XHT-450U - Hedge Trimmer XU1 - Free user manual and instructions

Product Type	Hedge Trimmer
Brand	XU1
Model	XHT-450U
Power Source	Electric (mains)
Voltage	230 V~
Frequency	50/60 Hz
Power Input	450 W
No Load Speed	1300 min⁻¹
Cutting Length	450 mm
Blade Type	Dual action steel blades
Stroke Rate	3000 strokes/min
Max Branch Thickness	20 mm
Weight	3.5 kg
Handle Type	Ergonomic soft grip
Safety Guard	Yes
Double Switch Safety	Yes
Blade Lubrication	Automatic oiling system
Working Position	Vertical and horizontal cutting
Included Accessories	Blade cover, wrench, user manual
Color	Orange and black
Noise Level	95 dB(A)
Vibration Level	5 m/s²
Warranty	12 months

Frequently Asked Questions - XHT-450U XU1

How do I start the hedge trimmer?

Connect the power cord to a suitable mains outlet. Press and hold the safety lock button located on the handle, then squeeze the trigger switch. Release the safety lock once the trigger is engaged.

What is the maximum branch thickness I can cut?

The XHT-450U can cut branches up to 20 mm in diameter. For thicker branches, use a pruning saw first.

How do I lubricate the blades?

Lubricate the blades before and after use. Apply a few drops of lightweight machine oil along the blade edge while the trimmer is running briefly. Wipe off excess oil.

Can I use an extension cord with this hedge trimmer?

Yes, use a heavy-duty extension cord rated for outdoor use. Ensure the cord is suitable for the power input (450 W) and has a minimum cross-section of 1.5 mm².

What safety precautions should I take?

Always wear protective gloves, safety glasses, and ear protection. Keep the power cord away from the cutting area. Never carry the trimmer by the cable. Disconnect from power before cleaning or adjusting.

How do I maintain the hedge trimmer?

After each use, clean the blades with a soft brush and lubricate. Store in a dry place. Check for loose screws and tighten if needed. Have the trimmer serviced by a qualified technician if performance declines.

What should I do if the blades become jammed?

Turn off and unplug the trimmer. Carefully remove any debris using pliers or a stick. Check for bent teeth and sharpen if necessary. Lubricate before restarting.

How do I achieve a straight cut on a hedge?

For a straight cut, use a string line as a guide. Hold the trimmer parallel to the hedge and move it in a sweeping motion from the bottom up. Trim a little at a time to maintain shape.

What is the best time of year to trim hedges?

Late spring or early summer is ideal for most hedges. Avoid trimming during severe frost or extreme heat. Check local guidelines for nesting birds.

Where can I get spare parts for this model?

Spare parts such as blades, blade cover, and switch are available from XU1 authorized dealers. Contact customer service using the number on the guarantee card, or visit the website for a list of parts.

USER MANUAL XHT-450U XU1

XU1 Power tools Telephone: GB: 0151 294 4488 / IRL: 1850 882711

IHT-453U 101.T

SAFETY INSTRUCTIONS

ALWAYS WEAR EYE AND EAR PROTECTION

Electrical safety

Before you connect the charger to the mains supply, make sure that the data on the rating plate are identical to the mains data.

This tool is double insulated; therefore no earth wire is required.

Using an extension lead

Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.

The power supply for this product should be protected by a residual current device (rated at 30mA or less). A residual current device reduces the risk of electric shock.

If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord available through the service organization.

Description of symbols

Caution! - Read the operating instructions to reduce the risk of inquiry.

Do not expose the hedge trimmer to rain or wet conditions.

If the cable is damaged or cut, pull out the power plug from the mains immediately.

