USER MANUAL P7040 PANTECH

Smartphone screen displaying a black keypad interface with status bar, time, and navigation icons, alongside a digital display showing a landscape scene.

PANTECH Link User Guide SU00271COA REV.00

Shortcase Menu

PANTECH Link

User Guide

at&t

Some of the contents in this manual may differ from your phone

depending on the software of the phone or your service provider.

© 2010 AT&T Knowledge Ventures. All rights reserved. Subsidiaries and

affiliates of A&T Inc. provide products and services under the A&T brand.

Your phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, we offer privacy controls that let you decide how an application may use the location of your phone and other phones on your account. However, the AT&T privacy tools do not apply to applications available outside of AT&T. Please review the terms and conditions and the associated privacy policy for each location-based service to learn how location information will be used and protected. In addition, your AT&T phone may be used to access the Internet and to download, and/or purchase goods, applications, and services from AT&T or elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain devices which bypass AT&T controls.

PANTECH Link

User Guide

Thank you for choosing the Pantech Link, our latest 3G mobile phone.

The Pantech Link has many features designed to enhance your mobile experience. From its unique, stylish design and QWERTY keypad, we know you will enjoy the entire Link experience.

This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech Link has to offer.

Specifications

Design

QWERTY bar

Displays

• 262k colors TFT LCD with 2.4" display
• 320*240 resolution
- 5 lines for text in basic mode with 16-point font
- Two soft keys and four-way scroll and selection keys

Melodies

.mp3, .midi, .mid, .iMelody, .wav, .mmf, .wma, .3gpa

Camera

Integrated 1.3M CMOS Camera

• Resolution up to 1280 x 1024 (1,310,720 pixels)

• Mpeg4 Video recording/playing up to 15f/s (QVGA size)

• Self-timer function (5 seconds or 10 seconds)

• Photo album and video album

Dimensions & Weight

• Weight: 91 g/3.2 oz (with standard battery)

• Dimensions: 115.20 mm x 60.90 mm x 9.9 mm

4.5"×2.4"×0.39"

Power Management (Performance)

Battery Type	Capacity Standby Time Talk Time
Standard Lithium-Ion (Li-ion)	930 mAh	Minimum 10 days (250 hrs)	Minimum 3 hrs

Operating Frequency

• GSM 850Mhz, GSM 900Mhz, GSM 1800Mhz, GSM 1900Mhz, UMTS 850Mhz and UMTS 1900Mhz networks in North America,
South America, Europe, Africa, and Asia-Pacific where these
networks are supported.
• Automatic band switching.

Phone overview

Left Side key Volume up and down microSD Slot Speaker Camera Charger slot / Ear mic Camera key Internal antenna area

note: Holding the device by the internal antenna area might affect the quality of all calls.

Using shortcuts

Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Menu mode, Main Menus can be accessed by pressing the number keys (☑ to ☑, ☐) corresponding to their location on the screen.

Example: Accessing the Language menu.

1. Press Menu.

2. Press the for Settings.

3. Press the for Phone.

4. Press the 📋 for Language.

5. Press Select for Screen Text.

6. Press the ▲ or ▼ scroll key to display the list of available languages.

note: In main menu screen the number keypad is matched with the menus as follows.

Address Book	Messaging	IM	Mobile Email
Mobile Web	AppCenter	AT&T GPS	Y?mobile
My Stuff	Online Locker	AT&T Music	Settings

Menu overview

Address Book

My settings

All Contacts

Favorites

Groups

Messaging

Conversations

Create Message

Mobile Email

IM

Outbox

Drafts

Voice Mail

Settings

Templates

Used Space

IM Mobile Email

Mobile Web

AppCenter AT&T GPS

Community Music Apps

Online Locker Settings

Profiles

Display

[Non-Text]

Phone

Network Connections

Connectivity

Security ^1

AT&T Software Update

[Non-Text]

TIV

Phone Information

^a SIM dependent ^b Network dependent

Quick & Easy

Keys Functions
	Perform the functions shown at the bottom line of the display by using these soft keys.
	Scroll through the menu options in Menu mode. In standby mode,Left: Access Mobile Email menuRight: Access IM menuUp: Access Create Message menuDown: Access Contacts menuWork in Word search mode if pressed in the Predictive text input mode.
	Select a menu function or store user-input information, such as names. Also use this key for confirmation as theOK(key).Launch the Mobile Web directly if pressed in standby mode.
	Turn on the speaker mode.
	Delete characters from the display, or return to previous menu.
	Send or receive a call. Show the recent call list in standby mode.
	Complete the current call. Turn on/off the phone if pressed and held.Cancel user input and return to main screen while in Menu mode.

Keys Functions

	Quickly connect to the voice mail server if pressed and held in standby mode.
	Enter numbers, letters or special characters. Go to the dial screen if pressed in standby mode.
	Enter or exit from vibrate mode if pressed and held in standby mode.
	Enter an international dialing prefix if pressed and held in standby mode.
	Change various text input modes if pressed at the text-editing screen.
	Adjust the earpiece volume while making a call.Control the Ringtone volume, vibrate mode and silent all mode in standby.Mute the ringtone of an incoming call.
	Turn camera capture mode on.Work as a camera shutter in capture mode.

Contents

Specifications 2

Using shortcuts 5

Menu Overview .... 3 Quick & Easy .... 8

1. Getting Started

SIM card and battery 14

Turning the phone on/off ....15

Keypad unlock 16

Essential display indications .....16

Memory card 17

Assigning the menu .....18

Updating software ....18

Using the QWERTY keypad .....18

Using the multitask menu .....19

2. Calls and address book

Making, receiving and ending

calls 2

Using video share 23

Options during a call 24

Call settings 29

Checking all calls 26

Speed dialing 27

Using the address book 27

Address book settings .....28

Caller identification 29

Using your headset ....29

Service numbers and fixed dialing29

3. Messaging

Entering text 32

Receiving messages 32

Creating and sending text

messages 33

Creating multimedia messages ...34

Message templates....36

Message settings 37

Managing memory 38

Email 38

Using instant messenger....38

4. Multimedia

Camera....42

Photo album 44

Video album 46

Audio album 47

Music player 48

Music player settings 50

Media player 51

Other files 52

Managing memory ....52

Playing games 52

5. Useful Features

Alarm 56

Calendar 56

Notepad and voice memo ....56

World time 57

Calculator, tip calculator and

converter 58

Stop watch and timer ....58

Business card 59

Memory information....59

6. Connectivity

Bluetooth 62

Using mobile web 63

Using the browser 63

Profile settings 64

7. Settings

Language 68

Time and date 68

Ring tanes 68

Display 68

Security 69

Reset 70

ITY 70

8. Appendix

Alert message 74

Troubleshooting checklist .....74

Safety information 75

contents

Safety precautions 76

About the battery usage .....76

FCC Hearing-Aid Compatibility (HAC)

Regulations for Wireless Devices ..77

FCC Regulatory Compliance .....79

Warranty 80

P7040 Link™ 1 Getting Started SIM card and battery Turning the phone on/off Keypad unlock Essential display indications Memory card Assigning the menu Updating software Using the OWERTY key pad Using the Multitask menu

SIM card and battery

About your SIM card

When you subscribe to your network operator, you receive a SIM (Subscriber Identity Module) card containing your registration information, PIN code, etc.

Like a credit card, it should be kept secure and handled carefully. Do not bend, scratch or expose it to moisture. Avoid static electricity.

To avoid corrupting your SIM card's memory, always switch off your phone before removing or inserting your SIM card.

About your battery

Your phone uses a Li-ion battery. Make sure to use an authorized battery and charger only. For more details, please inquire at your nearest dealer.

note: Your phone is powered by a Lithium Ion (Li-Ion) battery. Unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone's autonomy due to the "battery memory effect" inherent in those technologies.

Installing/removing SIM card and battery

1. Remove the battery cover from the up

2. To fit the battery cover, put it on the guide rail and push up.

3. Insert the SIM card into the slot. The gold contacts of the SIM card should go against the metal contacts of the phone

Put the contacts of the battery into the hole located at the bottom of the unit insert and press the upper side of the battery until you hear the "click". Make sure you align the gold contacts at the battery end with contacts on the phone. If the contacts at the battery are not properly aligned, damage could occur to the phone and the battery.

1. To remove the battery push the bottom of the battery to upwards (1) and remove (2) the battery. Push the SIM card in the direction of the arrow as shown.

Charging your battery

1. To charge, open the protective cover on the top right side and connect the charger adapter. Make sure you align the connector as shown in the image. If not, it will damage the charging connector on the phone and will not charge.

2. To remove the adapter connection press the adapter's side buttons (1) and pull the adapter away (2).

Turning the phone on/off

To turn on

1. Press and hold

To turn off

1. Press and hold(3).

Keypad unlock

Unlocking the keypad

1. Press Unlock > Yes

Essential display indications

	Signal strength. The greater the number of bars, the stronger the signal. When network is to searching mode. Is displayed.
	A call is being made. When you are in no service and is displayed.
	Call forwarding is active.
	Incoming calls set to ring only (Normal).
	Incoming calls set to Vibrate and Ring.
	Incoming calls set to Vibrate Only.
	Incoming calls set to Silent.
	Flight Mode is active.
	Received one or more text messages.
	Received one or more multimedia messages.
	Received one or more WAP push messages.

