Product Type	Refrigerator
Brand	Scancool
Model	DKS 123 BE
Height	85 cm
Width	60 cm
Depth	60 cm
Weight	30 kg
Power Supply	220-240 V, 50 Hz
Power Consumption	100 W (approx.)
Energy Class	A (typical)
Refrigerant	R600a
Noise Level	40 dB (approx.)
Capacity	100 L (approx.)
Climate Class	N/ST
Temperature Range	0°C to 8°C
Defrosting	Manual
Interior Light	Yes, LED
Adjustable Thermostat	Yes
Reversible Door	Yes
Shelves	3 adjustable glass shelves
Door Storage	2 door bins
Vegetable Crisper	1 drawer

Frequently Asked Questions - DKS 123 BE Scancool

How do I adjust the temperature on my Scancool DKS 123 BE?

Use the thermostat dial inside the fridge compartment. Turn it clockwise for colder, counterclockwise for warmer. Wait a few hours for the temperature to stabilize. The recommended setting is mid-way.

Why is my fridge making a clicking noise?

Clicking sounds are normal and come from the compressor turning on and off. If the noise is loud or continuous, check if the fridge is level and not touching walls or cabinets.

How often should I defrost my Scancool DKS 123 BE?

Defrost the freezer compartment when frost reaches about 5 mm (0.2 inches) thickness. For the fridge section, no defrosting is needed as it is automatic.

Can I reverse the door opening direction?

Yes, the door is reversible. Consult the manual for detailed steps. You'll need a screwdriver and possibly an assistant to hold the door.

What is the correct way to clean the fridge?

Unplug the appliance. Remove all food and shelves. Clean the interior with a mild detergent and warm water. Rinse and dry thoroughly. Do not use abrasive cleaners.

Why is there water pooling inside the fridge?

This may be due to a blocked defrost drain. Clean the drain hole using a pipe cleaner or cotton swab. Ensure the drain is not obstructed by food items.

How can I save energy with my refrigerator?

Keep the fridge away from heat sources and direct sunlight. Ensure door seals are clean and tight. Let hot food cool before placing inside. Open the door as briefly as possible.

My fridge is not cooling enough. What should I do?

Check the thermostat setting. Ensure the condenser coils at the back are clean. Verify that the door closes properly. If the problem persists, contact a technician.

Can I store vegetables in the door bins?

It's better to store vegetables in the crisper drawer where humidity is controlled. Door bins are best for bottles, jars, and condiments.

How do I change the interior light bulb?

Unplug the fridge. Remove the light cover (usually snaps off). Replace with a LED bulb of the same type and wattage (typically 10W max). Reattach cover and plug in.

USER MANUAL DKS 123 BE Scancool

Original user manual

Line drawing of a person working at a desk with equipment, no text or symbols present

F∅R DU BRUGER APPARATET F∅RSTE GANG

Refrigerator

Thank you for buying this Refrigerator. It has been designed and manufactured for many years of trouble-free service.

Operation is very simple, but please take a few minutes to read this booklet.

It contains important safety information, and tips to ensure you receive the best possible service from your Refrigerator.

This appliance is intended to be used exclusively for the storage of beverages.

WARNING:

RISK OF ELECTRICAL SHOCK HAZARD

USERS IN EUROPE This unit must be earthed and plugged into a grounded 220V AC circuit. If the power cable is damaged, it must be replaced by a qualified engineer to avoid shock hazard.

DO NOT ATTEMPT TO REPAIR THE ITEM YOURSELF.

Ensure that the appliance is properly grounded.

Stop using the appliance immediately if electric shock is felt when touching the cooler.

DISPOSAL OF OLD REFRIGERATORS

BE SURE TO MAKE ANY LOCKS UNUSABLE. IF POSSIBLE, REMOVE THE DOOR(S) AND DISCARD SEPARATELY.

WARNING – CHEMICAL HAZARD: DO NOT ALLOW CHILDREN TO PLAY WITH THE OLD APPLIANCE. CONTACT YOUR LOCAL AUTHORITY FOR PROPER DISPOSAL PROCEDURES.

Before disposing of an old appliance, please make sure it is switched off and safe. Unplug the appliance and break any locks in order to avoid children becoming trapped.

Please note: the cooling system contains flammable gases and refrigerants which require specialist waste disposal. The materials contained in a refrigerator must be recycled.

Contact your local waste disposal depot for proper disposal of an old appliance and contact your local authority or dealer if you have any questions. Please ensure the pipework of your cooler is not damaged prior to disposal.

DISPOSAL OF PACKAGING

All the packaging materials with your Refrigerator may be disposed of without danger to the environment.

The cardboard may be broken or cut into smaller pieces and given to a waste paper disposal service. The wrapping is made of polyethylene. The polyethylene pads and stuffing contain no fluorochloric hydrocarbons.

All these valuable materials should be taken to a waste collecting depot and used again after adequate recycling.

Consult your local authority for the name and address of the waste paper disposal services nearest to you.

SAFETY INSTRUCTION & WARNINGS

Before switching on your Refrigerator, read the information in this User Guide carefully. The User Guide contains important observations relating to the assembly, operation and maintenance of the appliance.

Please keep this booklet in a safe place for future reference. If you ever sell this unit, hand this User Guide to the new owner.

