USER MANUAL DCTS151 Lanzar

MANUFACTURER'S LIMITED THREE YEAR WARRANTY

LANZAR SOUND CORP. warrants this unit to be free from defective material or workmanship and will repair or replace this unit or any part thereof if it proves defective in normal use or service within three (3) years from the date of original purchase.

our obligation under this warranty is limited to the repairing or replacing, at our discretion, the defective instrument of any part thereof when it is returned, transportation prepaid to the lanzar service centre at the address below. This warranty will be considered void if the unit has been tampered with, improperly serviced, subject to abuse or misuse or if installed in a commercial vehicle. This warranty does not cover accidental damage. When returning this unit for service, please include \$10.00 for return postage and handling. Send your unit to:

LANZAR SERVICE CENTRE

1600-63rd Street

Brooklyn, New York 11204 USA

IMPORTANT:

Pack carefully in original carton if possible. We are not responsible for damage incurred in returning items for repair. A letter stating your exact street address, daytime phone number and the problem you are experiencing should be included. You must also enclose a copy of the original receipt as proof of date of purchase.

Registor [e-mail]

SPECIFICATION	DCT8D	DCT10D	DCT12D	DCT15D
POWER(WATTS PEAK)	600	1000	1600	2000
NOM.IMPEDANCE (OHM)	DUAL 4	DUAL 4	DUAL 4	DUAL 4
SPL(DB)	84	85	84	86
FS(HZ)	40	35	28	25
QTS	0.637	0.795	0.733	0.86
VAS(CUFT)	0.613	1.008	1.852	5.218
VOICE COIL DIAMETER	1.5°BAEISV	2°BAEISV	2.5°BAEISV	2.5°BAEISV
VOICE COIL LAYER	DUAL	DUAL	DUAL	DUAL
MAGNET (OZ)	33+33	33+33	40+40	50+50
MOUNTING DEPTH,D1	4.41	9.142	10.858	13.818
OVERALL DEPTH,D2	8.46	10.772	12.718	15.354
MOUNTING DIAMETER,L1	4.41	9.142	10.858	13.818
OVERALL DIAMETER,L2	8.46	10.772	12.718	15.354

SPECIFICATION		DCTS101	DCTS121	DCTS151
POWER(WATTS PEAK)	600	1000	1600	2000
NOM-IMPEDANCE (OHM)	4	4	4	4
SPL(DB)	84	88	89	90
FS(HZ)	40	35	30	26
QTS	0.570	0.658	0.744	0.767
VAS(CUFT)	0.57	0.95	2.498	6.5
VOICE COIL DIAMETER	1.5"BAEISV	2"BAEISV	2.5"BAEISV	2.5"BAEISV
VOICE COIL LAYER	SINGLE	SINGLE	SINGLE	SINGLE
MAGNET (OZ)	33+33	33+33	40+40	50+50
MOUNTING DEPTH,D1	4.41	9.142	10.858	13.818
OVERALL DEPTH,D2	8.46	10.772	12.718	15.354
MOUNTING DIAMETER,L1	4.41	9.142	10.858	13.818
OVERALL DIAMETER,L2	8.46	10.772	12.718	15.354

THEDISTINCT .PERFORMANCE

FOR THE INSTALL WHERE ONLY A SMALL ENCLOUSE WILL DO-LANZAR ST'S DISTINCT LINE OF WOOFERS OFFER THE PREFECT SOLUTION.

OPTIMIZED FOR SMALL SEALED ENCLOSURES, DISTINCE DELIVERS EXCEPTIONAL SOUND QUALITY AND HIGH POWER HANDLING IN ONE ELEGANT WOOFER, STYLING CUES FROM THE EMBOSSED DUSTCAP WITH

BRONZE PRINTING TO THE LARGE BUT TASTEFUL MOLDED MAGNET BOOT, INSIST THAT YOU WILL HAVE A GREAT SOUNDING GAS WELL AS LOOKING INSTALL. THE EXTRAWIDESURROUNDSUPPORTSA WHILE THE DOUBLE STACKED MAGNET HELPS DELIVER GREAT BASS SOUND, TOGETHER WITH THE DUAL VOICE COIL UNIT-MAX SERIES TO BE THE ULTIMATE CHOICE FOR A VARIOTY OF USES AND NEEDS.

FROM APPLICATION SPECIFIC INSTALLS TO GREAT SMALL CAR INSTALLS-MAX SURE IS THE IDEAL WOOFER TO SUIT ALL OF YOUR NEEDS

ABOUT THIS BOOKLET

IN THIS BOOKLET, YOU COULD FIND THE SPECIFICATIONS AND TEMPLATE OF THE WOOFER.

WITH THIS INFORMATION, YOU COULD ACHIEVE THE BEST PERFORMANCE OF WOOFER CONVENIENTLY.

BELOW IS THE MEANING OF THE RATING ABBREVIATIONS.

FS: "FREE AIR RESONANCE", THIS VALUE IS THE LOWEST AUDIBLE FREQUENCY (IN HZ) OF THE WOOFER.

Q : THIS VALUE DESCRIBES THE DEGREE OF CONTROL ("DAMPING")

WHICHTHESPEAKEREXHIBITS, SPEAKERDAMPING

BOTH MECHANICAL CHARACTERISTICS (QMS) AND ELECTRICAL CHARACTERISTICS (QES). A SPEAKER'S TOTAL DAMPLING VALUE IS REFERRING AS QTS.

SPL: THIS VALUE MEANS THE SENSITIVITY OF THE SPEAKER.

THIS VALUE DESCRIBES (IN CUBIC FEET) THE MAXIMUM AMOUNT OF AIR WHICH IS DUSPLACED BY THE SPEAKER CONE IN A SINGLE EXCURSION.

BASIC FEATU

- BLACK NON-PRESSED PAPER CONE-WIDE FOAM SURROUND - STAMPED STEEL BASKET WITH SILVER INPUT TERMINAL - BUMPED &VENTED MOTOR STRUCTURE

- SPECIAL DESIGNED RUBBER MAGNET BOOT

- HIGH TEMPERATURE ALUMINUM VOICE COIL - HEAVY DOUBLE STACKED MAGNET STRUCTURE
