Type de produit	Casque gaming
Marque	Cougar
Modèle	Immersa
Connectivité	Filaire (jack 3,5 mm)
Diamètre des haut-parleurs	50 mm
Réponse en fréquence	20 Hz - 20 kHz
Impédance	32 ohms
Sensibilité	100 dB
Type de microphone	Microphone unidirectionnel
Réponse en fréquence du micro	50 Hz - 10 kHz
Alimentation	Pas de batterie, alimenté via la prise jack
Longueur du câble	2 mètres
Poids	300 grammes
Matériau du cadre	Plastique renforcé
Matériau des coussinets	Similicuir à mémoire de forme
Compatibilité	PC, PS4, PS5, Xbox One, Xbox Series X|S, Nintendo Switch, smartphones
Fonctions principales	Son surround 7.1 virtuel, contrôle du volume sur le câble, fonction muet
Entretien et nettoyage	Nettoyer avec un chiffon doux et sec, ne pas utiliser de produits chimiques
Sécurité	Utilisation à volume modéré pour protéger l'audition
Pièces détachées et réparabilité	Remplacer le câble ou les coussinets, contactez le SAV Cougar
Informations générales	Garantie 2 ans

FOIRE AUX QUESTIONS - Immersa Cougar

Comment brancher le casque Cougar Immersa à ma console ?

Branchez le câble jack 3,5 mm du casque dans la prise casque de votre manette ou de la console. Pour le son surround, installez le logiciel Cougar UIX (sur PC) et sélectionnez le mode 7.1 virtuel.

Le microphone ne fonctionne pas, que faire ?

Vérifiez que le câble est bien enfoncé et que la fonction muet n'est pas activée (bouton sur le câble). Assurez-vous également que le micro n'est pas désactivé dans les paramètres audio de votre appareil.

Puis-je utiliser le casque avec mon téléphone ?

Oui, le casque est compatible avec les smartphones disposant d'une prise jack 3,5 mm. Si votre téléphone n'a pas de prise jack, utilisez un adaptateur USB-C vers jack.

Comment activer le son surround 7.1 ?

Téléchargez et installez le logiciel Cougar UIX depuis le site officiel. Branchez le casque, puis activez l'option 'Surround 7.1' dans l'interface du logiciel.

Le son est trop faible, comment l'augmenter ?

Utilisez la molette de volume située sur le câble du casque. Vous pouvez aussi augmenter le volume dans les paramètres audio de votre appareil ou via le logiciel Cougar UIX.

Comment nettoyer les coussinets du casque ?

Retirez les coussinets (ils sont clipsés). Nettoyez-les avec un chiffon doux légèrement humide et laissez sécher à l'air libre avant de les remettre.

Le câble du casque est endommagé, puis-je le remplacer ?

Contactez le service après-vente Cougar pour commander un câble de remplacement. Le câble est amovible sur certains modèles, vérifiez si le vôtre l'est.

Le casque est-il compatible avec la Xbox Series X ?

Oui, branchez-le directement sur la prise jack de la manette. Le son surround 7.1 n'est pas disponible sur Xbox, mais le son stéréo fonctionne parfaitement.

Comment mettre à jour le firmware du casque ?

Le logiciel Cougar UIX peut rechercher les mises à jour. Ouvrez le logiciel, allez dans 'Paramètres' puis 'Mise à jour firmware' et suivez les instructions.

Le casque serre trop, comment l'ajuster ?

Le casque dispose d'un arceau réglable. Tirez doucement sur les branches pour l'agrandir. Les coussinets épais s'adapteront avec le temps à la forme de votre tête.

MODE D'EMPLOI Immersa Cougar

PRODUCT PARTS AND PACKAGE CONTENTS

Ultra-Light Suspended Headband Support Structure
Ultra Lightweight Suspended Leatherlike Headband
Extra-Large (100 mm) Circumaural Leatherlike Ear Pads
Retractable Microphone for Gaming
Control unit with volume control and microphone on/off functionality
4 Pole Audio and Microphone Jack (3.5mm)
4 pole to dual (microphone + audio) 3 pole adaptor

Technical line drawings of two types of electronic devices labeled F and E, showing internal components without any text or symbols.

