| Product Type | Electrical Switch |
| Model | XD150FX-MM |
| Brand | Adder |
| Switch Type | Single-Pole Single-Throw (SPST) |
| Mounting Type | Wall Mount |
| Voltage Rating | 120 V AC |
| Current Rating | 15 A |
| Maximum Power | 1800 W |
| Dimensions (H x W x D) | 4.2 x 2.8 x 1.5 cm |
| Weight | 35 g |
| Material | Thermoplastic, Brass Contacts |
| Color | White |
| Certifications | UL Listed, CE Marked |
| Operating Temperature | -20°C to 60°C |
| Wiring Type | Screw Terminals |
| Number of Poles | 1 |
| Number of Throws | 1 |
| Illumination | None |
| Actuator Type | Toggle |
| Grounding | Ground Screw Included |
| Compliance | RoHS, REACH |
Frequently Asked Questions - XD150FX-MM Adder
How do I install the Adder XD150FX-MM switch?
Turn off power at the circuit breaker. Connect the hot wire to the brass screw, neutral to silver, and ground to green. Push wires into box, attach switch, and secure cover plate.
What is the maximum wattage for this switch?
The switch handles up to 1800 W for resistive loads on a 120 V circuit (15 A). For inductive loads, derate to 80%.
Can I use this switch for 3-way applications?
No, the XD150FX-MM is a single-pole switch designed for one location. For 3-way, use a compatible single-pole double-throw (SPDT) model.
Does the switch require a neutral wire?
No, a neutral wire is not required as it is a mechanical toggle switch without electronic components.
Is the switch suitable for outdoor use?
No, this switch is rated for indoor use only. For outdoor, use a weatherproof enclosure and a switch with appropriate IP rating.
What type of wire should I use?
Use copper wire only, gauge 14-12 AWG (solid or stranded). Strip 5/8 inch (16 mm) for connection.
How do I clean the switch?
Wipe with a dry or slightly damp cloth. Do not use solvents. Ensure power is off before cleaning.
Does it have a built-in night light?
No, the XD150FX-MM does not include any illumination feature. It is a standard toggle switch.
Is the switch mercury-free?
Yes, the switch is mercury-free and complies with RoHS directives.
What is the warranty period?
Adder provides a 2-year limited warranty against defects in materials and workmanship.
