NDS-5000 - Sound system Naxa - Free user manual and instructions

Product Type	Portable Bluetooth Sound System
Dimensions	7.5 x 3.5 x 2.5 inches
Weight	1.2 lbs
Power Supply	Built-in rechargeable lithium battery, 5V DC via USB
Output Power	5W RMS
Battery Life	Up to 4 hours
Connectivity	Bluetooth 5.0, USB port, microSD card slot, 3.5mm AUX input
Radio	FM tuner
Controls	Play/Pause, Volume, Next/Previous, Mode
Speaker Driver	2-inch full range
Color	Black
Package Includes	Sound system, USB charging cable, AUX cable, User manual
Care and Cleaning	Clean with soft dry cloth, avoid moisture
Safety	Do not expose to water, keep away from heat sources
Spare Parts and Repairability	No user-serviceable parts; contact support for repairs

Frequently Asked Questions - NDS-5000 Naxa

How to pair the NDS-5000 with my phone?

Turn on the speaker by pressing the Power button. Activate Bluetooth on your phone and select NDS-5000 from the available devices. Pairing is complete when the indicator light stops flashing.

How to charge the speaker?

Connect the included USB charging cable to the speaker's DC 5V port and plug the other end into a USB power adapter. The LED turns red while charging and goes off when fully charged.

How to use the FM radio function?

Press the Mode button to switch to FM mode. Use the Next/Previous buttons to search for stations automatically. For optimal reception, extend the built-in antenna if available.

Why is there no sound from the speaker?

Check if the speaker is powered on and the volume is turned up. Ensure your device is connected via Bluetooth or AUX cable. Also verify the source is playing audio.

What is the battery life of the NDS-5000?

The built-in battery provides up to 4 hours of playtime at moderate volume. Battery life may vary depending on volume level and audio content.

Can I use the speaker while it is charging?

Yes, the NDS-5000 supports pass-through usage. You can play music while the speaker is connected to a power source.

How to reset the speaker?

If the speaker becomes unresponsive, press and hold the Power button for 10 seconds to force a reset. Then turn it on again normally.

Can I connect two NDS-5000 speakers for stereo sound?

The NDS-5000 does not support True Wireless Stereo (TWS). Only one speaker can be connected to a device at a time.

What is the Bluetooth range?

Bluetooth range is approximately 33 feet (10 meters) in open space, but walls and obstacles may reduce the effective range.

How to clean the speaker?

Use a soft, dry cloth to wipe the exterior. Do not use water, solvents, or abrasive cleaners. Avoid getting moisture into any openings.

USER MANUAL NDS-5000 Naxa

Black soundproof portable electronic device with hexagonal grille and control panel (no visible text or symbols)

WARNING

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of significant magnitude to constitute risk of electric shock. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operation and servicing instructions in the literature accompanying the appliance.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Guard this m anual.

3. Obey a ll a lerts.

4. Follow all instructions.

5. WAR NING: To prevent fire or shock hazard, do not expos e this equipment to rain or moisture. Do not store and operate this product near liquid.

6. C lean only with dry cloth.

7. Not s tore and not operate this product near any heat s ources s uch as radiators and h eat regis ters , s tove or other appliances (including amplifiers ) that produce heat. Keep this product in a well ventilated place.

8. Not ignore the safety purpose of the polarized or grounding plug. A polarized plug has two blades being wider than the other. A grounding plug has two blades plus a round pin to ground. The wide blade or the third prong is intended to provide security. If the provided plug does not fit into your outlet, consult an electrician to replace the outlet.

9. Protect all wires connected to this unit from being walked on or pinched, particularly at plugs and the point where the cord exits the unit. When unplugging from the electrical outlet, gras p the plug and do not pull the cord.

10. Dis connect the unit during lightning s torms or when long period is to remain unus ed.

11. Keep this unit off when connecting all the devices connected to it.

12. After finis hing the ins talla tion and connections, connect all your equipment with low volume level. Once all devices are connected, slowly increase the volume or level controls to achieve the proper position.

13. Before placement, ins tallation, as sembly or s us pending any product, ins pect all e equipment, s us pens ion, cabinets, trans ducers , brackets and as s ociated equipment.

Any mis sing component, corroded, deformed, or with non-nominal load can reduce the intensity, placement and arrangement of the installation significantly. Any of these conditions can reduce the security of the facility and must be corrected immediately.

Use only suitable equipment for the loading conditions of the installation and that any possibility of reducing term, unexpected overload, never exceed the capacity of the material or equipment.

