pin SOIC, 8 pin MSOP, 8 pin 2 × 3 TDFN
MCP6V51	1	2 MHz	0.59	15	0.038	4.5 to 45	-40 to +125	Rail-to-Rail Output, Enhanced EMI Rejection	5-pin SCT-23 ^a,b , 8-pin MSOP
MCP6V71	1	2 MHz	0.26	9	0.015	2.0 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SCT-23 ^a,b , 5-pin SC-70 ^b,c
MCP6V72	2	2 MHz	0.26	9	0.015	2.0 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	6 pin 2 × 3 TDFN, 8 pin MSOP
MCP6V74	4	2 MHz	0.26	8	0.015	2.0 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin TSSOP
MCP6V78	1	2 MHz	0.26	25	0.15	2.0 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SCT-23 ^a,c , 5-pin SC-70 ^b,c
MCP6V77	2	2 MHz	0.26	25	0.15	2.0 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	6 pin 2 × 3 TDFN, 8 pin MSOP
MCP6V79	4	2 MHz	0.26	25	0.15	2.0 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin TSSOP
MCP6V81	1	5 MHz	0.77	9	0.02	2.2 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SCT-23 ^a,b , 5-pin SC-70 ^b,c
MCP6V82	2	5 MHz	0.77	9	0.058	2.2 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	6 pin 2 × 3 TDFN, 8 pin MSOP
MCP6V84	4	5 MHz	0.77	9	0.058	2.2 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14 pin TSSOP
MCP6V86	1	5 MHz	0.77	25	0.15	2.2 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SOT-23 ^a,b , 5-pin SC-70 ^b,c
MCP6V87	2	5 MHz	0.77	25	0.15	2.2 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	8-pin 2 × 3 TDFN, 8-pin MSOP
MCP6V89	4	5 MHz	0.77	25	0.15	2.2 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin TSSOP
MCP6V91	1	10 MHz	1.8	9	0.017	2.4 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	5-pin SOT-23 ^a,b , 5-pin SC-70 ^b,c
MCP6V92	2	10 MHz	1.8	9	0.04	2.4 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	8 pin 2 × 3 TDFN, 8 pin MSOP
MCP6V94	4	10 MHz	1.6	9	0.01	2.4 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enhanced EMI Rejection	14-pin TSSOP

LINEAR: Differential Amplifiers

Part #	# per Package	GBWP Slew Rate (V/μs) Iq Typical (mA) Vos Max (μV)			Input Voltage Noise Density (nV/rtHz)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP6D11	190 MHz 25	1.415052	5 to 5.5	-40 to +125				Low noise, low distortion with power down pin	8-pin MSOP, 16-pin 3 x 3 QFN

LINEAR: Programmable Gain Amplifiers (PGA)

Part #	Channels	-3dB BW (MHz)	Io Typ. (mA)	Vos (μV)	Operating Voltage (V)	Temperature Range (°C)	Features	Packages
MCP6S21	1	2 to 12	1.1	275	2.5 to 5.5	-40 to +85	SPI, Eight Gain steps, Software shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6S22	2	2 to 12	1.1	275	2.5 to 5.5	-40 to +85	SPI, Eight Gain steps, Software shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6S26	8	2 to 12	1.1	275	2.5 to 5.5	-40 to +85	SPI, Eight Gain steps, Software shutdown	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6S28	8	2 to 12	1.1	275	2.5 to 5.5	-40 to +85	SPI, Eight Gain steps, Software shutdown	16-pin PDIP, 16-pin SOIC
MCP6S31	1	1 to 18	1.0	4000	2.5 to 5.5	-40 to +125	SPI, Eight Gain steps, Software shutdown, Vfree	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6S32	2	1 to 18	1.0	4000	2.5 to 5.5	-40 to +125	SPI, Eight Gain steps, Software shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6S33	2	1 to 18	1.0	4000	2.5 to 5.5	-40 to +125	SPI, Eight Gain steps, Software shutdown, Vic., SO	10-pin MSOP

LINEAR: Selectable Gain Amplifiers (SGA)

Part #	Channels	3dB BW (kHz)	Iq (μA)	Vos (mV)	Operating Voltage (V)	Temperature Range (°C)	Gain Steps (V/V)	Features	Packages
MCP6G01	1	900	110	4.5	1.8 to 5.5	-40 to +125	1, 10, 50	Tri-State control pin	8-pin SOIC, 8-pin MSOP, 5-pin SOT 23 ^ SOP
MCP6G02	2	900	110	4.5	1.8 to 5.5	-40 to +125	1, 10, 50	Tri-State control pin	8-pin SOIC, 8-pin MSOP
MCP6G03	1	900	110	4.5	1.8 to 5.5	-40 to +125	1, 10, 50	Tri-State control pin, chip select	8-pin SOIC, 8-pin MSOP
MCP6G04	4	900	110	4.5	1.8 to 5.5	-40 to +125	1, 10, 50	Tri-State control pin	14-pin SOIC, 14-pin TSSOP

LINEAR: Instrumentation Amplifiers

Part #	# Per Package	Bandwidth (kHz)	Io Max (mA)	Max Vos (μV)	Vos Drift Max (μV/°C)	Operating Voltage (V)	Temperature Range (°C)	Features	Packages
MCP6N11	1	500	1.1	350	2.7	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, mCal Technology	8-pin SCIC, 8-pin 2 x 3 TDFN
MCP6N18	1	500	1.8	17	0.08	1.8 to 5.5	-40 to +125	Rail-to-Rail Input/Output, Enable Pin, Enhanced EMI Rejection	8-pin MSOP, 8-pin 3 x 3 DFN

LINEAR: Comparators

Part #	# Per Package	VREF(V)	Typical Propagation Delay (μs)	Io Typical (μA)	Vos Max (mV)	Operating Voltage (V)	Temperature Range (°C)	Features Packages
MCP6541 1-1151.6 to 5.5 -40 to +125 Push-Pull, Rail-to-Rail Input/Output									5-pin SOT-235F-U, 5-pin SC-705A,8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6542	2	-	4	1	5	1.6 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6543	1	-	4	1	5	1.6 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6544	4	-	4	1	5	1.6 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP6546 1-41 to 5.5 -40 to +125 Open-drain, 9V, Rail-to-Rail Input/Output									5-pin SOT-235F-U, 5-pin SC-705A,8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6547	2	-	4	1	5	1.6 to 5.5	-40 to +125	Open-drain, 8V, Rail-to-Rail Input/Output	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6548	1	-	4	1	5	1.6 to 5.5	-40 to +125	Open-drain, 8V, Rail-to-Rail Input/Output, Chip select	8-pin PDIP, 8-pin SOIC, 8-pin MSOP
MCP6549	4	-	4	1	5	1.6 to 5.5	-40 to +125	Open-drain, 8V, Rail-to-Rail Input/Output	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP65F41	1	1.21/2.4	4	2.5	10	1.8 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output, VREF	6-pin SOT-23
MCP65F46	1	1.21/2.4	4	2.5	10	1.8 to 5.5	-40 to +125	Open-Drain, Rail-to-Rail Input/Output, VREF	6-pin SOT-23
MCP6561	1	-	0.047	100	10	1.8 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output	5-pin SOT-235F-U, 5-pin SC-705A
MCP6562	2	-	0.047	100	10	1.8 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output	8-pin SOIC, 8-pin MSOP
MCP6564	4	-	0.047	100	10	1.8 to 5.5	-40 to +125	Push-Pull, Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MCP6566	1	-	0.047	100	10	1.8 to 5.5	-40 to +125	Open-Drain, Rail-to-Rail Input/Output	5-pin SOT-235F-U, 5-pin SC-705A
MCP6567	2	-	0.047	100	10	1.8 to 5.5	-40 to +125	Open-Drain, Rail-to-Rail Input/Output	9-pin SOIC, 8-pin MSOP
MCP6569	4	-	0.047	100	10	1.8 to 5.5	-40 to +125	Open-Drain, Rail-to-Rail Input/Output	14-pin SOIC, 14-pin TSSOP
MIC6270	1	-	0.6	300	5	2.0 to 26	-40 to -85	Open Collector Output, High-Voltage	5-pin SOT-23
MIC7211	1	-	4	5	10	2.2 to 5.0	-40 to -85	Rail-to-Rail Input, Push-Pull Output	5-pin SOT-23
MIC7221	1	-	4	5	10	2.2 to 5.0	-40 to -85	Rail-to-Rail Input, Open-Drain Output	5-pin SOT-23
MIC833	1	1.25	5	1	-	1.5 to 5.5	-40 to -85	Windowed Comparator with Adjustable Hysteresis	5-pin SOT-23
MIC841	1	1.25	12	1.5	-	1.5 to 5.5	-40 to +85	Windowed Comparator with Adjustable Hysteresis, Push-Pull and Open-Drain Output Options	5-pin SC-70, 8-pin 1.6 x 1.6 TDFN
MIC842	1	1.25	12	1.5	-	1.5 to 5.5	-40 to +85	Windowed Comparator with Hysteresis, Push-Pull and Open-Drain Output Options	5-pin SC-70, 4-pin 1.2 x 1.6 TDFN

Legend: S = Standard Pinout; R = Reverse Pinout; U = Alternative Pinout

LINEAR: Current Sense Amplifiers

Part #	# per Package	Input Common-Mode Range (V)	Vos Max (uV)	Vos Drift Max (nV/°C)	Max Gain Error (%)	Bandwidth (kHz)	Iq Max (mA)	Operating Voltage (V)	Temperature Range (°C)	Features	Packages
MCP8C02	1	3 to 65	16 (G=20), 14 (G=50), 12 (G=100)	85 (G=20), 70 (G=50), 65 (G=100)	1.6	500 (G=20), 500 (G=50), 350 (G=100)	0.75	2 to 5.5	-40 to +125	Bidirectional Current Sense Amplifier, Enhanced EMI Rejection	6-pin SOT-238 pin 3 x 3 VOFN
MCP8C04	1	3 to 62	30 (G=20), 27 (G=50), 24 (G=100)	180 (G=20), 140 (G=50), 130 (G=100)	1.6	500 (G=20), 500 (G=50), 350 (G=100)	0.84	2 to 5.5	-40 to +125	Bidirectional Current Sense Amplifier, Enhanced EMI Rejection	6-pin SOT-23

MIXED SIGNAL

MIXED SIGNAL: SUCCESSIVE APPROXIMATION REGISTER (SAR) A/D CONVERTERS

Part #	Resolution(bits)	Maximum Sampling Rate(ksamples/sec)	# of InputChannels	Input Type	Interface	Input VoltageRange (V)	Max. SupplyCurrent (μA)	Max. INL	TemperatureRange (°C)	Packages
MCP3C21	10	22	1	Single-ended	^ C	2.7 to 5.5	250	± 1 LSB	-40 to +125	5-pin SOT-23A
MCP3C01	10	200	1	Single-ended	SPI	2.7 to 5.5	500	± 1 LSB	-40 to +85	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin TSSOP
MCP3C02	10	200	2	Single-ended	SPI	2.7 to 5.5	650	± 1 LSB	-40 to +85	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin TSSOP
MCP3C04	10	200	4	Single-ended	SPI	2.7 to 5.5	550	± 1 LSB	-40 to +85	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP3C06	10	200	9	Single-ended	SPI	2.7 to 5.5	550	± 1 LSB	-40 to +85	16-pin PDIP, 16-pin SOIC
MCP3221	12	22	1	Single-ended	^ C	2.7 to 5.5	250	± 2 LSB	-40 to +125	5-pin SOT-23A
MCP3201	12	100	1	Single-ended	SPI	2.7 to 5.5	400	± 1 LSB	-40 to +85	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin TSSOP

MIXED SIGNAL: SUCCESSION APPROXIMATION REGISTER (SAR) A/D CONVERTERS

Part #	Resolution(bits)	Maximum Sampling Rate(ksamples/sec)	# of InputChannels	Input Type Interface		Input VoltageRange (V)	Max. SupplyCurrent (μA)	Max. INL	TemperatureRange (°C)	Packages
MCP3202	12	100	2	Single-ended	SPI	2.7 to 5.5	550	±1 LSB	-40 to +85	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin TSSOP
MCP3204	12	100	4	Single-ended	SPI	2.7 to 5.5	400	±1 LSB	-40 to +85	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP3208	12	100	8	Single-ended	SPI	2.7 to 5.5	400	±1 LSB	-40 to +85	16-pin PDIP, 16-pin SOIC
MCP3301	13	100	1	Differential	SPI	2.7 to 5.5	450	±1 LSB	-40 to +85	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin TSSOP
MCP3302	13	100	2	Differential	SPI	2.7 to 5.5	450	±1 LSB	-40 to +85	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP
MCP3304	13	100	4	Differential	SPI	2.7 to 5.5	450	±1 LSB	-40 to +85	16-pin PDIP, 16-pin SOIC
MCP33141-05	12	500	1	Single-Ended	SPI	0V to 5.1V	900		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33141-10	12	1 Msps	1	Single-Ended	SPI	0V to 5.1V	900		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33141D-05	12	500	1	Differential	SPI	±5.1V	900		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33141D-10	12	1 Msps	1	Differential	SPI	±5.1V	900		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33151-05	14	500	1	Single-Ended	SPI	0V to 5.1V	900	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33151-10	14	1 Msps	1	Single-Ended	SPI	0V to 5.1V	900	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33151D-05	14	500	1	Differential	SPI	±5.1V	900	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33151D-10	14	1 Msps	1	Differential	SPI	±5.1V	900	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33111-05	12	500	1	Single-Ended	SPI	0V to 5.1V	2400		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33111-10	12	1 Msps	1	Single-Ended	SPI	0V to 5.1V	2400		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33111D-05	12	500	1	Differential	SPI	±5.1V	2400		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33111D-10	12	1 Msps	1	Differential	SPI	±5.1V	2400		-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33121-05	14	500	1	Single-Ended	SPI	0V to 5.1V	2400	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33121-10	14	1 Msps	1	Single-Ended	SPI	0V to 5.1V	2400	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33121D-05	14	500	1	Differential	SPI	±5.1V	2400	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33121D-10	14	1 Msps	1	Differential	SPI	±5.1V	2400	±1.5	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33131-05	16	500	1	Single-Ended	SPI	0V to 5.1V	2400	±6	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33131-10	16	1 Msps	1	Single-Ended	SPI	0V to 5.1V	2400	±6	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33131D-05	16	500	1	Differential	SPI	±5.1V	2400	±6	-40 to +125	10-pin MSOP, 10-pin TDFN
MCP33131D-10	16	1 Msps	1	Differential	SPI	±5.1V	2400	±6	-40 to +125	10-pin MSOP, 10-pin TDFN

MIXED SIGNAL: Delta-Sigma A/D Converters

Part #	Resolution (bits)	Maximum Sampling Rate (samples/sec)	# of Input Channels	Interface	Supply Voltage Range (V)	Typical Supply Current (μA)	Typical INL (ppm)	Temperature Range (°C)	Features	Packages
MCP3421	18 to 12	4 to 240	1 Diff	IC	2.7 to 6.5	155	10	-40 to +125	PGA, Vpu	8-pin SOT-23A
MCP3422	18 to 12	4 to 240	2 Diff	IC	2.7 to 6.5	145	10	-40 to +125	PGA, Vpu	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 DFN
MCP3423	18 to 12	4 to 240	2 Diff	IC	2.7 to 6.5	145	10	-40 to +125	PGA, Vpu, Selectable IC addressing	10-pin MSOP, 10-pin 3 x 3 DFN
MCP3424	18 to 12	4 to 240	4 Diff	IC	2.7 to 6.5	145	10	-40 to +125	PGA, Vpu, Selectable IC addressing	14-pin SOIC, 14-pin TSSOP
MCP3425	16 to 12	16 to 240 1 Diff	I	C	2.7 to 6.5	155	10	-40 to +125	PGA, Vpu	6-pin SOT-23A
MCP3426	16 to 12	16 to 240 2 Diff	I	C	2.7 to 6.5	145	10	-40 to +125	PGA, Vpu	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 DFN
MCP3427	16 to 12	18 to 240 2 Diff	I	°C	2.7 to 6.5	145	10	-40 to +125	PGA, Vpu, Selectable IC addressing	10-pin MSOP, 10-pin 3 x 3 DFN
MCP3428	16 to 12	15 to 240 4 Diff	I	C	2.7 to 6.5	145	10	-40 to +125	PGA, Vpu, Selectable IC addressing	14-pin SOIC, 14-pin TSSOP
MCP3461	16	153.6k	1	SPI	2.7 to 3.6	930	7	-40 to +125	One Differential or Two Single-ended Input Channels, 153.6 kSPS, Low-Noise 16-bit Delta-Sigma ADCs	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3462	16	153.6k	2	SPI	2.7 to 3.6	930	7	-40 to +125	Two Differential or Four Single-ended Input Channels, 153.6 kSPS, Low-Noise 16-bit Delta-Sigma ADCs	3 mm x 3 mm UQFN-20, 20-pin TSSOP

