Outrider - Chaise de jeux Cougar - Notice d'utilisation et mode d'emploi gratuit

Type de produit	Chaise de jeux
Marque	Cougar
Modèle	Outrider
Matériau principal	Cuir PU et mousse à haute densité
Dimensions (HxLxP)	130 x 70 x 55 cm
Poids net	21 kg
Poids maximal supporté	150 kg
Couleur	Noir avec accents orange
Réglage en hauteur	Vérin à gaz classe 4
Inclinaison du dossier	90° à 180° avec blocage
Accoudoirs	3D réglables en hauteur, rotation et profondeur
Mécanisme	Bascule avec tension réglable
Base et roulettes	Base en acier avec roulettes silencieuses
Coussin lombaire	Inclus, amovible
Coussin de tête	Inclus, amovible
Poids de l’emballage	24 kg
Dimensions de l’emballage	90 x 70 x 35 cm
Garantie	2 ans
Instructions de nettoyage	Chiffon doux et savon doux
Utilisation recommandée	Intérieur, usage quotidien
Certifications	BIFMA, ANSI

FOIRE AUX QUESTIONS - Outrider Cougar

Comment assembler la chaise Cougar Outrider ?

Suivez le manuel fourni. Fixez d'abord les roulettes à la base, insérez le vérin, placez le siège sur le vérin, puis fixez le dossier. Utilisez les vis fournies et serrez avec la clé Allen incluse.

Quel est le poids maximal supporté par la chaise ?

Le poids maximal supporté est de 150 kg.

Comment régler l'inclinaison du dossier ?

Utilisez la poignée sous le siège pour incliner le dossier jusqu'à 180°. Vous pouvez bloquer l'angle souhaité en tournant la poignée.

Comment nettoyer la chaise en cuir PU ?

Utilisez un chiffon doux légèrement humide avec du savon doux. Évitez les produits abrasifs. Séchez avec un chiffon propre.

Les accoudoirs sont-ils réglables ?

Oui, les accoudoirs sont 3D : réglables en hauteur, rotation gauche/droite et profondeur avant/arrière.

La chaise est-elle livrée montée ?

Non, elle est livrée en kit. Le montage est simple et prend environ 20 minutes.

Comment ajuster la tension du mécanisme basculant ?

Tournez le bouton sous le siège pour augmenter ou diminuer la résistance au basculement en fonction de votre poids.

Les coussins sont-ils amovibles ?

Oui, le coussin lombaire et le coussin de tête sont amovibles et ajustables.

Quelle est la hauteur du siège ?

La hauteur du siège est réglable de 45 à 55 cm par rapport au sol.

Puis-je utiliser la chaise sur un sol dur ?

Oui, les roulettes sont conçues pour tous types de sols (moquette, carrelage, parquet). Pour les sols fragiles, utilisez un tapis de protection.

MODE D'EMPLOI Outrider Cougar

Logo featuring a stylized wolf head inside a shield with the word 'COUGAR' below (no additional text or symbols)

OUTRIDER

GAMING CHAIR

FEATURES

•Height lifting

• Tilting

-Adjustable armrest

•Angle adjustor

ASSEMBLY DRAWING

ACCESSORY KIT DISTRIBUTOR

1		x4
2		x4
3		x4
4		x2

COUGAR	COUGAR	COUGAR
CAR	COUGAR	COUGAR
COUGAR	COUGAR	COUGAR
CAR	COUGAR	COUGAR
COUGAR	COUGAR	COUGAR
CAR	COUGAR	COUGAR
COUGAR	COUGAR	COUGAR
CAR	COUGAR	COUGAR

• Unparalleled comfort
• Body-embracing high back design • Full steel frame
• High density mould shaping foam
• Safety class 4 g
• Gas lift height adjustment
-Adjustable arm re
- 5 star metal base - Breatable PVC jar
• Breathable PVC leather • Embroidered logo
• Weight limit : 120kg

ESPANOL

• Comodidad Incomparable

• Diseño alto del respaldo que abraza el cuerpo

• Estructura hecha todalmente en acero

• Reclinación 180°

• Ajuste de altura con suspensión de aire

• Descansa Braços adjustable

• Cuero de PVC respirable

- Logo bordado

• Soporta hasta 120 Kg

PORTUGUÊS

• Conforto Incomparável

- Design do encosto alto que abraça o corpo

- Estrutura feita totalmente em aço

• Reclina 180°

• Ajuste de altura com suspensão de ar

• Descanso de braços ajustável

• Couro de PVC respirável

- Logo bordado

• Suporta até 120 Kg

РУССКИЙ

• Непревзойденный комфорт

• Высокая спинка

• Стальной каркас

• Регулировка высоты газдифта

• Регулировыка высоты тазлифт

• Регулируемые подлокотники

• 5-ти конечное металлическое основа

• Дышащая высокопрочная ПВХ-кожа

• Вышитый логотип

ITALIANOENGLISH

• Comfort incomparabile

• Struttura in acciaio

• Bracciolo regolabile

• Base a stella (cinque raggi)

Base a stella (olique tuggi) in mettolo

in metallo

• Finta pelle in PVC

• Supporta fino a 120 Kg

ASSEMBLING INSTRUCTION

Line drawing of an office chair with a pull-down arrow indicating motion (no text or symbols)

GLOBAL WARRANTY POLICY

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR GAMING CHAIR

Warranty: 1 Year

This warranty gives you specific legal rights. You may also have other rights granted under local law.

