MPH500B - Air purifier Mirage - Free user manual and instructions

Product Type	Air Purifier
Brand	Mirage
Model	MPH500B
Dimensions (H x W x D)	60 x 30 x 30 cm
Weight	5.0 kg
Power Supply	220-240V ~ 50Hz, 60W
Coverage Area	Up to 30 m²
Filtration System	Pre-filter + HEPA filter + Activated carbon filter
HEPA Filter Type	True HEPA H13
CADR (Smoke/Dust/Pollen)	200 m³/h
Air Quality Sensor	Yes (PM2.5)
Fan Speeds	3 speeds + Auto
Timer	2h, 4h, 8h
Noise Level	30 - 50 dB
Energy Efficiency Class	A
Auto Mode	Yes (based on air quality)
Sleep Mode	Yes
Child Lock	Yes
Filter Replacement Indicator	Yes
Filter Life	6-12 months
Pre-filter Cleaning	Monthly (vacuum or wash)
Auto Shut-off	When front cover is opened
Remote Control	Included (battery CR2032)
Spare Parts Available	Replacement filter set (MPH500B-Filter)
Warranty	2 years

Frequently Asked Questions - MPH500B Mirage

How often should I replace the filters?

The HEPA and carbon filters should be replaced every 6-12 months, depending on usage and air quality. The device has a filter replacement indicator that will alert you when it's time.

Can I wash the HEPA filter?

No, the HEPA filter is not washable. Only the pre-filter can be cleaned with a vacuum or by washing with water. The HEPA filter must be replaced.

What is the coverage area of the MPH500B?

The air purifier is designed for rooms up to 30 m² (approximately 320 sq ft). For best performance, keep doors and windows closed.

Is the purifier noisy?

Noise level ranges from 30 dB (sleep mode) to 50 dB (maximum speed). It's quiet enough for bedroom use at lower speeds.

Does it have a remote control?

Yes, a remote control is included. It requires a CR2032 battery (not included). The remote allows you to change fan speed, timer, and modes.

How do I reset the filter replacement indicator?

After replacing the filters, press and hold the 'Filter Reset' button for 3-5 seconds until the indicator turns off. Refer to the manual for exact steps.

Can I use the purifier 24/7?

Yes, the purifier is designed for continuous operation. The energy-efficient fan motor ensures low power consumption (60W max). Auto mode adjusts speed based on air quality.

What does the auto mode do?

Auto mode uses the built-in PM2.5 sensor to detect air quality. It automatically adjusts fan speed: low for clean air, high for polluted air. The sensor also shows real-time air quality via color-coded indicator.

Is there a child lock?

Yes, press and hold the 'Child Lock' button for 3 seconds to lock the control panel. This prevents accidental changes by children or pets.

Where can I buy replacement filters?

Replacement filters (model MPH500B-Filter) are available from authorized dealers, online retailers, and the Mirage official website. Check your local store or contact customer support.

USER MANUAL MPH500B Mirage

Two white XClear air purifiers with digital display and ventilation grilles, one emitting blue light (no text or symbols visible)

Illustration of a hand inserting a plug into a device (no text or symbols visible)

Illustration of a portable air conditioner unit with a sun symbol above it, placed on a balcony railing (no text or symbols present)

Illustration of a cylindrical device and a radio with a stylus (no text or symbols)

Simple line drawing of a container with liquid and a droplet on top, connected by a line (no text or symbols)

Illustration of a cylindrical device with a coiled cable and power plug, no text or symbols present

ADVERTENCIAS

Illustration of a plug inserted into a socket connected to a steaming container (no text or symbols)

Line drawing of a gas washing machine with a bottle and a container (no text or symbols)

Illustration of two cylindrical containers, one larger and one smaller, with no visible text or symbols.

Illustration of a hand cleaning a device with a mesh cover (no text or symbols)

Illustration of hands installing or adjusting a solar panel on a device (no text or symbols visible)

5 Coloque el filtro HEPA

Illustration of a hand holding a folded paper or sheet with a triangular shape and arrow (no text or symbols)

Illustration of a hand opening a desktop computer tower with a fan inside (no text or symbols)

Illustration of hands cleaning a large refrigerator with a cloth cover (no text or symbols)

Illustration of a refrigerator with a fan inside, showing internal components (no text or symbols)

3 Retire el filtro HEPA

Illustration of a hand opening a refrigerator with a fan inside (no text or symbols)

Illustration of hands installing or adjusting a solar panel on a device (no text or symbols visible)

9 Instale la rueda

4. Funcionamiento

Illustration of a refrigerator with a shaded cover partially inserted (no text or symbols visible)

Illustration of a hand placing a shaded rectangular object into a container (no text or symbols)

5 Retire la relilla de salida de aire

Illustration of hands cleaning a portable air conditioner unit (no text or symbols visible)

Illustration of a hand brushing a small object on a tray (no text or symbols)

Line drawing of hands cleaning a cylindrical object from a machine (no text or symbols)

Completely black image with no visible content or text.

Illustration of hands holding a folded paper or document with a directional arrow (no text or symbols)

Illustration of a hand opening a desktop computer tower with a fan inside (no text or symbols)

3 Retire el filtro HEPA

Illustration of a hand opening a fan into a computer tower (no text or symbols visible)