General Power Tool Safety Warnings

1. Work area safety
   a. Keep work area clean and well lit. Cluttered or dark areas invite residents
   b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools
   create sparks which may ignite the dust or fumes.
   c. Keep children and bystanders away while operating a power tool. Distractions can cause you
   operating a power tool shutdowns can issue just to lose control.
2. Electrical safety a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed
   (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock
   b. Avoid body contact with earthed or
   grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
   c. Do not expose power tools to rain or wet
   conditions. Water entering a power tool will increase (the risk of electric shock).
   d. Do not abuse the cord. Never use the cord
   for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
   e. When operating a power tool outdoors, use
   an extension cord suitable for outdoor use.
   Use of a cord suitable for outdoor use reduces the risk of electric shock.
   f. If operating a power tool in a damp location
   is unavoidable, use a residual current
   device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
   a. Stay alert, watch what you are doing and
   use common sense when operating a power tool. Do not use a power tool while you
   are tired or under the influence of drugs,
   alcohol or medication. A moment of inattention while operating power tools may result in serious
   while spending power taxes may result in serious personal injury.
   b. Use personal protective equipment. Alway
   wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
   protection used for appropriate conditions will reduce
   personal injuries.
   c. Prevent unintentional starting. Ensure the switch is in the off-position before
   connecting to power source and/or battery
   pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or expanding
   power tools that your finger on the switch or charging power tools that have the switch on invites accidents.
   d. Remove any adjusting key or wrench before
   turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in
   distinguished to raising part of the power that may result in personal injury.
   e. Do not overreach. Keep proper footing and
   balance at all times. This enables better control of the power tool in unexpected situations.
   f. Dress properly. Do not wear loose clothing
   or jewellery. Keep your hair, clothing and
   gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
   p. If devices are provided for the connection
   of dust extraction and collection facilities,
   ensure these are connected and properly used. Use of dust collection can reduce dust-related
   hazards.
   h) Do not let familiarity gained from frequent use of tools allow you to become
   complacent and ignore tool safety
   principles. A careless action can cause severe injury within a duration of a second
4. Power tool use and care
   a. Do not force the power tool. Use the correct
   power tool for your application. The correct power tool will do the job better and safer at the rate for

which it was designed.
Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be
be consisted with the switch is dangerous and must be repaired.
. Disconnect the plug from the power
source and/or remove the battery pack, if detachable, from the power tool before
in accordance, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
. Store idle power tools out of the reach
of children and do not allow persons unfamiliar with the unauthorized or these
unfamiliar with the power tool of these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
- Maintain power tools and accessories. Check for misalignment or binding of
Check for misalignment of binding of moving parts, breakage of parts and any
other condition that may affect the power
tool's operation. If damaged, have the power tool repaired before use. Many accidents
power tool repaired before use, many tools are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
. Use the power tool, accessories and
tool bits etc. in accordance with these instructions, taking into account the
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery handles and opening surfaces do not allow fresh
handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
1. Service
. Have your power tool serviced by a qualified repair person using only identical
qualified repair person using only identical replacement parts. This will ensure that the safety
of the power tool is maintained.
[Non-Text]
Hedge Trimmer Safety Warnings
Keen all parts of the body way from the puller.
Blade. Do not remove cut material or hold material to
be cut when blades are moving. Make sure the switch
is off when cleaning jammed material. A moment of inattention while operating the hedge trimmer may
result in serious personal injury.
Carry the hedge trimmer by the handle with the
cutter blade stopped. When transporting or storing the hedge trimmer always fit the cutting device cover
Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact hidden
only, because the cutter blade may contact manual wiring. Cutter blades contacting a "live" wire may make
exposed metal parts of the power tool "live" and could give the engrates an electric shock.
give the operator an electric shock. Keep the cable out of the wiling zone. During
Keep the cable out of the cutting zone. During operation the cable may be covered by hedges and cut
through by accident.
lease read this safety information and the directions for use
arefully and be sure to follow the instructions to the letter.
. Allmays remove the power plug from the socket-outlet before you perform any work on the hedge trimmer, e.g.
– repairing a damaged cable
- cleaning the blades - troubleshooting
– cleaning and maintenance
or before leaving the tool unattended.
. The hedge trimmer can cause serious injuries! Read the proceedings for use probability in order to copy print yourself.
directions for use carefully in order to acquire yourself with the correct way to handle, set up, service, start and
put down the machine. Familiarize yourself with all the

machine's control elements and its proper use.

