RT21M - Radio MAJESTIC - Free user manual and instructions

Product Type	Radio
Brand	Majestic
Model	RT21M
Dimensions (approx.)	200 x 120 x 60 mm
Weight (approx.)	0.5 kg
Power Source	2x AA batteries (3V DC) or AC adapter (not included)
Tuning Bands	FM / AM
Volume Control	Rotary knob
Headphone Jack	3.5 mm stereo
Speaker	Built-in monaural
Antenna	Telescopic rod for FM, built-in ferrite for AM
Display	Analog tuning dial
Power Indicator	LED on/off
Cleaning	Wipe with a soft, dry cloth
Safety Precautions	Do not expose to water or moisture; keep away from heat sources
Spare Parts / Repairability	Batteries (user-replaceable); other parts serviceable by authorized technicians
Additional Information	User manual available for free download at notice-facile.com

Frequently Asked Questions - RT21M MAJESTIC

How do I power on the Majestic RT21M radio?

Turn the volume knob clockwise until you hear a click. The power indicator LED will light up.

How do I change the batteries?

Open the battery compartment on the back of the radio. Insert two AA batteries following the polarity markings (+/-). Close the compartment securely.

Why is the FM reception weak?

Fully extend the telescopic antenna. Try rotating the radio or moving it near a window. Avoid metal objects that may interfere.

Can I use headphones with this radio?

Yes, plug a 3.5 mm headphone into the headphone jack on the side. The built-in speaker will be muted automatically.

How do I tune to a specific station?

Rotate the tuning knob slowly to select the desired frequency on the analog dial. For FM, use the fine tuning for better clarity.

What should I do if the radio doesn't turn on?

Check that the batteries are installed correctly and have charge. If using an AC adapter, ensure it is properly connected. Try fresh batteries.

Is the radio suitable for outdoor use?

It is not waterproof. Keep it dry and avoid rain or splashes. Use indoors or in a sheltered area.

How do I clean the radio?

Use a soft, dry cloth to wipe the exterior. Do not use liquids or abrasive cleaners.

Can I listen to AM stations?

Yes, switch the band selector to AM. The built-in ferrite antenna does not require extension, but rotating the radio may improve reception.

Where can I find the user manual?

The user manual is available for free download at notice-facile.com. Search for Majestic RT21M.

USER MANUAL RT21M MAJESTIC

Line drawing of a portable radio with a perforated grille, speaker grille, and control buttons (no text or symbols)

New Majestic SpA

Via Rossi Martini, 41

26013 Crème (CR) - Italia

www.newmajestic.com

MADE IN CHINA

To download the instruction manual frame QR code:

DATA PRODUZIONE/PRODUCTION DATE:01/2024

24

NEW MAJESTIC S.p.A.

MOD. RT 21M

INSTRUCTION MANUAL

AM/FM/SW MULTIBAND PORTABLE RADIO CLOCK WITH ALARM

MAJESTIC

Line drawing of a vintage portable radio with a circular vent and control panel (no text or symbols)

New Majestic SpA

Via Rossi Martini, 41

26013 Crème (CR) - Italy

www.newmajestic.com

MADE IN CHINA

We recommend that you carefully read the following instruction manual before using the appliance and keep it for possible future use.

To download the instruction manual frame QR code:

To avoid the danger of electric shock or fire, do not expose to rain or moisture.

IMPORTANT NOTES

- The use must be allowed only to adults and responsible persons, adequately educated on the damages deriving from incorrect use.

- This appliance can be used by children aged 8 and over if they are under supervision or if they have received instructions regarding the safe use of the appliance and if they understand the dangers.

- Cleaning and maintenance operations by the user must not be carried out by children unless they are over 8 years of age and operate under supervision. Keep the appliance and its cord out of the reach of children under the age of 8.

- The devices can be used by people with reduced physical, sensory or mental abilities or with a lack of experience and knowledge if they are supervised or if they have received instructions regarding the safe use of the appliance and understand the dangers involved.

• Children must not use the appliance as a game.

• Do not allow the appliance to be used by children or the disabled without supervision

- Keep away from pets

- Avoid installing the unit in the locations listed below:

Places exposed to direct sunlight or close to equipment that generate heat, such as radiators Above other stereo equipment that may radiate excessive heat Places that block ventilation or are humid or dusty Environments subject to constant vibration

- Do not place accessories with naked flames, such as lighted candles, on the appliance.

- Do not try to repair or intervene on the appliance yourself. Incorrect interventions or tampering can void the guarantee. In the event of any damaged parts or suspected malfunction, discontinue use immediately and consult qualified personnel. Never immerse the appliance in water or other liquids. Do not place items containing liquids (such as vases) on top of the appliance.

- Do not touch the appliance with wet hands and do not place it near sinks, tubs or containers of liquids. Use the product only if it is in perfect condition. If the appliance has been immersed in water or is damaged, contact qualified personnel.

• The product should not be used if it has been dropped or if there are any visible signs of damage.

- Exposure to high volume levels can cause hearing problems, including permanent damage. The predisposition to hearing loss varies from person to person, however constant exposure to high volume levels is harmful to anyone. Moderate the volume level.