MIXED SIGNAL: Delta-Sigma A/D Converters

Part #	Resolution (bits)	Maximum Sampling Rate (samples/sec)	# of Input Channels	Interface	Supply Voltage Range (V)	Typical Supply Current (μA)	Typical INL (ppm)	Temperature Range (°C)	Features Packages
MCP3464 16	153.6k 4 SPI 2.7 to 3.6 930 7 -40 to +125								Four Differential or Eight Single-ended Input Channels, 153.6 kSPS, Low-Noise 16-bit Delta-Sigma ADCs	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3561 24	153.6k 1 SPI 2.7 to 3.6 930 7 -40 to +125								One Differential or Two Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3562 24	153.6k 2 SPI 2.7 to 3.6 930 7 -40 to +125								Two Differential or Four Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3564 24	153.6k 4 SPI 2.7 to 3.6 930 7 -40 to +125								Four Differential or Eight Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3461R 16	153.6k 1 SPI 2.7 to 3.6 930 7 -40 to +125								One Differential or Two Single-ended Input Channels, 153.6 kSPS, Low-Noise 16-bit Delta-Sigma ADCs with VREF	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3462R 16	153.6k 2 SPI 2.7 to 3.6 930 7 -40 to +125								Two Differential or Four Single-ended Input Channels, 153.6 kSPS, Low-Noise 16-bit Delta-Sigma ADCs with VREF	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3464R 16	153.6k 4 SPI 2.7 to 3.6 930 7 -40 to +125								Four Differential or Eight Single-ended Input Channels, 153.6 kSPS, Low-Noise 16-bit Delta-Sigma ADCs with VREF	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3465R 24	153.6k 1 SPI 2.7 to 3.6 930 7 -40 to +125								One Differential or Two Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs with VREF	2 mm x 2 mm UQFN-12
MCP3561R 24	153.6k 1 SPI 2.7 to 3.6 930 7 -40 to +125								One Differential or Two Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs with VREF	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3562R 24	153.6k 2 SPI 2.7 to 3.6 930 7 -40 to +125								Two Differential or Four Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs with VREF	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3564R 24	153.6k 4 SPI 2.7 to 3.6 930 7 -40 to +125								Four Differential or Eight Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs with VREF	3 mm x 3 mm UQFN-20, 20-pin TSSOP
MCP3565R 24	153.6k 1 SPI 2.7 to 3.6 930 7 -40 to +125								One Differential or Two Single-ended Input Channels, 153.6 kSPS, Low-Noise 24-bit Delta-Sigma ADCs with VREF	2 mm x 2 mm UQFN-12
MCP8550-50	22	13	1 Diff	SPI	2.7 to 5.5	120	2	40 to +125	50 Hz rejection	8-pin SOC, 8-pin MSOP
MCP8550-60	22	15	1 Diff	SPI	2.7 to 5.5	140	2	-40 to +125	60 Hz rejection	8-pin SOC, 8 pin MSOP
MCP8551	22	14	1 Diff	SPI	2.7 to 5.5	120	2	-40 to +125	Simutaneous 50/60 Hz rejection	8 pin SOC, 8 pin MSOP
MCP8553	20	60	1 Diff	SPI	2.7 to 5.5	140	2	-40 to +125		8-pin SOC, 8-pin MSOP

MIXED SIGNAL: Pipelined A/D Converters

Part #	Resolution	Max Sample Rate (Msamples/sec)	# of Input Channels	Input Type	Interface	Supply Voltage (V)	Power Dissipation (mW)	Input Channel BW (MHz)	SNR (dB)	SFDR (dB)	Input Range (Vp-p)	Features	Temperature Range (°C)	Packages
MCP37D31-200	16	200	1, 2, 4, 8	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	490	500	74.7	90	2.98	Decimation filters, digital down- converter, AEC-Q100 Grade 1 (only TFBGA package)	-40 to +85	124-ph VTLA, 121-ph TFBGA
MCP37231-200	16	200	1, 2, 4, 8	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	490	500	74.7	90	2.98	Decimation filters, AEC-Q100 Grade 1 (only TFBGA package)	-40 to +85	124-ph VTLA, 121-ph TFBGA
MCP37D20-200	14	200	1	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	348	650	67.8	96	1.9	Decimation filters, digital down- converter	-40 to +85	124-ph VTLA, 121-ph TFBGA
MCP37220-200	14	200	1	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	348	650	67.8	96	1.9	Decimation filters	-40 to +85	124-ph VTLA, 121-ph TFBGA
MCP37D21-200	14	200	1, 2, 4, 8	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	490	500	74.2	90	2.98	Decimation filters, digital down- converter, AEC-Q100 Grade 1 (only TFBGA package)	-40 to +85	124-ph VTLA, 121-ph TFBGA
MCP37221-200	14	200	1, 2, 4, 8	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	490	500	74.2	90	2.98	Decimation filters, AEC-Q100 Grade 1 (only TFBGA package)	-40 to +85	124-ph VTLA, 121-ph TFBGA
MCP37D10-200	12	200	1	Differential	Serial DDR LVDS or Parallel CMOS	1.2, 1.8	338	650	67	96	1.9	Decimation filters, digital down- converter, noise-shaping requantizer	-40 to +85	124-ph VTLA, 121-ph TFBGA

MIXED SIGNAL: Pipelined A/D Converters

Part # Resolution

Max Sample Rate (Msamples/sec)

# of Input Channels

Input Type

Interface

Supply Voltage (V)

Power Dissipation (mW)

Input Channel BW (MHz)

SNR (dB)

SFDR (dB)

Input Range (Vp-p)

Features

Temperature Range (°C)

Packages

MCP37210-200 12 200 1 Differential

Serial DDR LVDS or Parallel CMOS

1.2, 1.8

338 65067 96

1.8

Decimation filters, noise-shaping requantizer

-40 to +85

124-pin VTLA, 121-pin TFBGA

MCP37D11-200 12 200 1, 2, 4, 8 Differential

Serial DDR LVDS or Parallel CMOS

1.2, 1.8

468 500/1.3

2.08

Decimation filters, digital down-converter, AEC-Q100 Grade 1 (only TFBGA package)

-40 to +85

124-pin VTLA, 121-pin TFBGA

MCP37211-200 12 200 1, 2, 4, 8 Differential

Serial DDR LVDS or Parallel CMOS

1.2, 1.8

468 500/1.3

2.08

Decimation filters, noise shaping requantizer

-40 to +85

124-pin VTLA, 121-pin TFBGA

MCP37D31-80 16 80 1, 2, 4, 8 Differential

Serial DDR LVDS or Parallel CMOS

1.2, 1.8

329 500

73.9

2.98

Decimation filters, digital down-converter, AEC-Q100 automotive qualification

-40 to +125

121-pin TFBGA

MCP37D21-80

1, 2, 4, 8

Differential

Serial DDR LVDS or Parallel CMOS

1.2, 1.8

320

500

73.9

Decimation filters, digital down-converter, AEC-Q100 automotive qualification

-40 to +125

121-pin TFBGA

MCP37D11-80 12 80 1, 2, 4, 8 Differential

Serial DDR LVDS or Parallel CMOS

1.2, 1.8

311 500

70.9

92.2

2.98

Decimation filters, digital down-converter, AEC-Q100 automotive qualification

-40 to +125

121-pin TFBGA

MIXED SIGNAL: Energy Metering and Power Monitoring ICs

Part #

Dynamic Range

Power System

Typical Accuracy

Input Channels

ADC Resolution

Event Monitoring

Zero-Cross Detection Pin

Output Type

Von (V)

Temperature Range (°C)

Features

Packages

MCP39F511

4000:1

Single Phase

0.1%

I, V, Temp.

24-bit

Yes

UART/ Single-wire

2.7 to 3.6

-40 to +125

Power monitoring IC with active, reactive and apparent power, active and reactive energy, PF, RMS current/voltage, frequency, event notifications, EEPROM, PWM output

QFN

MCP39F521

4000:1

Single Phase

0.1%

I, V, Temp.

24-bit

Yes

2.7 to 3.6

-40 to +125

Power monitoring IC with active, reactive and apparent power, active and reactive energy, PF, RMS current/voltage, frequency, event notifications, EEPROM

QFN

MCP39F511N

4000:1

Single Phase

0.5%

I1, I2, V

24-bit

Yes

UART

2.7 to 3.6

-40 to +125

Dual-channel power monitoring IC with active, reactive and apparent power, active and reactive energy, PF, RMS current/voltage, frequency, event notifications, EEPROM, PWM output

QFN

MCP39F511A 4000:1

Single Phase

0.1%

I, V, Temp

24-bit

Yes

UART/ Single-wire

2.7 to 3.

-40 to +125

AC & DC dual-mode power monitoring IC with active, reactive and apparent power, active and reactive energy, PF, RMS current/voltage, frequency, event notifications, EEPROM, PWM output

QFN

MCP3805AV DGA

500:1/1000:1

Single Phase

0.10%

I, V

16-bit

–

Active Power Pulse

4.6 to 5.5

-40 to +125

Active power calculation

SSOP

ATM90E28 5000:1

Single Phase

0.1%

I, V, N

N/A

Yes

SPI/UART/ Pulse

2.8 to 3.6

-40 to +85

Single-phase energy meter IC with active, reactive and apparent power, active and reactive energy, PF, RMS current/voltage, anti-tampering

SSOP

ATM90E32AS 6000:1

Poly-phase

0.1%

3x1, 3xV

N/A

Yes

SPI/Pulse

2.8 to 3.6

-40 to +85

Three-phase energy meter IC with active, reactive and apparent power and energy, PF, RMS current/voltage, frequency, fundamental and harmonic measurement, event notifications, temperature sensor

TQFP

ATM90E36A

6000:1

Poly-phase

0.1%

3x1, 3xV, N

N/A

Yes

SPI/Pulse

2.8 to 3.6

-40 to +85

Three-phase energy meter IC with active, reactive and apparent power and energy, PF, RMS current/voltage, frequency, DTT function, fundamental and harmonic measurement, event notifications, temperature sensor

TQFP

MIXED SIGNAL: Energy Measurement AFEs

Part #	Dynamic Range	Typical Accuracy	ADC Channels	ADC Resolution	SINAD	Gain Selection	Output Type	VDD (V)	Temperature Range (°C)	Features	Packages
MCP3918/10	10000:1	0.1%	1/2	24-bit	93.5	Up to 32	SPI/2-wire	2.7 to 3.6	-40 to +125	AFE with phase correction, Programmable data rate, 16-bit CRC, Register map lock, 2 wire Interface	SSOP, QFN
MCP3919	10000:1	0.1%	3	24-bit	93.5	Up to 32	SPI/2-wire	2.7 to 3.6	-40 to +125	AFE with phase correction, Programmable data rate, 16-bit CRC, Register map lock, 2 wire Interface	SSOP, QFN
MCP3912	10000:1	0.1%	4	24-bit	93.5	Up to 32	SPI	2.7 to 3.6	-40 to +125	AFE with phase correction, Programmable data rate, 16-bit CRC, Register map lock	SSOP, QFN
MCP3913/14	10000:1	0.1%	6/8	24-bit	94.5	Up to 32	SPI	2.7 to 3.6	-40 to +125	AFE with phase correction, Programmable data rate, 16 bit CRC, Register map lock	SSOP, UQFN
ATSENSE101	3000:1	0.1%	3	16/32-bit	84	Up to 8	SPI	3.0 to 3.6	-40 to +85	De temperature sensor	SOIC
ATSENSE201(H)	3000:1	0.1%	4	16/32-bit	84	Up to 8	SPI	3.0 to 3.6	-40 to +85	De temperature sensor	TQFP
ATSENSE301(H)	3000:1	0.1%	7	16/32-bit	84	Up to 8	SPI	3.0 to 3.6	-40 to +85	De temperature sensor	TQFP

MIXED SIGNAL: DC Power Monitors

Part #

# of Current Sensors

Description

Full Scale Range (mV)

Current Measurement Max Accr (%)

Effective Sampling Interval Min to Max (msec)

Bus Voltage Range (V)

# of Temp. Monitors (Ambient, Remote)

Temp. Accuracy Typ/Max (°C)

Alert/ THERM

Peak Detection

Address Select

Package

PAC1710 13MBus/I

IC Current/DC Power Sensor

10, 20, 40, 80

±1

2.5 to 2,600

0 to +40

Yes

10-pin DFN

PAC1720 2 Dual SMBus/I

IC Current/DC Power Sensor

10, 20, 40, 80

±1

2.5 to 2,600

0 to +40

Yes

10-pin DFN

PAC1921 2

SMBus/IC Current/Power Sensor with Analog Output

100

±1

2.5 to 2,900

0 to +32

Yes

10-pin DFN

PAC1931

SMBus/IC Current/Power Sensor with Accumulator

100

±0.9

0.98 to 125

0 to +32

Yes

2.225 x 2.17 mm WL CSP

PAC1932

SMBus/IC Current/Power Sensor with Accumulator

100

±0.9

0.98 to 125

0 to +32

Yes

2.225 x 2.17 mm WL CSP, 16-pin QFN

PAC1933

SMBus/IC Current/Power Sensor with Accumulator

100

±0.9

0.98 to 125

0 to +32

Yes

2.225 x 2.17 mm WL CSP, 16-pin QFN

PAC1934 4

SMBus/IC Current/Power Sensor with Accumulator

100

±0.9

0.98 to 125

0 to +32

Yes

2.225 x 2.17 mm WL CSP, 16-pin QFN

EMC1701-1

SMBus/IC Current/DC Power Sensor with Temperature Monitoring

10, 20, 40, 80

±1

2.5 to 2,600

+3 to +24

1, 0

±0.25/±1

Hardware

Yes

12-pin 4 x 4 QFN

EMC1701-2

SMBus/IC Current/DC Power Sensor with Temperature Monitoring

10, 20, 40, 80

±1

2.5 to 2,600

+3 to +24

1, 0

±0.25/±1

Software

Yes

10-pin MSOP

EMC1702-1

SMBus/IC Current/DC Power Sensor with Two Temperature Monitors

10, 20, 40, 80

±1

2.5 to 2,600

+3 to +24

1, 1

±0.25/±1

Hardware

Yes

12 pin 4 x 4 QFN

EMC1704-1

SMBus/IC Current/DC Power Sensor with Four Temperature Monitors

10, 20, 40, 80

±1

2.5 to 2,600

+3 to +24

1, 3

±0.25/±1

Software

Yes

14 pin SOIC

EMC1704-2

SMBus/IC Current/DC Power Sensor with Four Temperature Monitors

10, 20, 40, 80

±1

2.5 to 2,600

+3 to +24

1, 3

±0.25/±1

Hardware

Yes

16-pin 4 x 4 QFN

MIXED SIGNAL: Dual-Slope A/D Converters

Part #	Supply Voltage (V)	Input Voltage Range	Resolution	Sampling Rate (Conv/s)	Input Channels	Data Interface	Temperature Range (°C)	Features	Packages
TC600	± 4.5 to ± 7.5	Vss + 1.5V to Vcc - 1.5V	Up to 16 bits	4 to 10	1	3-Wire	0 to +70	Differential input range, Programmable resolution/ conversion time	18-pin PDIP, 16-pin SOIC
TC500A	± 4.5 to ± 7.5	Vss + 1.5V to Vcc - 1.5V	Up to 17 bits	4 to 10	1	3-Wiro	0 to +70	Differential input range, Programmable resolution/ conversion time	18 pin PDIP, 16 pin SOIC
TC510	± 4.5 to ± 8.5	Vss + 1.5V to Vcc - 1.5V	Up to 17 bits	4 to 10	1	3-Wiro	0 to +70	Differential input range, Programmable resolution/ conversion time, Charge pump (-V) output pin	24 pin PDIP, 24 pin SOIC
TC514	± 4.5 to ± 8.5	Vss + 1.5V to Vcc - 1.5V	Up to 17 bits	4 to 10	4	3-Wiro	0 to +70	Differential input range, Programmable resolution/ conversion time, Charge pump (-V) output pin	28 pin PDIP, 28 pin SOIC
TC520A	± 4.5 to ± 8.5	-	-	-	-	Serial port	0 to +70	Optional serial interface adapter for TC500/500A/510/514	14-pin PDIP, 16-pin SOIC
TC710B	± 4.5 to ± 8.5	Vss + 1.5V to Vcc - 1.0V	12 bits plus sign bit	2 to 10	1	Parallel or Serial port	-25 to +85	Differential input range	40 pin PDIP, 44 pin PLCC, 44 pin MOFP
TC7109A	± 4.5 to ± 8.5	Vss + 1.5V to Vcc - 1.0V	12 bits plus sign bit	2 to 10	1	Parallel or Serial port	25 to +85	Differential input range	40-pin PDIP, 44-pin PLCC, 44-pin MOFP

MIXED SIGNAL: Binary and BCD A/D Converters

Part #	Description	Supply Voltage (V)	Input Voltage Range	Resolution (Digits)	Resolution (Counts)	Max Power (mW)	Data Interface	Temperature Range (°C)	Features	Packages
TC850	Binary A/D	± 5	V_in + 1.5V to V_to - 1.5V	15-bit	± 32,76B	35	8-bit parallel	-25 to +70	Highest conversion speed (40 conv/sec)	44-pin PLCC, 40-pin PDIP
TC14433	BCD A/D	± 4.5 to ± 6	± 199.9 mV to 1.999V	312	± 2,000	20	MUXed BCD	-40 to +85	For DMM, DPM, Data loggers	24 pin SOIC, 24 pin PDIP, 28 pin PLCC
TC14433A	BCD A/D	± 4.5 to +8	± 199.9 mV to 1.999V	312	± 2,000	20	MUXed BCD	-40 to +85	For DMM, DPM, Data loggers	24-pin PDIP, 28-pin PLCC

MIXED SIGNAL: Display A/D Converters

Part #	Display Type	Supply Voltage (V)	Resolution (Digits)	Resolution (Counts)	Power (mW)	Temperature Range (°C)	Features	Packages
TC7106	LCD	9	3 12	+2,000	10	25 to +85	For DMM, DPM, Data logger applications	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7106A	LCD	9	3 12	+2,000	10	-25 to +85	For DMM, DPM, Data logger applications	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7107	LED	±5	3 12	±2,000	10	-25 to +85	For DMM, DPM, Data logger applications	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7107A	LED	±5	3 12	±2,000	10	-25 to +85	For DMM, DPM, Data logger applications	40-pin POIP, 44-pin PLCC, 44 pin MOFP
TC7116	LCD	9	3 12	±2,000	10	-25 to +85	Hold function	40-pin POIP, 44-pin PLCC, 44 pin MOFP
TC7116A	LCD	9	3 12	±2,000	10	-25 to +85	Hold function	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7117	LED	+5	3 12	+2,000	10	-25 to +85	Hold function	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7117A	LED	+5	3 12	+2,000	10	-25 to +85	Hold function	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7126	LCD	9	3 12	+2,000	0.5	25 to +85	Low-power TC7106	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7126A	LCD	9	3 12	+2,000	0.5	-25 to +85	Low-power TC7106	40-pin POIP, 44-pin PLCC, 44-pin MOFP
TC7129	LCD	9	4 12	±20,000	4.5	0 to +70	Lowest noise 43 mv'sensitivity	40-pin POIP, 44-pin PLCC, 44-pin MOFP