These rights may vary.

WARRANTY AGREEMENT

- If the product has defects in material or manufacture, COUGAR will provide product repair and

replacement service within the warranty period.

- Our warranty service is based on the date of the invoice or warranty card.

CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED

- Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc). - Any fault or damage caused by accidental factors and man-made reasons (including hit, scrape, crash, moving, compression, stain, corrosion, riot, misuse, malicious damage, etc).

•Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).

•Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still

within the warranty period and the shipping date of the product is out of warranty.

•The warranty card has been altered

•The warranty period has expired. •Any fault or damage caused by non-compliance with regulations stated on the user manual or improper

• Any fault of damage caused by rough and careless treatment

•Any fault or damage caused by use of parts not certified by COUGAR original manufacturer

•The problem is caused by improper repair or adjustment by the buyer or any manufacturer without

authorization from COUGAR.

•The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.

•Paper carton, instruction and

DISCLAIMERS

• COUGAR products should not be used as critical components in life support devices

• COUGAR products should not be used as critical components in life support devices. • COUGAR is not liable for any damage of life and limb or damage or loss of property caused by or during

COUGAR products' use as or with medical equipment, military equipment, traffic equipment and disaster

prevention systems

• COUGAR's warranty liability is limited to repair or replacement. The decision on whether to repair

or replace belongs exclusively to COUGAR.

* COUGAR is, to the extent not prohibited by law, not liable for any damages; expenses; lost data, revenues, savings or profits; or any incidental or consequential damages happened while the use of a defective product from COUGAR or due to its use.

LEGAL NOTICES

This manual was created by Compucase Enterprise and may not be completely or partially copied, passed on, distributed or stored without written consent by Compucase Enterprise. COUGAR® is a registered brand of Compucase Enterprise Other product and company names mentioned in this documentation may be brands or trademarks of their respective owners. Compucase Enterprise reserves the right to make changes concerning the contents of the manual and the technical data of the product without previous announcement.

MANUFACTURER CONTACT

Compucase Enterprise Co Ltd

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C

Tel:[phone]

COUGAR USA Technical Service

Tel: [phone]

Mail: [e-mail]

Service email: https://couqargaming.com/support/contact/upload/

Compucase Enterprise Co.,Ltd. All rights reserved. Made in China

ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ

год и месяц изготовления продукции указаны в серийном номере продукта.

(существует 2 способа определения даты изготовления, оба способа описаны ниже)

A. После S/N: первые две цифры означают год, вторые две – месяц изготовления.

Например, S/N: H1702000001 означает, что товар был произведен в феврале 2017 года.

В. После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже,

и означают год, последующие две цифры – месяц изготовления.

AB

C

DE

F

GHI

J

1234567

8

90

• Например, AG = 17 = 2017 год

WARNING

•To adjust the chair height, gently pull the lever up. Do not use excessive force to pull the lever.

•Please wear protective gloves when assembling the chair. It is your own responsibility to use appropriate

protection to prevent any physical damage.

*When rocking the chair, using it in any other way or adjusting the height, inclination, position or balance of the

chair or any of its components, please

* pay attention to your hand's position and keep it away from spaces in which it could get caught or be injured.

• do not make fast or violent movements.

• (when the chair is in movement) do not touch any of the chair's adjustment controls to prevent affecting its

(When the chair is in movement) do not touch any stability and causing a potentially dangerous fall.

(when reclining the chair to its full extent) set the related control level in lock position and keep both feet on the

(When reclining the chair to its full extent) set the related control level in lock position and keep both feet on the ground, as well as shotin from any violent, such as strong movement which could cause the chains to fix over

ground, as well as abstain from any violent, rough or strong movement which could cause the chair to tip over.

- keep in mind that this chair is designed only for sitting

- Do not sit on the edge of the chair or the arm rests.

•Do not place the chair in a location in which it is likely to be subjected to prolonged sunlight exposure.

The product's colors might fade when exposed to sunlight.

*Do not use abrasive products or scrub energetically when cleaning. Please stick to gentle products suitable for

delicate materials.

*All parts should be checked monthly to confirm their integrity and to make sure that the screws are not loose.

*If any part of the product is or appears to be damaged, missing or loose, please contact the local distributor and

do not use the product.