- Contact qualified service personnel only, to avoid voiding the warranty. For information and questions, contact the New Majestic S.p.A. technical assistance service.

WARNING: DO NOT SWALLOW BATTERIES. RISK OF CHEMICAL BURNS.

1. READ INSTRUCTIONS - Read all safety and operating instructions before using the appliance.

2. SAVE THE INSTRUCTIONS - Keep the safety and operating instructions for future reference

3. HAZARD WARNINGS - Observe all warnings marked on the device and in the operating instructions.

4. FOLLOW THE INSTRUCTIONS - Scrupulously follow all the operating instructions.

5. WATER AND HUMIDITY - The appliance should not be used near water, for example near a bathtub, washbowl, kitchen sink, swimming pool or in a wet cellar.

6. VENTILATION - The appliance must be positioned so that its position does not interfere with its good ventilation. Do not place the appliance on a bed, sofa, rug, or other similar surface likely to obstruct the ventilation openings in a built-in installation, such as a bookcase or cabinet, which would prevent the passage of air through the cabinets.

7. HEATING - The device should be placed away from heat sources such as radiators, stoves or other devices (including amplifiers) that produce heat.

8. OBJECTS AND PENETRATION OF LIQUIDS - Take care that objects do not fall and that liquids do not enter the enclosure through the openings.

9. DAMAGE REQUIRING REPAIR - The appliance must be repaired by qualified service personnel when: e. The device has been dropped or liquid has been poured into the device.

f. The device has been exposed to rain.
g. The device has been dropped or the packaging is damaged.
h. The device does not seem to be operating normally.

CONTROLS:

1. TELESCOPIC ANTENNA
2. MODE
3. RADIO BAND SWITCH
4. SET
5. LCD DISPLAY
6. TUNING
7. VOLUME
8. POWER ON OFF SWITCH
9. SPEAKER
10. BATTERY COMPARTMENT (BACK SIDE)

Battery installation

1. Slide the latch located on the back of the unit to open the battery compartment door.
2. Insert UM-4 "AAA" batteries and place them according to the polarity diagram in the battery compartment. We recommend using alkaline batteries to get the longest playing time.

Battery precautions

Follow these precautions when using batteries in this device:

1. Use only specified batteries.
2. When installing batteries, follow the polarity diagram indicated in the battery compartment. Incorrect installation of batteries can cause damage to the device.
3. Do not mix different types of batteries together (for example, alkaline with carbon zinc or used batteries with new batteries).
4. If you plan not to use the device for a long period of time, remove the batteries to avoid damage or injury due to possible battery leakage.
5. Do not recharge non-rechargeable batteries. They may overheat or be damaged.

Setting Date and Time

1. Press the MODE button (2) four times to select the month option. Press the SET button (4) several times until the desired month appears on the display.

2. To change the day, press the MODE button (2) once again. Then press the SET button (4) several times to adjust the day number.

3. Press the MODE button (2) again to select the time option. Press the SET button (4) several times until the desired time appears on the display. NOTE: The following time format is shown during adjustment: 1-12 AM / 1-12 PM / 0-24 H.
4. To select the minutes option, press the MODE button (2) again. Then press the SET button (4) several times until the desired minutes appear on the display.
5. To return to normal time display, simply press the MODE button (2) again.

Display operation

When the display shows the time:

1. Press the SET button (4) once to view the alarm time. After approximately three seconds the time will be shown again.
2. Press the SET button (4) twice to display the month and day. After approximately three seconds the time will be shown again.
3. Press the SET button (4) three times to display the seconds. Press the SET button (4) again to return to the time display.

Alarm setting

1. Press the MODE button (2) once to view the flashing alarm time.
2. Press the SET button (4) once to activate the alarm, the sound wave icon will be visible at the top left. Press the SET button (4) again, the bell icon appears in the top right corner and the hourly beep is activated.
3. Press the MODE button (2) again and the time will flash. Then press the SET button (4) several times to select the desired alarm time.
4. Press the MODE button (2) again and the minutes will flash. Press the SET button (4) several times to select the desired minutes for the alarm.
5. Return to normal time display by pressing the MODE button (2) once.

Set alarm display

When the display shows the time, press the SET button (4) once to view the alarm time preset. After approximately three seconds the display will automatically return to normal time.

Alarm with Buzzer

When Buzzer alarm is activated, an acoustic signal is emitted. The alarm will continue for 30 seconds and then turn off automatically. To stop manually, press the MODE button (2) or the SET button (4) once.

Radio

1. Set the ON-OFF switch (8) to "ON" to turn on the radio. Rotate the volume control (6) to adjust the volume. Slide the AM/FM/SW BAND switch (3) to the desired radio band.
2. Rotate the TUNING knob (6) to search for the desired radio station.

Antenna

AM radio has a built-in ferrite antenna and its reception is directional. Therefore, turning the unit may improve reception. The FM radio is equipped with a telescopic antenna on the top of the device (1). Fully extend the antenna to improve reception.