MIXED SIGNAL: Digital Potentiometers

Part #	# of Taps	Memory	# Per Package	Interface	Resistance (kOhms)	INL (Max)	DNL (Max)	Temperature Range (°C)	Comments Packages
MCP4011	64	Volatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Potentiometer mode	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 DFN
MCP4012	64	Volatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Rheostal mode	6-pin SOT-23
MCP4013	64	Volatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Potentiometer to Vss	8-pin SOT-23
MCP4014	64	Volatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Rheostal to Vss	5-pin SOT-23
MCP4017	128	Volatile	1	I/C	5, 10, 50, 100	0.5	0.25	-40 to +125	7-bit, Volatile, I/C digital potentiometer	6-pin SC-70
MCP4018	128	Volatile	1	I/C	5, 10, 50, 100	0.5	0.25	-40 to +125	7-bit, Volatile, I/C digital potentiometer	6-pin SC-70
MCP4019	128	Volatile	1	I/C	5, 10, 50, 100	0.5	0.25	-40 to +125	7-bit, Volatile, I/C digital potentiometer	5-pin SC-70
MCP4017	128	Volatile	1	I/C	5, 10, 50, 100	0.5	0.25	-40 to +125	7-bit, Volatile, I/C digital potentiometer	6-pin SC-70
MCP4018	128	Volatile	1	I/C	5, 9, 50, 100	0.5	0.25	-40 to +125	7-bit, Volatile, I/C digital potentiometer	6-pin SC-70
MCP4019	128	Volatile	1	I/C	5, 10, 50, 100	0.5	0.25	-40 to +1125	7-bit, Volatile, I/C digital potentiometer	5-pin SC-70
MCP4021	64	Nonvolatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Potentiometer mode, Shutdown, WiperLockTM Technology	8-pin SOIC, 8-pin MSOP, 8-pin 2 x 3 DFN
MCP4022	64	Nonvolatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Rheostat mode, Shutdown, WiperLock Technology	6-pin SOT-23
MCP4023	64	Nonvolatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Potentiometer to Vss, WiperLock Technology	8-pin SOT-23
MCP4024	64	Nonvolatile	1	Up/Down	2.1, 5, 10, 50	0.5	0.5	-40 to +125	Rheostat to Vss, Shutdown, WiperLock Technology	5-pin SOT-23
MCP4141	128	Nonvolatile	1	SPI	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin 3 x 3 DFN
MCP4142	128	Nonvolatile	1	SPI	5, 10, 50, 100	0.8	0.25	-40 to +125	Rheostal mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin 3 x 3 DFN
MCP4241	128	Nonvolatile	2	SPI	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, Shutdown, WiperLock Technology	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP, 16-pin 4 x 4 QFN
MCP4242	128	Nonvolatile	2	SPI	5, 10, 50, 100	0.8	0.25	-40 to +125	Rheostal mode, Shutdown	10-pin MSOP, 10-pin 3 x 3 DFN
MCP4131	129	Volatile	1	SPI	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin 3 x 3 DFN
MCP41HV31	128	Volatile	1	SPI	5, 10, 50, 100	0.5	0.125	-40 to +125	7-bit Volatile digital potentiometer with specified operation from 10V to 36V and SPI interface	14-pin TSSOP, 5 x 5 QFN
MCP4132	129	Volatile	1	SPI	5, 10, 50, 100	0.8	0.25	-40 to +125	Rheostal mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8-pin 3 x 3 DFN
MCP4231	128	Volatile	2	SPI	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, Shutdown, WiperLock Technology	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP, 16-pin 4 x 4 QFN
MCP4232	128	Volatile	2	SPI	5, 10, 50, 100	0.8	0.25	-40 to +125	Rheostal mode, Shutdown	10-pin MSOP, 10-pin 3 x 3 DFN
MCP41010	256	Volatile	1	SPI	10	1	1	-40 to +85	Potentiometer mode, Shutdown	6-pin PDIP, 6 pin SOIC
MCP41050	256	Volatile	1	SPI	50	1	1	-40 to +85	Potentiometer mode, Shutdown	8-pin PDIP, 8-pin SOIC
MCP41100	256	Volatile	1	SPI	100	1	1	-40 to +85	Potentiometer mode, Shutdown	8-pin PDIP, 8-pin SOIC
MCP4151	256	Volatile	1	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8 pin 3 x 3 DFN
MCP41HV51	256	Volatile	1	SPI	5, 10, 50, 100	1	0.25	-40 to +125	8-bit Volatile digital potentiometer with specified operation from 10V to 36V and SPI interface.	14-pin TSSOP, 5 x 5 QFN
MCP4152	256	Volatile	1	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8 pin 3 x 3 DFN
MCP4161	256	Nonvolatile	1	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8-pin MSOP, 8 pin 3 x 3 DFN
MCP4162	256	Nonvolatile	1	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, Shutdown	8-pin PDIP, 8-pin SOIC, 8 pin MSOP, 8 pin 3 x 3 DFN
MCP42010	256	Volatile	2	SPI	10	1	1	-40 to +85	Potentiometer mode, Shutdown	14-pin PDIP, 14-pin SOIC, 14 pin TSSOP
MCP42100	256	Volatile	2	SPI	100	1	1	-40 to +85	Potentiometer mode, Shutdown	14-pin PDIP, 14-pin SOIC, 14 pin TSSOP
MCP4251	256	Volatile	2	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, Shutdown, WiperLock Technology	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP, 16-pin 4 x 4 QFN
MCP4252	256	Volatile	2	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, Shutdown	10-pin MSOP, 10-pin 3 x 3 DFN
MCP4261	256	Nonvolatile	2	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, Shutdown, WiperLock Technology	14-pin PDIP, 14 pin SOIC, 14 pin TSSOP, 16 pin 4 x 4 QFN
MCP4262	256	Nonvolatile	2	SPI	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, Shutdown	10-pin MSOP, 10-pin 3 x 3 DFN
MCP4341	129	Nonvolatile	4	SPI	5, 10, 50, 100	0.8	0.375	-40 to +125	7-bit, Volatile potentiometer with an SPI interface	20-pin TSSOP, 20-pin 4 x 4 QFN
MCP4342	129	Nonvolatile	4	SPI	5, 10, 50, 100	0.9	0.375	-40 to +125	7-bit, Volatile rheostat with an SPI interface	14-pin TSSOP
MCP4361	257	Nonvolatile	4	SPI	5, 10, 50, 100	1	0.5	-40 to +125	8-bit, Non-volatile potentiometer with an SPI interface	20-pin TSSOP, 20-pin 4 x 4 QFN
MCP4362	257	Nonvolatile	4	SPI	5, 10, 50, 100	1	0.5	-40 to +125	8-bit, Non-volatile rheostat with an SPI interface	14 pin TSSOP
MCP4331	129	Volatile	4	SPI	5, 10, 50, 100	0.8	0.375	-40 to +125	7-bit, Volatile potentiometer with an SPI interface	20 pin TSSOP, 20 pin 4 x 4 QFN
MCP4332	129	Volatile	4	SPI	5, 10, 50, 100	0.8	0.5	-40 to +125	7-bit, Volatile rheostat with an SPI interface	14 pin TSSOP
MCP4351	257	Volatile	4	SPI	5, 10, 50, 100	1	0.5	-40 to +125	8-bit, Non-volatile potentiometer with an SPI interface	20-pin TSSOP, 20-pin 4 x 4 QFN
MCP4352	257	Volatile	4	SPI	5, 10, 50, 100	1	0.5	-40 to +125	8-bit, Non-volatile rheostat with an SPI interface	14 pin TSSOP
MCP4441	129	Nonvolatile	4	TC	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, WiperLock Technology	20 pin TSSOP, 20 pin 4 x 4 QFN
MCP4442	129	Nonvolatile	4	TC	5, 10, 50, 100	0.8	0.375	-40 to +125	Rheostat mode, WiperLock Technology	14 pin TSSOP
MCP4161	257	Nonvolatile	4	TC	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, WiperLock Technology	6-pin MSOP
MCP4162	257	Nonvolatile	4	TC	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, WiperLock Technology	14-pin TSSOP, 5 x 5 DFN
MCP4531	128	Volatile	1	TC	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode	14 pin TSSOP, 5 x 5 DFN
MCP45H31	128	Volatile	1	TC	5, 10, 50, 100	0.5	0.125	-40 to +125	7-bit volatile digital potentiometer with specified operation from 10V to 36V and PC interface	14-pin TSSOP, 16-pin 4 x 4 QFN
MCP45IV51	258	Volatile	1	TC	5, 10, 50, 100	1	0.25	-40 to +125	7-bit volatile digital potentiometer with specified operation from 10V to 36V and PC interface	8-pin MSOP

MIXED SIGNAL: Digital Potentiometers

Part #	# of Taps	Memory	# Per Package	Interface	Resistance (kOhms)	INL (Max)	DNL (Max)	Temperature Range (°C)	Comments Packages
MCP4651 128 Volatile 2 I				°C	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode	14-pin TSSOP, 16-pin 4x4 QFN
MCP4541 128 Nonvolatile 1I				°C	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, WiperLock Technology	8-pin MSOP
MCP4641 128 Nonvolatile 2 I				°C	5, 10, 50, 100	0.5	0.25	-40 to +125	Potentiometer mode, WiperLock Technology	14-pin TSSOP, 16-pin 4x4 QFN
MCP4651 256 Volatile 2 I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode	14-pin TSSOP, 16-pin 4 x 4 QFN
MCP4561 256 Nonvolatile 1I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, WiperLock Technology	8-pin MSOP
MCP4661 256 Nonvolatile 2 I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Potentiometer mode, WiperLock Technology	14-pin TSSOP, 16-pin 4 x 4 QFN
MCP4532 128 Nonvolatile 1I				°C	5, 10, 50, 100	0.8	0.375	-40 to +125	Rheostat mode	8-pin MSOP, 8-pin 3 x 3 DFN
MCP4632 128 Volatile 2 I				°C	5, 10, 50, 100	0.8	0.375	-40 to +125	Rheostat mode	10-pin MSOP, 10-pin 3 x 3 DFN
MCP4542 128 Nonvolatile 1I				°C	5, 10, 50, 100	0.8	0.375	-40 to +125	Rheostat mode, WiperLock Technology	8 pin MSOP, 8 pin 3 x 3 DFN
MCP4562 256 Volatile 1I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode	6 pin MSOP, 6 pin 3 x 3 DFN
MCP4562 256 Nonvolatile 2 I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode	10-pin MSOP, 10-pin 3 x 3 DFN
MCP4562 256 Nonvolatile 1I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, WiperLock Technology	8-pin MSOP, 8-pin 3 x 3 DFN
MCP4662 256 Nonvolatile 2 I				°C	5, 10, 50, 100	1	0.5	-40 to +125	Rheostat mode, WiperLock Technology	10-pin MSOP, 10-pin 3 x 3 DFN

MIXED SIGNAL: Frequency-to-Voltage/Voltage-to-Frequency Converters

Part #	Frequency Range (kHz)	Full Scale (ppm FS/°C)	Non-linearity (%FS)	Temperature Range (°C)	Packages
TC8400	100	± 40	± 0.05	-40 to +85	14-pin PDIP, 14-pin SOIC
TC8401	100	± 40	± 0.02	-40 to +85	14-pin PDIP, 14-pin SOIC
TC8402	100	± 100	± 0.25	-40 to +85	14 pin PDIP, 14 pin SOIC

MIXED SIGNAL: D/A Converters

Part #	Resolution (Bits)	DAC Channels	Interface	Memory	Voltage Reference	Output Setting Time (μs)	DNL (LSB)	INL (LSB)	Max Operating Current (μA)	Temperature Range (°C)	Packages
MCP47CMB01 8	1	1	C	MTP	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CMB02 8	2	1	C	MTP	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CMB11	10	1	IC	MTP	Vcc, Ext, Int	16	0.25	0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CMB12	10	2	IC	MTP	Vcc, Ext, Int	16	0.25	0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CMB21	12	1	IC	MTP	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CMB22	12	2	IC	MTP	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CVB01 8	1	1	C	Volatile	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CVB02 8	2	1	C	Volatile	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CVB11	10	1	IC	Volatile	Vcc, Ext, Int	16	±0.25	±0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CVB12	10	2	IC	Volatile	Vcc, Ext, Int	16	+0.25	+0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CVB21	12	1	IC	Volatile	Vcc, Ext, Int	16	1	1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP47CVB22	12	2	IC	Volatile	Vcc, Ext, Int	16	1	1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP48CMB01 8	1	1	C	MTP	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CMDB02 8	2	1	C	MTP	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CMB11	10	1	IC	MTP	Vcc, Ext, Int	16	0.25	0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CMB12	10	2	IC	MTP	Vcc, Ext, Int	16	0.25	0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CMDB21	12	1	IC	MTP	Vcc, Ext, Int	16	1	1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CMDB22	12	2	IC	MTP	Vcc, Ext, Int	16	1	1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CVB01 8	1	1	C	Volatile	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CVB02 8	2	1	C	Volatile	Vcc, Ext, Int	16	0.1	0.1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CVB311	10	1	IC	Volatile	Vcc, Ext, Int	16	0.25	0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CVB312	10	2	IC	Volatile	Vcc, Ext, Int	16	0.25	0.25	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CVB301	12	1	IC	Volatile	Vcc, Ext, Int	16	1	1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49CVB322	12	2	IC	Volatile	Vcc, Ext, Int	16	1	1	700	-40 to +125	10-pin 3 x 3 DFN, 16-pin 3 x 3 QFN, 10-pin MSOP
MCP49FEB01	8	1	SPi	EEPROM	Vcc, VREF, Vsc	7.8	0.25	0.5	160	-40 to +125	8-pin MSOP
MCP49FLB11	10	1	SPi	EEPROM	Vcc, VFU, Vss	7.8	0.5	1.5	160	-40 to +125	8-pin MSOP
MCP49FEB21	12	1	SPi	EEPROM	Vcc, VREF, Vsc	7.8	1	8	160	-40 to +125	8-pin MSOP
MCP49FEB02	8	2	SPi	EEPROM	Vcc, VREF, Vsc	7.8	0.25	0.5	360	-40 to +125	8-pin MSOP

MIXED SIGNAL: D/A Converters

Part #	Resolution (Bits)	DAC Channels	Interface Memory Voltage Reference			Output Setting Time (μs)	DNL (LSB) INL (LSB)		Max Operating Current (μA)	Temperature Range (°C)	Packages
MCP48FEB12	10	2	SPI	EEPROM	VDD, VREF, VBG	7.8	0.5	1.5	380	-40 to +125	8-pin MSOP
MCP49FEB22	12	2	SPI	EEPROM	VDD, VREF, VBG	7.8	1	6	380	-40 to +125	8-pin MSOP
MCP49FVB01	8	1	SPI	Volatile	VDD, VREF, VBG	7.8	0.25	0.5	180	-40 to +125	8-pin MSOP
MCP48FVB11	10	1	SPI	Volatile	VDD, VHL, VBG	7.8	0.5	1.5	180	-40 to +125	8-pin MSOP
MCP49FVB21	12	1	SPI	Volatile	VDD, VREF, VBG	7.8	1	6	180	-40 to +125	8-pin MSOP
MCP49FVB02	8	2	SPI	Volatile	VDD, VREF, VBG	7.8	0.25	0.5	380	-40 to +125	8-pin MSOP
MCP48FVB12	10	2	SPI	Volatile	VDD, VHL, VBG	7.8	0.5	1.5	380	-40 to +125	8-pin MSOP
MCP48FVB22	12	2	SPI	Volatile	VDD, VREF, VBG	7.8	1	6	380	-40 to +125	8-pin MSOP
MCP47FEB04	8	4	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FEB14	10	4	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.05	±0.4	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FEB24	12	4	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.2	±1.5	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FEB08	8	8	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FEB18	10	8	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.05	±0.4	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FEB28	12	8	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.2	±1.5	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FVB04	8	4	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.05	±0.4	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FVB24	12	4	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.2	±1.5	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FVB08	8	8	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FVB18	10	8	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.05	±0.4	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FVB28	12	8	I2C	EEPROM	VDD, VREF, VBG	7.8	±0.2	±1.5	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FEB04	8	4	SPI	EEPROM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FEB14	10	4	SPI	EEPROM	VDD, VREF, VBG	7.8	±0.05	±0.4	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FEB24	12	4	SPI	EEPROM	VDD, VREF, VBG	7.8	±0.2	±1.5	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FEB08	8	8	SPI	EEPROM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FEB18	10	8	SPI	EEPROM	VDD, VREF, VBG	7.8	±0.05	±0.4	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FEB28	12	8	SPI	EEPROM	VDD, VREF, VBG	7.8	±0.2	±1.5	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FVB04	8	4	SPI	RAM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FVB14	10	4	SPI	RAM	VDD, VREF, VBG	7.8	±0.05	±0.4	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FVB24	12	4	SPI	RAM	VDD, VREF, VBG	7.8	±0.2	±1.5	1000	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FVB08	8	8	SPI	RAM	VDD, VREF, VBG	7.8	±0.0125	±0.1	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FVB18	10	8	SPI	RAM	VDD, VREF, VBG	7.8	±0.05	±0.4	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP48FVB28	12	8	SPI	RAM	VDD, VREF, VBG	7.8	±0.2	±1.5	1800	-40 to +125	VQFN-20 5x5, TSSOP-20
MCP47FEB01	8	11	C	EEPROM	VDD, VHL, VBG	6	0.25	0.5	180	-40 to +125	8-pin MSOP
MCP47FEB11 101			C	EEPROM	VDD, VREF, VBG	6	0.5	1.5	180	-40 to +125	8-pin MSOP
MCP47FEB21 12 11			C	EEPROM	VDD, VHL, VBG	6	1	6	180	-40 to +125	8-pin MSOP
MCP47FEB02	8	21	C	EEPROM	VDD, VREF, VBG	6	0.25	0.5	380	-40 to +125	8-pin MSOP
MCP47FUB12 1021			C	ELLROM	VDD, VHL, VBG	6	0.5	1.5	380	-40 to +125	8-pin MSOP
MCP47FEB22 12 21			C	EEPROM	VDD, VREF, VBG	6	1	6	380	-40 to +125	8-pin MSOP
MCP47FVB01	8	11	C	Volatile	VDD, VHL, VBG	6	0.25	0.5	180	-40 to +125	8-pin MSOP
MCP47FVB11 101			C	Volatile	VDD, VREF, VBG	6	0.5	1.5	180	-40 to +125	8-pin MSOP
MCP47FVB21 12 11			C	Volatile	VDD, VREF, VBG	6	1	6	180	-40 to +125	8-pin MSOP
MCP47FVB02	8	21	C	Volatile	VDD, VREF, VBG	6	0.25	0.5	380	-40 to +125	8-pin MSOP
MCP47FVB12 1021			C	Volatile	VDD, VREF, VBG	6	0.25	1.5	380	-40 to +125	8-pin MSOP
MCP47FVB22 12 21			C	Volatile	VDD, VHL, VBG	6	1	6	380	-40 to +125	8-pin MSOP
MCP47DA1 8	11		C	Volatile	V-DI	6	0.35	0.7	180	-40 to +125	8-pin SOT23, 6-pin SC/7C
MCP4706	8	11	C	EEPROM	VDD, V-DI	6	0.05	0.907	430	-40 to +125	8 pin SOT23, 6 pin 2 x 2 DFN
MCP4716	101		C	EEPROM	VDD, V-FF	6	0.188	3.625	430	-40 to +125	6-pin SOT23, 6 pin 2 x 2 DFN
MCP4726	12 11		C	EEPROM	VDD, V-FF	6	0.75	14.5	430	-40 to +125	6 pin SOT23, 6 pin 2 x 2 DFN
MCP4725	12 11		C	EEPROM	VDD	6	0.75	14.5	430	-40 to +125	6 pin SOT23
MCP4728	12 41		C	EEPROM	VDD, VBR	6	0.75	13	1400	-40 to +125	10-pin MSOP
MCP4801	8	1	SPI	Volatile	VBG	4.5	0.5	1	400	-40 to +125	8-pin MSOP, 8 pin 2 x 3 DFN, 8-pin SOIC, 8 pin PDIP
MCP4811	10	1	SPI	Volatile	VBG	4.5	0.5	3.5	400	-40 to +125	8 pin MSOP, 8 pin 2 x 3 DFN, 8 pin SOIC, 8 pin PDIP