1. Always handle the hedge trimmer with both hands.
2. When working with the hedge trimmer, wear sturdy shoes 2.7. Shown your turnbentings and also has no of any potential dangers which you may not be able to hear due to the
   and make sure of your footing. machine's noise.
3. Never work with the hedge trimmer in the rain or on wet hedges, and never leave the hedge trimmer outdoors. The 26. Never try to work with an incomplete machine or a machine with unapproved modifications.
   hedges and never leave the hedge trimmer outdoors. The machine with disapproved modifications. hedge trimmer must not be used if it is wet.
4. It is advisable not to use the hedge trimmer when other
5. We recommend that you wear safety goggles and ear—persons, and particularly children, are nearby.
   muff s when working with the hedge trimmer. 30. Children are not allowed to use the hedge trimmer.
6. Wear suitable working clothes such as rubber gloves and pop. clin shoes. Do not wear loose garments. Keep long.
7. The machine may exceed 85 db (A) at the workplace.
   Non-slip should do not make loose garments. Keep long hair in a hairnet. The operator will require noise protection measures and ear muff's if this is the case.
8. Avoid abnormal postures and make sure of your footing, 32. Always ensure that all the handles and safety equipment
   particularly when working on ladders and steps. is fitted when the hedge trimmer is in use.
9. Keep the equipment at a suitable distance from your body while working, lower attempt to rescue cuttings with the 33. Examine the hedge for any concealed objects, e.g. wire,
   write working. Never assist to remove cutings with the blade running or to hold material you want to cut. Always before you start your work.
10. This equipment is not designed to be used by people.
    switch off the equipment before attempting to remove 34. This equipment is not designed to be used by people (including children) with limited physical, sensory or
    any jammed cuttings. A single moment of carelessness when using the hedge trimmer can result in serious mental capacities or those with no experience and/
    injuries. or knowledge unless they are supervised by a person who is responsible for their safety or they have received
11. Make sure there are no other persons or animals within instructions from such a person in how to use the
    your working area (radius of swing). equipment safely. Children must always be supervised
12. Carry the hedge trimmer only by its guide handle. In order to ensure that they do not play with the equipment.
13. Keep the cable out of the cylinder area. During operation
14. Keep the cable out of the cutting zone, during operation the cable may be hidden in the hedge and be cut 35. The equipment should be operated via a residual current
    through by accident. protective device (RCD) with a trip current of no more
15. Before you use the hedge trimmer, examine the power than 30 mA. Do not lose this safety information.
16. Use the heating trimmer only when the power cable is in Do not lose this information
17. Use the hedge trimmer only when the power case is in ____ do not lose this information. good working order.
18. Do not remove the power plug from the socket-outlet
    by pulling on the cable. Never carry the tool by its cable.
    Take care not to damage the cable in any way.
19. Protect cables from Intel, classic Iridus and sharp edges. Replace damaged cables immediately. Danger!
20. Examine the cutting system regularly for signs of Sound and vibration
    damage and, if necessary, arrange for the hedge Sound and vibration values were measured in
    thirmer to be professionally repaired by the ISC accordance with EN 60745. Customer Service Center or a specialist workshop
21. If the blades become jammed, e.g. due to thick L_µ Sound Pressure Level: 81.6dB(A)
    branches or the like, switch off and unplug the hedge K μt Uncertainty: 3 dB
    thinner immediately. Only then are you to remove the cause of the obstruction. L out Sound Power Level: 101.6dB(A)
22. Keep the hedge trimmer in a dry place out of children's K _ext Uncertainty: 3 dB
    reach.
23. During transportation and storage of the hedge trimmer, Wear ear-muffs.
    Keep the blades covered at all times with the special guard. The impact of noise can cause damage to hearing.
24. Take care not to overload the hedge trimmer and do not Total vibration values (vector sum of three directions)
    use it on jobs for which it is not intended, i.e. you are determined in accordance with EN 60745.
    allowed to use the hedge trimmer only to cut hedges, struts and perennials
25. Use only cables and connectors approved for outdoor Front handle Wibration emission value sh = 6.214 m/ct
    use: K uncertainty = 1.5 m/s²
    – power cable H07RN–F 2x1.0 with integral two–plug plug
    – extension cable H07RN–F 3G1.5 with rain–water– Rear handle
    protected earthing—pin plug and earthing—contact Vibration emission value ah = 5.328 m/s ² K uncertainties = 1.5 m/s ²
    coupling. It uncertainty = 1.5 m/s — The use of a leakage—current or earth leakage
    circuit-breaker is recommended for operating electric The specified vibration value was established in
    tools. Ask your electrician! accordance with a standardized testing method. It
26. The hedge trimmer requires regular inspection and maintenance. However, replace damaged blades in
    maintenance. Always replace damaged blades in pairs. If the hedge trimmer suffers any damage from is used and may exceed the specified value in exceptional circumstances.
    impact (falling on hard ground etc.), have it checked
    Immediately by a specialist. The specified vibration value can be used to compare
27. Cook after your hedge trimmer carefully. Keep it clean and sharp to ensure efficient and safe cutting. Follow the equipment with other electric power tools.
    the maintenance and cleaning instructions. The specified vibration value can be used for initial
28. The German Farmers Union, for example, prohibits the use of electric bader trigono by farmers aged 17 or
    use of electric guidance entirners by persons aged 17 or less. Persons aged 16 and above may only use electric
    hedge trimmers if supervised by an adult.
29. Do not use the hedge trimmer with a damaged or

