| Product Type | KVM Switch |
| Brand | Adder |
| Model | AIM-96 |
| Number of Ports | 96 (dual access) |
| Supported Computers | Up to 96 servers |
| Video Resolution | Up to 1920x1200 @ 60Hz |
| Connector Types | RJ45 for CAT5/6, VGA, USB |
| Power Supply | 100-240V AC, 50-60Hz, 15W |
| Dimensions (W x D x H) | 482 x 250 x 44 mm (19" rackmount, 1U) |
| Weight | 4.5 kg |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 10% to 90% non-condensing |
| Supported Operating Systems | Windows, Linux, macOS, Solaris |
| Control Methods | Front panel, OSD, serial, IP |
| Security | Password protection, access control |
| Cable Distance | Up to 150m via CAT5/6 |
| Mounting | 19" rack mountable with included brackets |
Frequently Asked Questions - AIM-96 Adder
What is the maximum distance between the switch and computers?
Using standard CAT5/6 cabling, the maximum distance is up to 150 meters for video and keyboard/mouse signals.
Can I daisy-chain multiple AIM-96 switches?
Yes, the AIM-96 supports daisy-chaining to expand the number of ports. Up to 8 units can be cascaded for a total of up to 768 ports.
Does this switch support USB peripherals?
Yes, each computer port includes a USB 2.0 connection for keyboard, mouse, and other USB devices.
How do I access the On-Screen Display (OSD)?
Press the Print Screen key twice quickly to bring up the OSD menu. You can navigate using the keyboard arrows.
What video resolutions are supported?
The AIM-96 supports resolutions up to 1920x1200 @ 60Hz. Lower resolutions are also supported.
Is the switch hot-swappable?
Yes, you can connect or disconnect computers without powering down the switch. However, always follow proper ESD precautions.
Can I control the switch over the network?
Yes, the AIM-96 has an IP-based management option (add-on module) for remote access via web browser or SSH.
What power supply is required?
The switch uses an internal power supply, accepting 100-240V AC, 50-60Hz. It consumes approximately 15W.
How do I reset the switch to factory defaults?
Press and hold the Reset button on the front panel for 5 seconds using a paperclip. This clears all settings.
Are rackmount brackets included?
Yes, the AIM-96 comes with 19-inch rackmount brackets for installation in a standard server rack (1U height).
