Product Type	Built-in Microwave Oven
Brand	Beko
Model	HMM6420W
Color	White
Dimensions (W x H x D)	595 x 385 x 388 mm
Oven Capacity	40 Liters
Net Weight	25 kg
Power Supply	230 V, 50 Hz
Total Power Consumption	1450 W
Microwave Power	900 W
Grill Power	1000 W
Convection Power	1200 W
Functions	Microwave, Grill, Convection, Combi, Defrost, Auto Cook
Control Type	Electronic with Digital Display
Door Opening	Left hinged
Interior Coating	Easy-clean Enamel
Child Lock	Yes
Safety Features	Door Interlock, Overheat Protection
Spare Parts Availability	Authorized service centers
Cleaning Instructions	Wipe with damp cloth; avoid abrasive cleaners

Frequently Asked Questions - HMM6420W BEKO

How do I set the clock on my Beko HMM6420W microwave?

To set the clock, press the Clock button. Use the time selector to set the hour and minute, then press Clock again to confirm. The time will appear on the display.

What types of containers are safe to use in the microwave?

Only use microwave-safe containers such as glass, ceramic, and microwave-safe plastic. Avoid metal containers and aluminum foil as they can cause sparks.

How do I defrost food using the microwave?

Place the food on a microwave-safe plate. Press the Defrost button, enter the weight, and press Start. The microwave will automatically set time and power for defrosting.

What is the maximum operating time for continuous use?

The maximum continuous operating time is 90 minutes. If longer time is needed, restart the microwave after a brief pause.

How do I clean the interior of the microwave?

Wipe the interior with a damp cloth and mild detergent. For stubborn stains, heat a cup of water with lemon juice for a few minutes to loosen residues. Do not use abrasive cleaners.

Can I use the grill and microwave functions together?

Yes, you can use combination cooking. Select Combi mode to cook with microwave and grill simultaneously for faster browning.

Why does the microwave display show 'Error'?

An error code indicates a malfunction. Common causes include power surges, door not closed properly, or internal sensor issues. Try resetting the circuit breaker. If persists, contact an authorized service.

How do I activate the child lock?

Press and hold the Stop/Cancel button for 3 seconds until the lock icon appears on the display. To deactivate, repeat the same step.

What are the recommended power levels for different foods?

Use High (100%) for beverages and vegetables, Medium (50%) for reheating and defrosting, and Low (20%) for gentle warming.

How can I replace the microwave's light bulb?

The internal light bulb is replaceable. Unplug the microwave, remove the cover grille, and replace with a 20-25W, 230V screw-type bulb. For safety, consult the manual or a professional.

USER MANUAL HMM6420W BEKO

White and gray milkshake mixer with whisk, no visible text or symbols on the device itself

HMM6420W

ENDEFRTRESPLHRROIT

01M-8839433200-4717-01

Please read this user manual first!

Dear Customers,

Thank you for selecting an Beko product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use. If you handover the product to someone else, give the user manual as well. Follow all warnings and information in the user manual.

Meanings of the symbols

Following symbols are used in the various section of this manual:

	Important information and useful hints about usage.
	WARNING:Warnings for dangerous situations concerning the safety of life and property.
	Materials are intended to be in contact with food.
	Do not immerse the appliance, power cord or power plug in water or in other liquids.
	Protection class for electric shock.

This product has been produced in environmentally-friendly, state-of-the-art facilities.

CONTENTS

ENGLISH 4-9

DEUTSCH 10-17

FRANÇAIS 18-25

TÜRKÇE 26-32

ESPAÑOL 33-41

POLSKI 42-53

HRVATSKI 54-63

ROMANIAN 64-72

ITALIANO 73-80

1 Important in environment

This section contains safety instructions that will help protect from risk of personal injury or property damage.

Failure to follow these instructions invalidates the granted warranty.

1.1 General safety

• This appliance complies with the international safety standards.
• This appliance can be used by people who have limited physical, sensory or mental capacity or who do not have knowledge and experience, provided that they are supervised or they understand the instructions with regard to safe use of the product and potential dangers.
• This appliance cannot be used by children.
• Keep the appliance and the power cable out of the reach of children.
• Do not use it if the power cable or the appliance itself is damaged. Contact an authorised service.

• Unplug the appliance when left unattended, while installing/removing accessories or before cleaning.

• Only use the original parts or parts recommended by the manufacturer.

• Do not attempt to dismantle the appliance.
• Your mains power supply should comply with the information supplied on the rating plate of the appliance.
• Do not use the appliance with an extension cord.
• Do not pull the power cable when unplugging the appliance.
• Unplug the appliance before cleaning, disassembly, accessory replacement and wait for it to stop completely.
• Do not touch the plug of the appliance with damp or wet hands.
• Do not use the device for hot food.
• Remove bones and stones from food to prevent the appliance from getting damaged.
• This appliance is not suitable for dry or hard foods.
• To prevent overheating, do not use whisking continuously for more than 10 minutes. Leave to cool for 5 minutes in between each 10 minutes of operation.