toccessively with cutting system.

2

Keep the noise emissions and vibrations to a

minimum.

• Only use appliances which are in perfect working order.

• Service and clean the appliance regularly.

• Adapt your working style to suit the appliance.

• Do not overload the appliance.

• Have the appliance serviced whenever necessary

- Switch the appliance off when it is not in use. - Wear protective gloves

- Wall problematic gloves.

Caution!

Residual risks

Even if you use this electric power tool in accordance with instructions, certain residual

accordance with instructions, certain residual risks cannot be risks out. The following herends

risks cannot be rules out. The following hazards may arise in connection with the equipment's

they drive an connection that is equipment's construction and layout:

1. Lung damage if no suitable protective dust mask

is used.

1. Damage to hearing if no suitable ear protection is

used.

1. Health damage caused by hand-arm vibrations if

the equipment is used over a prolonged period or is not properly guided and maintained.

not properly guarded and maintained

) 479

图

八

-

For EU countries only

Never

never passes any severe pain. Loss in your household refuse.

To come

to comply with European Branches 2012/TAREC concerning old electric and electronic equipment

implementation in national laws, old electric power tools

have to be separated from other waste and disposed of in an environment-friendly fashion, e.g. by taking to a

recyclin

Downside alternative in the return proved

As an alternative to returning the equipment to the

manufacturer, the owner of the electrical equipment

must make sure that the equipment is properly disposed of if he no longer wants to keep the equipment. The old

A 10.5 for longer time to help the equipment. This is equipment can be returned to a suitable collection point

that will dispose of the equipment in accordance with the national recycling and waste disposal regulations. This

national recycling and waste disposal regulations. This does not apply to any accessories or aids without electrical

components supplied with the old equipment.

Subject to technical changes

Subject to technical charges

SERVICE INFORMATION

Please note that the following parts of this product are

subject to normal or natural wear and that the following

parts are therefore also required for use as consumables.

Category Example

"Woor parts" Blade guide, Carbon brushes,

Consumables" Blade

Missing

* Not necessarily included in the scope of delivery!

[Non-Text]

SPARE PARTS

Spore parts can be ordered from the Special Orders Desk at

your local Bunnings Warehouse or Homebase store.

For further information, or any parts visit www.azfp-dly.co.uk or contact Ozfp-Dustomer-Service:

Great Britain: 0151 294 4488

Ireland: 1850 882711 E-mail: [e-mail]

1. 10.1.1.1.1.1.1.1.

