Product Type	Kitchen Sink
Brand	Smeg
Model	LPR102
Series	Aurora
Material	Stainless Steel, Brushed Finish
Number of Bowls	1.5 (1 main + 1 half)
Main Bowl Dimensions (L x W x D)	340 x 400 x 180 mm
Half Bowl Dimensions (L x W x D)	165 x 300 x 130 mm
Overall Sink Dimensions (W x D x H)	1000 x 500 x 193 mm
Cut-out Dimensions (W x D)	980 x 480 mm
Tap Hole Diameter	35 mm
Number of Tap Holes	2
Drain Diameter	3.5 inches (89 mm)
Drain Type	Reversible
Dividing Wall Width	30 mm
Cabinet Width Required	60 cm
Gasket Type	Sealing paste
Number of Fixing Clips	10
Included Accessories	Strainer, Savespace siphon with dishwasher outlet connection, Fixing clips, Gasket, Blanking cap
Maintenance	Clean with mild soap and water; avoid abrasive cleaners
Spare Parts Availability	Accessories available separately (colanders, chopping boards, soap dispensers, waste disposals)

Frequently Asked Questions - LPR102 SMEG

What is the cabinet width required for installing the Smeg LPR102 sink?

The required cabinet width is 60 cm. The sink cut-out dimensions are 980 x 480 mm.

Can the sink be installed with a waste disposal unit?

Yes, the sink supports waste disposal units with 3.5-inch drain outlets. Optional kits like KIT FD050 (0.5 HP) and KIT FD100 (1 HP) are available.

What is the material and finish of the sink?

The sink is made of stainless steel with a brushed finish.

How many bowls does the LPR102 sink have?

It has one main bowl and one half bowl, totaling 1.5 bowls.

What are the dimensions of the main bowl?

The main bowl measures 340 mm in length, 400 mm in width, and 180 mm in depth.

Is the drain reversible?

Yes, the drain is reversible. The sink also has two tap holes for flexible installation.

What accessories are included with the sink?

Included accessories are a strainer, savespace siphon with dishwasher outlet connection, fixing clips, gasket, and blanking cap.

How do I clean and maintain the sink?

Clean with mild soap and water. Avoid abrasive cleaners or scouring pads to prevent scratching the brushed finish.

Can I install a soap dispenser on this sink?

Yes, there are optional soap dispenser kits available (e.g., KIT DS with chrome finish or KIT DSQ with square knob).

What is the overall size of the sink?

The overall dimensions are 1000 mm wide, 500 mm deep, and 193 mm high.

USER MANUAL LPR102 SMEG

Sink material Sink material Stainless steel

No. of bow IsNo. of bow Is 1 + 1/2

Draine rDraine r Reversible

EA N codeEA N code 8017709304683

Exterior view of a stainless steel kitchen sink with two circular cutouts and a blank lined panel on the right (no text or symbols)

Aesthetics

SerieSerie Aurora

Aesthetic

Johdaur

iFinishing

Universale

Stainless steel

Brushed

	Bowl typeeRHH	Bowl titlebicknesss (mm)	Bowl dirdiemeirations, W/DoDxH(h1mm)	Bowl depth (mm)	RoRidisusopener rightlabowl (mm)	Overflbow LHbowl l	Sturainer p position	Sturainer dirdiemeision
RH Bowl	Half bowl	0.7	165 x 300 x 130	130	80		Centre of bowl	3.5"
LH Bowl	Traditional	0.6	340 x 400 x 180	180	80	Yes, traditional	Side bowl	3.5"

Technical Laboratories

dimentleitkrickse ss

0,6 mm

:Fmerdepdhp(thrn)m)

13

the

193×1000×500 mm

qodu(ch(m)m)

t6utolirnelsiension

popo#d(m)m

980×480mm

TaTpo holo blichienberter

35 mm

Dividingmyawllidth

30 mm

DraDrairiedlinabiation

2^

G6skettype e

Sealing paste

Noafidips

10

Typppeobfclipss

Standard

Heigatfikotheitaltem toß mm

Boseiibsizeize

60 cm

Tap holeTap hole 2

Accessories IncludedAccessories Included

Accessories for Accessories for installa tioninstalla tion Strainer, Savespace siphon with dishwasher outlet connection, Fixing clips, Gasket, Blanking cap

Not included accessories Not included accessories

KIT FD050KIT FD050

Waste disposal 0,5 HP, Motor: 1/2 horsepower, Fits all sinks with 3 1/2" waste outlet

KIT FD100KIT FD100

Waste disposal 1 HP, Motor: 1/2 horsepower, Fits all sinks with 3 1/2" waste outlet

ST AB M IXST AB M IX

Tap stabiliser

COL19COL19

St/Steel colander to fit MINIMUM radius mm bowl, measures 200 x 410 x 26 mm

KIT DSCOTKIT DSCOT

Soap dispencer brass finishing charging from top side

KIT DSQKIT DSQ

Soap dispenser chrome finishing with square knob 40x40 mm

DB 34DB 34

St/steel drain basket to fit STD radius 340 x 400 bowl, 180 mm depth

371 3371 3

Siphon double bowls sinks (dishwasher connection included)

COL19 HCOL19 H

St/Steel colander to fit MINIMUM radius mm bowl, measures 200 x 410 x 100 mm

CB34CB34

Single wooden chopping board to fit STD radius 340 x 400 mm bowl

KIT DSKIT DS

Soap dispenser chrome finishing with round knob

CB25 M NCB25 M N

Single HPE chopping board to fit minimum radius bowls, black matt, measures 250 x 410 H 12 mm, dishwasher safe

KIT FD075KIT FD075

Waste disposal 0,75 HP, Motor: 1/2 horsepower, Fits all sinks with 3 1/2" waste outlet

KITTSSSTRAND22

2 Bowls automatic Rondò pop up waste kit with rectangular overflow and round knob

COLPTXCOLPTX

Draining rack base 300 x 185 x 82 mm

Symbols glossary (TT)Symbols glossary (TT)

Cupboard width required for sink installation Sink depth - depending on the model, the depth can be from 13 to 24.5

Sink depth - depending on the model, the depth can be from 13 to 24,5

Ultra-low profile: Installation of product with flat edge - height of 1 mm.

Thanks to the double tap hole, most of our sinks are easily reversible, giving you the flexibility to make any type of kitchen composition.
