USER MANUAL SUSHI MAKER SUP513 BRANDT

FR MANUEL D'INSTRUCTION

EN INSTRUCTION MANUAL

Sushi Party

SUP513

Brandt

Chère Cliente, Cher Client

ENGLISH INSTRUCTION MANUAL 12

You have just purchased a BRANDT Sushi Party and we would like to thank you.

We have placed in this appliance all our passion and know-how in order to meet at best your need. Innovative and efficient: we designed it to be always easy to use.

In the BRANDT products line, you will also find a wide range of small domestic appliances that can be coordinated to your new BRANDT Sushi Party.

Of course, in a permanent wish to satisfy as best as possible your expectations toward our products, our after-sales service department is at your disposal and at your listening to answer to all your questions and suggestions.

You can also visit our website www.brandt.com where you will find all our products, as well as additional and useful information.

BRANDT

As part of our commitment to constantly improve our products, we reserve the right to make technical, functional or esthetical properties modifications linked to their technological development.

Be careful : Before installing and using your appliance, please carefully read this Guide to Installation and Use, which will allow you to quickly familiarise yourself with its operation.

www.brandt.com

TABLE OF CONTENTS

1/ INFORMATION FOR THE USER 14

A. Safety recommendations 14-17
B. Technical data 17
C. Protecting the environment 17

2/ SUSHI PARTY DESCRIPTION 18
3/ USING YOUR APPLIANCE 18

A. Using your rice cooker 18
B. Using the steaming function 19

4/ CLEANING AND MAINTENANCE 19

A. Cleaning the rice cooker 19
B. Warranty and after-sales service 20

Keep this guide with your appliance. If the appliance is ever sold or transferred to another person, ensure that the new owner receives this user guide. Please familiarise yourself with these recommendations before installing and using your appliance. They have been written for your own safety as well as the safety of others.

A. Safety recommendation

Safety tips when connecting the appliance:

• This appliance is intended for household use only. Any other use is considered unsuitable or dangerous. It can only be used in covered, closed and warmed environment such as kitchen or a room with the same specifications.
• After removing the packaging, check that the appliance is in good condition and especially that the power cord is not damage. In doubt, contact the After Sales Service of your dealer.
• Before connecting the appliance, make sure that the electric power supply is compatible with the power rating and voltage indicated on the bottom of the appliance.
• The use of adaptors, multiple sockets or extension cables is not recommended. If theses elements were essential, only use adapters or extension cable that comply with the safety standards.

• This appliance is not intended to be operated by an external timer or separate remote control system.

• Place the appliance on a dry, stable and smooth surface.

• Keep the appliance and its cord out of reach of children under 8 years.
• Always hold the plug itself, rather than pulling on the power cable.
• Children should be supervised to ensure that they do not play with the appliance.

Safety tips when using the appliance:

• This appliance shall no be used by children from 0 to 8 years. It can be used by children aged from 8 years and above if they are continuously supervised.
• This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• The appliance and its accessible parts become hot during the use. Children under the age of 8 years should not use this appliance unless continuous supervision by a responsible adult is given.
• Keep cord away from heated surface.
• Do not touch the appliance with wet or damp hands.
• Do not open the lid when the appliance is in process.

• Do not remove the plug when the kettle is in process.

• Do not leave the appliance unattended when it is turned on because it can be dangerous.

• Do not cover the steam output with a textile or another object.
• The tank is designed only for the use of this appliance.
• Do not place the appliance on or near to a hot surface (heater, stove, cooking surface, hot oven, microwave oven, etc.)
• Do not use this appliance if the air is charged with more than 90% of humidity.
• Your appliance is designed for standard household use for cooking and reheating food. The drying of food or linen and the heating of heating pillows, slippers, sponges, wet linen and other similar goods could bring risks of wounds, inflammation or fire.
• The use of accessory attachments not recommended by the appliance's manufacturer may cause hazard or injury.

Cleaning and Maintenance:

• Unplug the appliance before cleaning and allow the appliance to cool down.
• The supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.
• To protect against electric shock, do not place any part of this appliance in water or other liquid.
• Do not use harsh abrasive cleaners or sharp metal scrapers to clean your Sushi Party.
• Cleaning and user maintenance shall not be made by children.

