USER MANUAL POC Cart Anthro
Adjustable-height POC Cart has been a favorite Anthro medical cart since it was introduced in 2001. Its wide five-point chair base provides a stable and easy-to-move foundation, and the strong pneumatic cylinder lifts the 32"-42" high to position your work at a comfortable height. The POC Cart 2 is the updated version (new in 2012) with a larger work area, hidden support bracket, and the lower column cover has a new curved profile.
PRODUCT SPECIFICATIONS
Shelves: 3/4" thick 45 lb. industrial-grade particle board with high-pressure, scratch-resistant laminate. Vinyl contour edge banding matches the laminate.
Column and Base: Column is a pneumatic cylinder behind a removable steel cover that conceals and protects cords and cables. Five-point star base.
Casters: Soft rubber, black, twin-wheel 4" casters, two locking.
Warranty: Lifetime Warranty against manufacturing defects on the cart; 5-year warranty on the column.
Adjustable-height POC Cart 2, loaded up with bins and shelves plus holders for keyboard and monitor.
- The new POC Cart-2 uses the same height-adjustable column and wide chair base as the original POC Cart, now updated with a larger top and new colors. The cart adjusts 32"-42" high with the squeeze of the lever.
- The large shelf measures 24.5"w x 21"d, plenty of space for all your equipment and supplies. It's also big enough to support a storage drawer or retracting keyboard.
- The curved trunk cover conceals the pneumatic cylinder inside and routes equipment cords and cables out of sight. Knobs on the outside edges of the cover hold optional shelves and bins on the front and back.
- Two versions, Standard (POCD-series) and Super (POCE-series). The column in the Standard version is balanced to lift 16-30 lbs. The column in the Super version is balanced to lift 27-41 lb. Include the weight of the accessories when calculating the load on the column. Lighter loads will be harder to push down; heavier loads will be harder to pull up. Weight ranges are estimates only.
- Comes with shelf, gas cylinder with rubber cylinder cover and lever, cable, trunk, black star base, and 5 casters (4", 2 locking).
- Overall weight capacity of 150 lbs. The cap shelf holds 50 lbs., but cylinder lifts less.
- Wide 5-point chair base provides plenty of stability and the large 4" casters (2 locking) move over rough surfaces, in and out of elevators, and stay in place when locked.
- Lifetime Warranty against manufacturing defects; Five Year Warranty for the cylinder.
• Available in Cool Grey (CG) metal with Fog (FG) laminate or Silver Satin (SS) metal with Blanc (BC) laminate.
| PRODUCT | Height Range | Weight (2 boxes) | Part # | Price | |
| POC Cart-2, Standard | 32"-42" | 35 lbs./33 lbs. | POCDzz/xx4 | 659 | |
| POC Cart-2, Super | 32"-42" | 35 lbs./33 lbs. | POCEzz/xx4 | 689 |
POC CART
- Comes with shelf, handle, gas cylinder with rubber cylinder cover and height-adjustment lever, cable trunk, black star base, and 5 casters (4" size, 2 locking).
• The gas cylinder is balanced to lift 16-30 lbs. - Overall weight capacity of 150 lbs. Cap shelf holds up to 50 lbs, but the cylinder lifts 16-30 lbs.
| PRODUCT | Height Range | Weight (2 boxes) | Part # | Price | ||
| POC Cart | 32"-42" | 27 lbs. / 22 lbs. | POCCSM/LG | $599 |
POC CART ACCessORies
DOCumenT sTAnD
- Comes with steel stand, 10" gooseneck and C-clamp. Attaches onto the edge of any shelf.
- The lip of the steel stand is 2" deep and .5" high to securely hold your documents, a book, or a multi-line phone.
• Available in Black (BK).
| PRODUCT | Width | Depth | Height | Weight | Part # | Price |
| Document Stand | 14.25" | 2" | 11" | 4 lbs. | 440BK | $139.95 |
Black (BK)
EQUIPMENT HOLD-DOWN
- Secure your monitor or other equipment to a shelf with this handy kit. Attach an adhesive-backed buckle to one side of your equipment and another to the shelf, then feed the included strap through the buckles to secure.
- Comes with four adhesive buckles, two Polypropylene straps (1" wide x 8" long), and two alcohol pads for cleaning equipment and shelves.
| PRODUCT | Part # | Price | |
| Equipment Hold-down | 333BK | $29.95 |
EQUIPMENT STRAP
- Keep your equipment in place with this strap. Clamps to the sides on any wood shelf with a pair of C-clamps.
