Type de produit	Graveur Blu-ray portable (Super Multi Blue)
Dimensions (L x H x P)	160 x 22 x 153 mm
Poids	380 g
Interface	USB 2.0
Taille du tampon	4 Mo (avec prévention de sous-utilisation)
Formats de disque pris en charge	BD (BDXL), DVD (DVD±R, DVD±RW, DVD-RAM), CD (CD-R, CD-RW), M-DISC
Vitesse d'écriture BD-R (SL/DL)	6x CAV max
Vitesse d'écriture BD-R (TL/QL)	4x (TL), 6x (QL) ZCLV/CAV
Vitesse d'écriture DVD±R (SL)	8x CAV max
Vitesse d'écriture CD-R	24x ZCLV max
Vitesse de lecture BD-ROM	6x CAV max
Vitesse de lecture DVD-ROM	8x CAV max
Vitesse de lecture CD-ROM	24x CAV max
Lecture Blu-ray 3D	Oui
Technologie Silencieuse	Silent Play (réduction du bruit)
Lecture sans saut	Jamless Play (correction des disques endommagés)
Revêtement anti-rayures	Oui (UV Coating)
Compatibilité Mac	Oui
Systèmes d'exploitation supportés	Windows 7, Windows Vista, Windows XP
Conformité	RoHS, FCC, CE, etc.
Alimentation	Via USB (bus-powered)
Entretien	Nettoyer avec un chiffon doux et sec.

FOIRE AUX QUESTIONS - BP40NS20 LG

Ce lecteur peut-il lire des Blu-ray 3D ?

Oui, le LG BP40NS20 prend en charge la lecture des Blu-ray 3D.

Quels formats de disque puis-je graver avec ce lecteur ?

Il peut graver des BD (y compris BDXL), DVD (DVD±R, DVD±RW, DVD-RAM), CD (CD-R, CD-RW) et M-DISC.

Le lecteur est-il compatible avec les ordinateurs Mac ?

Oui, il est compatible Mac.

Dois-je installer un logiciel pour utiliser ce lecteur ?

Sous Windows, il est généralement reconnu automatiquement. Un logiciel de gravure peut être nécessaire pour certaines fonctionnalités.

Quelle est la vitesse maximale d'écriture pour un DVD ?

La vitesse maximale d'écriture pour un DVD±R simple couche est de 8x CAV.

Le lecteur peut-il lire des disques endommagés ?

Grâce à la technologie Jamless Play, il peut contourner les parties endommagées pour une lecture plus fluide.

Est-il possible de lire des CD audio avec ce lecteur ?

Oui, il lit les CD audio et peut les extraire à 24x.

Quel est le poids du lecteur ?

Le LG BP40NS20 pèse environ 380 g.

Le lecteur nécessite-t-il une alimentation externe ?

Non, il est alimenté via le port USB, aucun adaptateur secteur n'est nécessaire.

Quelle est la capacité maximale des disques BD-XL supportés ?

Le lecteur supporte les disques BD-XL quadruple couche jusqu'à 128 Go.

MODE D'EMPLOI BP40NS20 LG

Blu-ray™ Disc Rewriter

Illustration of a CD-ROM with a 3D logo floating above Earth and space debris (no text or symbols)

DVDBLU-RAY DISC

CD

6x8x2x 4x 6x 6x8x6x

SD-R(S)/DI SD-RF MAX ROB(TI) ROB(TI) SD-ROM MAX WRITE WRITE MAX WRITE MAX READ MAX READ

5x 8x 6x 4x 8x

DVD+R DVD+RW DVD+RW DVD+RAM DVD+ROM DVD+R CI MDISC MDISC MAX WRITE MAX WRITE MAX WRITE MAX WRITE MAX READ MAX WRITE MAX WRITE MAX READ

24×24×24×

CDR CDRW CDROW MAXWRITE MAXWRITE MAXREAD

Super Multi Blue Slim Portable with 3D Blu-ray Disc Playback & M-DISC™ Support

The LG Super Multi Blue BP40NS20 slim portable Blu-ray rewriter features USB 2.0 connectivity with a 6x BD-R write speed. Simply plug in and record up to 128GB of files, photos, or business documents onto a BD-XL(quadruple) disc. With Blu-ray, DVD and CD burning capabilities, the BP40NS20 gives you the option to choose the media best suited for each task.

EXTERNAL CONNECTS VIA USB 2.0

SILENT PLAY

Reduces noise from disc spin during movie playback

SUPPORTS 3D BLU-RAY DISC PLAYBACK

SUPPORTS BD-XL (128GB, QUADRUPLE) DISC

ANTI-SCRATCH UV COATING

MAC COMPATIBLE

JAMLESS PLAY

Smooths out playback of damaged Blu-ray or DVD discs

6X BDR READ AND WRITE CAPABILITY

MAX. 6X DVD±R WRITE SPEED

BLU-RAY DISC (INCLUDING BDXL), DVD (INCLUDING M-DISC & DVD-RAM), AND CD FAMILY READ/WRITE COMPATIBLE

4MB BUFFER UNDER-RUN PREVENTION

FUNCTION EMBEDDED

RoHS COMPLIANT

MODISC

THE SUPER MULTI BLUE ADVANTAGE

Multi Blue Compatibility

LG Super Multi Blue optical drives can read and write four types of disc formats in one convenient package:

1. DVD+R
2. RW DVD-R
3. RW DVD-RAM
4. Blu-Ray Disc

This gives you the option to choose the media best suited for each task.

Blu-Ray

Blu-ray Disc is the next generation in optical storage, offering 25GB and 50GB of storage capacity on a disc.

