| Product Type | Bookshelf Speaker |
| Brand | Revel |
| Model | C363DT |
| Dimensions (H x W x D) | 16.5 x 9.0 x 11.5 in (419 x 229 x 292 mm) |
| Weight | 20.5 lbs (9.3 kg) each |
| Power Handling (Recommended Amplifier) | 25 - 150 watts RMS |
| Impedance | 8 ohms nominal (6.6 ohms minimum) |
| Frequency Response | 42 Hz - 20 kHz ±3 dB |
| Sensitivity | 87 dB (2.83V @ 1m) |
| Crossover Frequency | 2.5 kHz |
| Drivers | 1" (25mm) aluminum dome tweeter, 6.5" (165mm) micro-ceramic composite woofer |
| Inputs | Single pair of gold-plated binding posts |
| Bi-wiring / Bi-amping Capable | Yes (with jumper removal) |
| Placement | Bookshelf or stand-mounted, at ear level |
| Grille | Removable magnetic grille |
| Finish | Black Ash or Cherry vinyl veneer |
| Warranty | 5 years limited |
| Cleaning | Wipe with a soft, dry cloth. Avoid harsh cleaners. |
| Safety | Do not expose to moisture or excessive heat. |
| Spare Parts | Contact Revel authorized service centers for replacement drivers or crossovers. |
Frequently Asked Questions - C363DT Revel
What is the recommended amplifier power for the Revel C363DT?
The recommended amplifier power is between 25 and 150 watts RMS per channel. Using an amplifier within this range ensures optimal performance and avoids damage.
Can I bi-wire or bi-amp the C363DT speakers?
Yes, the C363DT features dual binding posts that allow bi-wiring or bi-amping when the metal jumpers are removed. This can improve sound quality by separating the signal paths for the tweeter and woofer.
What is the best placement for these bookshelf speakers?
Place the speakers on sturdy stands or bookshelves at ear level when seated. Keep them at least 12 inches from the back wall to avoid bass bloat. Toe them in slightly toward the listening position.
Do the C363DT speakers require a break-in period?
Yes, Revel recommends a break-in period of about 20-40 hours of moderate playback. During this time, the suspension components will loosen, and the sound will become smoother and more dynamic.
What is the impedance of the C363DT?
The nominal impedance is 8 ohms with a minimum of 6.6 ohms. It is compatible with most amplifiers and receivers, but ensure your amp can handle 8-ohm loads.
How do I clean my Revel C363DT speakers?
Use a soft, dry cloth to gently wipe the cabinet and grille. Avoid using any liquids, abrasive cleaners, or vacuum cleaners near the drivers. For stubborn marks, slightly dampen the cloth with water.
Can I use these speakers in a home theater system?
Absolutely. The C363DT works well as front or rear channels in a surround sound setup. Pair them with a capable subwoofer for a full-range experience.
What is the frequency response of the C363DT?
The frequency response is 42 Hz - 20 kHz ±3 dB. This provides extended low-end for a bookshelf speaker while maintaining accurate highs.
Are replacement parts available for the C363DT?
Yes, Revel offers replacement drivers, crossovers, and other parts through authorized service centers. Contact Revel customer support or visit their website for details.
What is the sensitivity of these speakers?
The sensitivity is 87 dB (2.83V @ 1m). This means they can produce a moderate volume with a standard amplifier, but higher power will provide more headroom.