Received one or more configuration messages.

Received one or more voice messages.

A message is being sent.

A message is being received.

An alarm is set.

Schedule Alarm is set.

Browser is Active, Secured and being downloaded.

Bluetooth is active.

Bluetooth hands-free headset is connected.

Bluetooth A2DP headset is connected.

Bluetooth hands-free + A2DP headset is connected.

Data transfer via Bluetooth.

Headset is connected.

USB is connected.

TTY is active.

A GPRS signal is available. It is displayed when there is an actiGPRS session.

• getting started

	An EDGE signal is available. It is displayed when there is an active EDGE session.
	microSD card is inserted.
	Battery strength. When the battery charge is left[7] is displayed.
	Available, Away, Invisible Status of AIM.
	Online, Away, Busy, Offline Status of MSM.
	Available, Busy, Invisible Status of YAHOO.
	You have received one or more IM messages.
	BGM is play, pause and being stopped.

Memory card

You can use a microSD card as a memory card. It gives you more space to save pictures, videos music, etc.

Inserting and removing a memory card

1. Open the memory card slot.
2. Insert the card. The icon will be displayed.
3. Press the card to remove.

Using a memory card

You can save, move and delete the files between your phone and external memory card. You can also move and copy the files to computer from your phone.

Resetting a memory card

1. Press Menu > Settings > Reset.
2. Enter the password > External Memory Reset > Yes. Note: The default password is '1234'.

To copy a file to the card

1. Select the file > Options > Copy to External Memory.
2. To copy the file back to phone, press Options > Copy to Phone.

To move a file to the card

1. Select the file > Options > Move to External Memory.
2. To move the file back to phone, press Options > Move to Phone.

To delete a file from the card

1. Select the file from the card > Options > Delete.

To move a file from the card to the computer

1. Connect the data cable with mobile and the computer.

2. Press Menu > Settings > Connectivity,

3. Press Select USB Mode.

4. Select Music Player, Mass Storage or Ask on Connection.

5. Fallow the instructions on your computer screen

note: Select Music Player when you want to add music to the playlist in your device. When you select Ask on Connection, it will ask you to select either the Music Player or Mass Storage every time you connect your device with your computer.

Assigning the menu

You can set the most commonly used menu in Options in standby mode.

1. Press Shortcuts in standby mode >select Unassigned.

2. Press Add.

3. Select the menu and sub menu.

Updating software

You can update your software without visiting your nearest dealer.

To update the software

1. Press Menu > Settings > AT&T Software Update

2. Press Check for Update > Yes to check whether or not you need to update the software.

note: After downloading the software, the device will ask you whether to update the software now or later. If you choose to update the software now, it will restart the handset. If you postpone updating the software, you can select between 30 mins, 1 hour or 4 hours in the Options. After selecting the updating time, you will be sent back to standby mode. If you go to Software Update while you are in postponing press Continue Update.

To view the version of software

1. Press Menu > Settings > Phone Information.

2. Press ▲/▼ to view Software Version.

Using the QWERTY keypad

Your phone has a QWERTY keypad which provides a superior typing experience on a small handheld for easy and comfortable texting. You can use all of the phone functions with the QWERTY keypad.

Key Function

	Perform the functions shown at the bottom line of the display by using these soft keys.
	Press to change text input mode.
	Press to type a special character or number. To enter symbols and numbers continually, press until displays.
	Enter the space character in text input mode.
	Insert a carriage return in text input mode.
	Delete a character to the left of the text cursor in text editing screen.
	Press to type a special character that is not placed on the keypad.

Using the Multitask menu

Press and holds to launch the Multitask menu that can be accessed from any active window or page on the phone. There is no need to stop what you are doing, if you want to jump out and activate another common feature. The idea is to allow you to temporarily exit from your current location to access a group of common functions such as: Call, Messaging, Mobile Web, Music player and Games & Apps. This key keeps you from having to

completely exit from your current task or window, whether that be a text message, a web page, or an active call, to do something else.

Multitask functions

To use the multitask function, press and hold . You can choose from one of the following functions:

• Call: Make a voice call while using the handset for other tasks.
  If Music Player is active, it is muted during the call.
• Messaging: Send a text or multimedia message while using the handset for other tasks.
  • Mobile Web: Launch the browser while using the handset for other tasks.
  • Music Player: Launch the Music Player while using the handset for other tasks. If an incoming call is received or you want to make a call, the Music Player is muted.
• Games & Apps: Access Games and Applications while using the handset for other tasks.

P7040 Link™ 2 Calls and address book Making, receiving and ending calls: Using video share Options during a call Call settings Checking all calls Speed dialing Using the address book Address book settings Caller identification Using your headset Service numbers and fixed dialing

Making, receiving and ending calls

Making a call

1. Enter the area code and phone number.

2. Press

Answering a call

1. Press

Ending a call

1. Press

Once the call is complete, a call summary is displayed.

Rejecting a call

1. Press or Ignore.

Making a call using the call list

Your phone logs up to 20 dialed, received and missed call numbers.

1. Press 🔑 to display the Recent Calls list.

2. Select All Calls, Missed Calls, Received Calls, or Dialed

Calls pressing the◀/▶

1. Select a number

2. Press ⬇ to dial the selected number.

note: To redial the last number in the Recent Calls list, press ↗.

Making a call during a call

1. Enter the phone number or look it up in Address Book.

2. Press 🔍 to dial the second call. The first call is

automatically put on hold.

Switching between two calls

1. Press Swap.

Making an international call

1. Press and hold for the international prefix until the '+'

character appears.

1. Type the country code, area code, and phone number.

2. Press

Making an emergency call

You can make emergency calls even if your phone does not have

SIM card.

1. Press Emergency Number, or press SOS if your phone does

not have a SIM card

1. Press

Replying to a missed call

1. Press View to display the list of missed calls.

2. Select a number to call by pressing th▲;▼

3. Press

Answering a second call

1. Press ☐. The first call is automatically put on hold.

2. Press [→] to end the second call.

The call on hold is automatically reconnected.

Using video share

You can share live or recorded video while on a call. You can send or receive video.

note: Video Share is not available in all markets. Both parties must be in a 3G service area — a 3G icon must appear by the signal bars prior to a call being placed, and both parties must remain in the 3G coverage area for the duration of the Video Share.

Making video share call

1. Enter the area code and phone number ↗.

2. Press Options > Video Share

3. Select Live or Recorded

note: To use video share in the Recent Calls, press Options > Video Share.

Turning off the speakerphone

1. Press 🧠 or press Options > Speakerphone Off during

video share mode.

1. Press Options > Mute to mute the sound

Increasing or decreasing the brightness

1. Press Options > Brightness.

2. Adjust the brightness by pressing ▶

Zooming in and out

1. Press Options > Zoom. It ranges from 1x to 4x.

Stopping the recording

1. Press Options > Stop Record

Stopping or ending video share

1. Press Stop to end the video share.

2. It will ask you whether you will stop video share > Yes to stop. note: The recorded video will be saved in My Stuff > Video.

Receiving video share

1. After receiving video share, it will ask you whether to accept or reject the video share > Yes to accept and No for reject

2. Press Options > Full Screen to enlarge the video to fill the entire screen.

Options during a call

Microphone off and on

Switching your phone's microphone off 1. Press Options > Mute.

Switching your phone's microphone back on 1. Press Options > Unmute.

Talking on speaker

1. Press Speaker Phon

Putting a call on hold and returning

Putting a call on hold

1. Press Options > Hold or press

Returning to a held call

1. Press Options > Unhold or press 📋 again.

Multi-party calls

You can talk with more than one person or have conference call.

Making a multi-party call

1. Call the first participant.

2. Call the second participant. The first call is automatically put on hold.

3. Press Options > Join.

Having a private conversation with one participant

1. Press Options > Split

2. Select the participant and press Select.

All of the multi-party call participants can now hear each other.

Removing one participant from a multi-party call 1. Press Options > End.

1. Select the participant and press Select.

The call ends with that participant, but you can continue to talk to the other participants.

Searching for a number in the address book during a call

1. Press ▼ and press Select or press Options > View Contacts > All Contacts.

2. Select a number >

Searching for a name or group in the address book Enter the first letters of the name for Name Search. The entries are displayed starting with the first entry matching your input. Finding a name manually in the address book

1. Press the ▲/▼.

Viewing the details of the highlighted entry in the address book

1. Press Select.

For details on address book, see page7.

- calls and address book

Reading a message during a call

1. Press Options > View Message.

2. Select a message > view.

Sending a message during a call

1. Press Options > Send Message. For details on creating a text message, see page

Viewing the calendar during a call

1. Press Options > View Calendar.

Making a note during a call

1. Press Options > Notepad,

Voice recording

1. Press Options > Voice Recording.

Call settings

Setting auto redial

1. Press Menu > Settings > Call > Auto Redial.

2. Select On or Off,

Answering by pressing any key

1. Press Menu > Settings > Call > Any Key Answer.

2. Select Answer with Any Key.

ote: You can answer with any key excepted and ignore.

