| Product Type | Power Distribution Unit (PDU) |
| Model | PDU15B12R |
| Brand | CyberPower |
| Form Factor | 1U Rack-Mount |
| Rated Current | 15A |
| Voltage | 120V |
| Plug Type | NEMA 5-15P |
| Outlet Type | 12 x NEMA 5-15R |
| Power Cord Length | 10 ft (3 m) |
| Dimensions (W x H x D) | 17.3 x 1.75 x 5.5 in (44 x 4.4 x 14 cm) |
| Weight | 5.5 lbs (2.5 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Surge Protection | Yes, 1400 Joules |
| EMI/RFI Filtering | Yes |
| Circuit Breaker | 15A resettable |
| Diagnostic LED Indicators | Power, Fault |
| Mounting Kit Included | Yes, with keyhole slots |
| Safety Certifications | UL 1449, cUL, CE |
| Maintenance | Wipe with dry cloth; do not use liquids |
| Safety Warning | Do not exceed rated load; keep away from moisture |
| Repairability | No user-serviceable parts; contact support |
Frequently Asked Questions - PDU15B12R CyberPower
How do I install the PDU15B12R?
Mount the unit in a standard 19-inch rack or cabinet using the included brackets. Secure with screws and ensure the power cord reaches an outlet. Do not block the ventilation.
What is the maximum power load?
The maximum load is 15A at 120V, equating to 1800W. Do not exceed this rating to avoid tripping the circuit breaker.
Does the PDU provide surge protection?
Yes, it has built-in surge protection rated at 1400 Joules, protecting connected equipment from voltage spikes.
What type of plug does it use?
It uses a NEMA 5-15P plug (standard 3-prong grounded plug) with a 10-foot power cord.
Can I mount it in a non-standard rack?
The PDU is designed for standard 19-inch racks. For other installations, use an optional mounting adapter or place on a shelf.
How do I reset the circuit breaker?
If overloaded, the breaker will trip. Unplug some devices, wait a few minutes, then press the reset button on the front panel.
Are the outlets individually controlled?
No, all outlets are switched together via the main breaker. There is no individual outlet control.
What is the warranty period?
CyberPower typically offers a 3-year warranty. Check the included warranty card or visit their website for details.
Can I use it with a generator or UPS?
Yes, as long as the generator or UPS provides stable 120V power. Avoid overloading the source.
What does the fault LED indicate?
The fault LED lights up when the surge protection circuit has been compromised or if there is a wiring fault. Contact support if it remains on.
