SVM130 - Weather Station JOHNSON - Free user manual and instructions

Product Type	Weather Station with Alarm Clock
Brand	Johnson
Model	SVM130
Power Supply	2 x 1.5V AAA batteries (not included)
Display	Digital LCD with backlight
Temperature Measurement Range	-10°C to 50°C (estimated)
Temperature Accuracy	±1°C
Humidity Measurement Range	20% to 95% RH (estimated)
Humidity Accuracy	±5%
Time Accuracy	±2 seconds per day
Functions	Time, Calendar, Alarm, Temperature, Humidity, Comfort Level indicator, Temperature trend
Alarm	Single alarm with snooze function
Backlight	Yes, activated by SNOOZE/LIGHT key
Comfort Level	Displays Dry, Comfort, or Wet based on humidity and temperature
Dimensions	Approx. 100 x 100 x 20 mm (estimated)
Weight	Approx. 150 g (without batteries, estimated)
Color	Black
Guarantee	2 years
Cleaning	Use a soft, non-abrasive cloth; do not immerse in water

Frequently Asked Questions - SVM130 JOHNSON

How do I set the time on my Johnson SVM130 weather station?

In home time mode, press and hold the MODE key for 2 seconds. Use the UP or DOWN key to adjust the hour, then press MODE to confirm. Repeat for minutes. First, set the 12/24 hour format by pressing and holding the UP key in normal display.

How do I set the alarm?

In alarm mode, press and hold the MODE key for 2 seconds. Adjust the hour using UP or DOWN, then press MODE to confirm. Repeat for minutes. The alarm will start at the set time.

How do I change the temperature unit between Celsius and Fahrenheit?

Press the DOWN key to toggle between °C and °F.

What do the comfort level indicators mean?

If humidity is below 40%, the display shows Dry. If humidity is between 40% and 70% and temperature between 20°C and 25°C, it shows Comfort. If humidity is above 70%, it shows Wet.

How do I replace the batteries?

Open the battery compartment on the back and insert two fresh AAA batteries (1.5V each) following the polarity markings. Batteries are not included. Dispose of old batteries properly.

How do I use the snooze function?

When the alarm sounds, press the SNOOZE/LIGHT key to activate snooze. The alarm will stop and re-sound after a short interval. Press any other key to cancel the snooze function.

Why is the display dim?

A dim display usually indicates low battery. Replace the batteries with new ones. You can also press the SNOOZE/LIGHT key to temporarily activate the backlight.

What is the accuracy of the temperature and humidity readings?

The temperature accuracy is ±1°C and the humidity accuracy is ±5%. The time accuracy is ±2 seconds per day.

How do I clean the weather station?

Use a soft, non-abrasive cloth to gently clean the device. Do not immerse it in water or use harsh chemicals. Ensure it is unplugged (or batteries removed) before cleaning.

What does the warranty cover?

The device comes with a 2-year guarantee from the purchase date. It covers material and manufacturing defects. It does not cover damage from improper use, tampering, or normal wear of the power cord or plastic parts. Freight to the service center is at buyer's expense.

USER MANUAL SVM130 JOHNSON

Sveglia digitale

ISTRUZIONI D'USO

Digital alarm clock

INSTRUCTIONS FOR USE

RoHS conform

Batteries: 2×1,5V (AAA)

Batterie non incluse/Batteries not included

AVVERTENZE GENERALI

Carefully read the requirements in this manual and keep in a safe place. It contains important instructions on the safety, use and future of your appliance.

This appliance is only for domestic use and must only to be used for the purpose it was specifically designed.

Any other use is considered improper and dangerous.

The manufacturer cannot be held responsible for any damages caused by improper, incorrect and negligent use.

The installation must be carried out according to the manufacturer's instructions.

The manufacturer shall not be held responsible for any damages to people, animals or objects caused by incorrect installation.

The safety of the electrical equipment is only guaranteed if it is connected to an electrical installation equipped with a suitable earthing system in compliance with the current standards on electrical safety.

Do not leave parts of packaging (plastic bags, foam polystyrene, nails, etc) within reach of children or incapacitated people since they are potential sources of danger.

Before connecting the appliance, check that the technical data on the rating label corresponds to those of the main electricity network.

In case of incompatibility between the outlet and the plug, contact a qualified electrician for the necessary adjustments.

Do not use adaptors, multiple plugs and extension leads.

However, if absolutely necessary only use materials that conform to the current safety standards and that are compatible with the appliance and the main electricity network.

On using the appliance for the first time, remove any labels or protective sheets.

If the appliance is equipped with air inlets, make sure they are never blocked not even partially.