Answering by pressing send key

1. Press Menu > Settings > Call > Any Key Answer.

2. Select Answer with Send Key.

Checking all calls

You can view information about all Recent Calls. For more options for all, missed, received and dialed calls press Options. You can also view the call history simply by pressing.

Viewing missed calls

1. Press Shortcuts in standby mode or press Menu > My Stuff > Tools Press Recent Calls > Missed Calls.

Viewing received calls

1. Press Shortcuts in standby mode or press Menu > My Stuff > Tools

2. Press Recent Calls > Received Calls.

Viewing dialed calls

1. Press Shortcuts in standby mode or press Menu > My Stuff

Tools

1. Press Recent Calls > Dialed Calls.

Viewing call rankings

1. Press Shortcuts in standby mode or press Menu > My Stuff > Tools.

2. Press Recent Calls >Call Ranking.

Deleting call logs

1. Press Shortcuts in standby mode or press Menu > My Stuff > Tools Press Recent Calls > Delete Call Logs.

2. Select All Calls > Yes.

Viewing call time

1. Press Shortcuts in standby mode or press Menu > My Stuff > Tools Press Recent Calls > Call Time.

2. Press ▲/▼ to view Last Call, Received Calls, Dialed Calls and Total Calls.

Resetting all call times

1. Press Shortcuts in standby mode or press Menu > My Stuff > Tools Press Recent Calls > Call Time.

• calls and address book

1. Press Reset > Yes.

2. Enter password > OK.

note: The default password is '1234'.

Viewing data transmitted information

1. Press Shortcuts in standby mode or press Menu > My Stuff

Tools Press Recent Calls > Packet Counter.

- Current Info: You can view transmitted data in the current session, in kilobytes. Sent, Received and Total information are also available.

- Last Info: You can view Sent, Received, Total and

Duration information of the previous session's transmitted in kilobytes.

• Total Info: You can view all the Sent, Received, Total and Duration transmitted data in kilobytes.

• Clear Logs: The default password is '1234'.

Speed dialing

You can dial quickly using speed dialing. Up to 8 phone numbers can be programmed using numbers 2 to 9.

: Voice mail

: Prefix for international call

Setting speed dial

1. Press Menu > Address Book > My Settings > Speed Dial.

2. Select an empty entry and press Add.

3. Select a person and press Select.

Changing speed dial contact

1. Press Menu > Address Book > My Settings > Speed Dial.

2. Select a number > Change.

3. Select a person > Select > Yes.

Removing from speed dial

1. Press Menu > Address Book > My Settings > Speed Dial.

2. Select a number > Remove.

Using the address book

You can save names, phone numbers, and information on the SIM or phone. Number of entries can depend on the capacity of the SIM card.

Viewing the contact list

1. Press ▼ or press Menu >Address Book >All Contacts.

Searching for a phone number

1. Press▼ or press Menu > Address Book > All Contacts.

2. Input the first letter or two of the person's name and scroll with ▲/▼.

3. Press Select to view the detailed information.

4. To update information, press Options > Edit Contact.

Calling from the contact list

1. Press ▼ or press Menu > Address Book > All Contacts.
2. Select a person to call.
3. Press

Forwarding contact details

1. Press ▼ or press Menu > Address Book > All Contacts.
2. Select a contact > Options > Send Contact.
3. You can send the information using Multimedia Message or Bluetooth.

Deleting a contact

1. Press ▼ or press Menu > Address Book > All Contacts.
2. Select a contact > Options > Delete Contact.

Adding a contact

1. Press Menu > Address Book > All Contacts > Options >
   Add New Contact.

2. Input the fields.

3. Press Save.

Making & Editing groups

1. Press Menu > Address Book > Groups.
2. To add new group, press Options > Create New Group.
3. To edit group, press Options > Edit Group > Add Members.
   Edit Members or Remove Members.
4. To rename group, press Options > Rename Group.
5. To delete group, press Options > Delete Group.

Address book settings

Managing my info

1. Press Menu > Address Book > My settings > My Info.

Setting the sort order

1. Press Menu > Address Book > My settings > Sort by.
2. Select First Name or Last Name.

Setting Sync settings

1. Press Menu > Address Book > My settings > AT&T
   Address Book.
2. Select Auto Sync On or Auto Sync Off.

Setting SIM management

1. Press Menu > Address Book > My settings > SIM Management.

Caller identification

Caller identification

1. Press Menu > Settings > Call > Display My Number.
2. Select Network Default, Show or Hide.

Using your headset

You can send or receive a call using your headset.
When you connect your headset to the jack the button on the headset works as follows.
note: You must use the headset designed for this device. It is an optional accessory. Not all headsets will have a button.

While In standby mode

1. Press the button once to list recent calls.
2. Press the button twice to redial the last call.

- calls and address book

Service numbers and fixed dialing

Calling your service numbers

You can see the service number to reach the service provider.

1. Press Menu > Address Book > My Settings > Service
   Numbers.
2. Select a number > press

Viewing the fixed dialing list

Fixed dialing is a service that limits your access to specific numbers in the address book list recorded on the SIM. Input the PIN2 to set up or cancel this service.

1. Press Menu > Address Book > My Settings > FDN List.
2. Select a number > press

note: PIN2 must be correctly entered within 3 attempts. If you input the incorrect code three times in a row the PIN2 code will be blocked, if the PIN2 code is blocked please contact your service provider. Your PIN2 code is supplied with the SIM card.

P7040 Link™ 3 Messaging Entering text Receiving messages Creating and sending text messages Creating multimedia messages Message templates Message settings Managing memory Email Using instant messenger

3

Messaging

Entering text

Receiving messages

Creating and sending text messages

Creating multimedia messages

Message templates

Message settings

Managing memory

Email

Using instant messenger

Entering text
You can enter text with multi-tap, predictive, numeric or symbol.
Useful keys

	Display symbols
box	Adding space
	Press to change capital modePress to change ab Mb AB and press to change from multi to predictive to NumberMulti-top CBA, ABA, ABA (all small caps / first letter caps / all caps)Predictive CBA, CBA, CBA (all small caps / first letter caps / all caps)Number [123]

For details on using QWERTY keypad, see page.

Predictive mode

The predictive mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word. It will display the most commonly used word first. To save word not listed in phone's dictionary, press Options > Predictive Settings > Selection List > On.

Alphabet input mode

. Press ☐ to change the mode as multi-tap.

. Press ☐ to ☐ to input text repeatedly.

Numeric mode

You can input numbers in this mode.

1. Press 2 to change the mode to 123.

2. Press ☐ to ☐ and ☐ to input numbers.

Symbol mode

Symbol mode You can input symbols.

1. Press □ to view the symbols

2. Press ▲ to view the symbols.

3. Press ▲/▼/◀/▶ to select symbol and press Insert.

Receiving messages

Viewing a new message

1. Press View.

- messaging

Reading a message from the inbox

1. Press Menu > Messaging > Conversations.

2. Selecta received message >Open >View.

Saving the contact information from a received

message

1. Select a received message > View.

2. Press Options > Save.

3. Select New Contact or Update Contact.

Saving the object in a received multimedia message

1. Open the multimedia message.

2. Select an object.

3. Press Options > Use > Save,

It will be saved in one of the categories in the My Stuff folder.

For details on photo album, see page

Listening to voice message

1. Press and hold 📊 or press Menu > Messaging > Voice

Mail.

It will automatically call the voice mail center.

Loading URL using Push message

1. Press Menu > Messaging > Conversations > Open.

2. Press Options > Load URL.

Saving connection settings using configuration message

1. Press Menu > Messaging > Conversations > Open.

2. Press Options > Install.

Creating and sending text messages

Sending a new text message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter the message.

3. To save the message as draft, press Options >Save to

Drafts.

1. Press Send to and select the person to send message and

press Select

S. Press Send.

1. To view sent message, press Menu > Messaging >

Conversations, select a recipient > Open > View. note: All successfully sent messages will be saved in Conversations while the messages that failed to be sent will be saved in the Outbox.

Finding all sent messages

1. Press Menu > Messaging > Conversations.

Replying to a message

1. Press Menu > Messaging > Conversations.

2. Select a recipient > Open.

3. Select a message > View > Reply.

Creating multimedia messages

You can create and send multimedia messages. Capacity is 100Kb, 300Kb, 600Kb an error message will alert you once you exceed the capacity.

Adding a saved picture to the message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter a message.

3. Press Insert > Picture > Picture > Camera.

4. Scroll to the saved picture and press Select.

5. To preview the current page, press Options >Preview >Current.

6. To preview the whole message, press Options > Preview > Whole Message. To no back to text editor page, press Stop

7. To edit the text message, press ▲/▼ to select the text box.

8. Press Send to and select the person to send message and press Select.

9. Press Send.

Adding a new picture to the message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter a message.

3. Press Insert > Take New Picture.

4. Focus on the object >OK

5. To preview the current page, press Options > Preview > Current.

6. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press Stop.