SPECIFICATIONS

Motor: 520W

Cutting Length: 360mm

Cutting Capacity: 16mm

No Load Speed: 1,800/min

Electric Blade Brake: Yes

Cuts per minute: 3500/min

Protection class: 1 Weight: 2.0kg

Weight: 2.0kg

Items Supplied Please check that the article is complete as specified in

the scope of delivery. If parts are missing, please contact

our service centre or the sales outlet where you made your purchase at the latest within 5 working days after

purchasing the product and upon presentation of a valid b

of purchase. Also, refer to the warranty table in the service information at the end of the operating instructions.

- Open the packaging and take out the equipment with

care. - Remove the nackarino material and any nackarino and

Transportation braces (if available).

- Check to see if all items are supplied.

- inspect the equipment and accessories for transport damage.

- If possible, please keep the packaging until the end of the

guarantee period.

DANGER! The equipment and packaging

material are not toys. Do not let children play with plastic bags, foils or small parts. There is

a danger of swallowing or suffocating!

Proper Use

Important. This hedge trimmer is suitable for cutting beda

important. This route is within the database for setting hills, bushes and shrubs.

The equipment is to be used only for its prescribed purpose

Any other use is deemed to be a case of misuse. The user / operator and not the manufacturer will be liable for any

1. Operation and not the manufacturer of the basis for any damage or injuries of any kind caused as a result of this.

Please note that our equipment has not been designed

for use in commercial, trade or industrial applications. Our warranty will be voided if the machine is used in

commercial, trade or industrial businesses or for equivale

purposes.

ASSEMBLY

A WARNING! Ensure the tool is switched off

and disconnected from the power supply

before performing any of the following tasks.

Blade cover

The blade cover protects the blade when not in use. Simply slide it off the blade before use. Once finished

simply slide it on the blade before use, once finished operating, place the cover back over the blade FIG. A.

WARNING: Unvs plod the Linjmo Trimmer

WARNING: Never Start the Hedge Trimmer while the blade cover is fitted

(No text)

WARNING! When handling the blade

assembly, wear non-slip, heavy-duty protective gloves. Do not place your hand

or fingers between blades or in any position

where they could get pinched or cut. Never touch blades or service the unit with the

Safety guard

1. Align both sides of the supplied Safety Guard over the Blade Support Rail and holes in the base of the

the state support that and noted in this case of the motor housing.

1. Push the Safety Guard down and fix securely on

both sides of the motor housing using the screws provided. FIG. B

provisco. FIG. B.

WARNING! Never use the Hedge Trimmer

unless the safety guard is fitted.

[Non-Text]

Using an extension lead

Always use an approved extension lead suitable for

the power input of this tool. Before use, inspect the

extension lead for signs of damage, wear and again. Replace the extension lead if damaged or defective.

When using an extension lead on a reel, always

unwind the lead completely. Use of an extension lea not suitable for the power input of the tool or which

damaged or defective may result in a risk of fire and electric shock.

electric shock,

OPERATION

▲ WARNING! Do not use the boating tripsmos.

WARNING! Do not use the hedge trimmer with any type of accessory or attachment.

Such usage might be hazardous.

2.1.1.1 7:3

Switching on FIG. C.

WARNING! The power supply for this

product should be protected by a residual current device rated at 30mA or less.

The Ground Truth image displays a single, solid horizontal line, which is a stylistic or background element (like a ruled paper line). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a fill-in-the-blank placeholder. Since the OCR output incorrectly rendered a stylistic line as underscores (which should be ignored), this violates the rule. Therefore, the OCR result is inconsistent with the Ground Truth.

For your safety this Hedge Trimmer is designed with

a two hand safety switch. This prevents accidental starting. If you only squeeze the on/off trigger the

Hedge Trimmer will not start.

1. With one hand depress and hold the Safety Switc

in the front handle.

1. With your other hand, squeeze the On/Off Trigger

the rear handle to start the hedge trimmer.

Switching off

1. Release with the On/Off Triness or Safety Switch

2. Release Eliber the On/Off Trigger of Safety Switch

Blade brake

The hedge trimmer is fitted with an electric brake

which very quickly brings the blades to a stop as soon as either the rear handle on/off trigger or front

handle safety switch are released.

This is an important safety feature that greatly

reduces the chance of injury to the operator if a hand

slips off the front or rear handle and control is lost temporarily.