MIXED SIGNAL: D/A Converters

Part #	Resolution (Bits)	DAC Channels	Interface Memory Voltage Reference			Output Setting Time (μs)	DNL (LSB) INL (LSB)		Max Operating Current (μA)	Temperature Range (°C)	Packages
MCP4821	12	1	SPI	Volatile	Vcc	4.5	0.75	12	400	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4802	8	2	SPI	Volatile	Vcc	4.5	0.5	1	400	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4812	10	2	SPI	Volatile	Vcc	4.5	0.5	3.5	400	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4822	12	2	SPI	Volatile	Vcc	4.5	0.75	12	400	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4801	8	1	SPI	Volatile	Vcc	4.5	0.5	1	350	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4911	10	1	SPI	Volatile	Vcc	4.5	0.5	3.5	350	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4821	12	1	SPI	Volatile	Vcc	4.5	0.75	12	350	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4902	8	2	SPI	Volatile	Vcc	4.5	0.5	1	350	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4912	10	2	SPI	Volatile	Vcc	4.5	0.5	3.5	350	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP
MCP4922	12	2	SPI	Volatile	Vcc	4.5	0.75	12	350	-40 to +125	8-pin MSOP, 8-pin 2 x 3 DFN, 8-pin SOIC, 8-pin FDIP

INTERFACE AND NETWORKING

INTERFACE AND NETWORKING: CAN Products

Part #	Description and Features	Operating Voltage (V)	Temperature Range (°C)	Tx Buffers	Rx Buffers	Filters	Masks	Interrupt Output	Packages
ATA6580	CAN Transceiver with stand-by and silent mode, 5V I/O, CAN FD ready, 6 Mbps, AECQ100 Grade 1	4.5 to 5.5	-40 to +125	N/A	N/A	N/A	N/A	N/A	8-pin DFN, 8-pin SOIC
ATA6581	CAN Transceiver with stand-by mode, compatible with 3.3V and 5V microcontroller, CAN FD ready, 5 Mbps, AECQ100 Grade 1	4.5 to 5.5	-40 to +125	N/A	N/A	N/A	N/A	N/A	8-pin DFN, 8-pin SOIC
ATA6582	CAN Transceiver with stand-by and silent mode, 5V I/O, wake up pattern, CAN FD ready, 5 Mbps, AECQ100 Grade 0, 1	4.5 to 5.5	-40 to +125/+150	N/A	N/A	N/A	N/A	N/A	8-pin DFN, 8-pin SOIC
ATA6583	CAN Transceiver with stand-by mode, compatible with 3.3V and 5V microcontroller, wake up pattern, CAN FD ready, 5 Mbps, AECQ100 Grade 0, 1	4.5 to 5.5	-40 to +125/+150	N/A	N/A	N/A	N/A	N/A	8-pin DFN, 8-pin SOIC
ATA6584	CAN Transceiver with silent mode, compatible with 3.3V and 5V microcontroller, CAN FD ready, 5 Mbps, AECQ100 Grade 0, 1	4.5 to 5.5	-40 to +125/+150	N/A	N/A	N/A	N/A	N/A	8-pin DFN, 8-pin SOIC
ATA6585	Dual CAN Transceiver with stand-by mode, 5V I/O, wake up pattern, CAN FD ready, 5 Mbps, AECQ100 Grade 0, 1	4.5 to 5.5	-40 to +125/+150	N/A	N/A	N/A	N/A	N/A	14-pin DFN, 14-pin SOIC
ATA6586	CAN Transceiver with stand-by mode, compatible with 3.3V and 5V microcontroller, CAN FD ready, 2 Mbps, AECQ100 Grade 0, 1, suitable for the Japanese market	4.5 to 5.5	-40 to +125/+150	N/A	N/A	N/A	N/A	N/A	8-pin DFN, 8-pin SOIC
ATA6570	CAN Partial Networking Transceiver with Wake pin and Window Watchdog, compatible with 3.3V and 5V microcontroller, wake up frame, CAN FD ready, 5 Mbps, AECQ100 Grade 0, 1	4.55 to 28	-40 to +125/+150	N/A	N/A	N/A	N/A	N/A	14-pin DFN, 14-pin SOIC
MCP2518FD	External CAN FD Controller with SPI Interface, ISO 11986-1:2015 Compliant, 32-bit Time Stamp, Supports CAN 2.0B and CAN FD, Highly Configurable 31 FIFOs and 32 Filters	2.7 to 5.5	-40 to +150	Up to 32	Up to 32	32	32	1 to 3	14-pin DFN, 14-pin SOIC
MCP25625	Integrated High-Speed CAN Transceiver and CAN 2.0B Controller	2.7 to 5.5	-40 to +125	3	2	6	2	1	28-pin SSOP, 28-pin 6 x 6 QFN

INTERFACE AND NETWORKING: LIN Products

Part #	Description	VREG Output Voltage (V)	Operating Temp. Range (°C)	VREG Output Current (mA)	Supply Voltage Range (V)	Max Baud Rate	LIN Specification Supported	Packages
ATA663211	LIN Transceiver	-	-40 to +125	-	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	8-pin DFN, SOIC8
ATA6625	LIN Transceiver with Integrated Vinc	5.0	40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	8-pin DFN, SOIC8
ATA663201	LDO, pin compatible with ATA663231 LIN SBC	3.3	-40 to +125	85	5 to 28	-	-	8-pin DFN
ATA663203	LDO, pin compatible with ATA663254 LIN SBC	5.0	-40 to +125	85	5 to 28	-	-	8-pin DFN
ATA663231	LIN Transceiver with Integrated Vinc	3.3	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	8-pin DFN
ATA663232	LIN Transceiver with Integrated Vinc and Wake Pin	3.3	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	8-pin DFN
ATA663254	LIN Transceiver with Integrated Vinc	5.0	40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	8-pin DFN, SOIC8
ATA663255	LIN Transceiver with Integrated Vinc and Wake Pin	5.0	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	8-pin DFN

INTERFACE AND NETWORKING: LIN Products

Part # Description		Vrea Output Voltage (V)	Operating Temp. Range (°C)	Vrea Output Current (mA)	Supply Voltage Range (V)	Max Baud Rate	LIN Specification Supported Packages
ATA663331	LIN Transceiver with Integrated Vrea and 2 relay driver	3.3	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	16-pin DFN
ATA663334	LIN Transceiver with Integrated Vrea and 2 relay driver	5.0	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	16-pin DFN
ATA663431	LIN Transceiver with Integrated Vrea, WWOT	3.3	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	16-pin DFN
ATA663454	LIN Transceiver with Integrated Vrea, WWOT	5.0	-40 to +125	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	16-pin DFN
ATSAMHA1G16A-MST-B	LIN S/P with Vrea, LIN TRX and uC, 84K Flash memory	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	48-pin QFN
ATSAMHA1G15A-MST-B	LIN S/P with Vrea, LIN TRX and uC, 32K Flash memory	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	48-pin QFN
ATSAMHA1G14A-MST-B	LIN S/P with Vrea, LIN TRX and uC, 16K Flash memory	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	48-pin QFN
ATSAMI IACG18A-MZT-D	LIN S/P with Vrea, LIN TRX and uC, 64K Flash memory	3.3	-40 to +105	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	49-pin QFN
ATSAMI IACG15A-MZT-B	LIN S/P with Vrea, LIN TRX and uC, 32K Flash memory	3.3	-40 to +105	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	49-pin QFN
ATSAMHACG14A-MZT-B	LIN S/P with Vrea, LIN TRX and uC, 16K Flash memory	3.3	-40 to +105	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	48-pin QFN
ATSAMHA1E16A-MBT-B	LIN S/P with Vrea, LIN TRX and uC, 64K Flash memory	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN
ATSAMHA1E16A-MBT-B	LIN S/P with Vrea, LIN TRX and uC, 32K Flash memory	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN
ATSAMHA1E14A-MBT-B	LIN S/P with Vrea, LIN TRX and uC, 16K Flash memory	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32 pin QFN
ATSAMI IACL16A-MZT-B	LIN S/P with Vrea, LIN TRX and uC, 64K Flash memory	3.3	-40 to +105	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32 pin QFN
ATSAMHACE15A-MZT-B	LIN S/P with Vrea, LIN TRX and uC, 32K Flash memory	3.3	-40 to +105	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN
ATSAMHACE14A-MZT-B	LIN S/P with Vrea, LIN TRX and uC, 16K Flash memory	3.3	-40 to +105	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN
ATSAMHA1E14A-MBT-B510	LIN S/P with Vrea, LIN TRX and uC, 16K Flash memory, ISELED license	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN
ATSAMHA1E15A-MBT-B510	LIN S/P with Vrea, LIN TRX and uC, 32K Flash memory, ISELED license	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN
ATSAMHA1E16A-MBT-B510	LIN S/P with Vrea, LIN TRX and uC, 64K Flash memory, ISELED license	3.3	-40 to +85	85	5 to 28	20 kbaud	2.0, 2.1, 2.2, 2.2A, SAEJ2602-2	32-pin QFN

INTERFACE AND NETWORKING: Line Circuits

Part Number	Line Circuit Type	Application	Series	Loop Length	Battery Topology	Soc Interface	Output Voltage	Number of Ports
LE57D111	Access Networks	Access Network SLIC	VE560	Long	External		58	2
LE57D121	Access Networks	Access Network SLIC	VE560	Long	External		60	2
LE57D122	Access Networks	Access Network SLIC	VE560	Long	External		60	2
LE58CL02	Access Networks	Access Networks Quad SLAC	VE580	Long		PCM/MPI		4
LE58CL021	Access Networks	Access Networks Quad SLAC	VE580	Long		PCM/MPI		4
LE58CL022	Access Networks	Access Networks Quad SLAC	VE580	Long		PCM/MPI		4
LE58CL031	Access Networks	Access Networks Quad SLAC	VE580	Long		PCM/MPI		4
LE58CL061	Access Networks	Access Networks Quad SLAC	VE580	Long		PCM/MPI, OCI		4
LE58CL063	Access Networks	Access Networks Quad SLAC	VE580	Long		PCM/MPI, GCI		4
LE79112	Access Networks	Access Networks Voice Control Processor	VE790	Long		PCM/MPI		32
LE79114	Access Networks	Access Networks Voice Control Processor	VE790	Long		PCM/SPI		64
LE79124	Access Networks	NGCC Voice Control Processor	VE792	Long		PCM/SPI/GPI		72

www.microchip.com/anslog
INTERFACE AND NETWORKING: Line Circuits

Part Number	Line Circuit Type	Application	Series	Loop Length	Battery Topology	Soc Interface	Output Voltage	Number of Ports
LE79128 Access Networks NGCC Voice Control Processor VE792 Long PCM/SPI/GPI 128
LE79234	Access Networks	NGCC Voice Control Processor	VE792	Long		PCM/SPI		32
LE792386	Access Networks	NGCC Octal SLAC	VE792	Long	Fixed	PCM/MPI	140	8
LE79252	Access Networks	Access Network SLIC	VE790	Long	External		150	2
LE79271	Access Networks	NGCC SLIC	VE792	Long			150	1
LE79272	Access Networks	NGCC SLIC	VE792	Long	External		150	2
LE79Q22B1	Access Networks	Access Networks Quad SLAC	VE790	Long		PCM/MPI, GCI		4
LE79Q22B4	Access Networks	Access Networks Quad SLAC	VE790	Long		PCM/MPI, GCI		4
LE79R70	Access Networks	PBX	VE580	Short	External		67	1
LE79R79	Access Networks	PBX	VE580	Short	External		75	1
LE88010	Broadband Gateway	Broadband Gateway FXO CODEC	VE880	Short		PCM/SPI		1
LE88131	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Tracking	PCM/SPI	150	2
LE88221	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Shared	PCM/SPI	100	2
LE88231	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Tracking	PCM/SPI	150	2
LE88241	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Shared	PCM/SPI	120	2
LE88266	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Shared	PCM/SPI	100	2
LE88278	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Tracking	PCM/SPI	150	2
LE88286	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Shared	PCM/SPI	120	2
LE88508	Broadband Gateway	Broadband Gateway SLAC	VE880	Short		PCM/SPI		2
LE88630	Broadband Gateway	Broadband Gateway SLIC	VE880	Short	Tracking		150	2
LE88150	Broadband Gateway	Broadband Gateway FXS	VE880	Short	Tracking	PCM/SPI	100	1
LE88810	Broadband Gateway	Broadband Gateway SLIC	VE880	Short	Tracking		100	1
LE9530	Broadband Gateway	Broadband Gateway SLIC	VE950	Short	Tracking	Parallel	145	2
LE9540	Broadband Gateway	Broadband Gateway SLIC	VE950	Short	Tracking	Serial	145	2
LE9541	Broadband Gateway	Broadband Gateway SLIC	VE950	Short	Tracking	Serial	145	1
LE9551	Broadband Gateway	Broadband Gateway SLIC	VE950	Short	Tracking	Serial	145	1
LE9622	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Shared	PCM/SPI	120	2
LE9632	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	PCM/SPI	150	2
LE9641	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	PCM/SPI, ZSI	100	1
LE9642	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Shared	ZSI	120	2
LE9643	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	PCM/SPI, ZSI	95	1
LE9651	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	PCM/SPI, ZSI	150	1
LE9652	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	ZSI	150	2
LE9653	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	PCM/SPI, ZSI	150	1
LE9662	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Shared	ZSI	120	2
LE9672	Broadband Gateway	Broadband Gateway FXS	mISLIC	Short	Tracking	ZSI	150	2
ZL79124 Access Networks NGCC Voice Control Processor VE792 Long PCM/SPI/GPI				72
ZL792388	Access Networks	NGCC Octal SLAC	VE792	Long	Fixed	PCM/MPI	140	8
ZL792588	Access Networks	NGCC Octal SLAC	VE792	Long		PCM/MPI		8
ZL88601	Broadband Gateway	Broadband Gateway FXS	ZL880	Short	Shared	PCM/SPI	100	2
ZL88602	Broadband Gateway	Broadband Gateway FXS	ZL880	Short	Shared	PCM/SPI	120	2
ZL88701	Broadband Gateway	Broadband Gateway FXS	ZL880	Short	Tracking	PCM/SPI	100	2
ZL88702	Broadband Gateway	Broadband Gateway FXS	ZL880	Short	Tracking	PCM/SPI	150	2

INTERFACE AND NETWORKING: Line Circuits

Part Number	Line Circuit Type	Application	Series	Loop Length	Battery Topology	Soc Interface	Output Voltage	Number of Ports
ZL68801	Broadband Gateway	Broadband Gateway FXS	ZL680	Short	Shared	PCM/SPI	100

INTERFACE and Networking: Line Drivers

Part Number	Application	Series	Loop Length	Signal Power (dBm)	Number of Ports	Packages
LE87100	PLC, G.HN, HPAV 2.0	PLC	Short	15.5	1	16/VQFN
LE87251	ADSL2+, HDSL	DSL CO	Long	20.5	2	16/VQFN
LE87270	VDSL2 35c	DSL CPE	Medium/Long	14.5	1	16/VQFN
LE87271	VDSL2 35c	DSL CPE	Medium/Long	14.5	1	20/VQFN
LE87281	G.Fast 106MHz	G.fast	Short	8	1	16/VQFN
LE87282	G.Fast 106MHz	G.fast	Short	8	2	28/VQFN
LE87285	G.Fast 106 MHz/VDSL2	G.fast	Short/Medium	8 or 13	1	16/VQFN
LE87286	G.Fast 212MHz	G.fast	Short	8	1	16/VQFN
LE87290	VDSL2 35c	DSL CO	Medium	20	2	32/VQFN
LE87401	PLC, G.HN, HPW 2.0	PLC	Short	20	1	16/VQFN
LE87402	PLC, G.HN, HPW 2.0	PLC	Short	20	2	28/VQFN
LE87501	PLC, G.HN, HPW 2.0	PLC	Short	20	1	16/VQFN
LE87511	PLC, G.HN, HPW 2.0	PLC	Short	16	1	16/VQFN
LE87536	ADSL21, HDSL	DSL CO	Long	20	2	16/VQFN
LE87557	VDSL2 35c	DSL CPE	Medium	14.5	1	16/VQFN
LE87611	PLC, G.HN, HPW 2.0	PLC	Short	8	1	16/VQFN
LE87612	PLC, G.HN, HPW 2.0	PLC	Short	8	2	28/VQFN

