USER MANUAL Relief 4010 OBH NORDICA

DESIGNING GOOD LIFE

Heating Pad

RELIEF

Keep warm with style

Black-and-white photo of a medical pressure monitor resting on a rolled-up medical tube, with a small bottle and straw in the background (no text or symbols visible)

Feeling good!

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 4010

OBH Nordica Norway AS

Postboks 5334 Majorstuen

0304 Oslo

Tlf: 22 96 39 30

www.obhnordica.no

Tekniske data

OBH Nordica 4010

1. Read the instruction manual carefully before use and save it for future use.
2. Plug the heating pad to a household outlet of 220-240 volt AC only and use the heating pad only for the intended use.
3. Always unplug the appliance from the mains supply after use.
4. Never immerse the appliance and the cord in water or any other liquid.
5. This appliance can be used by children aged 8 years and over and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way by a person responsible for their safety and they understand the hazards involved.
6. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
7. Cleaning and maintenance shall not be made by children, unless they are over the age of 8 and supervised.

8. Never place objects such as e.g. water bottles or pillows on the heating pad.

9. NEVER sleep with the heating pad on. Never leave the heating pad out of sight and always unplug the heating pad if you leave the room.

10. The heating pad must never be used by babies, handicapped persons or persons who have an insensitivity to heat.

11. Use over a long period of time at high temperature may cause a risk of skin burns.

12. When the heating pad is not in use, put it back in the original packaging and store it at a dry place.
13. Never pull the cord and do not carry the heating pad in the cord.

14. Do not wind up the cord and do not position it on the heating pad.

15. Do not use the heating pad if rolled up or folded.

16. Take care not to make any sharp wrinkles in the heating pad by positioning anything on top of it when not in use, as this may destroy the safety system of the heating pad.

17. Never put needles or sharp objects into the heating pad.

18. Check at regular intervals the surface of the heating pad for possible signs of wear and tear or dark spots. In case of wear and tear, damages or spots, do not use the heating pad. It should be discarded or handed over to a service agent for repair.

19. No matter how often the heating pad has been used, it should be discarded after 10 years from date of purchase for safety reasons and due to normal wear and tear.

20. Never immerse the on/off button and the cord in water or any other liquid.

21. Never use the heating pad in wet rooms.

22. Clean the heating pad in accordance with the instructions given in the manual.

23. Never use the heating pad if humid or wet. Always wait until the heating pad is absolutely dry.

24. Unplug from the power supply, if:

25. the heating pad gets disagreeably warm, even though the temperature is at a low level

26. the heating pad gets so warm that certain areas are discoloured
27. you hear crackling from the switch or you can see visible damage to the switch, the heating pad or the cord

28. the heating pad has not become warm after 10 minutes at maximum temperature level. First, try to plug the switch to another wall outlet.

29. The heating pad is for domestic use only.

30. The heating pad is not made for medical professional use or any other health care use. This means that it should not be used for treatment, alleviation or prevention of diseases, syndromes or other handicaps

31. medical treatment in hospitals, care homes or other institutions

32. medical treatment in the field of professional and commercial care.

33. Because of the consequential risk of personal injury, it is strictly forbidden under any circumstances to try to separate or repair the heating pad personally. Without specialist tools is it not possible to guarantee the safety of the product during use.

34. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer or his service agent or a similarly qualified person in order to avoid a hazard.

35. For additional protection the installation of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA is recommended. Ask your installer for advice.
36. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages of the product or other things are not covered by the warranty.

This product comprises a safety system that will cut off the power supply within milliseconds in case of a short circuit or an abnormally high power consumption. In such case it is not possible, for safety reasons, to use the heating pad. Consequently, the heating pad should be discarded, see more in section “Disposal of the appliance”.

How to use the appliance

Check that the on/off button is off (0). Connect the plug of the appliance to a wall outlet. Sit or lie down comfortably with the heating pad as you want it and keep the switch within reach. You can also fasten the heating pad by means of the Velcro straps on the underside of the heating pad. Make sure that the cord between the heating pad and the on/off button has not been folded or rolled up. The on/off button gets hot during use, which is quite normal. Consequently, never cover the on/off button and do not leave it on the heating pad during use. Switch on the heating pad by selecting one of the following settings (the signal lamp goes on):

0 - Turned off
1 - Low temperature
2 - Medium temperature
3 - High temperature

We recommend that you already at the beginning set the on/off button at setting 3 (high temperature) and lower the temperature as you find it necessary. Switch off the heating pad by pushing the on/off button to 0. Always unplug after use.

Warning! The heating pad should not be used by small children, unless the on/off button has been set by a grown-up or if the child has been thoroughly instructed in the use of the on/off button. Never let children use the heating pad without supervision. Children are not always able to understand potential risks. Teach children a responsible handling of the heating pad.

Automatic switch-off

The heating pad switches off automatically, when it has been activated continuously for about 90 minutes ( ± 10 min.). The signal lamp of the chosen temperature is flashing to indicate that the heating pad has been switched off automatically. In order to restart the heating pad, push the on/off button to 0 and choose the optional setting.

Note!

If you use the heating pad continuously for a long period of time, this might cause skin burns that will show at a later stage. Therefore, never use the heating pad for more than 90 minutes without a pause!

Cleaning and maintenance

Unplug from the wall outlet and let the heating pad cool for at least 10 minutes before cleaning.

Always dismantle the removable switch and the cord before cleaning. To do so, press the buttons at both sides of the coupling at the underside of the heating pad and unplug at the same time. You can hand wash the heating pad or put it in a washing machine (“sensitive” programme) at 40^ C. The heating pad should only be washed if very dirty and not more than 2-3 times a year as all washing will wear out the product. Stains and dirt can be removed by using a humid sponge and a little mild detergent. Note that the heating pad must not be dry-cleaned.

IMPORTANT!

Make sure that the switch of the cord does not get in contact with water or any other liquid.

If you hand wash the heating pad, press the heating pad carefully into the water with a little washing powder to remove the spots. Next, rinse the heating pad in clean water to remove all washing powder.

Let the heating pad drip dry after washing. Never twist the heating pad or use a tumble dryer. Never mangle or iron the heating pad. Never - under any circumstances - switch on the heating pad in order to dry it. Position the heating pad on a stable surface for drying. Do not fasten it by means of clothes-pegs or similar. Do not use the heating pad until it has dried completely. If not, the safety system will be activated and the heating pad will be switched off.

After cleaning and prior to the following use, always check the heating pad in order to locate any possible damages/wear.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment shall be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Warranty

Warranty according to current law. Any claim shall be accompanied by the cash receipt with purchase date. When raising a claim the appliance must be returned to the store of purchase.

OBH Nordica AB

Löfströms Allé 5

SE-174 66 Sundbyberg

Tel.: [phone]

www.obhnordica.se

Technical data

OBH Nordica 4010

220-240 volt AC

100 watt

3 heat settings.

Washable (sensitive programme 40°C)

Automatic switch-off after 90 min. (±10 min).

These instructions are subject to alterations or improvements.

Top-down view of a rectangular medical or surgical device with ribbed internal structure and a small circular opening (no text or symbols visible)

SE/CS/4010/UVN/190614
