IP745N - Dishwasher REX - Free user manual and instructions

Product type	Dishwasher
Brand	Rex
Model	IP745N
Installation type	Freestanding
Width	60 cm
Height	85 cm
Depth	60 cm
Net weight	48 kg
Energy efficiency class	E
Annual energy consumption	255 kWh
Water consumption per cycle	12 L
Capacity	12 place settings
Number of programs	6
Programs	Eco, Intensive, Normal, Quick, Glass, Pre-wash
Noise level	49 dB(A)
Drying system	Condensation drying
Water connection	Cold water only
Salt indicator	Yes
Rinse aid indicator	Yes
Delay start	Up to 24 hours
Child lock	Yes
Self-cleaning filter	No, manual cleaning required
Repairability index	7.5 / 10
Spare parts availability	7 years

Frequently Asked Questions - IP745N REX

How do I install the Rex IP745N dishwasher?

Ensure the appliance is placed on a solid floor. Connect the inlet hose to a cold water supply with a 3/4 inch threaded tap. The drain hose must be connected to a sink drain with a minimum height of 40 cm. Level the appliance using the adjustable feet. Refer to the installation section in the manual for detailed steps.

How to add dishwasher salt?

Open the salt container cap at the bottom of the dishwasher. Fill the container with water (only for first use) then add dishwasher salt using the funnel provided. Close the cap tightly and run a rinse program to avoid corrosion.

Which detergent should I use?

Use any standard dishwasher detergent (powder, gel, or tablets). For best results, use a detergent with rinse aid and salt built in. Adjust dosage according to water hardness and soil level.

How to clean the filter?

Turn off the dishwasher and remove the lower rack. Unscrew the filter assembly (fine and coarse filters). Rinse under running water to remove debris. Use a soft brush if needed. Reinstall the filters and tighten clockwise. Clean monthly.

Why is the dishwasher not draining?

Check if the drain hose is kinked or blocked. Clean the filter and ensure the sink drain is not clogged. If error persists, check the drain pump impeller for obstructions. Refer to the manual for error codes.

What do the error codes mean?

Common codes: E1 (water inlet problem), E4 (overflow), E8 (heating issue). For specific codes, see the troubleshooting section in the manual. If an error appears, note the code and contact technical support.

How to adjust rinse aid dosage?

Open the rinse aid dispenser door and adjust the dial (usually from 1 to 6). Start with setting 3. If dishes have spots, increase dosage. If they have streaks, decrease. Use a rinse aid specifically for dishwashers.

Can the dishwasher handle pots and pans?

Yes, the Rex IP745N has an Intensive program designed for heavily soiled pots and pans. Load them upside down in the lower rack. Ensure they are not obstructing the spray arms.

How to enable the child lock?

Press and hold the 'Start' button for 3 seconds until the child lock indicator appears. To disable, repeat the same action. The control panel will be locked to prevent unintended operation.

Where can I find spare parts?

Spare parts are available through authorized repair centers or online. Use the model number IP745N to ensure compatibility. Rex guarantees spare parts availability for at least 7 years after purchase.

USER MANUAL IP745N REX

Illustration of a mechanical device with a magnified inset showing a rotating component (no text or symbols)

Illustration of a battery cell with positive and negative terminals, alongside a bread roll and cup (no text or symbols)

Line drawing of a hand using a tool to apply liquid into a device (no text or symbols visible)

Technical line drawing of a mechanical assembly with multiple components and no visible text or symbols

Technical line drawing of a mechanical component with internal parts and no visible text or symbols

Illustration of a basket filled with leafy greens, no text or symbols present

Technical line drawing of a mechanical assembly with multiple circular components and housing (no text or symbols)

Line drawing of a multi-tiered plastic container filled with various circular components (no text or symbols)

Technical line drawing of a mechanical assembly with no visible text or symbols

Importante

Simple line drawing of a door with handles and buttons, no text or symbols present

Isometric line drawing of a kitchen interior with a rack and a bucket (no text or symbols)

Simple line drawing of a rectangular box with a dark interior and a diagonal ruler beside it (no text or symbols)
