100357 - Smoke detector AVIDSEN - Free user manual and instructions

Product Type	Smoke Detector
Brand	Avidsen
Model	100357
Sensor Type	Photoelectric
Power Source	9V DC battery (included)
Battery Life	Approximately 1 year
Dimensions	100 mm diameter x 40 mm height
Weight	150 g (including battery)
Mounting Type	Ceiling mount
Operating Temperature	0°C to 40°C
Humidity Range	10% to 90% non-condensing
Alarm Volume	≥ 85 dB at 3 meters
Test Button	Yes
Low Battery Indicator	Chirping sound every 30-40 seconds
Compliance Standards	EN 14604, CE
Maintenance	Vacuum clean monthly; replace battery annually
Replaceable Battery	Yes (standard 9V)
Installation	Quick mount with screws and anchors included
Warranty	2 years
Color	White

Frequently Asked Questions - 100357 AVIDSEN

Where is the best location to install the smoke detector?

Install on the ceiling at least 30 cm from walls and corners. Avoid kitchens and bathrooms to prevent false alarms.

How do I test if the detector is working?

Press and hold the Test button until the alarm sounds (3-5 seconds). Release to silence. Test weekly.

What does a chirping sound mean?

A chirp every 30-40 seconds indicates a low battery. Replace the 9V battery immediately.

How often should I replace the battery?

Replace the battery at least once a year, or when the low battery chirp occurs. Use a fresh 9V alkaline battery.

Can I install this detector in a mobile home?

Yes, it is suitable for mobile homes. Ensure proper mounting on the ceiling and avoid areas with extreme temperatures.

What causes false alarms and how to prevent them?

Steam, cooking fumes, or dust can trigger false alarms. Install away from kitchens and bathrooms. Clean monthly with a vacuum.

How do I clean the smoke detector?

Use a soft brush or vacuum cleaner on low suction to gently remove dust from the vents. Do not use water or chemicals.

What should I do if the alarm sounds continuously?

Evacuate immediately. If it's a false alarm, press the test/hush button to silence for 10 minutes. Identify the source.

Does this detector have a hush feature?

Yes, press the Test/Hush button to temporarily silence nuisance alarms for about 10 minutes. The detector will automatically reset.

How long is the warranty and how to claim?

The device comes with a 2-year warranty against manufacturing defects. Contact Avidsen support with proof of purchase.

USER MANUAL 100357 AVIDSEN

Architectural diagram of a multi-level building with staircases and wall-mounted sensors (no text or labels)

industrial data above the price of 100,000.

SI "alerte smart in the source says that be relevant, Optable

hall event attendance to gather a league et les chambers. Vote

SI Implementation is possible

al Habitation a un stage

Figure 8

one personne. ou have you able to sell and assess pressure your level

Illustration of hands using a tool to adjust or install a component (no text or symbols visible)

(1) 2017年1月1日