BDXL™

The BDXL format supports high-capacity blu-ray discs (up to 128GB write-once discs) for users that need to store a large amount of data.

M-DISC™

Compared to other recordable DVDs on the market today, M-DISC offers superior reliability in data storage that provides the permanent optical data storage solution.

Silent Play

As a disc is being read, Silent Play technology automatically controls the disc read speed for optimal noise reduction.

Jamless Play

A damaged disc can cause interruptions during movie playback. Jamless play technology automatically skips past damaged parts of a disc to maintain smooth playback while reducing interruptions.

LGsolutions.com

LG

Life's Good

LG Electronics U.S.A., Inc.

HE B2B Division

2000 Millbrook Drive

Lincolnshire, IL 60069

Customer Service: 888.865.3026

www.LGsolutions.com/support

Contact your LG Regional Sales Representative:

Hospitality: 800.228.1236

Channel: 800.897.8871

E-mail: [e-mail]

SPEC_BP40NS20_031221_PR

TECHNICAL SPECIFICATIONS

TYPE Portable Blu-ray Disc Rewriter
TRANSFER RATES-WRITE (MAX)	BD-R (SL) 2x CLV, 4x PCAV, 6x CAV
	BD-R(DL) 2x CLV, 4x PCAV, 6x CAV
	BD-R (TL) 2 z CLV, 4x ZCLV
	BD-R (TH) 2x CLV, 4x PCAV, 6x CAV
	BD-RE (SL/DL/TL) 2x CLV / 2X CLV / 2x CLV
	DVD-R (SL/DL) 2x CLV, 4x PCAV, 8x CAV/ 2x CLV 4x, 6x ZCLV
	DVD+R(SL/DL) 2.4x CLV, 4x PCAV, 8x CAV/ 2.4x CLV, 4x, 6x ZCLV
	DVD-RW 1x, 2x CLV, 4x, 6x ZCLV
	DVD+RW 2.4x, 3.3x CLV, 4x ZCLV, 8x ZCLV disc: 3.3x, 8x)
	DVD-RAM 2x, 3x ZCLV, 5x PCAV(Ver.2.2) (16x disc: No support)
	M-DISC 2.4 CLV, 4x PCAV
	CD-R 10x CLV, 16x, 24x ZCLV
	CD-RW 4x, 10x CLV, 16x, 24x ZCLV
TRANSFER RATES - READ (MAX)	BD-ROM(SL/DL) 6x CAV / 6x CAV
	BD-R (SL/DL/TL) 6x CAV / 6x CAV / 6x CAV
	BD-R (TH) 6x CAV max.
	BD-RE(SL/DL/TL) 6 x CAV / 6x CAV / 2x CLV
	BD-MV 4.8x CAV max.
	DVD-ROM 8x CAV max.
	DVD-R (SL/DL) 8/ 8x CAV
	DVD+R(SL/DL) 8/ 8x CAV
	DVD-RW 8x CAV max.
	DVD+RW 8x CAV max.
	DVD-Video (CSS Compliant) 4x CAV max.
	DVD-RAM (Ver.2.2) 2, 3x ZCLV, 5x PCAV
	M-DISC 8x / 8x CAV
	CD-R/RW/ROM 24x CAV max.
	CD-DA(Ripping/Audio Play)24x CAV/ 10x CAV
OTHER FEATURES	Silent PlayJamless Play
ACCESS TIME (1/3 STROKE)	BD-ROM 260ms typ.
	DVD-ROM 270ms typ.
	DVD-RAM 240ms typ.
	CD-ROM 260ms typ.
SUSTAINED RATE	BD-ROM 143.86 Mbits/s (6x) max.
	DVD-ROM 11.08 Mbytes/s (8x) max.
	CD-ROM 3,600 kB/(24x) max.
BURST TRANSFER RATEUSB 2.0 480 Mbps
BUFFER SIZE	4MB Buffer Under-run prevention function embedded
HOST INTERFACE	External (Host) USB 2.0480Mbits/s)
	Internal (Drive) ATAB ACS Revision 6INF-8090i Ver. 7 Rev 1.21INCITS xxx T10/1675D Revision 4
COMPLIANCE	RoHS
	Safety UL: UL 60950-1 First Edition
	C-UL: CSA C22.2 No. 60950-1-07 Second Edition
	TÜV: EN 60950-1 / EN60825-1
	SEMKO: EN 60950-1 / EN60825-1
	EMC CE Marking, C-Tick Mark, BSMI, VCCI, KCC, FCC Part 15 Class B Digital Device, ICES-003 Digital Apparatus
	Laser Safety Class 1 laser product comply with DHHS rules 21 CFR Subchapter J Class 1 laser product to EN60825-IEC 60825-1

OPERATING SYSTEMS Windows 7, Windows Vista™, Windows XP

SYSTEM REQUIREMENTSCPU: Intel Pentium D 3.2GHz or Higher (with USB 2.0)

Recommended: Intel Pentium 4 Core 2 Duo P8600 2.4GHz or higher

HDD: 30GB or more of available space (60GB for Blu-ray Disc authoring)1

RAM: 1GB or Higher

HDD: 60GB or more of available space

BD Movie Playback: CPU: Following CPU recommended -Intel: E6400 or higher

Graphic Card: Card recommended with following GPU(Graphic Processing Unit)-nVidia: GeForce 7600GT or higherGeForce B400 or higher-ATI: ATI Radeon HD 2400 or higherGraphic Card Driver shall meet AACS compliance criteria.

DIMENSIONS (W x H x Dφ.29" x 0.86" x 6.02" (160 x 22 x 153mm)
WEIGHT 0.8lbs (380g)

Dimensions and weights are approximate. Design, specifications, and features subject to change without notice.