INTERFACE AND NETWORKING: Ethernet products
Part Number Bandwidth Interface (Upstream) Wake-On-LAN EEE Temperature* Packages

Ethernet Controllers
ENC28/60 10SPI —128-pin SPDIP, SSOP, SOC, QFN
LNC624J600	10/100	SPV/Parallel	-	-	1	24-pin TQFN, QFN, 84-pin TQFN
LAN9217	10/100	16-bit Host Bus/MII	-	-	-	100-pin TQFP
LAN9219	10/100	32-bit Host Bus	-	-	1	100-pin TQFP
LAN9220/1	10/100	18-bit Host Bus	-	-	1	56-pin QFN
LAN9250	10/100	SPI, SQI4, HPI	√	√	164-pin QFN, 84-pin TQFP-EP
LAN9420	10/100	32-bit PCI 3.0	-	-	1	128-pin VTQFP
LAN99218	10/100	32-bit Host Bus	-	-	A, I	100-pin TQFP
KSZ3851	10/100	8-/16-/32-bit or SPI	√	-	A, I	32-pin QFN, 48-pin LOFP, 128-pin PQFP
KSZ3852	10/100	8-/16-/32-bit	√	√	164-pin LOFP
KSZ3411	10/100	8-/16-/32-bit or SPI	√	√	164-pin LOFP
Ethernet Bridges
LAN9500A	10/100	USB 2.0	√	-1.56-pin QFN
LAN9730	10/100	USB 2.0 (HSIC)/MII	-	-	1	56-pin QFN
LAN9512/13/14	10/100	USB 2.0	-	-	1	84-pin QFN
LAN89530	10/100	USB 2.0	√	-	A, I	56-pin QFN
LAN95/30	10/100	HSIC	√	-1.56 pin QFN
LAN7430	Gigabit	PCIe 3.1	√	√	148-pin VQFN
LAN7431	Gigabit	PCIe 3.1 RGMII	-	√	A	72-pin VQFN
LAN7500	Gigabit	USB 2.0	√	-1.56-pin QFN
LAN7600/01/50	Gigabit	USB 3.1/USB 2.0/HSIC	√	√	A, I	48-pin SQFN, 64 pin SQFN, 56 pin SQFN
Ethernet Transceivers (PHYs)
KSZ9031	Gigabit	MI/RMI/TQMII	√	-	A, I	48-/64-pin QFN
LAN9810	Gigabit	GMII	-	-	1	72-pin QFN
LAN9820	Gigabit	RGMII -1.56-pin QFN
KSZ8061	10/100	MI/RMI	√	√	A, I	32-/48-pin QFN
KSZ8061	10/100	MI/RMI	-	-	1	24-/32 pin QFN, 48-pin LOFP
KSZ8091	10/100	MI/RMI	√	√	124-/32-pin QFN, 48-pin LOFP
KSZ8051	10/100	MI/RMI	-	-	A, I	32-pin QFN
LAN8710A	10/100	MI/RMI	-	-	1	32-pin QFN
LAN8720A	10/100	RMII	-	-	1	24-pin QFN
LAN8740A	10/100	MI/RMI	√	√	132 pin QFN
LAN8741A	10/100	MI/RMI	-	√	132-pin QFN
LAN8742A	10/100	RMII	√	-1.24-pin QFN
LAN88/30	10/100	MI/RMI	-	-	A, I	32-pin QFN

INTERFACE AND NETWORKING: Ethernet products

Part #	Bandwidth	Ports	Interface (Upstream)	1588-v2	Cable Diags	100 Fx	Temperature*	Packages
EtherCAT®Controllers
LAN9252	10/100	2/3	SPI, SQIT®, 8-/10-/32-bit host bus	Clock Sync.	√	√	1	64-pin QFN, 64-pin TQFP-EP

INTERFACE AND NETWORKING: Ethernet products

Part # Bandwidth Ports Interface (Upstream) 1588-v2 Cable Diags 100 Fx Temperature* Packages
Ethernet Switches

LAN9352 10/100 2 SPI/SQVHBI				√	√	-1	72-pin QFN, 80-pin TQFP-EP
LAN9300	10/100	3	MIV/RMI/Turbo MII	-	-	√	1	56-pin QFN, /2 pin QFN
LAN99303	10/100	3	MIV/RMI/Turbo MII	-	-	√	A, I	56-pin QFN
LAN9353 10/100 3			MIV/RMI/Turbo MII	√ √	√		1	64-pin QFN, 64-pin TQFP-EP
LAN9954 10/100 3			RMI	√ √	√		1	56 pin QFN
LAN9355 10/100 3			MIV/RMI/Turbo MII	√ √	√		1	64-pin QFN, 64-pin TQFP-EP
KSZ9863	10/100	3	MIV/RMI	-	√	√	1	48-pin LQFP
KSZ9873	10/100	3	MIV/RMI	-	√	√	A, I	64-pin VQFN
KSZ9463 10/100 2			MIV/RMI	√ √	√		1	64-pin LQFP
KSZ9864	10/100	4	MIV/RMI	-	√	-	A, I	64-pin VQFN
KSZ9794	10/100	4	MIV/GMI/RGMII	-	√	-1	64-pin VQFN
KSZ9795 10/100 5GMI/RGMII/MI/RMI			-		√	-1	80-pin LQFP
KSZ9775	10/100	5	MIV/GMI/RGMII	-	√	-1	80-pin LQFP
KSZ9765	10/100	5	MII/GMI/RGMII	-	√	√	1	64-pin QFN, 80-pin LQFP
KSZ9895	10/100	5	MIV/RMI	-	√	-1	128-pin LQFP
KSZ9567 10/100	5, 7		SGMI/RGMII/MI/RMI	√	LinkVO+ with signal quality indicator	with SGMI	A, I	64-pin QFN, 128-pin LQFP
KSZ9563	10/100/1000 3		RGMI/MI/RMI	√	√	-1	64-pin VQFN
KSZ9893	10/100/1000	3	RCMI/MI/RMI	-	√	-1	64-pin VQFN
KSZ9563 10/100 3			RGMI/MI/RMI	√	√	-1	64-pin VQFN
KSZ9897	10/100/1000	8, 7	SGMI/RGMII/MI/RMI	-	√	with SGMI	1	84-pin QFN, 128-pin LQFP
KSZ9567	10/100/1000 7		SGMI/RGMII/MI/RMI	√	LinkVO+ with signal quality indicator	with SGMI	1	84-pin QFN, 128-pin LQFP
KSZ9477	10/100/1000 7		SGMI/RGMII/MI/RMI	1588 + HSR/DLR	LinkVO+ with signal quality indicator	with SGMI	1	128-pin LQFP

Note: AI products above are supported with 3.3V operating voltage 'A = Automotive temperature range, (40° to -105°C) = Industrial temperature range; (40° to +85°C)

INTERFACE AND NETWORKING: Serial Peripherals

Part #	Description	Operating Voltage (V)	Operating Temp. Range (°C)	Bus Type	Max Bus Frequency (kHz)	Features	Packages
MCP23008	8-bit I/O Port Expander	1.8 to 5.5	-40 to +85	IC	1700	Three HW address pins, HW interrupt, 25 mA source/sink capability per I/O	18-pin PDIP, 18-pin SOIC, 20-pin SSOP, 20-pin 4 x 4 QFN
MCP23S08	9-bit I/O Port Expander	1.8 to 5.5	-40 to +85	SPI	10000	Two HW address pins, HW interrupt, 25 mA source/sink capability per I/O	18-pin PDIP, 18-pin SOIC, 20-pin SSOP, 20-pin 4 x 4 QFN
MCP23008	8-bit I/O Port Expander	1.8 to 5.5	-40 to +125	IC	3400	One HW address pin, HW interrupt, 25 mA source/sink per I/O, 100 kHz, 400 kHz and 3.4 MHz IC supported	18-pin PDIP, 18-pin SOIC, 20-pin SSOP
MCP23S09	9-bit I/O Port Expander	1.8 to 5.5	-40 to +125	SPI	10000	HW interrupt, 25 mA source/sink per I/O	18-pin PDIP, 18-pin SOIC
MCP23018	16-bit I/O Port Expander	2.0 to 5.5	-40 to +85	IC	400	Three HW address inputs, HW interrupt, 25 mA source/sink capability per I/O	28-pin PDIP, 28-pin SOIC, 28-pin SSOP, 28-pin 6 x 6 QFN
MCP23017	16-bit I/O Expander	1.8 to 5.5	-40 to +125	IC	1700	Three HW address pins, 25 mA sink/source per I/O, 100 kHz, 400 kHz and 3.4 MHz IC supported, Interrupt output	28-pin PDIP, 28-pin SOIC, 28-pin SSOP, 28-pin QFN
MCP23S17	16-bit I/O Expander	1.8 to 5.5	-40 to +125	SPI	10000	Three HW address pins, 25 mA sink/source per I/O, Interrupt output	28-pin PDIP, 28-pin SOIC, 28-pin SSOP, 28-pin QFN
MCP23018	16-bit I/O Port Expander	1.8 to 5.5	-40 to +125	IC	3400	One HW address pin, 2 HW interrupts, 25 mA source/sink per I/O, 100 kHz, 400 kHz and 3.4 MHz IC supported	24-pin SSOP, 26-pin SOIC, 28-pin SDIP
MCP23S18	16-bit I/O Port Expander	1.8 to 5.5	-40 to +125	SPI	10000	Two HW interrupts, 25 mA source/sink per I/O	28-pin SOIC, 28-pin SDIP

INTERFACE AND NETWORKING: Wi-Fi ^3 Modules

Part #

Radio

Pin Count

Antenna

Frequency Range (GHz)

Sensitivity (dBm)

Power Output (dBm)

Power Consumption (mA) Tx Rx

Sleep

MAC Features

Protocols

Encryption

Interface

Packages

MRF24WG0MA

802.11 b/g

PCB

2.412-2.434

-95

+18

240

196

0.1 mA ^1

802.11 b/g, Wi-Fi Direct, SchAP, WPS

Wi-Fi Connection Manager, Announce, DNS, DONS, DHCP, FTP, HTTP, NBNS, SNMP, SNTP, SSL, TCP, UDP, ZoroConf ^2

WPA2-PSK, WPA-PSK, WEP, WPA-2-ENTERPRISE

4-wire SPI

38/Module(21.0 x 31.0 mm)

WINC1500-MR210PB

802.11 b/g/h

PCB,U.FL

2.412-2.472

-94 +18.5

250

380 μA

802.11 b/g/h, SchAP,WI-FI Direct

TCP, UDP, DHCP, A3P, HTTP, SSL, DNS

WEP, WPA, WPA2 Security

SPI,UART,IC

28/module(21.5 x 14.5 mm)

INTERFACE AND NETWORKING: Wi-Fi ^® Modules

Part # Radio

Pin Count

Antenna

Frequency Range (GHz)

Sensitivity (dBm)

Power Output (dBm)

Power Consumption (mA) Tx Rx

Sleep MAC Features Protocols Encryption Interface Packages

SAMW25 802.11

c/g/n 51-

2.412-2.472

-94 +17

250 57 380 μA

802.11b/g/n, SoftAP, Wi-Fi Direct, station mode

DHCP, DNS, TCP/IP (IPv4), UDP, HTTP, HTTPS

WEP, WPA/WPA2 Personal, TLS, SSL

SPI, UART

51/module (33.86 × 14.86 mm)

Note 1: Indicates "off" current Note 2: Supported in the provided attack

INTERFACE AND NETWORKING: High-Linearity 2.4-GHz Amplifiers

Part Number	Freq (GHz)	802.11 Standard	Description	Gain (dB)	Linear Po (dBm)	EVM (%)	Vcc (V)	Current @ Po (mA)	Package (mm)
LX5511	2.3-2.5	n	PA + PDET	26.0	20	3.0	3.3	170	16-pin QFN, 3 x 3 x 0.9
LX5535	2.4-2.5	n	PA + PDET	32.0	24.5	3.0	3.3-5	260	16-pin QFN, 3 x 3 x 0.9
LX5518	2.4-2.5	n	PA + PDET	30.0	26	3.0	3.3-5	380	16-pin QFN, 3 x 3 x 0.9
LX5602	2.4-2.5	n	PA, Filtering, PDET	30.0	26	3.0	5	440	16-pin QFN, 3 x 3 x 0.9
LX5533	2.4-2.5	ac	PA, Filtering, PDET	30.0	24	1.8	5	380	16-pin QFN, 3 x 3 x 0.9
INTERFACE AND NETWORKING: High-Linearity 5-GHz Amplifiers
LX5530	4.9-5.9	n	PA + PDET	28.0	22	3.0	3.3-5	360	16-pin QFN, 3 x 3 x 0.9
LX5531	5.15-5.85	n	PA, Filtering, PDET	33.0	25	3.0	5	380	20-pin QFN, 4 x 4 x 0.9
LX5531	5.15-5.85	ac	PA, Filtering, PDET	33.0	23	1.8	5	260	20-pin QFN, 4 x 4 x 0.9

INTERFACE AND NETWORKING: Low-Noise Amplifiers

Part Number	Freq (GHz)	802.11 Standard	Description	Gain (dB)	Noise Figure (dB)	IIP3 (dBm)	Current @ Po (mA)	Vcc (V)	Package (mm)
LX5561	2.4-2.5	b/g/n/ac	LNA	13	1.5	6.5	10.5	3.3	12-pin QFN, 2 x 2 x 0.5
LX5560	4.9-6.0	a/n/ac	LNA	12	1.7	6	9.5	3.3	12-pin QFN, 2 x 2 x 0.5
LX5563	2.4-2.5	b/g/n/ac	LNA + Bypass	14	1.3	7.5	9	3.3	6-pin DFN, 1.5 x 1.5 x 0.5
LX5575	5.15-5.85	a/n/ac	LNA + Bypass	12	1.7	12	9	3.3-5	16-pin QFN, 2.5 x 2.5 x 0.45

INTERFACE AND NETWORKING: Dual-Band Front-End Modules

Part Number	Freq (GHz)	802.11 Standard	Description	Gain (dB)	Linear Po (dBm)	EVM (%)	Vcc (V)	Current @ Po (mA)	Package (mm)
LX5591	2.4-2.5	n	Dual Band PA + PDET + LNA with Bypass + SPDT	30	18	3.0	3.3	210	QFN-28, 4x3x0.9
	2.4-2.5	ac		30	16	1.8	3.3	190
	5.15-5.85	n		27	18	3.0	3.3	280
	5.15-5.85	ac		27	16	1.8	3.3	230

INTERFACE AND NETWORKING: Single-Band, High-Linearity Front-End Modules

Part Number	Freq (GHz)	802.11 Standard	Description	Gain (dB)	Linear Po (dBm)	EVM (%)	Vcc (V)	Current @ Po (mA)	Package (mm)
LX5551	2.4-2.5 n PA + SPOT + POCT 27 18 3.03.3		140QFN-16, 3x3x0.9
LX5584A	2.4-2.5	n	PA + Log DET + LNA with Bypass + SPOT	30	19 3.03.3	200			QFN-16, 3x3x0.9
LX5584A	2.4-2.5	ac	PA + Log DET + LNA with Bypass + SPOT	30	18 1.8 3.3	200			QFN-16, 3x3x0.9
LX5584B	2.4-2.5	n	PA + Log DET + LNA with Bypass + SPOT	33	21 3.05.0	260			QFN-16, 3x3x0.9
LX5584B	2.4-2.5	ac	PA + Log DET + LNA with Bypass + SPOT	33	20 1.8 5.0	240			QFN-16, 3x3x0.9
LX5584H	2.4-2.5	n	PA + Log DET + LNA with Bypass + SPOT	33	21 3.05.0	260			QFN-16, 2.5x2.5x0.9
LX5584H	2.4-2.5	ac	PA + Log DET + LNA with Bypass + SPOT	33	20 1.8 5.0	240			QFN-16, 2.5x2.5x0.9
LX5586	5.15-5.65	n	PA + POET + LNA with Bypass + SPOT	27	17.0	3.03.3	230		QFN-16, 2.5x2.5x0.4
LX5586	5.15-5.65	ac	PA + POET + LNA with Bypass + SPOT	27	16.0	1.8	3.3	185	QFN-16, 2.5x2.5x0.4
LX5586A	5.15-5.65	n	PA + POET + LNA with Bypass + SPOT	27	17.5	3.03.3	200		QFN-16, 2.5x2.5x0.45
LX5586A	5.15-5.65	ac	PA + POET + LNA with Bypass + SPOT	27	16.5	1.8	3.3	185	QFN-16, 2.5x2.5x0.45
LX5586H	5.15-5.65	n	PA + POET + LNA with Bypass + SPOT	27	20 3.05.0	230			QFN-16, 2.5x2.5x0.45
LX5586H	5.15-5.65	ac	PA + POET + LNA with Bypass + SPOT	27	19 1.8 5.0	210			QFN-16, 2.5x2.5x0.45
LX5589A	5.15-5.65	n	PA + Log DET + LNA with Bypass + SPOT	30	18 3.03.3	210			QFN-16, 2.5x2.5x0.9
LX5589A	5.15-5.65	ac	PA + Log DET + LNA with Bypass + SPOT	30	17 1.8 3.3	180			QFN-16, 2.5x2.5x0.9
LX5589H	5.15-5.65	n	PA + Log DET + LNA with Bypass + SPOT	32	22 3.05.0	250			QFN-16, 2.5x2.5x0.9
LX5589H	5.15-5.65	ac	PA + Log DET + LNA with Bypass + SPOT	32	20 1.8 5.0	230			QFN-16, 2.5x2.5x0.9
LX5589B	5.15-5.65	n	PA + Log DET + LNA with Bypass + SPOT	32	22 3.05.0	250			QFN-16, 3x3x0.9
LX5589B	5.15-5.65	ac	PA + Log DET + LNA with Bypass + SPOT	32	20 1.8 5.0	230			QFN-16, 3x3x0.9