7. To edit the text message, press ▲/▼ to select the text box.

8. Press Send to and select the person to send message and press Select.

9. Press Send. or taking a picturesee page43.

Adding a saved video to the message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter a message.

3. Press Insert >Video >Video.

4. Scroll to the saved video clip and press Select.

5. To preview the current page, press Options > Preview > Current.

6. To preview the whole message, press Options > Preview >

Whole Message. To go back to text editor page, press Stop.

1. To edit the text message, pres▲/▼ to select the text box.
2. Press Send to and select the person to send message and press Select.

9. Press Send.

Adding a new video to the message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter a message.

3. Press Insert > Record New Video.

4. Focus on the object >OK.

5. To stop recording and save press Stop.

6. To edit the text message, pres▲;▼ to select the text box.

7. To preview the current page, press Options >Preview >Current.

8. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press Stop.

9. Press Send to and select the person to send message and press Select.

10. Press Send. For recording a videpsee page44.

Adding a recorded voice memo to the message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter a message.

3. Press Insert > Sound

4. Select Audio > My Voice.

5. Scroll to the saved audio clip and press Select.

6. To edit the text message, pre▲/▼ to select the text box.

7. To preview the current page, press Options > Preview > Current.

8. Press Pause to stop listening.

9. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press Stop.

10. Press Send to and select the person to send message and press Select.

11. Press Send.

Adding a new voice memo to the message

1. Press ▲ or press Menu > Messaging > Create Message.

2. Enter a message.

3. Press Insert > Record New Sound.

4. Press Record to record the sound.

5. To stop and save press Stop.

6. To edit the text message, pre▲/▼ to select the text box.

7. To preview the current page, press Options > Preview > Current.
8. Press Pause to stop listening.
9. Press Resume to replay.
10. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press Stop.
11. Press Send to and select the person to send message and press Select.
12. Press Send.
    for recording a voice mematee page57.

Adding other files to the message

1. Press ▲ or press Menu > Messaging > Create Message.
2. Enter a message.
3. Press Insert > Other Files > Other Files.
4. Select the file and press Select.
5. To edit the text message, pres▲/▼ to select the text box.
6. To preview the current page, press Options > Preview >
   Current.

7. To preview the whole message, press Options > Preview > Whole Message. To go back to text editor page, press Stop.

8. Press Send to and select the person to send message and press Select.

9. Press Send.

Message templates

When you often use the same phrases, you can save the message under template messages.

Adding the message as a template

1. Press Menu > Messaging > Templates.
2. Press Options > Add New.
3. Enter the frequently used message > Options > Save.

Sending a message with template

1. Press Menu > Messaging > Templates.
2. Select the message to send
3. Press Send to add more messages.

4. Press Send to and select the person to send message and press Select.

5. Press Send.

note: You can add a template while entering a message. Enter a message > insert > Templates. Select the message to add.

Message settings

Setting message center

1. Press Menu > Messaging > Settings.
2. Press Text Message.
3. Enter new Center Address.
4. Press Save.

Setting e-mail gateway

1. Press Menu > Messaging > Settings.
2. Press Text Message.
3. Enter new Email Gateway for sending text message by email address.
4. Press Save.

Setting profiles for multimedia message

1. Press Menu > Messaging > Settings.
2. Press Multimedia Message > MMS Profiles.
3. Select a profile.

Setting for sending multimedia message

1. Press Menu > Messaging > Settings.

2. Press Multimedia Message > Sending Settings.

3. You can set the Validity Period, Delivery Time, Priority, Creation Mode and Max Message Size.

Setting for receiving multimedia message

1. Press Menu > Messaging > Settings.
2. Press Multimedia Message > Receiving Settings
3. You can set the Automatic Download, Allow Delivery

Reply, Allow Read Reply.

Setting for receiving voice message

1. Press Menu > Messaging > Settings.
2. Press Voice Mail.
3. Enter the number of the voice mail center > Save.
   note: This number may be pre-configured by the service provider upon

Setting default edit mode

1. Press Menu > Messaging > Settings.
2. Press Default Edit Mode
3. Select Alphabet or Predictive.

Setting for auto delete old message

When message memory capacity (Max. 200 messages) is full, the oldest message will be deleted automatically.

messaging

1. Press Menu > Messaging > Settings
2. Press Auto Delete Old Message.
3. Select On or Off.

Managing memory

Up to 200 messages can be stored in the phone memory.

additional messages will be saved to the SIM card.

When the message box is full the messages full icon will appear.

All messages share memory

When It means

Text messages are full (SIM and Phone messages)

Moving a message to SIM

1. Press Menu > Messaging > Conversations.
2. Select a recipient > Open.
3. Select a message > Options > Move to SIM.

Deleting a message in the inbox

1. Select a message > Options > Delete > Yes.

Deleting all messages in the inbox

1. Select a message > Options > Delete All.

Viewing memory space information

1. Press Menu > Messaging > Used Space.
2. Press ◀/▶ to view SIM and Phone memory.

Email

You can receive emails from your service provider.

Receiving an email

1. Press Menu > Messaging > Mobile Email.
2. Select an email > Select.

Using instant messenger

Use Instant Messenger (IM) to send and receive short, simple
messages that are delivered immediately.

Starting an instant messenger

1. Press Menu > Messaging > IM.
2. Select the IM application > Select.
3. Enter login and password > Sign In.

Viewing the conversation log

You can view the conversations log in the Instant Messenger

Saved History.

P7040 Link™ 4 Multimedia Camera Photo album Video album Audio album Music player Music player settings Media player Other files Managing memory Playing games

4

Multimedia

Camera

Photo album

Video album

Audio album

Music player

Music player settings

Media player

Other files

Managing memory

Playing games

Camera

You can take pictures and record movies using the built-in camera. The photos and video clips can be saved and sent via multimedia messages.

Video mode Camera mode Pictures Remaining Size Self Timer Effect White Balance Brightness Zoom

Setting camera settings

1. Press Menu > My Stuff > Tools
2. Press Camera.
3. Press Options > Settings to change settings prior to taking a picture.

In the options menu for camera

Icons Name Description
	White Balance: [ ], Daylight [ ], Tungsten [ ], Fluorescent [ ]
	Effect: Normal [ ], Septa [ ], Negative [ ], B&W [ ]
	Self Timer Off: 5 secs { , 10 secs }
	Picture Size: 1280x1024 [ ], 1, 1024x768 [ ], 640x480 [ ], 320x240 [ ]
	Advanced: Picture Quality, Save Location, Shutter Sound, Timer Sound, Default File Name

In the options menu for video camera

Icons Name Description
	White Balance	Auto[ ], Day Light [ ], Tungsteng [ ], Fluorescent [ ]
	Effect	Normal [ ], Sepia [ ], Negatng [ ], B&W [ ]
	Self Timer Of	{ 0 sets { 0 sets {
	Resolution	176x144(MMS) [], 176x144 [ ], 320x240 [ ], Video Share

multimedia

Icons Name Description

Advanced Video Quality, Sound Recording, Save Location, Timer Sound, Default File Name

Zoom in and out

1. Press ▲/▼. It ranges from 7x to 4x.

Increasing or decreasing the brightness

1. Press ◀ / ▶ It ranges from -2 to +2.

Taking a picture

1. Press [30] in standby mode or press Menu > My Stuff > Tools.

2. Press Camera.

3. Focus on the object >OK or press Options >Capture. note: Your photo will be saved automatically to My Stuff >Picture >Camera.

Changing to video camera mode

1. Press [∞] in standby mode or press Menu > My Stuff > Tools > Camera.
2. Press Options while camera mode is activated.
3. Press Video Camera Mode

4. Focus on the object >OK or press Options > Record.

5. Record the motion > Stop.

note: Your video will be saved automatically to My Stuff > Video.

Viewing the taken picture

1. Press in standby mode or press Menu > My Stuff >

Tools > Camera.

1. Press Options > Photo Album.

2. Select the picture > View.

After taking pictures

To Press
Send a multimedia message	Options > Send > as Multimedia Message
Send via mobile share	Options > Send > via Mobile Share
Send via bluetooth	Options > Send > via Bluetooth
Set as wallpaper	Options > Set as > Wallpaper
Set as address book	Options > Set as > Caller ID
Delete	Options > Delete
Rename	Options > Rename
View photo information	Options > Properties

Recording a video

1. Press Menu > My Stuff > Tools > Video Camera.
2. Focus on the object >OK or press Options > Record.
3. Press Stop to stop.
4. Press Options > Play to play the video dip.
5. Press ☐ to go back to preview mode.

Changing to camera mode

1. Press Menu > My Stuff > Tools > Video Camera.
2. Press Options while video camera mode is activated.
3. Press Camera Mode.

For details on taking a picture, see page.

Viewing the recorded video clip

1. Press Menu > My Stuff > Tools > Video Camera.
2. Press Options > Video Album.
3. Select the video clip > Play.

After saving recorded video clips

To Press

Options > Send > as Multimedia

Message

Send via mobile share Options > Send > via Mobile Share

To Press

Send via bluetooth Options > Send > via Bluetooth

View recorded video clip Options > Play

Delete Options > Delete

Rename Options > Rename

View the information Options > Properties

During recording a video

To Press

Receive an incoming call

Stop recording Stop

Photo album

You can save photos to your phone or an external memory card and view, send or delete them in the photo album. JPEG format is supported, and other formats are saved in the Picture folder. note: To access Picture, press Menu > My Stuff > Picture.