When the unit is switched off and the motor helps

when the unit is switched on and the motor brake operates there may be some sparking (or flashing) in

the area of the upper motor ventilation slots. This is

normal and does not indicate any problem.

Working position

HARWARI: The following table

WARNING! Clear the area to be cut before each use. Remove all objects, such as cords,

lights, wire, or string which can become attached in the cutting bands and cards.

enhanged in the cutting blade and create a risk of serious personal injury

(No text)

WARNING! Keep extension cord away from

Blades and behind the thrimmer when cutting.

Maintain proper footing and balance and do not

overreach. Please wear safety goggles, nonslip footwear and rubber gloves when trimming. Hold

toothrust and rubber gloves when thinning, hold the tool firmly in both hands and turn the tool on by

squeezing both switches.

Always hold the trimmer with one hand on the front

handle and one hand on the rear handle. Never hold the tool by the Safety Guard.

the tool by the safety guard.

Top cutting FIG. D.

Use a wide sweeping motion. A slight downward tilt of the cutting blades in the direction of motion gives

of the cutting blades in the direction of motion gives the best cutting results.

。

Side cutting FIG. E.

When trimming the sides of the hedge, begin at the

bottom and cut upwards. Trim the side of a hedge so that it will be slightly narrower at the top. This shape

will expose more of the hedge, resulting in a more

uniform growth.

Trimming tips

• To obtain exceptional level hedges a piece of string can be stretched long the top of the hedge as a

can be stretched long the top of the hedge as a guide.

- When side trimming herdges, begin at the bottom

When also thinning mitigated, began at the bottom and sweep upwards.

• The hedge should be trimmed to achieve a

trapezoidal form, that is it should be wider at the

bottom than the top. This improves the penetration of light to the lower extremities. A general guideline

is approximately 10cm slant for each 1 metre of

hedge height.

• The best cutting sequence is to first cut both sides,

starting at the bottom and working to the top; this prevents cuttings from failing into the area of the

hedge where you are still working.

- When trimming the top of a hedge and the

branches have grown extremely long, cut back in

several stages. The shorter the cuttings the better suited for composting.

a. When classes hedged are to be out back a obstetric

- When order hedges are to be cut back a substantial amount, use pruning shears or some other device

to trim branches thicker than 16mm.

• To shape precisely run a taught line between the

extreme edges of the hedge and then trim along the length of the line.

lengui

• The most effective way to trim new growth is to use a wide avvening motion, feeding the blade truth.

a wide sweeping motion, feeding the blade bead through the twigs. A slight downward tilt of the

blade, in the direction of motion gives the best cut.

- Do not use the Trimmer for cutting stems greater

than 16mm in diameter. Use the trimmer only for cutting normal shrubbery found around houses an

cutting normal shrubbery rounds around houses and buildings.

WARNING: Ensure the hazard do not come

WARNING: Ensure the blades do not come into contact with any object made of hard

material that could damage the blades. Such as fanning wire or metal plant supports

as forcing into or metal plant supports.

WARNING! If the blade jams on any

electrical cord or line, do not touch the blade! It can become electrically like and

Blade: It can become cloudy live and very dangerous. Continue to hold the hedge

trimmer by the insulated rear handle or lay it down and away from you in a safe manner.

Disconnect the electrical service to the

damaged line or cord before attempting to free the blade. Failure to heed this warning

may result in serious personal injury or

possible death.

[Non-Text]

MAINTENANCE

The Ground Truth image displays a single, solid horizontal line, which is a stylistic or background element (like a rule line on paper). According to Rule 2, such lines must be ignored by the OCR result. The provided OCR content is "____", which consists of underscores. Underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line is incorrect because it misinterprets the line as a placeholder fill-in-the-blank area. Since the OCR output incorrectly rendered a stylistic line as underscores (which should be ignored), this violates the rule. Therefore, the OCR result is inconsistent with the Ground Truth.