INTERFACE AND NETWORKING: Bluetooth® Modules

Part #	Bluetooth Spec	Module Type	No Shield Option	Rx Sensitivity (dBm)	Power Output (dBm) (typ.)	Sleep	Profiles	Interface	Pin Count	Anthenna	Packages (Dimensions)
BM62 5.0		Stereo Audio	Yes	-90	2	-	HFP, HSP, A2DP, AVRCP, SPP	UART	37	PCB	28 x 15 x 2.5 mm
BM63 5.0		Stereo Audio	No	-89	2	-	HFP, HSP, A2DP, AVRCP, SPP	UART	48	PCB	32 x 15 x 2.5 mm
BM64 5.0		Stereo Audio	Yes	-90	15	-	HFP, HSP, A2DP, AVRCP, SPP	UART, IC	43	PCB	32 x 15 x 2.5 mm
BM20	5.0	Audio	Yes	-91	4	System Off 2 μA	HFP, HSP, A2DP, AVRCP, SPP, PCAP	Analog audio cut, mic in, line in, UART	40	PCB	29 x 15 x 2.5 mm
BM23	5.0	Audio	Yes	-91	4	System Off 2 μA	HFP, HSP, A2DP, AVRCP, SPP, PCAP	PS Digital audio cut, mic in, line in, UART	43	PCB	29 x 15 x 2.5 mm
RN4670	5.0	BLE	Yes	-90	0	-	L2CAP, ATT, GATT, CAP, Integrated Public Profiles	UART, IC	33	Chip	22 x 12 x 2.4 mm
RN4671	5.0	BLE	Yes	-90	0	-	L2CAP, ATT, GATT, CAP, Integrated public profiles	UART, IC, SPI	16	Chip	11.5 x 9 x 2.1 mm
RN4678	5.0	Data, Dual Mode	Yes	-90 BR/EDR -92 LE	2	Deep Power Down 130 μA	BT3.0: CAP, SPP, SPD, RFCOMM, L2CAP BT4.2: GAP, GATT, ATT, SMP, L2CAP	UART, IC	33	Chip, RF Pac	22 x 12 x 2.4 mm
BM70 5.0		Data, Single- Mode BLE	Yes	-90	0	Power saving 1 μA	GAP, GATT, SM, L2CAP, Integrated cubic profiles	UART, IC, SPI, ADC, PWM, GPIOs	33	Chip, RF Pac	22 x 12 x 2.4 mm 25 x 12 x 1.8 mm
BM71 5.0		Data, Single- Mode BLE	Yes	-90	0	Power saving 1 μA	GAP, GATT, SM, L2CAP, Integrated cubic profiles	UART, IC, SPI, ADC, PWM, GPIOs	17	Chip, RF Pac	9 x 11.5 x 2.1 mm 6 x 8 x 1.6 mm
RN4020	4.1	Data, Single- Mode BLE	No	-92.5	7	Dormant < 700 nA, deep seep < 5.0 μA	GAP, GATT, SM, L2CAP, Integrated public profiles	UART, PIO, AIO, SPI	21	PCB	11.5 x 19.5 mm
BM78 5.0		Data, Dual Mode	Yes	-90 (BR/EDR) -92 LE	2	Deep Power Down 130 μA	BT3.0: GAP, SPP, SDP, RFCOMM, L2CAP BT4.2: GAP, GATT, ATT, SMP, L2CAP	UART, IC, GPIOs 33		Chip, RF Pac	22 x 12 x 2.4 mm 25 x 12 x 1.8 mm

INTERFACE AND NETWORKING: IEEE 802.15.4 zigbee® RF Transceiver Products

Part #

Pin Count

Antenna

Frequency Range (GHz)

Sensitivity (dBm)

Power Output (dBm)

RSSI

Tx Power Consumption (mA)

Rx Power Consumption (mA)

Clock (MHz)

Sleep MAC

MAC Features

Encryption Interface Packages

MRF24J40

2.405 to 2.48

-95

Yes

2 μA

Yes

CSMA-CA

AE5128

4 wro SPI

40 pin OFN

MRF24J40MA

PCS

2.405 to 2.48

-94

Yes

2 μA

Yes

CSMA-CA

AE5128

4 wro SPI

12/Modulo

MRF24J40MD

PCS

2.405 to 2.48

104

+19

Yes

140

10 μA

Yes

CSMA-CA

AE5128

4-wire SPI

12/Modulo

MRF24J40ME

U.FL

2.405 to 2.48

-104

+19

Yes

140

10 μA

Yes

CSMA-CA

AE5128

4 wro SPI

12/Modulo

INTERFACE AND NETWORKING: Sub-GHz Transceivers/Modules

Part #	Pin Count	Frequency Range (MHz)	Sensitivity (dBm)	Power Output (dBm)	RSSI	Tx Power Consumption (mA)	Rx Power Consumption (mA)	Clock (MHz)	Sleep	Interface	Packages
MRF89XA	32	866/31x950	-113	-12.5	Yes	25 mA @ +10 dBm	3	12.9 MHz	0.1 μA	4-wire SPI	32 pin TOFN
MRF89XAM8A	12	868	-113	-12.5	Yes	25 mA @ +10 dBm	3	12.9 MHz	0.1 μA	4-wire SPI	12/Mcure
MRF89XAM8A	12	915	-113	-12.5	Yes	25 mA @ +10 dBm	3	12.9 MHz	0.1 μA	4-wire SPI	12/Mcure

INTERFACE AND NETWORKING: Sub-GHz Transmitters

Part #	Pin Count	Frequency Range (MHz)	Modulation	Data Rate (Kbps)	Tx Power (dBm)	Operating Voltage (V)	Packages
MICRF114	6	265-445	OOK	115.2 (NRZ), 57.6 (Manchester Encoded)	10	1.8-3.6	6-pin SOT-23
MICRF113	6	300-450	ASK	20	10	1.8-3.6	6-pin SOT-23
MICRF112	10	300-450	ASK/FSK	50 (ASK), 10 (FSK)	10	1.8-3.6	10-pin MSOP, 10-pin DFN

INTERFACE AND NETWORKING: Sub-GHz Receivers

Part #	Pin Count	Frequency Range (MHz)	Modulation	Data Rate (Kbps)	Sensitivity (dBm)	RSSI	Rx Power Consumption (mA)	Sleep	Interface	Packages
MICRF219A	16	300-450	ASK/OK	20	-110	Yes	4.3	15 μA	Serial Output	16-pin OSOP
MICRF220	18	300-450	ASK/OK	20	-110	Yes	4.3	N/A	Serial Output	16-pin OSOP
MICRF221	18	650-850	ASK/OK	10	-109	Yes	9	15 μA	Serial Output	16-pin OSOP
MICRF229	16	400-450	ASK/OK	20	-112	Yes	6	15 μA	Serial Output	16-pin OSOP
MICRF230	18	400-450	ASK/OK	20	-112	Yes	6	N/A	Serial Output	16-pin OSOP

INTERFACE AND NETWORKING: MCU Transmitters

Part #	Pin Count	Frequency Range (MHz)	Program Memory (Bytes)	EEPROM (bytes)	RAM (bytes)	Digital Timer	Watch Dog Timer	Max Speed (MHz)	ICSP	Modulation	Data Rate (kbps)	Output Power (dBm)	Operating Voltage (V)	Packages
PIC12F529T39A	6	310-928	2.3K	84	201	1	1	8	Yes	OOK/FSK	100	10	2.0-3.7	14-pin TSSOP
PIC12LF1840T39A	8	310-928	7.1K	256	256	2	1	32	Yes	OOK/FSK	100	10	1.8-3.6	14-pin TSSOP
PIC16LF1824T39A	20	310-928	4K	256	256	1	1	32	Yes	OOK/FSK	100	10	1.8-3.6	20-pin TSSOP
rFPC12F675F	6	380-450	1.7K	128	64	1	1	20	Yes	ASK/FSK	40	10	2.0-5.5	20-pin SSOP
rFPC12F675H	6	850-930	1.7K	128	64	1	1	20	Yes	ASK/FSK	40	10	2.0-5.5	20-pin SSOP
rFPC12F675K	6	290-350	1.7K	128	64	1	1	20	Yes	ASK/FSK	40	10	2.0-5.5	20-pin SSOP

INTERFACE AND NETWORKING: USB Bridge Devices

Part #	USB Speed	USB Compliant	PHY	MCU Interface	Tx/Rx Buffer Size (bytes)	Number of GPIO	Operating Voltage (V)	Packages
MCP2200	Full-Speed USB (12 Mb/s), Low-Speed USB (1.5 Mb/s)	Yes	Yes	UART	129/129	8	2.7 to 5.5	20-pin SOIC, 20-pin TSSOP, 20-pin QFN
MCP2210	Full-Speed USB (12 Mb/s), Low-Speed USB (1.5 Mb/s)	Yes	Yes	SPI	64	9	3.3 to 5.5	20-pin SOIC, 20-pin TSSOP, 20-pin QFN
MCP2221	Full-Speed USB (12 Mb/s), Low-Speed USB (1.5 Mb/s)	Yes	Yes	IC	64	4	3.0 to 5.5	14-pin PDIP, 14-pin SOIC, 14-pin TSSOP, 16-pin QFN

INTERFACE AND NETWORKING: USB Products

Part #	Description	Processor Interface	# of Downstream Ports	Card Formats	Industrial Version	Packages
USB Hub Controllers
USB2412	Hi Speed USB 2.0 2-Port Hub	USB 2.0	2	-	-	28-pin QFN
USB2422	Small-lociprint, 2-Port Value Hub, Commercial and Industrial Temperature with USB Battery Charging 1.1	USB 2.0	2	-	√	24-pin QFN

INTERFACE AND NETWORKING: USB Products

Part # Description		Processor Interface # of Downstream Ports Card Formats Industrial Version Packages
USB251XB/US32617	Hi-Speed USB 2.0 Hub with Battery Charger Detection	USB 2.0	2, 3, 4, 7 port options	-	√, Automotive	36 or 64-pin QFN
USB2524	4-Port Hi-Speed USB 2.0 Multi-Switch Hub	USB 2.0 x 2	4	-	-	56-pin QFN
USB3503	3-Port Hi-Speed USB 2.0 HSIC Hub for Mobile Applications	HSIC	3	-	√	25-ball WLCSP
US33603	3-Port Hi-Speed USB 2.0 Hub for Mobile Applications	USB 2.0	3	-	√	25-ball WLCSP
USB3X13	3-Port Hi-Speed USB 2.0 Smart Hub for Mobile Applications	USB 2.0 or HSIC	3 (USB 2.0 x 2/HSIC x 1)	-	√	30-ball WLCSP
US3253X	Hi-Speed USB 2.0 Controller Hub with Battery Charger Detection	USB 2.0	2, 3, 4 port options	-	√	36-pin QFN
USB46X4 Hi-Speed USB 2.0 Controller Hub with USB and HSIC Interfaces		USB 2.0 or HSIC	4 (USB 2.0 x 4 or USB 2.0 x 2/HSIC x 2)	-√, Automotive 48-pin QFN
USB353XB	SuperSpeed USB 3.0 Hub with Battery Charger Detection	USB 3.0	2, 3, 4 or 7 port options	-	√	64 or 72-pin QFN
USB5734	SuperSpeed USB 3.1 Gen1 Smart Hub Controller with I/O Bridging and FlexConnect	USB 3.1 Gen1	4	-	√, Automotive	64-pin QFN
USB5744 SuperSpeed USB 3.1 Gen1 Small Form Factor Hub Controller		USB 3.1 Gen1	4	-	√	58-pin QFN
USB-CTM Power and Charging
UTC200X	USB-C Controller	I/O	1 DTP or 1 UFP	-	√, Automotive	18-pin QFN
USB Transceivers/Switches
US3333X	Mobile Hi-Speed USB 2.0 Transceiver with Multi-frequency Support	ULPI	-	-	√	25-ball WLCSP
US3334X	Hi-Speed USB 2.0 Transceiver with Multi-frequency Support	ULPI	-	-	Automotive	24 or 32-pin QFN
USB3300	Hi-Speed USB 2.0 Transceiver (24 MHz reference cock support)	ULPI	-	-	√	32-pin QFN
US3174CB	Hi-Speed USB 2.0 Switch with Extromely Low Power	USB 2.0	-	-	√	10 pin QFN
US3375XA-X	Hi-Speed USB 2.0 Port Protection with Switch and Charger Detection	USB 2.0	-	-	√	16-pin QFN

INTERFACE AND NETWORKING: USB Products (Continued)

Part #	Description	Processor Interface	# of Downstream Ports	Card Formats	Industrial Version	Packages
USB Flash Media Controllers
USB224X	Hi-Speed USB 2.0 Multi-Format Flash Media Controller	USB 2.0	-	SDTM/MVC/eMMC/MS/xD	√	36-pin QFN
USB225X	Hi-Speed USB 2.0 Multi-Format Flash Media Controller	USB 2.0	-	SD/MMC/eMMC/MS/xD/CF	√	128-pin VTQFP
USB264X	Hi-Speed USB 2.0 Multi-Format Flash Media Hub Controller	USB 2.0	2	SD/MMC/eMMC/MS/xD	√ (Automotive)	48-pin QFN
USB2660	Hi-Speed USB 2.0 Multi-Format Flash Media Hub Controller	USB 2.0	2	SD/MMC/eMMC/MS/xD (x2)	√	64-pin QFN
USB4640	Hi-Speed USB 2.0 Multi-Format Flash Media HSC Hub Controller	HSC	2	SD/MMC/eMMC/MS/xD	√	78-pin QFN
USB Security
SEC1110	Smart Caro Controller	USB 2.0	-	Smart Card	√	16-pin QFN
SEC1210	Smart Caro Controller with Multi-Interface Support	USB 2.0	-	Smart Card x2	√	24-pin QFN

INTERFACE AND NETWORKING: Real-Time Clock/Calendar (RTCC)

Bus	Part #	Pins	Timing Features				Memory ^1)			Power		Unique Features ^2)	5 ku Pricing ^	Packages
Bus	Part #	Pins	Digital Trimming (Adj./Range)	Alarm Settings	WDT	Outputs	SRAM (Bytes)	EEPROM (Kbits)	Protected EEPROM (bits)	Min Vcc	Min IBAT	Unique Features ^2)	5 ku Pricing ^	Packages
IC	MCP7840M	9	+127 ppm	1 sec.	-	IRQ/CLK	64	0	0	1.8	-	-	0.46	SOIC (SN), TSSOP (ST), MSOP (MS), TDFN (MNY), PDIP (F)
	MCP7840N	9	±127 ppm	1 sec.	-	IRQ/CLK	64	0	0	1.8	1.3	Power Fail Timestamp	0.59	SOIC (SN), TSSOP (ST), MSOP (MS), TDFN (MNY), PDIP (F)
	MCP7840X	9	±127 ppm	1 sec.	-	IRQ/CLK	64	0	64	1.8	1.3	Power Fail Timestamp	0.66	SOIC (SN), TSSOP (ST), MSOP (MS), TDFN (MNY)
	MCP7841X	8	±127 ppm	1 sec.	-	IRQ/CLK	64	1	64	1.8	1.3	Power Fail Timestamp	0.72	SOIC (SN), TSSOP (ST), MSOP (MS), TDFN (MNY)
	MCP7851X	10	±255 ppm	0.01 sec.	-	IRQ/CLK	64	1	128	1.8	1.3	Power Fail Timestamp	0.90	SOIC (SL), TSSOP (ST)
	MCP7852X	10	±255 ppm	0.01 sec.	-	IRQ/CLK	64	2	128	1.8	1.3	Power Fail Timestamp	0.96	MSOP (MS), TDFN (MN)
SPI	MCP785W1X	14	±255 ppm	0.01 sec.	√	1. CLK, 2. RG, 3. WDT RST	64	1	128	1.8	1.3	Power Fail Timestamp, Event Detects (× 2)	1.22	SOIC (SL), TSSOP (ST)
SPI	MCP785W2X	14	±255 ppm	0.01 sec.	√	1. CLK, 2. RG, 3. WDT RST	64	2	128	1.8	1.3	Power Fail Timestamp, Event Detects (× 2)	1.28	SOIC (SL), TSSOP (ST)

Note 1: All part numbers with an "X" have three protected ETROM programming options: [0 - Blank [0], [1 - EU-48™ MAC Address], [2 - EU-54™ MAC Address]
2: The Power Fall Timestamp in all RTCOs occur at Battery Switchover.

