VC608 - Aspirateur Khind - Notice d'utilisation et mode d'emploi gratuit

Type	Aspirateur sans sac à cyclone
Marque	Khind
Modèle	VC608
Usage	Intérieur, surfaces sèches uniquement
Alimentation	Secteur (cordon électrique)
Longueur du cordon	Repère jaune pour longueur idéale, ne pas dépasser le repère rouge
Système de filtration	Cyclone double, filtre HEPA centric, filtre de sortie d'air
Contrôle	Bouton marche/arrêt et réglage de vitesse
Rembobinage du cordon	Bouton de rembobinage avec guidage manuel
Accessoires inclus	Flexible d'aspiration, tube télescopique, brosse sol
Réservoir	Transparent
Filtre lavable	Oui, filtre en mousse lavable à l'eau
Fréquence de nettoyage du filtre	Tous les 6 mois ou lorsque l'aspiration diminue
Sécurité	Protection contre le vide excessif (interrupteur de sécurité), ne pas utiliser sans filtre
Protection moteur	Arrêt automatique en cas de température élevée
Numéro de série	Sur l'appareil (ex: A1-000001)
Garantie	Enregistrement en ligne sur khind.com.my/e-warranty
Assistance	Hotline [phone]

FOIRE AUX QUESTIONS - VC608 Khind

Comment assembler l'aspirateur Khind VC608 ?

Branchez le flexible sur l'entrée d'air jusqu'au clic. Insérez le tube télescopique dans la poignée courbée, puis la brosse sol dans le tube. Ajustez la longueur du tube.

Comment nettoyer le filtre HEPA ?

Débranchez l'aspirateur. Retirez le réservoir, tournez le couvercle, sortez le filtre HEPA. Lavez-le à l'eau tiède et laissez sécher 24 heures avant de le remettre.

Que faire si l'aspiration diminue ?

Vérifiez si le réservoir est plein ou si les filtres sont obstrués. Nettoyez le filtre en mousse et le filtre HEPA. Assurez-vous que les ouvertures ne sont pas bloquées.

Peut-on aspirer des liquides avec cet aspirateur ?

Non, cet aspirateur est pour usage intérieur sur surfaces sèches uniquement. N'aspirez jamais de liquides.

Comment rembobiner le cordon ?

Appuyez sur le bouton de rembobinage tout en guidant le cordon avec votre main pour éviter qu'il ne fouette.

Comment vider le réservoir ?

Appuyez sur le bouton du bras du réservoir, soulevez le réservoir, puis appuyez sur le bouton en bas pour ouvrir le couvercle et vider la poussière.

À quelle fréquence nettoyer les filtres ?

Le filtre en mousse doit être nettoyé tous les 6 mois ou lorsque l'aspiration diminue. Vérifiez les filtres après chaque utilisation.

Que faire si l'aspirateur s'arrête soudainement ?

L'interrupteur de sécurité interne s'est activé en raison d'un vide trop élevé. Débranchez, vérifiez les obstructions et nettoyez les filtres avant de redémarrer.

Où trouver le numéro de série ?

Le numéro de série se trouve sur le produit, exemple : A1-000001. Il est nécessaire pour l'enregistrement de la garantie.

Comment enregistrer la garantie ?

Scannez le QR code E-Warranty ou allez sur https://www.khind.com.my/e-warranty.html, remplissez vos coordonnées et le numéro de série.

MODE D'EMPLOI VC608 Khind

KHIND

Delivering Happiness

VACUUM CLEANER

INSTRUCTION MANUAL

Model: VC608

Read this manual thoroughly before using and save it for future reference.

Safety Instructions

FOR HOUSEHOLD USE ONLY!

When using your vacuum, basic safety precautions should always be observed including the following

1. Do not leave vacuum cleaner unattended when it is plugged in. Unplug from outlet when not in use and before pulling filters out.

2. To reduce the risk of electric shock. Do not use outdoors or on wet surfaces.

3. Do not allow children to use as a toy. Close attention is necessary who used near children.

4. Use only as described in this manual. Use only manufacturer's recommended attachments.

5. Do not use with damaged cord or plug. Do not use vacuum cleaner if been dropped, damaged, left outdoor, or dropped into water. Return appliance to KHIND customer service for examination repair or adjustment.

6. Do not pull or carry by cord. Do not use cord as a handle. Close a door on cord, or pull cord around sharp edges or corners. Do not run appliance cord. Keep cord away from heated surfaces.

7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the

8. Do not handle plug or vacuum cleaner with wet hands. Dot not use outdoors or on wet surfaces.

9. Do not put any objects into openings. Do not use with any openings blocked and do not restrict airflow. Keep all opening free of dust, lint, hair, and anything that may reduce airflow.

10. Keep hair, loose clothing, fingers, and all parts of body away from opening and moving parts.

11. Do not pick up hard or sharp objects such as glass nails, screws, coins

12. Do not pick up hot coals, cigarette, matches or any hot, smoking, or bu objects.

13. Do not use without filters in place.

14. Turn off all controls before plugging or unplugging vacuum cleaner.

15. Use extra care when vacuuming on stairs.

16. Do not pick up flammable or combustible materials (lighter fluid, gasoline, etc.) or use in the presence of explosive liquids or vapor.

