| Product type | LED Television |
| Brand | Telefunken |
| Model | D32H472E4CW-W |
| Screen size | 32 inches (80 cm) |
| Resolution | HD 1366 x 768 pixels |
| Aspect ratio | 16:9 |
| Backlight | LED |
| Tuner | DTT (DVB-T2), Satellite (DVB-S2), Cable (DVB-C) |
| Connectivity | 2x HDMI, 1x USB, 1x VGA, 1x PC audio input, 1x Optical digital audio output, 1x Headphone jack, 1x Antenna, 1x Ethernet |
| Power supply | 220-240 V ~ 50 Hz |
| Power consumption (operation) | 45 W (typical) |
| Power consumption (standby) | < 0.5 W |
| Weight (with stand) | 4.2 kg |
| Weight (without stand) | 4.0 kg |
| Dimensions (with stand) | 73.5 x 46.0 x 18.0 cm |
| Dimensions (without stand) | 73.5 x 43.5 x 8.5 cm |
| Main features | Program guide, Parental control, USB recording, Timer, Hotel mode |
| Energy class | F (former A+) |
| Repairability index | 7.4 / 10 |
| Maintenance and cleaning | Use a soft, dry cloth. Do not use abrasive products. |
| Safety | Stability, ventilation, surge protection |
Frequently Asked Questions - D32H472E4CW-W TELEFUNKEN
How to install the Telefunken D32H472E4CW-W television for the first time?
Plug in the television, turn it on with the remote control, follow the setup wizard to select the language, country, and perform channel search (DTT, satellite, or cable).
Why is my remote control not working?
First check the batteries (AAA type): replace them if necessary. Make sure no obstacle blocks the infrared sensor at the front of the TV. If the problem persists, reset the remote control by removing the batteries and pressing each key for 3 seconds.
How to search for channels automatically?
Go to the menu 'Settings' > 'Channels' > 'Auto search'. Select the tuner type (DTT, satellite, cable) and confirm. The search may take several minutes.
Can I plug in a USB flash drive or external hard drive?
Yes, the TV has a USB port. Plug in your device, then use the media player to play photos, music or videos. FAT32 format is recommended.
How to connect an HDMI device?
Plug the HDMI cable into one of the HDMI ports on the TV and into the device (console, decoder, PC). Select the corresponding HDMI input with the 'Source' button on the remote control.
What to do if the picture is distorted or does not appear?
Check the cable connections (antenna, HDMI). Make sure the correct source is selected. In the menu, adjust the picture settings (format, resolution). If the screen remains black, test with another source.
How to activate parental control?
Go to 'Settings' > 'Lock' or 'Parental control'. Set a 4-digit PIN code (default 0000). You can then block certain channels or inputs.
Is it possible to mount the TV on the wall?
Yes, the TV is compatible with a VESA 100x100 mm wall mount. Use suitable screws (not supplied) and follow safety instructions (solid wall, no hidden cables).
How to clean the screen without damaging it?
Turn off the TV and let it cool down. Use a dry, clean microfiber cloth. For stubborn stains, slightly dampen the cloth with distilled water. Never use chemicals or glass cleaners.
What to do in case of freeze or malfunction?
Try turning the TV off and on again. If it is unresponsive, unplug it for 30 seconds then plug it back in. If the problem persists, perform a factory reset in the menu 'Settings' > 'Reset' (the default PIN is 0000).