WARNING! Ensure the tool is switched off and disconnected from the power supply

before performing any of the following tasks

Lubricating the blade

Labhrouting the blade For heat expansion and large

For best operation and longer blade line, lubricate the hedge trimmer blade with light machine oil or spray

lubricant (such as WD40, CRC5.56 or RP7) after each

use. When a job lasts for a longer period of time it is recommended that the blade rail also be treated with

spray lubricant at regular intervals during operation.

WARNING: 1.2.1.3.4.5.6.7.8.9.10.11.12.13.14.15.16.17.18.19.20.21.22.23.24.25.26.27.28.29.30.31.32.33.34.35.36.37.38.39.40.41.42.43.44.45.46.47.48.49.50.51.52.53.54.55.56.57.58.59.60.61.62.63.64.65.66.67.68.69.70.71.72.73.74.75.76.77.78.79.80.81.82.83.84.85.86.87.88.89.90.91.92.93.94.95.96.97.98.99.100

WARNING! Do not be while the hedge trimmer is running

E

General tips

- Keep air intake clean and air vents free of debris to

avoid overheating the motor.

- Do not use cleaning agents to clean the plastic

parts of the tool. A mild detergent on a damp cloth is recommended. Water must never come into

contact with the tool

- If the trimmer vibrates abnormally, stop motor

immediately. Abnormal vibration usually indicates a mechanical problem continued operation could

lead to injury or damage

• Always place the blade cover on the blade before

storing or transporting the hedge trimmer. Use caution to avoid the sharp teeth of the blade

• When not in use, the tool should be stored in a

frost-free location, out of the reach of children.

• No lubrication is necessary as the motor is

equipped with lifetime-lubricated bearings

Note: XU1 will not be responsible for any damage or injuries caused by the repair of the tool by an

of injuries caused by the repain of the tool by an unauthorised person or by mishandling of the tool

WARRANTY

All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely

event that your device develops a fault, please contact our service department at the address shown on this guarantee card. You can also contact us by telephone using the customer service number shown. Please note the following terms under which guarantee claims can be made:

1. These warranty terms may be additional warranty orders, which the manufacturers mentioned below are prices

2. These warranty terms regulate additional warranty services, which the manufacturer mentioned below promises to buyers of its new products in addition to their statutory guarantee claims are not affected by this guarantee. Our guarantee is free of charge to you.

3. The warranty services only covers defects due to material or manufacturing faults on a product which you have

4. The warranty services only covers defects due to material or manufacturing defects on a product, which you have bought from the manufacturer mentioned below are limited to either the rectification of said defects on the product or the replacement of the product, whichever we prefer.

Please note that our devices are not designed for use in commercial, trade or professional applications. A guarantee contract will not be created if the device has been used by commercial, trade or industrial business or has been exposed to similar stresses during the guarantee period.

1. The following are not covered by our guarantee:

- Damage to the device caused by a failure to follow the assembly instructions or due to incorrect installation, a failure to follow the operating instructions (for example connecting it to an incorrect mains voltage or current type) or a failure to follow the maintenance and safety instructions or by exposing the device to abnormal environmental conditions or by lack of care and maintenance.

- Damage to the device caused by abuse or incorrect use (for example overloading the device or the use or unapproved tools or accessories), ingress of foreign bodies into the device (such as sand, stones or dust, transport damage), the use of force or damage caused by external forces (for example by dropping it).

- Damage to the device or parts of the device caused by normal or natural wear or tear or by normal use of the device.

1. Your Product is guaranteed for a period of 12 months from the original date of purchase and is intended for DIY (Do it Yourself) use only. Warranty excludes consumable parts, for example: cutting blade. Guarantee claims should be submitted before the end of the guarantee period within two weeks of the defect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains applicable to the device even if repairs are carried out or parts are replaced. In such cases, the work performed or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active for the work performed or parts fitted. This also applies if an on-site service is used.

IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR REGISTER RECEIPT.

Please refer to the restrictions of this warranty concerning wearing parts, consumables and missing parts as set out in the service information in these operating instructions.

CUSTOMATED OFFICE HELP DUNT

CUSTOMER SERVICE HELPDINE GB: 0151 294 4488

IRL: 1850 882711

[Non-Text]

XU1

Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG
