RCA 680 - Heating Zibro Kamin - Free user manual and instructions

Product Type	Portable Kerosene Heater
Brand	Zibro Kamin
Model	RCA 680
Heating Power	3.0 kW (10,200 BTU/h)
Fuel Type	Kerosene (paraffin)
Tank Capacity	6.0 liters
Burn Time per Tank	Approx. 12 hours at full power
Ignition	Electronic (battery powered)
Dimensions (HxWxD)	60 x 40 x 30 cm (23.6 x 15.7 x 11.8 in)
Weight (empty)	12.0 kg (26.5 lbs)
Safety Features	Tip-over switch, overheat protection, flame failure device
Thermostat	Adjustable room thermostat
Room Coverage	Up to 70 m² (750 ft²)
Emissions	Low CO and NOx emissions (eco-friendly)
Maintenance	Clean burner and wick regularly; replace wick annually
Spare Parts Available	Wick, igniter, burner assembly, tank cap
Warranty	2 years (manufacturer warranty)
Manual Languages	English, Dutch, German, French (depending on region)

Frequently Asked Questions - RCA 680 Zibro Kamin

How do I ignite the Kamin RCA 680?

Press and hold the electronic ignition button while turning the fuel knob to the 'Start' position. Release after ignition. If using batteries, ensure they are fresh.

What type of fuel should I use?

Only use high-quality kerosene (paraffin) to ensure clean burning and prevent soot. Do not use diesel or other flammable liquids.

How do I refuel the heater?

Turn off the heater and let it cool. Unscrew the tank cap, fill using a funnel, and replace cap tightly. Wipe any spills before turning on.

Why does my heater produce smoke or smell?

This may indicate incomplete combustion. Check for a clogged wick or low fuel level. Clean the burner and wick according to the manual.

How often should I clean the wick?

Clean the wick after every 500 hours of use or if you notice reduced performance. Replace the wick annually or when it becomes worn.

What safety features does the RCA 680 have?

It includes a tip-over switch, overheat protection, and a flame failure device that automatically shuts off the heater if the flame goes out.

Can I use the heater in a bedroom?

Yes, but ensure proper ventilation (e.g., leave a door slightly open) and never cover the heater. Follow all safety instructions in the manual.

Where can I find replacement parts?

Replacement wicks, igniters, and other spare parts are available through Zibro Kamin dealers or online retailers. Use only genuine parts.

How do I store the heater when not in use?

Empty the fuel tank completely, clean the burner and wick, and store in a dry, dust-free place. Remove batteries from the ignition.

What is the maximum room size for this heater?

The Zibro Kamin RCA 680 is designed to heat rooms up to approximately 70 m² (750 ft²), depending on insulation and ceiling height.

USER MANUAL RCA 680 Zibro Kamin

Technical line drawing of a mechanical device with two inset views showing internal components (no text or symbols)

RCA-300

RCA-882

RCA-86

1A

Illustration of a hand washing a dog inside a cage (no text or symbols)

2A

Illustration of a hand placing a circular object into a cage with a ring and a small protrusion (no text or symbols)

3A

Illustration of a hand holding a rotary dial with three circular components above (no text or symbols)

1B

Illustration of a hand holding a ball next to a mechanical component (no text or symbols visible)

2B

1C

Diagram of a mechanical or electrical component with layered structure and hand gesture (no text or symbols)

4A

5A

Hand holding a gear with directional arrows indicating motion or force (no text or symbols)

6A

6B

7A

Technical line drawing of a mechanical component with a dial and handle (no text or symbols)

7B

7C

8
3
b

Line drawing of a mechanical or architectural component with no visible text or symbols

Technical line drawing of a mechanical component with no visible text or symbols

C

Technical line drawing of a mechanical component or housing (no text or symbols)

d

Technical line drawing of a mechanical component with no visible text or symbols

Simple line drawing of a table with two chairs, no text or symbols present