1. C ons ult a licens ed profes s ional t o ins tall the equipment and make sure that all local, regional and national regulations related to s ecurity are unders tood and adhered to.

2. All services should be performed by qualified professions. Servicing is required when the apparatus has been damaged in any way, as if having the power cord or its damaged connector, or if the machine breaks contact with liquid or if any object is inserted in the unit or if the unit is exposed to rain or moisture, or if the unit does not operate normally, or has been dropped.

CHARGE THE BATTERY FULLY BEFORE FIRST USE TO OPTIMIZE ITS LIFETIME PERFORMANCE.

1. LED DISPLAY: Indicates Status
2. USB SLOT: Insert USB Drive to listen stored tracks
3. POWER ON/OFF: Turn ON/OFF Unit's power supply
4. MICROPHONE INPUT: (MICROPHONE NOT INCLUDED): Plug in Microphone for Karaoke
5. POWER: 5V (CABLE INCLUDED): Use included charging cable to charge unit. Adaptor not included
6. AUX INPUT: Connect external media player using 3.5mm line in cable
7. MEMORY CARD INPUT: Insert memory card to listen stored tracks
8. Battery Charging Indicator
9. MODE: Toggle between source BT/USB/ Memory Card /FM/Aux
10. REPEAT: Repeat current track or repeat all tracks in Album or Random play tracks
11. LIGHT ON/OFF: Turn On/Off Woofer Light while Unit is powered on.
12. ROTARY VOLUME CONTROL KNOB: Increase/Decrease Volume
13. PREVIOUS: Select previous track in USB/Memory Card Modes, Select previous preset frequency in FM mode
14. PLAY/PAUSE: Play or Pause in BT/USB/ Memory Card Mode, Mute in Aux Mode, Long Press to Scan for available frequencies in FM Mode and Short Press to Mute in FM Mode
15. NEXT: Select next track in USB/ Memory Card Modes, Select next preset frequency in FM mode

POWER SUPPLY

1. Connect the supplied USB cable unit to a 5V USB outlet to charge the unit.
2. Switch the Power button to turn On and Off the unit.

Note: Low Battery indicator will flash on display once battery is Low. Sound output will be reduced. Recharge unit when the Low Battery indicator starts flashing.

PAIRING A BLUETOOTH® DEVICE

Use Bluetooth ^® mode to stream music from a Bluetooth ^® enabled player (e.g., smartphone or tablet device). A device must be paired with the unit before using them together for first time

1. Make sure Bluetooth® is enabled on your device and that it is next to the unit before attempting to pair it
2. Turn on the DJ Speaker and set it to Bluetooth® mode (Press the MODE Button). The speaker will automatically enter pairing mode and make a beeping sound.
3. Use your device to search for nearby Bluetooth devices. The Speaker will be listed as "SOUND PRO NDS-5000". (This function is usually in the Bluetooth® settings menu; refer to your device's instruction manual to learn more.)
4. Select "SOUND PRO NDS-5000" from the list of found/available devices. The speaker will make a confirmation tone that connection is successful. You can now start playback on your connected device to begin streaming music to the speaker.

FM RADIO

1. Press the "MODE" button to select FM Radio.
2. Long press the Play/Pause button to auto scan all available radio frequencies. It will search and automatically store all available.
3. Press Next or Previous to select desired stored stations.
4. Short press Play/Pause to Mute.
5. The LED Display will show the selected station.

AUX IN

1. Press the "MODE" button to select the AUX function.
2. Press the Play/Pause button to Mute the sound on the unit.
3. Plug in an external device to the AUX jack to listen to audio through the speaker.

SPECIFICATIONS

Woofer x 1, Driver Size: 5.25"

Wireless Source: Bluetooth®

Removable Memory Support: USB/Memory Card

Audio Format Support: MP3

Tuners: FM

Input Sources: 3.5mm AUX, 6.3mm MIC

Power Source: 5V DC, charging cable included. Adaptor not included

FCC NOTICE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interreference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CAUTION ON MODIFICATIONS

Any changes or modifications not expressly approved by the grantee of this device may void the authority granted by the FCC to operate the equipment.

SUPPORT

If you have problems with your device, please consult the instructions in this manual. Please also visit us on the web at www.naxa.com to get up to the minute news, alerts, and documentation for your device. For additional assistance, please contact Naxa Technical Support.

Naxa Technical Support

2320 East 49th St.

Vernon, CA 90058

[phone]

http://www.naxa.com/supportcenter/