1 Important instructions for safety and environment

• To prevent overheating, do not use mixing with spirals continuously for more than 2 minutes. Leave to cool for 1 minute in between each 2 minutes of operation.
• Follow all warnings to prevent injuries due to incorrect use.
  • After cleaning, dry the appliance and all parts before connecting it to mains supply and before attaching the parts.
• Do not immerse the appliance, power cable, or power plug in water or any other liquids.
• Do not operate or place any part of this appliance or its parts on or near hot surfaces.
• If you keep the packaging materials, store them out of the reach of children.
• If you keep the packaging materials, store them out of the reach of children.

1.2 Compliance with the WEEE Directive and Disposing of the Waste Product:

This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE).

This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at the end of its service life. Take it to the collection center for the recycling of electrical and electronic equipment. Please consult your local authorities to learn about these collection centers.

1.3 Compliance with RoHS Directive

The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain harmful and prohibited materials specified in the Directive.

1.4 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities.

2 Hand Mixer

2.1 Overview

1. Accessory release switch
2. Speed control
3. Turbo button
4. Handle
5. Accessory slots for beaters and dough hooks
6. Beaters
7. Kneading hooks

2.2 Technical data

Power supply: 220-240 V\~, 50/60 Hz

Power: 425 W

Technical and design modifications reserved.

The values which are declared in the markings affixed on your appliance or the other printed documents supplied with it represent the values which were obtained in the laboratories pursuant to the pertinent standards. These values may vary according to the usage of the appliance and ambient conditions.

3 Operation

3.1 Preparation

1. Remove all packaging and sticker materials and dispose of them according to the applicable legal regulations.
2. Before using the appliance for the first time, clean parts which come into contact with food (see the "Cleaning and care" section).

3.2 Operation

1. Make sure that the power cord has been disconnected from the wall socket and the speed control (2) and accessory release switch (1) is set to speed 0 prior to attaching the beater or dough hooks to the mixer.
2. Insert the beaters (6) or kneading hooks (7) into the accessory slots for beaters and dough hooks (5) on the mixer until they lock into place.

Insert dough hook (7) in the larger of the two accessory slots (5).

The beaters (6) can be inserted in either of the two accessory slots (5).

1. Insert the plug into the wall socket.

2. Dip the beaters (6) or kneading hooks (7) into the food mixture before switching the hand mixer on.

3. Set the speed control (2) to the desired speed (1 to 4 speed settings).

- The appliance begins to operate.

Select a suitable speed level, depending on the type of food. While mixing, you can press the Turbo button (3) to briefly raise the speed level to the maximum speed. The speed of the Turbo button (3) corresponds to the level 4 of the speed control (2).

WARNING: Here, the standard load means the added flour should be less than 900g in every time blend and the added water ratio should be around 72g of water for each 100g of flour.

1. After you finish operation, set the speed control (2) to speed 0. Disconnect the plug from the wall socket. Wait for the appliance to come to a complete standstill and then pull out the beaters/kneading hook from the food mixture.
2. Hold the beaters (6) or kneading hooks (7) with one hand and push the accessory release switch (1).

- The beaters (6) or kneading hooks (7) will be released.

WARNING: Never press the accessory release switch (1) unless the speed control is on position 0 and the appliance is disconnected from the wall socket.

3 Operation

3.2.1 Hints and tips

• To avoid mixing egg shells in with the food already in the container, put them into a separate container first. Then add them to the mixture.
• Remember that climatic conditions, seasonal temperature differences, temperature and consistency of the ingredients could affect the preparation time necessary as well as the results.
• Always start blending on a low speed. Increase the speed gradually until you have reached the recommended speed for the food you are mixing.

Food Butter and honey mixture
Amount 300g butter	550g honey
Preparation method butter taken from the freezer (should be kept in the freezer min.4 hrs.and cut in pieces of size approx.10-15 mm x 35-40mmhoney taken from the refrigerator (should be kept min.1 day).
Appr.Time 10 secs.

4 Information

4.1 Cleaning and care

WARNING: Never use petrol solvents, abrasive cleaners, metal objects or hard brushes to clean the appliance.

1. Turn the appliance off and disconnect it from the wall socket.
2. Let the appliance cool down completely.
3. Use a damp soft cloth to clean the exterior of the appliance.

WARNING: Never put the appliance or power cord in water or any other liquids and never hold them under running water.

1. Clean the beaters (6) or kneading hooks (7) with warm, soapy water. Then rinse the beaters or kneading hooks with clear water and dry them off thoroughly. The beaters or kneading hooks can also be cleaned in the dishwasher.

Before using the appliance after cleaning, dry all parts carefully using a soft towel.

4.2 Storage

• If you do not plan to use the appliance for a long period of time, please store it carefully.
• Make sure the appliance is unplugged and completely dry.
  • Store the appliance in a cool, dry place.
• Make sure the appliance is kept out of the reach of children.

4.3 Handling and transportation

• During handling and transportation, carry the appliance in its original packaging. The packaging of the appliance protects it against physical damages.
• Do not place heavy loads on the appliance or the packaging. The appliance may be damaged.
• Dropping the appliance will render it non-operational or cause permanent damage.

White and gray blender with whisk, no visible text or symbols on the device itself

HMM6420W
