| Product Type | Electrical Enclosure |
| Brand | Hoffman |
| Model | P2BP185 |
| Material | Steel with powder coating |
| Color | Gray (RAL 7035) |
| Dimensions (H x W x D) | 185 mm x 140 mm x 100 mm |
| Weight | 1.8 kg |
| IP Rating | IP66 (dust-tight and protected against powerful water jets) |
| Operating Temperature | -40°C to 80°C |
| Mounting Type | Wall-mounted with bracket |
| Accessories Included | Mounting bracket, screws, sealing gasket |
| Maintenance | Clean with a damp cloth; avoid solvents |
| Safety | Grounding provision (internal stud) |
| Spare Parts | Hinges, latches, gaskets available from Hoffman |
| Warranty | 5 years against manufacturing defects |
| Certifications | UL 508A, CSA C22.2, CE compliant |
| Manual Languages | English (EN) – downloadable PDF |
Frequently Asked Questions - P2BP185 Hoffman
How do I install the Hoffman P2BP185 enclosure?
Mount the enclosure securely on a flat wall surface using the provided bracket and screws. Ensure the wall can support the weight (1.8 kg). Use appropriate anchors for masonry. The enclosure must be grounded via the internal stud for safety.
Refer to the manual for detailed instructions.
Refer to the manual for detailed instructions.
What is the IP rating and can it be used outdoors?
The P2BP185 has an IP66 rating, meaning it is dust-tight and protected against powerful water jets. Yes, it is suitable for outdoor use, but avoid direct sunlight exposure if not UV-rated.
How do I clean the enclosure?
Use a soft, damp cloth with mild soap and water. Do not use abrasive cleaners, solvents, or high-pressure washers as they may damage the powder coating. Dry thoroughly after cleaning.
What material is the enclosure made of?
The enclosure is constructed from steel with a durable powder coating for corrosion resistance. The finish complies with RAL 7035 (light gray).
Does the P2BP185 come with a lock?
The enclosure does not include a lock, but it features a hasp that accepts a padlock for security. Padlock not included. Use a lock with a shackle diameter up to 8 mm.
What is the operating temperature range?
The enclosure can function in temperatures from -40°C to 80°C. For extended outdoor use, avoid exposing the enclosure to continuous extreme high temperatures.
Where can I find the user manual?
The manual is available for free download in PDF format on notice-facile.com. Search for Hoffman P2BP185 to access the document.
Are replacement parts available?
Yes, Hoffman offers spare parts such as hinges, latches, and gaskets. Contact an authorized distributor and provide the model number P2BP185. Parts are also available online.
Can I mount this enclosure directly to plywood?
Yes, you can mount it on plywood or other solid surfaces using screws. Ensure the screws are rated for the weight. Use the mounting template in the manual for accurate hole placement.
What is the internal grounding provision?
The enclosure includes an internal grounding stud for connecting a ground wire. This is essential for electrical safety and compliance with UL and CE standards. Use a copper lug with appropriate ring terminal.
