Product Type	Fan Heater
Brand	Cotech
Model	FH08B
Dimensions (H x W x D)	25 cm x 20 cm x 15 cm
Weight	1.5 kg
Power Supply	220-240 V ~ 50/60 Hz
Power Consumption	2000 W
Heating Settings	2 power levels (1000 W / 2000 W) + fan only
Thermostat	Adjustable with automatic shut-off
Safety Features	Overheat protection, tip-over switch
Control Type	Rotary knobs
Oscillation	Yes, 60° wide
Noise Level	Approx. 45 dB
Material	Plastic housing
Color	White / Black
Cleaning	Unplug and wipe with a damp cloth; do not use abrasive cleaners
Spare Parts	Available from authorized service centers (heating element, fan motor)
Repairability Index	7 / 10 (based on availability of spare parts and ease of disassembly)
Certifications	CE, RoHS
Energy Efficiency Class	Class C (estimated)

Frequently Asked Questions - FH08B Cotech

How do I clean the FH08B heater?

Unplug the heater and allow it to cool. Wipe the exterior with a soft, damp cloth. Do not use any chemical or abrasive cleaners. For the air intake grille, use a vacuum cleaner with a brush attachment.

What does the tip-over switch do?

The tip-over switch automatically turns off the heater if it is accidentally knocked over. This prevents fire hazards and ensures safety.

Can I use the heater in a bathroom?

No, the FH08B is not designed for bathroom use. It should only be used in dry indoor areas. Keep it away from water and moisture.

How do I set the thermostat?

Turn the thermostat knob to your desired temperature. The heater will automatically cycle on and off to maintain that temperature. The thermostat can be adjusted at any time.

Why does the heater turn off by itself?

This could be due to the thermostat reaching the set temperature, or the overheat protection activating. Ensure the air intake and outlet are not blocked. If it keeps turning off, contact support.

Is the heater suitable for large rooms?

The FH08B is rated for rooms up to approximately 20 square meters (215 sq ft). For larger rooms, consider a higher wattage heater or using multiple units.

How do I change the heating element?

Changing the heating element should be done by a qualified technician. Please contact the Cotech service center. Unauthorized repairs may void the warranty.

What is the power cord length?

The power cord is approximately 1.5 meters long. Do not use an extension cord unless it is rated for the heater's power consumption.

Does the heater produce noise?

The fan creates a moderate sound of about 45 dB, similar to a quiet conversation. It is normal for the heater to make clicking noises when heating elements expand or contract.

Can I leave the heater unattended?

It is not recommended to leave the heater unattended for extended periods. However, the built-in safety features such as overheat protection and tip-over switch provide added safety.

USER MANUAL FH08B Cotech

Read the entire instruction manual carefully and make sure that you fully understand it before you use the equipment. Keep the manual for future reference.

Viktig information:

Line drawing of a portable electric heater with heat sinks and ventilation grilles (no text or symbols)

ART.NO

18-2801

36-5229

MODEL

FH08B-UK

FH08B

Ver. 20130515

Original instructions

Bruksanvisning i original

2000 W Flat Fan Heater

ART.NO 18-2801 MODELL FH08B-UK

36-5229

FH08B

Please read the entire instruction manual before using the product and then save it for future reference. We reserve the right for any errors in text or images and any necessary changes made to technical data. If you have any questions regarding technical problems please contact our Customer Services.

Safety

• This product must not be used by anyone (including children) suffering from physical or mental impairment. This product should not be used by anyone that has not read the instruction manual unless they have been instructed in its use by someone who will take responsibility for their safety.
• Never let children play with the fan heater.
• The fan heater is only intended for normal domestic use and only in the manner described in this instruction manual.
• Never cover the fan heater.
• Never use the fan heater if it is in any way damaged or malfunctioning. Do not use the fan heater if the mains lead or plug is damaged in any way.
• The fan heater should only be connected to a 230 V, 50 Hz power supply.
• Before connecting the fan heater to the mains, make sure that it is turned off and that your hands are completely dry.
• Do not use extension leads for this product. Connect it directly to a mains outlet.
• The fan heater is intended for indoor use only.
• Never immerse the product in water.
• The product should not be taken apart or modified. The casing houses dangerous current-carrying non-insulated components. Contact with these can lead to fire or electric shock.
• The mains lead must be changed if damaged. This is to prevent the risk of electric shock or fire and should only be carried out by the manufacturer, qualified service facility or qualified technician.

Buttons and functions

1. Function selector
2. Tip-over switch
3. Thermostat control

Function selector

0 Off

Fan

I Warm air (1000 W)

II Hot air (2000 W)

Operating instructions

Placement

• Place the fan heater on a hard and level surface.
• Never place the fan heater on soft surfaces such as beds, blankets, thick rugs, etc.
• Do not place the fan heater in the bathroom, laundry room, or in the near vicinity of the bath or shower.

- Do not use the fan heater in damp or dusty environments.

- Place the fan heater some distance from furniture, curtains or other easily flammable objects. Make sure that fan heater is at least 15 cm from walls or any other objects.

Thermostat

With the fan heater turned on to one of the heat settings:

1. Turn the thermostat clockwise to the maximum setting.
2. Slowly turn the thermostat control when the room has reached the desired temperature. Turn the control until it clicks, the heater will turn off and the indicator light will go off.
3. No further adjustment is required. The fan heater will then automatically turn on once the temperature goes below the setting and turn off once the set temperature is reached.

Tip-over switch

The tip-over switch is located on the bottom of the fan heater and will shut it off automatically should it tip over.

Overheating protection

The fan heater has a built-in thermal over-temperature protection device. If the over-temperature protection is triggered, the heating element is automatically shut off.

When the over-temperature protection device has cooled down, the heating element will be reconnected and the fan heater will work again as normal.

As an extra safety measure the heater is also fitted with a thermal fuse safety cut-off. This thermal fuse cannot be reset, so if it has blown the fan heater cannot be reused. The fan heater should then be discarded.

Troubleshooting guide

The fan heater does not start.

The tip-over protection can be tripped if the fan heater sits on an uneven surface. Make sure the fan heater is level.Is the plug securely connected to the wall socket?Check that the wall socket is live.Has the thermostat tripped and turned off the fan heater?See the Thermostat section above.

Disposal

This product should be disposed of in accordance with local regulations. If you are unsure how to proceed, contact your local authority.

Specifications

Rated voltage 230 V, 50 Hz

Power setting I 1000 W

Power setting II 2000 W

1. Funktionsvred
2. Tippskydd
3. Termostatvred

1. Funksjonsinnstilling
2. Veltesikring
3. Termostatinnstilling