Viewing the saved pictures

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Select a picture > View.

multimedia

Viewing zoom mode

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Select a picture >View >Options >Zoom Mode.

Setting as wallpaper in the display

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Select a picture > Options > Set as > Wallpaper.

Setting as caller identification

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Select a picture > Options > Set as > Caller ID.

Sending pictures using multimedia message

1. Press Menu > My Stuff.
2. Press Picture > Camera.

3. Select a picture.

4. Press Options > Send > as Multimedia Message.

For details on creating a multimedia message, see page

Sending pictures via mobile share

1. Press Menu > My Stuff.

2. Press Picture > Camera,

3. Select a picture
4. Press Options > Send > via Mobile Share.

For details on creating a multimedia message, see point

Sending pictures via bluetooth

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Select a picture.
4. Press Options > Send > via Bluetooth.

Deleting multiple pictures

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Press Options > Multiple Select.
4. Press Select to select more than one picture.
5. Press Deselect to unselect.
6. Press Options > Delete.

Viewing file information

1. Press Menu > My Stuff.
2. Press Picture > Camera.
3. Select a picture.
4. Press Options > Properties.

Video album

You can view, send, save and delete videos.

The supported formats are MP4, WMA, 3GP and 3G2.

Playing the saved video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video clip > Play.

Using video player controls

To Press

Play & Pause OK

Stop Options>Stop

Mute Options>Mute

Rewind hold

Fast forward hold

Control volume Side key up or down up ▲/▼

Repeat On Options> Repeat On

Properties Options> Properties

Sending a video clip using multimedia message

1. Press Menu > My Stuff

2. Press Video.

3. Select a video clip.

4. Press Options > Send > as Multimedia Message.

For details on creating a multimedia message, see page

Sending video clip via mobile share

1. Press Menu > My Stuff.

2. Press Video.

3. Select a video clip.

4. Press Options > Send > via Mobile Share

For details on creating a multimedia message, see page

Sending video clip via bluetooth

1. Press Menu > My Stuff

2. Press Video.

3. Select a video clip.

4. Press Options > Send > via Bluetooth.

For details on creating a multimedia message, see page

Deleting multiple video clips

1. Press Menu > My Stuff.

2. Press Video.

3. Press Options > Multiple Select.

4. Press Select to select more than one video.

5. Press Deselect to unselect.

6. Press Options > Delete.

Audio album

You can play, send, delete, moves to external memory or to phone the saved sounds. The supported formats are .qcp, .amr, .mid, .pmd, .mp3, .wav, .mmf, .aac, .m4a, .imy, .wma, .midi, .3gpa, .spmid and .mp4a.

Listening to the recorded sound

1. Press Menu > My Stuff > Audio.

2. Press My Voice > select a sound > Play.

Using sound controls

To Press

Play & Pause [OK]

Stop Options > Stop

Mute Options > Mute

Rewind hold

multimedia

To Press

Fast forward hold ▶

Control volume Side key up or down pr▲:▼

Repeat On Options> Repeat On

Properties Options > Properties

Setting as a ring tone

1. Press Menu > My Stuff > Audio.

2. Select a sound > Options > Set as Ring Tone.

note: The maximum ringtone file size is 300KB.

Moving or copying multiple sounds to external memory

1. Press Menu > My Stuff > Audio,

2. Select a sound and press Options > Multiple Select.

3. Press Select to select more than one sound file.

4. Press Options > Copy to External Memory or Move to

External Memory. The selected sound will copy to Audio

folder in external memory card.

Sending a sound file using multimedia message

1. Press Menu > My Stuff > Audio.

2. Select a sound file.

3. Press Options > Send > as Multimedia Message.

Music player

You can listen to music on your phone through the Music Player. The Music Player is only compatible with and can play the following audio types saved in MP3, AAC, AAC+, and .WMA.

When It means
	Music is playing
	Music has been paused
	Music has been stopped

note: microSD card must be inserted to transfer music to your device.

Adding music from Windows Media Player™

1. Connect the USB cable to the device and the computer.

2. Select Music Player > Select.

3. Open the Sync tab in Windows Media Player™ in your computer.

4. Select the music from the list and drag and drop to your device.

note: Windows Media Player™ 10, 11 and Window XP version is required.

Playing the music

1. Press Menu > AT&T Music > Music Player.

2. Select the categorize using ▲ /▼ to play the music.

3. Select the file using ▲/▼ then press Play.

4. Press Options > Add to Playlist to add to the playlist.

5. Press Options > Stop to stop playing.

note: Music will pause when you receive an incoming call and Music will resume when the call ends.

Icons for player

Icon Name Description
_n,7	Volume
	PausePlay
	RewindFast Forward	Long Press: Rewind, Fast Forward
	Previous TrackNext Track	Short Press: Previous, Next
	Repeat All Tracks
	Repeat Off

multimedia

Icon Name Description
	Repeat Single Track
	Shuffle On / Off	Off: the current list of songs are randomly shuffled for playback OFF: songs play in order and are not shuffled

Making playlist

1. Press Menu > AT&T Music > Music Player.

2. Press Playlists > New Playlist.

3. Input Playlist Name > Save

4. Select All Music, Albums, Artists or Genres.

5. Select the music file using ▲ i▼ then press Select to add to playlist.

6. Press Done.

Editing playlists

1. Press Menu > AT&T Music > Music Player.

2. Press Playlists

3. Select the playlist to add music > Options > Add Tracks.

4. Select the music to add > Select > Done.

5. To remove tracks press Options > Remove Tracks > select the music by pressing Select > Remove.

6. To rename the playlist press Options > Rename Playlist.

7. To delete the playlist press Options > Delete.

Listening to music with a Bluetooth headset

1. While music is playing in the standby mode, Press Menu > AT&T Music > Music Player.

2. Press Now Playing > Play > Transfer to B/T Headset.

Viewing the information

1. Press Menu > AT&T Music > Music Player.

2. Select the categorize using ▲/▼ to play the music.

3. Select the file using ▲;▼ then press Play.

4. Press Options > Properties.

5. Use ▲/▼ to view Track Number, Title, Artist, Album, Genre, Duration, File Name, File Size, Location, Format, Bit Rate, Created, License and Sharing.

Setting as ringtone

1. Press Menu > AT&T Music > Music Player.

2. Select the categorize using ▲/▼.

3. Select the file using ▲/▼.

4. Press Options > Set as Ring Tone.

note: During playback, the file can not be set as ringtone. You cannot set a file larger than 300 Kb as a ringtone.

Deleting music

1. Press Menu > AT&T Music > Music Player.

2. Select the music from the list.

3. Press Options > Delete.

note: If the music is playing you cannot delete it

Shopping the music

1. Press Menu > AT&T Music

2. Press Shop Music.

3. To go to previous page press= .

Listening the radio

1. Press Menu > AT&T Music

2. Press AT&T Radio.

Using music identification

1. Press Menu > AT&T Music.

2. Press Shazam.

3. Hold the phone close to the music. Your phone will analyze the music and display the artist, title and album. Note: For the cost plan contact your nearest carrier.

Watching the music video

1. Press Menu > AT&T Music.

2. Press Music Videos.

Viewing Billboard information

1. Press Menu > AT&T Music.

2. Press Make - UR - Tones.

Launching to community

1. Press Menu > AT&T Music.

2. Press Community.

Launching more applications

1. Press Menu > AT&T Music

2. Press Music Apps

Music player settings

Shuffling music

1. Press Menu > AT&T Music > Music Player.

2. Press Settings

3. Select Shuffle.

4. Select Shuffle On or Shuffle Off.

Repeating the music

1. Press Menu > AT&T Music > Music Player.
2. Press Settings.
3. Select Repeat.
4. Select Repeat All Tracks, Repeat Single Track or Repeat

0ff.

Setting equalizer

1. Press Menu > AT&T Music > Music Player.
2. Press Settings
3. Select Equalizer.
4. Select the category by using ▶/▶ > Select.

Auto Full Screen

1. Press Menu > AT&T Music > Music Player.
2. Press Settings
3. Select Auto Full Screen.
4. Select On or Off

Removing

1. Press Menu > AT&T Music > Music Player.
2. Press Settings
3. Select Remove
4. Select License Data File or All Music Contents >Yes.

Media player

You can play audio and video clips with the media player. The Media Player is only compatible with and can play the following formats saved in .3gp, .mp4, .m4a, .3gpa, .wmv, .wma, .mp3, .aac, .amr, .mid, .mrnf, .prnd, .imy, .wav and .qcp.

note: Do not use this feature illegally. Sound and video can be protected by copyright. It is illegal to copy such sound / video tracks for the purpose of selling or distribution. Pantech does not in any way support the unauthorized use of content on your phone media player.

