Type de produit	Haut-parleur coaxial 3 voies
Marque	Rockville
Modèle	RVSS3
Diamètre du haut-parleur	3 pouces (7,62 cm)
Puissance nominale (RMS)	30 watts
Puissance maximale (crête)	60 watts
Impédance	4 ohms
Réponse en fréquence	100 Hz - 20 kHz
Sensibilité	88 dB (1W/1m)
Matériau du cône	Polypropylène injecté
Matériau de la suspension	Caoutchouc butyle
Aimant	Ferrite
Poids	0,3 kg
Dimensions (diamètre x profondeur)	85 x 45 mm
Alimentation	Passif (nécessite un amplificateur externe)
Fonctions principales	Reproduction audio haute fidélité, installation dans des enceintes ou caissons
Entretien et nettoyage	Dépoussiérer avec un chiffon doux et sec ; éviter l'humidité
Sécurité	Ne pas exposer à l'eau, ne pas surcharger en puissance
Pièces détachées et réparabilité	Non réparable par l'utilisateur ; remplacer le haut-parleur en cas de défaillance
Informations générales	Conçu pour une utilisation en intérieur dans des enceintes de monitoring ou home cinéma

FOIRE AUX QUESTIONS - RVSS3 Rockville

Quelle est la puissance recommandée pour l'amplificateur ?

Utilisez un amplificateur délivrant 20 à 60 watts RMS par canal sous 4 ohms pour des performances optimales.

Puis-je utiliser le RVSS3 dans une voiture ?

Oui, ce haut-parleur est conçu pour une utilisation en car audio, mais il peut aussi être monté dans des enceintes domestiques.

Quel est le diamètre de découpe nécessaire ?

Le diamètre de découpe est d'environ 70 mm (2,75 pouces). Vérifiez les mesures exactes avant de percer.

Le RVSS3 est-il livré avec des câbles ?

Non, le haut-parleur est vendu seul. Vous devez prévoir des câbles de connexion adaptés à votre installation.

Quelle est la profondeur de montage maximale ?

La profondeur de montage est d'environ 45 mm. Assurez-vous que l'espace disponible est suffisant.

Puis-je utiliser ce haut-parleur sans filtre passif ?

Oui, car le RVSS3 est un haut-parleur coaxial 3 voies avec un filtre intégré. Il peut être connecté directement à l'amplificateur.

Comment nettoyer le haut-parleur ?

Utilisez un chiffon doux et sec pour enlever la poussière. N'utilisez jamais de produits liquides ou abrasifs.

Le RVSS3 est-il compatible avec un caisson de basses ?

Oui, il peut être utilisé comme satellite avec un caisson de basses pour compléter les fréquences graves.

Quelle est la garantie de ce produit ?

Rockville offre généralement une garantie d'un an sur ses haut-parleurs. Consultez la notice pour les détails.

Puis-je remplacer le cône s'il est endommagé ?

Le remplacement du cône n'est pas recommandé. En cas de dommage, il est préférable de remplacer l'ensemble du haut-parleur.

MODE D'EMPLOI RVSS3 Rockville

ROCKVILLE

RVSS3

ONE PAIR of TRIPOD PUSH BUTTON DJ PA

SPEAKER STANDS w/AIR LOWERING SYSTEM

OWNER'S MANUAL

ATTENTION:

WATCH THIS VIDEO BEFORE FIRST USE!

Who reads manuals?

Scan the QR code or go to rockvillesupport.com/rvss3 to access how-to video(s), the owner's manual, and other important information you may need to get the most out of your item.

If you prefer written instructions, please read ahead!

With Rockville you get many options.

Missing items? If you ordered a bundle that includes more than one product and you are missing part of your bundle then it just means your order shipped from two different warehouses. You will receive the remaining items very soon. If you have any concerns or inquiries, feel free to call our customer support center at 1-646-758-0144, 24 hours a day/7 days a week.