The manufacturer does not accept responsibility for any damages that may arise due to non-observation of these instructions.

• Do not use damaged appliances. If you are in any doubt, consult the supplier.
• Connection and installation of the unit is to be carried out in strict compliance with the relevant instructions in this User Guide.
• For safety, the appliance must be properly earthed in accordance with the specifications.
• Always remember to unplug the appliance before cleaning. Never unplug your cooler by pulling on the power cable. Always grip the plug firmly and pull straight out from the socket.
• All electrical repairs must be carried out by qualified engineers. Inadequate repairs may be dangerous.
• Do not damage any parts of the appliance which carry refrigerant by piercing, perforating, crushing, twisting or scraping. If the refrigerant comes into contact with the eyes, it may cause serious eye injury.
• Do not obstruct or cover the ventilation aperture.
• Do not allow children to play with your Refrigerator, or to sit on it or swing from the door.
• This appliance is not intended for used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

SPECIFICATIONS

• Th is appliance is designed as a beverage cooler.
• It is intended strictly for domestic use.
  • The refrigerating circuit is leak-proof.

Line drawing of a room interior with furniture and a circular object (no text or symbols)

BEFORE USING FOR THE FIRST TIME

- The appliance may be placed with its rear panel directly against the wall. The minimum air gap must be 2 centimeter.

For good circulation, the vent at the back of the unit must not be blocked. Your Refrigerator should be placed on flat and firm surface for quieter operation.

• Do not expose the appliance to direct sunlight or a heat source such as ovens, radiators, heaters, etc.
• Do not under any circumstances place heated beverages in your Refrigerator.
• Do not open the door more often than necessary to lessen the escape

of cold air.

• For better air circulation, do not overfill the unit.
• Adjust the temperature regulator according to the amount of product and the ambient temperature.
• Turing it to maximum will cause it to run continuously and ice up. Avoid the maximum setting.

BASIC OPERATION

Your Refrigerator must stand on an even surface.

If the appliance is to be placed on carpet, support it with a wooden board underneath. Be aware that placing the appliance on carpet may mean that heat from the compressor may cause the carpet to fade.

To operate

1 Pl ug in your Refrigerator.
2 The first time you turn the unit on, turn the thermostat, situated at the back of the unit, clockwise to the max. position "SUPER".

It can make your Refrigerator cool faster.

3 After 20 minutes, adjust the temperature control setting to "NORMAL". This setting should be correct for home or office use.
4 To turn the unit off, disconnect the plug from the mains supply.

NOTE: If the unit is unplugged or power lost, you must wait 3 to 5 minutes before restarting. If you attempt to restart the unit before this delay, the unit will not start.

WARNING

If temperature selector is set to too low a setting, drinks may become frozen. In extreme circumstances, glass bottles may even break. Always exercise caution when setting the temperature.

• Do not place heavy items (more than 20kg/44lbs) on top of the cooler.
• Do not place any items on top of the cooler which may fall off when the door is opened.
  • After the appliance has been unplugged, leave for three minutes before plugging it in again.

When not in use

If the unit is not being used for long periods:

• Unplug your Refrigerator.
- Clean and dry the inside of the appliance. Leave the door slightly open to allow it to dry completely.
- A cooler which is unused without being cleaned may start to smell musty or develop mildew.

DEFROSTING

The surface of the evaporator ices up when the refrigerator is working. This is an entirely normal part of operation. If the frost layer is more than 3mm / ^1/8 thick, the cooler must be defrosted and cleaned to avoid unnecessary energy consumption and inefficientoperation.

1 Remove all items inside and unplug the unit.
2 After defrosting, clean the unit (see instructions below) and allow it to

dry. Reconnect to the mains supply with the temperature control at "MAX", then follow the directions 'To operate' and 'Tips for refrigeration' opposite).

Cleaning

• Unplug your Refrigerator.
• Sponge the interior with warm water and neutral detergent.
• Dry all surfaces thoroughly.

Note: Do not use abrasive cleaners! Do not use sharp objects!

To ensure efficient operation the back and bottom of the cooler should be cleaned thoroughly. Use mild soapy water to clean the door seal.

Moving your Refrigerator

• Unp lug the appliance
• Remove all items inside

Note: Never hold the appliance by the door.

- Keep level and upright.

Power Failure

If a power cut occurs, do not open the door more often than necessary in order to conserve cold air.

TROUBLE SHOOTING

Before returning your Refrigerator to the store, check the following points; you may be able to solve any problem yourself.

Not cooling

• Chec k power cable is connected and fuse is intact.

• Wrong temperature selected.

• Adjust setting on controller to position shown

• Cooler is overfilled.
• Appliance exposed to direct sunlight or a heat source.
• Door is opened too often.
• The frost layer is too thick.
• Needs to be defrosted

Unusual noises or noisy operation

• App liance is not on a level, firm surface or may be touching other items.
  Note: It is normal to hear refrigerant flowing as the compressor stops and starts.

Outer surfaces are wet

- Water source or leak too near the appliance – dry surfaces thoroughly and move the appliance.

Inner surfaces are wet

- Door opened too often or kept open too often.

LED

• Lam p type: LED-light.
  • Energy efficiency level: G
• Light source in this product is replaceable only by a professional