CO AND SMOKE DETECTOR ICS
CO AND SMOKE DETECTOR ICS: Photoelectric Smoke Detector ICs

Part #	Horn Driver Alarm Pattern	Alarm Memory	Low Battery Detection	Chamber Test	Alarm Interconnect	Sensitivity Timer	Internal POR	Alternate Diagnostic Mode	Operating Temp. Range (°C)	Packages
RE46C140	NFPA Temporal	No	Yes	Yes	Yes	Yes	Yes	-	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C141	NFPA Temporal	No	Yes	Yes	Yes	-	Yes	-	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C143	Continuous Tone	No	Yes	Yes	Yes	-	Yes	-	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C144	Continuous Tone	No	Yes	Yes	Yes	Yes	Yes	-	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C145	NFPA Temporal	No	Yes	Yes	Yes	Yes	Yes	Yes	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C165	NFPA Temporal	Yes	Yes	Yes	Yes	Yes	Yes	Yes	25 to +75	16-pin FDIP, 16-pin SOIC
RE46C166	Continuous Tone	Yes	Yes	Yes	Yes	Yes	Yes	Yes	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C167	NFPA Temporal	Yes	Yes	Yes	Yes	Yes	Yes	Yes	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C168	Continuous Tone	Yes	Yes	Yes	Yes	Yes	Yes	Yes	-25 to +75	16-pin FDIP, 16-pin SOIC
RE46C190	NFPA Temporal or Continuous Tone	Yes	Yes	Yes	Yes	Yes	Yes	-	-10 to +60	16-pin SOIC
RE46C191	NFPA Temporal or Continuous Tone	Yes	Yes	Yes	Yes	Yes	Yes	No	-10 to +60	16-pin SOIC
RE46C194	NFPA Temporal or Continuous Tone	Yes	Yes	Yes	Yes	Yes	Yes	No	0 to 60	16-pin SOIC
RE46C200	NFPA Temporal or Continuous Tone	Yes	Yes	Yes	Yes	Yes	Yes	No	-10 to +60	16-pin FDIP, 16-pin SOIC

CO AND SMOKE DETECTOR ICS: Ionization Smoke Detector ICs

Part #	Horn Driver Alarm Pattern	Alarm Memory	Low Battery Detection	Reverse Battery Protection	Alarm Interconnect	Hush Timer	Power-up Low Battery Test	Operating Temp. Range (°C)	Packages
RE46C180	NFPA Temporal or Continuous Tone	Yes	Yes	No	Yes	Yes	Yes	-10 to +60	18-pin PDIP, 16-pin SOIC
RE46C181	NFPA Temporal or Continuous Tone	Yes	Yes	No	Yes	Yes	Yes	-10 to +60	18-pin PDIP, 16-pin SOIC

CO AND SMOKE DETECTOR ICS: Ionization Smoke Detector Front Ends

Part #	Microprocessor Compatible Output	Output Options	Typical Application	Operating Temperature Range (°C)	Packages
RE46C112	Yes	Vout 1/4 of Vout or Vout 1/4 of Detect Input	3V or 3.3V Microprocessor	-10 to +60	8-pin POIP
RE46C114	Yes	Vout 1/2 of Vout or Vout 1/2 of Detect Input	5V Microprocessor	-10 to +60	8-pin POIP
RE46C311	Yes	Op Amp	Ionization Smoke Detector Front End	-10 to +60	8-pin PDIP, 8-pin SOIC
RE46C312	Yes	Op Amp	Ionization Smoke Detector Front End	-10 to +60	8-pin PDIP, 8-pin SOIC

CO AND SMOKE DETECTOR ICS: CO Detectors

Part #

Operating Voltage (Voc)

Voltage Regulator (Voc)

LED Driver

Hom Driver

Interconnect

Low Battery Detection

Brown Out

Boost Regulator

Op Amp Vos Max (μV)

Op Amp Ib Max (pA)

Op Amp GBWP (kHz)

Op Amp AoI (dB)

Op Amp Slew Rate (V/μS)

Op Amp Unity Gain Stable

Op Amp CMRR Min (dB)

Op Amp Rail-to-Rail

Operating Temp. Range (°C)

RE46C800

2 to 12

3.3

Yes

1000

200

115

0.003

Yes

In/Out

-10 to +60

RE46C803

2 to 3.6

3.3/1.8

Yes

1000

200

115

0.003

Yes

In/Out

-10 to +60

CO AND SMOKE DETECTOR ICS: Piezoelectric Horn Drivers

Part #	Operating Voltage (V)	LED Driver	Voltage Regulator (V)	Low Battery Detection	Interconnect	Power Good	Operating Temp. Range (°C)	Packages
RE46C102	6 to 18	-	-	-	-	-	-40 to +85	8-pin PDIP, 8-pin SOIC
RE46C101	6 to 18	Yes	-	-	-	-	-40 to +85	8-pin PDIP, 6-pin SOIC
RE46C104	4 to 6	-	-	-	-	-	0 to -50	14-pin PDIP, 14-pin SOIC
RE46C105	6 to 12	Yes	3.3 or 5	Yes	-	-	-40 to +85	14 pin PDIP, 14 pin SOIC
RE46C107	2 to 6	Yes	3 or 3.3	Yes	-	-	0 to -50	18-pin PDIP, 18-pin SOIC
RE46C108	6 to 12	-	3.3 or 5	-	-	-	-40 to +85	8-pin PDIP, 8-pin SOIC
RE46C109	6 to 12	-	3	Yes	Yes	Yes	-40 to +85	16-pin PDIP, 16-pin SOIC
RE46C117	2 to 6	-	-	-	-	-	0 to 160	8 pin PDIP, 8 pin SOIC
RE46C118	6 to 12	-	3	Yes	Yes	Yes	-40 to +85	18 pin PDIP, 18 pin SOIC
RE46C317	2 to 6	-	-	-	-	-	-10 to +60	8-pin PDIP, 8-pin SOIC
RE46C318	2 to 6	-	-	-	-	-	-10 to 160	8 pin PDIP, 8 pin SOIC

ULTRASOUND

ULTRASOUND: High-Voltage Analog Multiplexers

Part #	# of Ch. and Configuration	Bleed Resistor	VPP-VNN	RON (Ω)	Csg On/Off (pF)	Isw (A)	Features	Packages
HV20220	8 SPST	No	200V	22	38/12	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP, 28-Lead PLCC
HV20320	8 SPST	No	200V	22	38/12	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP
HV232	8 SPST	Yes	200V	22	38/12	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP, 28-Lead PLCC
HV219	8 SPST	No	200V	11	50/20	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP, 28-Lead PLCC
HV2201	8 SPST	No	200V	22	38/12	3	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP, 28-Lead PLCC
HV2301	8 SPST	Yes	200V	22	38/12	3	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP, 28-Lead PLCC
HV2221	8 SPST	No	Vpp range = +15V to +50V,Vpp range = -190V to -225V	15	70/18	4	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV2321	8 SPST	Yes	Vpp range = +15V to +50V,Vpp range = -190V to -225V	15	70/18	4	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV208	6 x 2:1 Mux	Yes	200V	22	38/12	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP
HV20822	2 Banks of 8 channel	No	220V	22	38/12	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP
HV238	2 Banks of 8 channel	Yes	220V	22	38/12	3	5V-12V Logic Input, 5 MHz clock frequency	48-Lead LOFP
HV2601	16 SPST	No	200V	22	38/12	3	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP, 42-Ball Bumped Die (3D)
HV2701	16 SPST	No	200V	22	38/12	3	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP, 42-Ball Bumped Die (3D)
HV2605	16 SPST	No	200V	22	13/10	3	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP, 42-Ball Bumped Die (3D)
HV2705	16 SPST	Yes	200V	22	13/10	3	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP, 42-Ball Bumped Die (3D)
HV2831	2 Banks of 8 channel	No	220V	22	38/12	2	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV2731	2 Banks of 8 channel	Yes	220V	22	38/12	2	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV2803	32 SPST	No	±6V	10	27/9	3	3.3V Input Logic, 68 MHz Clock Frequency	132-ball TFBGA 12 x 12 mm
HV2903	32 SPST	Yes-2	-6V	10	27/9	3	3.3V Input Logic, 66 MHz Clock Frequency	132-bal TFBGA 12 x 12 mm
HV2904	32 SPST	Yes-1	-6V	10	27/9	3	3.3V Input Logic, 66 MHz Clock Frequency	132-bal TFBGA 12 x 12 mm
HV2070	32 SPST	No	-6V	4.5	20/11	3.7	3.3V Input Logic, 66 MHz Clock Frequency	132-ball TFBGA 10 x 10 mm
HV2735	8 SPDT	Yes	200V	22	38/12	2	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV2661	8 x 3:1 Mux	No	200V	22	30/9	2	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV2761	8 x 3:1 Mux	Yes	200V	22	30/9	2	3.3V-5V Logic Input, 20 MHz clock frequency	48-Lead LOFP
HV2662	24 SPST	No	200V	22	12/9	2	3.3V-5V Logic Input, 20 MHz clock frequency	64-Ball VFBGA
HV2762	24 SPST	Yes	200V	22	12/9	2	3.3V-6V Logic Input, 20 MHz clock frequency	64-Ball VFBGA
HV2806	2 Banks of 16 SPDT	No	200V	22	23/9	3	3.3V-5V Logic, A/B bar Control pin	56 Lead QFN
HV2809	2 Bank of 16	No	200V	22	23/9	3	3.3V-5V Logic, A/B bar + EN Control pins	56-Lead QFN
HV2801	16 x 2:1 Mux	No	200V	22	23/9	3	3.3V-5V Logic input, 20 MHz clock frequency	64-Lead QFN
HV2901	16 x 2:1 Mux	Yes	200V	22	23/9	3	3.3V-5V Logic Input, 20 MHz clock frequency	64-Lead QFN
HV2802	32 SPST	No	200V	22	13/10	3	3.3V-5V Logic Input, 20 MHz clock frequency	9 x 9 VFBGA
HV2902	32 SPST	Yes	200V	22	13/10	3	3.3V-5V Logic Input, 20 MHz clock frequency	9 x 9 VFBGA
HV2821	16 SPST	No	300V	22	18/10	3	3.3V-5V logic input, 33 MHz clock frequency	64 Lead QFN
HV2721	16 SPST	Yes-2	300V	22	18/10	3	3.3V-5V logic input, 33 MHz clock frequency	64 Lead QFN
HV2722	16 SPST	Yes-1	300V	22	19/10	3	3.3V-5V logic input, 33 MHz clock frequency	64 Lead QFN
HV2708	16 SPST	SWA side Only	5	14	12/8	1.9A	Low Harmonic Distortion, Low Charge Injection	48L LOFP
HV2707	16 SPST	Both Sides	5	14	12/8	1.9A	Low Harmonic Distortion, Low Charge Injection	48L LOFP
HV2607	16 SPST	None	5	14	12/8	1.9A	Low Harmonic Distortion, Low Charge Injection	48L LOFP
HV2918	16 x 2:1 Mux	SW Side Only	5	6	22/4	2.7A	Low Harmonic Distortion, Low Charge Injection	QFN-64
HV2818	16 x 2:1 Mux	None	5	6	22/4	2.7A	Low Harmonic Distortion, Low Charge Injection	QFN-64

ULTRASOUND: Ultrasound MOSFET Drivers

Part #	# of Channels	Input Voltage Min. (V)	Input Voltage Max. (V)	Output Voltage Bipolar (V)	Output Voltage Unipolar (V)	Output Rise/ Fall Time	Peak Current	Application Circuit Packages
MD1210 2	1.2 6.0NA 0-12 6 ns/6 ns ±2A Pair with 1 x TC8320 4 x 4 mm 12-lead QFN
MD1211 2	1.8 5.0NA 0-12 10 ns/10 ns +2A Pair with 1 x TC6320 8-Lead SOIC
MD1213 2	1.8 5.0±50-12 6 ns/6 ns ±2A Pair with 1 x TC6320 4 x 4 mm 12-lead QFN
MD1711	12	1.8	3.3	NA	0-12	8 ns/8 ns	±2A	Pair with 6 x TC8320 to form a 2 Channel 5-Level Pulsor	7 x 7 mm 48-Lead LOFP, 7 x 7 mm 48-Lead QFN
MD1712	12	1.8	3.3	NA	0-12	8 ns/8 ns	±2A	Pair with 6 x TC8320 to form a 2 Channel 5-Level Pulsor	7 x 7 mm 48-Lead LOFP, 7 x 7 mm 48-Lead QFN
MD1715	12	1.8	3.3	NA	0-12	6.5 ns/6.5 ns	±2A	Pair with 1 x TC8320 to form a 2-Channel 5-Level Pulsor	6 x 6 mm 40-Lead QFN
MD1716	12	1.8	3.3	NA	0-12	6.5 ns/6.5 ns	±2A	Pair with 1 x TC8320 to form a 3-Channel 3-Level Pulsor	6 x 6 mm 40-Lead QFN
MD1810 41.8 5		±50-12 6 ns/8 ns ±2A						Pair with 2 x TC6320 to form a 1-Channel 4-Level Pulsor/2 Channel 2 Level Pulsor/1 Channel 3 Level Pulsor	4 x 4 mm 18-Lead QFN
MD1811	4	1.8	5	±5	0-12	8 ns/8 ns	±2A	Pair with 2 x TC8320 to form a 2 Channel 2-Level Pulsor	4 x 4 mm 16-Lead QFN
MD1812	5	1.8	5	±5	0-12	8 ns/8 ns	±2A	Pair with 1 x TC8320 and 1 x TC3320 to form a 1 Channel 3-Level Pulsor	4 x 4 mm 16-Lead QFN
MD1813	5	1.8	5	±5	0-12	8 ns/8 ns	±2A	Pair with 1 x TC6320 and 1 x TC3320 to form a 1-Channel 3-Level Pulsor	4 x 4 mm 16-Lead QFN
MD1820 41.8 5		±50-12 7 ns/7 ns ±2A						Pair with 2 x TC6320 to form a 1-Channel 4-Level Pulsor/2 Channel 2 Level Pulsor/1 Channel 3 Level Pulsor	4 x 4 mm 16-Lead QFN
MD1821	4	1.8	5	±5	0-12	7 ns/7 ns	±2A	Pair with 2 x TC8320 to form a 2-Channel 2-Level Pulsor	4 x 4 mm 16-Lead QFN
MD1822	4	1.8	5	±5	0-12	7 ns/7 ns	±2A	Pair with 2 x TC6320 to form a 1-Channel 3-Level Pulsor	4 x 4 mm 16-Lead QFN

ULTRASOUND: Ultrasound TR Switches

Part #	# of Channels	Noise (per )	Features	Packages
MD0100	1/2	0.7 nW/	± 100V Ultrasound T/R Switches	SOT-89, 4 × 46 pin DFN
MD0101	4	0.8 nW/	± 100V Ultrasound T/R Switches with Clamp Diode	5 × 5 18-pin DFN
MD0105	4	0.8 nW/	± 130V Ultrasound T/R Switches	5 × 5 18-pin DFN

ULTRASOUND: Arbitrary Waveform Generators

Part #	Output	Sampling Frequency	Features	Packages
MD2131	Push-Pull Source Drive	250 MHz	8-bit DAC, 48-step phase, PWM, 8-bit Apodibadan DAC	5 × 5 40-pin QFN
MD2134	Push-Pull Source Drive	250 MHz	8-bit DAC, 7-bit PAM, 16-Level	5 × 5 40-pin QFN

ULTRASOUND: Ultrasound Transmitters

Part #	Output Voltage (V)	Output Current (A)	Number of Channels	Features	Packages
HV748	+75	+1.25	4	4-Channel 2-Level RTZ	48-pin QFN 7 x 7 mm
HV7360	+100	+2.6	1 or 2	1-Channel 3-Level or 2-Channel 2-Level	22-pin BCA 5 x 7 mm
HV7361	±100	±2.5	1 or 2	1-Channel 3-Level or 2-Channel 2-Level with Integrated T/R	22-pin BCA 5 x 7 mm
HV7355	150	+1.5	8	8-Channel Unipolar Active RTZ	48-pin QFN 7 x 7 mm
HV7350	±90	±1.0	8	8-Channel 3-Level	56-pin QFN 8 x 8 mm
HV7351	±70	±3.0	8	8-Channel 3-Level with Built-in Digital Beamformer	50-pin QFN 11 x 11 mm
HV7321	±90	±2.5	4	4-Channel 5-level RTZ, HD2 -44 dB @ 5 MHz	64-pin VQFN 9 x 9 mm
HV7322	±90	±2.0	8	8-Channel 7-level with dual T/R	206-bal TFBCA 12 x 12 mm
HV7358	+90	+1.8	16	16-Channel 3-Level with Built-In Digital Beamformer and T/R	168-bal TFBCA 13 x 13 mm

POWER MANAGEMENT: AC/DC

Part #	Minimum Input Voltage (V)	Maximum Input Voltage (V)	Osc Frequency Min (kHz)	Osc Frequency Max (kHz)	On-Board FET?	Type of On-Board FET?	Rds,on (Max, 25C)?	Overcurrent Protection	Other Protections	Package
MCP1012	16V (Typical)	500V Continuous/700V Transient	37	63	FALSE	NA	NA	Cycle-Cycle	CCM, OVP, UVLO, OTP (Shutdown)	7/SOIC

PoE Controllers

Part # Standards Supported Ports Operating Temperature Host Interface Temperature Grade Packages
PD69210	IEEE 802.3af, IEEE 802.3af, IEEE 802.3bt, UPoE, PoH	48	-40 to +85	PC UART	Industrial	32/VQFN
PD69220	IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, UPoE, PoH	48	-40 to +85	PC UART	Industrial	32/VQFN

For a complete list of development tools, please visit www.microchip.com/development tools.

Thermal Management Products

Microchip TC1303B - Thermal Management Products - 1

MCP9600 Evaluation Board (ADM00665)

The MCP9600 Evaluation Board is used to digitize the Thermocouple EMF voltage to degree Celsius with ±1.5^ accuracy. You can easily evaluate all device features using a Type K thermocouple. The device also supports Types J, T, N, E, B, S and R. Each of these types are evaluated by replacing the Type K Thermocouple connector with the corresponding connectors (not included).

Microchip TC1303B - MCP9600 Evaluation Board (ADM00665) - 1

Thermocouple Reference Design (TMPSNSRD-TCPL1)

This reference design demonstrates how to instrument a thermocouple and accurately sense temperature over the entire thermocouple measurement range. This solution uses the MCP3421 18-bit Analog-to-Digital Converter (ADC) to measure voltage across the thermocouple.

Sensor Products

Microchip TC1303B - Sensor Products - 1

Linear Sensor Kit (LXK3301AL003)

This 100 mm linear position sensor evaluation kit comes will all you need to test out inductive technology for a linear sensor. The kit includes a 100 mm linear sensor evaluation board, a programmer that is run from our Integrated Programming and Calibration Environment (IPCE) GUI and applicable cables.

Microchip TC1303B - Linear Sensor Kit (LXK3301AL003) - 1

Rotary Sensor Kit (LXK3301AR001)

This 18 mm 120° rotary position sensor evaluation kit comes will all you need to test out inductive technology for a rotary sensor. The kit includes a rotary position sensor evaluation board, a programmer that is run from our Integrated Programming and Calibration Environment (IPCE) GUI and applicable cables.

Power Management Products

Microchip TC1303B - Power Management Products - 1

MCP19111 Evaluation Board (ADM00397)

The MCP19111 is a digitally-enhanced PWM controller. It combines a pure-analog PWM controller with a supervisory MCU making it a fast, cost-effective and configurable power conversion solution. The MCP19111 is ideal for standard power conversion, LED drivers and battery charging applications. This board demonstrates how the device operates in a synchronous buck topology over a wide input voltage and load range.