Improper use:

• Use this appliance only for its intended uses as described in manual.
• The manufacturer shall not be liable for any damage resulting from improper use.
• The appliance is intended for domestic use only in private housing environments. The use of this appliance in common or professional's area such as staff kitchen areas in shop, offices and other working environments; by clients in hotels, motels and restaurants or any other shops; by clients in kitchen areas or campsite; are not a proper us as defined by the manufacturer

Be careful: external surfaces become hot during the use.

B. Technical Data

Model no	SUP513
Power supply	220V 50Hz
Power	500W
Dimensions	H215 x L266 x P280
Net wt.	2,85 Kg

C. Protecting the environment

At the end of its working life, the product must not be disposed with household waste. It must be taken to a special local authority waste collection centre or to a company providing this service. Disposing household appliances separately avoids possible negative effects on the environment and health and enables the constituent materials to be recycled which saves energy and resources.

To remind you that you must dispose of this appliance correctly the symbol shown above appears on the product warning you not to dispose of it with household waste. For further information, contact your local authority or the shop where you bought the product.

Makis mould

Bamboo mat for California rolls

Spatula

Steaming tray

Power cord

Measuring cup

Spatula bracket

3/ USING YOUR APPLIANCE

For more information for use the Makis tins and the bamboo mat for makis, please refer to the cookbook provided.

Before connecting your appliance:

• Clean all parts of the rice cooker and accessories

A. Using your rice cooker

Measure rice with rice cup available with you appliance.
- Rinse your rice thoroughly and drain 20 minutes for optimal cooking.

• Put rice into inner pot, add water to appropriate level. The rice cup and its graduation in g/ml can help you for this operation. The water volume can be added or reduced according to personal flavour and rice variety. Never fill over the maximum level indicate into the inner pot.

Example for 6 persons:

Add 450g of rice, then pour 550ml of water/ (100g of rice=125 ml of water)

• Plug power cord to rice cooker outlet, plug other end to an electrical outlet.
  After plug in the red cook indicator light up: the appliance is on preheating mode.
• The rice cooker change in the "keep warm mode": the yellow signal light up and a click sound advice you.
• Press cook key, the cook start and the red signal light up.
• Once the rice has absorbed all the water, the appliance will come to back to the "keep warm mode" automatically: the yellow signal light up and a click sound advice you.
  Plug off the power plug after use and then take out inner pot and food.
• Use provided spatula but do not put metal scoop in the pot to prevent damage of inner pot.

B. Using the steaming function

• Measure 3 cups of water with rice cup and pour into inner pot. Adjust the volume of water according to the quantity of food. The boiling time of 3 cups of water is 8 minutes.
• Put the food in dish or in steaming tray directly. Make the food scattered evenly but not crowded together to make sure the food be heated equally.
• Put the steaming tray into inner pot. When steaming and cooking process go on at the same time, make sure to leave enough space for steaming tray. The steaming food will be ready when the cooking process finished.
• Close the lid correctly, plugs in and connect power source.
  After plug in the red cook indicator light up: the appliance is on preheating mode.
• The rice cooker change in the "keep warm mode": the yellow signal light up and a click sound advice you.
• Press cook key, the cook start and the red signal light up.
• When you think your food is cooked, use a finger pull up cooking key as illustration.
• Open the lid, take out the food from dish or steaming tray carefully as it is very hot, you need wear a kitchen glove or use a cloth as pad.(Be careful when open the lid lest scalded by steam.)
  After steaming process finished, cut down power source and plug off.

4/ CLEANING AND MAINTENANCE

A. Cleaning the rice cooker

Before cleaning your appliance, unplug and allow cooling completely. To facilitate cleaning, some parts of the appliance can be removed. This is the case of the tank and the vent cover. To remove this cover, simply pull it as shown below:

Do not use harsh abrasive cleaners or sharp metal scrapers to clean your Sushi Party and don't use metal utensils to avoid damaging the appliance. To protect against electric shock, do not place any part of this appliance in water or other liquid.

Always check that grains of rice or other food pieces are not stuck in the griddle. This could damage the contact between the heating element and the tank.

B. Warranty and after-sale service

This product is covered by a 2-year warranty by your retailer. For more details, please refer to the warranty conditions supplied by your distributor
