MODE D'EMPLOI Home Office P806U CyberPower
CyberPower
P806U | PROFESSIONAL SURGE PROTECTOR
Protect home and office computers, electronics, and home theater equipment
Designed for use in home and office, the P806U Surge Protector US B from CyberPower protects electronic devices from damage caused by power spikes and surges. It features eight surge-protected outlet s (two widely spaced), two charge ports (2.4 Amps shared), and a six-foot power cord with a low profile plug. The Surge Protector USB , rated at 2,700 joules, is ideal for use video and audio equipment, cable and satellite equipment, game consoles, computers, laptops, and smartphones.
Features of the P806U include automatic shutdown, metal oxide varistor (MOV) technology, and an EMI/RFI noise filter. It also has LED indicators (Protected and Grounded) and impact-resistant casing. The P806U comes with a 1-Year Limited Warranty and a \$300,000 Connected Equipment Guarantee.
TYPICAL APPLICATIONS
- Mobile Devices
• Personal Electronics - Cell Phones
• Consumer Electronics
FEATURES
• Surge suppression: 2,700 J
- Volts: 125 V
- Circuit breaker: 15 A
- Plug type: NEMA 5-15P (45° offset)
• Outlet type: 8 NEMA 5-15R
- Power cord: 6 ft
- USB charge ports: 2
• LED indicator: Yes
• EMI/RFI Filtration: Yes
• Warranty: 1-Year Limited
- Connected Equipment Guarantee: \$300,000
| INPUT | |
| Circuit Breaker 15 A | |
| Cord Length 6 ft (1.8 m) | |
| Input Plug Type NEMA 5-15P | |
| Maximum Input Current 15 A | |
| OUTPUT | |
| Outlet Type 8 - NEMA 5-15R | |
| Outlets - Total 8 | |
| Outlets - Widely Spaced 2 | |
| USB Charge Port Yes | |
| USB Charge Port Amperage 2.4 A (Shared) | |
| USB Charge Port Quantity 2 | |
| USB Charge Port Type | Type A |
| USB Charge Port Voltage | 5 VDC |
SPECIFICATIONS CONT.
SURGE PROTECTION & FILTERING
| Attenuation 30 dB | |
| Clamping Voltage 600V (H-N, H-G, N-G) | |
| Coax Protection RG6 None | |
| EMI/RFI Filtration | 150 KHz100 MHzYes |
| Maximum Surge Current 105,000 A | |
| Maximum Surge Current H-G 30,000 A | |
| Maximum Surge Current H-N 45,000 A | |
| Maximum Surge Current N-G 30,000 A | |
| Maximum Surge Voltage 6,000 V | |
| Response Time <1 Nanosecond | |
| Surge Suppression (Joules) 2,700 J | |
MANAGEMENT & COMMUNICATIONS
| LED Indicators | Protected (green)Grounded (green) |
| PHYSICAL | |
| Color White | |
| Cord Management No | |
| Form Factor Strip | |
| Keyhole Mounting Slots No | |
| Material of Construction | Plastic |
| Safety Covers | No |
PHYSICAL DIMENSIONS
| Physical Dimensions - WxHxD (cm) | 9.91 x 3.1 x 19.81 cm |
| Physical Dimensions - WxHxD (mm) | 99 x 31 x 198 mm |
| Physical Dimensions - WxHxD (in.) | 3.9 x 1.22 x 7.8 in. |
| Weight (kg) | 0.58 kg |
| Weight (lb) | 1.28 lbs. |
SHIPPING DIMENSIONS
| Shipping Dimensions - WxHxD (cm) | 28.27 x 4.7 x 17.53 cm |
| Shipping Dimensions - WxHxD (mm) | 282.7 x 46.99 x 175.26 mm |
| Shipping Dimensions - WxHxD (in) | 11.13 x 1.85 x 6.9 in. |
| Weight (kg) | 0.68 kg |
| Weight (lb) | 1.50 lbs. |
CERTIFICATIONS
| Environmental | RoHS Compliant |
| Safety | UL1363UL1449 3rd EditioncUL |
WARRANTY
| CEG Amount | $300,000 |
| Connected Equipment Guarantee | Lifetime |
| Product Warranty | 1-Year Limited Warranty |
