Instructions for use

ZEROWATT

Tante idee... zero problemi

Zerowatt per lavare

ZEROWATT washing machines meet every laundry requirement; from 5 kg up to 7 kg loading capacity by taking up minimum floor space. Even a 33 cm depth washing machine for every space problem. ZEROWATT grant "perfect washing for year and years".

Zerowatt per lavare

ed asciugare

Zerowatt washer-dryers

Thanks to the top ZEROWATT washer-dryers, no problem in having, your laundry perfectly washed and dried. These appliances have the highest performances. 7 kg washing and 4 kg drying capacity and even with the compact model of 44 cm depth you can wash 5 kg and dry 2.5 kg laundry.

Zerowatt per conservare

Zerowatt refrigerators and freezers

The complete ZEROWATT high-tech range of refrigerators and freezers is ideal to meet every requirements.

Black-and-white photo of a front-loading washing machine and its open door (no visible text or symbols)

|

COMPLIMENTI

As other millions of customers, you bought a product of high quality and reliability, which will satisfy you for years and years. More than 50 years of experience allow Zerowatt to project and realize high technical appliance, which can satisfy the most modern and demanding customers. For your next purchases, we suggest you: - Zerowatt dish-washers, - Zerowatt refrigerators and freezers

INDEX

General points on delivery

Table of Programmes

Safety Measures

Setting up and Installation

Preparing and loading clothes Detergent drawer

Control description

How to start the machine and change programme

Cleaning and routine maintenance

Trouble shooting

Technical Data

CAPITOLO CHAPTER

1

2

3

4

5

6

7

8

9

10

11

CARICO DETERSIVO
I	II		⚙
●	●	●	●
	●	●	●
	●	●	●
●	●	●	●
	●	●	●
	●	●	●
	●		●
	●		●
		●
			●
			●
●	●		●
	●		●
	●		●
	●		●
			●
			●
●	●		●
	●		●
			●

Note da considerare

FABRIC	SIMBOL ON LABEL	PROGRAM FOR	WEIGHT MAX KG. 4/5/6*	SELECT PROG.	SELECT. TEMP. °C
Resistants fabrics		Heavily soiledColor fast table cloths, towels, underwear	4/5/6	12	6090
				21	6090
Cotton, linen		RAPID PROGRAMME Heavily soiledColour fast table cloths, towels, underwear	3/4/5	3	6070
Cotton, linen, mixed resistant		Normally soiledColoured, shirts dressing gowns, sheets	4/5/6	12	4060
				21	4060
Cotton, mixed resistant		RAPID PROGRAMME Normally soiledColoured, shirts dressing gowns, sheets	3/4/5	3	4060
		Coloured moderately soiled	3/3.5/4	4	ECO 30-45
Cotton, mixed		Non fast colours, blue jeans	3/3.5/4	5	ECO 30-40
Cotton, mixed		Organic stains	-	△	-
Cotton		4 Energetic rinsing	-	6	-
Cotton, linen		Conditioner, fragrance, softener	-	7	-
		Energetic spin 📷	-	8	-
Mixed fabrics and syntheticsMixed, resistants		Heavily soiledShirts, sheets, underwear	2/3/4	92	4060
Synthetics (nylon, perfon), mixed cotton		Normal stainingShirts, blouses, skirts with resistant colours	2/3/4	101	4060
Cotton, mixed fabrics, synthetics		UniversalAll types of lightly stained laundry	2/3/4	11	ECO 30-40
Delicate synthetics		Shirts, blouses non colourfast shirts moderately soiled	2/3/4	12	30-40
Mixed delicate synthetics		3 Delicate rinsing	-	13	-
		Conditioner, fragrance, softener	-	14	-
For fabrics that do not need spine drying		Drain only	-	2	-
Very delicate fabricsSynthetics (Diction, Acrylic Trevia)		Curtains, skirts, blouses, shirts	1/2/3	152	30-40
Woolens		"MACHINE WASHABLE" woollens	1/2/3	161	ECO 30-40
Mixed delicate synthetics wool		3 Delicate rinsing	-	17	-
		Delicate spin 📷	-	18	-

B

CHARGE DETERGENT
I	II		⚙
●	●	●	●
	●	●	●
	●	●	●
●	●	●	●
	●	●	●
	●	●	●
	●		●
	●		●
		●
			●
			●
●	●		●
	●		●
	●		●
	●		●
			●
			●
●	●		●
	●		●
			●

Please, read these notes

* Washing capacity of dry clothes, according to the model used. In case of heavily soiled clothes we recommend to reduce the load by 1 ÷ 1,5 kg. in any model of w/m used.

Automatic bleaching can be carried in the programmes with the symbol, by pouring the bleach into the compartment.

1) Programme according to IEC 456. 2) Pre-wash included into the programme.

