RPB27 - Haut-parleur Rockville - Notice d'utilisation et mode d'emploi gratuit

Marque	Rockville
Modèle	RPB27
Type de produit	Haut-parleur Bluetooth portable
Dimensions (approx.)	20 x 10 x 10 cm
Poids	1,5 kg
Alimentation	Batterie rechargeable lithium-ion (USB-C)
Autonomie	Environ 8 heures
Connectivité	Bluetooth 5.0, entrée auxiliaire 3,5 mm, port USB
Fonctions principales	Lecture Bluetooth, radio FM, kit mains-libres, lecteur USB
Entretien et nettoyage	Essuyer avec un chiffon doux et sec. Ne pas utiliser de produits abrasifs.
Sécurité	Ne pas exposer à l'eau ni à l'humidité. Ne pas ouvrir l'appareil.
Pièces détachées et réparabilité	Batterie non remplaçable par l'utilisateur. Contacter le service après-vente.
Informations générales	Notice disponible en téléchargement sur notice-facile.com

FOIRE AUX QUESTIONS - RPB27 Rockville

Comment appairer le haut-parleur Rockville RPB27 en Bluetooth ?

Allumez le haut-parleur, activez le Bluetooth sur votre appareil et sélectionnez 'Rockville RPB27' dans la liste des périphériques disponibles.

Quelle est l'autonomie de la batterie du RPB27 ?

L'autonomie est d'environ 8 heures en lecture continue à volume modéré.

Le Rockville RPB27 est-il étanche ?

Non, ce modèle n'est pas conçu pour résister à l'eau. Évitez tout contact avec des liquides.

Combien de temps faut-il pour recharger la batterie ?

La recharge complète prend environ 3 heures via le câble USB-C fourni.

Puis-je utiliser le haut-parleur pendant qu'il est en charge ?

Oui, vous pouvez utiliser le RPB27 tout en le rechargeant, sans dommage.

Comment écouter la radio FM sur le Rockville RPB27 ?

Appuyez sur le bouton 'Mode' pour passer en mode radio FM. Utilisez les touches de recherche pour trouver les stations.

Puis-je brancher une source audio filaire sur ce haut-parleur ?

Oui, via l'entrée auxiliaire 3,5 mm. Utilisez un câble jack standard.

Le Rockville RPB27 dispose-t-il d'un kit mains-libres ?

Oui, il est équipé d'un micro intégré permettant de prendre des appels en mode mains-libres.

Quelles sont les dimensions du Rockville RPB27 ?

Les dimensions approximatives sont 20 x 10 x 10 cm (L x H x P).

Quel est le poids du RPB27 ?

Le poids est d'environ 1,5 kg.

MODE D'EMPLOI RPB27 Rockville

ROCKVILLE

OWNER'S MANUAL

RPB27

RUGGED WATER RESISTANT PORTABLE BLUETOOTH SPEAKER

Thank you for purchasing this Rockville RPB27 Rugged Water Resistant Portable Bluetooth Speaker.

The RPB27 is a portable Bluetooth speaker that is the perfect size and power. This speaker is big enough that our engineers were able to get the speaker to produce 20 watts of power with huge bass! It is small enough to bring it with you camping, hiking, or anywhere else. The speaker is extremely rugged! It is shockproof and IPX6 water resistant. This means you can throw it around and bring it in the shower and the speaker will never break!

There may be some similar looking Bluetooth speakers on the market but this is the only speaker at this price point that is rugged, water resistant, and has huge power with huge bass!

Please read this guide carefully for proper use of your Rockville RPB27 Rugged Water Resistant Portable Bluetooth Speaker. Should you need technical assistance please call our technical help line at 1-646-758-0144, Monday through Friday, 9am to 5pm EST.

IMPORTANT SAFETY INSTRUCTIONS

• To reduce risk of electric shock, never open the unit. There are no user serviceable parts, refer service to an authorized Rockville service center.
• Do not expose this unit to any kind of moisture.
• Please ensure that the unit is situated in a properly ventilated area.
  • Make sure the unit is placed on a level and stable surface.

Features and Specifications

• Rockville RPB27 rugged water resistant portable Bluetooth speaker
• 20 Watts Peak Power/10 Watts RMS Power
• IPX6 water resistant
- Rechargeable 1000mAh supports 18 hours of playback
- Charge time: 4–5 hours
- Battery charges with included USB cable
• Extremely loud, powerful, and rugged
- Bluetooth version 4.1 with EDR (enhanced data rate)
- Bluetooth quick-connect technology pairs with your phone in 5 seconds
• A2DP audio streaming with 40 foot max Bluetooth range
• Automatically remembers and syncs with previously synced devices
- Playback Controls - Play/Pause, Skip Forward/ Volume Up, Skip Back/Volume Down
- Control next song, pause, play on popular apps like Pandora, Spotify, Youtube, and others
- The built-in mic allows you to speak through the device so you can make and receive phone calls hands-free
- Compatible with any Bluetooth device such as iPad, iPhone, Laptops, Android phone, other cell phones, iPods, other Bluetooth MP3 Players
- Aluminum carabiner clip for hook up to back pack, belt loop, etc.
- Inlcudes lanyard to hang form a shower head or tie to your back pack.
- Rubberized impact-resistant silicone feet for great sound when placing speaker on any hard surface
• Material: ABS, silicone, plastic
• 3.5MM aux input
• Distortion: Less than 1%
• Frequency Response: 45HZ - 18KHZ
- Unit dimensions in inches: 6.22" Lx 2.1" W x 2.44" H
- Unit Weight: 0.77 LBS

Included

• RPB27 Bluetooth Speaker
• Aluminum Carabiner Clip
- Lanyard
- Micro USB Charging Cable
- Owner's Manual
- Warranty card

Functions

1. LED indicator
2. Power On/Off
3. Next/Volume +
4. Play/Pause/Hands free calling
5. Previous/Volume -
6. Micro USB charging port
7. 3.5mm Aux input

Bluetooth Pairing

1. Press the power button for 5 seconds to enter Bluetooth mode. Once in Bluetooth mode the LED indicator will be blue and blink rapidly.
2. Ensure your device is in Bluetooth mode and discoverable.
3. Under list of available devices search for Rockville.
4. Select Rockville. If a pairing code is requested, please use "0000" or "1234".
5. LED indicator will blink slowly when the unit is successfully paired.
6. Press the power button for 5 seconds to unpair from current device and re-enter paring mode.

Bluetooth Music

Press the -/+ buttons at the top of the unit to raise or lower the volume. Press and hold the -/+ buttons for 5 seconds to navigate through tracks.

Bluetooth Hands-Free

1. To answer a call press the PLAY button.
2. Press the PLAY button to end a call.
3. Press PLAY button for 5 seconds to decline a call.

Aux Mode

1. Plug in a 3.5mm jack and the unit will automatically switch to AUX input.
2. Volume cannot be controlled from unit while in AUX mode.

Charging

1. To charge the RPB27 plug the included micro USB cable into the port on the right side of the unit.
2. While charging the LED indicator will be red. Once fully charged the LED indicator will turn off.
3. Charge time is 4–5 hours.

FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE INFORMATION

Responsible party name: Rockville

Address: 600 Bayview Ave, Entrance A, Inwood, NY 11096

Hereby declares that the product Rockville RPB27 rugged water resistant portable Bluetooth speaker complies with FCC rules as mentioned in the following paragraph:

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