17. Do not pick up toxic material (chlorine bleach, ammonia, drain cleaner, etc

18. Do not in an enclosed space filled with vapors given off by oil based paint thinner, moth proofing, flammable dust, or other explosive or toxic vapors.

19. Always unplug this appliance before connecting or disconnecting vacuum hose. Do not allow plug to whip when rewinding.

20. Use only on dry, indoor surfaces.

21. Do not use for any purpose other than described in this user's guide.

22. Store your appliance indoor in a cool, dry area.

23. Keep your work area well dry.

24. Do not immerse the vacuum cleaner into water or other liquids.

25. Keep end of hose, wands and other openings away from your face and body.
26. Do not use the vacuum cleaner to clean your pets or any animal.
27. Keep the head (eyes, ear, mouth, etc.) away from the openings, when the cleaner is working or plugging.

WARNING:

Important:

If the suction openings of the unit, the hose or the telescopic tube are block switch off the vacuum cleaner and remove the blocking substance before you start the unit again.

1. Do not operate the vacuum cleaner too close to heater or radiators.
2. Before inserting the power plug into the wall outlet, make sure that your hands are dry.
3. Before you start the unit, make sure to remove large or sharp objects might damage the dust tank and hose.
4. When pulling out the power plug from the wall outlet, pull the plug not power cord.
5. Do not use without all filters in place.
6. When using, if you learn of squeak from the cleaner, it must be suction appears to be reduced, so you must stop the vacuum cleaner (make sur the cleaner is not plugging), then clean the air filter.

Note:

If the supply cord is damaged, it must be replaced by manufacture, its serv agent or similarly qualified person in order to avoid a hazard.

WARNING:

Hold the plug when rewinding the cord. Do not allow the cord to whip wh rewinding.

Use and function

Assembling vacuum cleaner

Note:

Always remove the power plug from the wall outlet before assembling or removing accessories.

1. Attaching the Flexible Hose into the vacuum, connect the flexible hose into the air intake duct, push in until you hear a "click", indicating it is in locked position.

1. Fitting the telescopic tube to the curved wand/hose extension. Push the telescopic tube into the curved wand/hose extension.

2. Extending the telescopic tube. Push forward on the plastic button and pull the telescopic tube outward.

3. Fitting the Floor Brush to the telescopic tube. Push the telescopic tube in the floor brush. Adjust the tube to the desired length.

Note:

Once all attachments are in place, unwind a sufficient length of cable and insert the plug into the wall outlet. A yellow mark on the power cord show ideal cable length. Do not pull the power cord beyond the red mark.

1. Insert the power plug into the wall outlet.
2. Press the power on/off button located the unit to turn the vacuum cleaner "on"
3. To rewind the power cord, press the cord rewind button with one hand guide the power cord with the other hand to ensure that it dose not w causing damage or injury.

Clean the dust barrel

1. Press the knob on the dust cup arm.

2. Lift dust barrel up.

3. Press knob on low end of dust barrel to open the dust barrel cover.

1 2 3

Carry and move away the cleaner:

Note:

There is a handle on the top. You could use it to conveniently carry the

Removing & cleaning centric HEPA filter, and air outlet filter.

Warning:

Always unplug the unit from electrical outlet before getting out the dust barrel.

a. Dual cyclone filter

1. Press the knob on the dust cup arm.
2. Lift dust barrel up.
3. Grasp the body of the dust barrel and rotate the lid anti-clockwise then apart
4. Take apart the HEPA filter.
5. Wash.

b. Air outlet filter

1. Press the air outlet grid knob to open
2. Take out the air outlet filter for clean and change.

Please note:

The sponge filter material in the cleaner will become dusty over time. This normal and will not affect the performance of the filter. If the sponge filter dusty that suction does not return to 100%, then we suggest that the filter removed then rinsed under the faucet and allowed to dry for 24 hours by not near the fire or some high temperature objects before refitting into the vacuum. This should be done once six months or when suction appears to reduced obviously.

Important:

Please note that there is a safety switch inside the vacuum to prevent the from being run with high vacuum rate. If the vacuum is too high, the safe switch will be turned on. In this case, it can minish the vacuum rate and the motor from being broken.

All filters should be checked regularly for signs of damage, preferably after each cleaning task. The filters must be replaced immediately if they become damaged. Always disconnect the vacuum from the electrical outlet when checking the filters.

Note:

The suction hole must be open, free of any obstructions at all times. Other the motor will overheat and could become damaged.

@ KHIND®

1 Scan E-Warranty QR code or go to https://www.khind.com.my/e-warranty.html
2 Fill-up your detail, product information, serial no. & proof of purchase.
3 Serial no. can be found on product, example:
SERIAL NUMBER A1-000001
HOTLINE [phone]
