| Product Type | Managed Gigabit PoE+ Switch with 2 SFP+ Uplinks |
| Model | WGS-5225-8UP2SV |
| Brand | Planet |
| Ports | 24 x Gigabit RJ45 (8 PoE+), 2 x 10G SFP+ |
| PoE Budget | 240W (up to 30W per port) |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.23 Mpps |
| MAC Address Table | 16K entries |
| VLAN Support | 802.1Q VLAN up to 4K VLANs |
| Management | Web, SNMP v1/v2c/v3, CLI, Telnet, SSH |
| Dimensions (W x D x H) | 440 x 250 x 44 mm (19-inch rackmount) |
| Weight | 3.2 kg |
| Power Supply | 100-240V AC, 50-60Hz, internal power supply |
| Power Consumption | Max 280W (with full PoE load) |
| Operating Temperature | 0°C to 50°C |
| Cooling | Fan-based, intelligent speed control |
| Safety Certifications | CE, FCC, RoHS |
| Installation | 19-inch rackmount kit included |
| Maintenance | Keep vents clean; avoid dust and moisture |
| Spare Parts | Contact Planet support for replacement power supply or fans |
Frequently Asked Questions - WGS-5225-8UP2SV Planet
How do I reset the switch to factory defaults?
Press and hold the reset button (located on the front panel) for 10 seconds while the switch is powered on. Release when the system LED flashes rapidly.
Can I mix PoE and non-PoE devices on any port?
Yes, ports 1-8 are PoE+ enabled (30W max per port). Non-PoE devices will simply not draw power, but data connectivity works normally.
What is the maximum PoE budget?
The total PoE budget is 240W, shared across all 8 PoE ports. Ensure total power draw does not exceed this limit.
How do I access the web management interface?
By default, the switch has IP address 192.168.0.100. Connect a PC to any port, set your PC IP to 192.168.0.x (e.g., 192.168.0.50), and open a browser to https://192.168.0.100. Default credentials: admin/admin.
Does this switch support VLAN configuration?
Yes, it supports 802.1Q VLANs with up to 4K VLAN groups. Configuration is done via web, CLI, or SNMP.
What SFP+ modules are compatible?
The switch supports standard 10G SFP+ modules. Compatible models include Planet MGB-SX, MGB-LX, and MGB-T modules, but any standard module should work.
How do I update the firmware?
Download the latest firmware from Planet's website. Upload it via the web interface under 'Maintenance > Firmware Upgrade' or use TFTP/CLI.
What is the warranty period?
Planet typically offers a 3-year limited warranty on this switch. Register your product for full coverage.
Can I mount this switch on a wall?
The switch is designed for 19-inch rackmount only, but it can be placed on a flat surface using the included rubber feet. Wall mounting is not recommended.
Why are my PoE devices not powering on?
Check if the total PoE power exceeds 240W. Try connecting devices one by one. Also ensure that PoE is enabled on the port (default is enabled). If the issue persists, check the power cable and source.
