Product Type	Rear View Backup Camera
Brand	Pyle
Model	PLCM2720
Mount Type	Universal (Front or Rear)
Housing Material	Rugged Metal
Waterproof Rating	IP67 (Marine Grade)
Camera Resolution	656 x 492 pixels (420 TV lines)
Viewing Angle	170 degrees
Minimum Illumination	0.2 Lux
Video Output	1.0Vp-p, 75 Ohm
Power Supply	DC 12V, 200mA
Dimensions (L x W x H)	1.1 x 0.9 x 0.8 inches
Weight	0.5 lbs (0.23 kg)
Built-in Distance Scale Lines	Yes (toggle on/off via black button)
Lens Adjustment	Tilt adjustable
Auto White Balance	Yes
Included DC Power Cable	Yes (with round 1mm plug)
Included RCA Video Cable	Yes, 17 ft (5 m)
Wiring Connection	Hardwire to reverse tail light (Red +12V, Black GND)
Video Connection	Yellow RCA to monitor
Camera Controls	Red button (front/rear image flip), Black button (scale lines on/off)
Recommended Installation	Professional installer
Maintenance	Clean with soft dry cloth; avoid moisture inside connections
Safety	Ensure correct polarity; avoid short circuits

Frequently Asked Questions - PLCM2720 Pyle

How do I install the Pyle PLCM2720 backup camera?

Mount the camera to the license plate bracket. Connect the red power wire to the reverse tail light positive (+12V) and the black wire to ground. Use the included RCA video cable to connect the yellow video output to your monitor. The camera activates automatically when the car is in reverse.

What is the power connection for the camera?

The camera requires DC 12V, 200mA. The red wire (via the round 1mm DC plug) should be connected to the reverse tail light positive. The black wire goes to the nearest ground. The camera only powers on when the reverse gear is engaged.

How do I connect the video cable?

Use the included 17 ft (5m) RCA video cable. Connect the yellow RCA jack from the camera to the yellow video input on your monitor. The cable also carries power through separate wires.

What do the red and black buttons on the camera do?

The red button toggles between front view and back view image orientation. The black button turns the built-in distance scale lines on or off.

Is the camera waterproof?

Yes, the camera has an IP67 marine grade rating, making it waterproof and weather-resistant for outdoor use.

What is the resolution and image quality?

The camera has a resolution of 656 x 492 pixels (420 TV lines) and a 170-degree viewing angle. It performs well in low light down to 0.2 Lux with auto white balance.

What is the viewing angle?

The viewing angle is 170 degrees, providing a wide field of view behind the vehicle.

Can the camera be mounted on the front of the vehicle?

Yes, the camera supports both front and rear mount options. It comes with a universal mount and can be installed in front using the same wiring method.

How long are the included cables?

The included RCA video cable is 17 feet (5 meters) long. The DC power cable is integrated with the camera and has a round 1mm plug.

What should I do if the camera does not display an image?

Check that the red power wire is connected to a 12V source that is live only in reverse. Ensure the black ground is secure. Verify the yellow RCA video cable is properly connected to the monitor. Also check that the monitor is set to the correct video input.

USER MANUAL PLCM2720 Pyle

Metallic cylindrical object with reflective surface and glossy texture, partially collapsed (no text or symbols visible)

PLCM2720

Rear View Backup Camera

USER MANUAL

Please read instructions carefully before installation and use. Installation should be performed by a professional installer.

SPECIFICATIONS

Rear View Backup Camera, Parking Reverse Cam, Front/Rear Mount

Features:

Universal Mount Vehicle Backup Camera Waterproof & Weather-Resistant Marine Grade Camera Construction Built-in Distance Scale Lines Color Picture Output Mount Options: Front or Rear Installation Support Compact, Slim Bar Camera Style Tilt Adjustable Camera Lens Angle Rugged & Durable Metal Housing Includes Installation Cables/Wires Auto White Balance & Image Adjustment

What's in the Box:

Backup Camera DC Power Cable RCA Video Cable, 17' ft.

Technical Specs:

Marine Grade Rating: IP-67 Low Lux Light Performance (0.2 LUX) Video Output: 1.0V PP-75 Ohm Resolution: 656 x 492 Pixels, 420 TV Lines Viewing Angle: 170 Degree Power Supply: DC 12V, 200mA Dimension (L x W x H): 1.1" x 0.9" x 0.8" Weight: 0.5 lbs.

1. WIRE CONNECTION

Please hard wire the red positive wire connected to the round 1 mm DC plug (pictured below) to your reverse tail light positive 12V connection and the black wire to the closest available ground. You will probably need a small length of wire to reach from your reverse tail light to the DC plug.

Close-up of a hand holding a black cable with a metallic connector, partially exposed to a thin wire (no text or symbols visible)

1. Please Attach the camera to your license plate bracket as shown above. You can then run your wires so that they are out of the way.There is one 2 jack on the camera unit cable, the yellow RCA jack is for the video output, and red is for 12V DC power supply, and also there is 2 button, the red button is to control the camera front view or back view picture image, and black button is control the scale line on or off.

Three black cables with red, yellow, and black connectors against a white background (no text or symbols visible)

1. Please plug the round 1 mm DC plug that you just wired to your reverse tail light into the red (A) power connection (image on page 2)
2. Use the included 5m video cable to connect the yellow video wire (B) to your video monitor.

Monitor

Backup Light Power
Red: +12V (in)
Black: GND (in)

Attention:

The camera switch is controlled by the reverse gear shift. When you put your car in reverse, the camera will receive its 12 V power from the reverse tail light.

Illustration of a laptop with a red checkmark on screen, next to vertical text 'V H N W' (no other symbols or text)

VISIT US ONLINE:

Have a question?

Need service or repair?

Want to leave a comment?

PyleUSA.com/ContactUs
