| Product Type | Pellet Stove |
| Brand | EvoHeat |
| Model | Apex 14 |
| Fuel Type | Wood Pellets |
| Heating Capacity (BTU/hr) | 42,000 |
| Heating Area (sq ft) | Up to 1,400 |
| Hopper Capacity (lbs) | 60 |
| Efficiency (%) | 85 |
| Dimensions (H x W x D) in | 30 x 22 x 20 |
| Weight (lbs) | 200 |
| Power Supply | 110V AC, 60 Hz |
| Control Type | Digital thermostat with remote |
| Safety Features | Overheat protection, auto shutoff, cool-touch glass |
| Maintenance | Weekly ash removal, annual professional cleaning |
| Repairability | Replacement parts available online; user-replaceable igniter and auger motor |
| Warranty | 5 years limited |
Frequently Asked Questions - Apex 14 EvoHeat
What type of fuel does the EvoHeat Apex 14 use?
The Apex 14 uses wood pellets as fuel. Ensure you use high-quality, dry pellets for optimal performance and efficiency.
How do I install the Apex 14 stove?
Installation must be performed by a certified professional. The stove requires proper venting to the outside, clearances from combustibles, and a stable, non-combustible floor. Refer to the manual for specific clearances.
What is the recommended maintenance schedule?
Empty the ash pan weekly during heavy use. Clean the glass and heat exchanger tubes monthly. Have the stove professionally inspected and cleaned annually.
Why won't the stove ignite?
Check that the hopper has pellets, the igniter is clean, and the power cord is plugged in. Ensure the exhaust vent is not blocked. If the problem persists, consult the troubleshooting section of the manual.
Can I adjust the heat output?
Yes, use the digital thermostat or remote control to set the desired room temperature. The stove automatically modulates pellet feed to maintain the set point.
How often do I need to clean the chimney?
The chimney should be inspected and cleaned at least once a year to prevent creosote buildup. More frequent cleaning may be needed depending on usage and pellet quality.
Is the Apex 14 safe for use in a mobile home?
The Apex 14 is approved for mobile home installation if proper fresh air intake and grounding requirements are met. Consult local codes and the manual for details.
What does the error code 'E2' mean?
Error code E2 indicates ignition failure. Ensure the igniter is functioning and there are no obstructions in the burn pot or exhaust path. Restart after clearing any issues.
Can I use corn or other biomass pellets?
The Apex 14 is designed for wood pellets only. Using corn or other fuels may damage the stove and void the warranty.
Where can I find replacement parts?
Replacement parts are available through EvoHeat dealers and online retailers. Common user-replaceable parts include the igniter, auger motor, and combustion blower.
