| Product Type | Wireless Microphone System Transmitter |
| Brand | Lectrosonics |
| Model | SMV/X |
| Dimensions (approx.) | 1.9 x 7.5 inches (48 x 191 mm) |
| Weight (approx.) | 5.3 oz (150 g) with battery |
| Power Source | 2 AA alkaline batteries, 3.0 V |
| Battery Life (approx.) | Up to 8 hours |
| Frequency Range | 470-608 MHz (UHF) |
| RF Power Output | 50 mW (selectable to 10 mW) |
| Audio Input | Servo Bias lavaliere microphone input (TA5M) |
| Audio Output | Not applicable (transmitter) |
| Frequency Response | 50 Hz – 20 kHz (+/- 1 dB) |
| Signal-to-Noise Ratio | 107 dB (A-weighted) |
| Polar Pattern (lavaliere) | Omnidirectional (depending on microphone used) |
| Modulation Type | FM (Digital Hybrid Wireless®) |
| Operating Temperature | -20°C to +50°C |
| Maintenance | Wipe with dry cloth; avoid moisture and extreme temperatures |
| Safety Precautions | Use only approved batteries; do not disassemble; keep away from water |
| Spare Parts / Repairability | Contact authorized service center; replaceable battery door and belt clip |
| Warranty | 2 years (subject to terms) |
Frequently Asked Questions - SMV/X Lectrosonics
How do I turn on the SMV/X transmitter?
Press and hold the Power button located on the side of the unit for about 2 seconds until the display lights up.
What type of batteries does the SMV/X use?
It uses two AA alkaline batteries. For best performance, use high-quality lithium or rechargeable NiMH batteries.
How do I charge the SMV/X?
The SMV/X does not have a built-in charger. Remove the batteries and charge them in an external charger. Do not attempt to charge non-rechargeable batteries.
Can I use a different microphone with the SMV/X?
Yes, the SMV/X accepts any standard servo bias lavaliere microphone with a TA5M connector. Ensure compatibility with Lectrosonics wiring.
What is the range of the SMV/X?
In typical conditions, the operating range is approximately 300 to 1000 feet (100 to 300 meters) depending on obstacles and RF environment.
How do I clean the SMV/X?
Use a soft, dry cloth to wipe the exterior. Avoid solvents or abrasive cleaners. Keep the microphone grille free of debris.
Why is the audio distorted?
Check the input gain settings on the transmitter. Reduce the gain if the audio level is too high. Also ensure the microphone capsule is not blocked.
How do I change the frequency on the SMV/X?
Access the menu by pressing the MENU button, then use the arrow keys to select 'Frequency'. Adjust using the same keys and confirm.
Is the SMV/X compatible with other Lectrosonics receivers?
Yes, it works with all Lectrosonics Digital Hybrid Wireless® receivers. Ensure both units are set to the same frequency band.
Where can I find the user manual?
The user manual is available for free download on notice-facile.com or the Lectrosonics official website in PDF format.