Power supply:

Unit works with 2 x UM-4 "AAA" 1.5 V batteries. When the clock display dims and the flashing battery symbol appears, replace the batteries.

TECHNICAL SPECIFICATIONS

AM/FM/SW1-7 multiband radio

LCD display

Analog tuning with digital frequency display

Clock with alarm

Telescopic antenna

Powered by 2 UM-4 "AAA" batteries (not included)

Unit size: 13 (W) x 8 (H) x 3 (D) cm

Weight: 270gr.

MAJESTIC

Modello: RT 21M

RADIO PORTATILE MULTIBANDA

AM/FM/SW OROLOGIO CON ALLARME

FREQUENZA: AM 526 - 1606 kHz

FM 87.5 - 108 MHz

SW 1-7: 5.9 - 21.85 MHz

DC 3V==(AAA x 2PZ)

Name: Mainstay GDA

New Majestic SPA Via Rossi Martini 4

via Rossi Martin 4 26013 Crema (CP)

www.newmaiestic

Made in China

WEEE Logo (Waste electrical and electronic equipment)

WEEE eco-contribution paid where due - EEE Register No.: IT08020000001647

PILE eco-contribution paid where due - PILE Register No.: IT19070P00005533

GENERAL WARRANTY TERMS FOR THE PRODUCTS OF

New MAJESTIC SpA

Dear Customer, We thank you for your purchase and remind you that the product complies with current construction and safety regulations.

Should anomalies or defects in the product be found, New Majestic SpA offers a conventional warranty subject to the conditions set out here.

(specifying that the conventional guarantee is without prejudice to the consumer's rights referred to in Legislative Decree no. 206 of 06/09/2005).

The Warranty refers exclusively to the free repair or replacement of individual components or the entire product recognized as defective during manufacturing.

The Warranty period will not be renewed or extended following subsequent resale, repair or replacement of the product itself.

Repaired, replaced parts or total exchange of the product will be guaranteed for a period of 60 days starting from the date of repair

or replacement and naturally for the remaining duration of the Guarantee itself.

The Guarantee is valid starting from the date proven by a valid fiscal document (receipt or purchase invoice) for a period

24 months in case of purchase with tax receipt and 12 months in case of purchase with tax invoice (VAT number).

There are goods which due to their normal characteristics are perishable over time or subject to consumption and wear deriving from use, therefore,

for the accessories included in the sales package the Warranty is valid for 12 months.

A rechargeable battery is considered defective and replaceable under the 12-month warranty only when it is interrupted, i.e. it no longer supplies energy and voltage.

its leaders are from Zero Volt. In the event that the capacity to deliver energy is reduced compared to the new product (regarding consumption/wear)

the warranty period will be 6 months.

The following are not covered by the warranty:

- Deterioration due to wear of the aesthetic parts and of all components that may prove defective due to negligence or carelessness in use.

of incorrect maintenance or of circumstances that cannot be traced back to manufacturing defects of the appliance.

- User manuals, third-party software, configurations, applications or data downloaded by the customer.

- Defects caused by improper use of the product (drops, pressure, deformations or use of sharp objects).

- Opening, modification or repair of the product by anyone other than the Authorized Assistance Centre.

- Serial numbers, production date, barcode or IMEI code * that are erased, altered or illegible.

For interventions under warranty please contact one of the Authorized Assistance Centres

of New Majestic SpA, the complete list of which can be consulted on the website www.newmajestic.com, or at the point of sale where the product was purchased,

by delivering the duly completed warranty coupon and attaching the receipt relating to the purchase.

ATTENTION:

It is advisable to keep both the packaging and all the accessories contained therein intact, since in case of sending to the technical laboratory it is better

use the original packaging with all its accessories.

New Majestic SpA

* THE IMEI CODE IS FOR 3G / 4G SMARTPHONES, PHONES & TABLETS

INFORMATION TO USERS OF DOMESTIC EQUIPMENTS

Pursuant to Art. 25, Paragraph 1 of the Legislative Act N. 49 14th March 2014, "Implement of the Directives 2011/65 / EU and 2012/19 / EU concerning the reduction of the use of hazardous substances in electrical and electronic equipment, as well as waste disposal".

The crossed bin symbol on the appliance or on its packaging indicates that the product at the end of its useful life must be collected separately from other waste. The user must, therefore, dispose the equipment at the end of its life to the appropriate electronic and electro technical waste centers, or return it to the retailer at the time of purchase of a new type of equivalent equipment, one by one.

Appropriate separate disposal for the subsequent start-up of the disused equipment for recycling, treatment and compatible environmental disposal helps to avoid possible negative effects on the environment and health and favors the re-use and / or recycling of the materials it is composed the equipment.

The illegal disposal of the product by the user involves the application of the penalties referred to in current laws.

Any rechargeable batteries or rechargeable batteries contained in the device must be disposed separately in the appropriate expired batteries bins.

Any rechargeable batteries or rechargeable batteries contained in the device must be disposed separately in the appropriate expired batteries bins.

Battery disposal

Disposal of expired batteries must take place at the appropriate recycling centers or according to local authority. Batteries in compliance with the 2013/56 / EC directive.
