LANCIA
LANCIA k
1st Volume
Interior
In order to place the greatest emphasis on comfort, the interior fittings have been the subject of modifications.
The most apparent change involves the seats which have new foam and modified covers to guarantee comfort and give an improved wraparound effect.
CHARACTERISTICS AND TECHNICAL SPECIFICATIONS
There follows the main technical specifications of the Lancia k SW and saloon 96 range for the 5 engine types.
Other characteristics and technical specifications, in addition to the repair instructions are given in the specific Service Manual updates identified by print nos. 506.475/08, /14, /16 for the 96 range saloon and nos. 506.475/12 and/15 for the Lancia k Station Wagon.
LANCIA k 2.0 20v
| - Bodywork version code: | |
| Saloon Power Drive and Comfort Drive | 838 AG 1AA |
| Saloon Automatic Transmission | 838 AG 11A |
| Station Wagon Power Drive | 838 BG 1AA |
| - Engine marking | 838 A6.000 |
| - Total capacity (5 cylinder) | 1998 cc |
| - Max power CEE | 114 kW (155 CV) |
| - Corresponding speed | 6500 rpm |
| - Max torque CEE | 186 Nm (19,0 kgm) |
| - Corresponding speed | 4000 rpm |
| - Timing | T OHC |
| - Engine balancing | through 1 counter-balance shaft |
| - Fuel system | Bosch Motronic electronic injection |
| - Ignition | integrated with the electronic injection |
| - Type of fuel recommended | unleaded petrol (95 RON min) |
| - Top speed | |
| Saloon Power Drive (in 5th gear) | 212 km/h |
| Saloon Comfort Drive (in 4th gear) | 212 km/h |
| Saloon C.A. (in 4th gear) | 210 km/h |
| Station Wagon (in 5th gear) | 205 km/h |
C.A. = electronically controlled automatic transmission (AISIN)
IL49E6
LANCIA k 2.0 turbo
| - Bodywork version code: | |
| Saloon | 838 AB 1AA |
| Station Wagon | 838 BB 1AA |
| - Engine marking | 838 A4.000 |
| - Total capacity (4 cylinder) | 1998 cc |
| - Max power CEE | 151 kW (205 CV) |
| - Corresponding speed | 5600 rpm |
| - Max torque CEE | 298 Nm (30,4 kgm) |
| - Corresponding speed | 2750 rpm |
| - Timing | T OHC |
| - Engine balancing | through 2 counter balance shafts |
| - Fuel system | Bosch Motronic electronic injection and supercharging with GARRET turbocharger |
| - Ignition | integrated with the electronic injection |
| - Type of fuel recommended | unleaded petrol (95 RON min) |
| - Top speed: | |
| Saloon (in 5th gear) | 235 km/h |
| Station Wagon (in 5th gear) | 230 km/h |
LANCIA k 2.4 20v
| - Bodywork version code: | |
| Saloon | 838 AC 1AA |
| Station Wagon | 838 BC 1AA |
| - Engine marking | 838 A2.000 |
| - Total capacity (5 cylinder) | 2446 cc |
| - Max power CEE | 129 kW (175 CV) |
| - Corresponding speed | 6100 rpm |
| - Max torque CEE | 230 Nm (23,5 kgm) |
| - Corresponding speed | 3750 rpm |
| - Timing | T OHC |
| - Engine balancing | through 1 counter-balance shaft |
| - Fuel system | Bosch Motronic electronic injection |
| - Ignition | integrated with the electronic injection |
| - Type of fuel recommended | unleaded petrol (95 RON min) |
| - Top speed | |
| Saloon (in 5th gear) | 218 km/h |
| Station Wagon (in 5th gear) | 212 km/h |
LANCIA k 2.4 td
| - Bodywork version code: | |
| Saloon | 838 AH 1AA |
| Station Wagon | 838 BH 1AA |
| - Engine marking | 838 A7.000 |
| - Total capacity (5 cylinder) | 2387 cc |
