FRMA234B - Oven Profilo - Free user manual and instructions

Product Type	Built-in Electric Oven
Brand	Profilo
Model	FRMA234B
Overall Dimensions (HxWxD)	595 x 595 x 575 mm
Oven Cavity Volume	71 L
Net Weight	30 kg
Power Supply	220-240 V, 50/60 Hz
Rated Current	16 A
Total Power Consumption	3.0 kW
Energy Efficiency Class	A
Heating Modes	Top heat, bottom heat, fan-assisted, grill, defrost, pizza mode
Temperature Range	50°C to 250°C
Control Type	Rotary knobs and electronic timer
Display	LED digital display
Interior Light	Yes, halogen
Cleaning System	Enamel interior, easy-clean glass door
Safety Features	Child lock, automatic shut-off, cool door touch
Door Type	Drop-down, double-glazed glass
Spare Parts Availability	Genuine parts available via authorized service centers
Repairability Index	8.5/10

Frequently Asked Questions - FRMA234B Profilo

How do I install the Profilo FRMA234B oven?

Ensure the oven is installed by a qualified electrician. It must be connected to a 220-240 V, 16 A circuit. Follow the cut-out dimensions in the manual (595x595x575 mm) and secure the oven with provided screws.

Can I use metal containers in this oven?

Yes, metal containers are safe for most cooking modes. However, avoid using them in microwave mode (if applicable) and never cover the bottom with aluminum foil.

How do I set the timer on the oven?

Turn the timer knob to the desired cooking time (up to 120 minutes). The oven will automatically shut off when the time elapses. For end-of-cooking alarm, use the electronic timer function.

Why is my oven not heating properly?

Check that the oven is plugged in and the circuit breaker hasn't tripped. Ensure the correct mode is selected and the temperature is set. If the issue persists, the heating element may be defective; contact service.

How do I clean the oven interior?

Wipe with a damp cloth and mild detergent. For stubborn stains, use a non-abrasive oven cleaner. Avoid using steel wool or harsh chemicals. The door is dishwasher-safe? No, clean manually.

Can I use self-cleaning cycles?

This model does not have a pyrolytic self-cleaning function. Manual cleaning is required. Use the easy-clean enamel surface for easier maintenance.

What is the child lock feature?

The child lock prevents accidental operation. Activate it by pressing and holding the timer button for 3 seconds. The display shows a lock icon. Deactivate the same way.

How do I replace the oven light?

Disconnect the oven from power. Remove the glass cover by turning it counterclockwise. Replace the halogen bulb (25W, G9 base) and refit the cover. Do not touch the bulb with bare hands.

Where can I buy spare parts?

Original spare parts are available through Profilo authorized service centers. Use the model number FRMA234B when ordering. Some parts may be available online.

What should I do if the oven door does not close properly?

Check for obstructions around the door seal. The hinges may need adjusting. If the door is misaligned, contact a technician. Do not force the door.

USER MANUAL FRMA234B Profilo

Blue flag with a circle of twelve yellow stars, representing the European Union (no text or symbols beyond the stars)

PROFiLO
FRMA234B

ENERJİ