Line drawing of a pair of headphones with earbuds and cable (no text or symbols)

INSTRUCTIONS

A How to adjust the microphone

Diagram of two identical mechanical arms with a tool, showing rotational motion (no text or symbols)

B Caution

Line drawing of a headboard with earbuds and headphones, no text or symbols present

When stretching the headphones before placing them in your head, please pay attention to avoid stretching them beyond their physical limits to avoid damaging the product.

FEATURES

ENGLISH

· HIGH QUALITY STEREO SOUND

Exactly what you need to the vast majority of audio media on the market. With a superior bass performance and clear trebles, IMMERSA delivers exactly the experience you need for gaming.

40MM NEODYMIUM MAGNET DRIVER

IMMERSA's 40mm Neodymium magnet driver will provide crisp and clear audio for your games.

ULTRA LIGHTWEIGHT SUSPENDED LEATHERLIKE HEADBAND DESIGN

With carefully chosen materials that reduce weight without sacrificing durability, the IMMERSA's hanging leatherlike headband design allows you to use it for extended periods of time without experiencing fatigue and minimizing the physical contact of the headset's hard parts with your head to improve comfort.

100MM EXTRA-LARGE EAR PADS FOR MORE ISOLATION AND COMFORT

COUGAR has not skimped on good quality materials, and IMMERSA's 100 mm ear pads are proof of it. Built with a leatherlike material for extra comfort, their extended surface will always keep your ears covered, guaranteeing excellent sound isolation and comfort.

AUTOMATIC OMNI-DIRECTIONAL ADAPTATIVE EAR SHELLS

IMMERSA's extra-large automatic omni-directional adaptive ear shells will adapt their position automatically with 360€ adjustment, guaranteeing a perfect fit in all situations.

- 4 POLE TO 3 POLE ADAPTER FOR EXTRA COMPATIBILITY

The included 4 to 3 pole adapter will allow you to use IMMERSA with virtually any device, including laptops, phones, tablets and desktop computers.

-RETRACTABLE MICROPHONE: FLEXIBLE, CONVENIENT, DURABLE AND

DOES NOT GET LOST

IMMERSA's retractable microphone is always where you need it to be. When you're gaming, you can locate it near your mouth for optimal sound quality. When you don't need it, you can simply retract it back to make sure it doesn't get in your way. This, united with the microphone's high flexibility, not only makes it more convenient, it also strongly enhances its durability.

-NOISE CANCELLATION TECHNOLOGY

The microphone's advanced design makes use of several noise cancellation technologies that help it filter out background noise and make sure that your voice is transmitted clearly.

-CONTROL UNIT ON THE CABLE WITH VOLUME CONTROL AND MICROPHONE ON/OFF FUNCTIONS

A conveniently located control unit will allow you to easily adjust volume and mute the microphone when needed, the two functions more often required for gaming.

-BRAIDED CABLE FOR EXTRA DURABILITY

A highly resistant braided cable will enhance the device's durability, exactly what you need for a highly portable device such as IMMERSA.

DEUTSCH

• HIGH-QUALITY STEREO-SOUND
• 40-MM-NEODYMIUM-MAGNETTREIBER
EXTREM LEICHTES KOPFBUGEL-DESIGN MIT LEDER-OPTIK EXTRA GROBE OHPDOLSTER (100 MM) FÜR BESSERE ISOL
EXTRA-GROBE O MEHR KOMFORT
• ADAPTIVE OMNIDIREKTIONALE OHRMUSCHELN
• 4-POL ZU 3-POL-ADAPTER FÜR HOHE KOMPATIBILITÄT
• EINZIEHBARES MIKROFON: FLEXIBEL, PRAKTISCH, HALTBAR UND GEHT
NICHT VERLOREN
- INTEGRIERTE TECHNOLOGIE ZUR GERAUSCH-UNTERDRUCKUNG - KARELEERNREDIENUNG MIT LAUTSTÄRKEREGLER UND MUTE, EU
KABELFERNBEDIENONG MIT LAOTSTARKEEGLER OND MOTE-FUNKTION UMELOCHTENES KABEL FÜR DAUERHAETE HALTBARKEIT

ESPAÑOL

• ALTAVOZ DE 40 MM CON IMÁN DE NEODIMIO
ALMOHADILLAS DE TAMANO EXTRA-GRANDE (100 MM) PARA MAYOR AIGLAMIENTO Y CONFORT
AISLAMIENTO Y LCONFORT DISEÑO ECONÓMICO CO
- DISENO EKGONOMICO CON ADAPTACIÓN AUTOMATICA OMNIDIRECCIONAL - TECNOLOGÍA DE ELIMINACIÓN DE RUIDOS DE FONDO

PORTUGUÊS

• FONE DE NEODÍMIO MAGNÉTICO DE 40MM
- ESPUMA EXTRA-GRANDE COM 100MM PARA MAIOR ISOLAMENTO E CONFORTO
• ESTRUTURA AUTOMÁTICA, ONIDIRECIONAL E ADAPTAVEL • TECNOLOGIA DE CANCELAMENTO DE RUÍDOS

РУССКИЙ

•НАУШНИКИ С 40-ММ НЕОДИМОВЫМИ МАГНИТАМИ ДЛЯ СОВЕРШЕННОГО ЗВУНАНИЯ
- СВЕРХБОЛЬШИЕ 100-ММ АМБУЩОРЫ СОЗДАЮТ КОМФОРТ И
ДОПОЛНИТЕЛЬНУЮ ЗВУКОИЗОЛЯЦИЮ
• МИКРОФОН С ФУНКЦИЕЙ ШУМОПОДАВЛЕНИЯ
• УНИКАЛЬНЫЙ ЭРГОНОМИЧНЫЙ ДИЗАЙН С
АВТОМАТИЧЕСКИ-ПОДСТАРЕВАЕМЫМ ПОЛОЖЕНИЕМ АМБУШЮР

FRANÇAIS

• HAUTS PARLEURS DE 40MM AVEC AIMANTS EN NÉODYME
COUSSINET EXTRA-LARGE DE 100MM POUR UNE MEILLEURE ISOLATION ET UN
MEILLEUR CONFORT • POSITIONNEMENT AUTOMATIQUE ET ADAPTATIE DES COQUES POUR LUN SON
OMNI DIRECTIONNEL
• TECHNOLOGIE D' ÉLIMINATION DES BRUITS PARASITES

HUNGARIAN

• 40MM NEODIMIUM MAGNESSEL ELLATOTT MEMBRAN • 100MM ES EXTRA NAGY FÜLRÁDNA A HANGSZIGETELÚ
- 100MM-ES EXTRA-NAGY PULPARKA A HANGSZIGETELESERT ES KOMFORTERI - AUTOMATIKUSAN TÖBBIRÄNYÜ ADAPTÍV KAGYLÓK
• AKTÍV ZAJSZÚRŐ TECHNOLÓGIA

POLISH

• 40MM PRZETWORNIKI OPARTE O MAGNESY NEODYMOWE
• NAREADKI NA USZY O SREDNICY 100M DLA WIĘRSZEGO KOMFORTU ORAZ IZOLACILDŻWIEKU
• AUTOMATYCZNIE O
• TECHNOLOGIA IZOLUJĄCA HAŁAS

ITALIANO

• 40MM NEODYMIUM DRIVER MAGNETICO
• 100MM EXTRA-LARGE EAR PADS PER MAGGIORE COMFORT E ISOLAMENTO AGUSTICO
ACUSTICO ADATTATO
- ADATTATORE OMNIDIREZIONALE AUTOMATICO - TECNOLOGIA "NOISE CANCELLATION"

[Non-Text]

日本語
-40mmネオジムマグネットドライバー
- 密閉型タイプで、長時間の装着も快適な100mm大型イヤーパッド採用
- 360度回転可能なイヤーマ

・ノイスキャンセル機能搭載

한국어

-40mm 네오디 lyrics 자석 드라이버
-더욱 편안함과 격리를 위해 100mm 초대형 이어 패드
-자동 전방향 조정형
소음 취소 기술

中文

采用直径40mm钕质磁铁驱动单元，性能大幅提升，以高保真重现每一个音乐细节
- 100mm大尺寸适耳型耳罩设计，佩戴舒适、隔音效果更出色
- 360度活动耳罩，柔软的耳垫能紧贴在耳朵周围，提供杰出音频密封效果
·降噪麦克风设计·让对话更畅通无阻

SPECIFICATIONS

HEADPHONES
Drivers	40mm
Frequency response	20Hz - 20KHz
Sensitivity at 1KHz	95dB ± 3dB
Impedance at 1KHz	32Ω +/- 15%
Max. Input Power	100mW
Cable Length	2m

