Brand	Rex
Model	FMT5NC
Product Type	Built-in Electric Oven
Energy Source	Electric
Capacity	72 L
Dimensions (W x H x D)	595 x 595 x 575 mm
Weight	35 kg
Power Rating	3.2 kW
Voltage / Frequency	220-240 V / 50-60 Hz
Oven Functions	Bake, Broil, Defrost, Fan Forced, Grill, Rotisserie, Pizza, Slow Cook, Top/Bottom Heat
Temperature Range	50 °C - 280 °C
Control Type	Touch + Rotary Knobs
Display Type	LED Digital Display
Cleaning Type	Catalytic (self-cleaning panels)
Safety Features	Child Lock, Auto Shut-off, Overheat Protection, Cool Touch Door
Door Type	Drop-down, Tempered Glass
Number of Glass Layers	3
Interior Light	Yes, halogen
Timer	24-hour programmable timer with end of cooking signal
Energy Efficiency Class	A+
Annual Energy Consumption	0.93 kWh (standard load)
Noise Level	45 dB(A)
Net Capacity	72 L
Accessories Included	1 wire shelf, 1 baking tray, 1 broiler pan, rotisserie spit

Frequently Asked Questions - FMT5NC REX

How do I set the timer on my Rex FMT5NC oven?

Press the Timer button, then use the + and - buttons to set the desired time. Confirm by pressing the Start button.

What oven functions are available?

The Rex FMT5NC offers multiple functions including Bake, Broil, Defrost, Fan Forced, Grill, Rotisserie, Pizza, Slow Cook, and Top/Bottom Heat.

How do I activate the child lock?

Press and hold the Function and Timer buttons simultaneously for 3 seconds until a lock icon appears on the display.

How to clean the oven efficiently?

Use the Self-cleaning function if available, or manually clean with a damp cloth and mild detergent. Avoid abrasive cleaners. The door is removable for thorough cleaning.

Why is my oven not heating?

Check that the oven is properly plugged in and the circuit breaker is on. Ensure the oven function is selected and the temperature is set above room temperature. If the problem persists, contact Rex support.

How do I replace the oven light?

Disconnect the oven from power. Remove the glass cover by turning it counterclockwise. Replace the halogen bulb (G9, 40W) and screw the cover back tightly.

Can I use aluminum foil in the oven?

You can use aluminum foil, but avoid covering the oven bottom directly. Place it on a baking tray or shelf. Do not block air vents.

What does the error code E01 mean?

Error E01 indicates a problem with the oven temperature sensor. Try resetting the oven by disconnecting power for 5 minutes. If it persists, contact service.

How to preheat the oven?

Select the desired function and temperature, then press Start. The oven will preheat and a signal will sound once the target temperature is reached.

Does the oven have a rotisserie function?

Yes, the Rex FMT5NC includes a rotisserie function with a motorized spit. Insert the rotisserie spit through the meat, place it in the brackets, and select the rotisserie function.

USER MANUAL FMT5NC REX

Simple line drawing of a screw and wire connection (no text or symbols)

Fig. 2

Line drawing of a hand holding a curved object against a diagonal line, no text or symbols present

Fig. 14

Line drawing of a multi-tiered baking tray with pastries and baked goods (no text or symbols)

Fig. 15

Technical line drawing of a mechanical component with internal channels and mounting brackets (no text or symbols)

Fig. 16

La cottura al grill

Technical line drawing of a mechanical component with an inset close-up view (no text or symbols)

Fig. 17

Tabella n. 2

ALIMENTI	Quantità		Cottura a grill		Durata cottura minuti
	Numero Pezzi	Grammi	Livello	tempe-ratura °C	Lato Sup.	Lato Inf.
Bistecche	4	800	4	max	10	8
Braciole	4	600	4	max	12	8
Salsicce	8	500	4	max	10	6
Pollo a pezzi	6	800	3	max	30	20
Spiedini misti	4	700	4	max	12	10
Petto pollo	4	400	4	max	13	10
Pomodori dimezzati	8	500	4	max	12	—
Pesce, filetti	4	400	4	max	8	6
Capesante	6	—	4	max	12	—
Toast farciti	4	—	4	max	8	—
Pane a fette	4	—	4	max	2~3	1

Diagram of a mechanical device with internal components and directional arrows, no readable text or symbols

Fig. 18

PULIZIA GENERALE

PULIZIA GENERALE

Technical line drawing of a mechanical device with a central base and support brackets (no text or symbols)