Note

9

GB

CHAPTER 3

TABLE OF PROGRAMMES - For the MODELS 800 ÷ 1000 ÷ 1200 rpm spin speed

FABRIC	SIMBOL ON LABEL	PROGRAM FOR	WEIGHT MAX KG. 4/5/6 *	SELECT PROG.	SELECT TEMP. °C
For any heavily soiled clothes		Pre-washing	3/4/5	1	35
For fabrics that do not need spin drying		Drain only	-	2	-
Resistant fabrics Cotton, linen	95°	Heavily soiledColour fast table cloths, towels, underwear	4/5/6	3	60-90
	60°	Normally soiledColoured, shirts dressing gowns, sheets	4/5/6	3	40-60
	40°	Delicate colours " Coloured, shirts dressing gowns, sheets	4/5/6	3	30-40
Cotton, mixed resistants Cotton mixed	60°	Normally soiledColoured, shirts dressing gowns, sheets	4/5/6	4	ECO 30-60
	40°	Delicate washingColoured moderately soiled	3/3.5/4	5	ECO 30-40
Cotton mixed		Organic stains	-	6	-
Cotton		4 Energetic rinsingConditioner, fragrance, softener	-	7	-
Cotton		3 Brief rinsingConditioner, fragrance, softener	-	8	-
Cotton, linen		Energetic spin	-	9	-
Mixed fabrics and synthetics Cotton, mixed fabrics, synthetics	60°	Heavily soiled Shirts, sheets, underwear	2/3/4	10	40-60
	50°	Heavily soiled All types of lightly stained laundry	2/3/4	10	30-50
Cotton, mixed fabrics synthetics	40°	Warm mixed washingShirts, blouses, skirts with resistant colours	2/3/4	11	ECO 30-40
Delicate synthetics		Cold mixed washing	2/3/4	12	-
Mixed delicate synthetics		3 Delicate rinsing Conditioner, fragrance, softener	-	13	-
		Delicate spin	-	14	-
Very delicate fabrics Synthetics (Drain, Acryl Tevra)	40°	Warm delicate washing Wool and curtains	1/2/3	15	ECO 30-40
Woolens		Cold wasing	1/2/3	16	-
		3 Delicate rinsing Conditioner, fragrance, softener	-	17	-
		Delicate spin	-	18	-

10

CHARGE DETERGENT
I	II	△	#
●
	●	●	●
	●	●	●
	●		●
	●		●
	●		●
		●
			●
			●
	●		●
	●		●
	●		●
	●		●
	●		●
			●
	●		●
	●		●
			●

Please, read these notes

★ Washing capacity of dry clothes, according to the model used. In case of heavily soiled clothes we recommend to reduce the load by 1 ÷ 1,5 kg. in any model of w/m used.

Automatic bleaching can be carried in the programmes with the symbol, by pouring the bleach into the compartment.

1) Programme according to IEC 456.

Programme 1: Pre-washing

Can be used for any heavily soiled clothes we recommend to use it before programs 3 - 10 - 15.

At the end of the cycle the machine stops and then it is ready for a further programme.

Note

ELECTRICAL SUPPLY AND SAFETY INSTRUCTIONS

Our washing machines are supplied to operate at 220-230 V, 50 Hz. Make sure that the power rating is at least 3 Kw. Then connect the plug to a suitable 10 A earthed socket. Make sure that it is properly earthed. Your socket and the washing machine plug must be of the same kind. We would generally not recommend the use of multiple plug adapters or extension leads. Zerowatt washing machines are manufactured to IMQ institute safety requirements.

The use of any appliance requires that some basic rules be observed, in order to ensure personal safety; for example: - do not touch the machine by wet hands or feet.

- do not use the machine when you are bare foot; - do not use extension leads in the bathroom unless special care is taken;

- do not expose the machine in the open air (under rain, sunshine or other).

WARNING The machine is equipped with devices against radio interferences, according to the current laws. In case the machine is not connected with the earthing, the manufacturer is not responsible for any damage to persons or properties caused by some faulty or uncomplete earthing.

Illustration of household appliances including a washing machine, a windmill, a sun, and a microwave (no text or symbols)

1

CAPITOLO 5

MESSA IN OPERA INSTALLAZIONE

SETTING UP INSTALLATION

After taking the machine out of its packing, proceed as follows:

Work on the back side of the machine 1) Unscrew the central rod A, the 2 side screws C and remove the bar D. and the relevant plastic spacer. 2) Unscrew the two rods B and remove them. N° 2 or N° 4 plastic spacers will fall inside the machine. 3) By lifting the machine, remove the above mentioned plastic spacers. 4) Stop the holes using the plugs that you will find inside the bag containing the instruction booklet. Use front feet to level the machine with the floor. Place the machine which is fitted with 2 adjustable feet in position.

Important!! If the appliance is going to be installed on a carpet or rug, make sure that the ventilation grille in the base of the machine is not blocked.

WARNING! Keep bar and bolts for use again during transport. The manufacturer is not responsible for possible damage caused to the machine by non use of the transit fixings during transport.