| - Max power CEE | 91 kW (124 CV) |
| - Corresponding speed | 4000 rpm |
| - Max torque CEE | 265 Nm (27 kgm) |
| - Corresponding speed | 2000 rpm |
| - Timing | S OHC |
| - Engine balancing | through 1 counter-balance shaft |
| - Fuel system | indirect injection with electronically controlled pump and IHI turbocharger |
| - Type of fuel recommended | diesel |
| - Top speed | |
| Saloon | 193 km/h |
| Station Wagon | 190 km/h |
LANCIA k 3.0 V6 24v
| - Bodywork version code: | |
| Saloon | 838 AD 1AA |
| Saloon C.A. | 838 AD 11A |
| Station Wagon C.A. | 838 BD 11A |
| - Engine marking | 838 B.000 |
| - Total capacity (6 cylinder) | 2959 cc |
| - Max power CEE | 150 kW (204 CV) |
| - Corresponding speed | 6300 rpm |
| - Max torque CEE | 270 Nm (27,5 kgm) |
| - Corresponding speed | 4500 rpm |
| - Timing | T OHC for each cylinder head |
| - Fuel system | Bosch Motronic electronic injection |
| - Ignition | integrated with the electronic injection |
| - Type of fuel recommended | unleaded petrol (95 RON min) |
| - Top speed | |
| Saloon (in 5th gear) | 225 km/h |
| Saloon C.A. (in 4th gear) | 220 km/h |
| Station Wagon C.A. (in 4th gear) | 218 km/h |
C.A. = electronically controlled automatic transmission (AISIN)
Removing Disconnect
Refitting Connect
Dismantling Disassembly
Fitting Composition
Tighten to torque
Tighten to torque plus angle
Fully tighten
Stake nut
Adjustment Regulation
Visual inspection Check
Warning
Lubricate Grease
Replace Genuine spares
Bleed braking system
Work surface Machined surface
Interference Force fit
Distance to be measured Measurement -- Check Thickness - Clearance
Rolling torque
Inlet
Exhaust
Operation
Tolerance Difference in weight
Pre-loading
Rotation
Compression ratio
Selection Classes
Undersize Smaller than .... Idling
Number of revs
Ratio
Pressure
Temperature
Temperature <0°C Cold Winter
Temperature >0^ Hot Summer
Windscreen wiper with electric washer pump
Rearscreen wiper with electric washer pump
Engine
version: all versions
0000 0 000 AA
LANCIA k 98 RANGE
New aesthetic features and new engine types
00
05.98
OPERATIONS IN PRODUCTION
The new LANCIA k 98 range is distinguished through the introduction of the following improved features:
- new engine types;
- new aesthetic features;
- new optional equipment and higher specification level offered as standard.
New engine types
There are two new engine types fitted on the 98 range: a 2000 cc 5 cylinder, 20 valve turbo petrol version (2.0 turbo 20v) replacing the 2.0 turbo 16v and a 2400 indirect injection turbo Diesel version (2.4 JTD) replacing the 2.4 TD.
There follows a list of the main characteristics of these new engine types:
2.0 turbo 20v
- Engine marking 175A3.000
- Bodywork version code
- Saloon 838AM1AA 19
- Station Wagon 838BM1AA 20
- Coupé 838CM1AA 21
- Total capacity 1998 cc
- Number of cylinders 5 with 4 valves per cylinder
- Max. power CEE 162 kw (220 CV)
- At a speed of 5750 rpm
- Max. torque CEE 310 Nm (31,6 kgm)
- At a speed of 2500 rpm
- Timing TOCH with phase transformer
- Fuel system .... Bosch sequential timed electronic injection Motronic M 2.10.4 with turbocharger
- Ignition ...... electronic, static advance, integrated with the injection
- Top speed
- Saloon 243 kph
- Station Wagon 235 kph
- Coupé 243 kph