- Comes with nylon strapping (1.5" wide x 8' long).
- Clamps are available in Black (BK) or Silver Metallic (SM). Strap is Black (BK).
| PRODUCT | Weight | Part # | Price | |||
| Equipment Strap | 2 lbs. | 385zz | $39.95 |
FLAT PANEL MONITOR MOUNT
Lots of choices for your flat panel monitor! Pick the features you need. Note: all mounting options conform to VESA 75mm and 100mm mounting standards. If you need a different standard or would like to discuss additional monitor solutions that we have available, give us a call.
SINGLE MONITOR
DUAL MONITOR
- The Single, Dual, and Dual Heavy-duty mounts use a 13" high stand and tilt-and-swivel knuckles to support your monitors. The Single (part #615zz) supports a single display up to 22 lbs. The Dual (part #617zz) supports two displays up to 22 lbs. total and 17" across. The Dual Heavy-duty (part #627zz) supports two displays up to 44 lbs. and 20" across. The mount base is 4.5"w x 4.5"d.
- Need a monitor mount that takes up as little space on your cart as possible? Choose the Flat Panel Mount – Compact 18". A simple 1-1/2"-diameter tube mounts directly to your cart shelf. The tube is 18" long with holes every inch for installation of the tilt-and swivel mount. Holds up to 22 lbs. Works with POC-2 only.
- Need a mount that's a little taller? Choose the Extension Tube – Large 26" and add either a one-monitor or two-monitor knuckle to it. The Extension tube is a 2.5"-diameter tube with a 4.5"-diameter base. The tube has holes every inch for installation of a tilt-and-swivel knuckle assembly. Choose the Single (part #ZPMSzz) or Dual (part #ZPMDzz), supports two displays up to 44 lbs. total and 20" across), sold separately. Works with POC-2 only.
• Install by drilling through the shelf and securing to the shelf bracket with four bolts. Drill required for installation.
• Available in Black (BK), Putty Grey (PG), and MiniCart bonus colors Cool Grey (CG) and Silver Satin (SS).
| PRODUCT | Weight | Part # | Price | ||
| Single Monitor | 7 lbs. | 615zz 209.95 | |||
| Dual Monitor | 12 lbs. | 617zz299.95 | |||
| Heavy-Duty Dual Monitor (not pictured) | 15 lbs. | 627zz 339.95 | |||
| Flat Panel Mount - Compact 18" | 4 lbs. | MFP18zz169.95 | |||
| Extension Tube - Large 26" | 5 lbs. | ZET26zz 99.95 | |||
| Single Flat Panel Knuckle for Extension Tube | 5 lbs. | ZPMSzz139.95 | |||
| Dual Flat Panel Knuckle for Extension Tube | 17 lbs. | ZPMDSB $319.95 |
QuickShip available for Single Monitor Mount in Putty Grey (PG) only.
HANDLE
- Cast aluminum handle helps you easily steer your POC Cart-2 right where it's needed!
- At 17" wide, it gives you a good grip. Installs to the shelf with 4 screws.
• Available in Cool Grey (CG) or Silver Satin (SS).
| PRODUCT | Weight | Part # | Price |
| Handle | 4 lbs. | ZHzz | $49.95 |
COIOR CHOiCes
Select your product colors from the following swatches. Replace "zz" with a 2-letter Metal Code and "xx" with a 2-letter Laminate Code.
POC Combo (SM/LG)
POC 2 Cool Grey Combo (CG/CG)
POC 2 Silver Satin Combo (SS/BC)
KeYBOARD DRAweR
- Retractable keyboard surface slides in and out on full-extension glides and extends 3.5" below the surface.
- Installs under the shelf of the POC Cart-2 at the front or the back.
• Available in Cool Grey (CG) metal with Fog (FG) laminate or Silver Satin (SS) metal with Blanc (BC) laminate
| PRODUCT | Width | Depth (A) | Depth (B) | Weight | Part # | Price | |
| Keyboard Drawer - POC Cart 2 | 19.75" | 10.75" | 8.75" | 14 lbs. | 637zz/xx | $149.95 | |
Works with POC Cart 2 only.
siDe Bin
- Installs to the side, front, or back of your POC Cart-2 with three fasteners.
- Measures 12"w x 5.75"h. Tapers from 3.25" top depth to 2.25" bottom depth. Hangs down 8" below the shelf.