(四) 发行的定期存款和定期存款

Icons for player

Icon Name Description
	Volume
<<	Previous	Long Press: Rewind, Fast Forward
*	Next
	Pause
	Play
	Repeat On

Playing the video clip

1. Press Menu > My Stuff.
2. Press Tools > Media Player.
3. Press Video.
4. Select a file > Play.

Playing the audio file

1. Press Menu > My Stuff.
2. Press Tools > Media Player.
3. Press Audio.
4. Select the folder > select a file > Play.

For the audio player control see page8.

Other files

You can manage files in unsupported formats saved on your phone. It also lists files received via Bluetooth from other devices.

Viewing the list of the files

1. Press Menu > My Stuff
2. Press Other Files.

Managing memory

Viewing memory status

1. Press Menu > My Stuff
2. Press Used Space.
3. Use ▲/▼ to view the information.

Playing games

You can download games to play. It is easy to download and you can preview them beforehand. You will only be able to view games that are available on your mobile.

multimedia

Shop games

1. Press Menu > My Stuff.
2. Press Games.
3. Select Shop Games.
4. Play the demo and press BUY to download the complete game.

Link™ P7040 5 Useful Features Alarm Calendar Notepad and voice memo World time Calculator, tip calculator and converter Stop watch and timer Business card Memory information

5

Useful Features

Alarm

Calendar

Notepad and voice memo

World time

Calculator, tip calculator and converter

Stop watch and timer

Business card

Memory information

Alarm

Setting an alarm

1. Press Menu > My Stuff > Tools > Alarm Clock.

2. Press Create New for new alarm for the first time.

3. Set the Cycle, Time, Alarm Sound, Alert Type, Volume,

Smoize and Power Alarm > Save.

Viewing the saved alarms

1. Press Menu > My Stuff > Tools > Alarm Clock.

Editing existing alarms

1. Press Menu > My Stuff > Tools > Alarm Clock.
2. Select an alarm > Edit.
3. Press Options > Delete to delete an alarm.
4. Press Options > Create New to add new alarm.

Calendar

Calendar helps you manage your

schedule including your time for calls or special days. You can set a reminder on any given date with this function.

Viewing calendar

1. Press Menu > My Stuff > Tools > Calendar.

note: Monthly view is displayed as default.

In the monthly view

To Press

Move to another day

for Previous

▶ for Next

Move to another week

▲ for Previous

▼ for Next

View other month

Side key down for Previous

Stock key up to next

Creating a new event and edit

1. Select a day > Options > New Event.

2. Select Schedule, Task or Note.

3. Input the events > Save

note: You can create events for dates from 01/01/2000 to 12/31/2099

Notepad and voice memo

Using notepad

1. Press Menu > My Stuff > Tools > Notepad

2. Press Create New for the first time. To add new note press Create New or Options > Create New.

3. To edit memo press Edit.
4. Press Save to save
5. If you want place a note on idle, Press Options > Place on Wallpaper.
6. If you want remove the note from idle, Press Options > Remove from Wallpaper.

Recording voice memo

1. Press Menu > My Stuff > Tools > Voice Memo.
2. Press New Record for the first time To add new voice memo press New Record or Options > New Record.
3. Press Record.
4. Press Stop to stop recording. It will automatically save on My Voice.
5. Press Play to listen
   Note: To access My Voice, press Menu > My Stuff > Audio > My Voice.
   listening a recorded sound
6. Press Menu > My Stuff > Audio > My Voice.

1. Select a sound > Play.

Using sound controls

To Press

Play & Pause [OK]

Control volume Side key up or down or ▲?▼

Stop Options > Stop

Mute Options > Mute

Repeat Options > Repeat on off

Properties Options > Properties

World time

Using world time

1. Press Menu > My Stuff > Tools > World Time.
2. Select the city by using the up or down navigation key.
3. Press Save to save, note: If you want to set dual time in idle mode, press Menu > Settings > Display > Home Screen > ClockType > ClockType6.

Calculator, tip calculator and converter

Using the calculator

1. Press Menu > My Stuff > Tools>

Calculator.

1. Use ▲/▼/◄/►(OK) to calculate.
2. Press (c) to erase one digit.
3. Press Reset to reset
4. Press - to use the decimal point.

Using the tip calculator

1. Press Menu > My Stuff > Tools >
   Tip Calculator.
2. Enter values for all variable fields
   (BUKS) Tin(%) Split and the
   corresponding calculation fields
   Corresponding calculation fields (Tip(\), Total(\), You Pay) are up
   The image is too blurry to recognize any text content.
3. Press Reset to reset.
4. Press ☐ to use the decimal point.

Using the converter

1. Press Menu > My Stuff > Tools > Converter.
2. Select the categories.

1. Select current unit and enter figure. Other unit fields are updated automatically.

Stop watch and timer

Using the stop watch

1. Press Menu > My Stuff > Tools >
   Stop Watch.
2. Press Start to start.
3. Press Stop to stop.
4. Press Continue to restart
5. Press Reset to clear

6. To change to lag time, press Mode > Lag Time Mode.

7. To split the stopwatch, press Mode > Split Time Mode. note: In Basic Mode, when you exit the stopwatch menu, or become idle, the stopwatch will continue running and will be indicated by a clock icon. You can access the stopwatch by re-entering the stopwatch menu.

Using the timer

1. Press Menu > My Stuff > Tools > Timer.

2. Press Set to input the time.

3. Enter the hour, minute and second

   OK,

4. Press Start to start.
5. Press Restart to restart.

note: In Bask Mode, when you exit the timer menu, or become idle, the timer will continue running and will be indicated by a timer icon. You can access the timer by re-entering the timer menu.

Business card

You can send your information as a multimedia message or via bluetooth.

Creating your own business card

1. Press Menu > Address Book > My Info.
2. Edit the fields > Save.

Forwarding

1. Press Menu > Address Book > My Info.
2. Press Options > Send My Info > Multimedia Message or
   Bluetooth.
3. Search for device or choose the device to send via Bluetooth

and press Select.

1. Enter a message for Multimedia Message, Press Send to and
   select the person to send message and press Select.

2. Press Send.

Updating information

1. Press Menu > Address Book > My Info.
2. Press Options > Edit My Info
3. Update information.
4. Press Says
   4.1135 Silver

Memory information

You can view the information of your phone or memory card for

Used, Audio, Games, Applications, Picture, Video, Other Files

and System.

Viewing the information

1. Press Menu > My Stuff > Used Space.

Formatting the memory

1. Press Menu > My Stuff.

2. Press Used Space.

3. Press ◀ /▶ to select Phone or Memory Card
4. Press Format > Yes.

P7040 Link™ 6 Connectivity Bluetooth Using mobile web Using the browser Profile settings

6

Connectivity

Bluetooth

Using mobile web

Using the browser

Profi le settings

Bluetooth

Bluetooth technology enables free wireless connections between electronic devices within a maximum range of 33 feet (10 meters). Bluetooth connections can be used to send images, text, business cards, calendar events and notes or to connect to computers using Bluetooth technology.

Your mobile phone supports:

- Connect to PC to access internet.

- Connect to Hands-Free

• Connect to electronic devices.

Icons for Bluetooth

3	Bluetooth is active.
4	Bluetooth hands-free headset is connected.
5	Bluetooth A2DP headset is connected.
6	Bluetooth hands-free + A2DP headset is connected.
7	Data transfer via Bluetooth.

Activating Bluetooth

1. Press Menu > Settings > Connectivity > Bluetooth >

Activation.

1. Select On or Off.

Adding a device

1. Press Menu > Settings > Connectivity > Bluetooth > My

Devices.

1. Press Search.

2. The available device will display.

3. To select the device press > Select. To view the details press

View.

1. Enter password.

note: The other device must be in pairing mode.

Sending an object

1. Select the file from Menu > My Stuff > Picture, Video,
   Audio or Other Files.
2. Press Options > Send > via Bluetooth.
3. Press Search.
4. Select the device > Select.

note: If the other Bluetooth device requests pairing, the object is sent

after pairing is completed. Locked object or ones containing original nights

may not be forwarded.

Receiving an object

The receiving of an object starts only when the receipt has been

approved.

The received file will be saved in each place. For example, if you

received contacts information from the sender, it will be saved in

your phone's memo

Setting the visibility

1. Press Menu > Settings > Connectivity > Bluetooth >

Visibility.

1. Select Hide or Show.

Naming the phone

1. Press Menu > Settings > Connectivity > Bluetooth > My
   Bluetooth Info.
2. Select the Name > Edit > edit the field > Save.
   note: This is what others will see in their device's display for your phone when searching for your device.

connectivity

Using Mobile Web

Accessing Mobile Web

1. Press OK in standby mode or press Menu > Mobile Web.
   note: It will access the Mobile Web homepage.

Using the browser

Accessing browser

1. Press Menu > My Stuff > Applications > Browser >
   Home
   note: It will access your service provider's homepage.

Viewing bookmarks

1. Press Menu > My Stuff > Applications > Browser >
   Bookmarks.
2. To open the site, press Go.
3. To send via text message, press Options > Send by MSG.

Setting new bookmarks

1. Press Menu > My Stuff > Applications > Browser >
   Bookmarks.
2. Press Options > Create New.
3. Enter the field > Save.