Microchip TC1303B - MCP19111 Evaluation Board (ADM00397) - 1

MCP16251 and MCP1640B Synchronous Boost Converters Evaluation Board (ADM00458)

This board demonstrates the MCP16251/MCP1640B in two boost-converter applications with multiple output voltages and was developed to help reduce product design cycle time. Three common output voltages can be selected: 2.0V, 3.3V and 5.0V.

Microchip TC1303B - MCP16251 and MCP1640B Synchronous Boost Converters Evaluation Board (ADM00458) - 1

MIC33M650 6A Step Down Module Evaluation Board (DT100107)

The boards are intended to provide a platform allowing customers to easily evaluate the features of the new MIC33M650 6A Power Modules in a buck converter application with adjustable output voltage through pin-strapping using on board jumpers. These boards are ideal for powering core supply voltages and also high-power single-cell Li-ion battery powered applications.

Microchip TC1303B - MIC33M650 6A Step Down Module Evaluation Board (DT100107) - 1

MIC33M656 6A Step Down Module Evaluation Board (DT100108)

The boards are intended to provide a platform allowing customers to easily evaluate the features of the new MIC33M656 6A Power Modules in a buck converter application with output voltage and other settings via I2C. These boards are ideal for powering core supply voltages and also high power single-cell Li-ion battery-powered applications.

Featured Analog Development Tools

For a complete list of development tools, please visit www.microchip.com/development tools.

Power Management Products (continued)

Microchip TC1303B - Power Management Products (continued) - 1

DT100105 Evaluation Board (MCP16502)

The MCP16502 Evaluation Board was developed to evaluate the capabilities of the MCP16502 High Performance Power Management Integrated Circuit (PMIC) designed for SAMA5Dx/SAM9x6 MPUs. The device features 4 DC-DC buck converters capable of delivering 1A each, 2 LDOs with 300mA current capability and I2C programable output voltages and 4 operating modes: Active, Low Power, Hibernate and High Performance Mode

Microchip TC1303B - DT100105 Evaluation Board (MCP16502) - 1

MCP1633 SEPIC LED DRIVER Demo Board (ADM01002)

The MCP1633 SEPIC LED Driver Demo Board is a step-up/step-down, switch-mode, DC/DC converter used for LED driver applications. The demo board provides a 200mA constant current source. Other output currents can be obtained with minor modifications to the board's Bill of Materials (BOM). MCP1633 LED Driver Demo Board utilizes Microchip's MCP1633 high-speed Pulse-Width Modulator (PWM). The small 16-pin QFN MCP1633 device contains all the analog components necessary for a peak current mode control loop including specialized LED driver blocks. An 8-pin PIC12F1822 microcontroller is used to implement the dimming and protection functions.

Microchip TC1303B - MCP1633 SEPIC LED DRIVER Demo Board (ADM01002) - 1

MIC23350 3A Synch Buck Regulator Evaluation Board (ADM00880)

The MIC23350 Evaluation Board is developed to evaluate and demonstrate Microchip Technology's MIC23350 product. The board features the MIC23350 in a typical Buck application supplied from an external source, between 2.4V–5.5V. Nine output voltage levels can be set via two Voltage Select pins. Test connectors allow probing, while the board can be loaded up to 3A.

Microchip TC1303B - MIC23350 3A Synch Buck Regulator Evaluation Board (ADM00880) - 1

MIC23650 6A Synch Buck Regulator Evaluation Board (ADM00885)

The MIC23650 Evaluation Board is developed to evaluate and demonstrate Microchip Technology's MIC23650 product. The board features the MIC23650 in a typical Buck application supplied from an external source, between 2.4V–5.5V. Nine output voltage levels can be set via two Voltage Select pins. Test connectors allow probing, while the board can be loaded up to 6A.

Microchip TC1303B - MIC23650 6A Synch Buck Regulator Evaluation Board (ADM00885) - 1

MCP1633 SEPIC LED DRIVER DEMO BOARD (ADM01002)

Microchip TC1303B - MCP1633 SEPIC LED DRIVER DEMO BOARD (ADM01002) - 1

MCP16501 Evaluation Board (ADM01123)

MCP16501 evaluation boards are used to evaluate the MCP16501 PMIC. This is an addition to MCP1650x brand new family of PMICs targeted for MPU power. The board will not include I2C communication, as the IC does not support this, but it will still support load transient testing and voltage setting for the channels and stability analysis testing. Dimensions are similar with the MCP16502 eval board.

Linear Products

Microchip TC1303B - Linear Products - 1

MCP6V01 Thermocouple Auto-Zeroed Reference Design Board (MCP6V01RD-TCPL)

The MCP6V01 design board demonstrates how to use a difference amplifier system to measure Electromotive Force (EMF) voltage at the cold junction of thermocouple to accurately measure temperature of the thermocouple bead. This can be done by using the MCP6V01 auto-zeroed op amp because of its ultra-low offset voltage (Vos) and high Common Mode Rejection Ratio (CMRR).

For a complete list of development tools, please visit www.microchip.com/development tools.

Linear Products (continued)

Microchip TC1303B - Linear Products (continued) - 1

MCP6N16 Evaluation Board (ADM00640)

This board is designed to provide an easy and flexible platform when evaluating the MCP6N16, a zero-drift instrumentation amplifier designed for low-voltage operation featuring rail-to-rail input and output performance. The board is populated with the MCP6N16-100, which is optimized for gains for 100V/V or higher.

Microchip TC1303B - MCP6N16 Evaluation Board (ADM00640) - 1

MCP6421 EMIRR Evaluation Board (ADM00443)

The MCP6421 EMIRR Evaluation Board is intended to support the Electromagnetic Interference Rejection Ratio (EMIRR) measurement and to show the Electromagnetic Interference (EMI) rejection capability of the MCP6421 op amp.

Mixed Signal Products

Microchip TC1303B - Mixed Signal Products - 1

MCP37X3X-200 16-bit 200 Msps ADC VTLA Evaluation Board (ADM00505)

This board provides the opportunity to evaluate the performance of the MCP37X3X-200 device family. With the on-board MCP37D31-200 16-bit 200 Msps pipelined ADC, it allows you to evaluate the functionality of the 16-bit 200 Msps ADCs and the digital signal processing features. With the help of a compatible data capture card, the evaluation board can provide you with performance analysis features through the PC GUI.

Microchip TC1303B - MCP37X3X-200 16-bit 200 Msps ADC VTLA Evaluation Board (ADM00505) - 1

PAC1921 High-Side Power and Current Monitor Evaluation Board (ADM00592)

The PAC1921 is a dedicated power monitoring device with a configurable analog output. This device is unique in that all power-related information is available on the 2-wire/I-C-compatible interface and power, current or voltage is available on the analog output. This evaluation board provides you with the means to exercise device functionality while connected either to target systems or while utilizing on-board sources.

Microchip TC1303B - PAC1921 High-Side Power and Current Monitor Evaluation Board (ADM00592) - 1

MCP39F511 Power Monitor Demonstration Board (ARM00667)

The MCP39F511 Power Monitor Demonstration Board is a fully functional single-phase power monitor and energy monitoring system. The system calculates and displays active power, reactice power, RMS current, RMS voltage, active energy (both import and export) and four quadrant reactive energy. The Power Monitor Utility Software enables you to easily experiment with all system configuration settings such as zero-cross detection, PWM output frequencies, event configurations and calibration setup.

Interface Products

Microchip TC1303B - Interface Products - 1

UCS81003 Evaluation Board (ADM00561)

This board provides the ability to evaluate the features of the UCS81003 Automotive USB Port Power Controller with Charger Emulation. It allows the UCS81003 to be tested in different configurations by populating jumpers on specific header locations. The Evaluation Board contains the MCP2221 USB to I²C bridge, which allows communication via USB between the UCS81003 and the GUI running on the PC.

Microchip TC1303B - UCS81003 Evaluation Board (ADM00561) - 1

LAN9252 EtherCAT® Device Controller Evaluation Kit with HBI PDI Interface (EVB-LAN9252-HBI)

This kit is a standalone platform to develop an EtherCAT device. It offers flexibility to explore different host bus interfaces such as 8-bit and 16-bit parallel bus, SPI and SQI ^™ .

Microchip TC1303B - LAN9252 EtherCAT® Device Controller Evaluation Kit with HBI PDI Interface (EVB-LAN9252-HBI) - 1

LAN874X 10/100 Ethernet Transceiver with EEE and Wake-On-LAN (EVB8740)

The EVB8740 is a PHY evaluation board for our LAN874X family, which integrates Energy Efficient Ethernet and Wake-on-LAN features. It interfaces to a MAC controller via a standard MII or RMII interface.

Microchip TC1303B - LAN874X 10/100 Ethernet Transceiver with EEE and Wake-On-LAN (EVB8740) - 1

USB3740 Hi-Speed USB 2.0 2-Port Switch (EVB-USB3740)

The EVB-USB3740 is used to evaluate our USB3740 USB 2.0 compliant 2-port switch. Some applications require a single USB port to be shared with other functions. The USB3740 is a small and simple 2-port switch providing system design flexibility.

Featured Analog Development Tools

For a complete list of development tools, please visit www.microchip.com/development tools.

Interface Products (continued)

Microchip TC1303B - Interface Products (continued) - 1

UTC2000 Basic USB Type-C™ Controller Evaluation Kit (EVK-UTC2000)

The EVK-UTC2000 is a complete kit to evaluate our UTC2000 basic USB-C controller. It includes a downstream-facing port dongle which can connect to any standard host, an upstream-facing port board to mimic a USB-C device, as well as a USB-C cable.

Microchip TC1303B - UTC2000 Basic USB Type-C™ Controller Evaluation Kit (EVK-UTC2000) - 1

USB5734 USB 3.1 Gen1 Controller Hub Evaluation Board (EVB-USB5734)

This board is a demonstration and evaluation platform that provides the necessary requirements and interface options for evaluating the USB5734 Smart Hub on a 4-layer RoHS-compliant PCB. This will allow you to gain an understanding of the product and accelerate integration into your design.

Microchip TC1303B - USB5734 USB 3.1 Gen1 Controller Hub Evaluation Board (EVB-USB5734) - 1

USB5926 USB 3.1 Gen1 Smart Hub with 2:1 USB-C MUX Evaluation Board (EVB-USB5926)

This board demonstrates implementation of USB Type-C ports using Microchip's UTC2000 CC pin interface controller and the USB5926's built-in 2:1 Muxes. The board supports two downstream facing USB Type-C ports along with an upstream facing USB Type-C port. The USB5926 also supports two additional downstream Type A ports for legacy purposes.

Microchip TC1303B - USB5926 USB 3.1 Gen1 Smart Hub with 2:1 USB-C MUX Evaluation Board (EVB-USB5926) - 1

MCP2515 CAN Bus Monitor Demo Board (MCP2515DM-BM)

The MCP2515 CAN Bus Monitor Demo board kit contains two identical boards that can be connected together to create a simple two-node Controller Area Network (CAN) bus, which can be controlled and/or monitored via the included PC interface. The board(s) can also be connected to an existing CAN bus.

Microchip TC1303B - MCP2515 CAN Bus Monitor Demo Board (MCP2515DM-BM) - 1

USB to UART Converter Evaluation Board (MCP2200EV-VCP)

The MCP2200EV-VCP is a USB-to-RS232 development and evaluation board for the MCP2200 USB-to-UART device. The board allows for easy demonstration and evaluation of the MCP2200. The accompanying software allows the special device features to be configured and controlled. The board is powered from USB and has a test point associated with each GPIO pin. In addition, two of these pins are connected to LEDs which can be used to indicate USB-to-UART traffic when the associated pins are configured as TxLED and RxLED pins respectively.

Total System Solutions

Microchip TC1303B - Total System Solutions - 1

ATSAMA5D27-WLSOM1 Evaluation Kit

The ATSAMA5D27-WLSOM1-EK1 is ideal for evaluating and prototyping with the SAMA5D27-WLSOM1, Wireless System On Module (SOM) and the SAMA5D27C-LD2G, LPDDR2 System In Package (SIP). The Evaluation Kit is made up of a baseboard, an ATSAMA5D27-WLSOM1 SOM soldered on the baseboard and an ATSAMA5D27C-LD2G SIP soldered on the SOM.

Microchip TC1303B - ATSAMA5D27-WLSOM1 Evaluation Kit - 1

SAMA5D27-SOM1-EK1

The ATSAMA5D27-SOM1-EK1 is a fast prototyping and evaluation platform for the SAMA5D2 based System in Packages (SiPs) and the SAMA5D27-SOM1 (SAMA5D27 System On Module). The kit comprises a baseboard with a soldered ATSAMA5D27-SOM1 module. The module features an ATSAMA5D27C-D1G-CU SIP embedding a 1-Gbit (128 MB) DDR2 DRAM. The SOM integrates a Power Management IC (PMIC), a QSPI memory, a 10/100 Mbps Ethernet PHY and a serial EEPROM with a MAC address. 128 GPIO pins are provided by the SOM for general use in the system.

Support

Microchip is committed to supporting its customers in developing products faster and more efficiently. We maintain a worldwide network of field applications engineers and technical support ready to provide product and system assistance. For more information, please visit www.microchip.com:

• Technical Support: www.microchip.com/support
- Evaluation samples of any Microchip device: www.microchip.com/sample
• Knowledge base and peer help: www.microchip.com/forums
• Sales and Global Distribution: www.microchip.com/sales

Training

If additional training interests you, Microchip offers several resources including in-depth technical training and reference material, self-paced tutorials and significant online resources.

• Overview of Technical Training Resources: www.microchip.com/training
• MASTERs Conferences: www.microchip.com/masters
• Developer Help Website: www.microchip.com/developerhelp
• Technical Training Centers: www.microchip.com/seminars

Sales Office Listing

AMERICAS

Atlanta, GA Tel: 678-957-9614

Austin, TX Tel: 512-257-3370

Boston, MA Tel: 774-760-0087

Chandler, AZ (HQ) Tel: 480-792-7200

Chicago, IL Tel: 630-285-0071

Dallas, TX Tel: 972-818-7423

Detroit, MI Tel: 248-848-4000

Houston, TX Tel: 281-894-5983

Indianapolis, IN Tel: 317-773-8323 Tel: 317-536-2380

Los Angeles, CA Tel: 949-462-9523 Tel: 951-273-7800

Raleigh, NC Tel: 919-844-7510

New York, NY Tel: 631-435-6000

San Jose, CA Tel: 408-735-9110 Tel: 408-436-4270

Canada - Toronto Tel: 905-695-1980

EUROPE

Austria - Wels Tel: 43-7242-2244-39

Denmark - Copenhagen Tel: 45-4485-5910

Finland - Espoo Tel: 358-9-4520-820

France - Paris Tel: 33-1-69-53-63-20

Germany - Garching Tel: 49-8931-9700

Germany - Haan Tel: 49-2129-3766-400 Germany - Heilbronn

Tel: 49-7131-67-3636

Germany - Karlsruhe Tel: 49-721-62537-0

Germany - Munich Tel: 49-89-627-144-0

Germany - Rosenheim Tel: 49-8031-354-560

EUROPE

Israel - Ra'anana Tel: 972-9-744-7705

Italy - Milan Tel: 39-0331-742611

Italy - Padova Tel: 39-049-7625286

Netherlands - Drunen Tel: 31-416-690399

Norway - Trondheim Tel: 47-7289-7561

Poland - Warsaw Tel: 48-22-3325737

Romania - Bucharest Tel: 40-21-407-87-50

Spain - Madrid Tel: 34-91-708-08-90

Sweden - Gothenberg Tel: 46-31-704-60-40

Sweden - Stockholm Tel: 46-8-5090-4654

UK - Wokingham Tel: 44-118-921-5800

ASIA/PACIFIC

Australia - Sydney Tel: 61-2-9868-6733

China - Beijing Tel: 86-10-8569-7000

China - Chengdu Tel: 86-28-8665-5511

China - Chongqing Tel: 86-23-8980-9588

China - Dongguan Tel: 86-769-8702-9880

China - Guangzhou Tel: 86-20-8755-8029

China - Hangzhou Tel: 86-571-8792-8115

China - Hong Kong SAR Tel: 852-2943-5100

China - Nanjing Tel: 86-25-8473-2460

China - Qingdao Tel: 86-532-8502-7355

China - Shanghai Tel: 86-21-3326-8000

China - Shenyang Tel: 86-24-2334-2829

China - Shenzhen Tel: 86-755-8864-2200

China - Suzhou Tel: 86-186-6233-1526

China - Wuhan Tel: 86-27-5980-5300

China - Xiamen Tel: 86-592-2388138

China - Xian Tel: 86-29-8833-7252

ASIA/PACIFIC

China - Zhuhai Tel: 86-756-321-0040

India - Bangalore Tel: 91-80-3090-4444

India - New Delhi Tel: 91-11-4160-8631

India - Pune Tel: 91-20-4121-0141

Japan - Osaka Tel: 81-6-6152-7160

Japan - Tokyo Tel: 81-3-6880-3770

Korea - Daegu Tel: 82-53-744-4301

Korea - Seoul Tel: 82-2-554-7200

Malaysia - Kuala Lumpur Tel: 60-3-7651-7906

Malaysia - Penang Tel: 60-4-227-8870

Philippines - Manila Tel: 63-2-634-9065

Singapore Tel: 65-6334-8870

Taiwan - Hsin Chu Tel: 886-3-577-8366

Taiwan - Kaohsiung Tel: 886-7-213-7830

Taiwan - Taipei Tel: 886-2-2508-8600

Thailand - Bangkok Tel: 66-2-694-1351

Vietnam - Ho Chi Minh Tel: 84-28-5448-2100

2/27/20

Microchip TC1303B - ASIA/PACIFIC - 1

MICROCHIP

www.microchip.com

Microchip Technology Inc. | 2355 W. Chandler Blvd. | Chandler AZ, 85224-6199

The Microchip name and logo, the Microchip logo, Hyper Speed Control, HyperLight Load and PIC are registered trademarks and WiperLock is a trademark of Microchip Technology Incorporated in the U.S.A. and other countries. USB Type-C and USB-C are trademarks of the USB Implementers Forum. All other trademarks mentioned herein are property of their respective companies. © 2020, Microchip Technology Incorporated. All Rights Reserved. 10/20 DS20001060AX
