Home Office P604URC1 - Multiprise CyberPower - Notice d'utilisation et mode d'emploi gratuit
Retrouvez gratuitement la notice de l'appareil Home Office P604URC1 CyberPower au format PDF.
| Caractéristiques techniques | Multiprise avec 6 prises de courant, protection contre les surtensions, interrupteur marche/arrêt. |
|---|---|
| Utilisation | Idéale pour les bureaux à domicile, permet de brancher plusieurs appareils électroniques simultanément. |
| Maintenance et réparation | Vérifier régulièrement l'état des prises et du cordon d'alimentation. En cas de dommage, remplacer la multiprise. |
| Sécurité | Protection contre les surtensions, homologuée conforme aux normes de sécurité électrique. |
| Informations générales | Dimensions compactes, design moderne, garantie constructeur de 2 ans. |
FOIRE AUX QUESTIONS - Home Office P604URC1 CyberPower
Questions des utilisateurs sur Home Office P604URC1 CyberPower
0 question sur cet appareil. Repondez a celles que vous connaissez ou posez la votre.
Poser une nouvelle question sur cet appareil
Téléchargez la notice de votre Multiprise au format PDF gratuitement ! Retrouvez votre notice Home Office P604URC1 - CyberPower et reprennez votre appareil électronique en main. Sur cette page sont publiés tous les documents nécessaires à l'utilisation de votre appareil Home Office P604URC1 de la marque CyberPower.
MODE D'EMPLOI Home Office P604URC1 CyberPower
CyberPower
P604URC1 | HOME OFFICE SURGE PROTECTION
Protect home and office computers, electronics, and home theater equipment
The CyberPower Home Office Surge Protector P604URC1 prevents spikes in energy caused by storms and electrical power surges from reaching your home office equipment such as laptops, small electronics, and chargers. The P604URC1 provides 500 joules of protection, 6 AC outlets, and a 4-ft. power cord with a right-angle plug. It also has 2 USB ports (2.4 Amp) to quickly charge USB-powered devices.
Features of the P604URC1 include an on/off switch with integrated 15-amp circuit breaker, low-profile cord plug, keyhole mounting slots (back), and damage-resistant construction. This surge suppressor comes with a One-Year Limited Warranty and a \$50,000 Connected Equipment Guarantee.
TYPICAL APPLICATIONS
- Mobile Devices
• Personal Electronics - Cell Phones
• Consumer Electronics
FE AT UR E S
- Surge suppression: 500 Joules
- Volts: 125 V
- Circuit breaker: 15 A
• USB ports: 2 (2.4-Amp) - Plug type: NEMA 5-15P
• Outlet type: NEMA 5-15R - Outlets: 6 surge-protected
- Power cord: 4 ft
- Color: Black
• EMI/RFI Filtration: Yes
• Warranty: 1-Year Limited - Connected Equipment Guarantee: \$50,000
| INPUT | |
| Circuit Breaker 15 A | |
| Cord Length 4 ft (1.2 m) | |
| Input Plug Type NEMA 5-15P | |
| Maximum Input Current 15 A | |
| OUTPUT | |
| Outlet Type 6 NEMA 5-15R | |
| Outlets - Total 6 | |
| USB Charge Port Yes | |
| USB Charge Port Amperage 2.4 Amps (Shared) | |
| USB Charge Port Quantity 2 | |
| USB Charge Port Type Type A | |
| USB Charge Port Voltage | 5 VDC |
SPECIFICATIONS CONT.
SURGE PROTECTION & FILTERING
| Attenuation 32 dB | |
| Clamping Voltage 800V (H-N) | |
| Coax Protection RG6 None | |
| EMI/RFI Filtration Yes | |
| Maximum Surge Current 15,000 A | |
| Maximum Surge Current H-G N/A | |
| Maximum Surge Current H-N 15,000 A | |
| Maximum Surge Current N-G N/A | |
| Maximum Surge Voltage 6,000 V | |
| Response Time <1 Nanosecond | |
| Surge Suppression (Joules) 500 J |
MANAGEMENT & COMMUNICATIONS
| Indicators Protected | |
| PHYSICAL | |
| Color | Black |
| Cord Management | No |
| Form Factor | Strip |
| Form Factors Supported | Keyhole (Wall Mount or Under-counter Installation) |
| Keyhole Mounting Slots | Yes |
| Material of Construction | Plastic |
| Safety Covers | Yes |
DIMENSIONS
| Physical Dimensions - WxHxD (cm) | 4.72 x 3.45 x 30.99 cm |
| Physical Dimensions - WxHxD (mm) | 47 x 35 x 310 mm |
| Physical Dimensions - WxHxD (in.) | 1.86 x 1.36 x 12.2 in. |
| Weight (kg) | 0.36 kg |
| Weight (lb) | 0.80 lbs. |
SHIPPING DIMENSIONS
| Shipping Dimensions - WxHxD (cm) | 10.8 x 33.99 x 3.51 cm |
| Shipping Dimensions - WxHxD (mm) | 107.95 x 339.85 x 35.05 mm |
| Shipping Dimensions - WxHxD (in) | 4.25 x 13.38 x 1.38 in. |
| Shipping Weight (kg) 0.45 kg | |
| Shipping Weight (lbs.) | 1.00 lbs. |
CERTIFICATIONS
| Environmental | RoHS Compliant |
| Safety | UL1449cUL |
WARRANTY
| CEG Amount | $50,000 |
| Connected Equipment Guarantee | Lifetime |
| Product Warranty 1-Year Limited |