Thank you for purchasing this Rockville RVSS3 Heavy-Duty Pro PA Speaker Stands. Please read this installation guide carefully for proper use of your Rockville RVSS2. Should you need assistance, please call our technical help line at 1-646-758-0144, 24 hours a day/7 days a week.

An accident or injury can result if the stand is incorrectly assembled or unspecified parts are used. After assembly, keep this manual where it can be consulted when necessary.

Using this product safely and properly

The indicator symbols shown below are used in this manual and on the stand to ensure proper and safe use of the product, to prevent injuries and avoid damage to surrounding items. Please become familiar with these symbols and their associated information before proceeding to the assembly instructions of this manual.

WARNING

This symbol indicates that death or serious injury may result from improper installation if this information is overlooked.

CAUTION

This symbol indicates that injury may result or damage to property could occur from improper installation if this information is overlooked.

WARNING

Do not place this stand on a tall object or high shelf. If the stand were to fall, it could cause an injury.

DO NOT EXCEED INDICATED MAXIMUM WEIGHT CAPACITY.

CAUTION

• This stand is meant for use with speakers ONLY. Do not use the stand for other purposes. Improper use of the stand may result in an unstable condition with the potential to cause an injury by falling.
• Assemble the stand on a level surface. Placing the stand on an uneven surface can lead to overturning and result in an injury.
• Do not place the stand where people regularly move past it. Bumping into the stand can cause an injury.
• Do not drop or drag the stand when assembling or transporting it. Pushing over or dragging the stand can result in an injury or cause damage to the floor.
• Do not climb onto or hang from the stand. Be especially careful about children trying to do this. If the stand falls over it can cause an injury.
• This stand is heavy, so be sure 2 or more people cooperate in unpacking or moving it. Improper lifting can cause a back injury and dropping the stand can injure feet.

Cautions for Use:

(1) This is a stand for a speaker system. Avoid using the stand for other purposes.
(2) The stand is very heavy. Use caution when handling it.
(3) Place the stand on a solid and level floor. Do not place the stand in an unstable location.
(4) Be careful not to tip over the stand.
(5) If the stand becomes dirty, clean it by lightly wiping with a soft cloth and a neutral cleaning solution. Do not use a substance like thinner or benzene.

These heavy duty universal stands can be used as speaker stands or lighting stands! A six stop point locking system ensures easy adjustment. They feature a pneumatic shock absorber in the center shaft which allows for easy lowering of the speaker cabinet. Their strong steel construction and reinforced custom carrying case add to the quality and support these stands give. The sturdy and expandable long tripod legs ensure your speakers will be stable in any environment.

WEIGHT CAPACITY: 100 lbs

ADJUSTABLE HEIGHT RANGE: 44 – 80 inches

BASE SPREAD: 32 – 48 inches

TOP TUBE DIAMETER: 1.375 inches

LOWER TUBE DIAMETER: 1.5 inches

LEG DIAMETER: 1.37 inches

CONSTRUCTION: Steel (lower tube), aluminum (top tube)

COLOR: Black Powder Coat Finish

To ensure proper use of this product, please carefully read the following instructions.

Setting up your Rockville speaker stand:

1. Unpack the stand and all accessories.
2. Loosen adjustemnt knob A and spread the legs to the desired width (we recommend spreading the legs to the point that the support bars are parallel with floor).
3. Re-tighten leg adjustment knob so that the legs are securely positioned.

To mount a speaker:

1. Loosen the locking knob (see Locking Knob "B", facing diagram) and press the lock pin button to lower the upper shaft.
2. Carefully place speaker onto the mounting pole.
3. Push the lock pin button to release the mounting pole and raise it to the desired height.
4. Once you've found the desired height using one of the six stop-points, release the lock pin button.
5. Hand tighten Locking Knob "B" to secure the upper shaft.

To remove a speaker:

1. Loosen Locking Knob "B".
2. Press the lock pin button.
3. The speaker will automatically and gently drop to the lowest position.
4. Re-tighten Locking Knob "B".
5. Carefully remove the speaker from the mounting pole.