MICROPHONE
Type	Noise Cancelling Condenser
Frequency	100Hz to 16kHz
Sensitivity at 1KHz	-40dB ± 3dB
Impedance	2.2kΩ

The above specifications may vary by country or region

PACKAGE CONTAINS

COUGAR IMMERSA Gaming Headset

User Manual

4 to dual (microphone + audio) 3 pole adaptor

HARDWARE REQUIREMENTS

SINGLE JACK DEVICES

•Audio: 3.5 mm audio jack. •Audio + Micronphone: 3.5 mm audio + microphone integrated jack

Audio + Microphone, 5.3 mm audio + microphone integrated jack.

Local jack devices (non usage with the audio/mic splitter adapter). *Audio + Microphone: Separate 3.5 mm audio and microphone jacks

GLOBAL WARRANTY POLICY

WARRANTY PERIODS OF COUGAR GAMING DEVICES

Product : COUGAR IMMERSA gaming headset

Warranty : 1 Year

This warranty gives you specific legal rights. You may also have other rights granted under legal law. These rights may vary:

granted under local law. These rights may vary.

WARRANTY AGREEMENT

•If the product has defects in material or manufacture, COUGAR will provide

product repair and replacement service within the warranty period.

- Our warranty service is based on the date of the invoice or warranty card

(must be affixed with the store stamp).

If you lose the aforementioned evidence, we will apply the original shipping date of the product as the beginning date of warranty period. The shipping

date of the product as the beginning date of warranty period. The shipping date will be identified by the product serial number(S/N).

CONDITIONS WHERE FREE MAINTENANCE IS NOT PROVIDED

- Any fault or damage caused by natural disasters (including storm, fire, flood, thunder, earthquake, etc).

• Any fault or damage caused by accidental factors and man-made reasons

(including hit, scrape, crash, moving, compression, stain, corrosion, use of insured an upvitable voltage, computer vivo, net mixture, defective damage, etc.)

incurred on unsuitable voltage, computer virus, hot, misuse, malicious damage, etc.

- Use in an improper operating environment (including high temperature, high humidity, water inflow, etc).

- Inability to provide the product warranty card, purchase receipt or invoice to prove the product is still within the warranty period and the shipping date of the product is out of warranty.

• The warranty card or product serial number has been altered or its number is hard to identify.

• The warranty period has expired.

• Any fault or damage caused by non-compliance with regulations stated on

the user manual or improper, rough and careless treatment.

- Any fault or damage caused by use of parts not certified by COUGAR original manufacturer.

- The problem is caused by improper repair or adjustment by the buyer or any manufacturer without authorization from COUGAR.

• The product is not acquired from an authorized distributor of the company or is acquired from illicit sources.

• Paper carton, instruction and other accessories are not warranted.

DISCLAIMERS

• COUGAR product is not authorized for use as critical components in life

support device or for incorrect application software or malfunction of the product.

- COUGAR is not liable for the death or damage of person or loss of property when product is using as, including but not limited to, medical equipment, military equipment, traffic equipment and disaster prevention system.

• COUGAR's warranty liability is limited to repair, replacement.

- COUGAR is not liable for any damages, expenses, lost data, lost revenues, lost savings, lost profits, or any incidental or consequential damages due to using defect product of COUGAR.

If you have any question about the warranty, please feel free to contact us. Customer support: [e-mail]

LEGAL NOTICES

This manual was created by Compucase Enterprise and may not be completely or partially copied, passed on, distributed or stored without written consent by Compucase Enterprise.

COUGAR® is a registered brand of Compucase Enterprise Other product and company names mentioned in this documentation may be brands or trademarks of their respective owners.

Compucase Enterprise reserves the right to make changes concerning the contents of the manual and the technical data of the product without previous announcement.

CE FC MSIP-REI-CEE-COUGAR390H All other registered trademarks belong to their respective companies.

MANUFACTURER CONTACT

Compucase Enterprise Co., Ltd.

No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, D.G.C.

Taiwan, R.O.C.

Tel:[phone]

Service E-Mail: [e-mail]

More information you will find at cougargaming.com

Compucase Enterprise Co., Ltd.

All rights reserved.
Made in China
