NDS-1214 - Sound system Naxa - Free user manual and instructions

Product Type	Sound System
Brand	Naxa
Model	NDS-1214
Dimensions (Approx.)	240 x 150 x 120 mm
Weight (Approx.)	1.5 kg
Power Supply	AC 100-240V, 50/60Hz
Audio Output Power	10W RMS
Connectivity	Bluetooth 5.0, USB, SD Card, AUX Input
Radio	FM Digital Tuner
Playback Media	USB Drive, SD Card (max 32GB)
Display	LCD Screen with Backlight
Control Method	Button Panel, Remote Control
Speaker Driver	2 x 3 inch Full Range
Frequency Response	80Hz - 20kHz
Signal-to-Noise Ratio	≥60dB
Battery	Not applicable (AC powered)
Accessories Included	Remote Control, AUX Cable, Power Adapter, User Manual
Care Instructions	Wipe with a soft, dry cloth; avoid liquids
Safety Note	Keep away from water and heat sources; do not open
Spare Parts Availability	Contact Naxa Support
Country of Origin	China
Warranty	1 Year Limited

Frequently Asked Questions - NDS-1214 Naxa

How do I pair my phone via Bluetooth?

Turn on the system and press the Mode button until Bluetooth is selected. On your phone, enable Bluetooth and search for 'NDS-1214'. Select it to pair. If prompted, enter PIN 0000.

Why is there no sound from the speakers?

Check the volume level on the system and your source device. Ensure the correct input mode is selected (e.g., Bluetooth, AUX). Verify cables are firmly connected. If using USB/SD, ensure the file format is supported (MP3/WMA).

How do I set the FM radio stations?

Press Mode to select FM. Press and hold Scan to auto-scan and save stations. Use CH+/CH- to cycle through stored presets.

Can I charge my phone using the USB port?

No, the USB port is for media playback only (USB drives). It does not support charging external devices.

What to do if the remote control stops working?

Replace the battery (CR2025). Ensure there are no obstructions between the remote and the sensor. Point directly at the unit from within 5 meters.

How do I clean the sound system?

Unplug the unit. Use a soft, dry cloth to gently wipe the exterior. Do not use chemical cleaners or allow liquid to enter the vents.

What audio formats are supported?

For USB and SD playback, supported formats include MP3 and WMA. Files should be saved in FAT32 format on the storage device.

The display shows 'NO USB' even with a drive inserted.

Ensure the USB drive is formatted as FAT32 and contains playable audio files. Try another USB drive. The maximum capacity is 32GB.

How can I reset the system to factory settings?

There is no dedicated reset button. To reset, unplug the power cord for 10 seconds, then plug back in. This will clear any temporary glitches.

Is the system compatible with wall mounting?

No, the NDS-1214 is designed for tabletop use only. Place it on a stable, flat surface to ensure proper ventilation and sound quality.

USER MANUAL NDS-1214 Naxa

Black electronic device with a circular display and two side-mounted buttons, no visible text or symbols.

WARNING

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of significant magnitude to constitute risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instructions in the literature accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Guard this m anual.

3. Obey a ll a lerts.

4. Follow all instructions.

5. WAR NING: To prevent fire or shock hazard, do not expose this equipment to rain or moisture. Do not store and operate this product near liquid.

6. C lean only with dry cloth.

7. Not store and not operate this product near any heat sources such as radiators and heat registers, tove or other appliances (including amplifiers) that produce heat. Keep this product in a well ventilated place.

8. Not ignore the safety purpose of the polarized or grounding plug. A polarized plug has two blades being wider than the other. A grounding plug has two blades plus a round pin to ground. The wide blade or the third prong is intended to provide security. If the provided plug does not fit into your outlet, consult an electrician to replace the outlet.

9. P rotect all wires connected to this unit from being walked on or pinched, particularly at plugs and the point where the cord exits the unit. When unplugging from the electrical outlet, gras p the plug and do not pull the cord.

10. Dis connect the unit during lightning s torms or when long period is to remain unus ed.

11. Keep this unit off when connecting all the devices connected to it.

12. After finis hing the ins talla tion and connections, connect all your equipment with low volume level. Once all devices are connected, slowly increase the volume or level controls to achieve the proper position.

13. Before placement, ins tallation, as s embly or s us pending any product, ins pect all e equipment, s us pens ion, cabinets, trans ducers , brackets and as s ociated equipment.

Any mis sing component, corroded, deformed, or with non-nominal load can reduce the intensity, placement and arrangement of the installation significantly. Any of these conditions can reduce the security of the facility and must be corrected immediately.

Use only suitable equipment for the loading conditions of the installation and that any possibility of reducing term, unexpected overload, never exceed the capacity of the material or equipment.

1. Consult a licensed professional to install the equipment and make sure that all local, regional and national regulations related to security are unders tood and adhered to.

2. All services should be performed by qualified professions. Servicing is required when the apparatus has been damaged in any way, as if having the power cord or its damaged connector, or if the machine breaks contact with liquid or if any object is inserted in the unit or if the unit is exposed to rain or moisture, or if the unit does not operate normally, or has been dropped.

CHARGE THE BATTERY FULLY BEFORE FIRST USE TO OPTIMIZE ITS LIFETIME PERFORMANCE.

1. Power Switch
   2.3.5mm Auxiliary Input
2. TF Card Slot
3. Mode Selection Button
4. Previous Track/Station
5. LED Display
6. Battery Status Indicator
7. Remote Control Receiver
8. Microphone Priority Switch
9. Charging Port (DC 9V)

10. Microphone Input

11. Light Switch

12. Master Volume Tuning Knob
13. USB Port
14. Treble Tuning Knob
15. Pause/Play Button
16. Bass Tuning Knob
17. Next Song/Station
18. Echo Tuning Knob
19. Recording/Playback Button
20. Microphone Volume Tuning Knob
21. Power Input (DC 12V)

PAIRING A BLUETOOTH® DEVICE

Use Bluetooth ^® mode to stream music from a Bluetooth ^® enabled player (e.g., smartphone or tablet device). A device must be paired with the unit before using them together for first time

1. Make sure Bluetooth ^® is enabled on your device and that it is next to the unit before attempting to pair it
2. Turn on the DJ Speaker and set it to Bluetooth® mode (Press the MODE Button). The speaker will automatically enter pairing mode and make a beeping sound.
3. Use your device to search for nearby Bluetooth devices. The Speaker will be listed as “NDS-1214”. (This function is usually in the Bluetooth® settings menu; refer to your device’s instruction manual to learn more.)
4. Select “NDS-1214” from the list of found/available devices. The speaker will make a confirmation tone that connection is successful. You can now start playback on your connected device to begin streaming music to the speaker.

SPECIFICATIONS

Woofer x 1, Driver Size: 12"

Wireless Source: Bluetooth®

Removable Memory Support: USB/Memory Card (32GB Max.)

Audio Format Support: MP3

Tuners: FM

Input Sources: 3.5mm AUX, 6.3mm MIC

Battery: 7.4V 1800mA

Power Source: 9V DC

Accessories Included: Remote Control, Wired Mic, Manual, UL Adapter

FCC NOTICE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CAUTION ON MODIFICATIONS

Any changes or modifications not expressly approved by the grantee of this device may void the authority granted by the FCC to operate the equipment.

SUPPORT

If you have problems with your device, please consult the instructions in this manual. Please also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documentation for your device. For additional assistance, please contact Naxa Technical Support.

Naxa Technical Support

2320 East 49th St. Vernon, CA 90058 [phone]

http://www.naxa.com/supportcenter/
