ELC261D - Air-conditioner Mirage - Free user manual and instructions
Find the device manual for free ELC261D Mirage in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Split air conditioner (cooling only) |
| Cooling Capacity | 2.6 kW (9,000 BTU/h) |
| Power Supply | 220-240 V, 50 Hz, 1 phase |
| Rated Power Consumption | 800 W |
| Refrigerant | R32 (GWP 675) |
| Indoor Unit Dimensions (W×H×D) | 800 × 290 × 200 mm |
| Outdoor Unit Dimensions (W×H×D) | 800 × 550 × 320 mm |
| Indoor Unit Weight | 10 kg |
| Outdoor Unit Weight | 30 kg |
| Airflow Rate (Indoor) | 500 m³/h (max) |
| Functions | Cool, Fan, Dehumidify, Sleep Mode, Timer, Auto Restart |
| Remote Control | Included (IR, LCD display) |
| Filter Type | Washable anti-bacterial mesh filter |
| Maintenance | Clean filters every 2 weeks; annual professional check |
| Safety Features | Overload protection, self-diagnosis, child lock |
| Spare Parts Availability | Min. 10 years after discontinuation |
| Noise Level (Indoor) | 25-42 dB(A) |
| Installation Type | Wall-mounted, requires refrigerant line set |
Frequently Asked Questions - ELC261D Mirage
What is the cooling capacity of the Mirage ELC261D?
The Mirage ELC261D has a cooling capacity of 2.6 kW (9,000 BTU/h), suitable for rooms up to 25 m².
How do I clean the air conditioner filters?
Turn off and unplug the unit. Open the front panel, remove the filters, and wash them with lukewarm water using a mild detergent. Let them dry completely before reinstalling. Clean every 2 weeks for optimal performance.
Can I install the air conditioner myself?
No, installation requires a qualified technician due to refrigerant handling and electrical connections. Improper installation may cause leaks, poor performance, or void warranty.
What does the 'Sleep Mode' do?
Sleep Mode gradually adjusts the temperature (typically +1°C per hour for 2 hours) to reduce energy consumption and maintain comfortable sleeping conditions. It also minimizes fan noise.
How do I set the timer on the remote control?
Press the 'Timer' button to set the ON or OFF time. Use the '+' and '-' buttons to adjust hours. The timer can be set for 0.5 to 24 hours in 0.5-hour increments. The remote display will confirm the setting.
What do error codes E1, E2, etc. mean?
Common error codes: E1 = indoor coil sensor fault, E2 = outdoor coil sensor fault, E3 = refrigerant leak detection. Refer to the manual for a full list. If an error persists, contact a service center.
Why is the air conditioner not cooling properly?
Check if the filters are dirty, if the thermostat is set correctly, if windows/doors are closed, and if the outdoor unit is obstructed. Also ensure the unit is not in 'Fan Only' mode.
Does this unit have a heating function?
No, the Mirage ELC261D is a cooling-only model. It does not provide heating. For heating, consider a heat pump or additional heating source.
How do I replace the remote control batteries?
Slide the battery cover on the back of the remote control, remove old batteries (typically two AAA), and insert new ones with correct polarity. Dispose of old batteries properly.
What is the minimum room size recommended for this AC?
For optimal cooling, the room should be at least 15 m². Rooms smaller than 10 m² may cause short cycling and reduced comfort.
User questions about ELC261D Mirage
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Air-conditioner in PDF format for free! Find your manual ELC261D - Mirage and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. ELC261D by Mirage.
USER MANUAL ELC261D Mirage
E INSTALACIÓN
V.1121
MODELOS:
- ELF120D - CLF120D - ELC120D - CLC120D
- ELF121D - CLF121D - ELC121D - CLC121D
- ELF181E - CLF181E
- ELC181D - CLC181D
· ELF261E · CLF261E · ELC261E · CLC261E
Illustration of a person lying in bed with a medical device above (no text or symbols visible)natural_image
Simple line drawing of a car air conditioner unit and a small object (no text or symbols)natural_image
Illustration of a person using a handheld device to clean air from a large cylindrical container (no text or symbols visible)natural_image
Simple line drawing of a steam rising from a box to a container (no text or symbols)natural_image
Illustration of hands holding a cylindrical object with an arrow indicating rotation (no text or symbols)