Entering web addresses

1. Press Menu > My Stuff > Applications > Browser > Enter Address.

2. Enter the web address > 60.

Viewing history

1. Press Menu > My Stuff > Applications > Browser > History.

Setting advanced options

1. Press Menu > My Stuff > Applications > Browser > Manage > Options.

2. Select the category > Select.

3. Select the options > Select.

Viewing certificates

1. Press Menu > My Stuff > Applications > Browser > Manage > Security > Certificates.

Using memory operations

1. Press Menu > My Stuff > Applications > Browser > Manage > Private Data.

2. To dear the cache, press Clear Cache > Yes.

3. To dear the cookies, press Clear Cookies > Yes,

4. To dear the history, press Clear History > Yes.

Viewing download status

1. Press Menu > My Stuff > Applications > Browser > Manage > Download Manager.

Profile settings

You can set a profile and view Profile Name, Home URL, Connection Type, Proxy Address and Proxy Port.

Adding a new profile

1. Press Menu > My Stuff > Applications > Browser >

Manage > Profiles.

1. Press Options > Create.

2. Enter the fields > Save.

Editing profile

1. Press Menu > My Stuff > Applications > Browser >

Manage >Profiles.

1. Select a profile > Options > Edit.

Viewing default profile

1. Press Menu > My Stuff > Applications > Browser >

Manage > Profiles.

1. Select Mobile Web > Options > View.

Deleting profile

1. Press Menu > My Stuff > Applications > Browser >

Manage > Profiles.

1. Select a profile > Options > Delete.

connectivity

P7040 Link™ 7 Settings Language Time and date Ringtones Display Security Reset TTY

7

Settings

Language

Time and date

Ringtones

Display

Security

Reset

TTY

Language

Setting up

1. Press Menu > Settings > Phone > Language.

2. Select Screen Text or Predictive.

3. Select the language > Select.

Time and date

Setting up

1. Press Menu > Settings > Phone > Time & Date.

2. Select Auto Update, Time, Time Format, Date or Date

Format > Select.

1. Select the options > Select.

Ring tones

Setting ring tones

1. Press Menu > My Stuff > Audio.

2. Select the folder > select a file > Options > Set as Ring

Tone.

Setting sound profile

1. Press Menu > Settings > Profiles

2. Select Normal, Vibrate and Ring, Vibrate only, Silent or Flight Mode.

Display

Setting the home screen

You can set the Wallpaper, Clock Type and Text.

1. Press Menu > Settings > Display > Home Screen.

Setting the menu type

1. Press Menu > Settings > Display > Menu Type.

Setting the color theme

1. Press Menu > Settings > Display > ColorTheme.

Setting the font

1. Press Menu > Settings > Display > Font Style.

Setting the brightness

1. Press Menu > Settings > Display > Brightness.

note: Modifying brightness may affect battery life.

Setting time for backlight

1. Press Menu > Settings > Display > Backlight Timer.

note: Modifying backlight time may affect battery life.

settings

Security

Locking the phone

1. Press Menu > Settings > Security > Phone Lock > Phone Lock.

2. Select On.

note: The default password is 1294. To change the password press menu > Settings > Security > Phone Lock > Change Password.

Locking the PIN

The Personal Identification Number is the security code that protects the phone or SIM against unauthorized use.

1. Press Menu > Settings > Security > PIN > PIN Lock > Yes

2. Enter PIN code > OK.

note: To change the PIN code press Menu > Settings > Security > PIN > Change PIN.

Changing PIN 2

1. Press Menu > Settings > Security > Change PIN2.

Locking the keypad automatically

You can set the keypad to lock automatically to prevent mistaken key presses.

1. Press Menu > Settings > Security > Auto Key Lock.

2. Select On.

note: The auto keypad lock time is equivalent to the backlight display time. In change the backlight time, press Menu > Settings > Display > Backlight Timer.

Unlocking Auto Key Lock

1. Press Menu > Settings > Security > Auto Key Lock.

2. Select Off.

Changing hidden key

The hidden key is a security code for USIM Contact. You can lock the person's information in the USIM Contacts with the hidden key.

1. Press Menu > Settings > Security > Change Hidden Key. note: The default password is dependent by SIM card (either depends on the SIM card or determined by the SIM card).

Setting fixed dialing number

1. Press Menu > Settings > Security > FDN.

2. Select On or Off.

For details on fixed dialing, see page.

Reset

Resetting the phone

1. Press Menu > Settings > Reset.

2. Enter password > MasterReset > Yes

note: It will return configuration settings to default. The default password is '1234'.

Clearing the phone

1. Press Menu > Settings > Reset

2. Enter password > Master Clear > Yes

note: It will change the setting as default and erase all personal data. The default password is '1234'.

TTY

The teletypewriter (TTY) is a telecommunications device that

allows people who are deaf or hard of hearing, or who have

speech or language disabilities, to communicate via a telephone.

Setting teletypewriter

1. Press Menu > Settings > TTY.
2. Select Disable, TTY Full, TTY Talk or TTY Hear.
   • Disable: ITY mode is disabled.

• TTY Full: Users who cannot talk and hear, can send and receive text messages.
- ITY Talk: Users who can talk but cannot hear, can receive text messages and reply with voice message.
• TTY Hear: Users who can hear but cannot talk, can send a text message and receive a voice message.

settings

P1040

Link™

8

Appendix

Alert message

Troubleshooting checklist

Safety information

Safety precautions

About the battery usage

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices

FCC Regulatory Compliance

Warranty

Alert message

If you experience any problem while using your mobile phone, please refer to the following checklist. If the problem still persists, contact your dealer or nearest carrier.

When the "Insert SIM Card" message appears: Make sure the SIM card is correctly installed. Check to see if the SIM card is working properly. If it does not work, try to clean the contact points of the card with a dry cloth. If it is out of order, take it to your service provider.

When the "Messages full" message appears: The received or saved messages are full in your phone memory. You need to delete the message.

When the "Phone and SIM messages are full. Delete Messages" message appears: The received or saved messages are full in your phone and SIM card memory. You need to delete the message.

When the "Password" message appears in Phone locked state: Enter the phone password. The default password is "1234". If you cannot remember the password, contact the nearest carrier. When the "Enter PIN1" message appears: Input PIN1. If you cannot remember it, contact your service provider. You

can still receive calls even if your mobile phone becomes locked after entering the incorrect PIN1 on three consecutive attempts.

When the "No Service" or "Network Search" appears: If you cannot make/receive a call when you are indoors or undergrounds where the signal strength is poor, move toward a window or go out to an open area. If you still cannot make a connection, contact your service provider.

Troubleshooting checklist

When audio quality is poor: End a call and try again.

When the other party cannot hear you speaking: Your phone may be set to MUTE. Disable the MUTE function. Or your hand may be covering the microphone located below the).

When battery lifetime is shorter than usual: This may happen when you are in an area with low signal strength. Turn off your phone when it is not in use. Change the battery when battery energy is exhausted.

When your mobile phone does not turn on: Make sure your battery is charged. Check to see if your phone works while recharging the battery.

appendin

When you are unable to send a message:

Either you are not registered to receive an SMS service, or you may be in an area where your network service provider cannot provide such a service. When you are unable to make a call:

Your phone may be set to "fixed dial." Cancel the "fixed dial" function. When you are unable to charge the battery:

This may be the result of one of the following three cases: 1. Your charger may be out of order. Contact your nearest dealer. 2. You may be attempting to use the phone in an overly hot/cold temperature. Try changing the charging environment.

1. Your battery may have not been connected to the charger properly. Check the connector.

When you are unable to input data into your Address Book: Your Address Book memory may be full. Try deleting some entries from your Address Book.

When you are unable to select a certain function:

You may not have subscribed to that function, or your network service provider may be in an area where such service cannot be provided. Contact your local service provider.

Safety information

The following list shows how to maintain your mobile phone, together with precautions to take.

- Keep your mobile phone and its accessories out of the reach of children and pets.

- Maintain your mobile phone in dry conditions and keep it within normal operating temperatures. Temperatures higher than 55°C (131°F) or lower than -20°C (-4°F) may damage your phone.

- Do not try to dry your phone in a microwave oven. If not, sparks can occur and cause an explosion or fire.

- Do not use or store your mobile phone in dusty, dirty areas. - Do not attempt to disassemble your mobile phone.

- Do not drop or cause severe impact to your mobile phone. - Do not use chemical products, cleaning solvents or detergents to clean your mobile phone.

- If your mobile phone does not work properly, contact your dealer immediately.

- Use only authorized batteries, battery chargers and accessories. Any malfunction or damage caused by the use of unauthorized batteries, battery chargers and accessories will void the limited product warranty. - Ensure that the battery and battery charger do not come in contact with conductive objects.

Safety precautions

Using a mobile phone while driving may be prohibited. Please check local laws and regulations with regard to the prohibition of mobile phone use while driving, and comply with them.

Use of your phone while you are driving may disturb your concentration and so cause an accident. Always switch your phone off to drive safely. You should use your phone in an emergency, either use a hands free device built into your car or pull over in a safe place first.

