3800gHD - Barcode Reader HONEYWELL - Free user manual and instructions

Product Type	Barcode Reader
Brand	Honeywell
Model	3800gHD
Scan Technology	Linear Imager
Scan Rate	270 scans per second
Decode Capability	High Density (3 mil minimum element width)
Interface	USB, RS232
Dimensions (H x W x D)	11.5 cm x 7.1 cm x 4.8 cm
Weight	156 g
Power Source	Host powered via USB or external power supply (5V DC)
Operating Temperature	0°C to 50°C
Humidity	5% to 95% non-condensing
Drop Specification	1.5 m drops to concrete
Maintenance & Cleaning	Clean lens with a soft, dry cloth. Avoid solvents.
Safety	Class 1 LED, safe for eyes.
Spare Parts & Repairability	Replacement cables and power supplies available. Contact Honeywell support for repairs.
Warranty	1 year limited warranty

Frequently Asked Questions - 3800gHD HONEYWELL

How do I connect the 3800gHD to my computer?

Connect the interface cable to the scanner and your computer. The scanner is plug-and-play for most systems. Install the Honeywell Scan Configuration software for advanced settings.

The scanner is not reading barcodes. What should I do?

Ensure the barcode is clean and well-lit. Try scanning a different barcode. If it still fails, perform a factory reset by scanning the reset barcode in the manual. Also check cable connections.

Can I use this scanner with a smartphone?

The 3800gHD is primarily designed for computers via USB or RS232. To use with a smartphone, you may need an OTG adapter and compatible scanning app, but full functionality is not guaranteed.

What barcode types does it support?

It supports most 1D barcodes including Code 39, Code 128, EAN-13, UPC-A, Interleaved 2 of 5, and many more. Refer to the specifications for the full list.

How do I clean the scanner lens?

Use a soft, lint-free cloth slightly dampened with water or a mild lens cleaner. Do not use abrasive cleaners or solvents. Dry the lens before scanning.

What does the 'High Density' (HD) model mean?

The HD model is optimized for reading very small or dense barcodes (as low as 3 mil). It has a narrower scan angle and better resolution for high-density codes.

How do I change the interface settings (USB vs RS232)?

Use the configuration barcodes from the user manual to switch between interfaces. Alternatively, use the Honeywell Scan Configuration software to set the interface.

Is the scanner compatible with Mac computers?

Yes, it works with Mac via USB HID mode. No additional drivers are needed. It will appear as a keyboard, and scanned data will be typed into the active window.

What is the maximum scan distance?

The typical reading distance is 0 to 30 cm for high-density barcodes, and up to 50 cm for standard barcodes. Exact range depends on barcode size and quality.

Where can I find the user manual?

The user manual is available for free download on notice-facile.com or the official Honeywell support website. It contains setup instructions, troubleshooting, and configuration barcodes.

USER MANUAL 3800gHD HONEYWELL

Speichern

Manueller Trigger (Standard)

Bedarfsmodus

Suffix entfernen

Speichern

Programmiertabelle

Visual Menu

Honeywell International Inc. ("Honeywell") warrants its products to be free from defects in materials and workmanship and to conform to Honeywell's published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any Honeywell product which is (i) improperly installed or used; (ii) damaged by accident or negligence, including failure to follow the proper maintenance, service, and cleaning schedule; or (iii) damaged as a result of (A) modification or alteration by the purchaser or other party, (B) excessive voltage or current supplied to or drawn from the interface connections, (C) static electricity or electrostatic discharge, (D) operation under conditions beyond the specified operating parameters, or (E) repair or service of the product by anyone other than Honeywell or its authorized representatives.

This warranty shall extend from the time of shipment for the duration published by Honeywell for the product at the time of purchase ("Warranty Period"). Any defective product must be returned (at purchaser's expense) during the Warranty Period to Honeywell factory or authorized service center for inspection. No product will be accepted by Honeywell without a Return Materials Authorization, which may be obtained by contacting Honeywell. In the event that the product is returned to Honeywell or its authorized service center within the Warranty Period and Honeywell determines to its satisfaction that the product is defective due to defects in materials or workmanship, Honeywell, at its sole option, will either repair or replace the product without charge, except for return shipping to Honeywell.

EXCEPT AS MAY BE OTHERWISE PROVIDED BY APPLICABLE LAW, THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER COVENANTS OR WARRANTIES, EITHER EXPRESSED OR IMPLIED, ORAL OR WRITTEN, INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

HONEYWELL'S RESPONSIBILITY AND PURCHASER'S EXCLUSIVE REMEDY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT WITH NEW OR REFURBISHED PARTS. IN NO EVENT SHALL HONEYWELL BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, AND, IN NO EVENT, SHALL ANY LIABILITY OF HONEYWELL ARISING IN CONNECTION WITH ANY PRODUCT SOLD HEREUNDER (WHETHER SUCH LIABILITY ARISES FROM A CLAIM BASED ON CONTRACT, WARRANTY, TORT, OR OTHERWISE) EXCEED THE ACTUAL AMOUNT PAID TO HONEYWELL FOR THE PRODUCT. THESE

LIMITATIONS ON LIABILITY SHALL REMAIN IN FULL FORCE AND EFFECT EVEN WHEN HONEYWELL MAY HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH INJURIES, LOSSES, OR DAMAGES. SOME STATES, PROVINCES, OR COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.

All provisions of this Limited Warranty are separate and severable, which means that if any provision is held invalid and unenforceable, such determination shall not affect the validity of enforceability of the other provisions hereof. Use of any peripherals not manufactured/sold by Honeywell may result in damage not covered by this warranty. This includes but is not limited to: cables, power supplies, cradles, and docking stations. Honeywell International Inc. extends these warranties only to the first end-users of the products. These warranties are non-transferable.

The duration of the limited warranty for the 3800, 3800g, 3800gHD, 3800gPDF is five (5) years.

The duration of the limited warranty for the 3800i is three (3) years.

Disclaimer

Honeywell International Inc. (“Honeywell”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Honeywell to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Honeywell.

Honeywell shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Honeywell.

©2006-2008 Honeywell International Inc. All rights reserved.

Web Address: www.honeywell.com/aidc

Honeywell

700 Visions Drive

P.O. Box 208

Skaneateles Falls, NY 13153-0208