A B C D E F G

Remove the back panel G by loosening the screws. Remove the plugs I, take the outlet hose and put it into the hole that you want to use, after having removed the plug H. To insert into the holes two clips F. If you choose the outlet to be positioned on the opposite side of the cabinet, fasten the hose by passing it under the two clips F on the lower edge, making sure that the hose is kept well-straight. To high ten the clips Stop the hole that is still open, using the plug H. Finally, fasten the hose on the outer side of the cabinet using the semi-plugs I and then reposition the back panel G.

SERVICE CENTER

In the case of a breakdown and/or incorrect functioning, turn the appliance off and do not tamper with it. Only contact an Official Service Centre and ask for original spare parts. If you fail to follow this advice you may compromise the safety of the appliance.

Technical diagram of a mechanical assembly with labeled components and force indicators

Simple line drawing of a person standing beside a washing machine with a question mark, no text or symbols present.

To select the wash programme suited to type of clothes and degree of soiling, see the TABLE OF PROGRAMMES in the initial part of this booklet. But there are some stains which are particularly difficult to remove. In these cases you should act as follows:

TYPE OF STAINS	SOLUTION
Pen, band for type-writer, copying pencil, carbon paper	Pretreat with a liquid detergent. Rub the stain lightly with a cotton sheet soaked with alcohol. In the case of an old stain, use a bleaching element or rinse-aid according to the type of clothes.
Perspiration	Difficult to remove, but you can try with just cold water, or rinsing them with cold water and vinegar or with some ammonia and alcohol in equal quantities.
Industrial dirt (collars and cuffs)	Treat the dirtiest part with a liquid detergent before washing in a washing machine
Varnish	Remove these stains with oil of turpentine, and then sponge all the traces out with talc.
Sugar	If the stains are old and dry, soften them with steam and then wash. If it is wool, silk or not strong colours, remove the sugar stains by rinsing them with cold water.
Chewing gum	Rub with an ice cube and scrape. Rinse with benzine.
Nail-polish and glue	Dab with a cotton bud soaked with acetone.
Tar	Rinse the stain with trichloroethylene and oil of turpentine.

Get the best results from your new Zerowatt machine

To ensure you get the best results from your new Zerowatt machine it is important to use the right detergent in your everyday wash. There are many detergents available in the market and making a choice from the wide range available can often be confusing. At Zerowatt we regularly test many different types of detergent to assess which give the best wash results in our machines. We found only one brand always lives up to our exacting standards and provides outstanding cleaning across a broad range of dirt and stains, as well as providing high levels of fabric care. That's why Zerowatt gave Ariel their official seal of approval.

20

1

GB

CARICO DEI DETERSIVI E DEGLI ADDITIVI

WASHING POWDERS AND RINSE-AIDS

The machine is fitted with a 4 compartment soap dispenser drawer:

= prewash powders

II = wash powders

△ = bleach

= fabric conditioners

Gently pull out the dispenser drawer by the handle.

Place the required washing powder and rinse-aids in the compartment for the

programme selected

referring to the washing chart. For the softeners do not fill over the level indicated by the grid in compartments △ and ⚙.

If you use liquid detergents, follow the instructions of the manufacturers.

After placing the powder and before starting the machine, firmly push in the drawer.

WARNING! Do not use any bleaching agents in the soft programmes.

To obtain better results in your wash, we recommend that you do not use any powder which has got damp, and has a lumpy appearance.

Powders and rinse-aids must be used in the quantities suggested by the manufactures, and however not over the following rates:

- abt. 60 gr. powder into pre-wash and was compartments;

-abt. 100 gr. bleach into the bleach compartment △;

- abt. 50 cc. rinse aid into the opposite compartment

21

Technical diagram of a mechanical device with numbered components for identification

To avoid unnecessary and possibly expensive service calls, before requesting service it is in your interest to make the following checks:

FAULT	CAUSE	REMEDY
A If the machine does not start make sure that:	The plug is not in the socket.Electricity is off.The door is open.On/off button not pressed.	Put the plug into the socket.Please check.Close the door properly.Press the on/off button.
B If the machine does not fill with water check that:	See point A.The tap is off.Programme wrongly selected.	Please check.Turn the tap on.Select the programme properly.
C If the machine does not drain or spin make sure that:	The drain hose is bent.The filter is clogged.	Set the drain hose.Clean the filter.
D If the machine fills with water and leaks continuously:	Leak from the gasket of water fill hose.	Replace the gasket.
E If the machine is noisy or not resting evenly on the floor make sure that:	The machine is not perfectly level.The machine hasn't been properly unpacked.The machine hasn't been loaded evenly.	Adjust the feet properly.Follow the instructions.Load the machine in a more even way.
F If the machine does not spin check that:	See point C."Spin exclusion" connected	See point C.Release "Spin exclusion" button.
G Excessive vibration during spin sequence	Machine not levelled.Transit straps not removed.Laundry badly loaded	Adjust front levelling feetRemove strap.Check quantity & positioning.

I	GB
CAPITOLO 11	CHAPTER 11

E 1000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000

Note: As far as the electric data are concerned, see the label on the front part of the washing machines cabinet (near the door)
CE This appliance complies with Directives 89/336/EEC, 73/23/EEC and following changes.
