PLW12RD - Car speaker Pyle - Free user manual and instructions

Product Type	Car Speaker
Brand	Pyle
Model	PLW12RD
Speaker Size	12 inches
Speaker Type	Subwoofer
RMS Power Handling	400 Watts
Peak Power Handling	800 Watts
Impedance	4 Ohms
Sensitivity	89 dB
Frequency Response	20 Hz - 2 kHz
Mounting Depth	6.3 inches
Cutout Diameter	11.1 inches
Cone Material	Polypropylene
Voice Coil	2-layer, 2-inch
Magnet Weight	40 oz
Recommended Enclosure	Sealed or Ported
Product Dimensions (W x H x D)	12.2 x 12.2 x 6.7 inches
Shipping Weight	12.5 lbs
Connection Type	Spring-loaded terminals
Material	Steel basket, foam surround
Color	Red and Black

Frequently Asked Questions - PLW12RD Pyle

What is the RMS power handling of the Pyle PLW12RD?

The Pyle PLW12RD has an RMS power handling of 400 Watts and a peak power of 800 Watts.

What is the impedance of this speaker?

This subwoofer has an impedance of 4 Ohms, suitable for most car audio systems.

What type of enclosure is recommended?

The PLW12RD works well in both sealed and ported enclosures. A sealed box gives tight bass, while ported provides louder output.

What is the mounting depth required?

The mounting depth is 6.3 inches. Ensure your enclosure has enough space for this depth.

What is the cutout diameter?

The cutout diameter needed for installation is 11.1 inches.

Is this speaker compatible with a stock car stereo?

Yes, as long as the stereo or amplifier can handle a 4-Ohm load and provide sufficient power (at least 400W RMS).

What materials is the speaker made of?

The cone is made of polypropylene for durability, with a foam surround and steel basket for rigidity.

How do I clean the speaker?

Gently wipe the cone and surround with a soft, dry cloth. Avoid using liquids or cleaning agents.

What is the warranty on this product?

Pyle typically offers a 1-year limited warranty against defects. Check your purchase documentation for details.

Can I use this subwoofer in a home audio system?

Yes, but you will need a compatible amplifier and power supply. Car subwoofers can be used at home with proper setup.

USER MANUAL PLW12RD Pyle

MANUFACTURER'S LIMITED ONE YEAR WARRANTY

PYLE USA warranties this unit to be free from defective material or workmanship and wil repair or replace this unit or any part there of if it proves defective in normal use or service within one (1) year from the date of original purchase.

• Our obligation under this warranty is limited to the repairing or replacing at our discretion, the defective instrument or any part there of when it is returned, transportation prepaid to the Pyle Service Center.
• This warranty will be considered void if the unit has been tampered with, improperly serviced, subjected to abuse or misuse or if instaled in a commercial vehicle.
• This warranty does not cover accidental damage.

IMPORTANT:

Pack carefully in original carton if possible. We are not responsible for damage incurred inreturning items for repair. A letter stating your exact street address, daytime phone number and the problem you are experiencing should be included. You must also enclose a copy of the original receipt as proof of date of purchase.

About Pyle Blue (Red) Label Woofer

CONGRATULATIONS! You have just purchased one of our high quality Pyle woofer. Blue (Red) Labels Series Woofer are not only in unique design, but also could deliver consistent and high performance.

We do confident that Blue (Red) Labels Series Woofer will bring you many hours of enjoyment over the years.

The General Features Pyle Woofer Include:

BLUE LABEL

• Blue CD Wave Electro-platerd Polyproylence Cone
- Wide Butyl Rubber Surround With New Pattern
- Blue Steel Basket
• Bumped & Vented Extended Pole Piece
• High Temperature Kapton Polyamide Voice Coils
• 4 Ohm Impedance

RED LABEL

• Red CD Wave Electro-platerd Polyproylence Cone
- Wide Butyl Rubber Surround With New Pattern
- Red Steel Basket
• Bumped & Vented Extended Pole Piece
• High Temperature Kapton Polyamide Voice Coils
• 4 Ohm Impedance

Questions? Issues?

We are here to help!

Phone: [phone]

Email: [e-mail]

Blue speaker with blue speaker cone and 'PYLE' logo, shown from side to front (no text or symbols on body)

Red speaker with black head and red speaker grille, no visible text or symbols on the device itself.

Illustration of a laptop with a red checkmark on the screen (no text or symbols)

VISIT US ONLINE:

Have a question?

Need service or repair?

Want to leave a comment?

PyleUSA.com/ContactUs

PLW10BL/PLW10RD PLW12BL/PLW12RD PLW15BL/PLW15RD

Specification	PLW10BL	PLW12BL	PLW15BL
Steel Frame	Blue	Blue	Blue
Cone	Blue Electro-platerd	Blue Electro-platerd	Blue Electro-platerd
Surround	Wide Rubber	Wide Rubber	Wide Rubber
Power (Watts Peak)	600	800	1000
Impedance (Ohm)	4	4	4
Voice Coil (Inch)	1.5" KSV	2.0" KSV	2.5" KSV
Magnet Structure	70 Oz	90 Oz	70 Oz
Fs (Hz)	35.9	26.2	20
Qms	5.72	5.81	6.23
Qes	0.83	0.90	1.1
Qts	0.73	0.78	1.0
SPL (dB)	86.7	85.5	86
Vas (L)	1.932	4.146	9.416

Specification PLW10RD		PLW12RD	PLW15RD
Steel Frame	Red	Red	Red
Cone	Red Electro-platerd	Red Electro-platerd	Red Electro-platerd
Surround	Wide Rubber	Wide Rubber	Wide Rubber
Power (Watts Peak)	600	800	1000
Impedance (Ohm)	4	4	4
Voice Coil (Inch)	1.5" KSV	2.0" KSV	2.5" KSV
Magnet Structure	70 Oz	90 Oz	70 Oz
Fs (Hz)	35.9	26.2	20
Qms	5.72	5.81	6.23
Qes	0.83	0.90	1.1
Qts	0.73	0.78	1.0
SPL (dB)	86.7	85.5	86
Vas (L)	1.932	4.146	9.416

Pyle-Blue (Red) Label-Series continually strives to improve the performance and value of its products all specifications are subject to change.