• Available in Cool Grey (CG), Silver Satin (SS), or Slate Blue (SB) metal.
| PRODUCT | Width | Depth | Height | Weight | Part # | Price |
| Side Bin | 12" | 2.25" | 5.75" | 6 lbs. | ZSBzz | $69.95 |
smAll sHelf
- Comes with adjustable strap and buckle to secure equipment.
• Available in Silver Metallic (SM), Silver Satin (SS), Slate Blue (SB), or Cool Grey (CG) and has a weight capacity of 40 lbs.
| PRODUCT | Width | Inside Depth | Outside Depth | Weight | Part # | Price |
| Small Shelf | 12" | 7.25" | 9" | 3 lbs. | 621zz | $54.95 |
QuickShip available in Silver Metallic (SM) only.
IARge sHelf
- Comes with adjustable strap and buckle to secure equipment. Use this shelf to hold your CPU or other large items.
• Available in Silver Metallic (SM), Silver Satin (SS), Slate Blue (SB), or Cool Grey (CG) and has a weight capacity of 40 lbs.
| PRODUCT | Inside Width | Outside Width | Inside Depth | Outside Depth | Weight | Part # | Price |
| Large Shelf | 24.5" | 18.25" | 8.25" | 11.5" | 10 lbs. | 623zz | $99.95 |
QuickShip available in Silver Metallic (SM) only.
meTAl Bin
- Attaches along the trunk in 2" increments with 4 easy-to-adjust knobs.
• Available in Silver Metallic (SM), Silver Satin (SS), Slate Blue (SB), or Cool Grey (CG) and has a weight capacity of 40 lbs.
| PRODUCT | Width | Depth | Height | Weight | Part # | Price |
| Metal Bin | 12.25" | 8" | 3.75" | 10 lbs. | 635zz | $69.95 |
QuickShip available in Silver Metallic (SM) only.
MOUSE SOLUTIONS
Mouse Shelf - Swing-out
| • Made of heavy-duty phenolic in neutral granite finish. Attaches to wood surfaces. Drill required for installation. | ||||||||
| PRODUCT | Width | Depth | Weight | Part # | Price | |||
| Mouse Shelf - Swing-out | 8" | 9" | 2 lbs. 687BK $69.95 | |||||
Mouse Holder
PROBE HOLDERS
| • Store your mouse in this handy holder on the side or front of your workstation. Especially useful in mobile applications to protect your mouse from falling off the worksurface. | ||||||
| • Attaches to any wood surface with two wood screws. Mounting bracket is 5"w x 1"d. Drill required for installation. | ||||||
| • Available in standard AnthroCart colors Black (BK) and Putty Grey (PG). Also available in MiniCart bonus colors Silver Satin (SS) and Slate Blue (SB). | ||||||
| PRODUCT | Height | Width | Depth | Weight | Part # | Price |
| Mouse Holder | 5" | 5.75" | 4" | 2 lbs. | ZMHz | $39.95 |
| • Brackets measure 1.5" wide x 2.5" deep and attach to the bottom of any wood surface with 2 screws.Cushioned cups are open on the bottom and snap into place. |
| • Cups come in grey and light green. Brackets available in Black (BK) and Putty Grey (PG) plus MiniCart bonus colors Silver Satin (SS) and Slate Blue (SB). Drill required for installation. |
| PRODUCT | Width | Depth | Height | Weight | Part # | Price |
| Probe Holder, Small | 2.5" | 3.5" | 2.5" | 1 lb. | ZGCSCG | 44.95 |
| Probe Holder, Large | 2.5" | 3.5" | 4.5" | 1 lb. | ZGCLCG | 49.95 |
QuickShip available for Large Probe Holder only.
SCANNER BRACKET
| • Keep your barcode scanner right at hand with this metal bracket. Inside opening on bracket is 1.5"w x 2"d. • Available in Black (BK) and Putty Grey (PG) plus MiniCart bonus colors Silver Satin (SS) and Slate Blue (SB). • Installs on any wood surface with two screws. Drill required for installation. | ||||||
| PRODUCT | Height | Width | Depth | Weight | Part # | Price |
| Scanner Bracket | 3.5" | 2.25" | 5.25" | 1 lb. | 886SM | $29.95 |
SECURITY CABLE, 36"
| • Protect laptops and hard drives from theft with this adapter. The lock attaches to the back of your laptop or hard drive and the cable loops around the legs or brackets of your station. | ||||
| • Comes with a cable, lock, and 2 keys. | ||||
| PRODUCT | Length | Weight | Part # | Price |
| Security Cable, 36" | 36" | 2 lbs. | 960SM | $119.95* |
