BRUKSANVISNING MC-E654 PANASONIC

10) CARE OF FILTER

Technical diagram showing vehicle components with labels and annotations in Chinese

To protect the motor, a filter is installed in the dust bag compartment. One or twice a year, when the filter gets obviously dirty, it should be cleaned, as follows:
1) Remove filter by holding top part and pulling up (as illustrated).
2) Wash filter in lukewarm water and dry completely, in the shade.

Important: Do no forget to re-install the filter.

11) ACCESSORY (OPTIONAL)

Cloth dust bag.

12) ACCESSORY TRAY (MC-E652, MC-E653, MC-E654, MC-E655, Only).

Line drawing of a car with a hand holding a sheet of paper, showing internal components (no text or symbols)

19) CAUTIONS
1) Never let the cleaner pick up wet dirt, mud, or burning tobacco ashes.

2) Before using the cleaner, remove large or sharp objects from the floor or carpet.

3) Keep the cleaner away from heat sources such as radiator, oven, etc.

4) Refrain from pulling the cord too strongly. Unplug by pulling the plug, not the cord.

Illustration of a portable vehicle with a plug and no visible text or symbols

Operating Instructions

Panasonic

Vacuum Cleaner

MC-E650, MC-E651, MC-E652, MC-E653

MC-E654, MC-E655

Silhouette of a vintage propeller airplane (no text or symbols visible)

Before operating this vacuum cleaner, please read these instructions carefully.
This appliance was produced to BS 800: 1983.

FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY

-2.18

This appliance is supplied with a moulded three-pin mains plug for your safety and convenience. A 13 amp fuse is fitted in this plug.

Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 13 amps and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark or the BSI mark on the body of the fuse.

If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is replaced.

If you lose the fuse cover the plug must not be used until a replacement cover is obtained.

IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFC AND DISPOSED OF SAFELY.

THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO ANY 13 APM SOCKET. If a new plug is to be fitted please observe the wiring code as shown below. If in any doubt please consult a qualified electrician

IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:

Blue: Neutral

As the colours of the wire in the maine lead of this appliance may not, correspondence with the coloured markings identifying the terminals in your plug, proceed as follows.

The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with the letter L or coloured RED.

Under no circumstances should either of these wires be connected to the earth terminals of the three pin plug, marked with the letter E or the Earth Symbol.

How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse and fuse cover

Fuse Cover Part N.* AMCBGDM8C0000

Panasonic España, S.A.

DIVISION DE ASPIRADORAS

Zona Industrial del Poligono de CELRA 17480 CELRA (Girona-Spain)

207C6190
