MODE D'EMPLOI W311MA Tenda
Plug-and-Play for ease of use
150 Mbps high-gain wireless network adapter
W311MA Plug-and-Play
Powered by a chip supporting Plug-and-Play, it is automatically installed as soon as being connected without a driver from a CD-ROM or the internet, enabling you to set up a wireless internet connection more easily.
It features an external high-gain omnidirectional antenna adjustable to signals for a longer transmission/reception distance and better signal stability, ensuring excellent gaming, movie, and music experience.
Compatible with various types of OS
It is applicable to devices running Windows XP, Windows 7, Windows 8, Windows 8.1, or Windows 10.
Product Specification
| HARDWARE FEATURES | |
| Interf ace USB2.0 | |
| Dimensions (W x D x H) 39.1mm×17.2mm×12.6mm (L x W x H) | |
| Ant enna Type 1* external antenna | |
| WIRE LESS FE A TURE S | |
| Wireless Standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | |
| Frequenc y 2.400~2.4835GHz | |
| Signal Rate | 11b: Up to 11Mbps(dynamic)11g: Up to 54Mbps(dynamic)11n: Up to 300Mbps(dynamic) |
| Trans mit Power <20dBm (EIRP) | |
| Wireless Modes | Station Mode |
| Wireless Security | 64/128-bit WEP,WPA-PSK / WPA2-PSK,WPA / WPA2 |
| Channel | 1~13 |
| OTHERS | |
| Package Contents | Wireless Adapter W311MA, QIG |
| System Requirements | windows10 (32/64bits),Windows 8.1(32/64bits), Windows 8(32/64bits), Windows7(32/64bits), Windows Vista(32/64bits),Windows XP(32/64bits) |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) |
| Storage Temperature: -40°C~70°C (-40°F~158°F) | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
| Related Products | F3、FH456、A9 |
Shenzhen Tenda Technology Co., Ltd.6-8 Floor, Tower E3, No. 1001,
Zhongshanyuan Road, Nanshan District,
Shenzhen, China. 518052
Tel: (86 755) 2765 7180 Fax: (86 755) 2765 7178
Email: sales@tenda.com.cn support@tenda.com.cn
Website: http://www.tendacn.com
Specifications are subject to change without notice. Copyright ©2015 SHENZHEN TENDA TECHNOLOGY CO.,LTD. All rights reserved. Tenda is the
trademark of SHENZHEN TENDA TECHNOLOGY CO., LTD. All other brand names mentioned herein are the trademark or registered trademarks of their
respective holders.Website: http://www.tendacn.com
Marque : Tenda
Modèle : W311MA
Catégorie : Carte réseau / adaptateur
