| Product Type | Passive Infrared (PIR) Motion Detector |
| Brand | Bosch |
| Model | MB-SSC |
| Dimensions (H x W x D) | 120 mm x 80 mm x 50 mm |
| Weight | 150 g |
| Power Supply | 9 to 15 V DC, 12 mA typical |
| Detection Range | 12 m (40 ft) at 90° angle |
| Detection Angle | 90° standard, optional 180° with lens |
| Mounting Height | 2.0 m to 2.5 m (6.5 to 8.2 ft) |
| Operating Temperature | -30°C to +55°C (-22°F to +131°F) |
| Alarm Output | Normally closed (NC) relay, 50 mA at 30 VDC |
| Tamper Protection | Tamper switch (NC) against cover removal |
| LED Indicator | Red LED for alarm and walk test |
| Pet Immunity | Yes, up to 20 kg (45 lbs) |
| Protection Class | IP41 (indoor use) |
| Materials | ABS plastic housing |
| Installation | Wall or ceiling mount, includes bracket and hardware |
| Maintenance | Clean lens with soft dry cloth; avoid solvents |
| Compliance | CE, FCC, UL |
| Warranty | 2 years limited manufacturer warranty |
Frequently Asked Questions - MB-SSC BOSCH
How do I install the Bosch MB-SSC detector?
Mount the detector at a height of 2.0 to 2.5 m. Connect the power supply (9-15 VDC) and the alarm output (NC relay). Use the included bracket to secure the detector. Refer to the user manual for detailed wiring diagrams.
What is the detection range of the MB-SSC?
The standard detection range is 12 meters (40 feet) with a 90° detection angle. Optional lenses can extend the angle to 180°.
Is the MB-SSC pet immune?
Yes, the MB-SSC features pet immunity for animals up to 20 kg (45 lbs). Adjust the sensitivity if needed to avoid false alarms.
How do I test the detector after installation?
Walk across the detection zone and observe the red LED. The LED lights up for about 3 seconds when motion is detected. Ensure the LED is enabled in the settings.
Can I install the MB-SSC outdoors?
No, this detector is rated IP41 and designed for indoor use only. Outdoor installation may cause malfunction or damage.
What does the tamper switch do?
The tamper switch activates an alarm if the cover is removed. It is a normally closed (NC) circuit that must be connected to the alarm system.
How do I clean the MB-SSC detector?
Use a soft, dry cloth to wipe the lens and housing. Do not use solvents, abrasives, or water. Dust can reduce detection performance.
What is the power consumption of the detector?
The MB-SSC draws approximately 12 mA at 12 VDC standby, and slightly more during alarm. It requires a stable 9-15 VDC power source.
Does the MB-SSC support remote programming?
This model is a basic detector with physical DIP switches for settings (e.g., LED enable, pulse count). It does not support remote programming via software.
What should I do if the detector triggers false alarms?
Check for pets, heaters, or moving objects in the detection zone. Adjust the mounting height, reduce sensitivity, or increase the pulse count via DIP switches. Ensure the detector is not facing windows or heat sources.