The use of any electrical appliance involves the observance of some fundamental rules. In particular:

Do not immerge the appliance in water and do not wet; do not use it near water, in the tub, washbasin or near other recipients with liquids. If the appliance should accidentally fall in water, DO NOT try to touch it but immediately disconnect the plug from the mains power.

Then bring it to an authorised service centre for the necessary controls.

During use, the appliance must be kept away from any inflammable objects or substances or explosives.

Do not touch the appliance with wet hands or feet.

Do not use the appliance with bare feet.

Do not pull on the power cord or on the appliance itself to disconnect the plug from the power outlet.

Do not leave the appliance exposed to atmospheric agents (sun, rain...).

Keep the appliance out of reach of children or incapacitated people and do not let them use it.

Disconnect the plug from the power outlet when the ap-

pliance is not being used and before carrying out any cleaning or maintenance.

The power cord must be completely unwound to prevent it from overheating.

The power cord must be kept away from heat sources and/or sharp edges.

If power cord is damaged, have it replaced by qualified personnel.

Switch off and contact a qualified technician if the appliance should breakdown and/or not function properly.

Any tampering or interventions executed by unqualified people will cancel the guarantee.

Use a soft and non-abrasive cloth to clean the appliance.

When the appliance is unserviceable and must be eliminated, remove its cords and dispose of it at an authorised disposal centre in order to protect the environment.

- Warranty does not cover any glass parts of the product.

ATTENTION:

The damages of the power supply cord, originate by the wear aren't covered by guarantee; the repair will be in charge to the owner.

ATTENTION:

Warranty does not cover any plastic parts of the pro- duct

ATTENTION:

If the need should arise to take or send the appliance to an authorised service centre, make sure to clean all its parts thoroughly.

For hygienic purposes, the service centre shall reject appliances that are not perfectly clean on the outside or inside without making any controls or repairs.

The symbol 🏠 on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.

By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

Setting & function procedures How to select setting item

In normal display, press MODE key to show the following functions in sequence:

Time Calendar Alarm.

Home Time Setting

1. In normal display, press UP key and hold 2 sec to set 12/24 hr format,
2. In Home Time Mode, press MODE key and hold 2 sec to set Hour, press UP or DOWN key to adjust, then press MODE key to confirm.
3. To set Minute, press UP or DOWN key to adjust, then press MODE to finish.

Calendar Setting

1. In Calendar Mode, press MODE key and hold 2 sec to set Year, press UP or DOWN key to adjust, then press MODE key to confirm.
2. To set Month, press UP or DOWN key to adjust, then press MODE key to confirm.
3. To set Date, press UP or DOWN key to adjust, then press MODE key to finish.

Alarm Setting

1. In Alarm Mode, press MODE key and hold 2 sec to set Hour, press UP or DOWN key to adjust, then press MODE key to confirm.

2. To set Minute, press UP or DOWN key to adjust, then press MODE key to finish.

3. When the Alarm is start, press SNOOZE/LIGHT key to open snooze function, and press any other key to cancel snooze function.

Temperature & Humidity

1. Press DOWN key to select oC or oF.
2. Press UP key to open or close alarm function
3. Press MAX/MIN key to select Max or Min or current temperature & humidity record.
4. Press SNOOZE/LIGHT key to open the backlight function.

Remark:

1. The accuracy for temperature is + / - 1°C .
   The accuracy for humidity is + / - 5% .
   The accuracy for time is +/- 2 secs per day.

2. Humidity < 40%, COMFORT LEVEL will display Dry Humidity between 40%-70%, and temperature between 20°C-25 °C, COMFORT LEVEL will display Comfort. Humidity > 70%, COMFORT LEVEL will display Wet.

3. Temperature trend will show temperature changement in past 12 hours.

4. If the display become dim, please change the battery.

GARANZIA

The validity of the guarantee starts from the purchasing date certified by the seller's stamp and expires at the end of the indicated period, even when the device has not been used. The guarantee covers all substitutions or repairs due to material or manufacturing defects. The guarantee has no validity in case of device tampering or when the defect is due to incorrect or improper use of the same. Substitutions and repair covered by the guarantee are made free of any charge for goods delivered free our service company representative. Only the freight will be at buyer's expense. All replaced parts or devices will become our property.

GARANZIA - GUARANTEE

2 ANNI YEARS

internet: www.johnson.it

e-mail: com @johnson.it

MOD. SVM130

DATA ACQUISTO

PURCHASE DATE

DATA RIPARAZIONE

REPARE DATE

TIMBRO CENTRO ASSISTENZA

AFTER SALES SERVICE

CENTER STAMP

MOD. SVM130

This certificate of guarantee has to be dulyfilled in to be valid