Switch off in restricted areas

Always switch your phone off in areas where mobile phone use is restricted.

Switch off in explosive or dangerous areas

Always switch your phone off in areas with explosive or dangerous materials (such as fuels, fuel stations or areas containing chemical goods) and obey any instructions or signals. Do not remove your mobile phone's battery in such areas.

Switch off in aircraft

Always switch your phone off or select Flight Mode (press the Menu > Settings > Profiles > Flight Mode) when you are in an aircraft. The electromagnetic waves emitted by your phone may affect the electronic navigation equipment in the aircraft.

Switch off in hospitals and near medical equipment

Always switch your phone off in hospitals, and obey the regulations or rules of the hospital.

Switch your phone off when using medical equipment for private purposes, if possible. Always consult with the medical equipment's manufacturer or an expert regarding phone use near the medical equipment.

Installing a hands free device in your vehicle

Install vehicle hands free devices away from the steering wheel and airbag expansion area, otherwise injury may result.

Mobile phones and other electronic devices

Mobile phones emit electromagnetic waves that may affect nearby electronic devices. When it is switched on, do not place your phone close to delicate electronic equipment.

About the battery usage

Your phone is powered by a Lithium Ion (Li-Ion) battery. This means that, unlike other forms of battery technology, you can recharge your battery while some charge remains without reducing your phone's autonomy due to the "battery memory effect" inherent in those technologies.

Do not use a damaged battery or charger.

- Do not disassemble or open crush, bend or deform, puncture or shred.

- Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

- Do not put your battery into contact with conductive objects.

– Dispose of and recycle used batteries in accordance with local

regulations. Do not dispose of batteries by nursing, they may explode.

- Do not use an unauthorized charger.

- Only use the battery for the device for which it is specified.

- Only use the battery with a charging device that has been qualified with the device per this standard. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard. - Do not short circuit a battery or allow metallic conductive objects to

- Replace the battery only with another battery that has been qualified with the device per this standard, IEEE-Std-1725-2006. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

- Promptly dispose of used batteries in accordance with local regulations - Battery usage by children should be supervised.

- Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

— Use your battery for the specified purpose only.

The closer you are to your network's base station, the longer your phone

Usage time because less battery power is consumed for the connection. The battery recharging time varies depending on the remaining battery capacity and the battery and charger type you use.

Battery life inevitably shortens over time.

Use an authorized battery and charger only. Since overcharging may shorten battery life, remove the phone from its charger once it is fully charged. Unplug the charger, once charging is complete. Leaving the battery in hot or cold places, especially inside a car in summer or winter, may reduce the capacity and life of the battery. Always keep the battery within normal temperatures. To prevent injury or burns, ensure that no metal objects come into contact with the + and - terminals of the battery.

FCC Hearing-Aid Compatibility (HAC)

Regulations for Wireless Devices

On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01-309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to require digital wireless phones be compatible with hearing aids. The intent of the HAC Act is to ensure reasonable access to telecommunications services for persons with hearing disabilities.

While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.

The wireless telephone industry has developed a rating system for wireless phones, to assist hearing device users find phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box.

The ratings are not guarantees. Results will vary depending on the user's hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

- M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

- T-Ratings: Phones rated T3 or T4 meet FCC requirements and are like to generate less interference to hearing devices than phones that are not labeled. T4 is the better/higher of the two ratings.

Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this rating. Higher ratings mean that the hearing device is relatively immune to interference

noise. The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered acceptable for normal use. A sum of 6 is considered for best use.

In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level rating, the sum of the two values equal M5. This is synonymous for 1 ratings. This should provide the hearing aid user with "normal usage" while using their hearing aid with the particular wireless phone. "Normal usage" in this context is defined as a signal quality that is acceptable for normal operation.

The M mark is intended to be synonymous with the U mark. The T mark is intended to be synonymous with the UT mark. The M and T marks are recommended by the Alliance for Telecommunications Industries Solutions (ATIS). The U and UT marks are referenced in Section 20.19 of the FCC Rules. The HAC rating and measurement procedure are described in the American National Standards Institute (ANSI) C63.19 standard.

To ensure that the Hearing Aid Compatibility rating for your phone is maintained, secondary transmitters such as Bluetooth and WLAN components must be disabled during a call. See Page 62 for instructions to disable these components.

appendin

FCC Regulatory Compliance

FCC Regulatory Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Your mobile device is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commission [FCC] adopted RF exposure guidelines with safety levels for mobile devices. Those guidelines are consistent with safety standards previously set by both U.S. and International standards bodies: American National Standard Institute (ANSI), National Council of Radiation Protection and Measurements (INCRP), and International Commission on Non-Ionizing Radiation Protection (NCMRP). Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. The design of your phone complies with the FCC guidelines and applicable.

Statement according to FCC part 15.105

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help. Statement according to FCC part 15.21

Modifications not expressly approved by this company could void the user's authority to operate the equipment.

RF exposure FCC

For body worn operation, to maintain compliance with FCC RF exposure guidelines, use only accessories that contain no metallic components and provide a separation distance of 20 mm (0.6 inches) to the body. Use of other accessories may violate FCC RF exposure guidelines and should be avoided.

This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

Health and Safety Information FCC

This EUT has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in AMS/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003 Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W / kg^ .

* In the U.S. and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg [W/kg] averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in.

** This device contains 1800 MHz GSM functions that are not operational in U.S. Territories; this filing is applicable only for 850 MHz GSM and 1900 MHz PCS operations.

Warranty

Protect Your Warranty

Read your Warranty carefully, with the special consideration to paragraph seven of the Limited Warranty for your unit.

"Warranty does not apply to... or to any product or part thereof which has suffered through alteration... mishandling, misuse, neglect or accident". Many companies are making look alike accessories and in some cases, promoting that their product is equal to or better than the Pantech product. Be careful. Some of these products may not be compatible to use with your Pantech product and may damage the unit or cause it to malfunction.

If service is required on your unit and it is determined that a non-Pantech accessory has created the problem with your unit, the Warranty will not apply. In addition, if the unit has already suffered irreversible damage by reason of a non-compatible accessory, the Warranty will be voided. To protect your Warranty, use only compatible accessories which cannot damage or interfere with the functioning of your Pantech product.

12 Month Limited Warranty

Pantech Wireless, Inc. (the Company) warrants to the original retail purchaser of this Pantech handheld portable cellular telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or workmanship that results in product failure within the first twelve [12] months period from the date of purchase, such defect(s) will be repaired or replaced (with new or rebuilt parts) at the Company's option, without charge for parts or labor directly related to the defect(s).

appendin

The antenna, keypad, display, rechargeable battery and battery charger, if included, are similarly warranted for twelve (12) months from date of purchase. This Warranty extends only to consumers who purchase the product in the United States or Canada and it is not transferable or assignable.

This Warranty does not apply to:

(a) Product subjected to abnormal use or conditions, accident, mishandling, neglect, unauthorized alteration, misuse, improper installation or repair or improper storage;

(b) Product whose mechanical serial number or electronic serial number has been removed, altered or defaced.

(c) Damage from exposure to moisture, humidity, excessive temperatures or extreme environmental conditions;

(d) Damage resulting from connection to, or use of any accessory or other product not approved or authorized by the Company;

(e) Defects in appearance, cosmetic, decorative or structural items such as framing and non-operative parts;

(1) Product damaged from external causes such as fire, flooding, dirt, sand, weather conditions, battery leakage, blown fuse, theft or improper usage of any electrical source.

The Company disclaims liability for removal or reinstallation of the product, for geographic coverage, for inadequate signal reception by the antenna or for communications range or operation of the cellular system as a whole.

To obtain repairs or replacement within the terms of this Warranty, the product should be delivered with proof of Warranty coverage (e.g. dated bill of sale), the consumer's return address, daytime phone number and/or fax number and complete description of the problem, transportation prepaid, to the Company by calling the number listed below or to the place of purchase for repair or replacement processing.

To locate Pantech Authorized Service Center, call: [phone] or email [e-mail]

Please have the following information available when you send the phone in for repair.

- A valid original Proof of Purchase

- Return address

Daytime phone number or fax number

Model P

- IMEI # Look for the 15 digit IMEI # behind the battery of the device.

- Complete description of the problem

- Transportation prepaid

Other Warranty Program

You may have other warranty program with your purchase, such as warranty exchange. If so, please refer to equipment package or the original point of sale.

THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.

ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS BEING RESTAINED OR REPLACED.

No person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.

Some states or provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so the above limitation or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.

For technical support in the U.S. & Canada, call [phone].

Or email: [e-mail].

Dr visit the web sitewww.pantechusa.com

For all other inquiry, write to:

PANTECH WIRELESS, INC.

5607 Glenridge Dr. Suite 500 Atlanta, GA 30342

memo

PANTECH Link

Manual del Usuario

m = 311

m = 311

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it and output nothing or only meaningful text. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated placeholder underscores where none exist in the GT. Hence, the result is inconsistent with the Ground Truth.

prabación.

di yoz

in voz.

Mi reapical to Audio

Molecular > Rojo,

Pure horizontal and vertical lines forming a design element (no text or symbols)
